Before using the GPS, read the user manual attached in the package and check whether or not spare
parts are attached. Feel free to contact your retailer if you do not well find the spare parts or have
questions or problems at the time of operation.
Packing list
Before using the GPS, check all the following items are present and in good condition. If any of the
items is damaged or missing, contact your retailer immediately.
9 GPS x 1
9 Car Adapter x 1
9 USB Cable x 1
9 Stylus x 1
9 Mount Bracket x 1
9 Mount Cradle x 1
9 User Manual x 1
9 Quick Start Guide x 1
Navigation Function
The unit is designed to provide you with route suggestions. It supports voice navigation.
Other Special Functions
¾ SD Card and USB Input
The unit is designed with SD card and USB ports and can be connected to SD card or other
USB device for file loading.
¾ 2 GB Flash Storage
Built-in 2G Flash Storage can store map data.
¾ Power Adapter Switch
Automatically adapts to voltage requirements in U.S and other countries.
¾ Supporting file formats
MP3 and WMA Format files
vii
Global Positioning System
Notes and Cautions
Note and Caution in this manual are highlighted with graphics as below to indicate important
information.
Note Contains information that corresponds to a specific topic.
Caution
Represents essential steps, actions, or messages that should not be
ignored.
This User’s Manual contains information on how to install and configure your GPS device. From now on,
we will guide you through the correct configuration steps to implement your device.
viii
Chapter 1: Getting Started
Chapter 1 Getting Started
Hardware Features
Note
Depending upon the specific model you purchased, the color of
y
our
device may not exactly match that of device shown in this manual.
Front View
Number Component Description
1 Charge Indicator
When LED is red, the battery is being charged;
when LED is green, the battery is fully charged.
2 Microphone
You can speak through the component in the
hand-free profile mode.
3 3.5” LCD Panel Displays the output of your device. Tap the screen
with a fingertip to select a menu or read information.
Back View
Number Component Description
1 Speaker
Sends out music, sounds, and voice.
1
Global Positioning System
Left And Right Side Views
Number Component Description
1 Stylus
You can tap the screen with the stylus.
2 Volume Up Key You can tune up the volume of the headphone or
speaker.
3 Volume Down Key You can tune down the volume of the headphone or
speaker.
4 Headphone Jack
Used to connect a headphone for private listening.
When the headphone is connected to this jack, the
speaker will be turned off automatically.
5 Play / Pause Key You can use the key to play back or pause music.
6 External GPS Antenna
Connector
This connector (under rubber dust cover) allows use
of an optional external antenna with magnetic
mount, which may be positioned on top of the car for
better signal reception in areas with poor reception.
7 Power Button
Turns on and off the device.
8 Hold Key
Designed to prevent you from operation by mistake.
2
Chapter 2: Basic Operation
Top And Bottom Views
Number Component Description
1 MiniSD Card Slot
Accepts a MiniSD card for accessing data, such as
MP3 music and photos.
2 MiniUSB Port
Connects through an AC adapter or USB cable to a
PC or a car charger socket.
3 Reset Key
Restarts your device (soft reset).
4 Battery Switch
The main power/battery cutoff switch.
Initially Switching ON the GPS
Use a stylus to slide the ON/OFF switch to the
ON position.
Then, your product will be turned ON in 15 seconds. Connect the AC adapter as described below. Bear
in mind to fully charge the battery before using your product for the first time.
Caution
Always keep the ON/OFF switch in the ON position for normal
operation.
3
Global Positioning System
Connecting to AC Power and Charging the Battery
For the first time, you should charge it for at least 8 hours.
Initially, connect the AC power adapter to the
miniUSB port. Then, plug the AC adapter into
a wall outlet.
The charge indicator glows red when the battery is being charged. Do not disconnect your device from
AC power until the battery is fully charged and the charge indicator turns green. This will take a couple of
hours.
Note
1. Do not immediately turn on your device after connecting the AC
adapter to charge a power-consumed battery. If you need to turn
ON the device again, wait at least one minute.
2. Depending on your region of purchase, the connector converter
may not look exactly same as that in the picture shown above.
3. Your device can also be charged when it is connected to a desktop
computer via a USB cable.
For optimal performance of the lithium battery, bear in mind the following
notes:
1. Do not charge the battery when the surrounding temperature is high
(e.g. in direct sunlight).
2. There is no need to fully discharge the battery before charging. You
can charge the battery before it is discharged.
3. If you will not use the product for a long period of time, be sure to fully
charge the battery at least once in two weeks. Over discharge of the
battery can affect the charging performance.
Caution
4
Chapter 2: Basic Operation
Using Your Device in a Car
A car holder and a car charger are supplied with your device.
Using the Car Holder
Select an appro
p
riate location for the car holder. Never place the holder
where the driver’s field of vision is blocked. If the car’s windshield is tinted
with a reflective coating, an external antenna (optional) may be needed to
route to the top of the car through a window. When closing the car window,
be careful not to pinch the antenna cable. (An adequate space may be left, as
needed, for a car with an anti-jamming window design.)
Caution
The car holder consists of a bracket and a stand. Use the car holder to fix your device in a vehicle.
Make sure that the GPS antenna has a clear view of the space.
For initial positioning, remain at the same spot with a clear view of the space. The GPS may take a
few minutes to find its current location initially.
Connecting the Car Charger
The car charger supplies power to your device you are using in a car.
Caution
To protect your device against sudden surges in current, connect the car
charger only after the car engine has been started.
Follow the instructions below to connect the car charger to the car cigarette socket.
1. Connect one end of the car charger to
the power connector of your device.
2. Connect the other end to the 5V
cigarette lighter in the car to power and
charge your device. The indicator on
the car charger lights in green to
indicate that power is being supplied to
your device.
5
Global Positioning System
Connecting to a PC
Note
Always ensure that the GPS device and any other external device
connected to the GPS device are switched off and unplugged from the
power supply before you attempt to connect the GPS device to any
external device.
The GPS device is designed with a miniUSB port
that allows you to connect the device to a PC for
map update.
The requirements of the PC are listed below.
¾ Windows 98SE, ME, 2000, or XP (Driver required for Windows 98SE)
¾ CD-ROM Drive (for map upgrade)
¾ Intel Pentium II 233 MHz
¾ 64 MB RAM
¾ Hard drive space of 50MB available
¾ USB Port available
¾ 256-color display (16 bit color required)
6
Chapter 2: Basic Operation
Chapter 2 Basic Operation
Power ON and OFF
Use the power button to power ON and
OFF your device.
When you press the power button to turn off
the product, your device actually enters a
suspend mode and the system stops
operating. Once you power ON the system
again, it resumes.
Operating the Device
To operate your device, touch the screen with a stylus or your fingertip. You can perform the following
actions.
z Tap
Touch the screen with the stylus or your fingertip
to open the menu or an item.
z Drag
Hold the stylus or your fingertip on the screen and drag up/down/left/right or across the screen to
view photos.
7
Global Positioning System
Main Menu
At the first time which you initialize your
device, the Main Menu appears in about 3~5
seconds. The Main Menu is your starting place
for various tasks. Tap a button to start a task or
open another menu.
Button Name Description
Navigator Entering the GPS navigation service
A
llowing you to view pictures in the formats of BMP, JPG, and
GIF that were stored in a miniSD card or the built-in flash disk
MP3 Allowing you to enjoy songs in the formats of MP3 and WMA
that were stored in a miniSD card or the built-in flash disk
BT Carkit
A
llowing you to talk on the device by means of Bluetooth
wirelessly connected to your BT mobile phone
Calculator Allowing you to do calculation
Setup Entering to customize the device settings, such as backlight,
volume, date and time, as briefly described below
Setup Submenu
On this setting page, you can customize the
device settings, such as backlight, volume,
date and time. Once you change the
settings, your new settings will remain until
you change them again.
Button Name Description
Clock
A
llowing you to select a Time Zone and set the current date
and time
Volume Allowing you to enable or disable the key tone of touch pad
and adjustment the volume of system
Battery Allowing you to read the battery status and set the system’s
idle time
8
Chapter 2: Basic Operation
Button Name Description
Display Allowing you to set the LCD’s idle time and adjust the
backlight of LCD
Bluetooth
A
llowing you to search for a Bluetoooth device around and
pair the Bluetoooth device with your product
System Showing the information on the system’s brief specification
Inserting a MiniSD Card
The GPS device is designed with a miniSD Card slot which allows you to insert the miniSD card into the
GPS device.
To use the miniSD card, insert it into the slot of the
device, with the connector pointing to the slot and
its label facing the front of the device.
To remove the card, first make sure that no
application is accessing the card, and then slightly
push the top edge of the card to release and pull it
out of the slot.
Note
1. Make sure that no foreign object enters the slot.
2. Keep a miniSD card in a well protective box to avoid dust and
humidity when you are not using it.
Connecting an Earphone
Connect an earphone to the left side of the device
for private listening.
After the earphone is connected, the speaker of
GPS device will be automatically off.
Caution
Excessively loud volume could damage your hearing. So turn down the
volume before you connect the earphone, and then raise the volume to a
comfortable level.
9
Global Positioning System
10
Chapter 3: Device Settings
Chapter 3 Device Settings
You can customize the device settings, such as brightness, volume, date and time, etc. Once you
change the settings, your new settings will remain until you change them next time.
To open the Setup menu, first tap the Setup icon
on the main menu.
After you tap the Setup icon on the main menu, the
Setup submenu will now appear in the display.
On this submenu you can set:
Clock – Adjusting the time zone, date, and time
Volume – Adjusting the system volume and
enabling or disabling key tones
Battery – Displaying current battery status and
adjust the battery idle time
Display – Adjusting the display idle time and
brightness and calibrating the touch screen
Bluetooth – Searching, pairing, connecting a
Bluetooth device
System – Viewing the system information, such as
the information of firmware, CPU and the like
Clock
Tap Clock on the Setup submenu.
11
Global Positioning System
The Clock page appears in the display.
Time Zone
Firstly, tap the rectangle area of Time Zone.
To change the time zone, tap the left/right arrow
on the Time Zone bar.
Then, click at the upper right corner of the
page to save the setting and go back to the last
page.
Date
Firstly, tap the rectangle area of Date.
To change Year, Month, and Day, tap the
left/right arrow on the Date bar.
Then, click at the upper right corner of the
page to save the setting and go back to the last
page.
12
Chapter 3: Device Settings
Time
Firstly, tap the rectangle area of Time.
To change Hour, Minute, and Second, tap the
left/right arrow on the Time bar.
Then, click at the upper right corner of the
page to save the setting and go back to the last
page.
Volume
Tap Volume on the Setup submenu.
The Volume page appears in the display.
Check the Enable Keytone option if you would like
to hear a clicking sound each time you tap on the
display.
If you are using the earphone, the Enable keytone
option will be disabled automatically.
13
Global Positioning System
Tap the + or – symbol to increase or decrease the
volume.
Then, click at the upper right corner of the page
to save the setting and go back to the last page.
Battery
Tap Battery on the Setup submenu to check the
remaining power of your battery and/or choose the
idle time for power saving.
The Power page appears in the display.
Battery Status indicates the current status of
battery. When the battery of GPS device is being
charged, you see the indication of Battery Status :
Charging; when the battery of GPS device is fully
charged, you see the indication of Battery Status :
100%
Tap the right or left arrow to choose the idle time of
power. You can set a timer to automatically turn off
your device when it is idle for a set period of time.
The options include Never, 1 min, 2 min, 5 min, 10
min, and 15 min.
For power saving, you had better choose the idle
time. If you choose the idle time, the device will be
in the suspend mode at the time you set.
Then, click at the upper right corner of the page
to save the setting and go back to the last page.
14
Chapter 3: Device Settings
Display
Tap Display on the Setup submenu.
The Display page appears in the display.
Tap the right or left arrow to choose the idle time of
display. You can set a timer to automatically turn off
your display when it is idle for a set period of time.
The options include Never, 15 secs, 30 secs, 1
min, 2 min, and 5 min.
For power saving, you had better choose the idle
time. If you choose the idle time, the display will be
turned off at the time you set.
Tap the + or – symbol to increase or decrease the
brightness of display.
You can calibrate the touch screen if it is not
responding accurately to your taps.
Click Align Screen to calibrate the touch screen.
15
Global Positioning System
You see a screen with 4 languages. Tap and hold
the center of the target. When the target moves to
another position, tap and hold the center of the new
target. Repeat each time to complete the calibration
process.
Then, The Display page returns. Click at the
upper right corner of the page to save the setting
and go back to the last page.
Bluetooth
Tap Bluetooth on the Setup submenu.
The Bluetooth page appears in the display. There
are 2 tabs in the Bluetooth management, one for
Mode and the other for Devices.
Mode – You can turn on/off Bluetooth and make
your device to be discovered by other devices with
Bluetooth.
Devices – You can manage all searched/paired
devices.
If you finish in the setting, click at the upper
right corner of the page to save the setting and go
back to the last page.
16
Chapter 3: Device Settings
System
Tap System on the Setup submenu.
The System Info page appears in the display.
You can read the system information in this page,
such as model name, firmware version, NAND
Flash size, SDRAM size, and CPU type.
Click at the upper right corner of the page to go
back to the last page.
17
Global Positioning System
18
Chapter 4: Main Menu
Chapter 4 Main Menu
Whenever switching ON the GPS device, you will
see the main menu of system on the display. This
main menu is the starting point where all of the
functions exist for you to use. You can tap one of
the functional icons to start the function you want.
When the function exits, the system will take to the
main menu of system.
Button Name Description
Navigator Entering the GPS navigation service
A
llowing you to view pictures in the formats of BMP, JPG, and GIF that were stored
in a miniSD card
MP3 Allowing you to enjoy songs in the formats of MP3 and WMA that were stored in a miniSD
card
BT Carkit Allowing you to talk on the device by means of Bluetooth wirelessly connected to your BT
mobile phone
Calculator Allowing you to do calculation
Setup Entering to customize the device settings, such as backlight, volume, date and time, as
briefly described below
Navigator
Tap Navigator on the main menu of the display.
After tapping the Navigator icon on the main menu,
you enter the Warning page. If you agree on what
is described on this page, click I Agree.
Note For the detail of Navigator operation, please read a separately made user manual.
19
Global Positioning System
You can view photos or slideshow on your GPS device.
Tap Photo on the main menu of the display.
After tapping the Photo icon on the main menu, you
enter the Photo page.
Features of Photo Viewer
¾ Codec Engine
Supports BMP, JPEG, and GIF formats
Supports 1 bit, 4 bits, 8 bits, 16 bits, 24 bits, and 32 bits bitmap images
Supports 8 bits and 24 bits JPEG images
Supports 8 bits interlace and non-interlace static GIF images
¾ Control Functions
Up one level, allowing you to surf the image files in the whole storage card
Home, allowing you to go quickly back to root of storage card
SlideShow
¾ Display
Thumbnail View
Image View
Slideshow View
20
Chapter 4: Main Menu
Viewing Photos
If you cannot see photo thumbnails but instead folders (as shown in the figure above), then you can
click one of the folders to access the contents (as shown in the illustration below).
You can also scroll up or down to search up or
down the list of folders or photos.
Further, you can drag one of the photos, with a
stylus, towards every column at the left side and
every two columns at the right side; you can
also drag it up and down.
You will see 4 functional options at the bottom of the screen, which are defined as follows:
Back button to move up to a level
Home button to return to the first level where you enter from the main menu
Slideshow button to show you photos in the slideshow mode
Exit from this page to main menu
Once you can see photos, you can click on one
photo to show it at a full size.
You will see 8 functional options at the bottom of the screen, which are defined as follows:
Viewing a last photo
Viewing a next photo
Zoom in
Zoom out
Viewing a photo at the default rotation angle
21
Global Positioning System
Viewing a photo at 90° (clockwise)
View photo at 90° (anticlockwise)
Exiting the screen
Using the slideshow
Make sure that you can see photo thumbnails at
the steps outlined in Viewing Photos.
Press the Slideshow button and the
slideshow will start.
To stop the slideshow, click everywhere on the
screen.
MP3 Player
This section instructs you how to play MP3 files on your device.
Tap MP3 on the main menu of the display.
After tapping the MP3 icon on the main menu, you
enter the MP3 Player page.
Features of MP3 Player:
¾ Codec Engine
Supports Win CE. NET 5.0 default (WMA and MP3)
Supports sampling frequencies from 8 kHz to 48 kHz
Minimum bit-rate supported 32kbps and Maximum bit-rate supported 320kbps or higher for
22
Chapter 4: Main Menu
layer-3
Supports variable bit rates
¾ Control Functions
Play List Display
Play/Pause/Stop/Forward/Backward
Volume
Repeat mode
1. Repeat One
2. Repeat All
Shuffle
¾ Display
Displays play time elapsing
Track name ID3 support
Index of current playing title
Definition of MP3 Player Buttons
The MP3 Player buttons are defined as follows.
23
Global Positioning System
Operation on MP3 Player
On the MP3 player, press the Play button to begin listening to music. To pause the music,
press the Pause button . To stop listening to the music, press the Stop button . To skip to a
next track, press the Fast forward button . To go to the beginning of the current track or skip
back to the previous track, press the Rewind button .
Adjusting the Player Volume
To adjust the volume, press the Increase volume or Decrease volume buttons.
Changing the order of tracks
To choose between playing tracks in sequential order or random order, press the Select
sequence/random button. The current order is indicated at the upper right corner of the page.
Note
The appearance of the Select sequence/random button changes with the
current mode.
Repeating tracks
To repeat a track or tracks or not, press the Select linear/repeat button. The current mode is
indicated at the upper right corner of the page.
Note
The appearance of the Select sequence/random button changes with the
current mode.
Displaying a play list
Press the Play list button and then the
Play list page appears on the display.
Note By default, all tracks in the storage card will be added to the play list.
To update all tracks from the memory card, please press the Update all tracks button. But
MP3 Player will administrate this list automatically.
To add tracks, press the Add track button and then navigate to the track/s you would like to
add. And you can add several songs at the same time. This function is not used in the classified
file.
24
Chapter 4: Main Menu
To delete tracks, press the Delete track button in the My Favorite folder. And you can delete
several songs at the same time.
To return the previous page, press the Return button.
BT Carkit
With BT Carkit, you can make a phone call or answer a phone call thru the GPS device.
Note
Before using this function, pair and connect a Bluetooth mobile phone with
the GPS device through Bluetooth.
Tap BT Carkit on the main menu of the display.
After tapping the BT Carkit icon on the main menu,
you enter the BT Carkit page.
Features of BT Carkit:
¾ Main Feature
Supports dial pad
Supports contact viewer
Supports call history
Supports phone shell, allowing you to pick up an incoming call
¾ Control Functions
Digital keypad
Backup
Clear
Dial / call history / contact viewer
¾ Display
Displays phone number you want to dial out
25
Global Positioning System
Contact Viewer
Tap the Contact Viewer icon to view the
phone numbers of all your friends.
Features of Contacts Viewer:
9 Supports Add / Edit / Delete functions
9 Supports dial out from a list of contacts
Call History
Tap the Call History icon to view all the
call history, including outgoing calls, incoming
calls, and missed calls.
Features of Call History:
9 Supports the Delete function to delete all history functions
9 Supports the Save function to save the calls to history for contact
9 Supports the Quick Dial function, allowing you to very easily dial out from the call
history
26
Chapter 4: Main Menu
Phone Shell
The phone shell program allows you to dial out and pick up an incoming call.
Calculator
Tap Calculator on the main menu of the display.
After tapping the Calculator icon on the main
menu, you enter the Calculator page.
The calculator tool turns your device into a calculator. The calculator tool is easy to use, so you can
press every button with your fingertips.
Features of Calculator:
9 Supports basic calculation, such as addition, subtraction, multiplication, division, square, and
square root
9 Supports memory function, such as MC, MR, M+ and M-
9 Supports 12 digits as the maximum calculation result
27
28
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference and (2) this device must accept any interference received, including interference that may cause
undesired operation
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
