SECTION IV
THEORY OF OPERATION
4.1 INTRODUCTION
This section contains a description of equipment and a theory of operation for the BK Radio GMH Series
mobile radio. To aid in understanding the operation of the equipment, schematic diagrams are found in
Section VI of this manual.
4.2 EQUIPMENT DESCRIPTION
The BK Radio GMH Series radio comprises the following sub-assemblies:
4.2.1 System Board
This sub-assembly consists of core microprocessor, synthesizer, regulation, and switching circuitry. A
casting is used to shield the synthesizer area.
4.2.2 RX/TX Board
This sub-assembly consists of the RX/TX antenna switch, the receiver circuitry from the front-end through
the discriminator, and the low level transmitter line up.
4.2.3 High Level Power Amplifier Board
This sub-assembly consists of the final two stages of the transmitter power amplifier, harmonic filter, and
directional coupler.
4.2.4 Options Board
This sub-assembly consists of receive and transmit audio chains, and interfaces with both the system
board and the control board.
4.2.5 Control board
This sub-assembly consists of a control head microprocessor, switching regulator, display driver, and
audio power amplifier. It interfaces with the front panel and accessory connector.
4.2.6 VCO Board
The VCO board is a separate assembly that resides in its own shielded enclosure and interconnects with
the system board and RX/TX board.
Theory of Operation GMH Series VHF Radio
Page 4-2
BK RADIO
4.3 THEORY OF OPERATION
4.3.1 System board
System board functions include:
1. Core Microprocessor
2. Regulation: 5.0, 8.6, 9.6, and 20.0 Volts
3. Synthesizer
4. Squelch Detection
5. CTCSS/CDCSS Decode
6. Power Control
4.3.1.1 Microprocessor Control
The core microprocessor (U507) communicates with the control head microprocessor and controls radio
functions such as loading the synthesizer, adjusting the deviation and receiver tuning, and CTCSS/CDCSS
detection. An EEPROM is used to store calibration and tuning data unique to each radio. A 32.768 kHz
crystal is used as a clock for the core microprocessor.
Various transistors provide level interfaces and current capability.
4.3.1.2 Regulation: 5.0, 8.6, 9.6, and 20.0 Volts
U502 and associated circuitry comprise a 9.6 volt low noise feedback regulator for use by noise-sensitive
analog circuitry on the system and RX/TX boards. A low battery indication is derived by sensing the error
control voltage of this regulator.
U601 and associated circuitry provide a second level of regulation to supply the VCO and synthesizer with
8.6 volts and 5.0 volts.
U504 is the 5 volt supply for the core of the radio.
The microprocessor drives a FET amplifier (Q503) tied to a voltage doubler. This forms a 20 volt switching
regulator which is regulated by error amplifier U502 which controls the gain on the FET.
4.3.1.3 Synthesizer
Synthesizer IC - U604 forms the main synthesizer IC which contains three programmable CMOS dividers
and a sample-and–hold phase detector. The first divider (divide-by-R) divides the reference oscillator
down to a frequency which is used as a reference by the sample-and-hold phase detector. The second
divider (divide-by-N) divides the output of the Prescaler down to a frequency which is equal to the divided
down reference frequency when the loop is locked. The third divider (divide-by-A) controls the modulus
control line of the Prescaler. The sample-and-hold phase detector provides a DC voltage that is
proportional to the phase error between the divided down reference frequency and the divided down
carrier frequency. This voltage is fed through the loop filter to the VCO and adjusts the VCO frequency to
maintain phase lock between the divided down frequencies.
GMH Series VHF Radio General Information
BK RADIO
Page 4-3
Prescaler - The prescaler U602 is the first divider in the feedback path of the synthesizer. It divides the RF
signal to a frequency which can be processed by the following CMOS dividers. The prescaler is a dual
modulus type which allows the division ratio to be set by the synthesizer to either divide-by-128 (modulus
control line high) or divide-by-129 (modulus control line low). This capability allows the channel spacing to
be determined by the divided down reference frequency and not a multiple thereof.
Reference Oscillator - The Reference Oscillator provides the frequency reference from which the receiver
and transmitter injection signals are synthesized. The oscillator frequency is controlled by the crystal Y601
which operates in the parallel resonant mode. The core microprocessor uses temperature sensor U607 to
measure the temperature of the crystal and changes the bias on varactor CR602 accordingly, to
compensate the crystal to less than ±2.5 ppm tolerance. The varactor provides a means for modulating
the reference oscillator to improve the synthesizer frequency response for low frequency modulation.
Loop Filter - The Loop Filter removes noise and unwanted frequency components from the output of the
sample-and-hold phase detector which otherwise would modulate the VCO. In addition, it employs a
multiple filter bandwidth design which allows fast response during frequency changes (such as in channel
scan) without degrading the noise and spurious performance of the receiver during steady state receive
and transmit conditions. The filter bandwidth is switched to a wide condition when the LATCH line pulses
high for approximately 6 msec during a frequency change. This allows the new frequency to be reached
quickly. When the LATCH line to returns to a low state, the filter bandwidth changes to a narrow condition
and provides for good noise and spurious performance. Different filter bandwidths are used for transmit
and receive to provide better hum and noise performance in transmit and faster response time in receive.
This is accomplished by changing the filter bandwidth to a narrower value when the RX/-TX line goes low
during transmit.
Offset D/A – U603 and associated resistors form a serial latching D/A which is loaded by the
microprocessor when it loads the synthesizer IC. This provides an offset voltage which is summed into the
loop filter op amp U605 to shift up the 0 to 4 volt output of the phase detector. Calibration of the VCO is
provided for in the software by altering the loaded values of this IC.
Deviation Compensation – U508 is a digital pot used to control the amplitude of the transmit modulation
signal. As the transmit frequency increases, less voltage is needed at the VCO, so the modulation signal is
attenuated.
4.3.1.4 Squelch Detection
U505 and associated circuitry form a bandpass filter that selects and amplifies the noise on the
discriminator output near 20 kHz. The core microprocessor samples the output of the filter, averages a
number of samples, and compares the result to a threshold number to determine if carrier is present.
4.3.1.5 CTCSS/CDCSS Decode
U506 and associated circuitry act as a filter and limiter for CTCSS/CDCSS decoding interface to the core
microprocessor.
4.3.1.6 Power Control
The core microprocessor controls the output power of the transmitter by setting the reference voltage of a
feedback control loop. U509 and associated circuitry integrate the difference between the reference
voltage and the forward detected voltage from the directional coupler, and drives the amplifier/driver Q507.
Q507 supplies bias to the low level transmitter driver stage collector.
Theory of Operation GMH Series VHF Radio
Page 4-4
BK RADIO
4.3.2 RX/TX Board
4.3.2.1 Receiver
Buffer - Q101 is an L.O. buffer which provides approximately 15 dB of gain to supply the mixer and
transmitter line-up.
Front End - The preselectors are varactor-tuned direct coupled filters with impedance transformations built
into the configuration. The bipolar preamp provides approximately 18 dB of gain to overcome filter losses
and provides a low noise figure.
Mixer/IF - The active singly-balanced JFET mixer converts the signal to an IF of 16.9 MHz where it is
filtered by the crystal filters and amplified by the IF amplifier.
Demodulator IC - I1 is a multi-function IC which provides a second mixer, second IF oscillator, amplifier,
and quadrature detection.
Antenna Switch- The antenna switch provides RX/TX isolation and switching using a TX series PIN diode
pair (which is located on the High Level PA Board) and RX shunt PIN diode, with the coaxial cable running
from the High Level PA Board to the RX/TX Board being one quarter wave-length at mid-band.
Front End Tuning- I2 is a Hex DAC that provides an independent tuning capability for each of the five
varactor elements in the two pre-selectors.
4.3.2.2 Low Level Power Amplifier
Line-up- The low level power amplifier consists of the following stages and power levels:
Low Level Amp to 0.02 watt
Driver to 0.2 watt
Final to 2.0 watts
Broadband matching networks are used throughout the line-up. The Low Level Amp runs class A, and the
driver and final are operated in class C mode. The Power control voltage is applied to the driver stage
collector.
GMH Series VHF Radio General Information
BK RADIO
Page 4-5
4.3.3 High Level PA Board
4.3.3.1 Power Amplifier
The high level power amplifier consists of a driver stage with a nominal output power of 15 watts and a
final stage with sufficient output power to provide 50 watts at the antenna port. Both stages utilize
broadband matching networks and are operated in a class C mode.
4.3.3.2 Harmonic Filter
A 9th order elliptical filter is used to attenuate harmonic components before they reach the antenna port.
4.3.3.3 Directional Coupler
A stripline directional coupler and associated detectors provide DC voltages proportional to the forward
and reflected power at the antenna connector. The forward detected voltage is used for feedback to the
power control loop and the reverse detected voltage is used to detect high VSWR conditions.
4.3.4 Options Board
4.3.4.1 Control Functions
The routing of audio signals through the options board is determined by analog switch I1. The audio path
is controlled by outputs from the control board.
4.3.4.2 Receiver Audio
Low frequency tones are removed from the audio by a high-pass filter of I2A, I2B, I2C, and associated
circuitry. De-emphasis is set by C23.
4.3.4.3 Transmitter Audio
I3D performs pre – emphasis, and I3C performs limiting. I3B is used as a buffer/amplifier and drives a
three pole low pass filter consisting of I3D and associated circuitry. This low pass filter has a cutoff at 3
kHz and provides modulation filtering to within FCC requirements. The output is routed to the systems
board. Signaling tones are generated on the control boar and summed with the transmitter audio at I3B.
Theory of Operation GMH Series VHF Radio
Page 4-6
BK RADIO
4.3.5 Control Board
Control Board functions include:
1. Microprocessor Control
2. EEPROM storage
3. Regulation
4. Display Driver
5. Signaling
6. Audio Power Amplifier
4.3.5.1 Microprocessor Control
U102 controls the interface between the radio and the user. During normal operation, U102 monitors the
front panel and push-to-talk switches, and provides data to the display. In the radio programming mode,
U102 interprets commands from the serial bus and provides a transparent interface to the external
programming source.
4.3.5.2 EEPROM Storage
EEPROM U105 is used to store the radio configuration and channel information, i.e., receive and transmit
frequencies and code guard values for each channel.
4.3.5.3 Regulation
A switching regulator, U103, is used to generate +32 volts for the vacuum fluorescent display and driver. A
+5 volt regulator, U108, is used to supply power requirements for the control and options boards.
4.3.5.4 Display Driver
Display driver U100 receives data to be displayed from U102 and drives the vacuum fluorescent display.
4.3.5.5 Signaling
U206 generates audible and subaudible tones (such as CTCSS).
4.3.5.6 Audio Power Amplifier
The audio amplifier, U107, can deliver a maximum of 4 watts into a 3.2 ohm load. Audio muting is provided
by U109.
GMH Series VHF Radio General Information
BK RADIO
Page 4-7
4.3.6 VCO Board
The VCO is a varactor tuned feedback oscillator using Q1 with feedback from tapped auto transformer T1.
A steering voltage is used to set the capacitance of CR1, CR10, CR11, and CR12, which in turn controls
the frequency of oscillation. CR3 provides a low sensitivity input for modulating the carrier frequency.
The cascode amplifier comprised of Q6 isolates the VCO from its load and provides a nominal drive level
of 0 dBm in receive and transmit.
