Anker Technology R2220 Roav DashCam C2 Pro User Manual
Anker Technology Co., Limited Roav DashCam C2 Pro
User Manual
Owner’s Manual
Roav DashCam C2 Pro
Model: R2220
51005000800 V01
Table of Content
Safety Instructions 01
At a Glance 01
Inserting Memory Card 02
Installing Your DashCam 03
Connecting to Power 05
Downloading Roav App 06
Using Your DashCam 07
System Setup 09
Specifications 11
FAQ 12
Notice 13
01
Safety Instructions
Please read and understand all instructions before using
this product. If damage is caused by failure to follow the
instructions, the warranty does not apply.
• Keep these instructions.
• Do not drop, puncture or disassemble this product.
• This product shall not be exposed to dripping or splashing.
• Avoid long exposure to direct sunlight, which may cause damage.
• Exposing this product to open flames may cause explosion.
• Use original accessories only.
• Do not install this product where it will block the driver’s view
of the road or the deployment of the airbag.
• Keep your attention on the road. Do not operate the controls
of this product while driving.
• Ensure the camera lens is kept clean and there is nothing
blocking the lens.
• Setup time and date accurately before using this product.
• Do not use the charger if the cord is damaged or broken.
• Remove this product from your vehicle when not in use for a
long period.
• Keep out of reach of children.
• Use clean, soft cloth to clean. Do not use any corrosive
cleaner/oil to clean.
• The Company is NOT responsible for the loss of any data/
content during operation.
Owner’s Manual
DASHCAM C1
DashCam GPS Suction mount
Charging cable Crowbar
Car charger
Mount
Manual
02 03
Inserting Memory Card
Do not remove or insert microSD / TF card when this
product is powered on, which may damage the card.
For reliable operation, use a Class 10, 32GB microSD / TF card. For
a 64GB/128GB card, format it before using. It is
recommended to
format the card regularly.
Card Capacity 1080P 30FPS 720P 60FPS 720P 30FPS
32 GB 320 min 360 min 480 min
64 GB 640 min 720 min 960 min
128 GB 1280 min 1440 min 1920 min
Insert a microSD / TF card with the gold contacts facing
the screen side of the DashCam. Push the card until it
clicks into place.
To remove the card, gently push its top edge inward until it
clicks, and then pull it out of the slot.
At a Glance
Camera lens
Air vent
Power button
Memory card slot
Speaker
LED indicator
• Flashing blue: recording in progress
• Steady red: no recording status
Micro USB charging port
Buttons
LCD screen
04 05
Installing Your DashCam
• Never install this product while driving.
• Install this product near the rear-view mirror to obtain
the best open-field view. Do not install in a location
that will obstruct your required driving view.
• Make sure that the lens is within the wiping range
of the windscreen wiper to ensure a clear view even
when it rains.
• Do not touch the lens with your fingers. Finger grease
may be left on the lens and will result in unclear videos.
• The mount is adhesive and may be destroyed if it is
removed from the windshield.
Attach the DashCam onto the mount.
Select a location on the windshield near the bottom right
corner of the rear-view mirror, clean with clear water and
wait until fully dry.
Remove 3M adhesive sticker and firmly ax the mount onto
the windshield. Alternatively, cover the suction mount onto
the windshield and rotate the lock as indicated.
Use the crowbar to press and hide the charging cable
into the seams and weatherstrips around the edge of the
dashboard.
Adjust the lens viewing angle to ensure that it is aligned
with the road ahead, then rotate the fixing knob to fasten.
06 07
Connecting to Power
Connect the car charger and DashCam by using the charging cable.
(*
When using the GPS suction mount, plug the micro-USB cable
attached to it into the DashCam first, then connect the car charger
and the GPS suction mount by using the charging cable.
)
Plug the other end of the car charger to your vehicle’s cigarette
lighter socket.
T
Once the car engine is started, DashCam will automatically
power on and start recording. Once the car engine is shut
down, DashCam will automatically save the recording and
turn o.
Downloading Roav App
Download the Roav app from the App Store or Google Play.
Connect DashCam with Smartphone
When successfully connected with your smartphone via
built-in Wi-Fi, you can save and playback the driving recording
videos on your smartphone. You can also change settings of
the DashCam via Roav app.
When successfully connected, DashCam stops recording.
Press (Menu) , select "WIFI" > "On" to enable WiFi on
DashCam.
Enable WiFi on your smartphone, find “Roav DashCam
C2 Pro” on the list and connect it, enter password (initial
password: goroavcam) if required.
Follow the instructions on your smartphone to complete the
connection.
08 09
Using Your DashCam
As a driver, you have full responsibility to drive safely and adhere
to all applicable trac regulations.
Record Videos
When connected to a car charger, DashCam automatically
starts recording and a red dot flashes on the screen. The
current recording duration is displayed, and the current date
and time is displayed.
To enable / disable the audio recording, press .
Protect the Current Recording
By default, DashCam uses a sensor to automatically detect
accidental collisions and protect the video file with duration
of 30 seconds, and is displayed. This indicates that those
recordings have been locked and will not be overwritten by new
video clips.
To protect the current recording manually, press .
Playback Videos
The DashCam stops recording while viewing videos or settings.
Press to view all saved videos.
Select a video to playback.
Button Virtual Button Function
Back to previous menu
Lock Current / Unlock
Current
Delete Current / Delete All
Play / Pause
10 11
System Setup
To adjust DashCam’s settings, Press .
Menu Options Description Available Options
Resolution Set a desired video
resolution.
720P 60FPS / 720P
30FPS / 1080P 30FPS
Night Vision
Enhancement
Adjust the brightness to
enhance night vision.
Licence plate mode
/Panorama mode/
Balance mode
Driving
Collision
Detection
Sensitivity for gravity helps
to detect vibration and
shock while driving and
makes DashCam to respond
appropriately.
Low / Medium /
High / O
Parking
Collision
Detection
Enable to keep DashCam in
standby mode. Motion will
be detected for 15 times and
DashCam starts recording a
30 second video each time.
Low / Medium/
High / O
Time Setup Set date and time
Press to adjust
the value, press to
next option, press
to save
Language Set on-screen display menu
language.
English / Deutsch /
日本語 / 简体中文
/繁体中文/Español
/ Italiano / Français
LCD Auto O Turn o the screen backlight
after a period of inactivity.
30 Seconds / 60
Seconds / O
Loop Recording Set the duration of each
recording video clip.
1 Minute / 3 Minutes
/ 5 Minutes / 10
Minutes
Machine Sound
Button Sound / Voice
prompts / Power On/O
Sound
On / O
GPS
Enable / disable GPS
positioning module to
record the complete
driving path.
On / O
WiFi Connect with smartphone. On / O
Format
Format the memory card and
all the data will be deleted.
Cancel / OK
Water Mark Display / hide logo / date /
GPS speed. On / O
Default Reset all options to the
default settings. Cancel / OK
Frequency
Match the video frequency of
DashCam with the electrical
frequency of your location.
50 Hz (EU / China) /
60 Hz (US)
About Check the current version
number.
Button Virtual Button Function
Back to recording mode
12 13
Toggle the previous setting
Toggle the next setting
Click to confirm a selection
Specifications
Specifications are subject to change without notice.
Screen: 3” LCD color TFT (960 x 240)
Camera sensor: Sony Exmor IMX 291
Camera lens: wide-angle lens 145°
Chipset: Ambarella A12
Power input: 5V 1A
Max video resolution: 1080P 30FPS (1920x1080)
Video clip format: .MP4
Battery capacity: 470mAh
Operating temperature range: -20°C to 70°C / -4°F to 158°F
Operating temperature range: 0°C to 70°C / 32°F to 158°F
(Parking monitor)
Weight: Approx. 110 g / 3.6 oz
Size: 99*30*55 mm / 3.9*1.2*2.2 in
FAQ
Can not record?
• Check if the memory card is inserted properly and there is
enough free capacity.
• Check the battery level.
Blurred image?
• Use a clean, soft lens-cleaning cloth to gently clean the
lens.
Malfunction or crash?
• Press and hold the POWER button for at least 8 seconds.
Blank screen?
• The screen saver is activated. Change settings to “O” if
required.
How to enable parking monitor?
• Press , select “Parking Monitor” > “ON”.
Worry about the memory card is full?
• Continuous loop recording allows to overwrite the old
unlocked files.
14 15
This device complies with Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the device."
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement."
Notice
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept
any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved
by the party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures: (1)
Reorient or relocate the receiving antenna. (2) Increase the
separation between the equipment and receiver. (3) Connect
the equipment into an outlet on a circuit different from that to
which the receiver is connected. (4) Consult the dealer or an
experienced radio / TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
12-month limited warranty
Lifetime technical support
support@goroav.com
+1 (800) 988 7973 (US) Mon-Fri 9:00 - 17:00 (PT)
Live Chat on Roav app and website
@GoRoav @GoRoav
