Autec s r l RGAGA00M Remote control - fixed unit User Manual
Autec s.r.l. Remote control - fixed unit
User Manual
Original instructions
AIR SERIES
Part B:
Conformity and frequencies
(434 and 915MHz)
INDEX
1 Conformity ............................................................................................................. 2
1.1 Conformity of frequency band 433.050-434.790MHz ........................................ 2
1.2 Conformity of frequency band 915-928MHz ..................................................... 2
2 Frequencies ........................................................................................................... 3
2.1 Frequency band 433.050-434.790MHz ............................................................ 3
2.2 Frequency band 915-928MHz .......................................................................... 4
AUTEC LIAIRI10-02
1 Conformity
1.1 Conformity of frequency band 433.050-434.790MHz
Each AIR series' radio remote control working in the frequency band 433.050-434.790MHz
complies with the (R&TTE) Directive 1999/5/EC and its essential requirements.
Each radio remote control is also in conformity with the harmonised standards provided in
the EC Declaration of Conformity.
You can nd the EC Declaration of Conformity on the website www.autecsafety.com, in the
product page of the relevant transmitting unit.
1.2 Conformity of frequency band 915-928MHz
Each AIR series' radio remote control working in the frequency band 915-928MHz complies
with the essential requirements of the following regulations:
-FCC (Federal Communication Commission) Part 15
-IC (Industry Canada) RSS-102
Unit FCC ID IC Number
A8 transmitting unit OQA-A08LA0AM 9061A-A08LA0AM
Receiving unit G
ACRS13-G OQA-RGAGA00M 9061A-RGAGA00M a b c
Receiving unit G
DCRS13 OQA-RGEBA00M 9061A-RGEBA00M a b c
Receiving unit L
ACRS13-L OQA-RLBHA00M 9061A-RLBHA00M a b c
Receiving unit M
ACRM15 OQA-RMCEA00M 9061A-RMCEA00M a b c
a. Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary
for successful communication.
b. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain and required antenna impedance for each antenna
type indicated. Antenna types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this device.
Antenna type Antenna gain Antenna impedance
Autec stylus λ/4 <0dBi 50 Ohm
c. Autec allows you to use only the dedicated antenna supplied either with the remote control or
as original spare part. The use of any other type of antenna is prohibited and will invalidate the
guarantee.
2
LIAIRI10-02
Conformity
AUTEC - Air series
1.2.1 Federal Communications Commission (FCC)
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
1.2.2 Industry Canada (IC)
This device complies with RSS-210 of the Industry Canada Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
2 Frequencies
AIR series radio remote controls can work at two dierent frequency bands: 433.050-
434.790MHz or 915.000-928.000MHz.
The radio remote controls' working frequency is dened by market-specic
laws and standards. In order for the system “machine+radio remote control”
to be compliant and therefore to be used, it shall comply with such laws and
standards: if it does not, the system may be impounded by competent bodies.
Autec cannot be held responsible if the radio remote control is set with
forbidden frequencies.
They automatically search for a free working frequency.
2.1 Frequency band 433.050-434.790MHz
2.1.1 Frequencies
The radio link between the units of Autec AIR series radio remote controls is built at one of
the frequencies permitted by the European standards in force when the system is put on
the market.
Frequencies used in the band 433.050-434.790MHz ..................................................... 64
RF power ................................................................................................................ <1mW
Channel spacing ...................................................................................................... 25kHz
2.1.2 Market
Air series' radio remote controls working in the frequency band 433.050-434.790 MHz can
be used within the EU (European Union), the EFTA (European Free Trade Association) and
in Singapore.
AUTEC - Air series
Frequencies 3
LIAIRI10-02
2.2 Frequency band 915-928MHz
2.2.1 Frequencies
The radio link between the units of Autec AIR series radio remote controls is built at one of
the frequencies permitted by the US and Canadian standards in force when the system is
put on the market.
Frequencies used in the band 915-928MHz ................................................................ 256
RF power ........................................................................ meets FCC and IC requirements
Channel spacing ...................................................................................................... 50kHz
2.2.2 Market
Air series' radio remote controls working in the frequency band 915-928MHz can be used in
the US and Canadian markets.
4
LIAIRI10-02
Frequencies
AUTEC - Air series
