Argox Information Co SDMN 802.11B/G/N SDIO Module with Antenna Connectors User Manual ARGOX SDM 802 11 BGN

Argox Information Co Ltd 802.11B/G/N SDIO Module with Antenna Connectors ARGOX SDM 802 11 BGN

Contents

user manual

1
802.11B/G/NSDIOModulewithAntennaConnectors
ARGOXSDM802.11BGN
WLANModule
UserManual
2

ARGOXSDM802.11BGNWLANModule
ProductSpecification
Model#:ARGOXSDM802.11BGNWLAN
Module
IEEE802.11b/g/ncompliant
Features:
‐ CoreIC:SummitSSD‐40L
‐ IEEE802.11b/g/ncompliant 
‐ designedformobiledevices
‐ supportsWPA/WPA2/WEP64‐bit&128‐bit
encryption
‐ w/oAntenna
‐ Dimension:19.5x18.4x3.5mm
‐ SDIOinterface

3
Contents
PinDefinition   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 4
Specification    ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 5~8
BlockDiagram   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 9
Description    ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 9
4
PinDefinition
PinNo.PinNamePinNo.PinName
1 V3P3 11 BT_STATE
2 SD_DATA0 12 WLAN_ACTIVE
3 SD2_DATA1 13 BT_FREQ
4 SD2_DATA2 14 GND
5 SD2_DATA3 15 LED_IN
6 V3P3 16 LED_IN
7 GND 17 SD2_CMD
8 GND 18 SD2_CLK
9 NC
10 BT_PRIORITY
5
SpecificationsTable
Feature Description
Physical Interface 0.62 mm pitch LGA (land grid array) (0.62 GSP)
Wi-Fi Interface 1-bit or 4-bit Secure Digital I/O
Antenna Interface Single antenna port (when mounted on an MSD40L board)
Chip Set Broadcom BCM4319
Input Voltage Requirements 3.3 VDC ± 10% (core)
I/O Signaling Voltage 1.8/3.3 VDC ± 10%
Current Consumption
(At maximum transmit power setting)
802.11b (16 dBm output power)
Transmit: 294 mA (970 mW)
Receive: 40 mA (132 mW)
Standby: TBD mA (TBD mW)
802.11g (13 dBm output power)
Transmit:275 mA (908 mW)
Receive: 40 mA (132 mW)
Standby: TBD mA (TBD mW)
802.11n (12 dBm output power) (20-MHz channel)
Transmit: 255 mA (842 mW)
Receive: 40 mA (132 mW)
TBD mA (TBD mW)
Operating Temperature -20° to 70°C (-4° to 158°F) (SDIO)
Operating Humidity 10 to 90% (non-condensing)
Storage Temperature -30° to 85°C (-22° to 185°F)
Storage Humidity 10 to 90% (non-condensing)
Maximum Electrostatic Discharge ± 2 kV
Length
Note: Length, width, and thickness
measurements include the metal shielding.
10 mm (0.39”)
Width 10 mm (0.39”)
Thickness 1.3 mm (0.05”)
Mounting See “Mounting” section for more information
Wireless Media Direct Sequence-Spread Spectrum (DSSS)
Orthogonal Frequency Divisional Multiplexing (OFDM)
Media Access Protocol Carrier sense multiple access with collision avoidance
(CSMA/CA)
6
Network Architecture Types Infrastructure and ad hoc
Network Standards IEEE 802.11b, 802.11d, 802.11e, 802.11g, 802.11i, 802.11n
Data Rates Supported 802.11b (DSSS) 1, 2, 5.5, 11 Mbps
802.11g (OFDM) 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (OFDM, MCS 0-7) 6.5, 7.2, 13.0, 14.4, 19.5, 21.7, 26.0,
28.9, 39.0, 43.3, 52.0, 57.8, 58.5, 65.0, 72.2 Mbps
Modulation BPSK @ 1, 6, 6.5, 7.2 and 9 Mbps
QPSK @ 2, 12, 13, 14.4,18, 19.5 and 21.7 Mbps
CCK @ 5.5 and 11 Mbps
16-QAM @ 24, 26, 28.9, 36, 39 and 43.3 Mbps
64-QAM @ 48, 52, 54, 57.8, 58.5, 65, and 72.2 Mbps
802.11n Spatial Streams 1 (Single Input, Single Output)
2.4 GHz Frequency Bands ETSI
2.4 GHz to 2.483 GHz
FCC
2.4 to 2.483 GHz
MIC (Japan) (formerly TELEC)
2.4 GHz to 2.495 GHz
KCC
2.4 GHz to 2.483 GHz
2.4 GHz Operating Channels ETSI: 13 (3 non-overlapping)
FCC: 11 (3 non-overlapping)
MIC (Japan): 14 (4 non-overlapping)
KCC: 13 (3 non-overlapping)
Transmit Power Settings
Note: Maximum transmit power varies
according to individual country regulations. All
values nominal, +/-2 dBm
802.11b
16 dBm (40 mW)
802.11g
13 dBm (20 mW)
802.11n
12 dBm (16 mW)
7
Typical Receiver Sensitivity
Operating Systems Supported Windows Mobile 6.5
Windows Mobile 6.1
Windows Mobile 6.0
Windows Mobile 5.0
Windows Embedded CE 6.0 R3
Windows Embedded CE 6.0 R2
Windows Embedded CE 6.0
Windows Embedded CE 5.0
Security Standards
　 Wireless Equivalent Privacy (WEP)
　 Wi-Fi Protected Access (WPA)
　 IEEE 802.11i (WPA2)
Encryption
　 Wireless Equivalent Privacy (WEP, RC4 Algorithm)
　 Temporal Key Integrity Protocol (TKIP, RC4 Algorithm)
　 Advanced Encryption Standard (AES, Rijndael Algorithm)
Encryption Key Provisioning
　 Static (40-bit and 128-bit lengths)
　 Pre-Shared (PSK)
　 Dynamic
802.1X Extensible Authentication Protocol Types
　 EAP-FAST
　 EAP-TLS
　 EAP-TTLS
8
　 PEAP-GTC
　 PEAP-MSCHAPv2
　 PEAP-TLS
　 LEAP
Compliance
Note: These agency approvals are pending.
ETSI Regulatory Domain
EN 300 328
EN 301 489-1
EN 301 489-17
EN 301 893
EN 60950-1
EU 2002/95/EC (RoHS)
FCC Regulatory Domain
FCC 15.247 DTS – 802.11b/g/n (Wi-Fi) – 2.4 GHz & 5.8 GHz
FCC 15.407 UNII – 802.11a (Wi-Fi) – 2.4 GHz & 5.4 GHz
Industry Canada
RSS-210 – 802.11a/b/g/n/n (Wi-Fi) – 2.4 GHz, 5.8 GHz, 5.2
GHz, and 5.4 GHz
Certifications Summit will be pursuing Wi-Fi Alliance and CCX certifications for
this radio in the near term.
Warranty One-Year Warranty
All specifications are subject to change without notice
lectrical Specifications
9
Description
ARGOX‐SDM‐802.11BGNWLANmoduleisdesignedwithSummitSSD‐40LwirelessLANmoduleIC
whichcompliantwithIEEE802.11b/g/nstandard.ItalsosupportsWPA/WPA2/WEP64‐bit&128‐bit
encryptionandexternalantennamustbeappliedtothemoduleviaJ1connector.Itcommunicateswith
hostdevicebySDIOinterfaceandexternal3.3Vdcpowermustbesuppliedtothemodule.
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to
operate the equipment.
Labeling requirements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
RF exposure warning
This equipment must be installed and operated in accordance with provided instructions and must not be
co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must
be providing with antenna installation instructions and transmitter operating conditions for satisfying RF
exposure compliance.
10
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20cm may
be maintained between the antenna and users. The final end product must be labeled in a visible area with the
following: "Contains FCC ID: NBF-SDMN”
Information for the OEMs and Integrators
The following statement must be included with all versions of this document supplied to an
OEM or integrator, but should not be distributed to the end user.
1) This device is intended for OEM integrators only.
2) Please see the full Grant of Equipment document for other restrictions.
This radio transmitter FCC ID: NBF-SDMN has been approved by FCC to operate with the antenna types listed below with the
maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this
list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Antenna List
No. Manufacturer Part No. Antenna Type Peak Gain
1 Ji-Haw 69-70002-001 PIFA 3.48 dBi for 2.4 GHz
2 Ji-Haw 69-70003-001 PIFA 3.23 dBi for 2.4 GHz
3 LYNwave ALB120-052020-150052 PIFA 2.70 dBi for 2.4 GHz
4 Wgt AQ060WIPI01+A PIFA 4.36 dBi for 2.4 GHz
5 Aristotle Enterprises 69-70003-006 PIFA 3.40 dBi for 2.4 GHz
Note: The antenna connector is I-pex type.
Hosted Information
The “PA-6030” is a test-hosted board for Argox Information Co., Ltd. “ARGOX-SDM-802.11 BGN” RF module.
The hosted board manufacture and model name is Argox Information Co., Ltd. / PA-6030, PT-9130-1-1, PT-9230-1-1,
PT-9132-0-0, PT-9232-0-0
1. Hardware Setup
a.) The RF module need to soldered on the test-hosted board.
11
The ARGOX-SDM-802.11 BGN has received Limited Module Approval (LMA) from FCC. This is because the
ARGOX-SDM-802.11 BGN does not have a built-in +3.3V regulator circuit. Argox Information Co., Ltd.
recommends that customers follow the +3.3V supply voltage requirements given in this data sheet.
If the power supply recommendations are followed, then customers will not need to go through formal certification of
the product for WiFi related RF behavior for FCC. It is the product manufacturers responsibility to make sure that the
power supply recommendations is followed, and that the RF behavior meets the certification requirements when the
module is installed in the final product.
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或
變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善
至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫
療用電波輻射性電機設備之干擾。
本模組於取得認證後將依規定於模組本體標示審驗合格標籤，並要求最終產品平台廠商
(OEM Integrator)於最終產品平台(End Product)上標示” 本產品內含射頻模組，
其NCC 型式認證號碼為:CCXXxxYYyyyZzW
RF Module
