23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

SHARE WIRELESS MODEM-ROUTER

USER MANUAL

F7D3402 v1

TABLE OF CONTENTS

Getting Started

What’s in the Box

Initial Setup

Advanced Tools & Settings

The Belkin Router Manager

Manual Setup Using Your Browser

Adding Computers to Your Network

Adding USB Devices

Bundled Software

Additional Capabilities

Getting to Know Your Router

Front Panel

Back Panel

Technical Details

Technical Features

System Requirements

Troubleshooting, Support, and Warranty

Troubleshooting

Technical Support

Belkin International, Inc., Limited 2-Year Product Warranty

Regulatory Information

FCC Statement

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Getting Started

What’s in the Box

Share Wireless Modem-Router

ADSL cable (attached to router)

In some regions, a phone-jack adapter (microfilter) will be included.

Power supply (attached to router)

Network information card (attached to router)

Belkin Setup CD with User Manual

Initial Setup

Where to Place Your Router

Forthebestresults,placetheRouterinanopenlocationawayfrom

largemetalobjectsandmagnetssuchasthosefoundinspeakers.

RaisingtheRouterabovefloorlevelcanimprovethestrengthof

yourwirelesssignal.

How to Set It Up

[MRSHARE/PLAYSETUPDIAGRAMmrshareplaysetup.ai]

1) ConnectyourRouter’sADSLcabletoyourphonejackor

phone‐jackadapter(microfilter).Ifyouarereplacingan

existingRouterorgateway,thismayrequireunpluggingthe

existinggateway.

Note:IfrequiredbyyourInternetServiceProvider(ISP),

plugtheincludedphone‐jackadapter(microfilter)intoyour

wall‐mountedphonejack.Pleasecheckwithyourprovider

beforeconnectingyourRouterifyouareunsurewhetheror

notyouneedtousetheincludedphone‐jackadapter.

2) PlugtheRouter’spowersupplyintoawalloutlet.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

3) PuttheCDintoyourcomputer.IftheCDdoesn’topen

automatically,pleasebrowsetoyourCDdriveanddouble‐

clickontheBelkinSetupCDicon.

[SCREENSHOTOFSETUPMENUsetupmenu.png]

4) ClicktheSetupiconontheCDmenu.

[SCREENSHOTOFNETWORKINFOCARDSCREENsetup

netinfocard.png]

5) Afterabriefinstallation,thesetupsoftwarewillaskyoufor

thenetworknameandpasswordfromthenetwork

informationcardthatisattachedtoyourRouter.Storethe

cardunderthebaseofyourRouterforfuturereference.

[SCREENSHOTOFSUCCESSsetupsuccess.png]

6) Aprogressscreenwillappearwhileadditionalsoftwareis

installed.Thismaytakeafewminutestocomplete.Once

finished,a“Success”messagewillappearindicatingthatyou

areconnectedtotheInternetviayournewBelkinRouter.

Duringsetupyoumaybeaskedforadditionalinformation.

YoumayneedtoenterausernameandpasswordprovidedbyyourISP.

Thisusernameandpasswordislikelytobefoundonmaterialsthatcame

fromyourISPwhenyousignedupforservice.Ifnecessary,youmayneed

tocontactyourISPtoretrieveyourusernameandpassword.

IfyouhaveastaticIPaddress,youmayneedtoenteradditional

informationalsoprovidedbyyourISP.

Ifyourcomputerdoesn’thaveawirelessadapter,orthesetupsoftwareis

unabletocontrolit,youmaybeaskedtoconnectyourcomputertothe

Routerwithanetworkcable.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

IfthesetupsoftwareisunabletodetectyourVCIandVPIsettingsbased

onyourcountry,youmayalsoneedtoenterthisinformation.YourISPis

likelytohaveprovidedit.

Advanced Tools & Settings

[SCREENSHOT OF ADVANCED MENU setup advanced2.png]

After the initial setup is complete, you have the option to change

settings like your network name, security type, and password. To

make these changes and others, click on the Advanced Tools icon

at the CD Setup menu and select one of the following settings that

you would like to change:

NetworkName&Security

Personalizeyournetworkname(SSID),password,andstrengthof

wirelesssecurity.

InternetServiceProvider&LoginSettings

HaveyoumovedorchangedInternetServiceProviders?Ifyou’dliketo

changethesesettingswithoutrunningthroughthesetupprocessagain,

thisistheplace.

The Belkin Router Manager

[SHARE SCREENSHOT OF TRAY APP MENU (TBD)]

The Belkin Router Manager appears in your system tray (Windows) or

menu bar (Mac). Its icon indicates the current status of your Router

and also allows you to access your Router’s settings to make

changes. It also provides quick access to software that came

bundled with your Router.

To access the Router settings, click on the icon and select from the

menu that appears.

The status of your Router is shown by the Belkin Router Manager icon,

which closely mimics the light on the front of the Router.

Green: You are connected to your Belkin Router and it is connected to the Internet.

Amber: You are connected to your Belkin Router, but it is not connected to the

Internet.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Manual Setup Using Your Browser

[ZOOMED SCREENSHOT OF ADDRESS BAR address bar.png]

In your browser, type “http://router” (you do not need to type in

anything else such as “www”). Then press the Enter key. If you’re still

having trouble running the manual setup option, type “192.168.2.1”

in your browser (you do not need to type in anything else such as

“http://” or “www”). Then press the Enter key.

Adding Computers to Your Network

Wireless devices such as computers, network printers, and gaming

systems can connect to your Router with a few simple steps.

Using the CD

1) PuttheSetupCDintoyourcomputer.IftheCDdoesn’topen

automatically,browsetoyourCDdriveandopentheBelkin

SetupCDicon.

2) ClicktheSetupiconontheCDmenu.

3) Afterabriefinstallation,thesetupsoftwarewillaskyoufor

thenetworknameandpasswordfromthenetwork

informationcardthatcamewithyourRouter.Thiscardis

mostlikelynowlocatedunderneaththefootofyourRouter

intheprovidedcardslot.

4) Aprogressscreenwillappearwhileadditionalsoftwareis

installed.Thismaytakeafewminutestocomplete.Once

finished,a“Success”messagewillappearindicatingthatyou

areconnectedtotheInternetviayournewBelkinRouter.

Note:ThesetupsoftwarerunsonlyonWindowsandMacOSX

systems.

Manually

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

IfyouchoosenottousetheincludedSetupCDforadding

additionalcomputersorwirelessdevices,youcanmanuallyadd

theseitemstoyournetwork.

1) Locatethewireless‐network‐connectionsoptiononyour

computerorwirelessdevice.

2) SelectyourBelkinRouterfromthelistofavailablenetworks.

YoucanidentifyyourBelkinRouterbylocatingthenetwork

name(SSID)fromthecardlocatedunderneaththefootof

yourRouter.

3) Enteryournetworkpassword(locatedonyournetwork

informationcard).

Yourwirelessdevicewilltakeafewmomentstoconnectto

yournetwork.Iftheconnectionisnotmadethefirsttime,try

thisprocessagain.Ifyoustillhavedifficultyconnectingto

yournetworkaftertryingthisprocessafewtimes,seethe

“Troubleshooting”sectioninthismanualforhelpwith

connectingtoyournetwork.

Note:Insomecasesyoumaybepromptedtoselectthe

securitytype.Itisprintedonthecardforyourconvenience.

Using the WPS Button

1) StartWPSPushButtonConnection(WPSPBC)onyour

computerorotherWi‐Fidevicethatyouwouldliketoconnect

wirelesslytoyourRouter.Oftentherewillbeabuttonfor

thispurposeinsoftwarethatcamewiththedevice,ora

physical“WPS,”“PBC,”or“Security”buttononthedevice

itself.

2) Withintwominutes,presstheWPSbuttononyourRouter.

TheWPSlight(smalllightaboveWPSbutton)willblinkgreen

whileitlistensforyourWi‐Fidevice.Onceaconnectionis

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

established,thelightwillturngreenandthengoout.Ifa

connectionisnotestablished,thelightwillblinkamber.You

mayrepeattheprocesstotryagain.

YoucanrepeatthisprocessforeachWPS‐enableddeviceyou’d

liketoaddtoyournetwork.

Adding USB Devices

[USB INVITATION DIAGRAM (TBD)]

Adding a Drive

YoucanshareaUSBharddriveorflashdrivetoyournetworkvia

yourRouter’sUSBport.Onceconnected,youcansharefilesand

musicwithothercomputersanddeviceswithinyournetwork.

PlugyourUSBharddriveintotheUSBportonthebackofyour

Router.WhenthelightabovetheUSBportislit,yourdriveis

availabletocomputersonyournetwork.

Youcanmanuallycheckthestatusofyourshareddriveby

visitingtheUSBPrintandStorageManager,foundunderthe

BelkinRouterManagericondisplayedinyoursystemtray

(Windows)ormenubar(Mac).Ifyouhavedifficultysharing

adriveonyournetwork,pleaseseethe“Troubleshooting”

sectionofthismanual.

Adding a Printer

YoucanaddaprintertoyournetworkviayourRouter’sUSBport.

Onceconnected,youcanprintfromvariouscomputersand

wirelessdeviceswithinyournetwork.

Plugyourprinter’sUSBcableintotheUSBportlocatedontheback

ofyourRouter.WhenthelightabovetheUSBportislit,your

printerisavailabletocomputersonyournetwork.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Youcanmanuallycheckthestatusofyourprinterbyvisitingthe

USBPrintandStorageManager,foundundertheBelkinRouter

Managericondisplayedinyoursystemtray(Windows)ormenu

bar(Mac).Ifyouhavedifficultysharingaprinteronyournetwork,

pleaseseethe“Troubleshooting”sectionofthismanual.

Note:Eachcomputerthatwillusetheprintermusthaveboththe

Belkinsoftwareandtheprinter’sdriverinstalled.Iftheprintdriver

isnotinstalled,youwillbeaskedtoinstallitbytheBelkinUSB

PrintandStorageManager.

Adding Other USB Devices

OtherUSBdevicesmayalsobesharedviayourRouter.Plugyour

deviceintotheUSBportlocatedonthebackofyourRouter.When

thelightabovetheUSBportislit,yourdeviceisavailableto

computersonyournetwork.

ComputersrunningtheBelkinUSBPrintandStorageManager

willbeabletomakeuseoftheshareddevicebyvisitingtheUSB

PrintandStorageManager,foundundertheBelkinRouter

Managericondisplayedinyoursystemtray(Windows)ormenu

bar(Mac).

Bundled Software

USB Print and Storage Manager

TheUSBPrintandStorageManagerhelpstomanageandmonitor

theuseofyourUSBprinters,scanners,harddrives,andother

devicesthatareconnectedtoyourRouter’sUSBportandshared

acrossyournetwork.USBPrintandStorageManagerisfoundin

theBelkinRouterManagericondisplayedinyoursystemtray

(Windows)ormenubar(Mac).

WhenyouhaveoneormoreUSBdevicesattachedtoyourRouter,

themainactionsforthosedevicesareavailabledirectlyfromthe

BelkinRouterMonitormenu.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Memory Safe

MemorySafeallowsyoutosetuparoutinebackupofyourfilesto

aharddriveorflashdriveattachedtoyourRouter.MemorySafeis

foundintheBelkinRouterManagericondisplayedinyoursystem

tray(Windows)ormenubar(Mac).

Additional Capabilities

Guest Access

YoucanallowgueststouseyourInternetconnectionwithout

joiningyourpersonalnetwork.Thenetworknameandpassword

fortheguestnetworkislocatedonthenetworkinformationcard

foundunderthefootofyourRouter.

Apersonusingyourguestnetworkwillbeabletojoinwithouta

password,butwillbeshownaloginpagewhentheyattemptto

surftheWeb.Theywillneedtoentertheguestpasswordintothis

pagetocontinue.

Getting to Know Your Router

Front Panel

[DIAGRAM front.ai]

A) Router Status Light

YourRouter’sstatusisshownbythelightonthefront.

Off:TheRouterisnotpluggedintoapowersource.

BlinkingGreen:TheRouterisstartingup.

SolidGreen:TheRouterisconnectedtotheInternet.

BlinkingAmber:EithertheRJ11cableisnotpluggedin,orthereisno

signal.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

B) Wi-Fi Protected Setup (WPS) Light and Button

TheWPSbuttononthefrontofyourRoutercanbeusedtohelp

establishasecureconnectionbetweenyourRouterandotherWPS‐

enabledWi‐Fidevicessuchascomputers.TousetheWPSfeature

onyourRouter,see“GettingStarted>AddingComputerstoYour

Network>UsingtheWPSButton”.

ThesmalllightneartheWPSbuttonshowswhatishappening

whileyouareusingWPStoestablishaconnection.

Off:Idle

BlinkingGreen:TheRouterislisteningforaWPS‐enabledcomputeror

otherdevice.

SolidGreen:TheRouterhasmadeasecureconnectionwiththecomputer

orotherdevice.

Amber:Aconnectionwasnotcreated.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Back Panel

[MR DIAGRAM FOR SHARE AND PLAY mr_shareplay_back.ai]

A) ADSL Connector

ConnectyourRoutertoaphonejackusingatelephonecord.In

someareas,amicrofiltermightberequired.

B) Wired (LAN) Connectors

Connectcomputersandotherwirednetworkdevicestotheseports

usingEthernetcables.

C) USB Port

USBprinters,disks,andotherUSBdevicespluggedintothisport

willbesharedonyournetwork.EachUSBporthasalightthat

indicatesitsstatus.

Off:NoUSBdeviceisconnectedortheattachedUSBdeviceisnotinuse.

Blinking:Pleasewaittounplugthedeviceuntilthelightturnsoff.

On:TheUSBdeviceisconnectedandbeingsharedonyournetwork.

D) Reset Button

ThisbuttonisusedtorestartyourRouterinrarecaseswhenit

functionsincorrectly.ResettingtheRouterwillpreserveyour

settings.Thisbuttonmayalsobeusedtorestorethefactorydefault

settings.PleaseseetheTroubleshootingsectionformore

information.

E) Power Connector

Connecttheincludedpowersupplytothisjack.

Technical Details

Technical Features

Integrated ADSL2+ Modem

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

The integrated ADSL2+ modem allows you to connect to the Internet via

your local Internet Service Provider (ISP) without installing and

maintaining a separate DSL modem.

Integrated 802.11n Wireless Access Point

Utilizing MIMO (Multiple Input Multiple Output) smart-antenna

technology, your Router can reach data transfer speeds of up to 300Mbps

across your network.

NAT IP Address Sharing

To save you the cost of adding IP addresses per computer in your house,

your Belkin Router uses Network Address Translation (NAT) technology,

allowing you to share a single IP address across your network.

SPI Firewall

Your Router is equipped with a firewall that will protect your network

from a wide array of common attacks and viruses.

Universal Plug-and-Play (UPnP) Compatibility

The UPnP (Universal Plug-and-Play) feature in your Router offers

seamless operation of voice and video messaging, games, and other

applications that are UPnP-compliant.

Web-Based Advanced User Interface

You can easily make changes to your Router’s advanced settings through

your web browser. These changes can be made from any computer on your

network.

Belkin Router Monitor

The Belkin Router Monitor application helps you to monitor your

Router’s status and change network settings.

Integrated 4-Port 10/100 Switch

Your Router has a built-in, 4-port network switch to allow your wired

computers to share: printers, data, MP3 files, digital photos, and much

more.

USB Port

The USB port lets you plug in printers, hard drives, and other USB

devices to share across your network.

System Requirements

Modem Router

Broadband ADSL Internet connection with RJ11 (telephone) connection

At least one computer with an installed network interface adapter

TCP/IP networking protocol installed on each computer

RJ11 ADSL telephone cable

Internet browser

Setup Software

A computer running Windows® XP SP2 or higher, Windows Vista®, or

Windows 7; or Mac OS® X v10.x

Minimum 1GHz processor and 256MB RAM

600MB of free hard-drive space for installation

Memory Safe and USB Print and Storage Manager

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Windows XP SP2 or higher or Windows Vista; or Mac OS X v10.4 or later

Minimum 1GHz processor and 256MB RAM

50MB of free hard-drive space for installation

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Troubleshooting, Support, and Warranty

Troubleshooting

The Setup CD does not automatically start.

IfBelkinSetupdoesnotrunwhenyouinserttheCD‐ROM,your

computermaynotbeconfiguredtoopenCDsautomatically.

IfBelkinSetupdoesnotappearwithin15seconds,browsetoyour

CD‐ROMdriveandopenthe“BelkinSetup”icon.Alternatively,

youmayvisithttp://router/andperformthesetupmanually.Please

see“ManualSetupUsingYourBrowser”earlierinthismanualfor

moreinformation.

Belkin Setup cannot find my Router.

IfBelkinSetupisnotabletocommunicatewithyourRouter

duringtheinstallationprocess,pleasecheckthefollowingitems.

1) Makesurethatthewirelesshardwareonyourcomputeristurnedon,

ifavailable.

2) Tryconnectingyourcomputertooneofthefour“wired”portson

theRouterwithanEthernetcable.

3) EnsurethattheRouterison.Thefront‐panellightshouldbeon.

4) UnplugtheRouter’spowersupplyfor10seconds,thenplugitback

in.

5) Theremaybefirewallsoftwareonyourcomputerpreventingan

outgoingconnection.Youmaychoosetotemporarilydisablethis

softwarebeforeattemptingsetup.

IfBelkinSetupstillcannotfindtheRouter,youmightchoosetodo

amanualsetup.Referto“ManuallyConfiguringNetwork

Settings”inthismanualfordetails.

Belkin Setup cannot connect my Router to the Internet.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

IfBelkinSetupisnotabletoconnecttheRoutertotheInternet,

pleasecheckthefollowingitems:

1) Use the troubleshooting suggestions within Belkin Setup.

2) If your ISP requires a user name and password, make sure that

you have typed in your user name and password correctly.

Some user names require that the ISP’s domain may be at the

end of the name. Example: “myname@myisp.com”. The

“@myisp.com” part of the user name may need to be typed as

well as your user name.

3) If you continue to have no Internet connection, refer to

“Manually Configuring Network Settings” in this manual for an

alternative setup method.

Belkin Setup completed installation, but I cannot browse the Web.

The light on the front of my Router is blinking amber.

1) MakesuretheRouterisconnectedtoyourADSLlinewithan

RJ11(telephone)cableviatheRouter’sonegrayADSLport.

2) Checkthatthemodem(ADSL)connectionisconnectedto

yourbroadband(ADSL)socketonthewall(viaanADSL

filterifoneisrequired).

3) UnplugyourRouter’spowersupply,wait10seconds,and

plugitbackin.ThiswillcausetheRoutertotrytoreestablish

communicationwiththeADSLline.

I can’t connect to the Internet wirelessly.

IfthelightonthefrontoftheRouterissolidgreen,thenyour

RouterisconnectedtotheInternet.Youmaynotbeconnectedto

theRouter’swirelessnetwork.Pleasereferto“AddingComputers

toYourNetwork”inthismanualforinstructions.

I can’t connect to the Internet wirelessly and my network name is

not listed in Available Networks.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

1) VerifythatyourRouterisonandthefront‐panellightshows

solidgreen.

2) IfyouarefarfromtheRouter,youmighttrymovingcloserto

seeifyoumighthavebeenoutofrange.

3) UsingacomputerattachedtotheRouterviaanetworkcable,

visithttp://router/andensurethat“BroadcastSSID”isON.

Thissettingisfoundonthe“ChannelandSSID”page.

My wireless network performance is slow, inconsistent, suffers

from weak signal, or I’m having difficulty maintaining a VPN

connection.

Wireless technology is radio-based, which means connectivity

and the throughput performance between devices decreases

when the distance between devices increases. Other factors that

will cause signal degradation (metal is generally the worst

culprit) are obstructions such as walls and metal appliances.

Note also that connection speed may decrease as you move

farther away from the Router.

In order to determine if wireless issues are related to range, we

suggest temporarily moving the computer within 10 feet from

the Router if possible.

Changing the wireless channel—Depending on local wireless traffic and

interference, switching the wireless channel of your network can

improve performance and reliability. See the section titled

“Changing the Wireless Channel” for instructions on how to

choose other channels.

Limiting the wireless transmit rate—Limiting the wireless transmit rate can

help improve range and connection stability. Most wireless

cards have the ability to limit the transmission rate. To change

this property in Windows, go to the Windows Control Panel,

open “Network Connections”, and double-click on your wireless

card’s connection. In the properties dialog, select the

“Configure” button on the “General” tab, then choose the

“Advanced” tab and select the rate property.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Wireless client cards are usually set to automatically adjust the

wireless transmit rate for you, but doing so can cause periodic

disconnects when the wireless signal is too weak; as a rule,

slower transmission rates are more stable. Experiment with

different connection rates until you find the best one for your

environment. Note that all available transmission rates should

be acceptable for browsing the Internet. For more assistance,

see your wireless card’s user manual.

I’ve installed this new Router and some of my network clients

(computers, game consoles, etc.) are now unable to connect.

YournewRoutercamepre‐configuredwithanetworknameand

password,foundprintedonanattachedcard.Allclientsmustuse

thisnetworknameandpasswordtoconnectwirelesslytoyour

Router.Youwillneedtofindthenetworksettingsonyourclient,

selectthenetworknameprintedonthecardfromthelistof

availablenetworks,andenterthepasswordwhenpromptedtojoin

thewirelessnetwork.

Does the Router support Wireless Protected Access (WPA) security?

TheRoutershipswithWPA/WPA2securityturnedon.Windows

XPandsomeoldernetworkhardwaremayrequireasoftware

updatetosupportWPA/WPA2.

I am having difficulty setting up WPA security on my Router.

1) LogintoyourRouterbyvisitinghttp://router/withyourweb

browser.Click on the “Login” button in the top right-hand

corner of the screen. You will be asked to enter your

password. If you have never set a password, leave the

“Password” field blank and click “Submit”.

2) Click“Wireless”intheleft‐handmenu.Thenclick“Security”

justbelowthat.

3) Selectthe“WPA/WPA2”option.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

4) Enterapassword.Thiscanbefrom8–63charactersofyour

choice,includingspacesandpunctuation,ORa64‐digit

hexadecimalnumber(usingonlythenumbers0–9andletters

A–F).

5) Click“ApplyChanges”tofinish.Yourwirelessconnectionis

nowencrypted.Eachcomputerusingyourwirelessnetwork

willneedtousethenewkey.

Note:IfyouareconfiguringtheRouteroverawireless

connection,youwillhavetore‐connecttotheRouterafter

changinganysecuritysettings.

Note:SomeoldernetworkinghardwaresupportsonlyWEP

encryption.Ifyouroldercomputerscannotconnecttoyour

network,try128‐bitor64‐bitWEP,orseeksoftwareupdates

fromtheirmanufacturers.

I am having difficulty setting up Wired Equivalent Privacy (WEP)

security on my Router.

1) LogintoyourRouter.Visithttp://router/withyourweb

browser.Click on the “Login” button in the top right-hand

corner of the screen. You will be asked to enter your

password. If you have never set a password, leave the

“Password” field blank and click “Submit”.

2) Click“Wireless”intheleft‐handmenu.Thenclick“Security”

justbelowthat.

3) Selectthe“128‐bitWEP”option.

4) YoumaytypeinaWEPkeymanually,orgenerateonefroma

passphrase.Typeaphraseinthe“Passphrase”fieldandclick

the“Generate”button.AWEPkeyiscomposedof26

hexadecimaldigits(0–9,A–F).Forexample,C3030FAF4BB2

C3D44BC3D4EE74isavalid128‐bitWEPkey.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

5) Click“ApplyChanges”tofinish.Yourwirelessactivityis

nowencrypted.Eachcomputerusingyourwirelessnetwork

willneedtousethenewkey.

Note:IfyouareconfiguringtheRouteroverawireless

connection,youwillhavetore‐connecttotheRouterafter

changinganysecuritysettings.

Note:Someoldernetworkinghardwaresupportsonly64‐bit

WEPencryption.Ifyouroldercomputerscannotconnectto

yournetwork,try64‐bitWEP.

A disk I plugged into the USB port is not showing up on my computer

or in Memory Safe.

1) IsthelightonovertheUSBportthatthediskispluggedinto?

Ifnot,tryunpluggingandre‐pluggingthedisk.Pleasecheck

thattheUSBconnectorisfirmlypluggedintotheRouter.

2) Ifyourdiskhasanoptionalpowersupply,pleaseuseitwhile

thediskisattachedtoyourRouter.

3) TheRoutersupportsFAT16,FAT32‐,orNTFS‐formatted

disks.DisksinotherformatswillnotappearintheFinder

(MacOSX)orWindowsInternetExplorer.

A printer I plugged into the USB port is not showing up on my

computer.

1) IsthelightonovertheUSBportthattheprinterisplugged

into?Ifnot,tryunpluggingandre‐pluggingtheprinter.

PleasecheckthattheUSBconnectorisfirmlypluggedinto

theRouter.

2) ToprinttoaprinterattachedtotheRouter,yourcomputer

musthavethatprinter’sdriverinstalled.Pleasecheckthatthe

driverisinstalled.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

3) Theprintermaynotbesettoauto‐connect.ViatheBelkin

RouterManager,opentheUSBPrintandStorageCenter.

Checkthattheprinterappearsinthelistofavailabledevices.

Viewthepropertiesoftheprinter,andcheckthat“auto‐

connect”isselected.

A different sort of USB device that I plugged into the USB port is not

showing up on my computer.

MostUSBdevicesotherthandisksandprintersmustbe

accessedviatheUSBPrintandStorageCenter.

1) IsthelightonovertheUSBportthatthedeviceisplugged

into?Ifnot,tryunpluggingandre‐pluggingthedevice.

PleasecheckthattheUSBconnectorisfirmlypluggedinto

theRouter.

2) ViatheBelkinRouterManager,opentheUSBPrintand

StorageCenter.Checkthatthedeviceappearsinthelistof

availabledevices.

3) Selectthedeviceandclickthe“Use”button.Thedevicewill

bevirtuallyconnectedtoyourcomputeruntilyouchooseto

“StopUsing”thedevice,oranotherpersonrequestsuseof

thedevice.

Technical Support

US

http://www.belkin.com/support

UK

http://www.belkin.com/uk/support

Australia

http://www.belkin.com/au/support

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

NewZealand

http://www.belkin.com/au/support

Singapore

6562218850

Europe

http://www.belkin.com/uk/support

Belkin International, Inc., Limited 2-Year Product Warranty

What this warranty covers.

Belkin International, Inc. (“Belkin”) warrants to the original purchaser of this

Belkin product that the product shall be free of defects in design, assembly,

material, or workmanship.

What the period of coverage is.

Belkin warrants the Belkin product for two years.

What will we do to correct problems?

Product Warranty.

Belkin will repair or replace, at its option, any defective product free of charge

(except for shipping charges for the product). Belkin reserves the right to

discontinue any of its products without notice, and disclaims any limited warranty

to repair or replace any such discontinued products. In the event that Belkin is

unable to repair or replace the product (for example, because it has been

discontinued), Belkin will offer either a refund or a credit toward the purchase of

another product from Belkin.com in an amount equal to the purchase price of the

product as evidenced on the original purchase receipt as discounted by its

natural use.

What is not covered by this warranty?

All above warranties are null and void if the Belkin product is not provided to

Belkin for inspection upon Belkin’s request at the sole expense of the purchaser,

or if Belkin determines that the Belkin product has been improperly installed,

altered in any way, or tampered with. The Belkin Product Warranty does not

protect against acts of God such as flood, lightning, earthquake, war, vandalism,

theft, normal-use wear and tear, erosion, depletion, obsolescence, abuse,

damage due to low voltage disturbances (i.e. brownouts or sags), non-authorized

program, or system equipment modification or alteration.

How to get service.

To get service for your Belkin product you must take the following steps:

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

1. Contact Belkin International, Inc., at 12045 Waterfront Drive, Los Angeles,

CA 90094, Attn: Customer Service, or call (800)-223-5546, within 15 days

of the Occurrence. Be prepared to provide the following information:

a. The part number of the Belkin product.

b. Where you purchased the product.

c. When you purchased the product.

d. Copy of original receipt.

2. Your Belkin Customer Service Representative will then instruct you on

how to forward your receipt and Belkin product and how to proceed with your

claim.

Belkin reserves the right to review the damaged Belkin product. All costs of

shipping the Belkin product to Belkin for inspection shall be borne solely by the

purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship

the damaged equipment to Belkin, Belkin may designate, in its sole discretion, an

equipment repair facility to inspect and estimate the cost to repair such

equipment. The cost, if any, of shipping the equipment to and from such repair

facility and of such estimate shall be borne solely by the purchaser. Damaged

equipment must remain available for inspection until the claim is finalized.

Whenever claims are settled, Belkin reserves the right to be subrogated under

any existing insurance policies the purchaser may have.

How state law relates to the warranty.

THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN. THERE

ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED

BY LAW, IMPLIED, INCLUDING THE IMPLIED WARRANTY OR CONDITION

OF QUALITY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE LIMITED IN

DURATION TO THE TERM OF THIS WARRANTY.

Some states do not allow limitations on how long an implied warranty lasts, so

the above limitations may not apply to you.

IN NO EVENT SHALL BELKIN BE LIABLE FOR INCIDENTAL, SPECIAL,

DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS,

BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE

SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

This warranty gives you specific legal rights, and you may also have other rights,

which may vary from state to state. Some states do not allow the exclusion or

limitation of incidental, consequential, or other damages, so the above limitations

may not apply to you.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

*Regulatory Information

FCC Statement

DECLARATION OF CONFORMITY WITH FCC RULES FOR

ELECTROMAGNETIC COMPATIBILITY

We, Belkin International, Inc., of 12045 Waterfront Drive, Los Angeles, CA 90094,

declare under our sole responsibility that the device, F7D3402 v1, complies with

Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired

operation.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

Caution: Exposure to Radio Frequency Radiation.

The device shall be used in such a manner that the potential for human contact

normal operation is minimized.

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

a minimum distance of 20cm between the radiator and your body.

Federal Communications Commission Notice

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses, and can radiate radio frequency energy, and if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try and correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

• FCC Caution: Any changes or modifications not expressly approved by the

party responsible for compliance could void the user’s authority to operate

this equipment.

For product available in the USA/Canada market, only channel 1~11 can be

operated. Selection of other channels is not possible.

This device and its antenna(s) must not be co-located or operating in conjunction

with any other antenna or transmitter.

Canada-Industry Canada (IC)

The wireless radio of this device complies with RSS 210 Industry Canada. This

Class B digital apparatus complies with Canadian ICES-003.

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

IMPORTANT NOTE:

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

IC Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator & your body.

FCC PART 68 STATEMENT.

This equipment complies with Part 68 of FCC Rules. On the base unit of this

equipment is a label that contains, among other information, the FCC

Registration Number and Ringer Equivalence Number (REN) for this equipment.

IF REQUESTED, THIS INFORMATION MUST BE GIVEN TO THE TELEPHONE

COMPANY.

The REN is used to determine the number of devices that may be connected to a

telephone line. Excessive RENs on a telephone line may result in the devices not

ringing in response to an incoming call. In most but not all areas, the sum of RENs

should not exceed five (5.0). To be certain of the number of devices that may be

connected to a line, as determined by the total RENs, contact the local telephone

company. For products approved after July 23, 2001, the REN for this product is

part of the product identifier that has the format US: BKCDL01BF7D3402V1. The

digits represented by 01Bare the REN without a decimal point (e.g., 03 is a REN of

0.3). For earlier products, the REN is separately shown on the label.

The REN is useful to determine the quantity of devices you may connect to your

telephone line and still have all of those devices ring when your telephone

number is called. In most, but not all areas, the sum of the REN of all devices

connected to one line should not exceed five (5.0). To be certain of the number

of devices you may connect to you line, as determined by the REN, you should

contact your local telephone company to determine the maximum REN for your

calling area.

If your equipment causes harm to the telephone network, the telephone company

may discontinue your service temporarily. If possible, they will notify you in

advance. But if advance notice is not practical, you will be notified as soon as

possible. You will be informed of your right to file a complaint with the FCC. Your

telephone company may make changes in it is facilities, equipment, operations or

procedures that could affect the proper functioning of your equipment. If they do,

you will be notified in advance to give you an opportunity to maintain

uninterrupted telephone service.

23532_8820-00394_F7D3402 v1_Share Modem Router_0205 change

If you experience trouble with this telephone equipment, please contact the

following address and phone number for information on obtaining service or

repairs.

The telephone company may ask that you disconnect this equipment from the

network until the problem has been corrected or until you are sure that the

equipment is not malfunctioning.

This equipment may not be used on coin service provided by the telephone

company. Connection to party lines is subject to state tariffs.

COMPANY: Belkin International, Inc.

ADDRESS: 501 West Walnut Street, Compton, CA 90220-5221, USA

TEL NO: 1-310-604-2315

Europe

European Union Radio products with the CE or CE alert marking comply with the

R&TTE Directive (1999/5/EC) issued by the Commission of the European

Community.

Compliance with this directive implies conformity to the following European

Norms (in brackets are the equivalent international standards).

• EN 60950-1:2006 (IEC60950-1) – Product Safety

• EN 300 328 Technical requirement for radio equipment

• ETS 301 489 General EMC requirements for radio equipment.

Information

Products with the CE marking comply with the EMC Directive (2004/108/EC) and

the Low Voltage Directive (2006/95/EC) issued by the Commission of the

European Community. Compliance with these directives implies conformity to the

following European Product Family Standards.

• EN 55022 (CISPR 22) – Electromagnetic Interference

• EN 55024-1 – Electromagnetic Immunity

• EN 61000-3-2 (IEC610000-3-2) – Power Line Harmonics

• EN 61000-3-3 (IEC610000) – Power Line Flicker

• EN 60950-1 (IEC60950-1) – Product Safety

Products that contain the radio transmitter are sometimes labeled with the

Notified Body number (CE0560) or CE alert marking if the standard used in the

conformity is not harmonized across the European Community.
