TECHNICAL BULLETIN
Fire FPD-7024
Upgrading From D7024 or DS9400M/I August 19, 2011
Issue Severity: Products Affected:
High: Act immediately
Medium: Bosch Security Systems,
Inc. strongly recommends you
take the action(s) described
below.
Low: Advisory
FPD-7024 Control/Communicator
D7024 Fire Alarm Control Panel (FACP)
DS9400M/I FACP
D7039/DS9431 Multiplex (MUX) Expansion Module
D7033/FMR-7033/DS9447 LCD Keypad
D7036/FMR-7036/DS9436 Fire Annunciator Keypad
D7034/FPC-7034/DS9434 Four-Point Expander
D7038/DS9484/FPP-RNAC-8A-4C Remote
Notification Appliance Circuit Power Supply
Detection Systems MUX devices
Transformers
1.0 Upgrading a D7024 FACP to an FPD-7024 Control/Communicator
Use the table below to determine which D7024 FACP-compatible components you must
replace when upgrading to an FPD-7024 Control/Communicator:
D7024 Compatible
Component Equivalent FPD-7024 Compatible
Component Description
D7039 D7039 with v1.04 firmware or newer.
NOTE: Do not use the FACP’s v2.07 EPROM
(which shipped with older D7039 modules) in
the FPD-7024 Control Communicator.
Multiplex Expansion Module
D7033 FMR-7033 LCD Keypad
D7036 FMR-7036 Fire Annunciator Keypad
D7034 FPC-7034 Four-Point Expander
D7038 FPP-RNAC-8A-4C
NOTE: Replace the D7038 with the
FPP-RNAC-8A-4C if the D7038 is connected
to the Options Bus. Replacement is not
necessary if the D7038 is connected to the
conventional NAC outputs of the FACP.
Remote Notification Appliance
Circuit Power Supply
Transformer
(P/N: 29413), which
has only two leads
(black and white)
Transformer with three leads (black, white,
and yellow); use either
(P/N: F01U008702 with short leads, or
P/N: F01U033706 with long leads)
NOTE: If ordering a transformer
(P/N: F01U100228), call the Bosch Security
Systems, Inc. Spare Parts number:
800-894-5215.
Transformer
© 2011 Bosch Security Systems, Inc.
130 Perinton Parkway, Fairport, NY 14450-9199 USA
(800) 289-0096
TBF 11-16-09-02 Upgrading to FPD-7024
Technical Bulletin 8/11
FPD-7024
Page 2 of 2
2.0 Upgrading a DS9400M/I FACP to an FPD-7024 Control/Communicator
Use the table below to determine which DS9400M/I FACP-compatible components you
must replace when upgrading to an FPD-7024 Control/Communicator:
DS9400M/I
Compatible
Component
Equivalent FPD-7024 Compatible
Component Description
DS9431 D7039 with v1.04 firmware or newer.
NOTE: Do not use the FACP’s v2.07 EPROM
(which shipped with older DS9431 modules) in
the FPD-7024 Control Communicator.
Multiplex Expansion Module
DS9447 FMR-7033 LCD Keypad
DS9436 FMR-7036 Fire Annunciator Keypad
DS9434 FPC-7034 Four-Point Expander
DS9484 FPP-RNAC-8A-4C
NOTE: Replace the DS9484 with the
FPP-RNAC-8A-4C if the DS9484 is connected
to the Options Bus. Replacement is not
necessary if the DS9484 is connected to the
conventional NAC outputs of the FACP.
Remote Notification Appliance
Circuit Power Supply
Transformer
(P/N: 29413), which
has only two leads
(black and white)
Transformer with three leads (black, white,
and yellow); use either
(P/N: F01U008702 with short leads, or
P/N: F01U033706 with long leads)
NOTE: If ordering a transformer
(P/N: F01U100228), call the Bosch Security
Systems, Inc. Spare Parts number:
800-894-5215.
Transformer
MX361 D7044 MUX Single-Input Module
MX361M D7044M MUX Mini Single-Input Module
MX465 D7053 MUX Input-Output Module
MX363 D7052 MUX Dual-Input Module
MX250 Series D7050 Series Addressable Smoke and Heat
Detectors
DS9432 D7042 Eight-Input Remote Module
DS9432B D7042B Eight-Input Remote Module with
Fire Enclosure
MX310 FMM-7045 Series, or
D7045 Series
MUX Addressable Manual
Stations
