Audioengine B8 Audioengine 512 Portable Wireless Speaker User Manual
Audioengine LLC Audioengine 512 Portable Wireless Speaker
User Manual
Audioengine 512 User Manual
Specifications:
Battery Voltage: 7.4V
Battery Capacity: 2200 mAh
Charging Voltage: 5V
Features:
1.Adopt Bluetooth 5.0 Version
2.Waterproof
3.Support SIRI or S-Voice
4.Battery Level Display
5.Handsfree Call
6.AUX IN
7.Auto Idle Shutoff in 20minutes
Button Functions:
1.PowerButton
Press and hold for 3 seconds to power on / off the speaker.
2.Play/Pause/Siri Button
Simply press to play / pause the music.
Short press to answer the phone, press and hold to reject, when a coming call.
Press and hold to enter into/off SIRI function
3.Volume Down
Short press to decrease the volume level by level, press and hold to decrease the volume fast.
4.Volume Up
Short press to increase the volume level by level, press and hold to increase the volume fast, a
sound alert “Beep” for max volume.
5.AUX Button
Short press to enter / exit the Line-in mode.
6.Bluetooth Button
Press and hold to activate the bluetooth pairing.
Bluetooth
1.Press and hold the power button to turn on the speaker.
2.Press and hold the bluetooth button to enter into bluetooth pairing.
3.Search the bluetooth name on your phone, then pair them together to play media sources.
AUX IN
Insert the audio cable to the AUX port,the speaker will turn into AUX mode automatically.
Battery Level Indicators
Battery icon in red, when battery low
30% battery, the first level indicator in orange
60% battery, the first and the second level indicaters in orange
100% battery, all three indicators in orange
The three battery level indicators will flash one by one.
30% battery, the first one in solid.
60% battery, the second one also in solid.
All of them in solid, when charging full.
Bluetooth Indicator
Solid blue: speaker in bluetooth mode
Flash blue and red: ready to pair with a bluetooth device.
Flash in blue: paired successfully
Aux Indicator
Solid in green, when in AUX mode.
SIRI
Press and hold the button “Play/Pause” to enter into / exit SIRI function, when no coming calls.
Auto Idle Shutoff
The speaker will shutoff itself automatically, in no any activites in 20 minutes to save power.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to
computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
