FCC Class A Device
Class A Device Statement: (Section 15.105(a) of the FCC Rules)
Note: This equipment has been tested and found to comply with the limits for a Class A
digital service, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interface when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interface in which case the user will be
required to correct the interface at there own expense.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Intended Usage
The DBL can be used on three different sensors; Ford model year 06 banded sensors,
Schrader 315 MHz valve stem sensor, and the Schrader 433 MHz valve stem sensor.
Power Supply
The DBL is powered by one 9 volt battery.
DBL Operation
Low Power Indicator
The LED labeled POWER lights RED when the battery needs to be replaced.
Using the DBL
The process of using the DBL is one simple operation of holding the tool over the sensor
and pressing the test button down. When the TEST button is pressed the green TPMS
light will come on and stay a solid green color until a signal is received from the sensor in
the wheel, or the cycle time ends. The DBL will first attempt to activate Ford 06 sensor
types, followed by the activation of Schrader. Please be patient while holding the DBL in
position as read attempts occur for the various sensor types.
Successful Read
When the test tool reads the sensor correctly the green TPM light will flash and an
audible sound will be emitted.
Unsuccessful Read
The sensor in the wheel was not activated if the TPMS light does not flash, no audible
signal is heard and the TPMS light then turns off.
Proper Positioning
Ford model year 06 banded sensors
To read the Ford model year 06 banded sensors the DBL must be placed directly over the
sensor (as shown below) which 180 degrees from the valve stem.
Picture 1 - Ford model year 06 Banded 1
Schrader valve stem sensors
To read the Schrader 315MHz and 433MHz sensors, the DBL must be placed over the
sensor (as shown below) which is connected the valve stem.
Picture 2 - Schrader 1
Additional Information
Environmental
Operating Temperature xx degrees to xxx degrees F / xx degrees to xxx degrees C
Storage Temperature xx degrees to xxx degrees F / xx degrees to xxx degrees C
Humidity xx% to xx% (non-condensing)
Shock xx K G (at xx degrees F / xx degrees C)
DBL Technical Brief
??????? Processor
??????? Ram
??????? Flash programmable memory
LED spec?
Loud Sounder
Enclosure
Constructed from _____________ injection molded polypropylene-alloy
