B LINK ELECTRONIC BL-MP01 11N 150M WIRELESS Router User Manual BL MP01
B-LINK ELECTRONIC LIMITED 11N 150M WIRELESS Router BL MP01
Users Manual
Wireless Pocket Router BL-MP01
Client:
Client/Bridge
RT:
Router/WDS
AP:
AP/WIFI Amplifier
Product Specifications
With global extra small size, it works as a Mini WIFI signal amplifier,
functions of AP, wireless LAN card, client all in one; It is the perfect
match for Apple IPHONE and IPAD, as well as a good helper for mobile
working; it is portable wireless product customized for business
persons.
Size:85*32*17mm
Product features
Accessories
Package Size
Net weight (kg) Gross weight (kg) Cubic meter(mm)
Pcs/box Carton
Retail Packaging
ADD: B-LINK ELECTRONIC FACTORY, GUANLAN TOWN, SHENZHEN, CHINA
TEL:0086-755-28023440 FAX:0086-755-28029002 Website:www.lefen.com
Adapter
（Optional）
USB Cable
Quick Install
Guide
11n:supports 150Mbps at most
11g:supports 54Mbps at most
11b:supports 11Mbps at most
IEEE 802.11b、IEEE 802.11g、 IEEE802.11n、
IEEE 802.3、 IEEE 802.3U;
built-in intelligent Omni-directional antenna
RJ45 interface, USB interface
Wireless signal
transmission rate
Antenna
Ports
Operating environment
Frequency range 2.4-2.4835GHz
Transmitting power 12~15dBm
Modulation technique DBPSK, DQPSK, CCK, OFDM,16-QAM, 64-QAM
Reset/WPS button
Button
Power Adapter DC 5V/500MA
Protocol and
standard
Operating temperature：0℃- 40℃;
Storage temperature：-40℃-70℃;
Working humidity：10% -90% RH non-condensation;
Storage temperature：5% -90% RH non-condensation;
HIGH
GAIN
HIGH
GAIN
LED
2T2R
LED
WDS
WDS
2T2R
- Random choice of switching any mode among router, client and AP
- Supports WPS that encrypt by press one key, no need to set password.
- Plug and play, it's convenient to access wireless and share Internet
- Built in a device that can scan wireless hot spots, memorise SSID name and
bridge,relay automatically,convenience to use.
- Supports users' behavior management , QOS advanced management,MAC
address filtering,web page filtering and NAT address switching.
- Flexible multiple power way such as AC and USB charging, power adapter
is configured randomly with this device(5V/500MA)
- High-Integrate and multifunction designs,compact body, easy to carry.
In home network, it occupies little space and saves power. All wireless devices can be connected.
Wireline device also can be upgraded to wireless device.
In hotel network, it can help you to allow multi-user sharing wireless network without cable
restraint
In office network, you are free from pulling cable as it can bridge to any access point.
Outdoor, it acts as the receiver with high performance of wireless hot spot, allows multi-user
sharing one ID account freely at the same time.
At the place where wireless signal is weak,it can enhance signal strength to extend the
transmission distance,
Wireless r outer m ode
Internet
Client mode
Wireless A P mode
True plug
and play!
Network Cable
100 505*430*280mm
HIGH
GAIN
HIGH
GAIN
LED
2T2R
LED
WDS
WDS
2T2R
7 1
7 1
in
Wireless router
Wireless AP
Client
Bridge
WIFI e xchange
WIFI a mplification
Relay
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can be
used in portable exposure condition without restriction.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC ID: X2NBL-MP01
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
