Ascensia Diabetes Care US CGMM01 CGMM01 User Manual
Bayer HealthCare Diabetes Care CGMM01
User Manual
CGM Quick Reference Guide
Power/back button
Front buttons
USB plug
Home screen
Test strip port USB cap
CGM System: Monitor Features
CGM System: Monitor Charging
Charge your monitor every day.
1. Remove the protective cap from the
USB plug on the monitor.
2. Insert the monitor's USB plug into
the wall adapter.
3. Plug the wall adapter into an outlet.
- The orange light on the test strip
port will blink while it is charging.
- The light will turn off after it has
a full charge.
CGM System: Pairing the Monitor and Transmitter
1. Press and hold the power/back button
for 2 seconds to turn on the monitor.
2. Lift to remove the fully charged
transmitter from its charging unit.
3. Wait for the monitor to find the
transmitter (it may take as long as
one minute).
5. Wait for the monitor to connect to
the transmitter.
4. Use the UP and DOWN buttons to
find the number on the monitor
screen that matches the number on
the top of the charged transmitter,
and press OK.
1
2
Warnings:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
CGM Quick Reference Guide
270
75
11:32 AM 1:32 PM mg/dL
118
3
4
CGM System: Wearing a Sensor
Use the monitor screens to help guide you.
1. Remove the sensor guide from its
sterile packaging and insert the
transmitter into its slot in the
sensor guide.
2. Turn the sensor assembly over and
remove the adhesive liner before
putting the sensor assembly on
your skin.
3. Insert the sensor (a CLICK sound
means the sensor was inserted).
Once you have inserted a new sensor, you must wait 1 hour for the sensor to
stabilize before you can calibrate it.
CGM System: Calibrating a Sensor
In order for the monitor to properly display your glucose levels, it must be calibrated
with fingertip testing at least every 12 hours.
1. Choose to calibrate now or later.
- If you are ready to calibrate,
press YES and insert a test trip.
2. After performing a prick of the tip of
your finger, touch the tip of the test
strip to the drop of blood and hold it
there until the monitor beeps and
shows "Accepted"
3. Read your fingertip test result.
- If you want to use this result to
calibrate your monitor, press YES.
If you do not wish to use it to calibrate,
press NO.
4. Your continuous glucose reading will
appear on the Home screen within 5
minutes of calibrating.
Warnings:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
