air dryer control module

AHEAD OF THE CURVE™

BENDIX® EVERFLOW™MODULE

Continuous Flow of Cleaner, Drier Air

for High-Air-Demand Applications

Continuous air flow from Bendix

Bendix pioneered the first air dryer nearly 30 years ago, and

ever since, our air dryers have been the industry standard. Now

there’s a new way to provide a continuous flow of clean, dry air

for high-air-demand applications: the Bendix®EverFlow™air

dryer control module.

Bulk haulers, transit buses, and other high-air-usage applica-

tions, such as central tire inflation have special air supply needs.

These vehicles require a continuous, uninterrupted supply of

clean, dry air. While normal air dryers work well, their need to

periodically stop and purge moisture doesn’t make them

suitable for high-air-demand applications. For these vehicles,

there’s the Bendix EverFlow™module — an air dryer control

module that works with a pair of Bendix®soft seat AD-9™,

AD-IP™or AD-IS™air dryers to continuously provide drier,

filtered air for applications with high-air-demand.

Tag team performance

Unlike normal air dryers that periodically stop to purge

moisture, the EverFlow™air dryer control module keeps airflow

constant by connecting two of our popular Bendix soft seat

AD-9, AD-IP or AD-IS air dryers with an electronic control

module that utilizes ABS modulator technology. The EverFlow™

air dryer control module helps prevent contamination of the air

system by allowing one dryer to provide dry air to the system

while the other dryer purges. While one unit filters and dries

the air, the other purges the collected moisture. Then the

controller switches between the two to repeat the process.

In this way, air flows continuously through the system in an

uninterrupted supply.

Cleaner and more efficient

The Bendix®EverFlow™module delivers clean, dry air faster

than other system options. In fact, the EverFlow module is

designed to unload almost 10 percent faster than existing,

competitive continuous flow dryers. This 10 percent difference

means that in low pressure applications, such as pressure

assisted bulk offload, offload times may be fast enough to

allow for one extra load / offload cycle a day, which means

increased productivity for your fleet.

®

air dryer control module

AHEAD OF THE CURVE™

BENDIX® EVERFLOW™MODULE

Integrated Vehicle Solutions From Bendix.

The Power of Simplification for You.

Faster air delivery, continuous airflow for high-use applications,

and flexible mounting configurations. For more information on

how the power of the Bendix®EverFlow™air dryer control module

can work for you, talk to your Bendix Account Manager,

call 1-800-AIR-BRAKE, or visit www.bendix.com today.

Bendix Commercial Vehicle Systems LLC • 901 Cleveland Street • Elyria, Ohio 44035 • 1-800-AIR-BRAKE (1-800-247-2725) • www.bendix.com

BW2076 • ©2004 Bendix Commercial Vehicle Systems LLC, a member of the Knorr-Bremse Group • 02/04 • All Rights Reserved • Printed in U.S.A.

The Bendix® EverFlow™module also provides cleaner air to the

vehicle’s air system. Cleaner, drier air means minimized risk of

contamination in the air lines and to the accessories. In high-air-

demand applications such as transit buses, refuse haulers and

central tire inflation, the Bendix EverFlow module provides the

clean, dry air to high-air-use accessories and air brakes that

you’ve come to expect from Bendix air dryers.

Easy-to-find parts and service

Since each air dryer operates only half the time, replacement

desiccant cartridges last longer than with a single dryer

cartridge in this type of application. However, when they do

need to be replaced, Bendix®AD-IP™, AD-9™or AD-IS™

cartridges, along with any Bendix air dryer service part are

always available at your nearby Bendix distributor or truck

parts dealer. The EverFlow module offers the quality and relia-

bility you expect from Bendix air dryers and it’s backed by one

of the most powerful warranties in the industry.

Vocations

The Bendix®EverFlow™air dryer control module provides

continuous air to applications with special air supply needs,

including:

• Bulk haulers

• Transit buses

• Refuse haulers

• Central tire inflation

• Double / Triple trailer combination vehicles

• Military vehicles

• Cement mixers

• Off-highway construction vehicles

• Logging equipment

• Fire trucks

• Other high-air-usage applications

Mounting: No restrictions, however,

control lines to dryers should be as short

as possible and compressor discharge lines

kept within BW110-A application guidelines.

FEATURES BENEFITS

BENDIX® EVERFLOW™PART NUMBERS

Part Number Description

More efficient air

delivery than com-

petitive continuous

flow dryers

Continuous supply

of cleaner, drier air

Module Style

Bendix Parts

Faster air delivery and

faster offload times

Provides continuous airflow

to high-air-usage applications

Flexibility in mounting

configurations

Simple retrofit for vehicles

with existing air dryer

No waiting for service parts

Module Specifications

Height: 4-1/2 inches

Width: 2-3/4 inches

Depth: 3-1/2 inches

Weight: 2-1/2 pounds

Warranty: 1 year / 100,000 miles

™

800684 EverFlow™Module and Retrofit Kit

800685 EverFlow™Module 12 Volt

5006845 OE Piece Number 12 Volt

5007453 EverFlow™Module OE 24 Volt

800722 EverFlow™Module Service 24 Volt

800723 EverFlow™Module Retrofit Kit 24 Volt
