Axis Communications AXIS9010 LAN Access Point User Manual Preliminary Manual
Axis Communications AB LAN Access Point Preliminary Manual
Preliminary Manual
Product Information Sheet
BluetoothTM Access Point
Axis Communications is entering the wireless
communications market. With a unique
expertise in network connectivity and strong
technology partnerships, Axis is a leader in
the converging world of wireless and wired
networks.
Axis is creating new possibilities for wireless
broadband services for users with mobile devices,
by offering solutions for local mobile systems.
Local mobile systems in this context means access
points based on unlicensed radio technologies —
such as Bluetooth wireless technology, IEEE 802.11
and HiperLAN/2, and a system platform incorpo-
rating system intelligence for security, mobility and
access control.
The dramatic growth of wireless broadband
services based on unlicensed radio technologies is
driven by three fundamental industry trends:
iSustained high growth rate for mobile devices — mobile/cell phones, PDAs and laptop computers, due to decreasing
investment and usage costs as well as developments in functionality, battery life length and size.
iUnlicensed radio technologies are being deployed for short distance wireless voice and data communication, such as
Bluetooth wireless technology.
iExtensive roll out of broadband access to Internet, for example xDSL, cable modem and Ethernet.
Product Description
The Bluetooth Access Point from Axis is a wireless access point based on Bluetooth wireless technology supporting both
telephony and data services. Like other Axis products, it is based on the latest version of our integrated system-on-a-chip,
ETRAX, which is optimized for Internet applications and features embedded Linux. The Bluetooth Access Point will be
developed and expanded into a product family encompassing other wireless technologies.
Network Systems supported Supported Clients
• Systems running TCP/IP • All clients with support for Bluetooth Cordless
• 10/100 Ethernet on RJ45 Telephony Profile or LAN Access Profile
Performance Voice over IP Gateway
• 723 kbps down-link, 57 kbps up-link, or • SIP user agent (rfc 2543)
• 434 kbps down-link, 434 kbps up-link • G711, G723 and G729 codecs
Bluetooth LAN Access Profile RF Specification
• Up to 7 simultaneous data users • Unlicensed 2.4 GHz frequency band
• RX Sensitivity -90 dbm
Bluetooth Cordless Telephony Profile • TX Power 20 dbm
• Up to 3 simultaneous voice users Hardware
• 100 MIPS RISC processor
Technical Data
Preliminary data sheet
Technical specification may be subject to change without notice
Axis Communications is a leader in network connectivity and emerging wireless Internet-based services. The company is taking an active role in
driving technology development and standardization as part of the steering committee in the Microsoft Universal Plug and Play forum, as a
member in SUN's Jini forum, and as associate member of the Bluetooth Special Interest Group. Other initiatives include development and
integration of embedded Linux into Axis products as well as development and release under GPL of a Bluetooth stack for Linux. For more
information, see http://developer.axis.com
Axis products are sold in more than 60 countries worldwide through a network of distributors, value-added resellers and original
equipment manufacturers. Founded in 1984, Axis Communications employs more than 350 people worldwide, and is based in Lund,
Sweden with 17 offices throughout North America, Europe and Asia.
Corporate Headquarters U.S. Headquarters Asia-Pacific
Axis Communications AB Axis Communications, Inc Axis Communications
Scheelevägen 34 100 Apollo Drive Level 28,Central Plaza
S-223 63 Lund, Sweden Chelmsford, MA 01824, USA 34 Jalan Sultan Ismail
Phone: +46 46 272 18 00 Phone: +1 (978) 614 2000 50250 Kuala Lumpur, Malaysia
+46 46 270 18 23 +1 (650) 903 2221 Phone: +60 3 2474-582
Fax: +46 46 13 61 30 Fax: +1 (978) 614 2100 Fax: +60 3 2474-585
E-mail: info-mobile@axis.com
www.axis.com
©2000.Axis Communications AB.The Axis logo is a registered trademark of Axis Communications AB. BLUETOOTH is a trademark owned by Telefonaktiebolaget L M Ericsson,Sweden and licensed to Axis Communications AB.
All other company names and products are trademarks or registered trademarks of their respecitive companies.
About Axis Communications
User Scenarios
As you enter your room, you have instant wireless broadband access to the Internet and email on your laptop. From your
mobile/cell phone you can make business calls at a considerably lower charge than the hotel’s regular phone service. In the
conference room, you have access to all your files on the company’s intranet. While waiting for your potential customer in
the restaurant, you look up the latest sales statistics in order to be fully up to date. When you check out, the bill is confirmed
by a single click on the check-out button and you can bypass waiting in line to check out and catch the pre-ordered taxi.
iIn the hotel
When you enter the airport, your mobile device is identified by the local mobile operator —which could be the airline,
lounge or airport administration center, and the check-in gate for your departing flight is presented on your display. You
may also pull up additional information such as estimated check-in waiting time, whether the flight is on time or delayed,
and arrival time to your destination. If you wish, special duty-free offers in combination with product advertisements could
be presented on the display. Furthermore, a broadband connection for accessing the Internet and email access is available,
as well as phone calls via the airport’s phone network at a considerably lower charge than the regular mobile/cell phone
system. When you arrive at your destination, the baggage belt number will be presented on the display. While you wait for
your baggage, you can book a taxi, hotel accommodation or any other airport related service using your mobile device.
iAt the airport
As you enter the retail center, your mobile device downloads a program that supports you in all the aspects of shopping. The
program can assist you in finding that special item, whether it is available in stock, and whether or not the retail center is
offering a promotional discount on your item of choice. The system automatically transmits all your purchases to the check-
out counter for fast and easy payment.
iWhile shopping
Entering your home - your mobile phone becomes an IP-phone, using Voice over IP, providing cordless telephony
within your home as well as inexpensive external phone calls. Your laptop is always connected to the Internet — any-
where you are within your home. Through an intuitive Web interface you are able to control your household appliances
with Bluetooth wireless technology.
iAt home
Upon entering the office, you have immediate wireless access via your laptop to all applications on the company’s Intranet,
email, Internet browsing, printing and file access. The calendar and address book software in your PDA will be automati-
cally synchronized. Using your mobile/cell phone with Bluetooth wireless technology, you can make free internal calls and
inexpensive external calls, using the company’s IP telephony service, from anywhere within the office.
iAt the office
