BRIGHT DRAGON TECHNOLOGY SP-02 Bluetooth Speaker User Manual
BRIGHT DRAGON TECHNOLOGY LIMITED Bluetooth Speaker
User Manual
1
User’s manual
SP-02
Bluetooth Stereo Speaker
SPECIFICATIONS
Model no SP-02 Ver. Bluetooth V.3.0+EDR
Bluetooth Profiles HSP,HFP,A2DP,AVRCP Effective Range 10Meters
Music Time 6Hours Talk Time 9Hours
Standby Time Up to 250 Hours Iuput DC : 5V/500ma
Charge Time 4~5Hours Dimensions 142*35*63mm
2
About SP-02
SP-02 is a stereo speaker with Bluetooth technology. It supports the following Bluetooth
profiles:
HSP —— Speaker Profile
HFP —— Hands-free Profile
A2DP—— Advanced Audio Distribution Profile
AVRCP——Audio/Video Remote Control Profile
Overview
1 NEXT 2 Volume UP
3 MFB 4 Volume Down
5 Preview 6 Line in
7 USB Charge port 8 Power Switch
Charging the battery with USB cable
• Step1: Insert USB charging cable into any USB port have more than 500ma
(PC/NB/power bank/adapter)
• Step2: Connect charging cable with the charging port of SP-02.
• When the red light is on, the SP-02 is charging.
3
• When the blue light is on, the SP-02 battery is charged fully.
• It takes about 4~5 hours to full charge the battery.
Warning:
• The battery is rechargeable.
• First time charging : Before use SP-02, please charge the battery fully
How to use
A Switching on / off Speaker
When turn on power switch, the SP-02 will into the standby mode. Wait the device
connect with SP-02.
When turn off power switch, the SP-02will into power off status.
B Pairing the SP-02 with Bluetooth devices
A) How to enter pairing mode
Be sure SP-02 in “power on” and “Standby” status first. Press and hold the MFB for 3
seconds, till Red and blue Led blink alternately, or you hear the indication “Do Do” twice
come out. And then release the MFB. The unit will become pairing mode.
B) Pairing the speaker with Bluetooth mobile phone
Please make sure your mobile phone has Bluetooth function that can be used.
Specific pairing procedures were not the same with different mobile phone. Please refer to
your mobile phone manual for further information. Steps as follows:
a) Please keep the SP-02 and mobile phone in the range of 1 meter when pairing.
b) Start the Bluetooth function of mobile phone and search the Bluetooth devices.
c) Wait the SP-02 enter into pairing mode (Please refer to “how to enter into pairing
mode”).
After got the SP-02 is on the list, select “SP-02”in the Bluetooth device list.
4
a) Almost all mobile no need enter pass word but some version Bluetooth maybe need it,
if need it the password is”0000”, and press the key of” Yes” or “confirmed”.
b) After successful pairing, select “SP-02” in the Bluetooth device list, and press
“connect”.
c) After successful connecting, the blue LED of the SP-02 will quickly blinks twice or
three times every 4 seconds.
Making calls with the speaker
Function Status of SP-02 Operation
Redial last
number Standby mode Short press MFB twice quickly
Volume up Conversation
mode
Short press or hold + key.
When the volume is adjusted to max, you will hear an
indication tone.
Volume
down
Conversation
mode
Short press or hold – key.
When the volume is adjusted to min, you will hear an
indication tone.
Answer
calling Ringing Short press MFB
Reject calling Ringing Short press MFB twice quickly
Notes:
• For some mobile phones, when you press the key of accepting on the phone, the
conversation will be sent to the mobile phone. At this time, you can switch the call to
speaker by using the conversation switch button or through operating on the mobile
phone. Please refer to the instruction of your mobile phone for further information
Playing music
When the SP-02 connects with the mobile phone or other Bluetooth which supports A2DP,
you can enjoy music through SP-02 wirelessly.
5
Function Status of speaker Operation
Pause Playing music Short press MFB
Play Standby Short press MFB
Last song Playing music Press preview key
Next song Playing music press next key
Volume up Playing music
press + key.
When the volume is adjusted to max, you will
hear an indication tone.
Volume down Playing music
Short press – key.
When the volume is adjusted to min, you will
hear an indication tone.
Notes: .
• When you use SP-02 remote control the function of last song/next song/pause, it needs
your mobile phone or Bluetooth transmitter supports AVRCP. Please refer to the
instruction of your mobile phone or Bluetooth transmitter. for further information.
LED indicator
A) Charging
LED indicator Status of the SP-02
Red LED is on Charging
Blue LED is on Finish charging
6
B) In use.
LED Indicator Status of the speaker
Red and blue LEDs blink alternately Pairing mode
Blue LED quickly blinks once every 2 seconds. Not connected to a device
Blue LED gradually turns on and off Conversation mode
Red LED blinks twice every 20 seconds Low power
G Re-connecting to a Bluetooth device
A) Automatic connecting
Every time the SP-02 is switched on, it will connect to the last connected device, and
connected automatically.
B) Manual connecting to last connected device
When the speaker is in standby mode and doesn’t connect to any devices, short press
MFB button once, it will connect to last connected device automatically.
7
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
‐‐ Reorient or relocate the receiving antenna.
‐‐ Increase the separation between the equipment and receiver.
‐‐ Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
‐‐ Consult the dealer or an experienced radio/TV technician for help.
