Billionton Systems GBTIPOD Bluetooth iPOD Audio Transmitter User Manual GBTIPOD QSG release 20051025
Billionton Systems, Inc. Bluetooth iPOD Audio Transmitter GBTIPOD QSG release 20051025
Users Manual
Product shape
Connecting my iPod Audio Transmitter
1. Turn on your Bluetooth Receiver device. The device which the iPod
transmitter is to connect. ie. Bluetooth Receiver or Stereo headset.
2. Plug the iPod transmitter into the headphone connector
3. Power on your iPod and press PLAY on the iPod. The iPod transmitter will
power on automatically. The iPod transmitter should enter pairing mode
indicated by the Red and Blue flashing alternately.
4. Enjoy!
*Note: This device will only work with Bluetooth receiver devices that
has “0000” or “1234” as PIN code.
iPod Audio Transmitter LED Indicator
Mode
Idle Searching
last device Pairing mode In connection
LED
Indicator None Red and Blue
steady
Red and Blue flash
alternately
Blue flash twice
every 3 seconds
IPod Audio Transmitter
Quick Guide
Operating Procedures
1. Upon power on, the iPod transmitter will try and connect to the last paired
device for 10 seconds. If the last paired device is not found, then iPod
transmitter will automatically enter pairing mode.
2. Upon disconnection, the iPod transmitter will try to reconnect to the last
paired device. If the last paired device is not found, then iPod transmitter
will automatically enter idle mode. To power on the iPod transmitter,
please remove the iPod transmitter and plug into the iPod again.
3. During pairing mode, if devices are not found within 3 minutes, the iPod
transmitter enters idle mode. To power on the iPod transmitter, please
remove the iPod transmitter and plug into the iPod again.
Troubleshooting
IPod Transmitter is not powered on when plugged into the iPod.
z Remove the Transmitter and reinstall into the top of your iPod.
z Ensure your iPod is charged and powered on.
After connecting the Transmitter, there is no sound.
z Make sure your iPod is powered on and set to play
There is more than one Bluetooth Receiver device in the same room or
range.
z The Bluetooth iPod transmitter will pair with the Bluetooth receiver
that was turned on first or is the closet in proximity to the transmitter.
If you are paired with the incorrect receiver, turn off the power on the
receiver that will not be used
FCC Caution
1. The device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference
that may cause undesired operation.
2. This Transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
3. Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user authority to operate the
equipment.
