6.11.01 S46 US DRAFT A31008-H5450-A5-*
Thank you for buying a Siemens mobile phone. We wish you much enjoyment
and pleasure with it.
If you read through the user guide carefully, you will get to know all the
functions of the phone. In particular, please observe the safety and PIN/Secu-
rity precautions).
The wireless phone described in this guide is approved for use in TDMA 800,
TDMA 1900, GSM 900, and GSM 1900.
FCC/Industry Canada Notice
Your phone may cause TV or radio interference (for example, when using a
telephone in close proximity to receiving equipment). The FCC or Industry
Canada can require you to stop using your telephone if such interference can-
not be eliminated. If your require assistance, contact your local service facility.
This device complies with part 15 of the FCC rules. Operation is subject to the
condition that this device does not cause harmful interference.
U2
6.11.01 S46 US DRAFT A31008-H5450-A5-*
1
Safety precautions................................ 3
Safety Information................................. 4
Electronic devices................................. 5
SAR (Specific Absorption Rate) .......... 7
Overview of the phone.......................... 9
Display symbols.................................. 10
Getting Started.................................... 11
Insert SIM card................................... 12
Remove battery .................................. 13
Insert battery...................................... 13
Charge battery.................................... 14
Switch on, no SIM.............................. 15
Switch on with SIM............................ 15
After switching on.............................. 16
Menu control using the soft keys...... 18
Making a phone call............................ 20
Dialing with number keys................... 20
End call ............................................... 20
Accept call.......................................... 20
Reject call........................................... 20
When a number is busy ..................... 21
Redial previous numbers ................... 21
During a call........................................ 22
Swap/Conference ............................. 23
Send DTMF tones .............................. 24
Babysitter ........................................... 25
Addressbook....................................... 26
New entry........................................... 26
Read/change an entry........................ 27
Call an entry ....................................... 28
Search for an entry............................. 28
Addressbook-Menu............................ 28
Store control code .............................. 29
SIM Phonebook ................................. 30
New entry........................................... 30
Phonebook-Menu ............................... 30
Location .............................................. 31
Record no............................................ 31
Store control code .............................. 32
Voice control........................................ 33
Message (SMS).................................... 35
Read Messages.................................. 35
Inbox/Outbox ...................................... 36
Archive................................................ 36
Use SMS sample................................ 37
Compose message ............................. 37
Text input with "T9"............................ 39
Setup .................................................. 41
Bitmap viewer...................................... 42
WAP...................................................... 43
Internet access................................... 43
Browser menu ................................... 44
Setup ................................................. 45
Profiles ............................................... 45
Operating instructions ........................ 47
Voice message/Mailbox...................... 48
Cell broadcast...................................... 49
SIM services....................................... 50
Records................................................ 51
Missed calls........................................ 51
Calls received ..................................... 51
Calls dialled......................................... 51
Time/charge......................................... 52
Display................................................ 52
Charge settings ................................. 52
Divert.................................................... 53
Dictaphone........................................... 55
Contents
See also Index at the end of this User Guide
6.11.01 S46 US DRAFT A31008-H5450-A5-*
2
Organiser............................................. 57
Calendar ............................................. 57
Appointments..................................... 58
Tasks .................................................. 59
Alarm clock ........................................ 60
Missed alarms ................................... 60
Notes.................................................. 61
Businesscard....................................... 62
Calculator............................................. 63
Currency conv..................................... 64
Clock .................................................... 65
Time zones.......................................... 65
Time/date ........................................... 65
Format date ........................................ 65
Auto phone off ................................... 65
Stopwatch/Countdown....................... 66
Games.................................................. 67
Profiles................................................. 68
Setup.................................................. 68
Headset.............................................. 69
Airplane mode .................................... 69
Favourites............................................ 70
Fast access key................................... 71
Left soft key........................................ 71
Speed dialing keys ............................. 72
Quick menu selection ......................... 72
Audio.................................................... 73
Ringer setting..................................... 73
Volume................................................ 73
Silent alert.......................................... 73
Filter ................................................... 73
Information tones............................... 73
Key tones............................................ 73
1 minute beep..................................... 74
Melodies............................................. 74
Melody manager ................................ 74
Compose melody ................................ 75
Setup .................................................... 76
Device................................................. 76
Security............................................... 78
Network.............................................. 80
User group .......................................... 82
Call...................................................... 82
Datenaustausch ................................. 83
Time/date ........................................... 84
Accessories ........................................ 85
Explorer................................................ 86
Siemens Quick Sync software........... 87
Fax/data mode using a PC ................. 88
Send via .../Print via IrDA.................... 89
Siemens Service.................................. 90
Troubleshooting.................................. 91
Specifications...................................... 94
Maintenance......................................... 95
Accessories......................................... 96
Basics ................................................. 96
Data/Applications............................... 96
Car Solutions ..................................... 96
Innovations ......................................... 96
U.S. FDA............................................... 97
Index................................................... 103
Contents
See also Index at the end of this User Guide
3
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Safety precautions
Switch off in hospitals or in the vi-
cinity of medical devices, e.g.
pacemakers or hearing aids. Mo-
bile phones can interfere with the
function of these devices.
Always use the handsfree kit for
calls while driving (p. 96)!
Mobile phones must be switched
off at all times in an airplane. Pre-
vent accidental activation (p. 69).
Switch off near gas stations, fuel
depots, chemical plants or blast-
ing operations. Mobile phones
can interfere with the operation of
technical installations.
Do not examine the active infra-
red interface [Class 1 LED pro-
duct (classified according to
IEC 60825-1)] using optic magni-
fication devices.
The ring tone is reproduced
through the earpiece.To avoid
damage to hearing, first accept
the call, then hold the phone to
your ear.
SIM card may be removed. Cau-
tion: small parts could be swal-
lowed by children.
Please observe:
The voltage specified on the pow-
er supply must not be exceeded.
We recommend you use original
Siemens batteries (100% mercu-
ry-free) and charging devices.
Otherwise, considerable health
risks and damage to the product
cannot be excluded.
Neither the phone nor the battery
(100% mercury-free) may be
opened under any circumstanc-
es. Changes to this device are
strictly prohibited, as they will in-
validate the type approval criteria
required for operation of the unit.
Dispose of used batteries and
phones according to the legal
regulations.
Mobile phones can interfere with
the operation of nearby TVs,
radios, and PCs.
We recommend you use only ori-
ginal Siemens accessories to
avoid possible damage and en-
sure that the phone complies with
all the relevant regulations.
Improper use invalidates the warranty!
4
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Safety Information
Important: Read this information
before using your wireless handheld
phone.
As this mobile phone is equipped
with a fixed (non-retractable) anten-
na some paragraphs in the below
text may not be applicable.
Antenna care
Use only the supplied or an ap-
proved replacement antenna. Unau-
thorized antennas, modifications, or
attachments could damage the
phone and may violate FCC regula-
tions.
Phone operation
Normal position
Hold the phone as you would any
other telephone with the antenna
pointed up and over your shoulder.
Tips on efficient operation:
For your phone to operate most effi-
ciently:
• Extend your antenna fully, if appli-
cable
• Do not touch the antenna unnec-
essarily when the phone is in use.
Contact with the antenna affects
call quality and may cause the
phone to operate at a higher pow-
er level than otherwise needed.
Driving
Laws pertaining to the use of mobile
phones while driving vary signifi-
cantly from state-to-state and some-
times even from locality-to-locality
within states. For example, some
areas may allow persons to use their
mobile phones only if they employ a
handsfree device, and some areas
may prohibit the use of mobile
phones entirely. Accordingly, Sie-
mens recommends that persons
check the laws for the areas in which
they drive or will be driving. For ar-
eas where the use of mobile phones
while driving is permitted, Siemens
encourages persons to use their
phones responsibly and to employ
handsfree devices. Also, if using
your phone while driving, please:
• Give full attention to driving – driv-
ing safely is your first responsibili-
ty;
• Use hands-free operation, if avail-
able;
• Pull off the road and park before
making or answering a call if driv-
ing conditions so require.
For vehicles equipped with an
Air Bag
An air bag inflates with great force.
DO NOT place objects, including ei-
ther installed or portable wireless
equipment, in the area over the air
bag or in the air bag deployment ar-
ea. If in-vehicle wireless equipment
is improperly installed and the air
bag inflates, serious injury could re-
sult.
5
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Safety Information
Electronic devices
Most modern electronic equipment
is shielded from RF signals. Howev-
er, certain electronic equipment may
not be shielded against the RF sig-
nals from your wireless phone.
Pacemakers
The Health Industry Manufacturer’s
Association recommends that a min-
imum separation of six (6”) inches
be maintained between a handheld
wireless phone and a pacemaker to
avoid potential interference with the
pacemaker. These recommenda-
tions are consistent with the inde-
pendent research by and recom-
mendations of Wireless Technology
Research.
Persons with pacemakers:
•should ALWAYS keep the phone
more than six inches from their
pacemaker when the phone is
turned ON
•should not carry the phone in a
breast pocket;
•should use the ear opposite the
pacemaker to minimize the poten-
tial for interference.
•should turn the phone OFF imme-
diately if you have any reason to
suspect that interference is taking
place, turn your phone OFF im-
mediately.
Hearing Aids
Some digital wireless phones may
interfere with some hearing aids. In
the event of such interference, you
may want to consult your service
provider or your hearing aid manu-
facturer to discuss alternatives.
Other Medical Devices
If you use any other personal medi-
cal device, consult the manufacturer
of your device to determine if they
are adequately shielded from exter-
nal RF energy. Your physician may
be able to assist you in obtaining this
information.
Turn you phone OFF in health care
facilities when any regulations post-
ed in these areas instruct you to do
so. Hospitals or health care facilities
may be using equipment that could
be sensitive to external RF energy.
Vehicles
RF signals may affect improperly in-
stalled or inadequately shielded
electronic systems in motor vehi-
cles. Check with the manufacturer
or its representative regarding your
vehicle. You should also consult the
manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility
where posted notices so require.
6
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Safety Information
Aircraft
FCC and Airline Regulations prohibit
using your phone while in the air.
Switch OFF your phone before
boarding an aircraft.
Check and comply with the policy of
your airline regarding the use of your
phone while the aircraft is on the
ground.
Blasting areas
To avoid interfering with blasting op-
erations, turn you phone OFF when
in a “blasting area” or in areas post-
ed: “Turn off two-way radio.” Obey
all signs and instructions.
Potentially explosive atmo-
spheres
Turn you phone OFF when in any ar-
ea with a potentially explosive atmo-
sphere and obey all signs and in-
structions. Sparks in such areas
could cause an explosion or fire re-
sulting in bodily injury or even death.
Areas with a potentially explosive at-
mosphere are often but not always
clearly marked. They include: fueling
areas such as gasoline stations; be-
low deck on boats; fuel or chemical
transfer or storage facilities; vehicles
using liquefied petroleum gas (such
as propane or butane); areas where
the air contains chemicals or parti-
cles, such as grain, dust or metal
powders; and any other area where
you would normally be advised to
turn off your vehicle engine.
Emergency Calls
Your wireless phone can be used to
make emergency calls. Check to
make sure you have a strong enough
signal and that the battery has
enough charge available.
You can originate an emergency call
from the main display screen.
You can either enter the local emer-
gency number such as 911 and then
press the talk key or you can use the
red
key as a short cut:
Press long
Press to start call
6.11.01 S46 US DRAFT A31008-H5450-A5-*
7
SAR (Specific Absorption Rate)
THIS SIEMENS S46 PHONE
MEETS THE GOVERNMENT’S RE-
QUIREMENTS FOR EXPOSURE
TO RADIO WAVES.
Your wireless Siemens S46 phone is
a radio transmitter and receiver. It is
designed and manufactured not to
exceed the mission limits for expo-
sure to radio frequency (RF) energy
set by the Federal Communications
Commission of the U.S. Govern-
ment. These limits are part of com-
prehensive guidelines and establish
permitted levels of RF energy for the
general population. The guidelines
are based on standards that were
developed by independent scientific
organizations through periodic and
thorough evaluation of scientific
studies. The standards include a
substantial safety margin designed
to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless
mobile phones employs a unit of
measurement known as the Specific
Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg.*
Tests for SAR are conducted using
standard operating positions speci-
fied by the FCC with the phone
transmitting at its highest certified
power level in all tested frequency
bands. Although the SAR is deter-
mined at the highest certified power
level, the actual SAR level of the
phone while operating can be well
below the maximum value. This is
because the phone is designed to
operate at multiple power levels so
as to use only the power required to
reach the network. In general, the
closer you are to a wireless base sta-
tion antenna, the lower the power
output.
Before a phone model is available for
sale to the public, it must be tested
and certified to the FCC that it does
not exceed the limit established by
the government-adopted require-
ment for safe exposure. The tests
are performed in positions and loca-
tions (e.g., at the ear and worn on
the body) as required by the FCC for
each model. The highest SAR value
for this Siemens S46 phone when
tested for use at the ear is
1.12 W/kg, and when worn on the
body, as described in this user
guide, is 0.41 W/kg. (Body-worn
measurements differ among phone
models, depending upon available
accessories and FCC requirements).
While there may be differences be-
tween the SAR levels of various
phones and at various positions,
they all meet the government re-
quirement for safe exposure.
The FCC has granted an Equipment
Authorization for this Siemens S46
phone with all reported SAR levels
evaluated as in compliance with the
FCC RF emission guidelines. SAR in-
formation on this Siemens S46
phone is on file with the FCC and
can be found under the Display
Grant section of http://www.fcc.gov/
oet/fccid after searching on FCC ID
PWX-S46.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
8SAR (Specific Absorption Rate)
For body worn operation, to main-
tain compliance with FCC RF expo-
sure guidelines, use only Siemens
approved accessories. When carry-
ing the phone while it is on, use the
specific Siemens belt-clip that has
been tested for compliance.
Use of non-Siemens-approved ac-
cessories may violate FCC RF expo-
sure guidelines and should be avoid-
ed.
Additional information on Specific
Absorption Rates (SAR) can be
found on the Cellular Telecommuni-
cations Industry Association (CTIA)
web-site at http://www.wow-
com.com. For SAR information in
other regions please look under
product information at www.my-sie-
mens.com
* In the United States and Canada,
the SAR limit for mobile phones
used by the public is 1.6 watts/kg
(W/kg) averaged over one gram of
tissue. The standard incorporates a
substantial margin of safety to give
additional protection for the public
and to account for any variations in
measurements.
9
6.11.01 S46 US DRAFT A31008-H5450-A5-*
(service provider)
3/15/2002 4:00p
Set Menu
Infrared port
(PC communication)
Display indicators
Signal strength/
battery level.
Left side keys
• During a call:
Volume loud - quiet.
• In menus and lists:
Scroll up and down.
• In standby mode:
Upper key: Select GSM or
TDMA mode
Lower key: Hold down for
voice control.
Addressbook key
Press 1 x for Addressbook.
Press 2 x for Group:VIP.
Call key
Dial displayed phone number
or name, accept calls.
Display last calls in standby
mode.
Ringer
To switch on and off:
Hold down.
Device interface
Connection for charger,
headset etc.
Overview of the phone
Loudspeaker
Soft keys
Voice Memo key
Hold down:
Start the recording.
Press briefly:
Play recording back.
On/Off/End key
Press briefly:
End call or jump back to the
previous menu level.
Hold down:
Switch phone on and off or
return to standby mode.
Key lock
To switch on and off:
Hold down and
press.
Confirm (switching
off only).
Microphone
10
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Display symbols
On the phone display (selection):
Displays
+Strength of incoming signal.
PCharging completed.
TBattery indicator.
NAll calls are forwarded.
3Ringer off.
2Short ringer (beep) only.
1Ringer on only, if caller number is
stored in the Addressbook.
4Alarm is set.
zKey lock active.
*!* Transmission unencrypted.
.
Phone numbers/names:
SIM card.
Phone memory.
Restricted SIM card.
KNo network access.
{Function active.
?Unknown network function.
JAuto Call answering on.
BAddressbook.
abc/ABC Indicates whether upper or lower-
case letters are active.
T9Text input with T9.
mWAP Offline.
nWAP Online.
6Infrared standby.
7Infrared transmission.
wHeadset mode.
xAdditional handset mode.
v
Car Kit active.
Calendar icons
gMemo
IMeeting.
=Call.
HBirthday.
ESpeech memo.
Soft keys
#" Scroll up and down in menus and
lists.
9Message received.
iVoice mail received.
LMissed call.
Store in Addressbook.
T9 word selection.
hSIM services (example).
WO Switch to handset.
Store in the archive.
11
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Getting Started
The phone can be operated in TDMA
or GSM mode. You can select one
of these two modes as the standard
or use automatic selection (p. 81).
Not all features are available in any of
both modes.
Procedure TDMA installat
Installation
Insert SIM card (p. 12)
Your service provider has supplied you with a SIM card that is required for both
GSM and TDMA mode.
Insert the battery (p. 13)
The battery must be inserted first.
Charge battery (p. 14)
The battery must be fully charged before switching on your phone for the first
time.
Switch on phone (p. 15)
Hold down On/Off/End key
Enter PIN (p. 15), if required in GSM mode
The SIM card can be protected with a PIN (personal identification number). If
required this PIN must be entered after switching on. Please note the informa-
tion on security (p. 78).
After switching on (p. 16)
Depending on the configuration, several settings must be made after the phone
has been switched on for the first time
12
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Getting Started
Insert SIM card
The service provider may have sup-
plied you with a SIM card for GSM
mode on which all the important da-
ta of your number are stored.
If the SIM card has been delivered in
credit card size, snap the smaller
segment out and remove any rough
edges.
•Slide out the red SIM carrier
and twist the carrier in the direc-
tion indicated by the arrow .
n
o
p
r
G
•Insert SIM card in the carrier .
Make sure the angled corner is in
the correct position, contacts
pointing in the right direction.
•Twist SIM carrier until the SIM
card faces the phone .
•Insert SIM carrier in the phone
until it clicks into place .
Security/PIN
The SIM card can be protected against mis-
use with a 4 - 8 digit PIN (personal identifi-
cation number). Depending on the type of
your SIM card, the PIN can be changed or
the protection can be activated and deacti-
vated (p. 78).
Type of the SIM card
Only 3-Volt SIM cards are supported. Older
SIM cards (5-Volt technology) cannot be
used. Please contact your service provider
if you have an older card.
13
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Getting Started
Remove battery
•Unlock battery cover and
remove .
•Remove the battery .
n
o
p
Insert battery
•Insert battery in the phone
and .
•Replace battery cover and push
gently in the direction of the arrow
, until it engages.
G
H
I
14
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Getting Started
Charge battery
The battery is not fully charged
when delivered. You should there-
fore:
•Plug in charger cable at the bot-
tom of the phone and plug in the
power supply unit to the power
supply (only use the charger sup-
plied; charge for at least two
hours).
•Push the sides of the charger ca-
ble plug together and pull to re-
move it.
Charging
The following is shown at the top of the dis-
play:
QWhen charging is in progress.
PEnd of charging.
An empty battery is fully charged after
about 2 hours. Charging is only possible in
an ambient temperature of 5°C to 40°C
(the charge icon flashes as a warning when
the temperature is 5°C above/below). The
voltage specified on the power supply unit
must not be exceeded.
Standby time
A fully charged battery provides 60 to 300
hours of standby time or 100 to 360 minutes
of talk time. The standby times/talk times
are average values and depend on the op-
erating conditions (see table below).
Charge level display (fully charged to emp-
ty):
R
S
T
U
V
A beep sounds when the battery is nearly
empty.
Battery totally discharged
If your mobile phone will not switch on and
no charge icon is displayed when you plug
in the charger, it may be that the battery is
totally discharged and has to be reactivat-
ed.
If this is the case, leave the charger cable
plugged in. The charge icon will appear af-
ter a maximum of 2 hours. The battery is
then automatically recharged.
Decrease of standby time
Operation car-
ried out Time
(min) Decrease of
tstandby time
Callingl 1 30 to 60 minutes
Display back
light * 130 minutes
Network search 1 5 to 10 minutes
* key input, games, organizer etc.
15
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Getting Started
Switch on, no SIM
If you have no SIM card, the phone
can be used only with a limited func-
tionality.
Hold down On/Off/End
key to switch on.
Provided there is a strong enough
signal and the battery has sufficient
charge, you can still make an emer-
gency call without a SIM card by
pressing the soft key use the
following parts of the menu:
Demonstration
Games
Clock
Alarm clock
Calculator
Currency converter
Calendar
Appointments
Stopwatch
+R
03/12/2002 03:00 p
SOS Menu
Switch on with SIM
If you have inserted a SIM card you
may be requested to enter your PIN
(personal identification number), de-
pending on the SIM card you use.
(Enter your PIN using the
digit keys (shown as a
series of asterisks; if you
make a mistake press
).
Confirm input with the
right soft key (see figure).
Logging on to the network will take a
few seconds.
SIM problems
If Please insert your SIM card is dis-
played, check for faults (p. 91).
PIN
If the PIN is entered incorrectly three times,
the SIM card is locked. Unlock with PUK
(S. 78).
Activate, deactivate PIN control or
change PIN (p. 78).
Please enter
your PIN:
* * * *
Clear OK
16
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Getting Started
After switching on
Technology (TDMA/GSM)
The phone can be operated in TDMA
networks as well as in GSM net-
works. When you switch on your
phone for the first time, it automati-
cally searches the network currently
available (p. 81).
Network connection
After network search has been start-
ed, the strength of the incoming si-
gnal is shown in the top line of the
display.
+Strong signal.
*A weak signal reduces
the call quality and may
lead to loss of connec-
tion. Change your locati-
on.
Set the display contrast
After switching on the phone, you
can set the display contrast if neces-
sary (p. 76).
Import SIM card Phonebook
When you insert a SIM card for the
first time and whenever you change
the SIM card, you are asked whether
you want to import the SIM card
Phonebook in the Addressbook on
the phone.
In the SIM card Phonebook, only
names and phone numbers are
stored, therefore some data fields of
the Addressbook on the phone will
be left empty. You can edit the en-
tries of the Addressbook to com-
plete them later (p. 27).
Please do not interrupt the import.
Do not accept incoming calls at this
time. Follow the instructions on the
display.
To copy the data on the SIM card to
the phone's Addressbook later, you
can use the Copy into
function of
the Phonebook menu (p. 30).
17
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Legend
The following symbols are used:
(Enter numbers or letters.
On/Off/End key.
Hold down:
In menus or lists, go back to
standby mode.
In standby mode, switch off de-
vice.
Press briefly:
Go back one menu level.
Call key.
Press to dial a phone number
that has been entered or picked
out from the Addressbook.
]
a
Press the displayed soft key on
the side indicated.
_
Use the left soft key to scroll up
and down in menus and lists.
Displays a menu or function
that can be started by simply
pressing the soft key under-
neath it.
8Function depends on the ser-
vice provider, special registra-
tion may be necessary.
y
q
Only available in either GSM or
TDMA mode.
Menu functions and option menus
are represented as:
Function Description
View Display the selected entry.
Delete Delete an entry.
18
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Menu control using the soft keys
Example: Composing an SMS
To describe the steps for menu ac-
cess in this user guide, the following
abbreviated notation is used:
Messages New SMS
This is how you proceed on the
phone:
Open menu
From standby mode by pres-
sing the right soft key.
_
Scroll to messages.
Press the left soft key on the
right side to scroll down.
+R
(service provider)
03/12/2002 03:00 p
Set Menu
ba
n
Menu
Help
Messages
Records
# " Select
^
`
o
Press.
Start the Messages submenu
by pressing
the right soft key.
_
Scroll to New SMS.
Press the left soft key on the
left side to scroll up.
Press.
Start the text editor for New
SMS by pressing the right soft
key.
Menu
settings
Messages
Call lists
# " Select
ba
p
Messages
------------------------------------
New SMS
Use SMS sample
# " Select
]`
q
Messages
Help
New SMS
Use SMS sample
# " Select
ba
r
19
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Menu control using the soft keys
(Write your message.
OK Start the option menu.
Start the Options submenu by
pressing the right soft key.
Using "T9" to quickly write a text (p. 39):
"T9" deduces the correct word from the indi-
vidual key entries. You simply press the key
where the relevant letters are located once
only. Since the display changes as you pro-
ceed it is best if you finish a word without
looking at the display.
Inserting a blank ends word.
^
Going to the right ends a word.
$Delete a word letter for letter.
Select new word suggestion.
abc SMS 140
Meeting
! $ OK
s
abc SMS 140
Meeting at 08a h
! $ OK
a
t
Press.
(Enter phone number
or
Select from the Address-
book.
Send message.
Send the message to the
service center for trans-
mission.
wIf Message type, Validity pe-
riod or Service centre are
requested, (p. 41).
Press to save the mes-
sage after it has been
sent.
Hold down.
Go back to standby
mode.
Options
------------------------------------
Send
Save
# " Select
ba
u
123 Recipient
Send to:
! $ OK
v
20
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Making a phone call
Dialing with number keys
The phone must be switched on
(standby mode).
(Enter the phone number
(always with prefix, if
necessary with the inter-
national dialing code).
$ A short press clears
the last digit, a long press
clears the entire number.
Store phone number
in the Addressbook
(p. 26).
Press the Call key.The
phone number displayed
is dialed.
International dialing codes
Many international dialing codes are stored
in your phone:
Hold down until a "+" symbol
appears. This replaces the
first two digits of the interna-
tional dialing code.
Press.
Select the required country. The internation-
al dialing code is displayed. Now add the
national number (in many countries without
the first digit if it is a zero) and press the Call
key.
End call
Press the End key briefly.
The call is ended.
Accept call
The phone must be switched on
(standby mode).
Press or
press again.
Reject call
Press or
press briefly.
Press this key even if the person on the
other end of the line has hung up first.
You can answer incoming calls using any
key (p. 77).
Diverts the caller e.g. to the
mailbox if this is set (p. 53).
+498912345
Reply Reject
4
21
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Making a phone call
When a number is busy
If the called number is busy or can-
not be reached because of network
problems, the following options are
available (depending on the service
provider):
Press.
Your phone rings when
the busy number is avail-
able. The number is di-
aled with the Call key.
Open menu.
Call back See above.
Prompt Reminder
A beep reminds you to redial
the phone number after
15 minutes
Auto dial Auto redial previous num-
bers
The number is automatically
dialed for up to 15 minutes at
increasing intervals. During
this period, no other number
can be dialed.
To end press End key or
press .
An incoming call will end the function.
y 8
Redial previous numbers
To redial the phone number last
called:
Press the Call key
twice.
To display the list of other numbers
that were dialed previously:
Press the Call key
once.
_
Scroll to the required
phone number in the list.
Dial number.
Store number in the Address-
book (p. 26).
Records: The numbers of calls that have
been received, dialed or missed are stored
for call back purposes (p. 51).
An incoming call will interrupt any other use
of the phone.
Functions during the call (p. 22).
Switch off ringer for the current call (but not,
if "Any key answer", page 77 is active):
Hold down.
The call is displayed. The caller hears the
dialing tone.
22
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Making a phone call
During a call
Call waiting
During a call, you may be advised
that there is another call waiting. You
will hear a special tone during the
call. You have the following options:
Swap
Accept the waiting call
and place the current call
on hold.
To switch between the
two calls, press
each time.
Reject
Reject the waiting call.
The caller will hear the
busy tone
or
if this is set, the caller
will be diverted to the
mailbox for example
(p. 53).
End current call
End the current call.
Accept the new call.
You may need to register for this service
with your service provider and set your
phone accordingly (p. 82).
Z
Set volume
Yo u c a n adjust the hand-
set volume with the keys
on the left-hand side of the
phone.
If a car kit is used, its volume setting
does not affect the usual setting on
the phone.
Dictaphone
To play back a recording (the person
on the other end of the line also
hears it), press the key on the right-
hand side of the phone briefly.
To record the call, hold down the key
on the right-hand side of the phone
(p. 55).
Phone number memo
You can enter a number with the
keypad during a call. The person on
the other end of the line can hear the
number being entered. The number
can be stored or contacted after the
current call has ended.
The use of this feature may be subject to re-
strictions under criminal law or other legal
provisions. Please inform the other party to
the conversation in advance if you intend to
record the call and keep such recordings
confidential. You may only use this feature if
the other party to the conversation agrees.
23
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Making a phone call
Swap/Conference
You can call another number during a
call. You can switch back and forth
between both calls or link all callers
together in a conference.
During a call, inform the other party
of your intention, then:
Put the current call on
hold.
You can now dial a new number.
When the connection is established,
you have the following options:
Swap
Swap back and forth be-
tween the two calls.
Some functions may not be supported by
your service provider.
End current call.
The following query is dis-
played:
"Back to the call on hold?"
Return to the held call or
The held call is ended.
8
+R
=
f
=
Hold Menü
y
Conference
Open call menu and sel-
ect Conference.
A held call is added (conference call
with up to 5 subscribers).
To end:
All calls are ended simul-
taneously when the End
key is pressed.
Swap/Conference
In TDMA mode, a conference may
have up to three subscribers.
Press 1 x for conference
Press 2 x for 1st subscriber
Press 3 x for 2nd subscriber
then begin from start.
To end:
All calls are ended simul-
taneously when the End
key is pressed.
Call transfer
Open call menu and sel-
ect Call transfer.
The original call is joined to the sec-
ond one. For you, both calls are now
ended. Note: Not yet supported by
all service providers.
y
q
y 8
24
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Making a phone call
Call menu
The following functions are only
available during a call:
Open menu.
Microphone
on Switch the microphone on or
off. If switched off, the person
on the other end of the line
cannot hear you. DTMF sig-
nals, however, can be heard.
Alternatively:
Hold down.
You will hear a DTMF key
tone.
Volume Adjust handset volume.
Conference (p. 23)
Time/charge While the connection contin-
ues, the call duration and (if
set, page 52) the call time/
cost are displayed.
Send DTMF
tones See right.
Call transfer (p. 23)
Main menu Direct access to the main
menu.
Call status List all held and active calls
(e.g. participants in a confer-
ence).
y
y
y
Send DTMF tones
Activation via the call menu, see left.
You can enter control codes (digits)
during a call so that an answering
machine can be controlled remotely.
These digits are directly transmitted
as DTMF signals.
Control codes (DTMF tones) stored
in the Addressbook (p. 26) can also
be used.
25
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Making a phone call
Babysitter
Calls are made to only one phone
number that is dialed by holding
down the right soft key.
Switch on
Setup
Sicherheit Babysitter
Press.
(Enter phone code (see
instructions below).
Confirm input.
Press.
/
(Select phone number
from the Addressbook or
enter a new one (with
name). The babysitter is
now active.
Switch off
Hold down.
(Enter phone code.
Press.
Confirm input.
Phone code
When first prompted, you define and enter
the phone code (4 - 8 digits) (e.g. for
Babysitter)
Please do not forget this code!
It applies to other functions as well but it
may be changed at any time (p. 78).
26
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Addressbook
You can store up to 400 entries in
the Addressbook.
New entry
Open the Addressbook
(in standby mode).
^
Select <New entry>.
Confirm.
(Enter the first or last na-
me and a phone number
(p. 27).
^
Make further entries
field by field.
Open menu.
Save Store entry.
Last name: Fax:
First name: Street:
Company: Post code:
E-mail: City:/Country:
Phone: State:
Tel./office: URL:/SMS:
Tel./mobile: Group:
Addressbook /
- - - - - - - - - - - - - - - - - - -
<New entry>
Businesscard
# " Select
Abc Addressbook
Last name:
|
First name:
!
URL:/SMS:
In TDMA mode, you can store the SMS ad-
dress of this specific person at another ser-
vice provider here.
Group:
You should only assign important entries to
this group (VIPs).
You may display VIP entries at the top of
the Addressbook (p. 28).
You can set your phone so that the ringer
sounds only for calls from numbers in the
VIP group (p. 73).
A call from a VIP entry can be announced
by a special melody (p. 74).
Addressbook <-> Phonebook (SIM card)
The entries in the Addressbook are man-
aged separately from those in the Phone-
book on the SIM card. You can, however,
exchange data between the Addressbook
and the Phonebook.
For details see Copy to SIM (p. 28) or Co-
py into
(p. 30).
Copy data from another Ad-
dressbook entry.
27
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Addressbook
Phone number
Always enter the number with prefix, if nec-
essary with the international dialing code
(p. 20).
Text input
Press digit key repeatedly until the required
letter is displayed. The relevant characters
are shown in the display. The cursor ad-
vances after short delay.
Press once for a, twice for b
etc. The first letter in each
name is automatically written
in UPPERCASE.
1 -9 Numbers are displayed after
the relevant letter.
$Press briefly to delete the let-
ter before the cursor, hold
down to erase the whole
name.
_
Control cursor.
Switch between UPPER-
CASE lowercase and digits.
Activate/deactivate T9.
Write: . ,? ! 0 +-:
Create a blank.
Special characters
&, @,... Special characters, (p. 39).
Read/change an entry
You can access all entries via the ad-
dress list.
Open the Addressbook
(in standby mode).
_
Select the required entry.
Open menu.
View Press to display the en-
try.
The entry is opened for
changes.
(Make the required
changes.
Save the setting.
Right soft key
When you jump to a phone number
while you are reading, you can start
voice dialing using the right soft key:
Phone, fax number: (p. 33)
Addressbook
Last name:
Einstein
First name:
Edit
28
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Addressbook
Call an entry
Open the Addressbook
(in standby mode).
(/
_
Select a name by enter-
ing the first letter and/or
scroll to the name.
Press. The highlighted
number is dialed.
If several numbers are stored in this
entry, they are displayed in a list.
_
Select the required
phone number.
Press.
Search for an entry
You can search efficiently through
large Addressbooks. When the Ad-
dressbook is open, simply type the
first letter of the name required.
The first entry that begins with this
letter is displayed.
The search letters appear in the up-
per right-hand corner on the display
next to the magnifying glass icon.
Addressbook /
<New entry>
Carol
Daniel
# " Options
Addressbook-Menu
The following functions are available
depending on the current situation:
Open menu.
Save Store entry in the Address-
book.
View (p. 27)
Group sort-
ing Show the Addressbook as
an alphabetical list or with
the entries of the VIP group
(p. 26) at the top.
Edit Display the entry for chang-
es.
New entry (p. 26)
Delete Delete entry.
Delete all Delete all entries after con-
firming command.
Copy to SIM Highlighted entries are cop-
ied with name and the first
phone number to the SIM
card.
Phonebook Switch to the Phonebook
(p. 30) to be used as stan-
dard.
Send via ... (see p. 89)
Print via IrDA (see p. 89)
Voicedialling Start the recording for voice
dialing
Capacity Display the capacity used
and available.
29
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Addressbook
Store control code
You can store phone numbers and
control codes (DTMF tones) in the
address book as standard Address-
book entries, e.g. for operating an
answering machine control remote-
ly.
(Enter phone number.
Press until a "+" symbol
appears on the display
(pause for connection
setup).
(Enter DTMF signals (dig-
its).
If necessary enter other
pauses of 3 seconds to
ensure correct process-
ing at the destination.
Press to copy to the Ad-
dressbook and if re-
quired assign a name to
it.
Press.
You can also store the DTMF signals
(digits) just like a phone number and
send them during a call (p. 24).
Extending numbers
Using an external PC program such as Out-
look® , parts of a phone number can be re-
placed by a "? " and then transferred to the
Addressbook (for PABXs for example).
To call:
Open the Addressbook and select
(part of) the phone number.
Press.
(Replace "? " with digits.
Dial phone number.
Synchronizing with Outlook®
With the Siemens Quick Sync software
(p. 86) you can synchronize your Address-
book with your Outlook® database.
30
6.11.01 S46 US DRAFT A31008-H5450-A5-*
SIM Phonebook
The entries in the Phonebook (SIM
card only) are managed separately
from the Addressbook. You can,
however, exchange data between
the Phonebook and the Address-
book.
New entry
Office Phonebook
<New entry> select.
^
Select input fields.
(Make the following en-
tries:
Phone number (with pre-
fix)
Name
Location (p. 31)
Record no. (p. 31)
Open menu.
Save Store entry.
The phone number can
be dialed immediately
or
end input.
If entries are copied from the Phonebook to
the Addressbook, other data (p. 27) can be
subsequently added to them.
Phonebook /
<Eigene>
<New entry>
Carol
# " Select
Phonebook-Menu
The following functions are available
depending on the current situation:
Open menu.
Save Store entry in the Phone-
book.
View Display the selected entry.
Edit entry Change first names and/or
name, phone number and
storage location.
New entry Enter first name and/or
name, phone number and
storage location.
Delete Delete the entry selected.
Delete all Delete all entries after confir-
mation.
Voicedialling Use voice dialing to make an
entry (p. 33).
Copy into
Copy the entry selected to
the Addressbook.
Copy all
to
Copy all Phonebook entries
to the Addressbook.
Address-
book Switch to the Addressbook
(p. 26) to be used as stan-
dard.
Send/print (see p. 89)
Capacity Display the capacity used
and available.
31
6.11.01 S46 US DRAFT A31008-H5450-A5-*
SIM Phonebook
Location
When the Phonebook is open:
_
Select an entry.
Open menu and
select Edit entry.
^
Go to the input field Loca-
tion.
An entry can be moved from the
Phonebook to other storage loca-
tions:
SIM (Standard)
e
Numbers that are stored in the
Phonebook on the SIM card can also
be used on another GSM phone.
Protected SIM
\
With a special SIM card, phone
numbers can be stored in protected
locations. PIN 2 is required for edit-
ing (p. 78).
Mobile (phone memory)
.
Phonebook entries are stored here,
if
•voice recognition is assigned to
them,
•the memory of the SIM card is
full.
8
Record no.
A reference number that is automat-
ically assigned for a new entry is as-
signed to each phone number in the
Phonebook. You can also dial with
this number.
Call
)Enter phone number.
Press.
Press.
Edit
When the Phonebook is open:
_
Select an entry.
Open menu and
select Edit entry.
^
Go to the input field
"Record".
Press repeatedly,
or press
!to scroll through the
available record num-
bers. When the required
number is displayed:
Open menu.
Save Store entry.
32
6.11.01 S46 US DRAFT A31008-H5450-A5-*
SIM Phonebook
Store control code
You can store phone numbers and
control codes (DTMF tones) in the
Phonebook like a normal entry e.g.
for operating an answering machine
by remote control.
(Enter phone number.
Press until a "+" symbol
appears on the display
(pause for connection
setup).
(Enter DTMF signals (dig-
its).
If necessary enter other
pauses of 3 seconds to
ensure correct process-
ing at the destination.
Press to copy to the
Phonebook and if re-
quired assign a name to
it.
Press.
You can also store the DTMF signals
(digits) like a phone number and
send them during a call (p. 24).
Service numbers
Numbers that have been provided by your
service provider may be stored. With these
numbers you can call local or nationwide in-
formation services or use the services of
your service provider.
Protected phone numbers
Please note that the use of your Phonebook
may be restricted (usual for some business
applications), e.g. incomplete phone num-
bers may be indicated by a "? ". These can
be completed before dialing.
33
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Voice control
Up to 20 phone numbers or func-
tions can be selected or started by
simply saying a name. Voice dialing
entries are stored in the phone.
Record
Voicedialling for phone numbers
Office
Voice control
Voicedialling
A list with entries is displayed. In the
list select...
New record then
(enter name and phone
number
or
retrieve from
the Addressbook.
Confirm.
Start the recording.
A short signal sounds. Now say the
name and repeat it when prompted.
A beep confirms the recording and
all entries are displayed.
Voice command for
functions
Office
Voice control
Voice command
A list with 20 functions is displayed.
_
Select a function.
Press.
Confirm the function se-
lected.
Start the recording.
A short signal sounds. Now say the
command corresponding to the
function and repeat it when prompt-
ed.
Apply
Use the lo-
wer side key on the
left to start voice
control (in standby
mode).
Now say the name
or the function. The
number is dialed or
the function is car-
ried out.
34
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Voice control
Voice control menu
Office
Voice control
Voicedialling
or
Voice command
_
Highlight required entry.
Open menu.
View Display name and phone
number.
New record
or
New sample
Start a new recording.
or
Redo the (voice) recording of
an entry.
Delete Delete entry.
Edit Change name and phone
number (voice dialing only).
Then redo recording if neces-
sary.
Delete all Delete all entries after confir-
mation.
Play Play back the recording
belonging to the entry.
35
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Message (SMS)
You may transmit and receive mes-
sages with your phone (up to 160
characters in length).
Depending on your service provider,
e-mails and faxes can also be trans-
mitted via SMS (change settings if
necessary, page 41) and e-mails can
also be received as SMS messages.
Read Messages
9
D
Display indicates a new
message.
Press the key underneath the letter
symbol to read the message.
Scroll through the message (de-
pending on length of the text):
_
Line by line using the left
soft key.
$% Page by page using the
side keys.
+R
(service provider)
03/12/2002 11:45p
9Menu
03/12/2002 05:36p
Do we meet
8.00a in the hotel?
#" Options
Date/time
Phone num-
ber/sender
Message
The archive function is
displayed at the end of a
message. This moves
the message to the ar-
chive (p. 36).
Reply menu
Inbox/outbox menu.
Reply Open the reply menu.
When the message has been edited
in the editor, it can be stored or sent
with .
Write mes-
sage Create a new reply text
(p. 37).
Edit Edit message received or
assign a new text to it.
Answer is
YES Add YES to the message.
Answer is NO Add NO to the message.
I'll be late
Please call
back
Thank you
Add a standard text to the
message.
dThe memory is full when the message
symbol flashes. No more SMS messages
can be received. Delete or save messages
(p. 36).
Numbers in the message can
be dialed (Call key), stored in the Address-
book (p. 26) or used as the address for a
reply.
36
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Message (SMS)
Inbox/Outbox
Messages
Inbox/Outbox SMS
The list of the saved messages is
shown.
See right.
Archive
Messages
Inbox/Outbox
Inbox-Archive/
Outbox-Archive
The list of the messages recorded
on the device is shown.
Archive-Menu
Depending on the situation, diffe-
rent functions are available:
See right.
Symbol Inbox Outbox
:Read Not sent
Unread Sent
; Inbox
: Barbara
Carol
# " Options
Inbox/outbox/archive-Menu
Depending on the situation, diffe-
rent functions are available
Open menu.
Reply Open reply menu.
View Display entry.
Edit Open editor for changes.
Kopiere in
Archiv The archive function is dis-
played at the end of a mes-
sage. This moves the mes-
sage to the archive.
Delete Delete the message select-
ed.
Delete all Delete all entries after confir-
mation.
Send Dial number or select from
Addressbook, then send.
Save no. to
Copy the phone number se-
lected to the Address-
book.
Mark as un-
read Mark the message as un-
read.
Print via Ir-
DA (see p. 89)
Capacity Display number of saved
messages and the capacity
available.
Status report
8(Outbox list only)
Request delivery confirmati-
on for messages sent.
y
37
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Message (SMS)
Use SMS sample
The following standard messages
are stored in the phone. You only
need to add the time and date.
Messages
Use SMS sample
Selection:
Delay, Appointment, Congratulations
The cursor appears at the first input
point, e.g.:
(Complete the message.
aJump to the next input
point.
Open the text menu.
Send Select.
Dial number or pick out from the Ad-
dressbook and transmit.
T9 123 SMS 118
I will arrive
about |- - minutes late
on:--
! $ OK
Compose message
Messages New SMS
(Text input using "T9"
(p. 39) allows you to
quickly create long SMS
messages using just a
few key entries.
$ Press to delete letter
for letter.
Either
Press.
/
(Dial phone number or
pick out from the Ad-
dressbook.
Confirm.
Select. The message is
sent to the service cen-
ter for transmission.
The text can be
saved after transmission.
or
Open the text menu.
Send via ... select (p. 89).
Meldungstyp, Gültigkeit or Service-Zen-
trum may be requested (p. 41).
38
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Message (SMS)
Text Menu
Open the text menu.
Send Dial the number of the ad-
dress or select from the Ad-
dressbook, then send.
Save Save the composed mes-
sage in the outbox list.
T9 input
(p. 39) T9 preferred
Activate intelligent text entry
or deactivate it.
T9 language
Select language in which the
message is to be composed.
Insert new
line Enter a line break.
Delete text Delete the whole text.
Send via ... (see p. 89)
Print via Ir-
DA (see p. 89)
Information on SMS
Transmission of an SMS is confirmed with
Message sent.
The Message sent text only indicates that
the message has been transmitted to the
service center. The latter now tries to deliver
the message within a certain period.
If the phone was unable to send the mes-
sage, a retry option is available. If this
attempt also fails, contact your service
provider.
Open the Addressbook, high-
light the required entry and
copy it into the text.
39
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Message (SMS)
Text input with "T9"
"T9" deduces the correct word from
the individual key entries by making
comparisons with an extensive dic-
tionary.
Select T9 language
Select the language in which you
want to compose your message.
Open the text menu then
select T9 input and T9 lan-
guage.
Create a word using T9
Since the display changes as you
proceed
it is best if you finish a word without
looking at the display.
You simply press the keys where the
relevant letters are located once only.
For "hotel," for example, type:
:
T9 converts language specific spe-
cial characters (such as ä, à) for you.
Simply compose the message using
the respective standard character,
e.g. A instead of Ä.
If the word that T9 has chosen is not
the one you want see "T9 word sug-
gestions," page 40.
Press once for UPPER-
CASE/lowercase,
Press twice for
letters/digits.
Activate, deactivate T9 (SMS)
Open the text menu,
select T9 input, then
select T9 preferred and
confirm with .
Press before the word for UP-
PERCASE/lowercase or let-
ters/digits.
Blank. Ends a word.
Period. Ends a word when a
blank follows. Acts as a wild-
card character for an apostro-
phe/hyphen in the word:
e.g. = Provider’s.
^
Go to the right. Ends a word.
Deactivate T9 temporarily and
activate it again.
Special characters
Press the key repeatedly until the letter is
displayed. To write special characters after
numbers (e.g. 5 £), switch to the letter mode
first:
Blan
k1€£$¥¤
.,?!0+-:¿
¡“’;_
* / ( ) < = > % ~
#@\&§Γ ∆ Θ Λ
ΞΠΣΦΨΩ
Display in the uppermost line:
T9T9 active.
abc/Abc/123 Uppercase/lowercase,
letters/digits.
40
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Message (SMS)
T9 word suggestions
If several options are found in the
dictionary for a key sequence (a
word), the most frequent one is dis-
played first. If the word you want has
not been recognized, the next sug-
gestion from T9 may be correct.
The word must be . Then
press. The displayed
word is replaced with a
different word. If this
word is also incorrect,
press again. Repeat until
the correct word is dis-
played.
If the word you want is not in the dic-
tionary, it may be written without T9
or added to the dictionary.
Select.
The last suggestion is deleted and
the word may now be entered with-
out T9 support.
Open menu.
Save The word is automatical-
ly added to the dictio-
nary.
T9 abc SMS 140
At 08a we are
Spell
Correct a word
Words that have been created using
T9:
_
Move word by word to
the left/right until the re-
quired word is highlight-
ed.
Scroll through the
T9 word suggestions
again.
$ Deletes the letter to the
left of the cursor and dis-
plays a new possible
word!
Words that have not been created
using T9:
_
Move character by char-
acter to the left/right.
$ Deletes the letter to the
left of the cursor.
(Symbols are inserted at
the cursor position.
Replace existing languages:
http://www.my-siemens.com/s46
Within a "T9 word," individual letters may
not be edited without canceling T9 first. In
most cases it is better to rewrite the com-
plete word.
T9®Text Input is licensed under one or more of the
following: U.S. Pat. Nos.5,818,437, 5,953,541,
5,187,480, 5,945,928, and 6,011,554; Canadian
Pat. No. 1,331,057; United Kingdom Pat. No.
2238414B; Hong Kong Standard Pat. No.
HK0940329; Republic of Singapore Pat. No.
51383; Euro.Pat. No. 0 842 463 (96927260.8) DE/
DK, FI, FR, IT, NL, PT,ES, SE, GB; and additional
patents are pending worldwide.
41
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Message (SMS)
Setup
The transmission characteristics of
an SMS are defined in a profile (up
to 5).
Two profiles for GSM and TDMA
mode are preset.
Messages
Setup SMS
The list of available profiles is dis-
played. You may now select one of
these. To activate it:
Press.
Setup menu
Open menu.
Service centre
Enter or change the phone numbers
of the service centers as supplied by
the service provider.
Recipient
Enter the standard recipient for this
transmission profile.
Message type
Activate Use the profile selected.
Change set-
tings Change profile.
Rename Rename the profile.
Manual se-
lection The message type is requested
for each message.
Standard
text Normal SMS message.
E-mail Transmission via SMS.
Fax Transmission via SMS.
y
8
Validity period
Select the period in which the ser-
vice center tries to deliver the mes-
sage:
Manual selection, 1 day, 1 hour, 12 hours,
1 week, Maximum*, New
*Maximum period that the service provider
permits.
Status report
You receive confirmation of the suc-
cessful or unsuccessful delivery of a
sent message. This service may be
subject to a charge.
Direct reply
The reply to your message is han-
dled via your service center when
this function is activated (for infor-
mation please contact your service
provider).
SMS via GPRS
Messages
Setup
SMS via GPRS
When this function is activated,
SMS messages are automatically
sent via GPRS.
Requirement: GPRS must have
been activated, see page 83.
New You may need to obtain the re-
quired code number from your
service provider..
y
y 8
y 8
y 8
42
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Bitmap viewer
A graphic can be sent to your phone
via infrared or SMS or it can be
downloaded via WAP (GSM).
Receive graphic
A received graphic is indicated by a
symbol above the left soft key. By
pressing this key, the Bitmap viewer
is started and the graphic is dis-
played.
Store graphic
The graphic replaces the icon of your
home network's service provider.
Load graphic
Surf & fun Bitmap viewer
Bitmap viewer Open.
The menu is
opened.
Load bitmap Select.
Bitmap viewer-Menu
Open menu.
Save as... Store current graphic in one of
the storage locations or in the
Flex. memory.
Load Load graphic from the storage
location or Flex. Memory.
Discard The current graphic is
discarded.
Delete Delete the graphic.
Send via ... (see p. 89)
Ringertones, operator bitmaps, screen-
savers and other services for your Siemens
Mobile Phone can be found at:
http://www.my-siemens.com/city
43
6.11.01 S46 US DRAFT A31008-H5450-A5-*
WAP y
From the Internet, get the latest
WAP information that is specifically
adapted to the display options of
your phone. Internet access may re-
quire the registration with the ser-
vice provider.
Internet access
Surf & fun Internet
You can select the Internet access
profile (see Start with... page 44).
The start menu appears, e.g.:
_
Select the required func-
tion
Confirm.
You can now surf the Internet...
Hold down to end the
connection.
mOffline
nOnline
ono net-
work
The current display is in the upper right cor-
ner.
Scroll page by page using the
side keys.
kStart menu m
1 Homepage
2 Bookmarks
3 Resume
#" _
Start menu
Example: Home
The soft keys may be assigned func-
tions that are controlled online from
the homepage of your service pro-
vider such as "links" or "menus".
The contents of the option menus
are also variable.
Homepage The connection to the Inter-
net provider's portal is estab-
lished (may be set/preset by
the service provider).
Bookmarks List of up to 10 URLs for fast
access stored in the phone
(not supported by all service
providers).
Select New entry to enter a
new URL.
Use to complete, edit
and delete entries.
Resume Call up the visited pages that
are still in the memory.
Profiles Set up to 5 access
profiles (p. 45).
Select New entry to enter a
new profile
Exit browser End browser and connec-
tion.
8
News
Weather
Back
# " Link
44
6.11.01 S46 US DRAFT A31008-H5450-A5-*
WAP y
Browser menu
Menu access is only made when a
WAP page is displayed (online or of-
fline):
Press to start the
browser menu.
Startseite The first WAP Internet page
that is displayed after con-
nection is established (may
have been set/preset by the
service provider).
Bookmarks Display up to 10 URLs for
fast access stored in your
phone (not supported by all
service providers).
Select New entry to enter a
new URL.
Use to complete, edit
and delete entries.
Resume Call up the visited pages that
are still in the memory.
Go to URL Enter an URL for directly ac-
cessing an Internet address
(URL = Uniform Resource
Locator).
Show URL Show the URL of the current
page.
Reload The current page is restart-
ed.
Disconnect End connection.
More ... See below.
Exit browser End browser and connec-
tion.
8
More ...
Profile Set up to 5 access
profiles (p. 45).
Reset Delete the pages last visited
(cache).
Channels Access to services offered
by your service provider.
Incoming Incoming messages, for ex-
ample, are stored here (de-
pending on provider).
Outbox For example, e-mails are
stored here to be sent later
(depends on the service pro-
vider).
Charge info Display call duration and
transmission speed.
Security For secure data transmis-
sion some information is en-
crypted. All browser data rel-
evant for security can be
selected in this menu.
Further information on secu-
rity is found at:
http://www.
my-siemens.com/s46
Font size Switch between small and
standard font size.
Start with... Select the display for Inter-
net access:
Start menu
Browser-Menü
Startseite
Letzte Seite
Favourites
About Open-
wave Display the browser version.
45
6.11.01 S46 US DRAFT A31008-H5450-A5-*
WAP y
Setup
Preparation of the phone for Internet
access depends on the service pro-
vider currently used:
•If the settings have already been
made by your service provider you
may begin immediately.
•If access profiles have been as-
signed by your service provider
select a profile and activate
it (p. 45).
•The access profile must be set
and activated manually (p. 45).
If necessary, check with your service
provider for details.
Profiles
You can set and change up to 5 ac-
cess profiles (may be barred by the
service provider). The entries and
functions may vary depending on
your service provider. You can
change a profile each time before
you access the Internet (p. 46).
Profile settings
Surf & fun
Internet Profile
^
Select the profile to be
set.
Open menu.
Edit The setup menu is dis-
played.
^
Select the menu items
one by one and make
your entries.
You may get further information on
the entries from your service provid-
er.
Open menu.
Save The settings are stored
and the profile list is
shown.
Profile
name: Name the profile or rename a
default name.
WAP param-
eters IP address:
Enter the IP address.
Port:
Enter port number.
Homepage:
Enter homepage (p. 45), if
not set by the service provi-
der.
Linger time:
Enter time in seconds when
a connection should be ter-
minated if no input or no data
transfer takes place.
CSD and
GPRS data see page 83.
Special characters (as in the SMS text
editor)
Press 3 x for/
Press 3 x for @
Press for . (full stop)
Press repeatedly for :
Press repeatedly for ~
46
6.11.01 S46 US DRAFT A31008-H5450-A5-*
WAP y
Activate profile
Activate
Activate a profile to establish the In-
ternet connection.
Surf & fun
Internet Profile
_
Select the required pro-
file.
Open menu.
Activate Press to activate. The
connection is estab-
lished.
or
Edit Edit the profile selected.
When the function is ended, Startsei-
te, Bookmarks or Letzte Seite are avail-
able to establish the connection.
sProfiles
1 standard
2
3 profile 3
# " Options
Surf also with GPRS (p. 83).
Your Internet browser is licensed by:
47
6.11.01 S46 US DRAFT A31008-H5450-A5-*
WAP y
Operating instructions
Changing the home page
The address of the home page is set
in the (access) profile. You can
change it in standby mode (if permit-
ted by the service provider!):
Surf & fun
Internet Profile
Select the profile, e.g.:
e-Commerce Select.
Open menu.
Edit Press.
WAP parameters Select.
Press.
Startseite Select.
)Enter new address.
Open menu.
Save Press.
Enter the Internet address (URL)
Menu access is made as soon as
WAP pages are displayed (online or
offline).
Open the browser
menu.
Go to URL Select and confirm.
(Enter URL and confirm.
The connection is es-
tablished.
Bookmarks
Depending on the service provider,
you can store a list of your favorites
with their Internet addresses (URL)
in the phone (offline and online):
Store
Open the browser
menu.
Bookmarks Select.
<New entry> Select and confirm.
(Enter the favorite and
its URL and confirm.
Open menu.
Save Store bookmark.
To use a favorite
Proceed as with "Store": in the list,
select the stored bookmark and con-
firm. The connection is established.
8
48
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Voice message/Mailbox
Most service providers offer you an
external answering service. In this
mailbox, a caller may leave a voice
message, if
•your phone is switched off or not
ready to retrieve,
•you do not want to answer,
•you are making a phone call (and
when Call waiting is not
active, page 22).
If the voice mail service is not part of
your service provider's user pack-
age, you will need to register and
the settings must be made manual-
ly. The procedure described below
may vary slightly depending on the
service provider.
Setup
Your service provider supplies you
with two phone numbers:
Mailbox number
You call this phone number to listen
to the voice mails left for you. To set
it up:
Messages
Voice message
Select a phone number from the Ad-
dressbook or dial/change it and con-
firm with .
Forwarding number
Calls are diverted to this phone num-
ber. To set it up:
Divert e.g.
Unanswered Set
Dial the number of the mailbox.
Registration at the net-
work. Confirmation is
made after a few sec-
onds.
Further information on call divert is
found on page 53.
Listen to
A new voice mail can be displayed
as follows:
iIcon including beep.
or
9a text message an-
nounces a new voice
mail
or
you receive a call with an
automatic announce-
ment.
Call your mailbox and play the mes-
sage(s) back.
Hold down (if necessary dial
the mailbox number of the ser-
vice center).
Outside your home network, a different
mailbox number may need to be dialed and
a password may need to be entered to ac-
cess your mailbox.
49
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Cell broadcast
y
8
Cell broadcast
Some service providers offer infor-
mation services (info channels) such
as area codes, stock markets etc.
The information available depends
on the service provider. If reception
is activated, you receive messages
on the active topics in your "Topic
list".
Messages Cell broad-
cast
Broadcast
You can activate and deactivate the
CB service. If the CB service is acti-
vated, the operating time of the
phone will be reduced.
Read new CB
All unread CB messages are dis-
played.
Use the side keys to
scroll.
The message covers the
whole display.
Topic list
You can add an unrestricted number
of topics to this personal list from
the topic index ("Topic retrieval",
page 50). You can preset at least
10 entries with their channel num-
ber (ID) and, if necessary, with their
name. Five topics can be active at
one time.
New topic
New topic Select.
•If no topic index is available (see
"Topic retrieval", page 50), enter a
topic with its channel number and
confirm with .
•If the topic index has already been
transmitted, select a topic and
confirm with .
Selection from a list
Open list menu.
If a topic is selected in the list, you
can look at it, activate it, deactivate
it, edit it or delete it.
Auto display
CB messages are displayed in
standby mode, longer messages are
automatically scrolled.
The automatic display can be set for
all messages or only new messages
or be deactivated entirely.
Switches to "full page view" auto-
matically:
then press .
50
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Cell broadcast/SIM services
y 8
Topic index
The list of the topics currently pro-
vided by your service provider is dis-
played for you to choose from.
If none are displayed, the channel
numbers (ID) may be entered manu-
ally ("Topic list", page 49). Please
contact your service provider for de-
tails.
CB languages
You may define whether you want to
receive Cell Broadcast messages
only in a specific language or in all
languages.
Displays
{Topic activated.
|Topic deactivated.
9New messages received on
the topic.
:Messages on the topic already
read.
Highlighted phone numbers can be:
dialed.
stored in the Addressbook.
Additional beep, page 73.
SIM services
Your service provider can offer spe-
cial applications such as homebank-
ing, stock market etc. via the SIM
card.
If you are registered for one of these
services, the service name will ap-
pear at the top of the main menu or
directly above the left soft key.
hIcon of SIM
services (example).
If there is more than one application,
these are displayed in the "SIM ser-
vices" menu.
SIM serv
With the SIM services menu, your
phone is future-proof and will sup-
port additions to your service provid-
er's user package. For further infor-
mation, contact your service
provider.
y
8
51
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Records
Your phone stores the phone num-
bers of calls for convenient redialing.
Records
_
Select required call list
and select the number
there.
Dial number.
The following call lists are available:
Missed calls
The phone numbers of calls that you
have received but not answered can
be recorded for call-back purposes.
Requirement:
The networks used support the
"Caller Identity" feature.
Calls received
All accepted calls are listed.
Requirement:
The networks used support the
"Caller Identity" feature.
8
8
Calls dialled
Access the last phone numbers you
dialed.
Fast access in standby
mode.
Erase records
The contents of all call lists are delet-
ed.
Records-Menu
Open list menu.
View Show entry with call time and
date.
Correct no. Change phone number.
Copy into
Copy selected entry to the
Addressbook.
Delete all Delete all entries of the cur-
rent call list after confirma-
tion.
52
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Time/charge
You can display the charge details
and the duration of calls as you
speak as well as setting a unit limit
for outgoing calls.
Display
Records Time/charge
After you have made the charge de-
tail settings, you can display the call
duration/charge details for the fol-
lowing call types or you can display
the credit balance.
Last call
All calls
Remain. units
or
when total amount is deactivated:
Last call
All outgoing
Incoming calls
Remain. units
Select a call type.
Display the data.
When displayed, you may do the fol-
lowing:
Clear display.
End display.
Charge settings
Records
Charge settings
Currency
Enter the currency in which the
charge details are to be shown.
y
y
Charge/unit
(PIN 2 needed)
Enter the charges per unit/period.
Account limit
(PIN 2 needed)
Special SIM cards allow you or the
service provider to define a credit/
period after which the phone is
blocked for outgoing calls.
Open menu.
Edit Enter the number of
units and confirm with
.
The credit can be confirmed or the
counter can be reset. The display of
Prepaid cards may vary depending
on service provider.
All calls
Toggle between the displays.
Incoming calls
If your network supports the
charge detail display, the current
units are displayed.
If you have set charge details per
unit, the costs incurred are dis-
played.
Special registration may be neces-
sary for this service.
Auto display
Call duration/charges are automati-
cally displayed for each call.
8
8
8
8
53
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Divert
You can set the conditions for which
calls are forwarded to your mailbox
or other numbers.
Divert
You can set divert as follows:
In GSM mode, you can choose from
several conditions for forwarding, in
TDMA mode, there is only one condi-
tion available.
A condition for divert is e.g.: Unans-
wered
Divert
_
Unanswered
Select.
Press.
Set Select.
(Enter the phone number
to which the caller will be
diverted (if not done al-
ready)
or
3Select this number from
the Addressbook or via
.
Confirmation. After a
short pause, the setting
is confirmed by the net-
work.
Unanswered
This setting covers the most important con-
ditions (see also below):
Not reachable, No reply, Busy
All calls
All calls are diverted.
N Symbol in the top line of
the display in standby
mode.
Specific divert
Not reachable
Divert if the phone is switched off or
out of range.
No reply
A call is only diverted after a delay
(depends on the network). The peri-
od can be set by the user to a maxi-
mum of 30 seconds in intervals of
5 seconds.
Busy
Divert if a call is in progress.
Receiving fax
Fax calls are diverted to a number
with a fax connection.
Receiving data
Data calls are diverted to a phone
number with a PC connection.
Exception: If Call waiting is activated
(p. 82), you will hear the call waiting tone
during a call (p. 22).
y
y
54
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Divert
Status check
You can check the current divert sta-
tus for all conditions.
After a short pause, the current situ-
ation is transmitted by the network
and displayed.
{Condition set.
|Not set.
?Display, if status is unknown
(on a new SIM card for exam-
ple).
Clear all
All set diverts are cleared.
To check or delete a certain condition:
First select the condition.
Press.
Check status
or
Delete select.
y
y
Note that the divert is stored in the network
and not in the phone (when the SIM card is
changed for example).
Reactivate divert
The last divert has been stored. Proceed as
with Set Divert. The stored phone number
is displayed and is confirmed.
Change the phone number
Proceed as with Set Divert. When the
stored number is displayed:
Delete the phone number.
Enter new number and confirm.
55
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Dictaphone
With voice recording you can
•use your phone as a Dictaphone
when on the move.
•record a memo as a reminder or
as a reminder for others.
•add a voice memo to an alarm in
the Calendar (p. 58).
•record a call: this is useful for re-
membering numbers or address-
es.
The use of this feature may be subject to re-
strictions under criminal law or other legal
provisions.
Please inform the other party to the conver-
sation in advance if you intend to record the
call and keep such recordings confidential.
You may only use this feature if the other
party to the conversation agrees.
E Dictaphone
03/12/2002 05:30p
Customer query
Shopping
# " Options
Using the side keys
We recommend using the keys on
the side of the phone to control the
voice functions.
New record
Hold down the dictation key for the
duration of the recording. After a
short beep, the recording starts.
For a recording pause, you can release
the dictation key for a maximum of
10 seconds. If you press the key
once more, recording is resumed,
otherwise it is stopped.
Exit browser/Save
The record is stored if you release
the dictation key for more than
10 seconds. It is stored with the cur-
rent time and date as its name. A dif-
ferent name can be assigned to it af-
terwards.
Play
Press the dictation key briefly.
Loud
Quiet
Recording/
play back
(dictation
key)
56
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Dictaphone
Using the soft keys
Office Dictaphone
The list of the recordings is opened.
Open menu.
New record Select.
Start recording
( recording pause).
End recording.
Store and assign a name.
Play
Press.
Dictaphone-Menu
Open menu.
Playing The recording is played.
New record Start a new recording.
Delete Delete the entry selected.
Delete all Delete all entries after confir-
mation.
Rename Replace the time stamp with
a name.
57
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Organiser
Calendar
Office Organiser
Calendar
The Calendar offers a
•monthly view,
•weekly view,
•daily view.
Time and date must be set for the
Calendar to work properly (p. 84).
Side keys
Scroll between
the weeks or
months depen-
ding on the cur-
rent view.
Monthly view
_
Scroll between the
weeks.
Display the weekly view.
%Display the daily view
(agenda).
Back
Forw.
Th Apr 2002 W 16
1234567
8 9 10 11 12 13 14
15 16 17 18 19 20 21
22 23 24 25 26 27 28
29 30
! %
Weekly view
_
Scroll by the hour.
Display of the monthly
view.
%Daily view (agenda).
Agenda
%Press.
The agenda displays the appoint-
ments of the current day in chrono-
logical order.
Tasks that are still open are listed at
the top (p. 59).
When an appointment with alarm is
reached, you will hear a beep.
Schedule. Time overlaps are
highlighted.
Each day is divided into six blocks of
four hours (morning +afternoon).
Synchronizing with Outlook®
With the Siemens Quick Sync software, you
can synchronize your organizer with your
Outlook® Calendar (p. 86).
Th Apr 2002 W 16
MTWTFSS
15 16 17 18 19 20 21
! ?%
8
12
16
58
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Organiser
Appointments
Office Organiser
Appointments
All appointments/tasks of the day
are displayed in chronological order.
New appointment
<New entry> Select.
_
Make the entries field by
field:
Category: Appointments or select Ta-
sks.
Type:
gMemo. A short text may
be added.
=
Call. Enter phone num-
ber. Shown with alarm.
IMeeting
HBirthday
ESpeech memo
Description:
Display in the agenda.
Alarm:
Activate, deactivate.
~ Appointments
<New entry>
411:30 a Presentationg
4 03:00 p Meeting I
# " Options
Date:/End date:
Start date, end date if necessary.
Reoccurrence:
Select periods for repeating the ap-
pointment.
Start time:/End time:
Start time, end time if necessary.
Store the appointment.
Appointments menu
Open menu.
View Show appointment.
Activate/De-
activate Activate/deactivate appoint-
ment.
Edit Open the entry for changes.
New entry See left.
Delete Delete entry selected.
Delete all Delete all entries after confir-
mation.
Edit Open the entry for changes.
Send via ... (see p. 89)
Print via Ir-
DA (see p. 89)
Week beg.
Mo Set when the week is to start,
Monday or Sunday.
Capacity Display the capacity used
and available.
59
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Organiser
Tasks
Office Organiser
Tasks
A task is displayed like an appoint-
ment in the agenda of the day se-
lected. However unlike the appoint-
ment it does not need to have a time
and date. When this is the case, the
task appears at the top of the list
every day, until it is marked done.
New task
<New entry> Select.
Category: Select Tasks or Appoint-
ments.
_
Select task type (see Ap-
pointments, page 58)
A total of 50 appointments can be entered.
An alarm sounds even when the phone is
switched off. To deactivate it, press any key.
Deactivate all alarms (p. 68). Ringer set-
ting (p. 73), Clock (p. 84).
4Display when alarm is active.
Delays the alarm by 5 minutes.
}Tasks
<New entry>
4Car to inspection
=
405:00p Meeting I
# " Options
)Describe the task briefly.
)If necessary, enter date
and time.
Store the task.
{Display when a
{task is done.
Task menu
Open menu.
View Display entry.
Done Mark task as done.
Edit Display the entry for changes.
New entry Enter a new task.
Delete Delete an entry from the ap-
pointments list.
Delete all Delete all entries after confir-
mation.
Send via ... (see p. 89)
Print via Ir-
DA (see p. 89)
Week beg.
Mo Week starts on Monday.
Capacity Display the capacity used and
available.
60
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Organiser
Alarm clock
Office Organiser
Alarm clock
Use this function to set a single time
for the alarm call. The alarm sounds
even when the phone is switched
off.
Switching on and switch-
ing off the alarm.
Display the selection:
Time and days.
Set the time for the
alarm call (hh:mm:ss).
Set the days for the
alarm call with .
Missed alarms
Office
Organiser
Missed alarms
Appointments with alarm that you
have missed are listed and can be
displayed.
Missed alarms-Menu
Open menu.
You can send an alarm missed, print
it, delete it or delete all alarms
missed.
61
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Organiser
Notes
Office Organiser
Notes
T9 support (p. 39) makes writing
memos, e.g. shopping lists, easier
for you. Protect confidential data
with the phone code (p. 78).
New entry
<New entry> Select.
)Enter the text.
Open menu.
Save Store entry.
Editor menu
Open menu.
Save Store entry.
T9 input
(p. 39) T9 preferred
Activate intelligent text entry or
deactivate it.
T9 language:
Select language in which the
message is to be composed.
Line feed Enter a line break.
Delete text Delete a memo text.
Send Transmit via SMS.
Read entry
_
Select an entry.
Open menu.
View Select.
Notes menu
Open menu.
View Display entry.
Edit Display the entry for changes.
New entry Enter a new memo.
Delete Delete an entry from the ap-
pointments list.
Delete all Delete all entries after confir-
mation.
Confiden-
tial Protect entry with phone code
(p. 78).
Send Transmit via SMS.
Capacity Display the capacity used and
available.
r Notes
<New entry>
Shopping list
Office
# " Options
62
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Businesscard
You may create your own business
card and transmit it to another GSM
Phone (with IrDA capability) or a suit-
able PC/printer using infrared tech-
nology.
Office Businesscard
If a business card has not been cre-
ated, you are asked for input.
_
Go from field to field and
make your entries.
The phone numbers
can also be copied from
the Addressbook.
Save entry.
Last name: Tel./mobile:
First name: Fax:
Company: City:/state:
E-mail: Post code:
Phone: Street:
Tel./office: Country:
URL:/SMS:
The content of the business card corre-
sponds to international standards (vCard).
When you are sending a business card as
an SMS, note that a maximum of 160 char-
acters can be transmitted. If the card con-
tains more than 160 characters, the addi-
tional characters will not be transmitted.
Businesscard-Menu
Open menu.
Send via ... (see p. 89)
Print via Ir-
DA (see p. 89)
Edit Rename the profiles for
changes.
63
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Calculator
Office Calculator
)Enter number (up to 8
digits).
Select calculator func-
tion (repeatedly press
the right soft key).
(Repeat procedure with
other numbers if neces-
sary.
The result is displayed
123
4567
$ . =+-*/
nCalculator
+
Calculator functions
press repeatedly for:
.Decimal point.
=Result.
+Addition.
-Subtraction.
*Multiplication.
/Division.
Special functions
Press
or
repeatedly for:
± Toggle between "+" and "-".
%Convert to percentage.
KSave the number displayed.
JRetrieve the number saved.
eExponent (maximum of two digits).
Add (hold down).
64
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Currency conv.
Office Currency conv.
You may store up to three different
currencies.
Enter exchange rate
To convert, enter at least two curren-
cies. When no currency has been
entered yet, the input procedure is
started immediately.
Press.
)Enter the symbols for
your own and for the for-
eign currency.
Confirm.
Then...
)Enter exchange rate.
Confirm.
Soft keys:
Set decimal point.
Retrieve a number that
has been saved in the
calculator.
$Deletes the symbol in
front of the cursor.
Save exchange rate.
exchange rate for
DM
=
$$
Convert
Any combination of calculations may
be made between the entered cur-
rencies.
_
Select a combination of
currencies.
Open menu.
Start Confirm the two curren-
cies.
(Enter amount
(up to 12 digits).
The result is displayed.
Currency conv.-Menu
Open menu.
Enter
amount Start application.
New entry Enter two new currencies.
Edit Open input procedure with
the two currencies selected.
Delete Delete the two currencies.
65
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Clock
Office Clock
Time zones
Set the time zone for your area.
_
Select the required time
zone from the list.
Open menu.
Set Set the time zone.
Time zone menu
Open menu.
Time/date
Setup
Time/date
The clock must be set correctly once
at start-up.
Press.
(First date, then time.
View Display the time zone select-
ed with name and date.
Set Set the time zone.
Rename Assign a new name to the
time zone.
Auto timezo-
ne
8The time zone is switched to
local time automatically by
the network.
Sommerzeit: Activate/deactivate daylight
saving.
Format date
Set the date format with 24h or 12h
clock:
DD.MM.YYYY a/p
Auto display
The time display can be switched on
and off.
Auto phone off
The phone switches off each day at
the set time.
Activate:
Press.
)Enter time.
Confirm.
Deactivate:
Press.
Confirm.
If the battery is removed for more than
about 30 seconds, the clock must be reset.
66
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Stopwatch/Countdown
Stopwatch
Surf & fun Stopwatch
Display the time down to one thou-
sandth of a second. Two intermedi-
ate times can be clocked and stored.
Reset to zero.
Start/stop.
Intermediate time.
Control using the side keys:
CStopwatch
00:00:00.000
Start Options
Intermediate
time
Start/
Stop
Stopwatch-Menu
Open menu.
Countdown
Surf & fun Countdown
A set period elapses. The last 3 sec-
onds are indicated by a beep. At the
end, a special beep sounds.
/
Change period or enter
a new one.
Start counter.
Interrupt counter.
Reset counter to start
time.
Save Record the time(s) taken and
assign a symbol to them.
Rename Rename the entry selected.
Delete Select the entry to be delet-
ed.
List Display the stored entries.
View: Display of the stored
times and intermediate
times.
Delete all Delete the Stopwatch list.
67
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Games
Surf & fun Games
Select a game in the list and have
fun!
Game instructions
You will find special instructions for
each game in the option menu.
Provides tips on how to
play the game, shows
the saved scores and al-
lows you to set the diffi-
culty level.
Start game.
Key control
function depends
on the game
68
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Profiles
If a profile is used, several settings
are made with one function.
•Five profiles are standard with de-
fault settings. However, they can
be changed:
Normal envi., Quiet environ.,
Noisy environ., Headset
•You may set two personal profiles
individually (<No Title>).
•The special profile Ohne Alarm is
fixed and cannot be changed
(p. 69).
If the phone is used by several peo-
ple, they can each activate their own
settings by selecting their personal
profiles.
Activate
Profiles
_
Select default profile,
personal profile.
Open menu
Activate Activate the profile.
uIndicates the active
profile.
s Profiles
tNormal envi.
uQuiet environ.
tNoisy environ.
# " Options
Setup
Edit a default profile or create a new
personal profile:
_
Select profile.
Open menu.
Edit Select. Several functions
are found in the profile
menu.
Profiles-Menu
Open menu.
Activate Activate the profile selected.
Edit The following functions can
each be set individually for a
profile:
•Ringer setting p. 73
•Volume p. 73
•Melodies p. 73
•Silent alert p. 73
•Filter p. 73
•Information tones p. 73
•Key tones p. 73
•Big letters p. 76
•Illumination p. 76
When you have finished set-
ting a function, you return to
the profile menu, where you
can change other settings.
Rename Rename the selected profile.
Copy from Copy settings from another
profile.
69
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Profiles
Headset
If an original Siemens Headset is
used, the profile is activated auto-
matically as soon as the phone is
connected to the headset (see also
p. 85).
Airplane mode
All alarms are deactivated.
It is not possible to modify this profile
•The phone must be switched off
when you select a profile.
•In this status, alarms are not indi-
cated by the ringer or trembler
alarm.
Activate
Profiles
_
Airplane mode select.
Open menu
Activate Activate the profile.
Profile selection must be
confirmed.
Then switch off the
phone, otherwise the
phone switches itself off
automatically after
30 seconds.
Normal operation
The next time you switch on the
phone, the default profile will be ac-
tivated.
70
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Favourites
Favourites
Combine your own menu with fre-
quently-used functions and phone
numbers.
The list of the 10 entries available is
preset. However, you can change it
according to your wishes.
Apply
_
Select the required entry.
Press.
For fast access:
aPress then...
]..press. twice.
or use the speed dialing keys (p. 71).
If the selected entry is a phone
number, you can also call with
the Call key.
Change
You can replace each preset entry (1-
10) with another entry from the list
of your favorites.
_
Select the required entry.
Press.
Press.
_
Select the new entry in
the selection list.
Press.
If you have selected a phone num-
ber as a new entry, the Addressbook
opens for the selection.
Reset
After confirmation and entering the
phone code, the default entries are
reset.
71
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Fast access key
The left soft key and the keys 2 to 9
(speed dialing numbers) can each be
assigned an important phone num-
ber or a function. The phone number
can then be dialed or the function
can be started at the touch of a
button.
Key assignments available:
•Internet (GSM) ..................... p. 43
•Addressbook........................ p. 26
•Phone number ..................... p. 72
•Calendar............................... p. 57
•Alarm clock .......................... p. 62
•Notes ................................. p. 61
•Calculator ............................ p. 63
•Illumination .......................... p. 76
•Hide ID................................. p. 82
•GPRS on/off (GSM)
8...... p. 83
•GPRS info (GSM) ................. p. 83
•IrDA ................................. p. 84
•Games ................................. p. 67
•Missed calls......................... p. 51
•Calls received ...................... p. 51
•Inbox ................................. p. 36
•Outbox................................. p. 36
•Pers.Favourites .................... p. 70
A function may already have been pro-
grammed on this soft key by your service
provider (e.g. access to "
h SIM-Servic-
es"). This key assignment may be unmodifi-
able.
The soft key may sometimes be replaced
with "
9 /
i" to access a new mes-
sage.
Left soft key
The left soft key can be used for fast
access.
Edit
Press (if not preset differ-
ently).
Scroll to the application
in the list.
•Assign the new application (e.g .
Games) to the soft key.
•Special case Phone number. Pick
out a name from the Addressbook
( e.g. "Carol") to assign the soft
key.
Confirm setting.
Apply
The setting "Carol" is used here only
as an example.
Hold down.
+R
(service provider)
01.07.2002 23:45
Set Menu
72
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Fast access key
Speed dialing keys
Digit keys 2 to 9 can be used as
speed dialing numbers for fast ac-
cess. For available key assignment
see page 71.
Edit
In standby mode:
(Press digit key (2-9). If
the key is not assigned:
Press.
or
Press briefly (if assigned
with e.g. "Games").
Scroll to the application
in the list.
Special case Phone number. Scroll to
a name in the Addressbook for as-
signment to the key.
Confirm setting.
Special case Internet (GSM). Scroll to
an URL in the bookmark list for as-
signment to the key.
Confirm setting.
The following key is reserved:
= mailbox number (p. 48)
Apply
Select a stored phone number or
start a stored application
(e.g. Games).
In standby mode:
Press.
The assignment of digit key 2 is dis-
played instead of the left soft key,
e.g.:
hold down
or simply
hold down
Quick menu selection
All menu functions are numbered in-
ternally. The relevant sequence of
numbers is shown in the upper right
corner of the display.
Enter the appropriate sequence of
numbers to select a function direct-
ly.
For example, to compose a new
SMS:
Press.
for Messages
for New SMS
73
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Audio
You can set the tones that sound in
specific situations to suit your partic-
ular taste.
Audio
select a function:
Ringer setting
Activate, deactivate the ringer or re-
duce it to a short beep (beep).
2Beep is activated.
3Ringer is deactivated.
Volume
_
Select the range:
All calls
Calls
VIP calls
Event
Messages
Cell broadcast services
_
Set volume.
Confirm.
Activate, deactivate in standby mode:
Hold down.
Displays rising volume.
y
Silent alert
To avoid being disturbed by the ring-
er, you can activate the vibration
alarm of the phone instead. The vi-
bration alarm can also be active in
addition to the ringer (e.g. in noisy
environments). The vibration alarm
is deactivated when the phone is
connected to the Car Kit.
Filter
Only calls from numbers that are list-
ed in the Addressbook are signaled
audibly or by the vibration alarm.
Other calls are merely displayed.
If you do not accept these calls, they
are diverted to your mailbox (if set,
page 53).
1Displayed when activat-
ed.
Information tones
Activate/deactivate all service tones
and alarm tones or use Extended to
activate/deactivate tones.
Key tones
You can set the type of the key
tone:
Click or Tone or Silent
8
74
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Audio
Audio
select a function:
1 minute beep
During a call, you hear a beep after
every minute as a reminder of the
time elapsed.
Melodies
You can choose from 38 melodies
and additionally use four melodies
that you have composed/stored
yourself.
_
First select the type:
All calls
Calls
VIP calls
Event
Messages
Cell broadcast
_
Then select the melody.
Confirm.
y
Melody manager
You can use this function to manage
your melodies.
Surf & fun
Melody manager
Load
Load melody from Individual 1 to
Individual 4 or from the Explorer.
Melody manager Open.
Open menu.
Load Select and assign
storage location.
Save
Store loaded melody on Individual 1
to Individual 4 or on the Explorer
(*.mid).
The melody can be
played.
Receive melody
A melody can be sent to your phone
via infrared or WAP (GSM).
When a melody has been received,
an icon appears above the left soft
key.
Press this key to start the melody
manager.
Ringertones, operator bitmaps, screen-
savers and other services for your Siemens
Mobile Phone can be found at:
http://www. my-siemens.com/city
75
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Audio
Melody manager-Menu
Open menu.
Play Play the current melody.
Save as... Store melody on Individual 1to
Individual 4 or on the Explorer
(*.mid).
Send via ... (see p. 89)
Load Load melody from Individual 1
to Individual 4 or from the Ex-
plorer.
Discard The current melody is deleted
from the melody manager.
Delete Delete melody from Individual
1 to Individual 4.
Audio
select a function:
Compose melody
You can also compose one-voice
melodies yourself.
(Keys 1 to 7 correspond
to the notes C, D, E, F, G,
A, H.
!Go back and forward in
the melody by one note.
Set note half a tone high-
er/lower.
Increase length of note/
pause length.
Reduce length of note/
pause length.
Use the left side keys to
set a note one octave
higher/lower.
Insert a pause.
The menu offers further
functions:
Play, Playback speed, Save,
Insert note, Delete note, De-
lete, Load.
76
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Device
Setup
Device
Select a function.
Sprache
Set the language of the display text.
When "automatic" is set the lan-
guage of your service provider is
used. If a language that you do not
understand happens to be set, the
phone can be reset to the language
of your service provider with the fol-
lowing input:
*#0000#
Display
Own greeting
You can create a greeting that is dis-
played when you switch on the
phone.
Activate and deactivate.
(Delete old message and
create new message.
Confirm changes.
Screensaver
The screensaver shows a graphic on
the display after a period of time
which the user can set. It protects
the phone against unauthorized use,
like the key lock (p. 77). An incoming
call or a long press on
and con-
firmation with end the function.
You have the following options:
•Activate, deactivate the function.
•Set style: Special graphic, ana-
logue clock.
•Load graphic via Bitmap viewer
(p. 42).
•Test screensaver.
•Set period after which the screen-
saver starts.
•Activate password query as secu-
rity setting.
Illumination
The display illumination can be
switched on and off (this affects the
standby time).
Big letters
You can change the font size of the
display.
Contrast
Sets the display contrast level.
77
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Setup
Device
Select a function.
Keys
Any key to answer
You can use any key to accept in-
coming calls (except
).
Auto key lock
The key pad is automatically locked
if one minute elapses since any key
was last pressed. This prevents the
phone from being used accidentally.
However, you can still receive calls
and make an emergency call.
The keypad can also be directly
locked and unlocked.
Hold down.
Confirm (only when the
phone is being switched
off).
Key tones
You can set the type of key
tone:
Click or Tone or Silent
Status
Factory settings
The phone is reset to the default val-
ues (does not apply to SIM card and
network settings).
Phone identity
The phone identity number (IMEI) is
displayed. This information may be
useful for customer service.
Fast search
When this function is activated, net-
work reconnection is speeded up
(standby time is reduced).
T9 input
T9 preferred
Activate intelligent text entry or de-
activate it.
T9 language
Select language in which the mes-
sage is to be composed.
78
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Security
The phone and SIM card can be pro-
tected against misuse by several se-
curity codes (codes).
Setup
Security then
select a function:
Codes
PIN control
The PIN is usually requested each
time the phone is switched on. You
can deactivate this feature but you
risk unauthorized use of the phone.
Some service providers do not per-
mit this function.
PIN Protects your SIM card (personal
identification number).
PIN2 This is needed to set the charge
detail display and to access addi-
tional functions on special SIM
cards.
PUK Key code. Used to unlock SIM
cards after the wrong PIN has
been entered.
Phone-
code Protects your phone. Must be en-
tered at the first security setting
(4 to 8 digits).
Keep these confidential numbers in a
safe place where you can access them
again if required.
y
Change PIN
You can change the PIN to any
4 to 8 digit number (i.e. a number
you may find easier to remember).
(Enter old PIN.
Press.
(,Enter new PIN.
(,Repeat new PIN.
Change PIN2
You can change PIN 2 to any
4 to 8 digit number (displayed only if
PIN 2 is available).
Proceed as with Change PIN.
Change phonecode
You define and enter the phone code
when you call up a phone code pro-
tected function for the first time. It is
then valid for all functions.
You can change it to any 4 to 8 digit
number. If you forget it, please call
Siemens Service (p. 90).
Clear SIM card barring
If the PIN is entered incorrectly three times,
the SIM card is locked. Follow instructions
and enter the PUK (MASTER PIN) your ser-
vice provider has given you together with
the SIM card. If MASTER PIN or PIN is lost,
please contact your service provider.
y
y
79
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Setup
Security
select a function:
Babysitter
(phone code protected)
Calls can only be made to one phone
number that is dialed by holding
down the right soft key (detailed de-
scription on page 25).
Only
(PIN2 protected)
The dialing options are restricted to
phone numbers in the Addressbook/
Phonebook, new entries cannot be
made. If only area codes are en-
tered, the relevant phone numbers
can be added to these manually be-
fore dialing.
Depending on whether the Phone-
book is stored on the SIM card or in
the phone, PIN 2 or phone code are
requested before the entries can be
changed.
Last 10 only
(phone code protected)
Calls are limited to the call list (p. 51)
of "dialed numbers". This list can be
filled with phone numbers specifi-
cally for this purpose:
Delete the call list and create "new
entries" by dialing phone numbers
and canceling before the connection
is established.
This SIM only
(phone code protected)
Your phone cannot be operated with
a different SIM card.
y
80
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Network
Depending on the technology (GSM
or TDMA) used, the descriptions of
individual functions may vary.
Setup Network the
n select a function:
Konfiguration
Network info
The list of networks currently avail-
able is displayed.
KIndicates forbidden ser-
vice providers.
Choose network
Network search is restarted. This is
useful if you are not in your home
network or want to register in a diffe-
rent network. The network info list is
rebuilt.
Auto network
Activate or deactivate, see also
"Choose network" above.
When "Auto network" is activated, the
next network is dialed in the order of
your "preferred service providers."
Otherwise, a different network can
be selected manually from the list of
available networks.
Preferred network
The service providers you prefer af-
ter your home service provider are
displayed in this list (e.g. if there are
several networks that differ in price).
When this function is activated, the
list that your service provider pro-
poses is displayed first. You can edit
this as required:
Display list of preferred
networks.
•Create new entry:
<Leer> Select,
then scroll to an entry in the list of
the service providers and confirm.
•Change/delete old entry:
Select an existing entry and delete
it, or select an entry from the list of
the service providers and confirm.
y
81
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Setup Network
then select a function:
Mode of operation
The phone can be operated in TDMA
networks as well as in GSM net-
works. You can set one of these op-
erational modes as standard or
switch between the two modes au-
tomatically.
When switching on the phone for
the first time, automatic selection is
active.
•Automatic selection
When automatic selection is active,
the network last used is searched
and the phone determines whether
a SIM card is inserted.
Depending on the situation, the cur-
rently available network is displayed
for the selection.
• Only TDMA
In TDMA mode the phone can also
be used without a SIM card.
• Only GSM
GSM mode is only possible when a
SIM card is inserted.
Barrings
Locking restricts the use of your SIM
card (not supported by all service
providers). You need a 4-digit pass-
word that your service provider sup-
plies you. You may need to be regis-
tered separately for each lock.
y 8
Outgo. access
All outgoing calls except emergency
number 112 are barred.
Outgoing international
Only national calls can be made.
Outgo internat. x home barred
International calls are not permitted.
However you can make calls to your
home country when abroad.
All incoming calls
The phone is barred for all incoming
calls (forwarding all calls to the mail-
box has a similar effect).
When roaming
You do not receive calls when you
are outside your home network. This
means that no charges are incurred
for incoming calls.
Status check
The following information can be dis-
played after a status check:
|Lock set.
{Lock not set.
?Status unknown (e.g.
new SIM card).
Clear all
All locks are cleared.
82
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
User group
Setup
User group
select a function:
If offered by the service provider,
this service enables groups to be
formed. These have access for ex-
ample to internal (company) informa-
tion or special tariffs apply to them.
Check with your service provider for
details.
User group
Activate or deactivate the function.
"User group" must be deactivated for
normal phone use (p. 78).
Select group
You may select or add groups other
than the preferred groups (see be-
low). The service provider supplies
you with code numbers for the
groups.
Outgo. access
In addition to network control for a
user group, it is possible to choose
whether outgoing calls outside the
group are permitted. If the function
is deactivated, only calls within the
group are permitted.
Preferred group
If activated, only calls within this
standard user group can be made
(depending on the network configu-
ration).
y 8Call
Setup
Call
select a function:
Call waiting
If you are registered for this service,
you can check whether it is set and
you can activate or deactivate it
(p. 22).
Hide ID
When you make a call, your number
may be displayed on the recipient's
display (depending on the service
providers).
To suppress this display, you may
activate the "Conceal ID" mode for
the next call or for all subsequent
calls. You may need to register sepa-
rately with your service provider for
these functions.
8
y 8
83
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Datenaustausch
Setup
Datenaustausch
select a function:
GPRS
(General Packet Radio Service)
GPRS is a new method for transmit-
ting data in the mobile network fast-
er. If you use GPRS, you can be con-
nected to the Internet permanently
if the network capacities suffice. Ad-
vantages of GPRS, e.g.:
•WAP information is transmitted
faster.
•E-mails are sent and received
without loss of time.
•You can chat without long delays.
This service is not yet supported by
all service providers.
Ein-/ ausschalten
Activate or deactivate GPRS func-
tion for all relevant applications.
GPRS info
Display of information on the con-
nectivity status.
y 8
Data services
Select Browser (p. 45). Select the re-
quired profile from the list.
GPRS settings or select CSD settings:
GPRS set-
tings APN:
Enter the address of your
service provider.
Login name:
Enter login name.
Password:
Enter password (shown as a
series of asterisks)
CSD settings
(Circuit
Switch Data)
Dial-up no.:
Enter ISP number.
Call type:
Select ISDN or Analog.
Login name:
Enter login name.
Password:
Enter password (shown as a
series of asterisks).
84
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Setup
Datenaustausch
select a function:
IrDA(infrared)
The infrared port integrated in the
phone cannot be used unless the
other device has a corresponding
port. Align the infrared windows
with each other (max distance 30
cm).
Activate/deactivate IrDA.
Indicator on the display:
6If switched on.
7During transmission.
Fax/data mod.
See page 88.
Baud rate
You can use the baud rate to set the
transmission rate in a cable connec-
tion between your PC and the
phone:
115,2 Kbit/s
57,6 Kbit/s
38,4 Kbit/s
19,2 Kbit/s
To ensure optimum data flow when
connecting your phone to a comput-
er with a cable, we recommend you
use only the original Siemens acces-
sories:
Datacable Professional
y 8
Authentication
Encrypted WAP dial-up.
Time/date
Setup
Time/date
The clock must be set correctly once
at start-up.
Press.
(First date, then time.
y
85
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Setup
Accessories
Setup
Accessories
select a function:
Headset
If an original Siemens headset is
used, the profile is activated auto-
matically as soon as the headset is
plugged in.
User-definable settings:
Auto answer
(factory default: off)
Calls are automatically accepted af-
ter the 3rd ring. You should be wear-
ing the headset.
Switch between the
phone and the Headset
Switch to Headset during a call (if
the phone is connected to the Head-
set).
OW Activate and deactivate.
Automatic settings:
•Accept call with the Call key or
PTT key (Push To Talk) when the
key lock is activated.
•Actviate voice dialing with the PTT
key.
When calls come in unperceived, other per-
sons might listen in without your consent.
86
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Explorer
To organize your files, you can use
the Flex. Memory just like a PC file
manager. The Flex. Memory assigns
special folders to different data
types:
Surf & fun Explorer
A list of the folders and files is dis-
played.
_
Scroll up and down.
Go back from folder.
To open a highlighted file:
Press.
Bitmap
Start Bitmap viewer (S. 76). *.bmp
Melodies
Start melody manager (p. 74). *.mid
SMS
SMS messages (Out),
SMS messages (In).
The messages are displayed in the
editor.
*.smo
*.smi
Speech memo
Use the dictaphone to play (p. 55)
back voice memos.
*.vmo
Businesscard
Stored in vCard format. *.vcf
Alarm
stored in vCalendar format *.vcs
Verschiedenes
Other files. *.*
Flex. Memory menu
Open menu
Depending on whether you have
highlighted a file or a folder, you are
offered different functions.
Open Open folder.
Start Start application according
to the file format.
Mark/Unmark Highlight files/remove high-
lighting.
Delete Delete all highlighted files.
Delete all Delete all entries. PIN must
be entered.
New folder Create a new folder and give
it a name(the folder must be
on the same level).
Rename Rename a highlighted file.
Send via ... (see p. 89)
Sort Set sort criteria (alphabeti-
cal, type, time).
Attributes Display information on the
file or folder selected.
Drive info Display the capacity used
and available.
87
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Siemens Quick Sync software
Siemens Quick Sync
software
With the PC program provided, ad-
dresses and appointments can be
synchronized between our phone
and Windows® Outlook® and Lotus
Notes.
Software installation
Insert the CD ROM into the drive of
your PC and select "Siemens Quick
Sync". You will be guided through
the installation process by dialogue
boxes.
Operating instructions
The Siemens Quick Sync software
offers detailed operating instructions
and online help.
Connection
Phone and PC must be intercon-
nected via infrared or cable.
To ensure optimum data flow when
connecting your phone to a comput-
er with a cable, we recommend you
use only the original Siemens acces-
sories:
Datacable Professional
Flexible memory
The phone memory is used flexibly
by various applications and adapts it-
self to your personal user profile.
The applications available are:
Explorer
Addressbook
Dictaphone
SMS-Archive
Melodies
Pictures
Always delete data that is no longer
needed.
88
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Fax/data mode using a PC y
Setup
Connectivity
Fax/data mod.
With the phone connected to a PC,
you can transmit and receive faxes
and data. Appropriate software for
data communication/fax communi-
cation must be available on your PC
and there must be a connection (e.g.
IrDA, page 84) to the phone.
F ax and data services must be en-
abled by the service provider. Differ-
ent networks support different
types of fax/data reception, contact
your service provider for details.
Fax/data mod.
Your service provider must give you
a number for telephoning and a fax/
data number.
Sending
Start your PC communication pro-
gram and enter the required destina-
tion phone number in the program.
Receive
The call is signaled by a special ring-
er and the type (fax or data) is dis-
played.
Now start the communication pro-
gram in your PC to receive the fax/
data.
Speech/fax
Sending
8
Setup
Connectivity
Fax/data mode
Send vce/fax
Set this function on the phone before
transmission so that you can switch
from voice mode to fax mode.
While the connection is being set
up, the following soft key is available
for two seconds:
Switch to Send vce/fax
mode; you may now
send a fax.
Receive
(Only if a special fax or data number
is not available).
Start the required communication
program in your PC and switch on
the function at the phone during the
call (the PC accepts the connection).
Setup
Connectivity
Fax/data mode
Voice/fax rec
End transmission
End transmission in the PC software
and/or press
.
89
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Send via .../Print via IrDA
Send via ...
The phone offers several options to
transmit or receive messages and
data via various transmission routes.
The relevant option menus offer ac-
cess to this function:
SMS
Addressbook entries, appoint-
ments, memos, etc. can be sent as
an SMS to another suitable mobile
phone.
Larger objects are split into several
SMS messages, if necessary.
IrDA
The infrared port integrated in the
phone cannot be used (see also
p. 84) unless the other device has a
corresponding port.
This device can be a mobile phone,
PDA, PC or printer.
Print via IrDA
You can use your phone to send
messages or data to a printer with
an infrared port.
90
6.11.01 S46 US DRAFT A31008-H5450-A5-*
Siemens Service
Worldwide support by Siemens Partners is
only one phone call away or in the Internet:
Internet: http://www.my-siemens.com
Abu Dhabi ......... Siemens Service
Center..................... 0 26 42 38 00
Ägypten ............ Siemens.................. 0 23 33 41 11
Argentinien ....... Siemens............. 0 80 08 88 98 78
Australien.......... Siemens................ 18 00 62 24 14
Bahrain.............. Siemens.......................... 40 42 34
Bangladesch ..... Siemens.................. 0 17 52 74 47
Belgien .............. Siemens.................. 0 78 15 22 21
Brunei................ incomm .....................02 43 08 01
Bulgarien........... Omnitel ...................... 02 73 94 88
China................. Siemens............. 0 21 50 31 81 49
Dänemark* ....... Siemens..................... 35 25 86 00
Deutschland*, **Siemens............ 0 18 05 33 32 26
Dubai*............... Siemens.................. 0 43 55 99 88
Elfenbeinküste .. Siemens.....................80 00 03 33
Estland .............. Siemens.......................6 30 47 35
Finnland*........... Siemens................ 09 22 94 37 00
Frankreich* ....... Siemens................ 01 56 38 42 00
Griechenland..... Siemens.................. 0 16 86 43 89
Großbritannien* Siemens............. 0 87 05 33 44 11
Hong Kong ........ Siemens..................... 22 58 36 36
Indien ................ Siemens................ 01 16 83 97 55
Indonesien ........ Dian Graha Elektr. 02 14 61 50 81
Irland* ............... Siemens................ 18 50 77 72 77
Island ................ Smith & Norland.......... 5 11 30 00
Italien ................ Siemens................ 02 66 76 44 00
Jordanien.......... Siemens.................. 0 79 55 96 63
Kambodscha ..... Siemens..................... 12 80 05 00
Kanada.............. Siemens.............1 88 87 77 02 11
Katar ................. Siemens...........00 97 44 69 67 00
Kroatien ............ Siemens.................. 0 16 10 53 81
Kuwait............... NGEECO....................... 4 81 87 49
Lettland............. Siemens.......................7 50 11 14
Libanon* ........... F.A. Kettaneh............. 01 44 30 43
Libyen ................Siemens ............... 02 13 35 02 31
Litauen...............UAB Skaidula .............. 2 39 77 79
Luxemburg.........Siemens ................... 43 84 33 99
Malaysia............Siemens ............... 03 79 52 51 84
Malta .................Siemens ..... 00 35 32 14 94 06 32
Marokko ............Setel S.A. .................. 22 66 92 32
Mauritius ...........Ireland Blyth................ 2 11 62 13
Niederlande*.....Siemens ............ 0 90 03 33 31 00
Norwegen*........Siemens .................... 22 70 84 00
Österreich*........Siemens ............... 05 17 07 50 04
Oman .................Siemens ........................ 79 10 12
Pakistan.............Siemens ............... 02 15 67 35 65
Philippinen .........Siemens .................... 28 14 98 88
Polen..................Siemens ............... 08 00 22 09 90
Portugal* ...........Siemens ................. 8 00 85 32 04
Russland............Siemens ............... 09 57 37 29 51
Saudi Arabien....Siemens ................. 0 26 51 50 94
Schardscha........Siemens ................. 0 65 33 66 42
Schweden*........Siemens ................. 0 87 50 99 11
Schweiz .............Siemens ................. 0 12 12 00 90
Simbabwe .........Siemens .................... 04 36 94 24
Singapur ............Siemens ...................... 8 45 48 18
Slowakei............Siemens ............... 07 59 68 22 66
Slowenien..........Siemens ................. 0 14 74 63 36
Spanien .............Siemens ................. 9 02 11 50 61
Rep. Südafrika...Siemens ............... 08 60 10 11 57
Taiwan...............Siemens ............... 02 25 18 65 04
Thailand.............Siemens ................. 0 27 15 51 00
Tschechische
Republik.............Siemens ............... 02 33 03 27 27
Türkei.................Simko ................ 0 21 65 71 89 89
Tunesien ............Siemens .................... 01 86 19 02
Ungarn...............Siemens ............... 06 14 71 24 44
USA ...................Siemens .............. 1 877 687 1671
Vietnam .............Opticom..................... 45 63 22 44
** DM 0,24/Min
You can buy original Siemens accessories at http://www.my-siemens.com; in
countries marked with an asterisk *, you can also call the phone number shown.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
91
Troubleshooting
If problems occur when using the phone, try to find a solution here first. If the problem persists,
contact your service provider or the Siemens Service.
Problem Possible causes Possible corrective measures
Phone cannot
be switched on. On/Off key not pressed long
enough. Press On/Off key for at least two seconds.
Dead battery. Charge battery. Check charging indicator in the display.
Battery contacts dirty. Clean contacts.
See also below under:
"charging error"”
Standby time too
short. Frequent use of the organizer
and games. Restrict use if necessary.
Speed search active. Deactivate speed search (p. 77).
Display illumination on. Switch off display illumination (p. 76).
Unintentional keystroke (illumi-
nation!). Activate key lock (p. 77).
Charging error
(charge icon not
displayed).
Battery totally discharged. 1) Plug in charger cable 2) Wait for approx. 5 - 10 min-
utes until the charge icon is displayed 3) Charge for
2-3
hours
(use only the charger provided).
Temperature out of range:
-0 °C to +40 °C. Make sure the ambient temperature is right, wait a
while, then charge again.
Contact problem. Check power supply and connection to the phone.
Check battery contacts and device interface, clean
them if necessary, then insert battery again.
No power supply. Plug in to different socket or check voltage.
Wrong charger. Use only original SIEMENS accessories.
Battery faulty. Replace battery.
SIM error. SIM card not correctly inserted. Make sure that the SIM card is correctly inserted
(p. 12).
SIM card contacts dirty. Clean the SIM card with a dry cloth.
SIM card with wrong voltage. Use 3 V SIM cards only.
SIM card damaged
(e.g. broken). Inspect the damage.
Return the SIM card to service provider.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
92 Troubleshooting
Problem Possible causes Possible corrective measures
No connection to
network. Signal weak. Move higher, to a window or open space.
Outside range. Check service provider coverage map.
Fixed mode. Switch mode or it to automatic (p. 81).
SIM card not valid. Reclaim at the service provider.
New network not authorized. Try manual selection or select a different
network (p. 80).
Network barring is set. Check barrings (p. 81).
Network overloaded. Try again later.
Phone loses net-
work. Signal too weak. Reconnection to an other service provider is automatic
(p. 80). Switching the phone off and on again may
speed this up.
Communication dif-
ficult in car with
handsfree function.
Ambient noise level too high. Use Car Kit (Car Solutions, p. 96).
Calls not possible. Dialing error. New network not authorized (p. 80).
New SIM card inserted. Check for new restrictions.
Charge limit reached. Reset limit with PIN 2 (p. 52).
Credit used up. Load credit.
Certain uses of the
phone not possible. Call restrictions are set. Barrings may have been set by your service provider.
Check barrings (p. 81).
The phone number has more
than 20 digits. Check phone number.
Entries cannot be
made to Adress-
buch/Telefonbuch.
Adressbuch/Telefonbuch is
full. Delete Adressbuch/Telefonbuch entries(p. 28).
Voice mail does not
work Call divert to the mailbox not
set. Set call divert to the mailbox (p. 53).
SMS (text mes-
sage)
d flashes. SMS memory full. Delete messages (SMS) to make room (p. 36).
Function cannot be
set. Not supported by service
provider or registration re-
quired.
Contact your service provider.
Charge counter
does not work
(GSM).
Charge pulse not transmit-
ted. Contact your service provider.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
93
Troubleshooting
Reset all settings to the factory default: * # 9 9 9 9 #
G
Further information can be found on the Internet under:
http://www.siemens.com/productservice
Problem Possible causes Possible corrective measures
Message cannot be
sent. Some service providers do not support
this service. Check with your service provider.
Phone number of the service center is
not set or wrong. Set service center (p. 41).
SIM card contract does not support this
service. Contact your service provider.
Service center overloaded. Repeat message.
Addressee does not have a compatible
phone. Check.
PIN error. Three wrong entries. Enter the MASTER PIN (PUK) provided
with the SIM according to the instructions.
If MASTER PIN or PIN has been lost, con-
tact your service provider.
Phone code error. Three wrong entries. Contact Siemens Service (p. 90).
Service provider
code error. No authorization for this service. Contact your service provider.
Too few / too many
menu items. Functions may have been added or re-
moved by your service provider via the
SIM card.
Check with your service provider.
No fax possible. Incorrect settings in the PC. Check settings (p. 88).
No authorization for this service. Contact your service provider.
Wrong infrared driver in the PC. Install latest infrared driver.
Mode set to "only TDMA." Set "automatic" or "only GSM."
Damage
Severe shock. Remove battery and SIM and insert them again. Do not dismantle the phone.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
94 Specifications
Declaration of conformity
Exposure to radio frequency sig-
nals
Your wireless handheld portable
telephone is a low power radio trans-
mitter and receiver. When it is ON, it
receives and also sends out radio
frequency (RF) signals.
In August 1996, The Federal Com-
munications Commission (FCC)
adopted RF exposure guidelines
with safety levels for hand-held wire-
less phones. Those guidelines are
consistent with the safety standards
previously set by both U.S. and inter-
national standards bodies:
American Natinal Standards Institute
(ANSI) C95.1 (1992)
National Council of Radiation Protec-
tion and Measurement (NCRP) Re-
port 86 (1986)
International Commission of Non-
Ionizing Radiation Protection
(ICNIRP) 1996
Ministry of Health (Canada) Safety
Code 6
Those standards were based on
comprehensive and periodic evalua-
tions of the relevant scientific litera-
ture. For example, over 120 scien-
tists, engineers, and physicians from
universities, government health
agencies, and industry reviewd the
available body of research to devel-
op the ANSI standard (C95.1).
The design of your phone complies
with the FCC guidelines (and those
standards). For additional informati-
on concerning exposure to radio fre-
quency signal, see the statement by
the FDA at the end of this user gui-
de.
Technical data
GSM 900 class: 4 (33 dBm)
GSM 1900 class: 1 (30 dBm)
TDMA 800 class IV: (0.6 W ERP)
TDMA 1900 class IV: (0.6 W ERP)
Weight: 123g/4.3OZ
Dimensions: 118 x 46 x 21mm
(94 cm3)
Operating voltage: 3.8 Volts
Standby time:
GSM: Up to 260hr
TDMA: Up to 150hr
Talk time:
GSM: Up to 6hr
TDMA: Up to 150 minutes
SIM card: 3 Volt
6.11.01 S46 US DRAFT A31008-H5450-A5-*
95
Maintenance
Maintenance tips
•The SIM card should be treated
with the same care as a credit
card. Do not bend or scratch it or
expose it to static electricity.
•Clean the card with a damp cloth
or an anti-static wipe without
chemical cleaning agents.
•Protect the phone from moisture
and shocks. Do not expose your
phone to direct sunlight.
•Remove the battery if you are not
going to use the phone for ex-
tended periods of time (more than
one month).
Phone ID
You will need the following details if you
lose your phone or SIM card. Please enter
here the number of the SIM card (on the
card):
....................................................
15-digit serial number of the phone (under
the battery):
....................................................
Customer Service number of the service
provider:
....................................................
Lost phone
If you lose your phone or SIM card contact
your service provider immediately to pre-
vent misuse.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
96 Accessories
Basics
Li-Ion Battery (850 mAh)
Travel Charger
Like a standard charger, but with automatic
voltage selection: 90-270 V for international
use.
Desk Top Charger
Enables simultaneous charging of the phone
battery and a spare battery.
Headset PTT
Optimum freedom of movement with excel-
lent call quality. Including PTT (Push To Talk)
key to accept calls and to activate voice dial-
ling.
Belt Clip
Features a belt clip and a clip for fastening
your phone to clothes or bags.
Leather Case
Attractive protection from dirt and damage
from outside.
Data/Applications
Data Cable
To connect the phone with the RS 232 port
on the PC.
Car Solutions
Car Charger
Connection to dashboard (12/24 Volt) by
simply plugging into the cigarette lighter
socket. Kit with cradles.
Mobile Holder
Mobile holder for securing the phone. Ideal
in combination with the Headset PTT or the
Car Kit Portable.
Car Mobility Pack
Allows handsfree talking and simultaneously
charges the mobile phone in the car.
Car Kit Portable
Hands-free kit with integrated loudspeaker
and microphone and auto talk feature. Sim-
ply plug into the cigarette lighter socket.
Innovations
MP3 player USB
Stereo headset for handsfree talking and su-
perior sound quality when playing MP3 au-
dio files. The 32 MB MultiMediaCard records
30 minutes of music in premium quality. The
package includes the software for download-
ing and the USB connecting cables.
Products can be obtained in specialty shops.
Visit our online shop under:
www.icm.siemens.com
6.11.01 S46 US DRAFT A31008-H5450-A5-*
97
U.S. FDA
The U.S. Food and Drug Administration's (FDA)
Center for Devices and Radiological Health Con-
sumer Update on Mobile Phones
FDA has been receiving inquiries about the safety of mo-
bile phones, including cellular phones and PCS phones. The following sum-
marizes what is know - and what remains unknown - about whether these
products can pose a hazard to health, and what can be done to minimize any
potential risk. This information may be used to respond to questions.
Why the concern?
Mobile phones emit low levels of radio frequency energy (i.e., radio frequency
radiation) in the microwave range while being used. They also emit very low
levels of radio frequency energy (RF), considered non-significant, when in the
stand-by mode. It is well known that high levels of RF can produce biological
damage through heating effects (this is how your microwave oven is able to
cook food). However, it is not known whether, to what extent, or through
what mechanism, lower levels of RF might cause adverse health effects as
well. Although some research has been done to address these questions, no
clear picture of the biological effects of this type of radiation has emerged to
date. Thus, the available science does not allow us to conclude that mobile
phones are absolutely safe, or that they are unsafe. However, the available
scientific evidence does not demonstrate adverse health effects associated
with the use of mobile phones.
What kinds of phones are in question?
Questions have been raised about hand-held mobile phones, the kind that
have a built-in antenna that is positioned close to the user's head during nor-
mal telephone conversation. These types of mobile phones are of concern
because of the short distance between the phone's antenna - the primary
source of the RF - and the person's head. The exposure to RF from mobile
phones in which the antenna is located at greater distances from the user (on
the outside of a car, for example) is drastically lower than that from hand-held
phones, because a person's RF exposure decreases rapidly with distance
from the source. The safety of so-called "cordless phones," which have a
base unit connected to the telephone wiring in a house and which operate at
far lower power levels and frequencies, has not been questioned.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
98 U.S. FDA
How much evidence is there that hand-held mobile phones might be harmful?
Briefly, there is not enough evidence to know for sure, either way; however,
research efforts are on-going. The existing scientific evidence is conflicting
and many of the studies that have been done to date have suffered from flaws
in their research methods. Animal experiments investigating the effects of RF
exposures characteristic of mobile phones have yielded conflicting results. A
few animal studies, however, have suggested that low levels of RF could ac-
celerate the development of cancer in laboratory animals. In one study, mice
genetically altered to be predisposed to developing one type of cancer devel-
oped more than twice as many such cancers when they were exposed to RF
energy compared to controls. There is much uncertainty among scientists
about whether results obtained from animal studies apply to the use of mo-
bile phones. First, it is uncertain how to apply the results obtained in rats and
mice to humans. Second, many of the studies showed increased tumor de-
velopment used animals that had already been treated with cancer-causing
chemicals, and other studies exposed the animals to the RF virtually continu-
ously - up to 22 hours per day.
For the past five years in the United States, the mobile phone industry has
supported research into the safety of mobile phones. This research has re-
sulted in two findings in particular that merit additional study:
1. In a hospital-based, case-control study, researchers looked for an associa-
tion between mobile phone use and either glioma (a type of brain cancer) or
acoustic neuroma (a benign tumor of the nerve sheath). No statistically signif-
icant association was found between mobile phone use and acoustic neuro-
ma. There was also no association between mobile phone use and gliomas
when all types of gliomas were considered together. It should be noted that
the average length of mobile phone exposure in this study was less than
three years.
When 20 types of glioma were considered separately, however, an associa-
tion was found between mobile phone use and one rare type of glioma, neu-
roepithelliomatous tumors. It is possible with multiple comparisons of the
same sample that this association occurred by chance. Moreover, the risk did
not increase with how often the mobile phone was used, or the length of the
calls. In fact, the risk actually decreased with cumulative hours of mobile
phone use. Most cancer causing agents increase risk with increased expo-
sure. An ongoing study of brain cancers by the National Cancer Institute is ex-
pected to bear on the accuracy and repeatability of these results.1
6.11.01 S46 US DRAFT A31008-H5450-A5-*
99
U.S. FDA
2. Researchers conducted a large battery of laboratory tests to assess the ef-
fects of exposure to mobile phone RF on genetic material. These included
tests for sever-al kinds of abnormalities, including mutations, chromosomal
aberrations, DNA strand breaks, and structural changes in the genetic materi-
al of blood cells called lymphocytes. None of the tests showed any effect of
the RF except for the micronucleus assay, which detects structural effects on
the genetic material. The cells in this assay showed changes after exposure
to simulated cell phone radiation, but only after 24 hours of exposure. It is
possible that exposing the test cells to radiation for this long resulted in heat-
ing. Since this assay is known to be sensitive to heating, heat alone could
have caused the abnormalities to occur. The data already in the literature on
the response of the micronucleus assay to RF are conflicting. Thus follow-up
research is necessary. 2
FDA is currently working with government, industry, and academic groups to
ensure the proper follow-up to these industry-funded research findings. Col-
laboration with the Cellular Telecommunications Industry Association (CTIA)
in particular is expected to lead to FDA providing research recommendations
and scientific oversight of new CTIA-funded research based on such recom-
mendations.
Two other studies of interest have been reported recently in the literature:
•Two groups of 18 people were exposed to simulated mobile phone signals
under laboratory conditions while they performed cognitive function tests.
There were no changes in the subjects' ability to recall words, numbers, or
pictures, or in their spatial memory, but they were able to make choices
more quickly in one visual test when they were exposed to simulated mo-
bile phone signals. This was the only change noted among more than 20
variables compared.3
•In a study of 209 brain tumor cases and 425 matched controls, there was
no increased risk of brain tumors associated with mobile phone use. When
tumors did exist in certain locations, however, they were more likely to be
on the side of the head where the mobile phone was used. Because this
occurred in only a small number of cases, the increased likelihood was too
small to be statistically significant.4
6.11.01 S46 US DRAFT A31008-H5450-A5-*
100 U.S. FDA
In summary, we do not have enough information at this point to assure the
public that there are, or are not, any low incident health problems associated
with use of mobile phones. FDA continues to work with all parties, including
other federal agencies and industry, to assure that research is undertaken to
pro-vide the necessary answers to the outstanding questions about the safety
of mobile phones.
What is known about cases of human cancer that have been reported in users of hand-
held mobile phones?
Some people who have used mobile phones have been diagnosed with brain
cancer. But it is important to understand that this type of cancer also occurs
among people who have not used mobile phones. In fact, brain cancer occurs
in the U.S. population at a rate of about 6 new cases per 100,000 people each
year. At that rate, assuming 80 million users of mobile phones (a number in-
creasing at a rate of about 1 million per month), about 4800 cases of brain can-
cer would be expected each year among those 80 million people, whether or
not they used their phones. Thus it is not possible to tell whether any individ-
ual's cancer arose because of the phone, or whether it would have happened
anyway. A key question is whether the risk of getting a particular form of can-
cer is greater among people who use mobile phones than among the rest of
the population. One way to answer that question is to compare the usage of
mobile phones among people with brain cancer with the use of mobile
phones among appropriately matched people without brain cancer. This is
called a case-control study. The current case-control study of brain cancers by
the National Cancer Institute, as well as the follow-up research to be spon-
sored by industry, will begin to generate this type of information.
What is FDA's role concerning the safety of mobile phones?
Under the law, FDA does not review the safety of radiation emitting consumer
products such as mobile phones before marketing, as it does with new drugs
or medical devices. However, the agency has authority to take action if mobile
phones are shown to emit radiation at a level that is hazardous to the user. In
such a case, FDA could require the manufacturers of mobile phones to notify
users of the health hazard and to repair, replace or recall the phones so that
the hazard no longer exists.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
101
U.S. FDA
Although the existing scientific data do not justify FDA regulatory actions at
this time, FDA has urged the mobile phone industry to take a number of steps
to assure public safety. The agency has recommended that the industry:
•Support needed research into possible biological effects of RF of the type
emitted by mobile phones;
•Design mobile phones in a way that minimizes any RF exposure to the user
that is not necessary for device function; and
•Cooperate in providing mobile phone users with the best possible informa-
tion on what is known about possible effects of mobile phone use on hu-
man health.
At the same time, FDA belongs to an interagency working group of the feder-
al agencies that have responsibility for different aspects of mobile phone safe-
ty to ensure a coordinated effort at the federal level. These agencies are:
•National Institute for Occupational Safety and Health
•Environmental Protection Agency
•Federal Communications Commission
•Occupational Health and Safety Administration
•National Telecommunications and Information Administration
The National Institutes of Health also participates in this group.
In the absence of conclusive information about any possible risk, what can concerned
individuals do?
If there is a risk from these products and at this point we do not know that
there is-it is probably very small. But if people are concerned about avoiding
even potential risks, there are simple steps they can take to do so. For exam-
ple, time is a key factor in how much exposure a person receives. Those per-
sons who spend long periods of time on their hand-held mobile phones could
consider holding lengthy conversations on conventional phones and reserving
the hand-held models for shorter conversations or for situations when other
types of phones are not available.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
102 U.S. FDA
People who must conduct extended conversations in their cars every day
could switch to a type of mobile phone that places more distance between
their bodies and the source of the RF, since the exposure level drops off dra-
matically with distance. For example, they could switch to:
•a mobile phone in which the antenna is located outside the vehicle,
•a hand-held phone with a built-in antenna connected to a different antenna
mounted on the outside of the car or built into a separate package, or
•a headset with a remote antenna to a mobile phone carried at the waist.
Where can I find additional information?
For additional information, see the following websites:
•Federal Communications Commission (FCC) RF Safety Program (select "In-
formation on Human Exposure to RF Fields from Cellular and PCS Radio
Transmitters"): http://www.fcc.gov/oet/rfsafety.
•World Health Organization (WHO) International Commission on Non-Ioniz-
ing Radiation Protection (select Qs & As): http://www.who.int/emf
•United Kingdom, National Radiological Protection Board: http://www.nr-
pb.org.uk
•Cellular Telecommunications Industry Association (CTIA): http://www.wow-
com.com
•U.S. Food and Drug Administration (FDA) Center for devices and Radiolog-
ical Health: Http://www.fda.gov/cdhr/consumer/
1 Muscat et al. Epidemiological Study of Cellular Telephone Use and Malig-
nant Brain Tumors. In: State of the Science Symposium; 1999 June 20; Long
Beach, California.
2 Tice et al. Tests of mobile phone signals for activity in genotoxicity and other
laboratory assays. In: Annual Meeting of the Environmental Mutagen Society;
March 29, 1999, Washington, DC; and personal communication, unpublished
results.
3 Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey,
A. Effect of a 915- MHz simulated mobile phone signal on cognitive function
in man. Int. J. Radiat. Biol., April 8, 1999.
4 Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular
telephones and the risk for brain tumors; a case-control study. Int. J. Oncol,
15: 113-116, 1999.
6.11.01 S46 US DRAFT A31008-H5450-A5-*
103
A
Accepted calls ........................... 51
Accessories ............................... 96
Addressbook
call entry ................................ 28
make entry ............................. 26
read entry/change .................. 27
Agenda ...................................... 57
Alarm clock ................................ 60
Alarms missed ........................... 60
Answering service (external) ..... 48
Appointments ............................ 58
Auto answer (in the car) ............ 85
Auto redial ................................. 21
Autom. selection (GSM/TDMA) . 81
B
Babysitter .................................. 25
Baudrate .................................... 84
Beep, ringer ............................... 73
Big letters .................................. 76
Bitmap viewer ........................... 42
Browser (WAP) .......................... 44
Business card ............................ 62
C
Calculator ................................... 63
Calculator functions ................... 63
Calendar .................................... 57
Call
accept/end ............................. 20
charges .................................. 52
divert ...................................... 53
menu ..................................... 24
record .................................... 22
several simultaneously .......... 22
Call back .................................... 21
Call lists ..................................... 51
Calls dialed (call list) ................... 51
Calls missed (call list) ................ 51
Car Kit (headset) .................. 69, 85
Car solutions .............................. 96
CB services ................................ 49
Charge display ........................... 52
Charging (battery) ...................... 14
Clock .................................... 65, 84
Conceal ID ................................. 82
Conference ................................ 23
Confidential numbers ................ 78
Contrast (display) ....................... 76
Control codes (DTMF) ... 24, 29, 32
Countdown ................................ 66
CSD Data ................................... 83
Currency conv. ........................... 64
D
Daily view .................................. 57
Data exchange ........................... 83
Date set ..................................... 65
Dictaphone .......................... 22, 55
Display
big letters ............................... 76
contrast .................................. 76
illumination ............................. 76
Display (settings) ....................... 76
Divert ......................................... 53
DTMF tones ................... 24, 29, 32
E
E-mail via SMS ........................... 41
Extending numbers ................... 29
F
Fast access ................................ 71
Fast search ................................ 77
Favorites .................................... 70
Fax via SMS ............................... 41
Fax/data mode ........................... 88
Filter (for calls) ........................... 73
Flex. Memory ............................ 86
Flexible memory ........................ 87
Index
6.11.01 S46 US DRAFT A31008-H5450-A5-*
104
Folders (explorer) ....................... 86
Forwarding ................................ 23
Frequency range ........................ 80
G
Games ....................................... 67
Getting started .......................... 13
GPRS ......................................... 83
Greeting ..................................... 76
GSM .......................................... 81
H
Handset volume ........................ 22
Headset ..................................... 85
Holding a call ............................. 23
Home network .......................... 80
I
Illumination ................................ 76
IMEI number .............................. 77
Important numbers .................... 95
Information services .................. 49
Infrared (IrDA) ............................ 84
International dialing codes ......... 20
Internet (WAP) ........................... 43
K
Key lock ..................................... 77
Key tone .................................... 73
L
Language (display) ..................... 76
Limit (charge) ............................. 52
Loss of phone, SIM card ........... 95
Lowercase and uppercase ........ 39
M
Mailbox ...................................... 48
Maintenance of the phone ........ 95
Master reset .............................. 77
Melody
compose ................................ 75
load ........................................ 74
select ..................................... 74
Melody manager ........................ 74
Menu
quick selection ....................... 72
Messages (SMS) ....................... 35
Microphone off .......................... 24
Mode of operation ..................... 81
Monthly view ............................. 57
N
Network search ......................... 77
Network selection ..................... 80
New folder (explorer) ................. 86
O
Only GSM .................................. 81
Only TDMA ................................ 81
Outbox (SMS) ............................ 36
P
Phone code ................................ 78
Phone data ................................. 94
Phone identity number (IMEI) .... 77
Phone memory .......................... 31
Phonebook ........................... 30, 71
PIN
error ....................................... 93
PIN 2 .......................................... 78
Prefix ................................... 20, 27
Prevent new SIM ....................... 79
Print via ... .................................. 89
PUK ............................................ 78
R
Redial ......................................... 21
Reference number ..................... 31
Reminder ................................... 21
Ringer setting ............................ 73
S
Send via ... ................................. 89
Index
6.11.01 S46 US DRAFT A31008-H5450-A5-*
105
Service center ........................... 41
Service tones ............................. 73
Siemens Service ........................ 90
SIM services .............................. 50
SMS
archive ................................... 39
capacity .................................. 36
delivery confirmation ............. 36
insert picture .......................... 38
setup ...................................... 41
standard messages ............... 37
status report .......................... 41
T9 text entry .......................... 61
T9 text enty ........................... 38
Soft keys
set .......................................... 71
Special characters ..................... 39
Speech/fax ................................. 88
Speed dialing keys ..................... 72
Standby time ............................. 14
Stopwatch ................................. 66
Swapping ................................... 22
Switching off phone .................. 15
automatically .......................... 65
T
T9
switching on/off ............... 38, 61
text entry ............................... 39
TDMA ........................................ 81
Technical data ............................ 94
Text input ............................ 27, 39
Text message (SMS) ................. 35
Time zones ................................ 65
Time/charge ............................... 52
Time/date
set .................................... 65, 84
Topic list (CB) ............................ 49
Trembler alarm .......................... 73
Troubleshooting ......................... 91
U
Uppercase and lowercase ... 27, 39
User group (network) ................. 82
V
Validity (SMS) ............................ 41
VIP group ................................... 26
Voice command ......................... 33
Voice dialing ............................... 33
Voice mail .................................. 48
Volume (handset) ....................... 22
Volume (ringer) .......................... 73
W
WAP
access .................................... 43
browser .................................. 44
profiles ................................... 45
setup ...................................... 45
Weekly view .............................. 57
Index
