AW-GD200
Linux Driver Installation & User Guide
Version: 1.1
2005/10/20
2
History
Version Date Description
1.0 2005/08/01 First Edition
1.1 2005/10/20 Add iwconfig user
command
Table of Contents
AW-GD200 Installation and User Guide ………………………………………… 1
History ………………………………………………………………………………. 2
Table of Contents …………………………….…………………………………… 2
Introduction ………………………………………………………………………… 3
1.1 Installation …………………………………………………………………… 3
1.1.1 Adapter Linux Driver …………………………………………….………... 3
1.1.2 Installation and Configuring the Linux Source Tree ………………. 3
1.1.3 Compile the Driver ………………………………………………………… 3
1.1.4 Install the Driver …………………………………………………………… 4
1.1.5 Overall Installation Procedure …………………………………………… 4
2.0 Configure a wireless network interface ……………………………………….. 5
2.1 iwconfig ………………………………………………………………………… 5
3
Introduction
This guide explains how to install the following software on a Linux based desktop or laptop
computer:
- AW-GD200 Driver for Linux system
This adapter can be used in a non-PC device to easily enable Wireless connectivity.
1.1 Installation
The installation procedure includes two main steps:
1. Compile the Driver
2. Install the Driver
1.1.1 Adapter Linux Driver
The driver is distributed in source-code format. In order to compile the driver, you need to have the
Linux source tree installed in your desktop/laptop computers, preferably in the /usr/src/linux
directory. This driver has been tested with Linux version 2.4.22 and compiled with gcc 3.2.2. The
host Linux system that was used to compile and test the driver is based on Slackware 9.1
distribution.
1.1.2 Installation and Configuring the Linux Source Tree
The requirements for the environment to install and configure the Linux source tree are:
- Linux kernel source v2.4.22
- GCC v3.2.2
- Wireless Tools version 26
Then you have to follow the steps below to complete the installation and configuration process.
1. Download the Linux kernel file from http://www.kernel.org.
2. Untar the source in the /usr/src directory.
3. Create a symbolic link to the Linux source tree to a directory called "linux".
4. Run "make menuconfig" in the Linux directory and then enable the Wireless LAN under
"Network Device Support"/"Wireless LAN (Non Hamradio).
5. Configure any other options as required.
6. Exit and save the configuration.
The Linux kernel does not to be compiled when you compile the driver. However, you must install
the same version of the kernel which the driver is compiled against to run the driver.
1.1.3 Compile the Driver
If the Linux source tree is not presented in the default Linux directory, you can modify the
KERNELDIR parameter in the Makefile to direct to the location of the kernel source.
Then you can follow the steps below to compile the Linux driver:
a) Type “make clean”. Verify that there is no legacy file in the target directory.
b) Type "make". Verify that the file “deep31.o” is built and placed in the target directory.
c) The deep31.o is the driver compiled as a module for the current kernel. The Makefile also tries
to copy the driver to the /lib/modules/2.4.22/pcmcia directory so that the driver can be easily
loaded at boot time.
If you want to remove debug options -DDEBUG and –DDBG, they can be removed from Makefile
CFLAGS variable.
4
1.1.4 Install the Driver
After inserting the adapter, you can run
insmod deep31.o
to load the driver into the kernel.
1.1.5 Overall Installation Procedure
As a summary, the overall installation procedure for Linux driver is as below:
1. Extract the source into any directory. For example,
cd /usr/src
tar xvzf mb31ep_sdk_2_1_x_x.tar.gz
2. Go to the created directory and then compile the source code
cd MB31-DeepLinux
make clean
make
This should create the file deep31.o which is the driver as a loadable module.
3. There are four options to operate the driver.
a) To load this driver as AP mode, you can type
insmod deep31.o active=”deep_ap”
b) To load this driver as Client mode, you can type
insmod deep31.o active=”deep_wb”
c) To load this driver for firmware upgrade in AP mode
insmod deep31.o active=”change_ap_mode”
d) To load this driver for firmware upgrade in Client mode
insmod deep31.o active=”change_wb_mode”
(or You can execute/modify the run1 script in the source file directory to load driver)
4. If debug is enabled in the Makefile (-DDEBUG -DDBG) then debug messages can be printed
out through the klogd facility of the Linux kernel. The standard log files are in folder /var/log/debug,
folder /var/log/messages and folder /var/log/syslog.
5
2.0 Configure a wireless network interface
The following describes the configuration of AW-GD200 wireless driver using the wireless
extension tools.
2.1 iwconfig
iwconfig is dedicated to the wireless interfaces. It is used to set the parameters of the network
interface which are specific to the wireless operation (for example: the frequency). iwconfig may
also be used to display those parameters, and the wireless statistics.
The format of the iwconfig is depicted as following:
iwconfig
iwconfig -help
iwconfig interface
iwconfig interface [parameters]
Parameters
[essid X] [nwid N] [freq F] [channel C] [sens S] [mode M]
[ap A] [nick NN] [rate R] [rts RT][frag FT] [txpower T]
[enc E] [key K] [power P] [retry R] [commit]
Please refer the wireless extension tool manual for more information.
