Users Manual
1
Discover your phone
Philips continuously strives to improve its products.
Therefore, Philips reserves the rights to revise this user
guide or withdraw it at any time without prior notice.
Philips provides this user guide «as is» and does not
accept, except as required by applicable law, liability
for any error, omission or discrepancy between this
user guide and the product described.
Keypad
Microphone
Navigation
and
,
keys
65 000 colours
main screen
C
camera key
c
key
(
Pick up key
Hang up and
)
on/off keys
Side keys
(volume)
Back of
the phone:
camera
lens and
4000 colours
external screen
How to...
Switch phone On/Off
Press and hold
)
.
Enter PIN code
Enter your PIN code using
the keypad and press
,
or
#
to confirm.
Set the ringer volume
Press and hold either side key
when in idle mode.
A short press on either key
will mute the ringer when
you receive a call.
Make a call
Enter the phone number on
the keypad and press
(
to
dial.
Answer a call
Press
(
when your phone
rings.
Set conversation
volume
Press either side key during
the call.
End a call
Press
)
.
Reject a call
Press
)
or press and hold
either side key.
Philips855_GB_MKG_4311 255 58331.book Page 1 Mercredi, 17. décembre 2003 4:32 16
2
A carrousel is a circular loop of icons displayed on the
screen. Each icon represents a feature or operation of
your phone.
All icons don’t fit within the screen; the hidden ones
appear when scrolling
<
or
>
.
You access the main carousel by pressing
,
when
in idle mode. Move
<
(anti clockwise) or
>
(clockwise) and press
,
when the feature or option
of your choice is selected, or
c
to cancel. Another
sub-carousel or list will then appear.
Access the main
menu
Press
,
in idle mode.
Access the
Phonebook
Press
-
in idle mode.
Use the
Phonebook
Browse the list by
moving
+
or
-
and
press
(
to call the selected
name.
Access the
Call list
Press
+
in idle mode.
Go to previous menu
Press
c
.
Quickly return
to idle when
browsing menus
Press and hold
c
.
View the last call
made
Press
(
in idle mode.
Access a function
in the menu
Press
,
, move
<
or
>
to select a function,
then press
,
to enter the
sub-menu. Repeat to reach
the desired function.
Activate a
programmed
Voice command
Press and hold the
,
key.
Quickly send an
MMS
Press
<
in idle mode.
Quickly send an
SMS
Press
>
in idle mode
(opens the names list for you
to select the recipient).
Activate
Camera
Press
C
in idle mode.
Launch
WAP
Press and hold
0
.
The carrousel
Philips855_GB_MKG_4311 255 58331.book Page 2 Mercredi, 17. décembre 2003 4:32 16
3
Pressing
<
or
>
will alternate between two
options, such as Activate/Deactivate, On/Off,
Increase/Decrease a value, etc.
Browse carousels and lists until you reach the desired
feature or option. When navigating in a list, a scroll
bar located on the right hand side of the screen shows
your actual position in the list. With the navigation
key, you can then select or adjust all the functions of
your phone as described in the relevant chapter of this
user guide.
Some events may modify the idle screen (missed call,
new message, etc.). Press
,
to access the
corresponding menu or long press
c
to go back to
the idle screen.
Events
Philips855_GB_MKG_4311 255 58331.book Page 3 Mercredi, 17. décembre 2003 4:32 16
i
Table of contents
1. Get started ....................................................1
Insert the SIM card ...........................................1
Switch on the phone ........................................2
Set date and time ..............................................2
Copy the SIM phonebook ...............................2
Charge the battery ...........................................3
2. Main features ................................................4
Access and consult the phonebook ..............4
Make a call ..........................................................4
Answer and end a call ......................................4
Call handsfree ....................................................4
Change the ringer .............................................5
Activate the silence mode ..............................5
Activate the vibra alert ....................................5
Foto Talk: send voice clips with pictures ....5
Fotocall: see and hear who’s calling ..............6
Read your mobile phone number .................6
Adjust the earpiece volume ............................6
Unmute the microphone .................................7
Record a conversation .....................................7
Mute the microphone ......................................7
Clear the call list ...............................................7
Clear the SMS list .............................................7
Quickly scroll a list ...........................................8
Clear the phonebook ......................................8
Other features during a call ...........................8
3. Menu tree .......................................................9
4. Text or number entry ......................... 12
T9 ® Text input .............................................. 12
What is it? ............................................... 12
How to use it? .......................................... 12
Basic text input ............................................... 13
5. Taking pictures ......................................... 14
How to... .......................................................... 14
Pictures shots ................................................. 15
Preview mode settings ............................. 15
Take a picture ......................................... 15
Clip mode: using Foto Talk ................... 17
Review the pictures ................................. 17
Receive a call ........................................... 18
Make a call .............................................. 18
Settings ............................................................. 18
Frames ..................................................... 18
Vision mode ............................................. 18
Effect mode .............................................. 18
Self-timer ................................................. 18
General settings ....................................... 19
Philips855_GB_MKG_4311 255 58331.book Page i Mercredi, 17. décembre 2003 4:32 16
ii
6. Phonebook .................................................. 20
SIM card phonebook ..................................... 20
Phone’s phonebook ....................................... 21
Add names in the phonebook ..................... 21
In the SIM card ....................................... 21
In the phone ............................................. 21
Add a record in the phone’s phonebook .22
Own numbers .......................................... 22
Fotocall: see & hear who’s calling .............. 22
Edit and manage names ................................. 23
In the SIM card ....................................... 23
In the phone ............................................. 24
Make calls ......................................................... 25
Emergency number .................................. 25
Other number .......................................... 25
7. Settings .......................................................... 27
Sounds .............................................................. 27
Silent ........................................................ 27
Ringer volume .......................................... 27
Ringer ....................................................... 27
Messages Ringer ....................................... 27
Equaliser .................................................. 27
Key tones .................................................. 28
Sounds Alerts ........................................... 28
Vibra alert ............................................... 28
Display .............................................................. 28
Screen saver .............................................. 28
Animation ................................................ 29
Contrast ................................................... 29
Backlight .................................................. 29
Wallpaper ................................................ 29
Sub wallpaper ......................................... 29
Short cuts ........................................................ 29
Hotkeys ..................................................... 29
Voice command ....................................... 32
Voice dial ................................................. 33
Navigation icon ...................................... 34
Security ............................................................ 34
Public names ........................................... 34
Call barring ............................................. 34
Change codes ........................................... 35
PIN protection ........................................ 35
Network .......................................................... 35
GPRS attach ............................................ 35
Register again .......................................... 36
Preferred list ............................................ 36
Access settings ........................................... 36
Time and date ................................................. 37
Clock display ........................................... 38
Set date .................................................... 38
Date format ............................................. 38
Time zone ................................................ 38
Daylight saving ....................................... 38
Set time .................................................... 38
Profiles .............................................................. 39
Language ........................................................... 39
Philips855_GB_MKG_4311 255 58331.book Page ii Mercredi, 17. décembre 2003 4:32 16
iii
8. Messages ....................................................... 41
SMS .................................................................... 41
Send a SMS ............................................. 41
Read SMS ................................................ 42
SMS settings ............................................ 44
SMS Archive ............................................ 44
E-Mail ................................................................ 45
Settings ..................................................... 45
Write and send an e-mail ....................... 47
Receive and read e-mails ........................ 49
Broadcast message ........................................ 52
Instant message .............................................. 53
MMS .................................................................. 53
Create an MMS ...................................... 54
Receive an MMS ..................................... 57
Manage folders ........................................ 58
Settings ..................................................... 59
9. Infrared .......................................................... 62
Position of devices ......................................... 62
Send data .......................................................... 62
Select an item .......................................... 62
Send the selected item .............................. 63
Receive data .................................................... 63
Activate IrDA .......................................... 63
Save the data received ............................. 63
Use the phone as a modem ..................... 64
10. Multimedia ................................................ 65
Sound album ................................................... 65
Picture album .................................................. 65
Memory status ................................................ 68
Demo mode .................................................... 68
Sound recording ............................................. 68
TV Slideshow .................................................. 68
11. Games & Appli. ..................................... 70
Euro converter ............................................... 70
Calculator ........................................................ 70
Alarm clock ..................................................... 70
Organiser ......................................................... 71
Create a new event .................................. 71
Modify an event ...................................... 72
Brick game ....................................................... 73
JAVA ................................................................. 73
Settings ..................................................... 73
12. Call information .................................... 75
Call settings ..................................................... 75
Active flip ................................................ 75
Call forward ............................................ 75
Mailboxes ................................................ 76
Auto redial ............................................... 76
Any key answer ........................................ 76
Call waiting ............................................ 76
Caller ID ................................................. 76
Philips855_GB_MKG_4311 255 58331.book Page iii Mercredi, 17. décembre 2003 4:32 16
iv
Call list ..................................................... 77
Reset .......................................................... 77
Call list .............................................................. 77
Call counters ................................................... 77
GSM counters .......................................... 77
GPRS counters ......................................... 78
13. WAP ............................................................. 80
Internet services ............................................. 80
Launch a WAP session ............................ 80
End a WAP session .................................. 80
Homepage ................................................ 80
Bookmarks ............................................... 81
Enter address ............................................ 81
Settings ..................................................... 81
Push inbox ............................................... 83
Options ............................................................ 83
Homepage ................................................ 83
Back .......................................................... 84
Forward ................................................... 84
Refresh ...................................................... 84
Save as homepage .................................... 84
Save as... .................................................. 84
Exit ........................................................... 84
Receive a call ........................................... 84
14. Operator services ............................... 85
GSM strings ..................................................... 85
DTMF tones .................................................... 85
Make a second call ......................................... 86
Answer a second call .................................... 86
Answer a third call ........................................ 87
Conference call .............................................. 87
Explicit call transfer ....................................... 88
Precautions ....................................................... 89
Troubleshooting ........................................... 93
Icons & symbols ............................................ 96
Philips authentic accessories ................. 98
Philips855_GB_MKG_4311 255 58331.book Page iv Mercredi, 17. décembre 2003 4:32 16
Get started 1
1 • Get started
Read the safety instructions in the «Precautions» section
before use.
To use your phone, you must insert a valid SIM card
supplied by your GSM operator or retailer. The SIM
card contains your subscription, your mobile number,
and memory in which you can store phone numbers
and messages (see “Phonebook” page 20).
1.
Press on the back cover of your phone as shown
below and slide it downwards to remove it.
2.
Remove the SIM card from its holder and insert
it under the metal clip holder, until it stops. Be
careful that the clipped corner of the card is in
the correct corner.
3.
Place the battery in its slots as shown below: first
place its right side against the right edge of the
phone and press until it clips.
4.
Replace the back cover of your phone: hook the
front housing onto the hinges on the top of the
phone, then press the bottom down until the
latch catches.
Insert the SIM card
Philips855_GB_MKG_4311 255 58331.book Page 1 Mercredi, 17. décembre 2003 4:32 16
2Get started
Remove the protective film covering the screens and
the camera lens before using the phone.
1.
To switch on the phone, press the
)
key.
2.
When you switch on the phone, you may be
prompted to enter the PIN code, which is the 4
to 8-digit secret code of your SIM card to protect
it from unauthorised use. It is preconfigured and
communicated to you by your operator or
retailer. To personalise the PIN code, see
page 43.
If you enter a wrong PIN code 3 times, your SIM card
is blocked. To unblock it, you must request the PUK
code from your operator.
Enter your PIN code. If you make a mistake, press
c
. Then press
,
or
#
to confirm.
As prompted by the phone at first switch on, set the
date by pressing the appropriate numeric keys (press
c
to erase a number), then press
,
to validate.
Proceed in the same way to set the time.
For complete date and time options, see page 46.
If you do not copy the SIM phonebook at very first
switch, you will be able to do it directly from the
phonebook menu (see page 29).
If you had a mobile phone before and are using the
same SIM card, the card might contain all or part of
your current phonebook. The mobile phone detects
this and a message asks you if you want to copy your
SIM phonebook onto the built-in phonebook. Press
c
to cancel or
,
to accept. Whether you
accepted, aborted or cancelled the copy, the
phonebook located on your phone is always
automatically set as your default phonebook. To
switch back to the SIM phonebook, press
,
and
Switch on the phone
Set date and time
Copy the SIM phonebook
Philips855_GB_MKG_4311 255 58331.book Page 2 Mercredi, 17. décembre 2003 4:32 16
Get started 3
select
Phonebook
>
Phonebook settings
>
Phonebook
select
>
In SIM card
.
Your phone is powered by a rechargeable battery. A
new battery is partially charged and an alarm will warn
you when the battery reaches low.
We recommend that you do not
remove
the battery
when the phone is switched on: you may lose all your
personal settings (see information on battery safety,
page 93). If you do remove it, date and time settings
are memorized for around 2 minutes.
1.
Once the battery and battery cover are clipped
on the phone, plug the connector of the charger
(supplied with the phone, in the box) into the
BOTTOM
hand socket at the base of the phone
on one end, then plug it into a main AC power
socket with easy access on the other end.
2.
The battery symbol indicates the state of charge:
• During charging the 4 charge indicators change;
Each bar represents around 25% of charge and it
takes around 1.45 hours to fully recharge your
mobile phone.
• When all 4 bars are steady the battery is fully
charged, you can disconnect the charger.
Depending on the network and condition of use,
talk time goes from 2 to 4 hrs and stand-by time
from 200 to 400 hrs.
Keeping the charger plugged to the mobile when the
battery is fully charged doesn’t damage the battery.
The only way to turn off the charger is to unplug it, so
use an easily accessible AC power socket. You can
connect the charger to an IT supply (Belgium only).
3.
If you don’t intend to use your phone for several
days, we recommend you disconnect the battery.
You can use the phone while it is on charge (note that
the vibra alert goes
Off
when plugging the charger). If
the battery is completely flat, the battery icon will only
reappear after 2 or 3 minutes of charging.
Charge the battery
Philips855_GB_MKG_4311 255 58331.book Page 3 Mercredi, 17. décembre 2003 4:32 16
4 Main features
2 • Main features
In idle mode, press
-
. Depending
on the selected phonebook (in SIM or
in phone), the content that appears on
the screen may vary: see “Phonebook” page 20 for
details on this subject.
To consult the phonebook during a call, press
,
,
select
View Names List
, press
,
and scroll through
the entries by pressing
-
or
+
. Then press
c
twice to return to the in-call screen.
1.
In idle mode, enter the phone number using the
keypad. To correct an error, press
c
.
2.
Press
(
to dial the number and press
)
to
hang up.
For an international call, enter the «+» sign instead of
the usual international prefix by pressing and holding
*
. To learn how to make a call from the
phonebook, see “Make calls” page 25.
When receiving a call, depending on your
subscription and if the caller has permitted this
information to be transmitted, his number may be
displayed. If the number is stored in the selected
phonebook (see page 22), the corresponding name is
displayed instead of the number.
1.
To answer the call, press
(
.
2.
To reject a call, press
)
. If you have activated
“Active flip” (see page 75), the call is diverted to
a number or voice mail.
3.
To hang up, press
)
.
The phone will not ring if in
Silence
mode (see
page 5). If you have selected
Any Key Answer
(see
page 76), you can accept a call by pressing any key
(except
)
).
For your own comfort and safety, ensure you move the
phone away from your ear when calling handsfree,
especially when increasing the volume.
1.
If you selected the phonebook in your SIM card,
select a record, press
,
twice to access the next
Access and consult the phonebook
Make a call
Phonebook
Answer and end a call
Call handsfree
Philips855_GB_MKG_4311 255 58331.book Page 4 Mercredi, 17. décembre 2003 4:32 16
Main features 5
carousel, then select
Call handsfree
and
press
,
to dial the number.
2.
If you selected the phonebook in your phone,
proceed the same way to call the default number,
or press
<
or
>
, select another number in
the list, then press
,
and select
Call handsfree
.
If already on the phone, press
,
twice to switch to
handsfree mode and back.
1.
Press
,
, select
Settings
>
Sounds
>
Ringer
and
press
,
again.
2.
Move
+
or
-
to select a ringer in the list,
then press
,
to confirm your choice.
If you don’t want your phone to ring
when you receive a call, you can
deactivate the ringer as follows:
Press
,
and select
Settings
>
Sounds
>
Silent
and
press
-
until the volume is set to
On
.
You can also press the side key while in idle screen
until the volume is set to silence.
You can also mute the ringer when receiving a call by
pressing the side key down.
If you want your phone to vibrate when
you receive a call, you can activate the
vibra alert as follows:
1.
Press
,
, select
Settings
>
Sounds
>
Vibra alert
and press
,
.
2.
Move
+
or
-
to select
On
or
Off
and press
,
to confirm.
Activating the vibra doesn’t mute the ringer. If you
want to mute it and keep the vibra function on,
activate the
Silent
mode as described above.
The vibra alert is automatically deactivated when you
plug the charger.
This feature, which is available when using the camera
and also from the
Picture album
, allows you to quickly
send a message made of a picture and a sound.
1.
When in idle mode, press
C
to activate the
camera. In needed, press
#
to switch to the
Clip mode.
Change the ringer
Activate the silence mode
Silent
Activate the vibra alert
Foto Talk: send voice clips with
pictures
Vibra alert
Philips855_GB_MKG_4311 255 58331.book Page 5 Mercredi, 17. décembre 2003 4:32 16
6 Main features
2.
Press
C
to take a picture;the Record sound
window will then open automatically.
3.
Record the sound or message of your choice,
press
c
to cancel or
,
to stop the recording
(you can also wait for the maximum recording
time of 30 seconds to be reached).
4.
The send your message via MMS (see “MMS”
page 61 for details).
This feature is available only when selecting the
phonebook in the phone (not the one in the SIM card).
This feature allows you to link one or several names to
a group. When a name in that group calls, it will
appear along with the corresponding picture, and the
melody defined for that group will ring.
1.
When in idle mode, press
C
to activate the
camera, and press
C
to take a picture of your
friend.
2.
Select
Multimedia
>
Sound recording
>
New
.
Record them saying something and save it in the
Sound album
.
3.
Select
Phonebook
>
Phonebook set.
>
Group
settings
>
Groups
. Rename a group and select
your friend’s voice, then their picture.
Press
-
, select a name in your phonebook and press
,
. Press , and choose Select group to link it to the
group that you renamed.
To read your own mobile phone number, press
-
when in idle mode and select
Own numbers
, then press
,
, select
Show
and press
,
again. Your phone
number is displayed if present on your SIM card. If
not, select
New
, then follow the instructions.
If your own number has been stored in the Phonebook,
you can read it during a call. See “Access and consult
the phonebook” page 4.
During a call, move the side key up or down to
increase/decrease the volume.
Fotocall: see and hear who’s
calling
Read your mobile phone number
Adjust the earpiece volume
Philips855_GB_MKG_4311 255 58331.book Page 6 Mercredi, 17. décembre 2003 4:32 16
Main features 7
You can mute the microphone so that
your caller cannot hear you. During a
call, press
,
, select
Mute
and confirm
by pressing
,
.
To unmute the microphone during a
call, press
,
, select
Unmute
and
confirm by pressing
,
. The
microphone is unmuted.
In most countries, conversation
recording is subject to law regulation.
We advise you to notify the caller if you
intend to record the conversation you have with them
and only record if they agree. You should also keep any
recording private. 1 min. is the maximum recording
time available (see “Sound recording” page 68).
To record a conversation during a call:
1.
While one or several simultaneous calls are in
progress, press
,
to access the call context
carousel.
If you select
Mute
, then
Record dialogue
, only the
caller’s voice is recorded.
2.
Select
Record dialogue
and press
,
. Press
c
,
,
or hang up to end the recording.
3.
In all cases, and when hanging up, an edit
window allows you to name the recording.
Press
,
to save the recording, which is then available
in the menu
Multimedia
>
Sound album
.
To clear your call list, press
,
and
select
Call Info
>
Call list
>
Reset
. Press
,
twice to reset the call list.
To clear the whole messages list at once, press
,
and select
Messages
>
SMS
>
Read SMS
>
Delete all SMS
.
Press
,
twice to reset the SMS list.
You can also delete all the SMS messages from the
SMS
Archive
menu. Deleting your SMS list is useful to free
memory space in order to receive new messages.
Mute the microphone
Unmute the microphone
Record a conversation
Mute
Unmute
Record dialogue
Clear the call list
Clear the SMS list
Reset
Philips855_GB_MKG_4311 255 58331.book Page 7 Mercredi, 17. décembre 2003 4:32 16
8 Main features
To clear the content of your phonebook at once, press
,
and select
Phonebook
>
Phonebook set.
>
Delete
all
. Press
,
to reset the phonebook content.
This option only applies to the phonebook in your
phone, NOT to the SIM phonebook.
When browsing a list (of names, ringers, events, etc.),
press
0
to scroll page per page instead of item by
item.
• Change the equalizer settings (see page 27),
• Add a name to the phonebook (see page 21),
• Write and send a message (see page 41),
• Read a message (see page 42),
• Consult your Call list (see page 77),
• Consult your Organiser (see page 71),
• Make a second call (see page 86).
Clear the phonebook Quickly scroll a list
Other features during a call
Philips855_GB_MKG_4311 255 58331.book Page 8 Mercredi, 17. décembre 2003 4:32 16
Menu tree 9
3 • Menu tree
The table below describe the complete menu tree (first
to third levels) of your mobile phone, as well as the
page reference you should refer to for more
information concerning each feature or setting.
Settings p27
Sounds p27
Silent / Ringer volume / Ringer / Messages
Ringer / Equaliser / Key tones / Sounds
Alerts / Vibra alert
Display p28
Screen saver / Animation / Wallpaper / Sub
wallpaper / Contrast
Short cuts p29
Hotkeys / Voice command / Voice dial /
Navigation icon
Security p34
Public names / Call barring / Change codes /
PIN protection
Network p35
GPRS attach / Register again / Preferred list
/ Access settings
Time and date p37
Clock display / Set date / Date format / Time
zone / Daylight saving / Set time
Language p39
List of available languages
Profiles p39
Messages p41
SMS p41
Send a SMS / Read SMS / SMS settings /
SMS Archive
E-Mail p45
For each available mail box
Settings / Open mailbox / Send mail
Broadcast message p52
Reception / Topics / District codes
Philips855_GB_MKG_4311 255 58331.book Page 9 Mercredi, 17. décembre 2003 4:32 16
10 Menu tree
Instant message p53
MMS p53
Create an MMS / Receive an MMS /
Manage folders / Settings
Multimedia p65
Picture album p65
List of available pictures
Sound album p65
List of available sounds
Demo mode p68
Memory status p68
Sound recording p68
TV Slideshow p68
Games & Appli. p70
Euro converter p70
Calculator p70
Alarm clock p70
Organiser p71
Brick game p73
Infrared p62
Camera
Philips855_GB_MKG_4311 255 58331.book Page 10 Mercredi, 17. décembre 2003 4:32 16
Menu tree 11
Call information p75
Call settings p75
Active flip / Active flip / Mailboxes / Auto
redial / Any key answer / Call waiting / Caller
ID
Call list p77
Call list / Reset
Call counters p77
GSM counters / GPRS counters
Phonebook p20
View names list
Phonebook settings
Delete all / Phonebook select. / Group
settings / Copy to phone
Operator services p85
Service numbers
The numbers available in this menu are
operator and subscription-dependent, please
check with your operator.
WAP p80
Services +
This menu is operator and subscription-
dependent, please check with your operator.
Philips855_GB_MKG_4311 255 58331.book Page 11 Mercredi, 17. décembre 2003 4:32 16
12 Text or number entry
4 • Text or number entry
Text can be entered in editing screens in two different
ways: by using T9® predictive Text Input, or basic
text input. Two other modes for numbers and
punctuation marks, are also available. Icons appearing
on the screen show the active text mode.
What is it?
T9® predictive Text Input is an
intelligent editing mode for messages,
including a comprehensive dictionary.
It allows you to quickly enter text. Press
only once on the key corresponding to
each letter needed to spell a word:
keystrokes input are analysed and the word suggested
by T9® is displayed in the edit screen. If several words
are available according to the keys used, the word you
entered is highlighted: press
>
to browse the list
and to choose from those proposed by the T9 ® built-
in dictionary (see example below).
How to use it?
Alphabets and symbols represented by each key are as
follows:
Example: how to enter the word «home»:
1.
Press
4
6
6
3
The screen displays
the first word of a list:
Good
.
2.
Press
>
to scroll and select
Home
.
3.
Press
,
to confirm selection of the word
Home
.
T9® Text input
Tegic Euro. Pat.
App. 0842463
2
to
9
To key in letters.
<
or
>
To browse the list of candidate words.
,
To confirm entry.
c
Short press to clear one entry, long
press to clear all text.
#
Shift from standard, to lower, to upper
case.
*
Shift from basic mode, to numeric or
to punctuation typing mode.
Philips855_GB_MKG_4311 255 58331.book Page 12 Mercredi, 17. décembre 2003 4:32 16
Text or number entry 13
If you wish to access the basic text input, select «Abc»
basic text input using
*
key. This method requires
multiple key presses to reach the desired character: the
letter «h» is the second letter on the
4
key, so you
must press it twice to enter «h». Using this mode
requires you press a key as many times as is equal to
the order of the letter.
To enter the word «Home» in basic text input mode,
you should therefore key in
4
,
4
(
G
H
I
)
6
,
6
,
6
(
MN
O),
6
(M
NO
),
3
,
3
(
D
E
F
).
Press
,
when the message is completed.
Letters, numbers and symbols are located on each key
as follows:
Basic text input
1
space 1 @ _ # = < > ( ) & £ $ ¥
2
a b c 2 à ä å æ ç
3
d e f 3 é è D F
4
g h i 4 G ì
5
j k l 5 L
6
m n o 6 ñ ò ö
7
p q r s 7 b P Q S
8
t u v 8 ü ù
9
w x y z 9 ø W X Y
0
. 0 , / : ; » ’ ! ¡ ? ¿ * + - %
Philips855_GB_MKG_4311 255 58331.book Page 13 Mercredi, 17. décembre 2003 4:32 16
14 Taking pictures
5 • Taking pictures
Your mobile phone features a digital camera that
allows you to take pictures, store them in your phone,
use them as wallpaper or send them to your friends
and relatives.
Within any menu related to the camera, a long press
on the
c
key will cancel any current action and
bring you back to idle mode.
How to...
Activate/deactivate
the camera
Press the
C
key to activate,
OR
press
,
and select the
menu
Camera
.
Long press
c
to deactivate.
Zoom in/out Press the navigation key
+
(up) or
-
(down).
Change the
vision mode
Press
*
to toggle between
Night
and
Normal
mode.
Change the
camera mode
Press
#
to switch from
VGA
(640*480 pixels) to
Wa l lP ap er
(128*160 pixels)
to
Clip
(128*160 pixels) to
Fotocall
(96 x 64 pixels).
Change the
special effect
Press the navigation key
<
(left) or
>
(right) to switch
from a special effect (sepia,
embossed, etc.) to another.
Access the
camera settings
Press
,
when the camera
is active.
Take a picture Press
C
when the camera
is active.
Save the picture Press
C
right after the
shot.
Delete the picture Press
c
right after the
shot.
Access the
shot options
Press
,
right after the
shot.
Activate/deactivate
the self-timer Press
0
.
Philips855_GB_MKG_4311 255 58331.book Page 14 Mercredi, 17. décembre 2003 4:32 16
Taking pictures 15
Preview mode settings
Press
C
to display the camera preview screen: the
lens of the camera is automatically focused. Icons
displayed on top and bottom of the screen allow you
to check the
Vision
,
Camera
and
Zoom
modes, and
also to set the
Self-timer activation
.
All options and key presses described in the present
section are applicable only when the camera mode is
active, i.e. when the preview is displayed on the screen
Press
,
to access any of them.
Vision mode
Two vision modes are available:
Normal
and
Night
mode
. According to ambiant light level, press
*
to
toggle between modes, which are reflected by the
icons in the bottom of the screen (sun & moon).
Camera mode
The default picture size of the standard format is
VGA
640 x 480 pixels. Press
#
to switch to
Wallpaper
(128 x 160 pixels), to
Clip
(128 x 160 pixels) to
Fotocall
(96 x 64 pixels). The
Camera mode
you select
is displayed in the bottom right corner of the screen.
The
Clip
mode also allows you to record a voice
message right after you shot the picture. See “Clip
mode: using Foto Talk” page 17 for details concerning
this camera mode.
Zoom mode
This option is available in all modes: one-level zoom
(x2) in
Clip
and
Wallpaper
modes, two-levels zoom (x2
and x4) in
VGA
mode. In any mode, press the
navigation key
+
or
-
to zoom in or out.
The zoom icon is highlighted when the zoom is
activated. Zoom out is available only after a zoom in.
Self-timer
This option allows you to set the
Self-timer
option
On
or
Off
(see “With the self-timer” page 16 for details).
Self-portrait
This option allows you to set the
Self-portrait
option
On
or
Off
(see “With the self-portrait mode” page 16).
Ta k e a p i c t u r e
With the
C
key
1.
If the self-timer option is
Off
, and once the
camera was activated, press the
C
key to take a
VGA
or
Wallpaper
picture, which is then
automatically displayed on the screen.
2.
The number in the upper black bar of the screen
shows its row. The pictures will be named
«img_1.jpg», etc., up to 9999.
Pictures shots
Philips855_GB_MKG_4311 255 58331.book Page 15 Mercredi, 17. décembre 2003 4:32 16
16 Taking pictures
This does not mean you can take up to 9999 pictures
(see “With the self-portrait mode” below), but that
pictures, including the ones you delete, are numbered
up to 9999. Numbering will then restart from 1 on.
You can then choose to:
With the self-timer
1.
If the self-timer option is
On
, press
C
to
activate it (or press
0
if the option is
Off
).
2.
The count-down starts at -10 seconds (this value
cannot be changed). A beep is played 3 seconds
before the picture is taken, then again when it’s
actually shot.
3.
A message will inform you when the camera
preview swaps from the main (internal) screen to
the external one: close the phone, put it down on
its hinges and orient it properly for the picture to
be correctly framed (the preview on the external
screen will then be reversed).
Beep alarms can be customized via the camera
settings. At any time, press
c
to stop the timer and
go back to preview mode or press
0
to just stop the
timer.
4.
Once the picture is shot, follow the instructions
starting at point 2 of the previous section.
With the self-portrait mode
This mode allows you to take a picture of yourself by
holding the phone opened in front of you.
1.
If the self-portrait option is
On
(see page 15),
press
C
to activate it.
2.
Place your finger on the
C
key, then hold the
phone opened at arms length, camera toward
your face (the preview on the external screen will
then be reversed).
3.
Press the
C
key to take the picture.
Press
c
To
Delete
the picture you
have taken.
Press
C
To
Save
it.
Press
,
To access the list of available
options, which are:
Save
the picture in the
Album
,
Modify
it,
Send
it via
MMS
,
Infrared
or
E-mail
,
Take
a new picture
, which will
bring you back to the
preview window.
Press
c
or
C
To go back to preview mode.
Philips855_GB_MKG_4311 255 58331.book Page 16 Mercredi, 17. décembre 2003 4:32 16
Taking pictures 17
Number of pictures
The number of pictures you can save in the phone will
vary according to the settings you have configured:
the higher the resolution, the bigger the file size.
A message will warn you if there isn’t enough memory
to store the picture you have just taken. In this case,
you must delete data (sounds, images, etc.) before
storing a new picture. Select
Multimedia
>
Memory
status
to check the memory available in your phone.
Clip mode: using Foto Talk
Create a clip
Selecting the
Clip
mode before taking a picture allows
you to use the
Foto Talk
feature: a quick way to make
a picture + sound clip to send to your friends and
relatives.
1.
When in idle mode, press
C
to activate the
camera.
2.
Press
C
again to take the picture; the
Record
sound
window will then open automatically.
3.
Record the sound or message of your choice,
press
c
to cancel or
,
to stop the recording
(you can also wait for the maximum recording
time of 30 seconds to be reached).
Options
Press
,
to access the Clip mode options, which are:
Review the pictures
The pictures you save are automatically stored in the
Multimedia
>
Picture album
menu. Select a picture in
the list and press
>
to access the graphical display.
Then press
+
or
-
to go to the next or previous
picture, or
,
to
Send
,
Delete, Modify
or
Rename
the
picture. Press
<
to go back to the text list.
See “Picture album” page 65 for detailed information
on how to retouch your pictures.
Save clip
To
Save
the clip you have
created: the picture in
album
and the recorded
sound in
Sound album
.
Change clip
To
Change
the clip you made.
Play clip
To
Play
it.
MMS
or
Send via E-mail
To
Send
your clip via MMS
or E-mail: selecting one of
these options will
automatically launch the
corresponding application.
Philips855_GB_MKG_4311 255 58331.book Page 17 Mercredi, 17. décembre 2003 4:32 16
18 Taking pictures
Receive a call
When receiving a call while using the camera:
1.
Answering the call will quit any action linked to
the camera: picture preview, picture shot, self-
timer, options browsing, etc. Your phone will
return to idle when you hang up. If you had
taken a picture that was not yet saved, it will be
lost.
2.
Rejecting the call will also quit any action linked
to the camera, and will bring you back to the
preview screen.
Make a call
To make a call, you must first long press
c
to go
back to the idle screen. Then enter the number or
select a name of your phonebook, press
(
to dial
and press
)
to hang up.
Further to the settings that are available directly
within the preview screen as described above, several
menus also allow you to set other options. Press
,
while the camera mode is active to access them.
In all cases, select an option, and press
,
for the
next picture to be taken using this mode, or
c
to
cancel.
When quitting the camera application, settings you
have defined will be saved and available when reusing
the camera or until you change them again.
Frames
Allows you to choose a frame from the ones available
in the list, and that will be applied to the picture you
take. Selecting a
Frame
automatically sets the mode to
120 x 160 pixels. Press
,
to confirm your choice.
Vision mode
Allows you to choose one of the two modes available:
Normal
and
Night
. The default mode is
Normal
.
Effect mode
Allows you to choose a mode available from the
following:
Normal
,
Black & white
,
Sepia
,
Digital
,
Embossed
,
Negative color
,
Edge
and
Edge 2
. The effect
will be applied to the picture according to the mode
you chose (e.g.,
Sepia
will take a brown and beige
picture, giving the impression of an old-times
picture). The default mode is
Normal
.
Self-timer
See “Self-timer” page 15.
Settings
Philips855_GB_MKG_4311 255 58331.book Page 18 Mercredi, 17. décembre 2003 4:32 16
Taking pictures 19
General settings
Time & date
Allows you to select what will be displayed on the
pictures you take:
Time & date
,
Date only
or nothing.
Picture quality
Allows you to choose an image quality available
among the following:
Low
,
Medium
,
High
. The default
mode is
Medium
.
Camera mode
This setting is also available directly within the
preview mode, when the camera is first activated.
Allows you to switch from VGA (640 x 480 pixels) to
Wallpaper
(128 x 160 pixels), to
Clip
(128 x 160
pixels) to
Fotocall
(96 x 64). The
Camera mode
you
select is displayed in the bottom right corner of the
screen.
Sounds
Both
Alert
and
Shoot
sounds can be set from this
menu. The first one occurs 2 seconds before the
picture is taken, the second one when it’s shot. In
both cases, select
On
, and press
,
to access the list
of available sounds. Select one of the sounds, or
<New>
to create a new sound, then press
,
to
activate it.
Reset
Allows you to reset all values to the default ones. Press
,
to confirm.
Philips855_GB_MKG_4311 255 58331.book Page 19 Mercredi, 17. décembre 2003 4:32 16
20 Phonebook
6 • Phonebook
All operations described in this chapter require the
relevant Phonebook, whether in the SIM or in the
phone, to be selected.
Your mobile phone has two phonebooks. The SIM
phonebook is located on the SIM card and the
number of entries depends on the card capacity.The
second phonebook is built into the mobile’s memory
and can hold up to 499 names.
The SIM card capacity depends on the type of card you
have. Please check with your local dealer for full
information on this subject.
The phonebook located on your phone shares the
mobile capacity and memory with other features. As
such, they are inter-dependent: the more names you
create, the less events you can store and vice-versa. 499
is the maximum number of names and events cards,
provided that other features (memos, sounds, pictures,
etc.) are not using a significant amount of the phone’s
memory.
The
Phonebook
menu allows you to select one of the
two available phonebooks: the one on your SIM card
or the one in your phone. When entering new names
in one of the
Phonebooks
, they will only be added to
the one you have selected.
The
Reset phonebook
option does NOT apply to the
SIM phonebook.
Copy all to phone
will copy the content of your SIM
card into your phone. Selecting this option twice will
duplicate all the names.
If you are using a SIM card for the first time, follow
the standard SIM card installation procedure as
described page 1, then go to the section titled “Add
names in the phonebook” below.
Press
,
and select
Phonebook
,
Phonebook set.
,
Phonebook select
. Then
press
+
or
-
to select the
phonebook located in your SIM card. Names added
to this phonebook can then be copied into the
phonebook located in your phone.
If you cancelled or aborted the automatic copy of your
SIM phonebook at very first switch, you can do it
manually: press
,
and select
Phonebook
,
Phonebook
set,
then
Copy to phone
.
SIM card phonebook
Phonebook select.
Philips855_GB_MKG_4311 255 58331.book Page 20 Mercredi, 17. décembre 2003 4:32 16
Phonebook 21
When you copy the contents of your
SIM phonebook into your phone, you
can still use the phonebook of your SIM
card, even though it features less fields of information.
Your mobile phone only manages one phonebook at a
time and will ignore the information relative to the
other one: e.g., if «Smith» is present in both
phonebooks and if you delete it in the phone, it
remains unchanged in the SIM.
The default selected phonebook is the
one located in your phone. It can hold
up to 499 names and can be reset at
once using the
Reset phonebook
option. Depending
on SIM card capacity, names added to this
phonebook can then be copied into the SIM
phonebook (see “Copy to SIM” page 25).
In the SIM card
To add a name in the SIM phonebook:
1.
Press
-
to enter the phonebook, select
New
,
then press
,
.
2.
Enter the name, then the number of your choice
and press
,
.
A number can contain a maximum of 40 digits,
depending on your SIM card.
Entering all numbers, including local ones with
international prefix, country code and area code will
allow you to dial them from any location.
3.
Select the type of number allocated to the name:
Phone
,
Fax
or
Data
and press
,
to confirm
and store this name in your phonebook.
In the phone
The phonebook in your phone can holds more
information fields than the SIM card phonebook.
Including (in latin characters):
You can create up to 499 records, holding up to a
maximum of 7 information fields for each, with a
maximum of 5 numeric fields. For example, you can
Phone’s phonebook
Add names in the phonebook
In SIM card
In phone
First and last names up to 20 characters
Numbers fields
(Mobile, Work, etc.) up to 40 digits and 1 «+»
Extra fields
(e-mail and note) up to 50 characters
Group selection 50 groups available
Philips855_GB_MKG_4311 255 58331.book Page 21 Mercredi, 17. décembre 2003 4:32 16
22 Phonebook
save 2 mobile numbers, 3 work numbers, an e-mail
address and a text note, all for the same person.
Add a record in the phone’s phonebook
Add a name field
1.
Press
-
to enter the
Phonebook
, select
<New>
, and then press
,
.
2.
Enter the last name of your contact and confirm
by pressing
,
, then enter their first name and
confirm by pressing
,
.
One of the two name fields can be empty, but not both.
To go back to the previous field, press
c
.
Add a number/text field
1.
After entering the name of your contact, you will
be in the
Number type
menu. You can choose
from numerical fields (Mobile, Fax, Data, Pager,
Home, Work) or alphanumeric fields (Note, e-
mail). Make your selection and enter the relevant
number or text. Then press
,
to save this
new record.
2.
The phone will then prompt you the
Group:
choose the group you want this name to belong
to and press
,
to confirm. The record is then
saved in your phone’s phonebook.
3.
You can associate a specific
Melody
and
to
each group, as well as
Rename
groups. Select
Phonebook > Phonebook set. > Group settings
,
then refer to “Fotocall: see & hear who’s calling”
page 22 for complete information). When
receiving a call from a contact associated to a
group, the melody and/or picture defined for
this group will automatically ring and/or appear
on the screen.
Own numbers
The
Own numbers
option that appears in your
phonebook should contain your own phone number.
If not, we advise that you enter your mobile number
as well as any other relevant information.
Although all its fields can be empty, the «Own
numbers» item cannot be deleted.
This feature is only available when you select the
phonebook of your phone, NOT the SIM phonebook.
The Fotocall feature allows you to personalize the
groups available with their own name («Friends»,
«Office», etc.), a given picture (from the
Picture album
)
and a given melody (from the
Ringers
list).
You can link one or several contacts from your
phonebook to a group. When a name in that group
Fotocall: see & hear who’s calling
Philips855_GB_MKG_4311 255 58331.book Page 22 Mercredi, 17. décembre 2003 4:32 16
Phonebook 23
calls, the contact’s name will appear along with the
defined picture of that group. The melody defined for
that group will also ring.
For that important person, why not set up a group just
for them. Use the camera to save their picture in the
Picture album
and
Sound recording
to save their voice
as a ringer. When they call, you will truly be able to
see and hear them (for camera, see page 14 and for
sound recording, see page 68).
1.
To use Fotocall, you need to be using the
phonebook in the phone; if you are not already
doing so, see “Copy the SIM phonebook”
page 2.
2.
Then select
Groups setting
, press
,
and select
the group of your choice.
3.
Rename the group to be identified («Friends»,
«Kids», etc.) and select the
Melody
and the
to be associated to this group.
4.
Long press
c
to go back to idle, then
-
to
display the content of your Phonebook. Select a
contact you wish to link to this group and press
,
. Then choose
Select group
and select the
group of your choice.
When this contact calls you, the
Melody
and
associated to his group will ring/appear on the screen.
Once you have stored names in your phonebook,
press
-
when in idle mode to access the
Phonebook
. You can search for a name in the
phonebook by pressing the corresponding key for the
letter that you want to go to in the list (e.g., press
8
twice to access the letter «U»). The first record starting
with this letter is selected in the list. Depending on the
phonebook menu you have selected, you will have
access to part or all of the following options:
In the SIM card
Select a name in the SIM card phonebook, then press
,
to access one of the following options:
-
Delete
to delete the selected name and number,
Edit and manage names
•Delete
•Show
•Copy to SIM
•Flash dial
•Change type
• Call
•Change name
•Include in a group
• Delete all
•Send an SMS
•Send an MMS
•Make default
• Copy to phone
• Call handsfree
• Associate a voice dial
•Send via IrDA
Philips855_GB_MKG_4311 255 58331.book Page 23 Mercredi, 17. décembre 2003 4:32 16
24 Phonebook
-
Change
to change the selected name and all
related information,
-
Copy to phone
to copy the selected name and
all related information into the phonebook
located in your phone. If you cancelled the
automatic copy of the SIM phonebook at the
very first switch of your phone, you need to do
it manually.
In the phone
Add a field
1.
To add a new field to an existing record, select
the name of your choice, select
Show
and press
,
.
2.
Select
<New>
and press
,
. Choose the type
of field to be added and press
,
. Enter the
number or text, then press
,
to save changes.
3.
Repeat steps 1 and 2 to add up to 6 fields to the
same record. Make a short press on
c
to go
back to the previous menu, or a long press to go
back to the idle mode.
Numbers or text will appear in order of creation date.
The first fax or phone number you enter becomes the
default number. As such, it appears in first position in
the list. To make another number default, see “Make
default” page 25. Alphanumeric fields (note and e-
mail) can only be changed or deleted.
Change a field content
1.
To change the content of a field in an existing
record, select the name of your choice, press
,
, select
Show
and press
,
again.
2.
Select the field to be changed in the list and press
,
.
3.
In the carousel that appears, select
Change
and
press
,
. Make the changes wanted and press
,
to save them.
Change a field type
To change a field type of an existing
record, repeat steps 1 to 3 of the
“Change a field content” paragraph.
Then select
Change type
in the carousel menu, select
the new type of number and press
,
to confirm
your choice.
If you copied your SIM phonebook into your phone,
some numbers might appear as being of «No type» and
don’t have any icon. «No type» numbers can be
changed: follow the procedure described previously to
define a type for these numbers.
Delete a field
To delete a field of an existing record,
repeat steps 1 to 3 of the “Change a field
Change type
Delete
Philips855_GB_MKG_4311 255 58331.book Page 24 Mercredi, 17. décembre 2003 4:32 16
Phonebook 25
content”paragraph. Then select
Delete
in the carousel
menu, and press
,
to confirm.
Make default
The first number you enter when
creating a new record becomes the
default number: it will appear first on
the fields list and is automatically called when pressing
the pick-up key or when pressing
,
and selecting
the
Call
,
Call handsfree
or
Send SMS
option. To change
the default number (e.g. make the «Work» number
default instead of the «Home» number), repeat steps 1
to 3 of the “Change a field content” paragraph. Then
select
Make default
in the carousel menu, and press
,
to confirm.
Copy to SIM
As mentioned earlier, entering names in
the SIM phonebook can be useful if you
change phones frequently. If you copy
phone numbers into the SIM card, your phonebook is
always updated when switching phonebooks or when
using another phone.
To copy a number into the SIM card phonebook,
repeat steps 1 to 3 of the “Change a field
content”paragraph. Then select
Copy to SIM
and press
,
.
For your own comfort and safety, ensure you move the
phone away from your ear when calling handsfree,
especially when increasing the volume.
Emergency number
The emergency number will call the
emergency services number in your
country. In most cases, you can call this
number even if you haven’t yet entered your PIN.
1.
Depending on the network operator, the
emergency number can be dialled without the
SIM card being inserted. In Europe the standard
emergency number is 112, in the UK it is 999.
To call this number, enter it in idle mode by
pressing the corresponding keys, or press
,
and select
Phonebook
>
View Names List
>
Emergency number
.
2.
Press
(
to dial and press
)
to hang up.
Other number
Enter a number
In idle mode, enter a number by
pressing the corresponding keys. Press
(
to dial and press
)
to hang up.
Make default
Copy to SIM
Make calls
SOS Call
Call
Philips855_GB_MKG_4311 255 58331.book Page 25 Mercredi, 17. décembre 2003 4:32 16
26 Phonebook
Pressing
,
will let you access a carousel allowing
you to call this number, store it or send a SMS.
Select a name
1.
Press
-
and select the record of your choice.
2.
If you selected the phonebook in your SIM card:
- once the record is selected, simply press
(
to call, or
- press
,
twice to access the next carousel,
then select
Call
or
Call handsfree
and press
,
to dial the number.
3.
If you selected the phonebook in your phone:
• To call the
default
number:
- once the record selected, simply press
(
to
dial, or
- press
,
to access the record carousel, then
select
Call
or
Call handsfree
.
• To call any other number, choose
Show
once the
record is selected and choose a number type in the
list (Mobile, Home, etc.). Press
,
to access the
next carousel and select
Call
or
Call handsfree
.
4.
In all cases, press
)
to hang up.
You can also switch to handsfree while a standard call
is in progress: press
,
, select
Activ.h/free
and press
,
to confirm.
Use Flash dial
In idle mode, press and hold a key
between
2
and
9
to dial the
associated entry (see “Hotkeys”
page 29): connection is established. Press
)
to
hang up.
Flash dial
Philips855_GB_MKG_4311 255 58331.book Page 26 Mercredi, 17. décembre 2003 4:32 16
Settings 27
7 • Settings
The
Settings
menu allows you to customise your
phone and change the settings related to each available
option (sounds, time and date, security, etc.). The
Profiles
menu allows you to change several settings at
once (see page 39).
Silent
Allows you to set the
Silence
mode
On
or
Off
. When this setting is
On
, all alerts
are deactivated and the vibra alert is
active.
The
Silent
mode also applies to key tones.
Ringer volume
By default the ringer volume can be set
to
Medium
. Press
+
or
-
to set the
volume of your ringer from
Silent
to
Increasing
.
Ringer
Allows you to select the ringer tone
from the choices available. The list also
includes recorded sounds and melodies attached to
messages you receive (from e-mail, SMS, etc.).
Scroll through the list by pressing
+
or
-
and
wait to hear the selected melody being played.
Press
,
to select this melody as ringer,
c
to
cancel, or move to the next melody.
You will not hear the melody if the volume ringer is set
to
Off
or if the
Silence
mode was activated (see page 5).
Messages Ringer
Allows you to set an alert beep
On
or
Off
, for each time you receive a new
message. When
On
, this option also
allows you to select the alert of your choice from the
ringers list.
Equaliser
This option allows you to choose from
different audio settings, also available
while a call is in progress. In this case,
press
,
, select
Equaliser
, scroll through the list and
wait a few seconds to hear the difference. Press
,
to
confirm your choice.
Sounds
Silent
Ringer volume
Ringer
Messages Ringer
Equaliser
Philips855_GB_MKG_4311 255 58331.book Page 27 Mercredi, 17. décembre 2003 4:32 16
28 Settings
Key tones
Allows you to set the key tones
On
or
Off
. Even when set
Off
, DTMF are
played during calls (see page 85).
Sounds Alerts
Allows you to set alert beeps
On
or
Off
for the following items:
-when an
Event
you programmed in your
organiser is due,
- when you have missed a call,
-when the
Battery
is low and requires charging,
- to manage the duration of your calls, first
after 45 seconds, then every minute of an
ongoing call (the beep cannot be heard by the
caller).
This menu only allows you to activate/deactivate the
alert sounds, NOT the alerts themselves. E.g. setting
the event alert
Off
will not prevent your phone from
displaying the
Reminder
screen (if you programmed
one), but the corresponding sound will not be played.
Vibra alert
Allows you to set the vibra alert
On
or
Off
when receiving a call, when an event
set in the organiser is due, when you receive a message
and when the alarm rings.
The vibra alert is always
Off
when you connect the
charger or the Cigarette Lighter Adapter.
Screen saver
Allows you to set the screen saver
On
or
Off
. When
On
, it will run a slide show
in idle mode, by using the jpeg file(s)
you have stored in your phone and selected.
Setting the Screen saver
Off
automatically activates
the
Economy mode
, i.e., the current time displayed on
a black background. This mode increases the
autonomy of your phone (increases your battery life).
1.
When setting the screen saver
On
, select a
picture in the list that appears by
pressing
<
or
>
(you deselect it also by
pressing these keys), then press
-
to move to
the next picture. Once you selected the pictures
of your choice, press
,
to activate the screen
saver.
You must select several pictures (up to 10) in order to
display a slide show. When selecting only one picture
Key tones
Sounds Alerts
Vibra alert
Display
Screen saver
Philips855_GB_MKG_4311 255 58331.book Page 28 Mercredi, 17. décembre 2003 4:32 16
Settings 29
to be used as screen saver, only this picture will be
displayed.
2.
Select
Start delay
and press
+
or
-
to
choose a value. When in idle mode, the screen
saver will start according to the time limit you
have set.
3.
Then select the
Display period
and press
,
.
The timing you have set will be applied between
each picture of the slideshow.
Animation
Allows you to set the animation of the
carousel menus
On
or
Off
. When
On
,
this option will also scroll texts, such a
message selected in the
Read SMS
menu.
Deactivating this function increases the autonomy of
your phone.
Contrast
Allows you to choose among several
levels of contrast.
Backlight
The backlight is activated when
receiving incoming calls or messages,
browsing lists and menus, etc. Press
+
or
-
to
set the backlight
Duration
by selecting one of the
available values and press
,
to confirm.
Deactivating this function increases the autonomy of
your phone.
Wallpaper
Allows you to set the Wallpaper of the
main screen
On
or
Off
. When
On
, the
picture(s) you selected is (are) displayed
in
Normal
or
Fade
mode in idle mode, if you didn’t
activate a slide show.
Only JPEG type pictures can be used as Wallpapers.
Sub wallpaper
Allows you to set the Wallpaper of the
external screen
On
or
Off
. The behavior
is then the same as the Wallpaper
described above.
Hotkeys
Instead of entering the various menus
and browsing the lists, you can set up
direct access to a specific function by
Animation
Contrast
Backlight
Short cuts
Wallpaper
Sub wallpaper
Wallpaper
Philips855_GB_MKG_4311 255 58331.book Page 29 Mercredi, 17. décembre 2003 4:32 16
30 Settings
linking it to a
Hotkey
. A long press on the key will
then automatically activate the function or call the
associated number (Flash dial).
You can only program keys
2
to
9
and
#
, as
keys
0
(launch Wap) and
1
(call voice mailbox)
are predefined and locked, preventing
reprogramming. Depending on your service provider,
other hotkeys may be predefined and locked.
1.
Select a key from
2
to
9
and press
,
.
2.
Browse the list to select the function you wish to
associate with this key (see list following). Press
,
to confirm your choice.
If the selected key is already set, you can reprogram it:
select
Settings
>
Hotkeys
> a hotkey in the list. Press
,
twice, select
Change
and press
,
. This will
bring you to the list of available functions.
3.
To use the hotkeys, simply press and hold the
key corresponding to the function you want to
launch or to the number you want to dial while
in idle mode.
You can associate hotkeys
2
to
9
to the
functions of the following table:
Dials the associated number of the
phonebook.
Opens the
Send Messages
menu.
Opens the
Read
Messages
menu.
Activates the
Instant message
feature,
to quickly
Reply
to the sender of the
received message.
Launches MMS for you to send a
multimedia message.
Activates the
Silence
profile (vibra on,
ringer volume off).
Activates the
Headset
profile (ringer
volume medium, any key answer on).
Flash Dial
Send SMS
Read SMS
Instant message
MMS
Active. Silence
Activ. Headset
Philips855_GB_MKG_4311 255 58331.book Page 30 Mercredi, 17. décembre 2003 4:32 16
Settings 31
Activates the
Meeting
profile (vibra on,
ringer and all keys set to silent).
Activates the
Outdoors
profile (ringer
volume high).
Activates the
Personal
profile.
Activates the
Autonomy
profile, which
extends the battery autonomy
(animation off, vibra off, backlight off,
ringer volume medium).
Direct access to the
Calculator
.
Redials the number of the last call
received.
Dials the emergency call number.
Meeting
Activ.Outdoors
Activ. Personal
Activ. Autonomy
Calculator
Reply last no.
SOS call
Launches the Demo mode.
Opens the
E-mail
menu for access to
the mail boxes.
Displays the remaining credit balance.
Subscription dependent
Displays the
Accumulated cost
of
outgoing calls.
Subscription dependent
Opens the
Add event
menu of the
Organiser.
Displays the
Events
list of the
Organiser menu.
Opens the
Alarm
menu.
Demo mode
E-mail
Show balance
Accum. cost
Add new event
Show events
Alarm Clock
Philips855_GB_MKG_4311 255 58331.book Page 31 Mercredi, 17. décembre 2003 4:32 16
32 Settings
Voice command
Instead of entering the various menus
and browsing the lists, you can also set a
voice tag that will activate a feature
(e.g., launch the Calculator).
Allows to record a new sound.
Open the list of sounds (including
your own recordings) for you to
choose from. Press
>
to play.
Launches a
WA P
session.
Subscription dependent
Opens the
Screen saver On/Off
menu.
Forwards ALL calls to the voice
mailbox.
Direct access to the
Brick Game
.
Opens the
Games
menu.
Subscription dependent.
Record
Play
WAP
Screen saver
To voice mail
Brick Game
Games
Automatically swaps phonebooks.
Launches Java.
Launches an infrared connection.
Direct access to the Euro converter
(from currency).
Direct access to the Euro converter (to
currency).
The Euro converter is available upon
subscription and only in countries us-
ing the Euro.
Phonebook select.
JAVA
Infrared
-> Euro
Euro ->
Voice Command
Philips855_GB_MKG_4311 255 58331.book Page 32 Mercredi, 17. décembre 2003 4:32 16
Settings 33
You can associate a Voice command to all the
functions supported by the
Hotkeys
(see page 29),
except for «Get mail» and «Alarm clock».
1.
Select
Settings
>
Voice Command
>
<New>
and
press
,
, then browse the list to select the
function to be set with a voice tag. Press
,
to
confirm your choice.
2.
When
Press OK and speak
appears, follow the
instructions displayed on the screen. When
prompted to record your voice tag, make sure
you are in a quiet environment, choose a short
and simple word and clearly pronounce it.
3.
Press
c
and repeat the steps described above
to add more voice commands.
To use the voice command, press and hold
,
when
in idle mode, then say the recorded voice tag. Words
recorded as voice tags can be played, changed or
deleted at any time.
Voice dial
Voice dial allows you to quickly call a
name from your phonebook: set a voice
tag by recording a word that will call the
corresponding name when pronounced.
1.
Select
Settings
>
Voice d i a l
>
<New>
and press
,
.
2.
Browse the list to select the call number to be set
with a voice tag. Depending on the selected
phonebook (see “Phonebook” page 20):
- SIM phonebook: select a name in the list and
press
,
,
- Phone’s phonebook: select a name in the list,
then the phone number of your choice if
several numbers were stored for this name and
press
,
.
3.
When
Add voice tag?
appears, press
,
and
follow the instructions displayed on the screen.
When prompted to record your voice tag, make
sure you are in a quiet environment, choose a
short and simple word and clearly pronounce it.
To use the voice command, press and hold
,
when
in idle mode, then say the voice tag corresponding to
the number you want to dial.
To display the list of voice dials you have defined,
select
Settings
>
Voice Commands
or
Voi ce d ia l
and press
,
. Words recorded as voice tags can be played,
changed or deleted at any time.
Up to 15 voice tags can be defined and shared between
voice dial and voice command.
Voice Dial
Philips855_GB_MKG_4311 255 58331.book Page 33 Mercredi, 17. décembre 2003 4:32 16
34 Settings
Navigation icon
Allows you to set the Navigation icon
On
or
Off
. When
On
, it replaces the
clock icon in idle mode, and allows you
to spot the menus that can be access via
the phone’s navigation key.
Public names
Allows you to manage a specific names
list, called
Public Names
list, and restrict
calls to this list via the
Call restriction
option.
This feature is subscription dependent and requires a
PIN2 code (see page 35).
Call restriction
Allows you restrict the calls to the
Public
Names
list. In this case, you can only
access the names of the
Public names
list,
as opposed to the
Phonebook
of the main menu.
This function is subscription dependent and requires
a PIN2 code (see page 35). Please note that when
activating this option, it might also apply to WAP and
e-mail connections over GPRS.
Public names
Allows you to consult and modify your
Public Names
list. You can enter a new
name, modify or delete a name in the
list via PIN2 code. Use the
<New>
option to enter the
name and phone number, then select the number
type:
Phone
,
Fax
or
Data
. Names in this list can be
changed or deleted.
Call barring
This menu allows you to limit the use of
your phone to specific calls by letting
you bar both outgoing and incoming
calls. This function is network dependent and requires
a specific call barring password supplied by your
service provider.
Outgoing calls
The
Outgoing
menu allows you to select
between
All
calls,
International
calls and
Intl. Exc. Home
calls (the latter allowing
you to call your home country when you are abroad).
You can also
Deactivate
the bar on outgoing calls.
These menus then allow you to bar, within each
available option,
All calls
,
Voice c a l ls
,
Data calls
or
Fax
calls
.
Security
Navigation
Public names
Call restriction
Public names
Call barring
Outgoing
Philips855_GB_MKG_4311 255 58331.book Page 34 Mercredi, 17. décembre 2003 4:32 16
Settings 35
Incoming calls
The
Incoming
menu allows you to select
All
calls or
When roaming
. It also
provides access to the
Cancel
menu to
remove bar on incoming calls.
These menus then allow you to bar, within each
available option,
All calls
,
Voice calls
,
Data calls
or
Fax
calls
.
Status
In each sub-menu (All calls, When
roaming, etc.), the
Status
option allows
you to know whether a type of call is
barred or not.
Change codes
Allows you to change your
PIN
and
PIN 2
codes, as well as the call
Barring
code
.
Depending on your SIM card, some features or
options may require a PIN2 secret code. This is a
second secret 4 to 8-digit code given to you by your
operator.
If you enter a wrong PIN2 code 3 times, your SIM
card is blocked. To unblock it, request the PUK2 code
from your operator or retailer.
If you enter an incorrect PUK code 10 times in a row,
the SIM card will be blocked and unusable. If this
happens, contact your operator or retailer.
PIN protection
This allows you to set the PIN
protection
On
or
Off
. When
On
, you
will be asked to enter your PIN code
when switching your phone on.
You cannot change your PIN code if this option is
Off
.
This menu allows you to handle the connection
between the phone and the network, register
manually the available networks and manage your
preferred networks.
GPRS attach
Your mobile integrates features that
support GPRS (Global Packet Radio
Service), a service allowing you to
exchange data with high speed rates and to stay always
on-line (i.e. have a permanent connection to the
Internet and WAP).
Contact your phone operator to have full information
about GPRS availability over their network and for
Incoming
Status
Change codes
Network
PIN protection
GPRS attach
Philips855_GB_MKG_4311 255 58331.book Page 35 Mercredi, 17. décembre 2003 4:32 16
36 Settings
an appropriate subscription. You might also need to
configure your phone with the GPRS settings supplied
by your operator, by using the menus described in this
section.
This menu allows you to define the attach mode of
your mobile phone to the GPRS service:
Always on
Your phone will always register to the GPRS service.
This option allows faster GPRS connection. However
it will increase energy consumption.
For data calls
Your phone will automatically register to the GPRS
service only when required. This option reduces
energy consumption, however it will increase the
connection delay.
In spite of these settings, you must still select the bearer
(GSM or GPRS) in the menus of each application to
be used (e.g., WAP, MMS, e-mail, etc.).
Register again
Provides you with a list of the networks
available in the area when the
Manual
mode is selected. Select the network you
want to register with and press
,
to confirm.
Preferred list
Allows you to build a network list in
order of preference. Once defined, the
phone will try to register on a network,
according to your preferences.
Access settings
This menu allows you to create several
data profiles: when using WAP or when
sending a multimedia message (MMS),
the selected profile will be used to connect to the
GSM or GPRS network.
All options described below are operator and/or
subscription dependent.With some operators, you may
receive a SMS which contains access parameters that
will be stored automatically. Please contact your
network operator for detailed information on this
subject.
Change name
Allows you to enter or change the name
of the selected profile. Press
,
, enter
the name of your choice and press
,
to confirm.
Some pre-configured profiles might be locked,
preventing re-programming and renaming.
Register again
Preferred list
Access settings
Change name
Philips855_GB_MKG_4311 255 58331.book Page 36 Mercredi, 17. décembre 2003 4:32 16
Settings 37
Show
Allows you to visualise all parameters of
the selected profile (ISP number, APN,
etc.), either
GSM
or
GPRS
.
GSM settings
Allows you to enter or change the GSM
settings and gives you access to the
following items:
Login
and
Password
allow you to enter the login and
password needed. In both cases, enter the information
and press
,
to confirm.
Phone Number
allows you to enter the phone number
needed to establish a connection. Select
Phone
numbers
and press
,
, then press
+
or
-
to
select:
-
ISDN No.
to enter an ISDN ISP number, OR
-
Analogic No.
to enter an analogic number.
In both cases, enter the «+» sign followed by the
number provided by your operator and press
,
.
Contact your operator to know what type of number
you should select.
Inactivity time
allows you to enter an inactivity time
period after which the phone automatically
disconnects (if a connection was in progress) and
returns to idle screen. Select
Inactivity time
and press
,
, then enter a value (in seconds) of over 30 s.
and
press
,
.
GPRS settings
This allows you to change the GPRS
settings,
Login
,
Password
and
Inactivity
time
(the same fields and the same
instructions as for GSM settings, please refer to the
previous section).
APN
allows you to enter the address of the external
data network you want to connect to, a text string (or
IP address, e.g., wap.operatorname.fr) used to
establish the connection. Select
APN
and press
,
,
then enter the appropriate address
and press
,
.
Error messages during connections are mainly due to
incorrect parameters: you should contact your
operator before first use, in order to have the
appropriate settings. With some operators, the access
parameters can be set remotely. Please check with your
operator.
This menu allows you to set the time and date, time
zone, daylight savings, and change the clock display
mode.
Show
GSM settings
Time and date
GPRS settings
Philips855_GB_MKG_4311 255 58331.book Page 37 Mercredi, 17. décembre 2003 4:32 16
38 Settings
Clock display
Allows you to select
Analogue
,
Digital
or
Tiny
time formats when shown in idle
mode, by pressing
+
or
-
. In all
cases, press
,
to confirm.
Set date
Allows you to set the date by pressing
the appropriate numeric keys (you can
also set the date by moving
+
or
-
). Press
,
to confirm.
Date format
Allows you to select one of the two
available date formats, either
We s te r n
or
Thai
. Press
,
to confirm.
Time zone
The time zone and daylight savings are to be set first.
You should then double-check date and time if
previously set. To know which time zone you are in,
we recommend you to check in an atlas or an
encyclopedia.
The
Time zone
option allows you to set
the time zone you belong to, according
to GMT (Greenwich Meridian Time).
Move
+
or
-
to select the setting corresponding
to your area.
Daylight saving
This setting only concerns countries in which time is
set according to summer/winter time (e.g. Greenwich
Meridian Time / British Summer Time).
This option allows you to set the
daylight savings to
On
(in summer
time) or
Off
(in winter time) by
moving
+
or
-
. As this setting impacts the date
and time option, it should be set first. If daylight
saving is
On
and you set the time to 12:00, it will
automatically switch to 13:00 when turning the
option to
Off
.
Set time
Allows you to set the time by pressing
the appropriate keys or
moving
+
or
-
to increase or
decrease the time minute by minute.
Clock display
Set date
Date format
Time zone
Daylight saving
Set time
Philips855_GB_MKG_4311 255 58331.book Page 38 Mercredi, 17. décembre 2003 4:32 16
Settings 39
This menu allows you to select a language for all menu
text. Press
+
or
-
to select the language of your
choice, then press
,
to confirm.
This menu allows you to access a group of predefined
settings, which let you quickly adapt your phone to
your environment by changing several settings at
once. For example, selecting
Meeting
will set your
ringer volume to silent, activate vibra and deactivate
the key tones (the other items are set according to the
settings you configured). When your meeting is over,
selecting
Personal
will reactivate all your usual settings.
When you associate a hotkey to a profile (e.g. long press
key
3
activates
Meeting
, see “Hotkeys” page 29),
also long press this key to deactivate it and go back to
the
Personal
settings.
The settings listed in the column
Personal
, in the
following table, are default settings preset during
production. As you can change them, the personal
settings in your phone may differ from the table.
Each box of the table refers to the settings as
stored in the
Personal
menu (whether you have
changed the settings or not).
Language
Profiles
Profiles
Vibra alert
On Off On
Ringer volume
Medium Medium
High Silent
Key tones
On Off
Organiser alerts
On
Battery low alert
On
Message alert
On
Backlight
10 sec Off
Zoom
Off
Any key answers
Off
Animation
On Off
Personal Autonomy Outdoors Meeting
Philips855_GB_MKG_4311 255 58331.book Page 39 Mercredi, 17. décembre 2003 4:32 16
40 Settings
When connecting an accessory, the settings described
in the table below also become available. When
disconnecting the accessory, the phone goes back to
the
Personal
profile.
Accessories
Profiles
Vibra alert
Off
Ringer volume
Medium Medium
Key tones
Organiser alerts
Battery low alert
Message alert
Backlight
Off
Any key answers
On
Animation
Off
Headset Activate Car
Philips855_GB_MKG_4311 255 58331.book Page 40 Mercredi, 17. décembre 2003 4:32 16
Messages 41
8 • Messages
The
Send SMS
item of the
Messages
menu allows you to:
• send a standard or customised short text message
to someone,
• edit the last message sent and send it again,
• add an iMelody, pre-defined sounds, an anima-
tion or a picture to your message.
The features above are not available from the idle
mode when the
Instant message
feature is
On
(see
page 53). In this case, you can only access the
Answer
option.
The Standard SMS messages are displayed in a list.
Press
+
or
-
to browse: for example
Can you
ring me back at this number..
allows you to select a pre-
configured message including your number, if this
number is the first one of the
Own num.
option (see
page 22).
Send a SMS
To a n a m e i n t h e l i s t
To the default number if several (phonebook in
phone) or to the unique phone number (phonebook in
SIM)
1.
Press
-
, select the name of your choice and
press
,
.
2.
Select
Send SMS
and press
,
, then select the
type of message to be sent and press
,
. Enter
your message, attach a graphic or a sound if you
wish, then select
Send now
or
Save
(see below).
To the number of your choice (phone name list only)
1.
Press
-
and select the record of your choice,
then press
,
, select
Show
and press
,
.
2.
Select the number of your choice and press
,
.
3.
Proceed as described in step 2 of the previous
paragraph.
To any other name
To send a short message to someone whose number
isn’t stored in the phonebook, press
,
and select
Messages
,
SMS
then
Send SMS
and
New
. Enter the
phone number to which the message should be sent to
and press
,
. Then follow the instructions detailed
above to send a message.
SMS
Send SMS
Philips855_GB_MKG_4311 255 58331.book Page 41 Mercredi, 17. décembre 2003 4:32 16
42 Messages
Together with an attachment
This option allows you to attach a sound, picture or
animation to your message and press
,
to confirm
and attach it to your message. Depending on the type
of file you want to attach, select
Add graphic
to attach
a bitmap image or an animation, and/or
Add sound
to
attach a melody. Select the sub-menu of your choice,
then one of the available items in the list that appears,
and press
,
to confirm and attach it to your
message.
You can send up to 2 attachments of 2 different types
together with your SMS. Animations and pictures are
exclusive: if you first select an animation, then a
picture, only the picture will be taken into account
and vice-versa.
Some pictures, animations and sounds are pre-defined
and supplied as standard with your mobile phone.
Personal pictures and sounds, e.g., that you have
received via SMS or e-mail and then stored in the
relevant menus, will automatically appear in the
«Own» sub-menus (Own melodies, Own animations,
etc.). You cannot send «Own» items via SMS when
they are copyright-protected.
Send now
This allows you to send the current
message you have entered (to learn how
to enter text and numbers, see “Text or
number entry” page 12). Press
,
to
confirm.
Save
Allows you to store the current message
and its associated icon and melody if
any. Press
,
to confirm.
Read SMS
The
Read SMS
option in the
Messages
menu allows you to consult the list of
SMS you have saved and received, and
that are first stored on your SIM card. Several options
allow you to then manage them directly on your
mobile phone.
Received Messages
The messages you have received and already read are
labelled with . Messages received but not yet read
are labelled with a sealed envelope icon. Select a
message and press
,
to read it. When displayed,
press
,
to access the following options:
Reply
to the sender,
Send now
Save
Read SMS
Philips855_GB_MKG_4311 255 58331.book Page 42 Mercredi, 17. décembre 2003 4:32 16
Messages 43
Saved Messages
The messages you sent are labelled with in normal
mode or with a mail box icon in auto save SMS mode
(see page 44). Select the message you want and press
,
to read it. When displayed, press
,
to access
the same options, including storing the caller’s
number.
Forward
the selected message (choose the
recipient in the phonebook or enter a
phone number manually),
Delete
the selected message,
Store
number
of the sender if it is attached to the
message,
Store
melody
if a melody was sent together with the
SMS,
Store
graphic(s)
if one or several graphics and/or
animations were sent together with
the message,
Extract
a number included in the message
itself, if this number is included in
double quotes (several numbers can
be included and extracted),
Call
the sender of the message (operator-
dependent),
Edit
a message in the
Read
or
Archive
folder, modifiy it and resend it to
someone (you can add a picture or a
sound).
If a picture or a sound was attached to
the message you edit, you must first
detach it and store it in the
album
or in the
Own melodies
menu of
the ringers list. Then re-attach it to
your message (see page 42).
Move to
archive
allows you to store read messages in
the phone memory. Saved messages
can then be consulted by pressing
,
and selecting
Messages
,
SMS
Archive
,
Moving a message to the archive list
deletes it from the read SMS list.
Philips855_GB_MKG_4311 255 58331.book Page 43 Mercredi, 17. décembre 2003 4:32 16
44 Messages
Delete all SMS
Allows you to delete all the messages of either the
Read
SMS
(messages on SIM card) or
SMS Archive
(messages
in phone) lists of the
Messages
menu.
SMS settings
This menu allows you to customise your
SMS via the options described below.
SMS centre
Allows you to select your default SMS
centre.
If not available on your SIM card,
you must enter your SMS centre number
.
Signature
Allows you to sign your SMS. By
default, your signature is you phone
number, added at the end of your
message (which length is consequently reduced). You
can
Edit
the signature,
Change
and
Save
it.
Validity period
This feature is subscription dependent.
Allows you to select the length of time
your message is to be stored in your
SMS centre. This is useful when the
recipient is not connected to the network (and thus
cannot receive your message immediately).
Reply path
This feature is subscription dependent.
Allows you to set the Reply path option
On
or
Off
. When
On
, it allows you to
transmit the number of your SMS
message centre together with the message. Your
correspondent can then reply using your own SMS
centre and not theirs. This speeds up the rate of
transmission.
Delivery report
This feature is subscription dependent.
Informs you via an SMS whether your
SMS was received or not. This option
can be set
On
or
Off
.
Auto save SMS
Allows you to set
On
or
Off
the option
of automatically saving messages sent in
the
Archive
menu.
SMS Archive
Allows you to consult all read messages
you saved and to
Reset
all archived
messages at once. You save a message by
activating the
Auto save SMS
option (see above), or by
SMS settings
SMS centre
Signature
Validity period
Reply path
Delivery report
Auto save SMS
SMS Archive
Philips855_GB_MKG_4311 255 58331.book Page 44 Mercredi, 17. décembre 2003 4:32 16
Messages 45
selecting a received message, pressing
,
twice and
selecting
Move to Archive
.
If not included in your phone subscription, you must
subscribe to an e-mail account (over the phone or via
Internet from a computer) and have received the
settings information from your provider. In this case,
all parameters are communicated to you by your
provider and/or operator as described below and must
be entered as given.
If included in your subscription, you simply have to
enter the login, password and e-mail address of your
e-mail account. In some cases, your operator might
also be your e-mail service provider.
Your phone might have been pre-configured. In this case,
most parameters are already set and you don’t have to
change them
(except for
Login
,
Password
and
E-mail
address
which are up to you when creating an e-mail
account).
To enter text and numbers, including specific signs
such as @ or %, see the characters table described
page 13.
Settings
Network access
This menu allows you to configure your phone and to
handle the connection to the network, whether GSM
or GPRS, in order to then connect to the appropriate
server that will let you send and receive e-mails.
All options described below are operator and/or
subscription dependent.
1.
Press
,
, select
Messages
>
E-mail
>
E-mail 1
>
Settings
and press
,
.
2.
Select
Network Access
and press
,
.
Bearer
This menu allows you to select the type
of network used when launching a
connection.
GSM
or
GPRS
: your mobile will only use the GSM or
the GPRS network for e-mail connections.
GPRS first
: your mobile will first try to connect to the
GPRS network, then to the GSM network if the
GPRS network isn’t available when connecting.
Selecting this option you need to have both GSM and
GPRS settings configured.
E-Mail
Bearer
Philips855_GB_MKG_4311 255 58331.book Page 45 Mercredi, 17. décembre 2003 4:32 16
46 Messages
GPRS settings
This menu allows you to enter or
change the GPRS settings
communicated to you by your operator,
which are:
APN
,
Login
and
Password
. All settings must
be entered as given to you by your operator.
Error messages during connections are mainly due to
incorrect parameters: you should contact your
operator before first use, in order to have the
appropriate GPRS parameters.
GSM settings
This menu allows you to enter or
change the GSM settings
communicated to you by your operator,
which are:
Phone number
,
Auto disconnection
,
Login
and
Password
. Enter them as defined.
Phone Number
: allows you to enter the phone number
provided by your ISP and needed to establish a
connection. Press
+
or
-
to select:
-
ISDN number
to enter an ISDN ISP number,
OR
-
Analogic No.
to enter an analogic number, then
press
,
.
Contact your ISP to know what type of number you
should select.
Auto disconnection
: allows you to select an inactivity
time period after which the phone automatically
disconnects (if a connection was is progress) from the
network. Press
+
or
-
to select a value from 3
to 10min. and press
,
to validate.
The lack of exchanges with the network (connecting,
sending an e-mail, disconnecting) defines the
inactivity time period leading to auto disconnection.
Login
and
Password
were up to you when you
subscribed to your account. Enter them also as
defined.
E-mail server access
The menus described in this section feature settings
needed to connect to the e-mail server of your Internet
Service Provider (ISP) via your mobile phone. Most
parameters are communicated to you by your service
provider and must be entered as given.
1.
Press
,
, select
Messages
>
E-mail
>
E-mail 1
>
Settings
and press
,
.
2.
Select
E-Mail server
and press
,
. The fields to
be completed are the following:
POP3 address
,
SMTP address
,
Login
,
Password
and
E-Mail
address
.
GPRS Settings
GSM Settings
Philips855_GB_MKG_4311 255 58331.book Page 46 Mercredi, 17. décembre 2003 4:32 16
Messages 47
•
POP3 address
: allows you to enter the IP or DNS
address of the POP3 server, which is used to
receive e-mails.
•
SMTP address
: allows you to enter the IP or DNS
address of the SMTP server, which is used to
send e-mails.
WARNING ! Network-dependent! For an e-mail connection
via GPRS, if your phone operator is not your e-mail
provider, contact your operator to get the correct address of
the SMTP server and enter it in this field.
In some cases,
Login
,
Password
and
E-mail address
are
up to you when you subscribe to your account. Enter
them as defined.
Account name
This menu allows you to rename the available e-mail
accounts.
An e-mail account might be preconfigured with the
name of your operator. In this case, its name cannot be
changed.
1.
Press
,
, select
Messages
>
E-mail
>
E-mail 1
>
Settings
>
Account
name
and press
,
.
2.
Enter the new name in the edition window that
appears and press
,
.
Advanced
The menus described in this section feature advanced
settings that may have been pre-configured, so you
shouldn’t have to change any of them.
If the fields of these menus are empty, or if you
encounter connection problems, contact your ISP.
Port POP3
: allows you to enter the POP3 port
number, which is used to receive e-mails.
Port SMTP
: allows you to enter the SMTP port
number, which is used to send e-mails.
DNS address
: allows you to enter the DNS address of
the external data network you want to connect to.
SMPT authenticat.
: allows you to activate/deactivate
the authentication process with the SMTP server.
In most European countries, this menu should be set to
Off
: your e-mails will NOT be sent if set to
On
.
Contact your provider for complete information.
Write and send an e-mail
The
Send mail
menu allows you to send
e-mails to one or several recipients at a
time, including with an attachment
such as a jpeg picture. Once received, your messages
can be forwarded and the attachments visualised with
the appropriate software.
Send mail
Philips855_GB_MKG_4311 255 58331.book Page 47 Mercredi, 17. décembre 2003 4:32 16
48 Messages
To one or several recipients
1.
Press
,
, select
Messages
>
E-mail
, then
E-mail 1
or
E-mail 2
depending on the one you wish to
use. Select
Send mail
and press
,
.
2.
Move
-
to select
Add addressee
and press
,
to access the list.
If you select the phonebook «On SIM card», you will
not be able to access any e-mail address, but an edit
window will allow you to enter one. See “Phonebook”
page 20 for information on phonebook selection.
3.
Select a name in the list and press
,
to add it
to your mailing list or press
c
to cancel and
go back to the previous sub-menu.
4.
Back to the
Addressees
list, press
,
to
Change
the e-mail address or to
Remove
it from the list,
or select
Add addressee
, press
,
to access the
phonebook again and add new names to the
mailing list.
5.
Repeat steps 2 to 4 to add as many recipients as
required.
6.
Select
Validate list
and press
,
. Then enter the
subject of your e-mail (you can leave this field
empty) and press
,
.
7.
In the next window, enter the text of your e-mail
(you can also leave this field empty). Press
,
when you are ready to send your e-mail.
To learn how to enter text, see “Text or number entry”
page 12. If you exit the
Send e-mail
menu before
sending your e-mail, its content is deleted without
being stored.
8.
Select
Modify mail
and press
,
if you want to
change the content of your e-mail. This takes
you back to step 2: follow the instructions from
there to complete the list of recipients and send
your e-mail.
9.
Select
Send now
and press
,
to send your
e-mail. Your mobile phone connects to the
Internet server, sends your e-mail to the names
present in your mailing list, then disconnects.
You can cancel this operation by pressing and holding
the
c
key. Your mobile will then disconnect from
the server, exit the e-mail menu and go back to idle.
Disconnection also occurs each time you enter the
Settings
menu while a connection is in progress. In this
case, your e-mail is lost.
Depending on the call settings you configured (see
“Call waiting” page 76), you can receive calls during
Philips855_GB_MKG_4311 255 58331.book Page 48 Mercredi, 17. décembre 2003 4:32 16
Messages 49
an e-mail connection. In this case, and if you accept
the incoming call, your phone switches to the call
screen context and the e-mail menu is closed; the
phone goes back to idle when you hang up.
With a sound or a picture
1.
Repeat steps 1 to 7 described above. Select
Add
sound
or
Add graphic
and press
,
.
2.
In both cases, a list appears, showing the
available JPEG, BMP, GIF, AMR or Midi files.
Select the picture and/or sound of your choice
and press
,
.
You can only attach one JPEG file at a time. If you
exit the
Send e-mail
menu before sending your e-mail,
its content (including attachment) is deleted without
being stored.
3.
Select
Modify mail
or
Send now
and press
,
to
confirm.
Receive and read e-mails
E-mails are received on a server, which
you must connect to in order to retrieve
your e-mails on your mobile phone
(some operators send you a SMS when you receive a
new e-mail). You must first download the headers
from the server before retrieving the corresponding
e-mails.
Connect to the server
Connection process
1.
Press
,
and select
Messages
>
E-mail
, then
E-
mail 1
or
E-mail 2
depending on the one you wish
to use. Select
Open mailbox
and press
,
.
Mailboxes 1 and 2 feature the same settings and
options. Configuring them differently will allow you
to have two different e-mail addresses from your
phone.
2.
Your mobile phone automatically connects to
the e-mail server and downloads the e-mail
headers. If you didn’t receive any e-mail,
List
empty
is displayed on the screen. Otherwise, the
e-mail headers are displayed in the form of a list.
3.
The total number of mails received and pending
on the server is displayed on the top of the
screen, as well as the number of pages needed to
display all headers.
4.
Your mobile phone retrieves five e-mail headers
at a time. If
Next
(respectively
Previous
) appears
at the end (respectively beginning) of the list,
other e-mail headers are pending: select one of
the available options and press
,
to retrieve
them.
Open mailbox
Philips855_GB_MKG_4311 255 58331.book Page 49 Mercredi, 17. décembre 2003 4:32 16
50 Messages
An e-mail without any attachment may be
automatically displayed in the details screen.
Headers information
Select a header, press
,
, select
Details
and press
,
again to see the address it was sent from, the date
and time at which it was sent, its subject and the size
of the attachment if any. The following status icons
may appear in regards to each header:
Download e-mails
Simply select one of the retrieved e-mail
headers and press
,
. Then select
Get
mail
and press
,
to download the
e-mail. Repeat this operation to download each e-mail
corresponding to each selected header.
You can also press
,
to access the e-mail headers’
carousel and select
Get mail
from the available options.
If the e-mail is too big (over 50 KB), it is rejected and
the download is cancelled.
Get and store attachments
If the e-mail you have received contains attachments
(JPEG picture, text file or another e-mail), they are
characterised by a specific icon:
[No
icon]
The e-mail can be downloaded.
The e-mail size is too large, it cannot be
downloaded.
The e-mail is marked to be deleted (see
page 52).
Get mail
Contains the details of the e-mail header
(date and time, sender’s e-mail address, etc.),
press
,
to display these details.
The text of the e-mail itself can be viewed as
an attachment, press
,
to read it. There
isn’t any advanced options in this situation:
it can be read, but not stored nor forwarded.
A text file (text only, «.txt» format) is at-
tached to the e-mail, press
,
to read it.
There isn’t any advanced options in this sit-
uation either.
The application needed to manage this
attachment isn’t available in your phone, or
the e-mail is too large to be uploaded.
Philips855_GB_MKG_4311 255 58331.book Page 50 Mercredi, 17. décembre 2003 4:32 16
Messages 51
You must have stored a picture before being able to
view it via the
Picture album
menu. See “Picture
album” page 65 for more details. If there isn’t enough
memory to store the new picture, you must delete other
items (name, event or picture) to release enough
memory to be able to save the new picture.
A picture may not be accepted by your mobile phone
if it is too large, or if it doesn’t have the right file
format. When receiving a picture via e-mail, proceed
as follows to obtain optimal results:
• The picture received must have been saved in
JPEG, BMP or GIF format.
• The size of the picture file should not exceed
50 KB.
• The optimal size is 128 x 128 pixels, in order to
be displayed correctly. We recommend you use a
standard picture editing software to create the
size of the picture you want.
• Use a file name, a maximum of 10 characters.
You can then add an extension such as «.jpg».
Add an e-mail address to the phonebook
You must have selected the phonebook in your phone
to be able to add an e-mail address; this menu item
will NOT appear if you selected the SIM phonebook.
You can add the sender’s e-mail address
to your phonebook, even when you
haven’t yet downloaded his e-mail
(retrieving the header only is sufficient to access the
e-mail address).
1.
Select an e-mail header, then press
,
to access
the carousel options.
2.
Select
Add to names
and press
,
. Then select:
- <new> to create a new name, enter first and
last name then add the associated e-mail
address,
or
- a name in the list and press
,
to add the
e-mail address to this name card. If it already
contains an e-mail address, you will be
prompted to press
,
to replace it.
Another e-mail is attached to the one you re-
ceived (up to five e-mails can be attached
one after the other). There isn’t any ad-
vanced options for an attached e-mail: it can
be read, but not stored nor forwarded.
A picture in JPEG, BMP or GIF format is
attached to this e-mail. Select the attached
picture in the list and press
,
twice to
store it in your mobile phone (you can re-
name it if you wish).
Add to names
Philips855_GB_MKG_4311 255 58331.book Page 51 Mercredi, 17. décembre 2003 4:32 16
52 Messages
Delete e-mails
1.
Select the e-mail to be deleted and press
,
to
access the options.
2.
Select
Delete
, and press
,
to confirm and
mark the e-mail to be deleted. A small icon
allows you to spot the header(s) of the list
corresponding to the e-mail(s) to be deleted.
To unmark the e-mail to be deleted, select this option
again.
3.
When you exit the
E-mail
menu, you will be
asked to confirm deletion of the selected item(s)
from the e-mail server. Press
,
to confirm or
c
to cancel (in this case, the marked e-mails
remain in the list and aren’t marked to be deleted
any more).
Reply to an e-mail
1.
Select the header of the e-mail you want to reply
to, press
,
to access the options menu, then
select
Reply
and press
,
.
2.
The address of the sender, which you can modify
(see “To one or several recipients” page 48), is
automatically added to the
Addressees
list. Select
Validate list
and press
,
.
3.
A new screen appears, that contains the subject
of the received e-mail preceded with
Re:
standing
for «Reply». Press
,
.
4.
Enter the text of your mail, then press
,
to
send it: select
Send now
and press
,
to send
your reply.
Forward an e-mail
In order to forward an e-mail to another recipient,
you must first have downloaded it (see “Download
e-mails” page 50). From the
Forward to
option,
proceed as described above in “Reply to an e-mail”.
In both cases (reply to an e-mail or forward it), your
phone will disconnect from the server when reaching
the network inactivity time out set in the
Auto
disconnection
menu (see “Bearer” page 45). It will
reconnect to this server when sending the e-mail.
The Broadcast SMS feature is network-dependent.
You can
Activate
or
Deactivate
the
reception of SMS broadcast regularly
transmitted to all subscribers on the
network.
Broadcast message
Broadcast SMS
Philips855_GB_MKG_4311 255 58331.book Page 52 Mercredi, 17. décembre 2003 4:32 16
Messages 53
Reception
Allows you to set the reception of cell
broadcast messages
On
or
Off
. When
On
, you must define one or several
topics as described below.
To p i c s
Allows you to define the type of
messages you want to receive. To define
a new type, select
<New>
, enter the
code provided by the operator, and, if desired,
associate a name. If you select an existing type in the
list, you can change or delete it. You can enter up to
15 different types in the list. To obtain the codes
corresponding to the different types, contact your
operator.
District codes
Allows you to select the type of
messages you would like to be
permanently displayed on the idle
screen. As a result, for this special treatment of the
message, you must enter the type in both the
District
code
and the
To p i c s
menu.
Allows you to set the
Instant message
feature
On
or
Off
.
When
On
, any short message (SMS) you receive is
automatically displayed in idle mode.
Scroll down to read it, and quickly reply by pressing
,
twice: first to enter the edition screen, then to
send your message. The phone will automatically go
back to the idle screen.
If you receive a second SMS while you are reading one,
press
c
to exit the first one or reply to it. The
mobile phone will then display the second message.
Your mobile phone allows you to send
and receive MMS (multimedia
messages), featuring texts, pictures and
sounds.
A multimedia message can be made of one slide
(including text, sound and image), or of several: in
this case, the message is played in a slide show,
whether you send it to an e-mail address or to another
mobile phone.
Reception
Topics
District Code
Instant message
MMS
MMS
Philips855_GB_MKG_4311 255 58331.book Page 53 Mercredi, 17. décembre 2003 4:32 16
54 Messages
Create an MMS
Select the addressees
1.
Select
Messages
>
MMS
>
New MMS
and press
,
.
2.
Select a name in the list and press
,
to add it
to your mailing list,
OR
Select
<New>
and enter the phone number or
e-mail address you wish to send your message to.
Then press
,
.
You must have selected the phonebook «In phone» to
access an e-mail address. See “Phonebook” page 20 for
information on phonebook selection.
3.
If you wish to send your message to this person
only, select
Validate list
and press
,
.
If you want to send it to several people, select
Insert name
, press
,
to access the phonebook
again and to add new names to the mailing list
(up to 20 names).
4.
Add as many recipients as required, then select
Validate list
and press
,
.
You can select one of the items and press
,
to
Edit
the e-mail address or phone number, or to
Remove
it
from the list.
Design your message
1.
On the left hand side of the screen, 5 icons allow
you to add a
, add
Te x t
, add a
Sound
,
Send
the message or access the
Options
menu. Move
+
or
-
to go to the previous or next icon.
2.
Press
,
to access the
Picture Album
list, select
a picture and press
,
to add it to your MMS.
The first window of your message is displayed,
showing the selected picture, which is resized if
needed, in order to fit the screen.
Although the picture preview when creating the MMS
is (W)105 x (H)55 pixels, the maximum size of a
picture you can send is (W)640 x (H)640 pixels.
Warning! The bigger the picture size, the longer it will
take to send it.
A copyright-protected picture cannot be sent. Select
None
if you don’t want to insert any picture.
3.
The
Te x t
icon is automatically selected: press
,
to access the text editing screen, enter the
text of your message (see “Text or number entry”
page 12 for help).
4.
The
Sound
icon is then selected: press
,
to
access the
Sound Album
list, select a sound and
press
,
to add it to your MMS.
Philips855_GB_MKG_4311 255 58331.book Page 54 Mercredi, 17. décembre 2003 4:32 16
Messages 55
Sounds can be one of the files available in the Album,
or a sound memo that you record when creating the
MMS: in this case, select
<Records>
, then
<New>
and
follow the procedure that appears on the screen.You
cannot attach an existing voice memo.
The icon of the item you have added (picture or sound)
changes colour to indicate its insertion.
5.
Press
,
to send your message, or move
-
to access the options.
If you quit the MMS menu and haven’t finished
writing your message, it will be automatically saved in
the
Draft
menu (see below).
Access the options
Move
-
to go to the
Options
icon and press
,
.
The following options are available:
Add slide
To create a new slide and add it
to your slide show.
You can also press
>
when
the last page of the message you
are currently designing is
selected.
Once you have created several
pages, move
<
or
>
to
browse slides.
Delete slide
To delete the selected page.
This option is only available if
there is more than one slide in
the message.
Next slide
Previous slide
To move to the next or to the
previous slide.
Slide duration
To change the value of slide
duration that you have set in
Settings
>
Application settings
(see page 61), and to set a delay
between each slide.
Philips855_GB_MKG_4311 255 58331.book Page 55 Mercredi, 17. décembre 2003 4:32 16
56 Messages
When browsing the lists, specific icons show the type of
the selected message (read MMS, delivery report,
template, etc.). The information about the message
(sender, recipients, subject) scrolls horizontally
automatically when selected.
Send your Message
As described above, you can either:
• Send your message as soon as it is completed:
select
Send MMS
and press
,
.
• Save it as a
Draft
to complete it and send it later:
to send, select the message in
Drafts
, select
Send
MMS
and press
,
. Once it has been sent, the
MMS
is removed from the drafts list.
If the sending of a draft message fails, the message will
be moved to the
Outbox
menu, and identified as Not
sent.
• Select it from the
Outbox
menu and send it:
select the message to be sent from this menu,
select
Re-send MMS
and press
,
. Once it has
been sent, the MMS is identified as a sent mes-
sage in the list.
In the two last cases, select the message to be sent in
the relevant folder. In all cases, select
Send MMS
and
press
,
: a progress bar allows you to follow the
sending of your message. Press
c
to cancel the
sending of your message.
Save MMS
as draft
To save your message as a draft,
that you can edit, complete and
send later on. MMS saved as
drafts are stored in
MMS
>
Drafts
(see “Manage folders” page 58).
Messages saved as drafts must
feature a subject.
Save
as template
To save your message as a
template, that you can use as a
basis for other MMS (e.g.,
«Happy birthday» type of
message). MMS saved as
templates are listed in
MMS
>
Templates
(see “Manage folders”
below).
Preview MMS
To preview the slide show you
have created from the first to
the last slide, including sounds
& pictures.
Add subject
To edit and change or enter the
subject of your message.
Philips855_GB_MKG_4311 255 58331.book Page 56 Mercredi, 17. décembre 2003 4:32 16
Messages 57
Receive an MMS
Download and play an MMS
When you receive an MMS, an alert message appears
on the screen to inform you.
1.
If you activated the
Automatic
retrieval mode (see
page 60), the message is automatically
downloaded and placed in the
Inbox
. Select it in
the
Inbox
list and press
>
to play it.
2.
If the
Manual
mode is activated:
-Press
c
to go back to idle mode and to save
the notification in the
Inbox
,
OR
-Press
,
to display the details of the
notification, then select
Download
and press
,
to download the message itself. As for
sending, a progress bar allows you to follow the
download of the message.
A notification isn’t the MMS itself, but an
information window gathering the details about the
sender’s identity, date and time of reception, subject,
etc. DO NOT DELETE NOTIFICATIONS
BEFORE YOU HAVE RETRIEVED THE
MESSAGE, or you will never be able to do so.
In both automatic and manual modes, a message will
inform you if the size of the MMS you wish to
download is bigger than the memory available in your
phone. In this case, you must free memory by deleting
data (picture, sounds, etc.). See “Memory status”
page 68.
- If the sender of the message has asked for a
Read report
, a prompt will ask you to press
,
to send it or to press
c
to refuse the
sending of the report.
3.
Once the MMS is downloaded, select it in the
Inbox
list and press
>
to play it.
Pressing
<
or
>
will switch the player mode
from automatic to manual. In manual mode, press
<
or
>
to display the previous or the next slide.
Get and store attachments
When playing an MMS as described in the previous
section, press
,
to access the following
Player
options
:
Play
message
To switch back to automatic
mode: the MMS is then played
as a continuous slide show.
Philips855_GB_MKG_4311 255 58331.book Page 57 Mercredi, 17. décembre 2003 4:32 16
58 Messages
Manage folders
The MMS menu allows you to manage your messages
in 4 different folders. The default (active) folder is the
last one you selected. To change the active folder,
press
c
to return to the main MMS menu and
select the folder of your choice:
Next /previous
slide
To move to the next or previous
slide. You can also press
<
or
>
when viewing the MMS in
manual mode.
This item is not available when
you have selected the last (or
first) slide.
Rewind
To rewind the MMS back to the
first slide.
Detach picture
To detach the picture of the
current slide and save it in the
Picture album
.
Detach sound
To detach the sound of the cur-
rent slide and save it in the
Sound album
.
Inbox
Lists all the
Notifications
,
Delivery
and
Read
reports
,
Read
and
Unread MMS
.
•You can
Read
or
Delete
notifica-
tions and reports.
•You can
Play
,
Forward
or
Reply
to
an MMS, display its
Details
or
Delete
it.
Notifications are automatically
deleted once you have received the full
MMS. Do NOT delete notifications
before you have retrieved the MMS, or
you will never be able to do so.
Outbox
Lists the messages you have
Sent
or
created but
Not sent
yet (e.g., if you
have cancelled the sending procedure
by pressing the
c
key).
-You can
Open
,
Delete
or view the
Details
of all these messages.
- In addition, an MMS not yet sent
can also be
Re-sent
to someone, and
you can
Forward
an MMS already
sent.
Philips855_GB_MKG_4311 255 58331.book Page 58 Mercredi, 17. décembre 2003 4:32 16
Messages 59
Messages you have saved can only be sent from the
Draft
or
Outbox
folders. You can NOT recover an item
(whether message, notification or report) that you
have deleted. Press
c
to cancel deletion.
Settings
Your phone may have been pre-configured to directly
access the services offered. If not, you must have
received from your operator the information items
described in the present section and enter them as
given.
With some operators, access parameters can be set
«over the air». Please check directly by your operator.
Network account
Allows you to choose a data profile from the ones you
have set (see “Access settings” page 36 for complete
information on how to configure or modify a data
profile). This profile and the parameters it features
will then be used for connection.
Bearer
This menu allows you to select the type of network
used when launching a connection.
If selecting
GPRS first
, you must have configured both
the GSM and GPRS settings (see “Access settings”
page 36).
MMS Centre
Allows you to enter or change the MMS address of the
server your phone will connect to.
Template
s
Lists all messages saved as templates
after their creation.
You can
Play
,
Edit
and
Delete
tem-
plates.
Drafts
Lists all messages saved as drafts after
their creation, or automatically saved
if you quit the MMS menu before
saving or sending your message.
You can
Play
,
Edit
,
Send
and
Delete
drafts.
GSM
Your mobile will only use the GSM
network for connections.
GPRS
Your mobile will only use the GPRS
network for connections.
GPRS first
Your mobile will first try to connect
to the GPRS network, then to the
GSM network if the GPRS network
isn’t available when connecting.
Philips855_GB_MKG_4311 255 58331.book Page 59 Mercredi, 17. décembre 2003 4:32 16
60 Messages
Gateway address
Allows you to enter or change the IP address of the
server’s gateway.
Gateway port
Allows you to enter or change the Port number of the
server’s gateway.
You must have the information relating to the three
points above, supplied by your operator, and must
enter them exactly as given.
Application settings
Retrieval mode
Delivery report
This option can be set
On
or
Off
and informs you (via
an SMS) whether your MMS was received or rejected.
The delivery report will display the sender’s identity,
date and time of receipt, MMS subject and status of
delivery.
Read report
This option can be set
On
or
Off
and informs you (via
an SMS) when the status the MMS you have sent has
Automatic
(default mode)
Any new MMS you receive is au-
tomatically downloaded from the
server and placed in the
Inbox
,
without you having to launch a
connection. Select the message
you have received in the
Inbox
and press
>
.
This mode is deactivated when
roaming.
Manual
Messages are stored on the MMS
server, and you must connect
manually to retrieve them:
1.
Press
,
to access the
Inbox
.
2.
Select the notification item
corresponding to this mes-
sage and press
,
.
3.
Select
Read
and press
,
.
4.
When the
Details
of the mes-
sage are displayed, press
,
to launch the connec-
tion and download it.
Once the message is in your
phone, press
,
, select
Play
message
and press
,
.
Philips855_GB_MKG_4311 255 58331.book Page 60 Mercredi, 17. décembre 2003 4:32 16
Messages 61
changed, i.e., whether it was read or deleted without
being read.
Auto save
This option can be set
On
or
Off
and allows you to
automatically save of the messages sent from the
Outbox
menu. Messages saved will then appear in the
Outbox
folder.
Validity period
Allows you to select the length of time your message
is to be stored on the server, from
1 hour
to
1 week
(maximum). This is useful when the recipient is not
connected to the network (and thus cannot receive
your message immediately).
Slide duration
Allows you to select the duration between each slide
included in your MMS, from
1sec.
to
60 secs
.
Philips855_GB_MKG_4311 255 58331.book Page 61 Mercredi, 17. décembre 2003 4:32 16
62 Infrared
9 • Infrared
Your mobile phone integrates the infrared technology
(also called IrDA), that allows you to send or receive
data to and from other IrDA-compliant devices
through a wireless link (e.g., another mobile phone, a
PC or PDA, a printer etc.). Instead of sending a
message, you can decide to use IrDA to quickly send
a sound you just mixed to a friend’s mobile phone, or
to receive pictures from their PDA.
Files that are copyright-protected cannot be sent.
When connecting with a PC, make sure you have
activated its infrared option.
Before sending or receiving data to and from another
device, they must be correctly positioned in relation to
your mobile phone. Make sure that the respective
IrDA ports are facing each other and are a maximum
of 50 cm away from each other (see diagram). Also
make sure that nothing obstructs the IrDA beam.
Select an item
To send data via IrDA from your mobile phone, you
must first select the item to be sent: for each category,
a sub-menu then gives you access to the
Send
option;
press
,
to send the selected data to the other
device.
Position of devices
Send data
Data you
can send
Where to find it
in the phone menus
Pictures (BMP,
GIF, JPEG)
Multimedia
>
Picture album
Sounds (MIDI
files & ringers)
Multimedia
>
Sound album
Philips855_GB_MKG_4311 255 58331.book Page 62 Mercredi, 17. décembre 2003 4:32 16
Infrared 63
Send the selected item
As soon as your phone finds another IrDA-compliant
device to communicate with, the sending
automatically takes place. Messages are displayed on
the screen, for you to follow the process.
If the phone finds several IrDA devices, a list is
displayed on the screen, for you to choose from. Press
,
to confirm and to send the selected data.
Sending is cancelled in the following cases:
- the phone cannot find another device and the time
out is reached before any data is sent,
- the infrared link is broken,
- you press the
c
key to cancel the process.
Activate IrDA
To receive data, press
,
and select
Infrared
>
Receive
and press
,
. Your
mobile phone is then ready to receive an
item and waits for the other IrDA device to send it. As
when sending, messages are displayed on the screen
and allow you to follow up the process.
Receiving is cancelled in the following cases:
- the phone isn’t contacted by another device and the
time out is reached before data is received,
- the infrared link is broken,
- the size of the file sent is too large for your phone to
manage it,
- you press the
c
key to cancel the process.
Save the data received
Several options are available when receiving data from
another IrDA device:
Press
c
Cancels the process: if you confirm your choice by
pressing
,
, the phone goes back to idle and the
data you have received isn’t saved.
Names
Phonebook
>
View names list
(or press
-
when in idle mode).
Events
Games & Appli
>
Organiser
>
Events
Receive data
Infrared
Philips855_GB_MKG_4311 255 58331.book Page 63 Mercredi, 17. décembre 2003 4:32 16
64 Infrared
Press
,
Gives you access to the options menu, from which the
following options are available:
Use the phone as a modem
You can also use your mobile phone
together with a PC or a PDA, e.g. to
surf the Internet or send faxes.
To fully benefit from the services available via IrDA
(send and receive SMS, e-mail and fax, upload
pictures and MIDI sounds in your phone, phonebook
synchronization, GPRS Wizard, etc.), you must
install Mobile Phone Tools on your PC. This software
application is available on the CD-Rom shipped with
your phone.
The software supplied on the CD-Rom is not
compatible with Apple® Macintosh® computers. It
only supports Windows® 98 SE, ME, 2000 and XP.
Specific software modules for Lotus Notes, Lotus
Organizer and Microsoft Outlook are designed to
allow synchronisation from your Philips mobile
phone to these applications: refer to their respective
user guides for detailed information concerning
installation and configuration.
Save
Saves the data in the appropriate menu
(
Name
cards in the
Phonebook
,
Event
cards
in the
Organiser
, etc.), then goes back to
idle.
In the case of a
Name
card, a
<New>
screen
will be opened, for you to save this new
record.
The files default names are used, and you
can freely rename each of them via the
appropriate menu (i.e. in
Multimedia
>
Sounds
when you have saved a ringer you
would like to rename).
Show
Displays the details of the data you have
received: press
c
to go back one screen.
You must save the data to modify it.
If you have received a
, it will be
displayed in full screen.
If you have received a
Sound
, it will be
played once. Press
c
or
,
to stop
playing it, or move the side keys up or
down to change the volume.
Data
Philips855_GB_MKG_4311 255 58331.book Page 64 Mercredi, 17. décembre 2003 4:32 16
Multimedia 65
10 • Multimedia
This menu allows you to manage and
listen to the sounds stored in your
mobile phone. When entering one of
the available sub-menus, the sounds are displayed as a
text list. Press
+
or
-
to go to the next or
previous sound and wait for a few seconds for the
sound to be played. Select a sound and press
,
to
access the following options:
You will not be able to send sounds that are protected
by a copyright. Sounds in the Standard melodies
folder cannot be deleted.
JPEG pictures must have the correct size and format
for your mobile phone to store and display them
correctly. Please check “Get and store attachments”
page 50 for complete information on this subject.
This menu allows you to manage and
display the pictures stored in your
mobile phone.
When entering one of the available sub-menus, the
pictures stored in your phone are displayed as a text
list. To access the graphical display, select a picture in
the list and press
>
. Then press
+
or
-
to go
to the next or previous picture, or
<
to go back to
Sound album
Rename
To Rename it: press
,
, enter a
name and press
,
again.
Delete
To Delete the selected sound.
Send by
email
To send the selected sound via infra-
red to another IrDA device (see “In-
frared” page 62 for details).
Set as
messages
ringer
To set the selected sound as
Messages ringer (this option must
be set On in Settings > Sounds, see
page 27).
Sound Album
Picture album
Picture Album
Philips855_GB_MKG_4311 255 58331.book Page 65 Mercredi, 17. décembre 2003 4:32 16
66 Multimedia
the text list. Press
,
to access the following
options:
Rename
To Rename it: press
,
, enter a
name and press
,
again.
Delete
To Delete the selected picture.
Pictures in the Standard Pictures
folder cannot be deleted. If there isn’t
enough space to store a new picture,
you must delete some other pictures to
release memory.
Send by
email
To send the selected picture via
E-mail (see “E-Mail” page 45 for de-
tails).
Send
To send the selected picture via
infrared to another IrDA device (see
“Infrared” page 62 for details).
Rotate
To rotate the picture of 90° or 270°:
press
,
to confirm your choice.
Set as
Wallpaper
To set the selected picture as
Wallpaper (this option must be set
On in Settings > Display, see
page 29).
Modify
You can also access this menu and
related features when using the
camera, i.e., when pressing the
,
button to access the options after you
have taken a picture.
When selecting this option, the
picture you have chosen is displayed
and automatically resized to
128 x 160 pixels.
On the left hand side of the screen
that appears, 6 icons allow you to
perform the tasks described below.
The prompt bar at the bottom of the
screen describes the selected icon; for
a maximum visibility of the picture
preview, you can hide this bar: press
+
or
-
to select the on / off
prompt bar icon, then press
,
to
set in On (show) or Off (hide).
Philips855_GB_MKG_4311 255 58331.book Page 66 Mercredi, 17. décembre 2003 4:32 16
Multimedia 67
•Add
text
To add some text to the selected
picture (the text will centered).
When done, a 4-arrows icon in the
upper left side of the screen allows
you to move the text up, down, left
and right.
A short press will move the text
1 pixel at a time, a long press will
move it 5 pixels at a time.
Press c to go back to the text
editor, or , to validate and go to
the next option.
•Add
graphic
To add a Frame or an Icon to the
picture: browse each list (press <
or > to access the graphical
display) and press , to validate
your choice. When done, a 4-arrows
icon in the upper left side of the
screen also allows you to move the
Icon up, down, left and right.
Back to the Modify picture preview,
the left part of a selected frame will be
hidden by the icons menu.
•Eraser To Undo the last modification made
on the picture, or to Reset, i.e.,
cancel all changes at once. Press c
to cancel or , to validate.
• Rotate To apply a rotation of 90°
(press >) or -90° (press <) to
the picture. Press , to validate.
• Send To send the picture via IrDA, E-Mail
or MMS (see relevant chapters in the
present user guide for detailes
information).
• Save To save the picture including all the
changes you have applied to it: enter
the name of your choice and press
, to validate.
If you don’t rename the picture, the
original file you selected from the
album will be overwritten. You can
save a picture at any time, even if you
are not done modifying it.
Philips855_GB_MKG_4311 255 58331.book Page 67 Mercredi, 17. décembre 2003 4:32 16
68 Multimedia
Press
,
to launch the Demo movie.
If you turned the phone on without having inserted a
SIM card, this menu is available in the first menu
level.
This menu allows you to display the
percentage of memory available in your
phone. Several features share the mobile
capacity: pictures and sound album, recorded memos
and voice tags for voice commands, messages you have
stored in the phone, phonebook and organiser entries,
games, etc.
Your mobile phone is supplied with many sounds and
pictures. You can only delete sounds or pictures in the
Picture or Sound albums, e.g., to free memory space
for your own sounds and pictures.
Press
,
to check the memory status. The display
shows you the percentage of memory free and the
phone’s total memory in KB. Press
,
again and
access the detailed list of memory used by each
feature.
If «List full» appears when saving a new item or to free
memory space, you must delete an item to be able to
create or add a new one.
This menu allows you to record a sound
of 1 min. maximum, and up to 20
different sounds, depending on the
Memory status.
Press
,
and select Multimedia > Sound recording,
then press
,
again. Select <New> to record a new
sound. Follow the instructions on the screen and press
,
once your sound is recorded. You can then
Delete or Rename it.
Memos can then be used as alarm or incoming call
ringers, etc. Voice memos previously saved cannot be
sent by MMS.
This feature allows you to display a
slideshow on the main (internal) screen,
Demo mode
Memory status
Demo mode
Memory status
Sound recording
TV Slideshow
Sound recording
TV Slideshow
Philips855_GB_MKG_4311 255 58331.book Page 68 Mercredi, 17. décembre 2003 4:32 16
Multimedia 69
by using your own JPEG pictures, i.e. the ones you
have taken and stored in your phone.
Using a TV Link accessory allows you to display the
same slideshow on a TV screen by connecting a cable
from your mobile phone to the TV: see “Philips
authentic accessories” page 98 for details.
1.
Select TV Slideshow and press ,, then select
the value that will be applied between each
picture of the slideshow (5, 7 or 10 seconds) and
press ,.
Selecting Manual will allow you to browse the list of
pictures like you would do in the Picture Album, by
pressing
+
or
-
.
2.
In the list that appears, choose Check all to
select all the pictures, OR
browse the list and select the pictures of your
choice by pressing < or > (you deselect a
picture the same way).
3.
Select Uncheck all and press , to deselect all
pictures at once.
4.
When browsing the list of pictures list, press
> to activate the graphical full-screen display.
Then press + or - to go to the next or
previous picture, and < to go back to the list.
5.
When browsing or during the slideshow, press
, to open the rotation options (90°, 180° or
270°), select the option of your choice and press
,. Changes are automatically stored.
Philips855_GB_MKG_4311 255 58331.book Page 69 Mercredi, 17. décembre 2003 4:32 16
70 Games & Appli.
11 • Games & Appli.
The
-> Euro
menu enables you to
convert a sum into Euros by entering
the amount and pressing
,
.
The
<- Euro
menu enables you to
convert a sum from Euros by entering
the amount and pressing
,
.
The currency used for the conversion is determined by
the country where you have subscribed. The Euro
converter is available upon subscription and only in
countries using the Euro.
This menu provides the following
functions:
Enter the figures using the keypad. Calculator
accuracy is to 2 decimal places and is rounded up to
the higher decimal figure. Press
c
to correct the
numbers. Press and hold
0
to get the dot. Press
and hold
c
twice to return to idle mode.
This menu allows you to set the alarm
clock. Press
,
and select
Games &
Appli
>
Alarm clock
, then press
+
or
-
to activate it. Enter the time, then press
,
and select:
-
Once
activates the alarm at a set hour on a set
day,
-
Every day
activates the alarm at a set hour every
day of the week,
-
On weekdays
activates the alarm at a set hour
on weekdays only.
Then select one of the alarm alerts: the buzzer, a
melody or a sound recording (the latter being played
only once). Select an item in the list if required, and
press
,
to confirm your choice.
Euro converter
Calculator
Addition
By pressing the
*
key.
Substraction
By pressing the
*
key twice.
Multiplication
By pressing the
*
key 3 times.
-> Euro
Euro ->
Calculator
Division
By pressing the
*
key 4 times.
Equals
By pressing the
#
key.
Alarm clock
Alarm clock
Philips855_GB_MKG_4311 255 58331.book Page 70 Mercredi, 17. décembre 2003 4:32 16
Games & Appli. 71
The alarm clock will ring even if you turned off your
phone, and even if the Ringer volume is set to
Off
(see
page 27). Press any key to stop the alarm ringing.
Create a new event
The
Events
menu allows to create events
and store them in your organiser.
Events can be
Meetings
,
Holidays
or
To D os
. When the organiser alert is On (see page 28),
a beep alerts you when an event is due.
1.
Select
Organiser
>
Events
>
<New>
and press
,
.
2.
Select the type of event to create (
Holiday
,
Meeting
,
To D o
) and press
,
.
3.
Enter the starting and ending date & time of the
event and press
,
, enter the text concerning
the event (e.g. «Meeting with Smith») and press
,
.
4.
The
Set Reminder
menu reminds you of events
via alerts triggered at the chosen time. Move
<
or
>
, set the
Reminder
for this event
and press
,
.
This menu only applies to
Meeting
and
To D o
events.
Note that the reminder depends on the time set and
displayed on the screen. As such, it will be updated
when changing time zones (see “Time and date”
page 37).
5.
Move
<
or
>
to set the
Repeat Event
option for this event and press
,
.
6.
The events will be listed using start time and
date. From the events list,
- press and hold
c
to go back to the idle
screen,
- repeat steps 2 to 5 to create more events.
The organiser shares the mobile capacity and memory
with other features (phonebook, picture album, sound,
etc.). As a consequence, all features are inter-
dependent: the more events you create, the less names,
memos or pictures you can store, and vice-versa. 299
is the maximum total of events + names you can store.
If «List full» appears, delete an event (or name) to be
able to create a new one. To check the memory
available in your phone, press
,
and select
Multimedia > Memory status
.
Organiser
Organiser
Philips855_GB_MKG_4311 255 58331.book Page 71 Mercredi, 17. décembre 2003 4:32 16
72 Games & Appli.
Modify an event
Change an event
When creating an event, not all fields
are available, this is designed so make
creating a new event quicker. When
changing an event, these further options become
available.
1.
To change an event, select the event of your
choice and press
,
.
2.
When your phone displays the details of the
selected event, press
,
, select
Change
and
press
,
again.
Changing a repeated event will also modify all
instances of this event: in this case, press
,
to
confirm.
3.
Change any information as needed and as
described above.
Deleting an event
Deleting a single event
Select the event of your choice and press
,
twice.
Then select
Delete
and press
,
to confirm.
Deleting a repeated event
• By selecting a past occurrence: select a past
occurrences of an event and press
,
. When
the event details appear, press
,
, then select
Delete
and press
,
to confirm: only the past
occurrences of the selected event are deleted.
• By selecting a future occurrence: select a future
occurrence of an event and press
,
. When
the event details appear, press
,
, then select
Delete
and press
,
to confirm: all occur-
rences of the selected event are deleted.
Deleting past events
You can also delete past events by
selecting
Delete past
at the first level of
the Organiser menu. In this case, enter
the starting date (past or future) from which all
previous events will be deleted and press
,
twice to
delete all events preceding this date.
To delete all events set in your organiser, enter a
starting date several years ahead (e.g., 3st of
December, 2010). This way, you make sure all events
preceding this date are deleted at once.
Views of events
The
Day view
,
Week view
and
Month view
display in
the respective format all events stored in your
organiser. To display events in these views, proceed as
follows:
1.
Select the view of your choice and press
,
.
Change
Delete past
Philips855_GB_MKG_4311 255 58331.book Page 72 Mercredi, 17. décembre 2003 4:32 16
Games & Appli. 73
2.
Once you entered the selected view, move
<
or
>
to display the previous or next day,
week or month.
3.
Press
,
to display the list of corresponding
events or to create a new one.
Time zone
Although changing time zones is
necessary when travelling a lot, be aware
that it will impact all organiser
reminders: the event alarms will be updated
depending on the time displayed on the screen (see
“Time and date” page 37).
This menu can be subscription dependent. As such its
icon and content may vary.
This menu gives you access to the brick
game. The object of the game is to
destroy the bricks by hitting them with
the ball.
When you have destroyed the last brick, you access
the next level. Keys used are the following:
Your mobile phone features JAVA,
which allows you to run JAVA-
compatible applications such as games
downloaded on the network.
Settings
Network
Bearer
Allows you to select the type of network used by the
selected profile when launching a connection.
Brick game
Time zone
Brick Game
4
and
6
To move the racket left or
right.
*
and
#
To throw the ball left or
right. Press either of these
keys to start the game.
0
To pause the game; pause
time is limited to 2 min. after
which the screen returns to
idle mode and the game is
lost.
JAVA
JAVA
Philips855_GB_MKG_4311 255 58331.book Page 73 Mercredi, 17. décembre 2003 4:32 16
74 Games & Appli.
GSM
or
GPRS
: your mobile will only use the GSM or
the GPRS network for WAP connections.
GPRS first
: your mobile will first try to connect to the
GPRS network, then to the GSM network if the
GPRS network isn’t available when connecting.
Selecting this option requires you to have configured
both GSM and GPRS settings. See page 36 for details.
DNS address
Allows you to enter the DNS address of the external
data network you want to connect to. Press
,
to
confirm.
Network account
Allows you to select one of the data profiles you have
defined in
Settings
>
Access settings
(see page 36 for
detailed information on this subject).
In the list that appears, select the connection setting of
your choice and press
,
to confirm.
Auto-Launch
Allows you to set the automatic launch of JAVA
On
or
Off
. When
On
, a JAVA application will be
automatically launched right after it was installed.
Session permission
Allows you to choose from three different options
which will define how JAVA will behave:
One shot
A message will ask you to confirm
each connection.
One session
A message will ask you to confirm
the first connection, any other
connection being performed
automatically.
Blanket
Connections are automatic.
Philips855_GB_MKG_4311 255 58331.book Page 74 Mercredi, 17. décembre 2003 4:32 16
Call information 75
12 • Call information
This menu allows you to set all the call
options (call forward, waiting, etc.).
Active flip
When activated, this option allows you to pick up an
incoming call by simply opening the phone. A beep
also indicates the end of the communication when
hanging up.
Rejecting calls isn’t possible in this case as you must
open the phone to access the
)
key and manually
reject the call.
Call forward
Allows you to divert incoming calls
either to your mailbox or to a number
(whether in your
Phonebook
or not) and
applies to:
Data calls
,
Voi ce c a ll s
and
Fax calls
.
Before activating this option, you must enter your
voice mailboxes’ numbers (see “Mailboxes” page 76).
This feature is subscription dependent, and different
from the call transfer, which takes place when one/
several calls are in progress.
Unconditional
The unconditional option will divert all the incoming
calls.
Warning! When selecting this option, you will not
receive any calls at all until you deactivate it.
Conditional
This option allows you to choose in which
circumstance(s) you want to divert incoming calls.
Three options are available:
If no reply
(you haven’t
replied to the call),
If not reachable
(your network isn’t
available) or
If busy
(you are already on the phone and
your subscription doesn’t include the call waiting
option or you haven’t activated it). Each option can
be set independently.
Once you have selected either
Conditional
or
Unconditional
, choose whether you want to divert calls
to your voice mailbox or to another phone number, or
cancel the call forward.
Status
Allows you to display the status of all
call forwarding.
Call settings
Call settings
Call forward
Status
Philips855_GB_MKG_4311 255 58331.book Page 75 Mercredi, 17. décembre 2003 4:32 16
76 Call information
Mailboxes
This menu allows you to enter your
voice mailbox numbers (if not available
on your SIM card).
In some cases, you might have to enter two numbers:
one to listen to your mailbox, the other one to forward
calls. Contact your operator for more information on
this subject.
Auto redial
Allows you to set the auto redial
On
or
Off
. When
On
and if the person you are
calling is busy, your phone
automatically redials this number until a successful
connection is made, or until the maximum number of
attempts is reached (10). The phone emits one beep at
the beginning of each attempt and one special beep if
the connection is successful.
The time between redials increases with each attempt.
Any key answer
Allows you to accept a call by pressing
any key, except
)
, used to reject a
call.
Call waiting
Call waiting is managed differently
depending on the type of network
(GSM or GPRS) you have selected.
With GSM call
Allows you to
Activate
or
Deactivate
the
call waiting and applies to:
All calls
,
Voice calls
,
Fax calls
and
Data calls
.
When this option is active, you hear a beep if someone
tries to call you while already on a call. Select the
Status
option to find out whether the GSM call
waiting is active or not.
This function is subscription-dependent. Contact your
operator.
With GPRS call
Allows you to
Activate
or
Deactivate
the
call waiting for voice incoming calls
while a GPRS connection in ongoing.
Caller ID
Allows you to
Show
or
Hide
your
identity to your correspondent. The
Status
option will inform you if this
function is activated or not.
Mailboxes
Autoredial
Any key answer
Call waiting
With GSM call
With GPRS call
Caller ID
Philips855_GB_MKG_4311 255 58331.book Page 76 Mercredi, 17. décembre 2003 4:32 16
Call information 77
This menu provides you with the list of
outgoing and incoming calls, as well as
attempts at auto redialling and call
details. The calls (made, missed and received) are
displayed in chronological order with the most recent
on top of the list. When the
Call list
is empty the
screen displays
List
empty
.
Call list
From the main carousel, press
,
then select
Call Info
>
Call list
>
Call list
to display the call list. Use
+
and
-
arrows to scroll the list and press
,
again to
consult the date, time, number, call status of any
selected call and to know if it was sent or received.
Press
,
for access to a carousel which allows you to
Call
or
Call handsfree
this correspondent,
Send a SMS
,
Delete
the selected call or
Store
the associated
number.
Reset
Press
,
, select
Call Info
>
Call list
,
then
Reset
. Press
,
twice to reset.
The phone stores the last 30 numbers in the
Call list
,
the most recent number being displayed first. You can
redial directly any of these numbers. In idle screen,
move
+
to access the
Call list
. If a number listed is
also in your
Phonebook
, the corresponding name is
displayed. Move
+
or
-
to select the number to
redial and press
(
. Press
)
to hang up.
This menu allows you to handle the cost
and duration of your calls.
GSM counters
This menu gives you access to the
options described below.
The GSM Call Counters do not include WAP
connections. Most options mentioned below are
subscription-dependent.
Total duration
Select this option and press
,
to
Show
or
Reset
the time duration of
Outgoing
or
Incoming
calls.
Call list
Call List
Call list
Reset
Call counters
Call counters
GSM counters
Total duration
Philips855_GB_MKG_4311 255 58331.book Page 77 Mercredi, 17. décembre 2003 4:32 16
78 Call information
Last call information
This feature is subscription dependent.
This menu allows you to display the
duration and/or cost of your last call.
Info at call end
This feature is subscription dependent.
Allows you to activate or deactivate the
systematic display of the length and/or
cost of each call when hanging up.
To t a l c o s t
This feature is subscription dependent.
Allows you to display the accumulated
cost and to set the counter to zero. It
may be protected by PIN or PIN2
codes.
GPRS counters
This feature is subscription and network dependent.
This menu allows you to select either
one of the following options:
Last mobile session
This option will display the last
connection session or transfer volume
Shows how much has been spent,
having established the charge rate.
Allows you to reset the current
To -
tal cost
to 0; requires your PIN2
code.
Last call info
Info at call end
Total cost
Show
Reset
Allows you to check the remaining
credit (compared with previously
set limit).
Allows you to cancel the cost limit.
It may be protected by PIN or
PIN2 codes (depending on your
subscription).
Allows you to enter the cost limit
used in the
Show balance
menu.
Allows you to set or change the
rate per unit. First enter the cur-
rency used (three characters maxi-
mum) then enter the cost per unit.
Show balance
Cancel cost limit
Cost limit
Charge rate
GPRS counters
Mobile session
Philips855_GB_MKG_4311 255 58331.book Page 78 Mercredi, 17. décembre 2003 4:32 16
Call information 79
of your mobile phone (e.g., after a WAP connection
over GPRS).
Last PC session
This option will display the last
connection session or transfer volume
of your PC transmission.
The call counters managed by your mobile phone
might differ from the ones used by your operator. You
should therefore consider the call counters displayed on
the screen as informative items, but NOT as the actual
charge rate basis.
PC session
Philips855_GB_MKG_4311 255 58331.book Page 79 Mercredi, 17. décembre 2003 4:32 16
80 WAP
13 • WAP
Your mobile phone supports services
based on the Wireless Application
Protocol (WAP). The built-in WAP
browser allows you to access services
supplied with your network, such as news, sports,
weather, etc.
Your mobile phone readily supports the WAP function
if it is included in your subscription; if your phone was
pre-configured, it shouldn’t be necessary for you to
change the settings described in this section.
With some operators, WAP parameters can be set
remotely. Please check directly with your operator for
detailed information.
This main menu of the WAP browser allows you to
configure the settings related to WAP, connect to
your operator’s homepage, define bookmarks for
direct and faster connections, etc.
Launch a WAP session
1.
To launch a WAP session, press and hold the
0
key while in idle mode.
You can also select
Operator Services.
>
WAP
>
Homepage
and press
,
.
2.
Your mobile phone will connect to the network
and according to the
Access settings
you have
defined in the menu
Settings
>
Network
(see
page 36).
3.
The browser is launched and your phone
connects to your operator’s homepage.
4.
Move
+
or
-
to navigate the on-line
pages, and press
,
to select a highlighted
item.
5.
Press
c
to return to the previous page.
End a WAP session
To end a WAP session, press and hold
0
,
OR
select
Options
>
Exit
and press
,
to confirm.
Homepage
The
Homepage
is the link to the first WAP site you
will access when launching WAP from the idle screen.
In most cases, this menu item of the
WAP s er v i c es
menu is preconfigured and will connect directly to
your operator’s WAP homepage.
You can change this default homepage by specifying
the name and URL address of another homepage,
which will then replace the current one (see “Save as
homepage” page 84).
Internet services
WAP
Philips855_GB_MKG_4311 255 58331.book Page 80 Mercredi, 17. décembre 2003 4:32 16
WAP 81
Bookmarks
This menu allows you to store your favourite WAP
site addresses, rename them if desired and access them
quickly from the list.
This can also be done while browsing: press
@
to
access the
Options
, then select
Bookmarks
. In this case,
the Name and URL fields will be automatically filled
in with the information contained in the page you are
browsing.
Add bookmarks
1.
Select
WAP
>
Bookmarks
>
Add bookmark
and
press
,
.
2.
Start entering the new name: an edit screen
automatically appears.
3.
Press
,
to save the name you entered.
4.
Press
-
to move to the address field and
proceed the same way to enter the WAP address.
Manage bookmarks
This menu allows you to
Delete
the stored
bookmarks, or to
Edit
them in order to change their
name and/or address. In both cases, press
,
to
confirm.
Use bookmarks
To connect to a WAP site you have stored as a
bookmark, simply select it in the list and press
,
to launch the connection.
Enter address
This menu allows you to enter a WAP site address, to
which you can connect directly when selecting it and
pressing
,
. This is a quick way to access WAP
addresses without saving them as bookmarks.
1.
Press
,
and enter the URL address of the
desired homepage.
2.
Press
,
to connect to this page.
All the addresses you enter in this menu and connect
to at least once, will appear in a list: select one of the
items and press
,
to reconnect to the corresponding
page, without having to enter the complete address
again.
Settings
Edit Homepage
Allows you to change the
Homepage
name and
address:
1.
Press
,
and start entering the new name. An
edit screen automatically appears.
2.
Press
,
to save the name you entered.
3.
Back to the
Edit Homepage
menu, press
-
to
move to the address field and proceed the same
way to change the address.
Philips855_GB_MKG_4311 255 58331.book Page 81 Mercredi, 17. décembre 2003 4:32 16
82 WAP
Select Profile
This menu allows you to select one of the available
profiles, and to then define the connection settings for
each of them: scroll
+
or
-
to choose the profile
of your choice, then press
<
or
>
to select /
deselect it and press
,
to confirm.
All connection settings described below will apply to
the selected profile, which you can then rename for
easier identification.
Connection
Select connection
Allows you to select one of the data profiles you have
defined in
Settings
>
Access settings
(see page 36 for
detailed information on this subject).
In the list that appears, select the connection setting of
your choice and press
,
to confirm.
Bearer
Allows you to select the type of network used by the
selected profile when launching a connection.
GSM
or
GPRS
: your mobile will only use the GSM or
the GPRS network for WAP connections.
GPRS first
: your mobile will first try to connect to the
GPRS network, then to the GSM network if the
GPRS network isn’t available when connecting.
Selecting this option requires you to have configured
both GSM and GPRS settings. See page 36 for details.
Proxy address
Allows you to specify a proxy gateway address to be
used when launching a WAP connection using the
selected profile. Press
,
and enter the address of
your choice, then press
,
to confirm.
Press and hold
0
to enter a dot «.»
Proxy port
Allows you to specify a proxy port number, in case the
proxy you are using requires a different port number.
Press
,
and enter the number of your choice, then
press
,
to confirm.
Security
Certificates
Select this menu and press
,
to display the list of
installed security certificates. Select one of the items in
the list and press
,
to display its details or delete it.
Session info
Allows you to display information about the current
WAP session: security type, class, etc. Press
c
to go
back one page.
Philips855_GB_MKG_4311 255 58331.book Page 82 Mercredi, 17. décembre 2003 4:32 16
WAP 83
Current certificate
Allows you to display the currently used security
certificate. Press
c
to go back one page.
Rename Profile
This menu allows you to rename the currently
selected profile: enter the new name (an edit screen
automatically appears), then press
,
to save the
name you entered.
Browser Options
This menu allows you to activate/deactivate the
downloading of images attached to WAP pages. Select
Never
or
Always
and press
,
to confirm your
choice.
Selecting
Never
will speed up the global downloading
time of the pages browsed.
Cache
This menu allows you to empty an area of the phone’s
memory where the pages browsed during a WAP
session are stored. Select
Clear cache
and press
,
to
confirm your choice.
Push inbox
This menu allows you to read and manage messages
automatically sent to you by the network and / or by
your operator.
1.
If you have been informed that you received a
push message, press
,
to read it.
2.
Otherwise, select
Operator Services.
>
WAP
>
Internet services
>
Push Inbox
and press
,
to
access the list of messages.
Messages with high priority feature an exclamation
mark together with the read / unread icon.
3.
Press
+
or
-
to browse the list and select
the message of your choice, press
,
to read it.
4.
If the message contains a WAP address (or
URL), press
,
to connect to the
corresponding WAP site.
5.
To delete one of the push messages, select
Push
Inbox
>
Manage
messages and press
,
.
6.
Select the message to be deleted and press
,
to confirm.
While browsing Internet pages, press the
,
key to
access the options described below.
The menus that are common to both
Internet services
and
Options
menus are described in the above section.
Homepage
Gives you direct access to the Homepage of the WAP
site you are currently browsing.
Options
Philips855_GB_MKG_4311 255 58331.book Page 83 Mercredi, 17. décembre 2003 4:32 16
84 WAP
Back
Brings you back to the previously browsed page.
You must have browsed at least 2 pages for this option
to be available.
Forward
Takes you to the next browsed page (e.g., when you
have previously selected
Back
).
Refresh
Will reload the currently browsed page from its
original server.
Save as homepage
This menu option allows you to save the currently
browsed WAP page as the default homepage.
1.
Select
Save as homepage
and press
,
. The
URL address of the page you are browsing
automatically appears in the
Address
field.
2.
Enter a name for this homepage and press
,
.
3.
Back on the
Internet services
menu, the
homepage name will be the first item on the list.
Press the
@
key while in idle mode to connect
automatically to this page.
Save as...
When browsing WAP sites, this menu option allows
you to save images embedded in the pages that are
displayed.
1.
While browsing, scroll
+
or
-
to select
the picture.
2.
Once the picture is highlighted, press
@
to
access the
Options
. Select
Save as...
and press
,
.
3.
Rename the picture if desired and press
,
to
save it in the
Album
.
Exit
Allows you to end a WAP session: press
,
to
confirm and to quit WAP.
Receive a call
When receiving a call whilst connected to WAP:
1.
Answering the call will quit the WAP application
and disconnect the current session. Your phone
will return to the last browsed page when you
hang up, but the connection itself will be lost.
2.
Rejecting the call will bring you back to the
preview screen.
Philips855_GB_MKG_4311 255 58331.book Page 84 Mercredi, 17. décembre 2003 4:32 16
Operator services 85
14 • Operator services
Most items of the Operator Services menu (e.g.
Service numbers, Services +) are subscription-
dependent and specific to operators: your mobile
phone readily supports them if they are included in
your subscription. Consequently, the menus shown
following may or may not be available. Contact your
network operator for detailed information on
availability and rates.
The services provided may involve making a phone
call or sending a SMS for which you may be charged.
The phone supports standard GSM strings that can be
sent from the keypad to the network and used to
activate services provided by the network.
•Example n° 1
Press
*
4
3
#
, then
(
, to activate
the Call Waiting service.
•Example n° 2
Press
*
#
3
1
#
, then
(
, to
know if the mobile identification has been sent.
•Example n° 3
Press
*
6
1
#
, then
(
, to activate
the feature call forward if no reply.
•Example n° 4
Press
*
6
2
#
, then
(
, to activate
the feature call forward if unreachable.
Contact your network operator for detailed
information on GSM strings.
Some phone services (such as phone answering
machines and pagers) require your phone to transmit
DTMF tones (Dual Tone Multi Frequency), also
known as “touch tones”. These are used to
communicate passwords, callback numbers, caller
choices, and so on.
You can send DTMF tones at any time during a call
by pressing any of the keys
0
to
9
,
*
and
#
. You can also attach a DTMF sequence to a
phone number before dialling it (or storing it in the
Phonebook
). The phone number and the DTMF part
must be separated by a wait character.
Pause and wait characters
To obtain a pause or wait character, press and hold
#
. The display shows
w
for a wait and
p
for a
pause. The phone always interprets the first pause
GSM strings
DTMF tones
Philips855_GB_MKG_4311 255 58331.book Page 85 Mercredi, 17. décembre 2003 4:32 16
86 Operator services
character as a wait character. When you dial a number
containing a wait character, your phone dials the first
part (the phone number) and then waits for the call to
be connected before sending the rest of the digits as
DTMF tones. Any subsequent pause character is an
ordinary pause that generates a delay of 2.5 seconds.
For example: access your answering
machine
To hear all messages (e.g. code 3) on your answering
machine (password 8421) at phone number
12345678, you could call:
12345678w8421p3.
The phone dials 12345678 and waits for the call to be
connected. When connected, the phone transmits
8421 (the password), pauses 2.5 seconds, and then
sends the last digit. If you find that 2.5 seconds is not
long enough for your needs, you can enter several
pause characters one after the other to increase the
pause time.
You can make a second call during an active call or
during a call on hold. You can switch between the two
calls (the cost displayed on the screen depends on local
charge rate).
1.
While already on the phone, dial a number then
press
(
. The first call is put on hold and the
number is displayed at the bottom of the screen.
The second number is then dialled.
2.
To toggle between the two calls, press
,
then
select
Switch calls
. Each time that you toggle
from one call to another, the active call is placed
on hold and the call which was on hold is
activated.
3.
To hang up the active line, press
)
. The
active line is hung up and the call on hold
remains as such.
4.
To end the call on hold, use
Switch calls
to reach
it, then press
)
.
Notes:
The second number can be dialled either from the
keypad or from:
- the phonebook, by pressing
-
, then selecting the
name to be called,
- the Call list, by pressing
+
, then selecting the
number to be called.
You are able to receive another call when already in
communication (if this feature is available with your
Make a second call
Answer a second call
Philips855_GB_MKG_4311 255 58331.book Page 86 Mercredi, 17. décembre 2003 4:32 16
Operator services 87
subscription). When you receive a second call the
phone emits an alert beep and the screen displays
Call
waiting
.
To receive a second call, you must have:
- subscribed to this feature,
- deactivated the Call forward option for voice calls
(see page 75),
- activated the Call waiting option (see page 76).
If you receive a second call, press
,
, then you can:
• accept the second call: the first one is put on
hold, the second one is active. If you want to
toggle between the two calls, press
,
then
select
Switch calls
. Each time you toggle from one
call to another, the active call is put on hold and
the call which was on hold is then activated. To
introduce the new caller into a conference
press
,
and select
Conference
.
• reject the second call
• end the active call, then your incoming call is
ringing.
Notes:
- If you also wish to answer the incoming call, press
(
; to reject it, press
)
.
- If you have activated call forwarding ‘If Busy’ (see
“Active flip” page 75), you will never receive second
calls since they are always forwarded when the line is
busy.
Subscription dependent
While in communication and one call being on hold,
you may receive a third call. The phone emits an alert
beep. You can either end one of the calls before being
able to answer the third one or introduce the calling
party into a conference (see below). This service is
limited to two current communications (one active
and one on hold).
Subscription dependent
You can activate the conference call by
making consecutive outgoing calls, or
create it from a multiparty call context.
You may have up to five members at the same time
and end the conference with
)
. At this point all
calls are disconnected.
In order to make consecutive outgoing calls, first
initiate a normal call with the first number of the
conference. When the first member is on line, initiate
Answer a third call
Conference call
Conference
Philips855_GB_MKG_4311 255 58331.book Page 87 Mercredi, 17. décembre 2003 4:32 16
88 Operator services
a second call as described in “Make a second call”
above. When the second call is engaged,
press
,
and select
Conference
. Repeat the above
process until five members are connected.
If there is an incoming call during the conference call
and there are less than five members, you can accept
this new call by pressing
,
. Press
,
again and
then select
Conference
to add this member to the
conference call. If there is an incoming call during a
conference with five members already connected, you
can answer this new incoming call, but not add it to
the conference.
While a conference call is in progress, press
,
to
access the
Conf. members
options. Disconnect a
member of the conference by selecting
Remove party
and pressing
,
to confirm, or select
Private call
to
have a private call with this member only (other
members are put on hold).
Subscription dependent
You can connect an active call and a call on hold. You
are disconnected when the transfer is completed.
During a call press
,
, select
Tr a n s f e r
and press
,
.
This feature is different from the Call forward, which
takes place before you pick up the call (see page 75).
Explicit call transfer
Philips855_GB_MKG_4311 255 58331.book Page 88 Mercredi, 17. décembre 2003 4:32 16
88 Precautions
Precautions
Your cellular mobile phone is a low power
radio transmitter and receiver. When it is
operating, it sends and receives radio waves.
The radio waves carry your voice or data
signal to a base station that is connected to
the telephone network. The network controls the
power at which the phone transmits.
• Your phone transmits/receives radio waves in the
GSM frequency (900 /1800MHz).
• The GSM network controls transmission power
(0.01 to 2 watts).
• Your phone complies with all relevant safety
standards.
• The CE mark on your phone shows compliancy
with European electromagnetic compatibility
(Ref. 89/336/EEC) and low voltage directives
(Ref. 73/23/EEC).
Your cellular mobile phone is your responsibility. To
avoid damage to yourself, to others or to the phone
itself, read and follow all the safety instructions and
make them known to anyone borrowing your phone.
Furthermore to prevent unauthorised use of your
phone:
Keep your phone in a safe place and keep it
out of small children's reach.
Avoid writing down your PIN code. Try to
remember it instead.
Switch off the phone and remove the battery if you are
going to leave it unused for a long time.
Use the
Security
menu to change the PIN code after
purchasing the phone and to activate call restriction
options.
The design of your phone complies with all
applicable laws and regulations. However
your phone may cause interference with
other electronic devices. Consequently you
should follow all local recommendations and
regulations when using your cellular phone both at
home and when away. Regulations on the use of
cellular phones in vehicles and aircraft are
particularly stringent.
Public concern has been focused for some time on the
possible health risks for users of cellular phones. The
current research on radio wave technology, including
the GSM technology, has been reviewed and safety
standards have been drawn up to ensure protection
from exposure to radio wave energy. Your cellular
telephone complies with all applicable safety
standards and the Radio Equipment and
Telecommunications Terminal Equipment Directive
1999/5/EC.
Radio waves
Philips855_GB_MKG_4311 255 58331.book Page 88 Mercredi, 17. décembre 2003 4:32 16
Precautions 89
Inadequately protected or sensitive electronic
equipment may be affected by radio energy. This
interference can lead to accidents.
Before boarding an aircraft and/or when
packing the phone in your luggage: the use
of mobile phones in an aircraft may be
dangerous for the operation of the aircraft, disrupt the
mobile phones network and may be illegal.
In hospitals, clinics, other health care
centres and anywhere else where you may be
in the close vicinity of medic
al equ
ipment.
In areas with a potentially explosive
atmosphere (e.g. petrol stations and also
areas where the air contains dust particles,
such as metal powders).
In a vehicle transporting flammable
products (even if the vehicle is parked) or a vehicle
powered by liquefied petroleum gas (LPG), check first
that the vehicle complies with the applicable safety
rules.
In areas where you are requested to turn off radio
transmitting devices, such as quarries or other areas
where blasting operations are in progress.
Check with the vehicle manufacturer that
electronic equipment used in your vehicle
will not be affected by radio energy.
If you are a user of a pacemaker:
• Always keep the phone more than 15 cm from
your pacemaker when the phone is switched on,
in order to avoid potential interference.
• Do not carry the phone in a breastpocket.
• Use the ear opposite to the pacemaker to mini-
mise the potential interference.
• Switch off your phone if you suspect that inter-
ference is taking place.
If you are a user of a hearing aid, consult your
physician and hearing aid manufacturer to learn
whether your particular device is susceptible to
cellular phone interference.
In order to improve the performance of your phone,
reduce radio energy emission, reduce battery
consumption and ensure safe operation adhere to the
following guidelines:
For the optimal and satisfactory operation of
the phone you are recommended to use the
phone in the normal operating position
(when not using in hands-free mode or with
a hands-free accessory).
Always switch off your phone Users of pacemakers
Users of hearing aids
Performance improvement
Philips855_GB_MKG_4311 255 58331.book Page 89 Mercredi, 17. décembre 2003 4:32 16
90 Precautions
• Do not expose your phone to extreme tempera-
tures.
• Treat the phone with care. Any misuse will void
the International Guarantee.
• Do not immerse the phone in any liquid; if your
phone is damp, switch it off, remove the battery
and let them dry for 24hrs before using them
again.
• To clean the phone, wipe it with a soft cloth.
• Placing and receiving calls consumes the same
amount of battery energy. However, the mobile
consumes less energy in idle screen when kept in
the same place. When in idle screen and while
you are moving, your phone consumes energy to
transmit updated location information to the
network. Setting the backlight for a shorter
period of time as well as avoiding unnecessary
navigating in the menus will also help to save the
battery’s energy for longer phoning and stand-by
performances.
• Your phone is powered by a rechargeable battery.
• Use specified charger only.
• Do not incinerate.
• Do not deform or open the battery.
• Do not allow metal objects (such as keys in your
pocket) to short circuit the battery contacts.
• Avoid exposure to excessive heat (>60°C or
140°F), moisture or caustic environments.
You should only use Philips Authentic
Accessories, as the use of any other
accessories may damage your phone and will
make all guarantees for your Philips phone
null and void.
Make sure damaged parts are replaced immediately by
a qualified technician and that they are replaced with
genuine Philips replacement parts.
It lowers concentration, which can be
dangerous. Adhere to the following
guidelines:
Give your full attention to driving. Pull off
the road and park before using the phone.
Respect the local regulations in countries where you
drive and use your GSM phone.
If you want to use your phone in a vehicle, install the
hands-free car kit which is designed for that purpose,
still ensuring you give full attention to driving.
Ensure that your phone and car kit do not block any
air bags or other security devices fitted in your car.
Information displayed on battery
Do not use your phone
while driving
Philips855_GB_MKG_4311 255 58331.book Page 90 Mercredi, 17. décembre 2003 4:32 16
Precautions 91
The use of an alarm system to operate a vehicle's light
or horn to indicate incoming phone calls is prohibited
on public roads in some countries. Check local
regulations.
In case of hot weather or after a prolonged exposure to
the sun (e.g., behind a window or a windscreen), the
temperature of your phone's casing might increase,
especially when featuring a metallic finish. Be very
careful in this case when picking up your phone and
also avoid using it with an ambient temperature over
40°C.
Remember to observe the local regulations
regarding the disposal of your packaging
materials, exhausted batteries and old phone
and please promote their recycling.
Philips has marked the battery and packaging with
standard symbols designed to promote the recycling
and appropriate disposal of your eventual waste.
EN 60950 Norm
Environmental care
The crossed-out dustbin signifies that the
battery should not be disposed of with
general household waste.
The mobius loop symbol signifies the la-
belled packaging material is recyclable.
The green point symbol signifies that a fi-
nancial contribution has been made to
the associated national packaging recov-
ery and recycling system (e.g. EcoEmbal-
lage in France).
The chasing arrows symbol on the plastic
tray and plastic bag indicate that the
materials are recyclable and also identifies
the plastic material.
Philips855_GB_MKG_4311 255 58331.book Page 91 Mercredi, 17. décembre 2003 4:32 16
Troubleshooting 93
Troubleshooting
The phone does
not switch on
Remove and reinstall the
battery (see page 1). Then
charge the phone until the
battery icon has stopped
flashing. Finally, unplug from
the charger and try to switch
the mobile on.
The display
shows
BLOCKED
when you switch
on
Somebody tried to use your
phone but didn’t know the
PIN code nor the unblocking
code (PUK). Contact your
service provider.
The and
symbols are not
displayed
The network connection is
lost. Either you are in a radio
shadow (in a tunnel or between
tall buildings) or you are
outside the network coverage
area. Try from another place or
contact your network operator
for assistance/information
about the network.
The display
doesn’t respond
(or the display
responds slowly)
to key presses
The display responds more
slowly at very low
temperatures. This is normal
and does not affect the
operation of the phone. Take
the phone to a warmer place
and try again.
In other cases please contact
your phone supplier.
Your phone
doesn’t return
to the idle
screen
Press and hold
c
, or switch
off the phone, check that the
SIM card and the battery are
installed correctly, and switch
it on again.
Your phone
doesn’t display
the phone
numbers of
incoming calls
This feature is network and
subscription dependent. If the
network doesn’t send the
caller’s number, the phone will
display
Call 1
instead. Contact
your operator for detailed
information on this subject.
Philips855_GB_MKG_4311 255 58331.book Page 93 Mercredi, 17. décembre 2003 4:32 16
94 Troubleshooting
You can’t send
text messages
Some networks don’t allow
message exchanges with other
networks. Contact your
operator for detailed
information on this subject.
The display
shows IMSI
failure
This problem is related to your
subscription. Contact your
operator.
You can’t
receive and/or
store JPEG
pictures
A picture may not be accepted
by your mobile phone if it is
too large, or if it doesn’t have
the correct file format. See
page 50 for complete
information on this subject.
When charging
the battery, the
battery icon
shows no bar
and the outline
is flashing
Only charge the battery in an
environment where the
temperature does not go below
0°C (32°F) or above 50°C
(113°F).
In other cases please contact
your phone supplier.
The display
shows SIM
failure
Check that the SIM card has
been inserted in the right
position (see page 1). If the
problem remains, your SIM
card may be damaged. Contact
your operator.
You are not sure
that you are
receiving calls
properly
To receive all calls, make sure
that none of the features
«Conditional call forward» or
«unconditional call forward» is
activated (see page 75).
When
attempting to
use a feature in
the menu, the
mobile displays
NOT
ALLOWED
Some features are network
dependent. They are only
available, therefore, if the
network or your subscription
supports them. Contact your
operator for detailed
information on this subject.
The display
shows INSERT
YOUR SIM
CARD
Check that the SIM card has
been inserted in the right
position (see page 1). If the
problem remains, your SIM
card might be damaged.
Contact your operator.
Philips855_GB_MKG_4311 255 58331.book Page 94 Mercredi, 17. décembre 2003 4:32 16
Troubleshooting 95
Your phone
doesn’t work
well in your car
A car contains many metallic
parts that absorb
electromagnetic waves which
can affect the phone’s
performances. A car kit is
available to provide you with
an external antenna and
enables you to make and
receive phone calls without
handling the handset.
You should check with local
authorities if you are allowed
to phone while driving.
Philips855_GB_MKG_4311 255 58331.book Page 95 Mercredi, 17. décembre 2003 4:32 16
96 Icons & symbols
Icons & symbols
In idle mode, several symbols can be displayed
simultaneously either on external screen or main
screen.
If the network symbol isn’t displayed, the network is
not currently available. You may be in a bad reception
area: move to a different location.
Silent
- Your phone will not ring when
receiving a call.
Vibra
- Your phone will vibrate when
receiving a call.
GPRS attach
- Your mobile phone is
connected to the GPRS network.
SMS message
- You have received a new
message.
Voice mail
- You have received a new voice
mail.
Battery
- The bars indicate the battery level
(4 bars = full, 1 bar = low).
Alarm clock
activated.
Roaming
- Displayed when your phone is
registered to a network other than your own
(especially when you’re abroad).
SMS full
- Memory for messages is full. De-
lete old messages to receive new ones.
Call Forward Unconditional to number
-
All your incoming voice calls are being for-
warded to a number other than voice mail.
Call Forward to voice mailbox
- All your
calls are being forwarded to voice mail.
Home zone
- A zone designated by your
network operator. Subscription dependent,
contact your service provider for details.
GSM Network:
your phone is connected to
a GSM network
Reception quality:
the more bars are shown
the better the reception is.
Instant message
- option is set to
On
.
Memory full
- The phone’s memory is full.
Delete items to store new ones.
MMS message
- You have received a new
multimedia message.
Philips855_GB_MKG_4311 255 58331.book Page 96 Mercredi, 17. décembre 2003 4:32 16
Icons & symbols 97
Philips855_GB_MKG_4311 255 58331.book Page 97 Mercredi, 17. décembre 2003 4:32 16
98 Philips authentic accessories
Philips authentic
accessories
Charges your battery in any AC outlet. Small enough
to carry in a briefcase/handbag.
Designed to operate your Philips mobile phone
hands-free and easy to use, this compact hands-free
solution offers a high audio quality. Simply plug the
kit into the vehicle auxiliary outlet.
In-line answer button offers you a simplified
alternative to searching for the phone. Simply answer
an incoming call by pressing the button. In idle mode,
press to activate voice dial.
In certain countries, telephoning while driving is
prohibited. For safe and trouble free installation, we
recommend that specialized technicians install hands-
free car kits.
A black leather carry case allows easy key presses while
protecting your phone from nicks and scratches.
Supplied with necklace.
To maximise the performance of your Philips phone
and not to void the warranty, always purchase Philips
Authentic Accessories that are specially designed for
use with your phone. Philips Consumer Electronics
cannot be held liable for any damage due to use with
non authorised accessories. Ask for Philips Authentic
Accessories where you purchased your Philips Phone.
This data/video cable allows you to display a slide
show on your TV. Simply connect the data end of the
cable to the headset (top) connector on the right
handside of your phone, then connect the video end
to the video IN connector of your TV or VCR.
See “TV Slideshow” page 68 for detailed information
on how to select pictures and display them in a
slideshow.
Charger
Universal car kit
XTra deluxe headset
Carry case
TV Link
Philips855_GB_MKG_4311 255 58331.book Page 98 Mercredi, 17. décembre 2003 4:32 16
Philips authentic accessories 99
Easy data connection to your Philips mobile phone:
the USB cable enable high speed connection between
your phone and your computer. Just connect your
phone to the cable for an automatic organiser and
phonebook synchronization within a few seconds.
The provided software allows you to send faxes and
SMS, access data communication facilities on mobile
networks and connect to the Internet.
Data connect kit
Philips855_GB_MKG_4311 255 58331.book Page 99 Mercredi, 17. décembre 2003 4:32 16
