Avantree Technology BTHS-ANC032 ANC Headphones with Bluetooth User Manual
Avantree Technology Co., Ltd. ANC Headphones with Bluetooth
user manual
Contents:
N5 Bluetooth
Noise-cancelling headphone
Features:
The Wireless Headphones is developed to deliver super roundquality with
Bluetooth 4.1V CSR 8635.
The Active Noise Cancelling technology reduce surroundingnosie up to
15-20dB and let you enjoy pure music without distraction.
Dear Customer
Thank you for purchasing the Bluetooth Noise-cancelling headphone .Please read
this manual carefully and follow the instructions listed in order to optimize the use of
your new headphones and enjoy your music the way it was meant to be heard.
3.5mm
Jack/Jack cable
USB/
mirco USB charging cable
Operation Manual
Speaker Unit: 40mm
Magnet: Neodymium
Sensitivity:113+/-3dB
Impedance: 32ohms+/-15%
Frequency response range: 20~20KHz
Activecancellation: Upto15~20dBBetween100~500Hz
Bluetoothversion: V4.1
Operationdistance: 10m
Power: 3.7V350mAh
WorkingHour: MusicPlaying12hrs
Specification:
Function Overview:
Noise cancelling On/Off Button
Multifunction Button (Bluetooth
On/Off,Make/Answer/End/Reject
Call,Pause Wireless Only)
Volume Down/Previous song
(Wireless Only)
Volume Up/Next song
(Wireless Only)
Once your telephone is paired with the N5, the two devices will connect to each other
automatically each time that the N5 is switched on. It is not possible to simultaneously
connect several devices to N5.
All Bluetooth Audio device
N5
Operation:
Noise Cancelling:
1. Press the ANC Button ON, the Noise Cancelling Indicator is green.
2. After turn the noise cancelling on, you may hear a slight hissing noise, this is
normal`will ceaseafter a few seconds.
3. When using noise cancelling feature, if the battery is off, the green indicator is off,
if you want tocontinueusing noise cancelling feature, you need charge the battery.
If you use wired connection you can continue use theheadphones.
Wireless Operation:
1. Press the Multifunction Button for one second, you will hear “BEEP” with the Blue
Indicator IsBlinking. and the Bluetooth is in pairing mode.
2. Enable the Bluetooth on your mobilephone or the device you want to connect and
scan/search for new device.
3. When N5 is found,
select and connect,
you will hear voice
remind “BEEP”.
and the Blueindicator
willflash every five
seconds. The connection
is completed.
Play Music:
1. Press the Multifunction Button once to play music, and press it again to pause.
2. Short pressing "+ button" for volume up, long pressing for skipping forward.
3. Short pressing"- button" for volume down, long pressing for skipping backwards.
Call Functions:
Call Answer: Press the Multifunction Button once to answer, and press again to end.
Last number redial: in standby mode, press the Multifunction Button twice to redial.
Listening to music at high volumes for long periods can lead to hearing problems. We do
not recommend using these headphones at maximum volume, particularly for long periods
of time.
To protect your hearing, turn down the volume of your music player before connecting your
headphones. After putting on the headphones, gradually turn up the volume until you reach
a suitable level. Sound levels are measured in decibels (dB). Exposure to sound 85 dB or
above may result in gradual loss of hearing. Monitor your use. Hearing loss depends on the
intensity of the sound and the duration. The higher the volume,the less your exposure
capacity will last. The lower the volume, the longer your exposure period can be.
Be responsible: pay attention to your environment (acoustic) when you are wearing your
headphones and listening to music or the radio.Avoid hazardous behavior that may cause
an accident for you or somebody else (pedestrians, motorcyclists, drivers, cyclists) or cause
damage to property when you are wearing your headphones.
Warning
Avoid hazardous behavior that may cause an accident for you or somebody else
(pedestrians, motorcyclists, drivers, cyclists) or cause damage to property when you are
wearing your headphones.
Avantree would like to inform you that the use of stereo headphones is strictly forbidden when
driving a motor vehicle. Avantree also recommends not listening to music or the radio through
your headphones when riding a bicycle, a scooter or any other means of transport for which
it is not compulsory to wear a helmet. Avantree can not accept any responsibility if you choose
to ignore these warnings.
100 mm
90.00 mm
FCC Statement
This equipment has been tested and found to comply with the limits for a Class C digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1 This device may not cause harmful interference, and 2 This device must accept any interference received,
including interference that may cause undesired operation.
FCC CAUTION
• Any changes or modifications not expressly approved by the party responsible for compliance could void the
user‘s authority to operate this equipment.
• This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter.
We, Avantree, declare under our sole responsibility, that the product Avantree N5, confirms with the
provisions of the following Directives: 1999/5/EC; 2004/108/EC and 2006/95/EC.
The crossed-out wheelie bin symbol means that the product must be disposed of separately in
the European Union. These products must not be disposed of with unsorted household waste.
FCC ID: 2AITF-BTHS-ANC032
To locate the FCC and IC identification numbers, please look on the underside of the Avantree
BTHS-ANC032.
Model number BTHS-ANC032
