BodyMedia MF Physiological monitoring device User Manual GSG minifly rev3 indd
BodyMedia, Inc. Physiological monitoring device GSG minifly rev3 indd
Users Manual
© Copyright 2007 BodyMedia, Inc.
100346_REV1
4 Smithfi eld Street
11th Floor
Pittsburgh, PA 15222
USA
P.412.288.9901
F.412.288.9902
www.bodymedia.com
Getting Started
R
1 2
Welcome to the SenseWear® Weight Management Solution (WMS). The
SenseWear® solution will allow you to easily collect, manage, and analyze
physiological and lifestyle data. Please read and follow the instructions in-
cluded in this guide before using the armband and WMS website.
This Getting Started Guide for SenseWear® WMS takes you step-by-step
through the set up of your system. It tells you how to confi gure and wear the
SenseWear® armband, and collect and retrieve data from your armband via the
SenseWear® WMS website. It is very important that you read and follow these
directions to ensure the accuracy of your data.
This product complies with the general requirements for a safe medical device.
However, this product alone is not meant to substitute for proper medical
diagnosis, care, or treatment.
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02
Important . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 03
Features of the SenseWear® armband . . . . . . . . . . . . . . . . . . . . . 12
Your SenseWear® armband. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Registration & Account Creation . . . . . . . . . . . . . . . . . . . . . . . . 18
Wearing the armband . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Uploading Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Legal Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
introductiontable of contents
The SenseWear® WMS
package includes:
One (1) SenseWear®
armband
One (1) standard wing/
strap assembly and one
(1) large size wing/strap
assembly
One (1) USB cable
•
•
•
PLACEHOLDER
3 4
Intended Use
The SenseWear® armband can be used as a monitor for applications such as:
nutritional diagnostics, metabolic diseases, pediatrics, pulmonary and cardiac
studies, geriatrics, internal medicine, occupational medicine, neurology, psy-
chiatrics, sleep screening, and in general anywhere it is necessary to monitor
caloric and energy consumption, movement, physical activity, quality of life,
lifestyle, behavior and/or stress.
This product complies with the general requirements for a safe medical device
under applicable directives. However, this product alone is not meant to
substitute for proper medical diagnosis, care, or treatment. Clinicians should
not make drastic changes to a user’s lifestyle based solely on data from the
armband. The SenseWear armband has been clinically validated for subjects
between 7 and 65 years of age who are engaged in resting, ambulatory, station-
ary biking, motoring and weight-lifting activities, etc. Due to metabolic varia-
tions, subjects who are 1) outside this age range or 2) engaged in alternate
or obscure activities may see decreased accuracy in the data. Any decisions
based on the data from this device should be made only by medical or para-
medic personnel and should consider the condition and lifestyle of the subject
tested. The SenseWear® armband should not be used for life critical applica-
tions; improper usage may result in harm or even death to the wearer.
This product is non-defi brillation proof.
Do not get the device close to other devices that can cause electromagnetic
interferences of any nature.
This EQUIPMENT not suitable for use in the presence of a FLAMMABLE AN-
AESTHETIC MIXTURE WITH AIR or WITH OXYGEN OR NITROUS OXIDE.
importantimportant
Please be sure to verify equipment is connected and used compliant to
UL1950.
Medical electrical equipment needs special precautions regarding EMC and
needs to be installed and put into service according to the EMC information
provided on pages 8-11. Portable and mobile RF communications equipment
can affect medical electrical equipment.
The equipment or system should not be used adjacent to or stacked with
other equipment and if adjacent or stacked use is necessary, the equipment or
system should be observed to verify normal operation in the confi guration in
which it will be used.
The SenseWear® wireless communicator should not be used in airplanes,
hospitals or locations where cellular telephones or electronic devices are
prohibited.
Keep the SenseWear® armband and wireless communicator out of reach of
children. Both products contain smaller, removable parts which can become
choking hazards.
Wear comfortably
Be careful not to over-tighten the armband while on your arm. If, at any time,
you feel constriction or loss of circulation, simply loosen the adjustable strap
and re-fasten it to a more comfortable setting.
Be sure that both your arm and the sensors on the back of the armband are
cleaned daily. To clean the sensors, wipe with a soft, damp cloth. If you de-
velop a rash where the armband comes in contact with your skin, discontinue
5 6
importantimportant
use and consult your physician before continuing regular use of the armband.
The design of the armband involved many materials experts, physicians, and
suppliers who are familiar with wearable materials and products. Each mate-
rial was chosen for its precedent in other skin contact products or has been
independently approved for skin contact. However, everyone’s skin is different
and wearers with very sensitive skin may experience irritation or redness after
wearing the armband. If this occurs, discontinue use and consult your physi-
cian. If you have known metals allergies, you should consult your physician
prior to wearing. Do not wear armband when open sores are present.
Check armband for sharp edges or damage before each use.
There have been reports of scratches/cuts associated with the Velcro tab of the
strap. The Velcro tab should be aligned with the strap to avoid contact with the
skin. Also, excessively hot armbands, such as those left in a car in the summer,
may cause skin burns if they are not allowed to cool before use.
When the armband is on the arm, DO NOT connect it to the USB cable.
Users with sensitive skin should avoid wearing the armband excessively. If you
have sensitive skin, remove the armband 1 hour for every 24 hours of wear
time to reduce potential for skin irritation.
Water resistance
The armband is not intended for long term operation under water. The arm-
band is IP67 water resistant to 1 meter under water for 30 minutes. Loss of
data may occur if the armband is under water for a longer period of time.
Please note when submerging the armband in water:
Data accuracy may become compromised if the sensing module is
submerged in water.
The wing seal must be in good condition and the wing must be properly
attached to the sensing module to avoid damaging the unit.
Do not get the sensing module wet while removed from the wing assemble
as damage will occur.
Handling
Though the SenseWear® armband was designed for wearability and long-term
use, it is a sensitive monitoring device. Rough handling can break internal
components. Never drop or shock the armband and always store it in a safe
place when not in use.
Avoid exposing the armband to extreme temperatures, direct sunlight, mois-
ture, sand, dust, or mechanical shock.
To prevent possible damage to the USB cable, grasp the plug end when dis-
connecting the USB cable. Replace the cable if it becomes frayed.
Dispose of device in accordance with local, state, federal, or country specifi c
regulations.
Maintenance
Do not attempt to open the armband yourself. It contains no user-serviceable
parts. Refer all servicing to qualifi ed Service Personnel. Opening the armband
yourself will void the warranty.
•
•
•
7 8
importantimportant
Changes or modifi cations to this equipment not expressly approved by the
party responsible for compliance could void the user’s authority to operate
the equipment.
If the armband is dropped, ensure that it is working properly and not physi-
cally damaged before relying on readings.
Cleaning
Always clean and dry the armband after vigorous sweating activities or when
it becomes noticeably moist or dirty. Failure to keep the armband clean, or
improper cleaning, may irritate the skin and affect the sensor performance.
Moisten a soft cloth or towel with mild disinfectant soap and water. Wipe and
dry the skin-touching side of the armband. Never use solvents to clean the
armband, only for disinfecting (see below). The adjustable strap should be
hand-washed with mild soap and warm water, then air-dried. Machine drying
should be avoided.
Disinfecting
Wipe back of armband with soft cloth dampened with 70% isopropyl alcohol.
Allow armband to dry for 5-10 minutes before wearing DO NOT STERILIZE
THIS UNIT.
Flicker
IEC 6100-3-3
N/A
Harmonics
IEC 6100-3-2
N/A The Product MF is suitable for use in all establish-
ments, including domestic, and those directly
connected to the public low-voltage power supply
network that supplies buildings used for domestic
purposes.
RF Emissions
CISPR 11
Class B, Group 1 The Product MF uses RF energy only for its inernal
function. Therefore, its RF emissions are very low
and are not likely to cause any interference in
nearby electronic equipment.
The Product MF (SenseWear® armband) is intended for use in the electromagnetic environment
specifi ed below. The customer or user of the Product MF should ensure that it is used in such an
environment.
Guidance and Manufacturer’s Declaration - Emissions
Emissions Test Compliance Electromagnetic Environment - Guidance
Computer and Wireless Communicator
1.5m
Diagram not to scale.
1.5m 1.5m
2.5m
Patient Environment
9 10
The Product MF (SenseWear® armband) is intended for use in the electromagnetic environment
specifi ed below. The customer or user of the Product MF should ensure that it is used in such an
environment.
Guidance and Manufacturer’s Declaration - Immunity
3A/m Power frequency magnetic fi elds should
be that of a typical commercial or hospi-
tal environment.
Power
Frequency
50/60Hz
Magnetic Field
IEC 61000-4-8
3A/m
N/A Mains power quality should be that of a
typical commercial or hospital environ-
ment. If the user of the Product MF re-
quires continued operation during power
mains interruptions, it is recommended
that Product MF be powered from an
uniterruptible power supply or battery.
Voltage Dips/
Dropout
IEC 61000-4-11
>95% Dip for
0.5 Cycles
60% Dip for 5
Cycles
30% Dip for 25
Cycles
>95% Dip for 5
Seconds
N/ASurge
IEC 61000-4-11
±1kV Differential
±2kV Common
Mains power quality should be that
of a typical commercial or hospital
environment.
N/AEFT
IEC 61000-4-4
±2kV Mains
±1kV I/Os
±6kV Contact
±8kV Air
Floors should be wood, concrete, or
ceramic tile. If fl oors are synthetic, the
r/h should be at least 30%.
ESD
IEC 61000-4-2
±6kV Contact
±8kV Air
Immunity Test IEC 60601
Test Level
Compliance
Level
Electromagnetic
Environment - Guidance
importantimportant
3 Vrms
150 kHz to
80 MHz
3 V/m
80 MHz to
2.5 GHz
3 Vrms
150 kHz to
80 MHz
3 V/m
80MHz to
2.5 GHz
Portable and mobile communications
equipment should be separated from
Product MF by no less than the distances
calculated/listed below:
D=(3.5/V1)(Sqrt P)
D=(3.5/E1)(Sqrt P)
80 to 800 MHz
D=(7/EI)(Sqrt P)
800 MHz to 2.5 GHz
Where P is the max power in watts and D
is the recommended separation distance
in meters.
FIeld strengths from fi xed transmitters,
as determined by an electromagnetic site
survey, should be less than the compli-
ance levels (V1 and E1).
Interference may occur in the vicinity of
equipment containing a transmitter.
•
•
•
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
The Product MF (SenseWear® armband) is intended for use in the electromagnetic environment
specifi ed below. The customer or user of the Product MF should ensure that it is used in such an
environment.
Guidance and Manufacturer’s Declaration - Emissions
IEC 60601
Test Level
Compliance
Level
Electromagnetic
Environment - Guidance
Immunity Test
11 12
0.1 0.3689 0.3689 0.7378
The Product MF (SenseWear® armband) is intended for use in the electromagnetic environment speci-
fi ed below. The customer or user of the Product MF can help prevent electromagnetic interference by
maintaining a minimum distance between portable and mobile RF Communications Equipment and the
Product MF as recommended below, according to the maximum output power of the communications
equipment.
Recommended Separations Distances for the Product MF
0.01 0.1166 0.1166 0.2333
Separation (m)
150kHz to 80MHz
D=(3.5/V1)(Sqrt P)
Separation (m)
80 to 800MHz
D=(3.5/V1)(Sqrt P)
Separation (m)
800MHz to 2.5GHz
D=(7/E1)(Sqrt P)
Max Output
Power (Watts)
1 1.1666 1.1666 2.3333
10 3.6893 3.6893 7.3786
100 11.6666 11.6666 23.3333
features of the sensewear® armbandimportant
Armband features
Gathers raw physiological data including Movement, Heat Flux, Skin Tem-
perature, Near Body Temperature, and Galvanic Skin Response.
Contains approximately 7 days of battery life before needing to
be recharged.
Stores approximately 10 days of continuous physiological and lifestyle
data.
Offers sound feedback for Reminders and alerts.
Wireless uploads available if data is sent to a PC via a wireless communi-
cator.
Product specifi cations
Sensors:
Accelerometer (3-axis)
Heat Flux
Skin Temperature
Near-Body Temperature
Galvanic Skin Response (GSR)
Materials:
Monitor: ABS, polyurethane, co-polyester, 304 grade stainless steel
Wireless Communicator: ABS
Adjustable Strap: Nylon, polyester, Lycra (no latex content) or polyisoprene
Battery type: Internal lithium polymer cell battery
RF Frequency: 2.4GHz
Transmitter output power: <1mW
Battery power: about 7 days under use (18 hrs/day)
Memory capacity: about 10 days under use (18 hrs/day)
Monitor size: (l) 55mm x (w) 62mm x (h) 13mm [2.2” x 2.4” x 0.5”]
Monitor weight (with adjustable strap): TBD
•
•
•
•
•
•
•
•
•
•
•
•
•
13 14
features of the sensewear® armbandfeatures of the sensewear® armband
Water resistance: 1 meter for 30 minutes when properly mated to the wing
assembly.
Operating temperature/humidity: 5°C to +40°C (50°F to 104°F)/100% RH
non-condensing
Humidity Condensing: 5 to 95% Relative Humidity non-condensing
Design and specifi cations are subject to change without notice.
Sensor Accuracy
Accelerometer (3-axis)
Calibrated range is +/- 2.00g
The minimum resolution is 0.01g
Two-standard-deviation accuracy of +/-0.05g, up to 1.00g on longitudinal axis
Two-standard-deviation accuracy of +/-12.00% of expected value otherwise on the longitudinal axis
Two-standard-deviation accuracy of +/-0.06g up to 1.00g on the transverse axis
Two-standard-deviation accuracy of +/-12.00% of expected value otherwise on transverse axis.
Two-standard-deviation accuracy of +/-0.06g up to 1.00g on the forward axis
Two-standard-deviation accuracy of +/-12.00% of expected value otherwise on forward axis.
Heat Flux
Calibrated Range is 0.00 W/m2 to 300.00W/m2
A minimum resolution of 1.00W/m2
Two-standard-deviation of +/-10.00W/m2 at heat fl ux less than 50W/m2
Two-standard-deviation of +/-35.00% of expected value otherwise
Galvanic Skin Response
Calibrated Range is 56KΩ to 20MΩ (50.00 nSiemens – 17.00 uSiemens)
Two-standard-deviation accuracy of +/- 7.00 nSiemen up to 233.34 nSiemens reading
Two-standard-deviation accuracy of +/- 3.00% of expected value otherwise
Skin Temperature
Calibrated Range is 20.00ºC to 40.00ºC
A minimum resolution of 0.05ºC
Two standard deviation accuracy of +/- 0.80°C
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Caution
TYPE B APPLIED PART
The Waste Electrical and Electronic Equipment Regulations
indicates separate collection for electrical and electronic
equipment.
Tested to applicable safety standards.
Identifi cation code of Notifi ed Body involved: XXX.
Classifi cation of the device, as per 93/42 directives: IIa (rule 10)
Certifi cation procedure : 93/42/EEC, Annex VI, VII.
Identifi cation code of Notifi ed Body involved: XXX
Transmit Power Class 8 - Less than 10mW output power
Duty Cycle Class 4 - permitted to operate at 100% duty cycle Receiver
Class 3 - Standard reliable SRD communication media
15 16
features of the sensewear® armbandfeatures of the sensewear® armband
FCC statement
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired
operation. If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit separate from
the receiver.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifi cations to this equipment not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC 47CFR 15C TCB - 47 CFR Part 15 Subpart C Intentional Radiator
Certifi cation Test
•
•
•
•
•
FCC 47CFR 15B CLA - 47 CFR Part 15 Subpart B Unintentional Radiators Class
A Verifi cation
UL 60601-1 - UL Standard for Safety Medical Electrical Equipment, Part 1:
General Requirements for Safety First Edition
CENELEC EN 60601-1-2 - 2001 - Medical Electrical Equipment Part 1-2: Gen-
eral Requirements for Safety - Collateral Standard: Electromagnetic Compat-
ibility - Requirements and Tests IEC 60601-1-2: 2001
CENELEC EN 60601-1-1 - Medical Electrical Equipment - Part 1: General
Requirements for Safety - Collateral Standard: Safety Requirements for Medical
Electrical Systems.
CAN/CSA-C22.2 No.606.1-M90
ETSI EN 301 489-1 - Electromagnetic Compatibility and Radio Spectrum Mat-
ters (ERM); ElectroMagnetic Compatibility (EMC) Standard for Radio Equip-
ment and Services; Part 1: Common Technical Requirements V1.3.1
ETSI EN 301 489-3 - (Draft) Electromagnetic Compat. and Radio Spectrum
Matters (ERM); Harmonized EN for ElectroMag. Compatibility (EMC) of Radio
Comms. Equip. & Srvs.; Pt. 3: Specifi c Conditions for Short-Range Devices
(SRD) Operating on Freqs Between 9 KHz and 40 GHz V1.3.1
ETSI EN 300 440-1 V1.3.1 (2001-07) Electromagnetic compatibility and Radio
spectrum Matters (ERM);Short range devices; Radio equipment to be used in
the 1 GHz to 40 GHz frequency range
17 18
registration & account creationyour sensewear® armband
The patented SenseWear® platform is a marriage of three basic components—
a wearable monitor, a personal feedback device and a website. Working in
concert, these three components deliver the data and insight that enable true
behavior modifi cation, guidance, and adherence.
The SenseWear® armband collects the data. The SenseWear® display shows
up-to-the-minute patient feedback. The SenseWear® WMS website allows arm-
band data uploads and manual input of nutrition intake and health indicators
such as weight and blood glucose.
Go to www.sensewear.com and click on the link For Health Practitioners or
For Patients.
If this is your fi rst time entering the site, you will be directed to the “Missing
Required Software” page. You must install the two support softwares to use
the WMS system. Click Next once you have completed both installations.
1.
2.
Use the user id and password provided to you to login.
You can now add facilitators. These are your health professionals that will
be administering the WMS program to your patients.
Once the facilitators have been registered, they can log in to the system and
begin entering Member (patient) accounts and setting up MBA or Weight
Management Programs.
Once an account and program are created, there are 5 steps to
complete set up:
Step 1. Agree to end user license agreement. Click Next.
Step 2. Record your patient’s basic body parameters. Click Next.
Step 3. Enter your patient’s weight loss goals. (Weight Management
Program Only). Click Next.
Step 4. Enter their daily targets. This includes targets for total energy expen-
diture (TEE)/calories burned, step, physical activity duration and
sleep. Click Next.
Step 5. Click Go to start armband registration.
3.
4.
5.
6.
Missing Required Software
We detected that your computer does not have the required software for Keystone system.
19 20
Plug the USB cable into a USB port on your computer.
Plug the opposite end of the USB cable into the armband. Windows will
detect the new hardware and display the Found New Hardware Wizard.
1.
2.
Skip Step 3 if not using SenseWear® wireless communicator.
If using the SenseWear® wireless communicator, attach the wireless com-
municator to the USB cable. Windows will detect the new hardware and
display the Found New Hardware Wizard.
After completing the New Hardware Wizard, click Finish.
Click Register to confi gure the armband. The armband is now ready to
collect data.
3.
4.
5.
wearing the armbandregistration & account creation
The SenseWear® armband is designed to be worn on the back of the upper left
arm (the tricep muscle), touching the skin.
Slide the SenseWear® armband onto your
left arm. The Status button should be
closer to your shoulder.
Adjust the strap so that it fi ts on your
arm comfortably, then secure the oval
pull-tab. Ensure that the sensors main-
tain continuous contact with your skin at
all times and that the armband does not
slide off your arm.
Sync the display device with the armband
by pressing the mode button and view
button simultaneously on the display
device and pressing the time stamp
button on the armband. A Welcome
message will appear on the display device
when you have successfully synced the
armband to the display.
The display device will go out-of-sync
when you are not wearing the armband,
to sync the display device again, press
only the mode button on the display
device and press the time stamp on the
armband.
1.
2.
3.
4.
PLACEHOLDER
PLACEHOLDER
21 22
uploading datawearing the armband
Go to www.sensewear.com and click on the link For Health Practitioners or
For Patients.
You will then be required to enter your user id and password. You will then
see the summary page of the user.
Select the member.
If not using the wireless communicator, connect
the armband to the USB cable.
Click the Upload Armband Data button.
Click Via USB Cable or Via Wireless Communicator.
1.
2.
3.
4.
5.
6.
When your data has been uploaded, you will see the summary screen show-
ing the comparison of your targets versus your actual data.
7.
Status Indicators
There is no on/off button on your SenseWear® armband. When the monitor
makes secure contact with your body, it automatically performs a “turning
on” sequence. This may take up to ten minutes for some people, depending
on your body state. At anytime you can press and hold the timestamp button,
you will hear a series of sounds as well as a which indicates the armband is
working properly.
NOTE: Fully charge the battery before fi rst use. the battery will arrive
with a small, inital charge.
NOTE: When the armband is on the arm, DO NOT connect it to the
USB cable.
NOTE: The armband unit will collect data for at least (7) eighteen hour
days on a single charge.
23 24
troubleshootingtroubleshooting
My armband is not automatically turning on when I slide it on my arm.
If your armband has not turned on within 10 minutes of putting it on, try
lightly moistening the back of your upper arm with water and slide the arm-
band on again. It should turn on within a few minutes. If the problem persists,
please contact Technical Support.
When I try to upload data from my armband, I get an error message.
If you are having diffi culty uploading your armband data, it could be one
of several reasons. Please double check the following and try again. If the
problem still persists, please contact Technical Support.
If you are uploading wirelessly, make sure you are within 10 feet of your PC.
If you wander outside of this range, the upload may not work. Also, make
sure that your armband has had a chance to turn on. It can take up to 10
minutes for the armband to turn on after you have put it on your arm.
If you are uploading via the USB cable, make sure the cable is connected to
the armband and the port on the back of your PC.
Make sure your battery or available memory is not too low. To make sure
that the armband is powered on and the battery and memory are function-
ing, press the Status button while the armband is on your arm. If it pro-
duces the low sequence when you push it, the battery or memory is too low.
If it produces the very low sequence, the battery is drained or the memory is
full. When you plug the USB cable in while uploading, if the battery light is
red, it needs to be recharged before you can upload.
Make sure you have the USB driver installed on the computer you are using.
If you are using a computer that is different than the one you used during
registration and set-up when you fi rst received the armband, you may need
to download the software that enables you to retrieve your data from the
armband to the computer. This is called the USB driver.
1.
2.
3.
4.
5.
My armband is not responding. It seems to be off, and I cannot get it to come
back on.
Press the Status button. If the battery or memory lights are fl ashing red, either
the battery needs to be recharged or the memory is full. If after pressing the
Status button you still receive no feedback (no lights or sound), try recharging
the battery, it may have drained while you were not wearing the armband. If
after recharging the battery you still do not receive feedback, please contact
technical support and they will help solve the issue.
My armband is beeping while it is on my arm.
Solution 1: Press the Status button. If the battery lights are fl ashing red or
amber, the battery is low and will need to be replaced.
Solution 2: Press the Status button. If the memory lights are fl ashing red or
amber, the memory is low and you must upload the data and clear to continue
collecting data.
Solution 3: You may have reminders set on your armband. Check this by click-
ing on the Personal Assistance tab and clicking Reminders.
NOTE: When installing the support software on your machine,
make sure the armband or wireless communicator is NOT plugged
into the USB cable! This will cause the driver to fail to install. If this
happens, simply unplug the armband or Wireless Communicator from
the USB cable and plug it in again. The driver will then install properly.
25 26
legal information
Patents and patents pending. The SenseWear® Weight Management Solution
armband, display and wireless communicator are covered by one or more
of the following patents: United States Patent Nos.: D439,981, 6,527,711,
6,595,929, 6,605,038, 7,020,508, 7,153,262; European Patent Nos.: 1,292,217,
1,292,218; and various worldwide patents pending. This notice is accurate as
of August 14, 2007. For latest information please see www.bodymedia.com.
SenseWear® and BodyMedia® are registered trademarks of BodyMedia, Inc.
When I press the armband button, the armband does not respond.
Disconnect the USB cable and hold the armband button for 15 seconds, re-
lease the button. Press the armband button again to see if it responds. Go into
the software and retrieve your data (upload) to re-sync your armband before
wearing again. Caution: Data loss may occur. .
Data that I thought was on my armband has been erased.
Your armband may not have turned on. If this is the case, the armband did not
collect data. Or your battery may need recharged.
troubleshooting
