Intrusion Alarm Systems | ICP-AMAX3-P1 Intrusion panel, en/pl/tr

ICP-AMAX3-P1 Intrusion panel, en/pl/tr

www.boschsecurity.com

u32 zones / 8 areas / 128 user codes

uOn-board voice dialer

uMacro functionality

uUSB direct connection

This hybrid panel is designed for residential and small

to medium-sized businesses. It offers 32 zones and 8

areas and comes with an enclosure and a transformer.

An on-board PSTN dialer transmits an alarm via the

common telephone network to a phone and / or a

communication center while at the same time a voice

message is sent to the owner’s landline or mobile

phone to inform him about an intruder’s presence.

Commissioning the system is simple and involves

minimum programming: the default settings already

cover 90 % of the available functionality. Programming

can either be done via the AMAX TEXT, LCD and LED

keypads or via the programming software (A-Link

Plus).

The intrusion system can be used with both RADION

wireless peripherals, operating at 433 Mhz and

hardwired detectors from Bosch.

System overview

Phone

CMS

PSTN

Telephone

Network

A-Link Plus

USB

Functions

Basic functions

• Keypad code STAY / AWAY arming

• One button STAY / AWAY arming

• On-board dialer with CID / SIA transmission format.

Voice dialer transmits up to 4 recorded messages to

landline/mobile phones in case of an alarm. Messages

can be recorded with A-Link Plus and sent to the

control panel with the remote programming software

A-Link Plus

• 16 weekly schedules with the option to add

exceptions in the calendar

• 3 programmable macros: several single functions

from the keypad are combined to one customer

macro function, can be executed by pressing one

button

• Remote maintenance operations (e.g. walk test,

bypassing)

• Installer can enable the service mode for comfortable

programming without having alarms or outputs

triggered

• In multi-area set-up (direct and multiple arming),

“area status” is displayed

• Area name is displayed on the master or area text

keypad

• 4 on-board outputs (two monitored)

• Up to three output event types can be configured for

one physical output

• Every zone except zone 1 can be used with four-wire

fire detectors

• Any zone can be used for chime mode (door bell)

• Any zone can be used to detect a sensor tamper

(DEOL)

• Zones can be bypassed by name

• Test mode for outputs and zones

Optional functions

• Wireless devices (433 MHz) RADION from Bosch

• Zone inputs on extension modules (with DX2010)

• Relay outputs on extension modules (with DX3010)

• Connect outdoor sirens and IP cameras to an optional

8 relay module (DX3010)

• Programming key

• Arming, bypassing, isolating, operating outputs and

inquiry with the RSC+ app on mobile devices (with

the B426-M or the B450-M with B442 or B443

modules)

Optional alarm transmission

• IP communication with Bosch Conettix IP, SIA DC09

UDP and SIA DC 09 TCP protocols via B426-M and

B450-M with B442 or B443 modules

• GPRS communication with Bosch Conettix IP, SIA

DC09 UDP and SIA DC 09 TCP protocols via B450-M

with B442 or B443 modules

Optional remote programming via A-Link Plus

• IP communication (B426-M and B450-M with B442 or

B443 modules)

• GPRS communication (B450-M with B442 or B443

modules)

Communication with Bosch Software Packages

The AMAX system can communicate with the following

software packages:

Remote programming software A-Link Plus

The AMAX system can be accessed and programmed

via the remote programming software A-Link Plus. All

control panel and status information are accessible

and an operation of the AMAX panel from a remote

location is possible.

A-Link Plus can connect to the AMAX panel via USB, IP

or modem.

Compatibility information

Basic

PSTN communicator (integrated) Formats:

Contact ID, SIA DC 03

Magnetic contacts All magnetic contacts, including

recessed, terminal connection,

miniature over-head door, and

surface mount.

Intrusion detectors All conventional intrusion

detectors, including Blue Line,

seismic, PIR, TriTech,

photoelectric and TriTech PIR

Microwave.

Four-wire smoke detectors Conventional 12V smoke, heat

and photoelectric smoke

detectors.

Optional

Zone DX2010 zone input module

Relays DX3010 output module

IP communicator B426-M and B450-M with B442

or B443 modules

GPRS/GSM communicator B450-M with B442 or B443

modules

Assorted literature is available. Refer to the

appropriate datasheet, brochure, and installation

manuals for additional data.

Availability varies according to sales region.

Certifications and approvals

Region Regulatory compliance/quality marks

Germany VdS H116003 [AMAX 2100/3000, RFRC-

OPT, RFUN, RFDW-RM, RFDW-SM,

RFPR-12, RFDL-11, RFKF-TB, RFKB-FB]

Europe CE AMAX panel 2100, AMAX panel 3000

Parts included

Quantity Component

1 AMAX panel 3000 including integrated PSTN

communicator

1 Enclosure

1 Transformer

2 | ICP-AMAX3-P1 Intrusion panel, en/pl/tr

Quantity Component

1 Tamper switch

1 Terminal block for power supply

1 Hardware accessory pack: EOL resistors

1 Operation Manual

Technical specifications

Electrical

Power supply type EN = A

Transformer

Transformer input in VAC 230

Transformer output in VAC 18

Transformer AC power in VA 20

Transformer fuse in mA 500

AC input

Minimum operating voltage in

VDC

195

Maximum operating voltage in

VDC

253

Line voltage frequency in Hz 50

DC output

DC output maximum current for

all components in mA

1100

DC output maximum current for

all components: dependency on

battery

• Battery 7Ah standby 12h

(recharge Batt 80% in

72h) = 550mA

• Battery 7Ah standby 36h

+ 15min alarm current

500mA (recharge Batt

80% in 72h) = 150mA

Aux 1 / 2 output

Aux 1 / 2 output voltage +12V / GND

Aux 1 / 2 nominal output voltage

under AC line input in VDC

13.8 (+3% / -5%)

Aux 1 / 2 output max. Vpp in mV 675

Aux 1 / 2 output voltage range

under AC line input in VDC

12.82 – 13.9

Aux 1 / 2 output current in mA 500

Outputs

PO -1 / PO -2 maximum

supervised output current in mA

500

PO -3 maximum current in mA 100

Option bus

Option bus nominal output

voltage under AC line input in VDC

13.8 (+3% / -5%)

Option bus output voltage range

under AC line input in VDC

13.11 – 14.2

Option bus 1 maximum current in

mA

500

Panel PCB maximum quiescent

current in mA

100

Battery

Battery type 12 V / 7 Ah

Bosch D 126

Low battery condition in VDC below 11.0

Minimum battery condition in

VDC

10.8

Frequency bands of operation Power level for radio

equipment

GSM900 Class 4 (2W) - GPRS Class 33

GSM1800 Class 1 (1W) - GPRS Class 33

UMTS2100 Class 3 (0.25W)

Mechanical

Dimension in cm (H x W x D) 26.0 x 28.0 x 8.35

Weight in g 1950

Panel features

Number of zones 32

Number of on-board zones 8

Number of users 128

Number of events 256 history events, stamped with

time, and date

256 EN history events, stamped

with time, and date

256 dialer history events,

stamped with time, and date

Pin code variations 1000000

Number of devices

Number of keypads 8

Number of DX 2010 modules 3

Number of DX 3010 modules 2

Number of GPRS modules: B450-

M with B442 or B443

1

Number of IP modules: B426-M 2 (1 if 1 of the GPRS modules

above is connected)

3 | ICP-AMAX3-P1 Intrusion panel, en/pl/tr

Number of RF receivers 1

Number of RADION RF repeaters 8

Number of RF sensors 32

Number of DSRF RF keyfobs 24

Number of RADION RF keyfobs 128

Zones

Zone 1 Single or dual end-of-line (EOL

2,2KΩ)

NC, NO

Zone 2 - 16 COM 7 Single or dual end-of-line (EOL

2,2KΩ)

NC, NO

Tamper Enclosure tamper input (does not

reduce point capacity)

Option bus

Dimensions in mm 4 wire, Ø 0.6 - 1.2

Maximum cable length in m 200 (panel to last keypad)

Maximum bus length in m 700 (maximum 14 devices,

maximum 8 keypads)

Environmental

Minimum operating temperature

in °C

-10

Maximum operating temperature

in °C

55

Minimum relative humidity in % 10

Maximum relative humidity in % 95

Protection class IP 30, IK 06

Ordering information

ICP-AMAX3-P1 Intrusion panel, en/pl/tr

Language package 1: English, Polish, Turkish,

Hungarian

Not certified according to European standards

Order number ICP-AMAX3-P1

Accessories

IUI-AMAX-LCD8 LCD keypad, 8-zone

AMAX keypad 2000 D8, 8 zones LCD icon keypad

Order number IUI-AMAX-LCD8

IUI-AMAX3-LED8 LED keypad, 8-zone

AMAX keypad 3000 L8 is a 8 zone LED keypad

Certification: EN 50131-3 Grade 2

Order number IUI-AMAX3-LED8

IUI-AMAX3-LED16 LED keypad, 16-zone

AMAX keypad 3000 L16 is a 16 zone LED keypad

Certification: EN 50131-3 Grade 2

Order number IUI-AMAX3-LED16

IUI-AMAX4-TEXT Text keypad

AMAX keypad 4000 T, LCD text keypad, two lines with

each 18 characters

Order number IUI-AMAX4-TEXT

ICP-AMAX3-PCBP4 PCB board , en/fr/es/pt

Mainboard for AMAX panel 3000

Language package 4: English, French, Spanish,

Portuguese

Order number ICP-AMAX3-PCBP4

DX2010 Input expander, 8-zone

Zone expansion module with 8 DEOL zone inputs

Order number DX2010

DX3010 Output expander, 8-relay

Package includes only the DX3010 board

Order number DX3010

AE20EN Enclosure for module w/tamper skirt, EN

AE20EN plastic enclosure for DX2010/DX3010

Order number AE20EN

B426-M Ethernet communication module, mobile

Supports Ethernet communication for remote

programming and mobile apps on AMAX and Solution

Series control panels

Order number B426-M

B450-M Plug-in communicator interface, mobile

Supports cellular communication for remote

programming and mobile apps on AMAX and Solution

Series control panels

Order number B450-M

B442 Plug-in cellular module, GPRS

Multi-function cellular communicator that provides IP

communication over a (GPRS) cellular network

Order number B442

B443 Plug-in Cellular, HSPA+ (3G+)

Multi-function 3G/4G cellular communicator providing

IP communication over a GPRS/EDGE/UMTS/HSPA+

cellular network

Order number B443

ICP-EZPK Programming key

Blue key for transferring configurations to and from

Easy Series and AMAX panels

Order number ICP-EZPK

ICP-EZRU-0106 ROM UPDATE KEY - EZ V1

Green key for upgrading the panel firmware

Order number ICP-EZRU-0106

4 | ICP-AMAX3-P1 Intrusion panel, en/pl/tr

5 | ICP-AMAX3-P1 Intrusion panel, en/pl/tr

Represented by:

Europe, Middle East, Africa: Germany: North America: Asia-Pacific:

Bosch Security Systems B.V.

P.O. Box 80002

5600 JB Eindhoven, The Netherlands

Phone: + 31 40 2577 284

emea.securitysystems@bosch.com

emea.boschsecurity.com

Bosch Sicherheitssysteme GmbH

Robert-Bosch-Ring 5

85630 Grasbrunn

Germany

www.boschsecurity.com

Bosch Security Systems, Inc.

130 Perinton Parkway

Fairport, New York, 14450, USA

Phone: +1 800 289 0096

Fax: +1 585 223 9180

onlinehelp@us.bosch.com

www.boschsecurity.us

Robert Bosch (SEA) Pte Ltd, Security Systems

11 Bishan Street 21

Singapore 573943

Phone: +65 6571 2808

Fax: +65 6571 2699

apr.securitysystems@bosch.com

www.boschsecurity.asia

© Bosch Security Systems 2017 | Data subject to change without notice

18243859211 | en, V17, 07. Dec 2017
