Axxess HPZM2 ZIGBEE WIRELESS MODULE User Manual 1

Axxess Industries Inc. ZIGBEE WIRELESS MODULE 1

User Manual

HPZM2 USER’S MANUAL JULY 10 2014
HPZM2 USER’S MANUAL JULY 10 2014
Contains FCC ID: HPZM2
United States (FCC)
This equipment complies with Part 15 of the FCC rules and regulations.
To fulfill FCC Certification requirements, and OEM manufacturer must comply with the following regulations: (1) The modular
transmitter must be labelled with its own FCC ID number, and, if the FCC ID number is not visible when the module is
installed inside another advice, then the outside of the device into which the module is installed must also display a label
referring to the enclosed module. This exterior label can use wording such as the following:
Example of label required for OEM product containing HPZM2 module
WARNING: The Original Equipment Manufacturer (OEM) must ensure that the OEM modular transmitter must be labelled
with its own FCC ID number. This includes a clearly visible label on the outside of the final product enclosure that displays
the content shown below. If the FCC ID is not visible then the outside of the device into which the module is installed must
also display a label referring to the enclosed equipment.
IMPORTANT: This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation (FCC 15.19). The internal / external antenna(s) used for this mobile
transmitter must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
IMPORTANT: The module is limited to OEM installation only. OEM integrators are responsible for ensuring that the end-user
has no manual instructions to remove or install module. The module is limited to installations in mobile or fixed applications,
according to Part 2.1091(b). Separate approval is required for all other operating configurations, including portable
configurations with respect to Part 2.1093 and different antenna configurations.
IMPORTANT: OEM integrators must include the following instructions and statements in the user manual (i.e. end product):
(1) statements and labeling as required per Part 15.19 and 15.21, and (2) end-users must be provided with
transmitter/antenna installation requirements and operating conditions for satisfying RF exposure compliance: (i) a separate
section should clearly state “FCC RF Exposure requirements”, (ii) Required operating conditions for end users, (iii) antenna
or transmitter installation requirements where relevant (i.e. “ The internal / external antenna(s) used for this mobile
transmitter must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.”)
HPZM2 USER’S MANUAL JULY 10 2014
For HPZM2 module:
IC: 9709A-HPZM2
AXXESS HPZM2 ZRM
HPZM2
Canada (IC)
Equipment is subject to certification under the applicable RSSs, shall be permanently labelled on each item, or as an
inseparable combination. The label must contain the following information for full compliance:
The Industry Canada certification label of a module shall be clearly visible at all times when installed in the host device,
otherwise the host device must be labelled to display the Industry Canada certification number of the module, preceded by the
words “Contains transmitter module”, or the word “Contains”, or similar wording expressing the same meaning, as follows:
Contains transmitter module IC: 9709A-HPZM2
The applicant for equipment certification of the module shall provide with each unit of the module either a label such as
described above, or an explanation and instructions to the user as to the host device labelling requirements.
IMPORTANT: This equipment for which a certificate has been issued is not considered certified if it is not properly labelled.
The information on the Canadian label can be combined with the manufacturer’s other labelling requirements.
IMPORTANT: Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : 1( l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
IMPORTANT: To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. The antenna
used with this module must be installed to provide a separation distance of at least 20cm from all persons, and must not
transmit simultaneously with any other antenna or transmitter.
Conformément à la réglementation d'Industrie Canada, le présent éemetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur approuvé pour l'émetteur par Industrie Canada. Dans le
but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e) ne dépasse pas
l'intensité nécessaire à l'établissement d'une communication satisfaisante.
IMPORTANT: The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not
emit RF field in excess of Health Canada limits for the general population. Consult Safety Code 6, obtainable from Health
Canada’s website www.hc-sc.gc.ca/rpb.
HPZM2 USER’S MANUAL JULY 10 2014
The HPZM2 Module has been certified for use in European Union countries. If the HPZM2 Module
Furthermore, the manufacturer must maintain a copy of the HPZM2 Module documentation
