Apple E2599A Cellular Phone with Bluetooth and WLAN radios User Manual RF Exposure iPhone 5
Apple Inc. Cellular Phone with Bluetooth and WLAN radios RF Exposure iPhone 5
Apple >
Contents
RF Exposure Info
10/5/12 10:25 AMRF Exposure - iPhone 5
Page 1 of 2http://www.apple.com/legal/rfexposure/iphone5,1/en/
iPhone has been tested and meets applicable limits for Radio Frequency (RF) exposure.
Specific Absorption Rate (SAR) refers to the rate at which the body absorbs RF energy. SAR limits are 1.6 Watts per kilogram (over a
volume containing a mass of 1 gram of tissue) in countries that follow the United States FCC limit and 2.0 W/kg (averaged over 10
grams of tissue) in countries that follow the Council of the European Union limit. During testing, iPhone radios are set to their highest
transmission levels and placed in positions that simulate use against the head, with no separation, and near the body, with 10mm
separation.
To reduce exposure to RF energy, use a hands-free option, such as the built-in speakerphone, the supplied headphones or other
similar accessories. Carry iPhone at least 10mm away from your body to ensure exposure levels remain at or below the as-tested
levels. Cases with metal parts may change the RF performance of the device, including its compliance with RF exposure guidelines, in a
manner that has not been tested or certified.
Although this device has been tested to determine SAR in each band of operation, not all bands are available in all areas. Bands are
dependent on your service provider’s wireless and roaming networks.
Band Transmit
Frequency
FCC 1g SAR
Limit (W/kg)
Body Head
GSM 850
UMTS V 850
CDMA 800 (BC 0)
LTE Band 5
824–849 1.6 1.04 0.972
GSM 1900
UMTS II 1900
CDMA 1900 (BC 1)
LTE Band 2
1850–1910 1.6 1.18 1.18
BC10 817-823 1.6 0.876 0.925
LTE Band 13 777-787 1.6 0.645 0.616
LTE Band 17 704-716 1.6 0.547
LTE Band 3 1710-1785 1.6 1.12
LTE Band 4 1710-1755 1.6 1.18 1.25
LTE Band 25 1850-1915 1.6 1.18
UMTS 2100 1920-1980 1.6 0.907
2.4 GHz Wi-Fi 2400–2483.5 1.6 0.198 0.572
5150-5250
5250-5350
1.6
1.6
0.13
0.114
0.594
0.575
1
3
3
10/5/12 10:25 AMRF Exposure - iPhone 5
Page 2 of 2http://www.apple.com/legal/rfexposure/iphone5,1/en/
1. FCC OET Bulletin 65, Supplement C (Edition 01-01) & IEEE 1528-2003, & Canada RSS 102, Issue 4, March 2010.
2. European Council Recommendation of 12 July 1999 on the Limitation of Exposure of the General Public to Electromagnetic Fields [1999/519/EC].
3. Only in Korea; Head measurements only for these bands, per KCC regulation. 대한민국에만 적용: 방송통신위원회(Korean Communication Commission) 지침에 따라 해당 대역대(주파수)에서는 머리만
측정
4. Australia Only
5 GHz Wi-Fi 5250-5350
5500-5700
5725-5850
1.6
1.6
1.6
0.114
0.089
0.067
0.575
0.593
0.593
Band Transmit
Frequency
EU 10g SAR
Limit (W/Kg)
Body Head
UMTS 850 824-849 2.0 0.625 0.493
EGSM 900
UMTS 900 880–915 2.0 0.951 0.747
GSM 1800
LTE Band 3 1710–1785 2.0 0.824 0.453
UMTS 2100
LTE Band 1 1920–1980 2.0 0.611 0.901
2.4 GHz Wi-Fi 2400–2483.5 2.0 0.103 0.349
5 GHz Wi-Fi 5150-5350
5500-5700
2.0
2.0
0.081
0.109
0.485
0.556
2
4
