Avantree Technology BTHS-063 Bluetooth Headset User Manual

Avantree Technology Co., Ltd. Bluetooth Headset

User manual

User’s Manual
Model No:
BTHS-063
Important safety instruction
If used in the correct method, this design and production of this product can ensure your personal safety
completely. However, any inappropriate use may lead to potential risk and danger of electric shock or fire
hazard. Please read all the safety instructions before installing and using the product. In particular, attention
shall be given to the following information:
1. It needs to be stored or used in the ambient temperature.
2. It shall not be placed in water or wet locations.
3. It can’t be disposed randomly for it may cause environmental pollution.
4. Without approval, It shall not be disassembled or repaired.
5. The built-in lithium battery can’t be disposed in the fire or other places to prevent causing fire hazards.
6. It shall be cleaned with dry cloth.
7. Whenever there is damage, it needs to be repaired by professional personnel.
Charging the battery
Fully charge the battery for about 3.5 hours before using the battery for the first time.
1. Plug the smaller end of USB charging cable into the Micro-USB interface of the connector.
2. Next, plug the other end of USB charging cable into other power charging devices or a computer with the
power on.
Status
LED indicator
Low battery
When power is less than 10%, the battery voltage will lower 3.3V,
then there will be a voice prompt “dududu”, while the RED LED
flashes twice per second---this alarm occurs every two minutes.
when the voltage is lower 3.1V,the earphone will shut down
automatically
Charging
The red light solid on.
Fully charged
The red indicator will go out .
Package content
1. Wireless headphone
2. Micro USB charging cable
3. 3.5mm audio cable
4. Quick user guide
5. PU bag
Earphone indicator
1.LED Charging indicator
2.Charging Port
3.Volume-/Previous Track
4. Volume+/Next Track
5. LED Indicator
6.Power Button
7．AUX Port
8.MicroPhone
Product feature
Pairing name
B036
Li-battery capability
400 mAh
Talking time
20hours
Playing time
20 hours
Charging time
3.5 hours
Charger mode
Micro USB 5V/1A
Straight-line distance
≥10m
Operation instructions
Operation instructions
function
Key operation
description
power on
Long press
power button
for 3s
At Power off state, press power button for 3s,
there is voice prompt “Dudududu". Loose the
button, it will go into pairing state automatically
if it’s first device pairing; if the Bluetooth
devices information existed before, it will go
into standby state directly (headset re-pairs
automatically in 3 minutes). it will power off if
10minutes no connection at standby state.
Power off
Long Press
power button
for 4s
At Power on state, press power button for 3s,
there is voice prompt “dudududu"
Pairing
Press power
button for
5s
At Power off state, long press power button for
5s, and it will go into pairing state while there is
a voice prompt "dududu". At the same time the
headphone will be detected by other device,
but if it’s not connected within 3 minutes, the
headphone will go into standby status.
connection
status
N/A
There have voice prompt “Di”when Bluetooth
pairing successfully
Re-pairing
Automaticall
y
Click power
button
Click power button at standby station, the
headphone will enter into the repairing list
Disconnect(
automaticall
y)
If the phone disconnects automatically, there is
no prompt, the headphone to into standby
status .
Disconnect
When the distance is out of range, the
headphone will go into re-pair status in
3minutes; it will go into standby status in 10
minutes no connection ; also it will closed
automatically if no connection after 10
minutes.
Play
Short press
power button
Short press power button can replay the media
while the headphone is in pause status
Pause
Short press
power button
Short press power button can pause the
media while the headphone is in play status
Volume up
Short press
Volume+(15
Level )
Short press Volume+ can increase the volume
level while on music playing mode or talk
mode, there will hear "beep" while the volume
is to Max
Volume
down
short press
Volume-"(15
Level )
Short press Volume- can decrease the volume
level while on music playing mode or talk
mode, there will hear "Di" at min volume while
the volume is to Min
Next Track
Long Press
Volume+
Long press Volume+ to go to next song
Previous
Track
Long Press
Volume-
Long press Volume- to go to next song
Answer
call
Short press
power button
Short press power button can answer a call
while there is a call incoming; again a short
press of power key can end a call
On call
N/A
N/A
Reject call
Long press
power button
Press and hold power button for approximately
2s can reject a call while there is a call
for 2s
incoming
Siri
Short Press
Volume+/-
Short Press both Volume+/- at the same time
when the device is connected
End call
Short press
power button
Short Press the power button can end a call
while the call in progress
Redial last
number
Double click
power button
Double click power button can do redial last
number
Clear
pairing list
Long Press
Volume+/- 5s
At the power on status, Long Press button
Volume+/- for 5s, the headphone will clear up
the pairing list and enter into pairing mode
Hardware
Restoration
Press button
Volume+ &
power button
Press both Volume+ & power button at the
same time, the hardware will reset
Mic Mute on
call
Long press
Volume-
Long press Volume-for 3s at call status, the
headphone will go into/out mute
Charging
When in charging, the red LED will be always on; once the energy is full,it will go
off
Line in
When the Audio cable is plug in, the headphone will play music in line-in
mode(suggestion: pls disconnect bluetooth manually, or the music quality will be
affected)
low battery
When power is less than 10%, the battery voltage will lower 3.3V, then there will
be a voice prompt “dududu”, while the RED LED flashes twice per second--this
alarm occurs every 1minutes. when the voltage is lower 3.1V,the earphone will
shut down automatically
Pairing the headphones with a computer
1.Before pairing the headphone with your computer, please make sure your computer or laptop can
support bluetooth function. If not, you must purchase a bluetooth adapter
(preferably version 2.1 or above).
2. Insert the bluetooth adapter to the computer, and make sure the bluetooth function of the computer is
already activated.
3. Press the power button about 5s when the headphone is at power off status. It will go into paring mode
when the blue and red LED light flash alternately, while you can also hear a prompt
4. Open the bluetooth software and choose to search the bluetooth device, and after few seconds, the
names of bluetooth device will list out.
6. Click the pairing name “B036”to pair, when there is a prompt “beep”, this means your headphone is
paired successfully .
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition
without restriction.
