BES820 Programmable Espresso Machine
Instructions & Recipe Inspirations

BES820 IB V6.indd 2BES820 IB V6.indd 2 19/9/07 2:23:25 PM19/9/07 2:23:25 PM

3
5 Breville Recommends Safety First
7 Features Of Your Breville Professional 800 Collection™
Programmable Espresso Machine
9 Know Your Breville Professional 800 Collection™
Programmable Espresso Machine
11 Before First Use
12 Assembling Your Breville Professional 800 Collection™
Programmable Espresso Machine
14 Operating Your Breville Professional 800 Collection™
Programmable Espresso Machine
18 Programming Your Breville Professional 800 Collection™
Programmable Espresso Machine
19 How To Texture Milk For A Cappuccino Or Latté
21 Using The Hot Water Function
22 Coffee Making Tips
24 Care And Cleaning
27 Trouble Shooting Guide
30 Coffees To Try
34 Recipe Inspirations
CONTENTS
BES820 IB V6.indd 3BES820 IB V6.indd 3 19/9/07 2:23:29 PM19/9/07 2:23:29 PM

4
At Breville, we know that coffee lovers
will go to great lengths to refi ne the art
of making coffee. They will experiment
with fl avours and adjust the tamp and
grind of the beans in search for the
perfect espresso. The Professional 800
Collection™ Programmable Espresso
Machine caters for all levels of coffee
making, from manual control to
programmable coffee and from the novice
through to the experienced barista.
After extensive research and rigorous
testing, this machine boasts key features
such as custom set programming, a
premium brew process and a quality
espresso pressure gauge. Energy saving
features, like the auto power down, help to
save on electricity consumption, and the
selection of premium materials make the
BES820 the best of Breville.
Enjoy!
BES820 IB V6.indd 4BES820 IB V6.indd 4 19/9/07 2:23:29 PM19/9/07 2:23:29 PM

5
We at Breville are very safety conscious. We design and manufacture consumer products with the safety of you, our valued customer foremost in
mind. In addition we ask that you exercise a degree of care when using any electrical appliance and adhere to the following precautions:
IMPORTANT SAFEGUARDS FOR YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ PROGRAMMABLE ESPRESSO MACHINE
• Always ensure the Breville Professional
800 Collection™ Programmable Espresso
Machine is properly assembled before
connecting to power outlet and operating.
• The appliance is not intended to be
operated by means of an external timer or
separate remote control system.
• Use only cold tap water in the water tank.
Do no use any other liquid.
• Never use the Breville Professional 800
Collection™ Programmable Espresso
Machine without water in the water tank.
• Ensure the fi lter holder is fi rmly inserted and
secured into the brewing head before using
the machine.
• Never remove the fi lter holder during the
brewing operation as the machine is under
pressure.
• Do not leave the Breville Professional
800 Collection™ Programmable Espresso
Machine unattended when in use.
• Do not touch hot surfaces. Allow the
Breville Professional 800 Collection™
Programmable Espresso Machine to cool
down before moving or cleaning any parts.
• Do not place anything, other than cups for
warming, on top of the Breville Professional
800 Collection™ Programmable Espresso
Machine.
• Always switch off the Breville Professional
800 Collection™ Programmable Espresso
Machine by pressing the Power button
to ‘Off’, switch off at the power outlet and
unplug if appliance is to be left
unattended, if not in use, before cleaning,
before attempting to move the appliance,
disassembling, assembling and when
storing the appliance.
• Keep the appliance and accessories clean.
Follow the cleaning instructions provided in
this book.
• Carefully read all instructions before
operating and save for future reference.
• Remove any packaging material and
promotional labels or stickers before using
the Breville Professional 800 Collection™
Programmable Espresso Machine for the
fi rst time.
• Do not place the Breville Professional
800 Collection™ Programmable Espresso
Machine near the edge of a bench or
table during operation. Ensure the surface
is level, clean and free of water and other
substances.
• Do not place the Breville Professional
800 Collection™ Programmable Espresso
Machine on or near a hot gas or electric
burner, or where it could touch a heated
oven.
• Do not use the Breville Professional 800
Collection™ Programmable Espresso
Machine on metal surfaces, for example, a
sink drain board.
BREVILLE RECOMMENDS SAFETY FIRST
BES820 IB V6.indd 5BES820 IB V6.indd 5 19/9/07 2:23:43 PM19/9/07 2:23:43 PM

6
• Unwind the cord before use.
• To protect against electric shock, do not
immerse cord, plug or appliance in water or
any other liquid.
• Do not let the cord hang over the edge
of a bench or table, touch hot surfaces, or
become knotted.
• This appliance is not intended for use
by young children or infi rm persons unless
they have been adequately supervised by
a responsible person to ensure they can
use the appliance safely.
• Young children should be supervised to
ensure they do not play with the appliance.
• This appliance is for household use only.
Do not use this appliance for anything other
than its intended use. Do not use in moving
vehicles or boats. Do not use outdoors.
• It is recommended to inspect the appliance
regularly. Do not use the appliance if power
supply cord, plug or appliance becomes
damaged in anyway. Return the entire
appliance to the nearest authorised Breville
service centre for examination and/or
repair.
• Any maintenance other than cleaning
should be performed at an authorised
Breville Service Centre.
• The installation of a residual current device
(safety switch) is recommended to provide
additional safety protection when using
electrical appliances. It is advisable that a
safety switch with a rated residual
operating current not exceeding 30mA
be installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.
IMPORTANT SAFEGUARDS FOR ALL ELECTRICAL APPLIANCES
BREVILLE RECOMMENDS SAFETY FIRST (continued)
BES820 IB V6.indd 6BES820 IB V6.indd 6 19/9/07 2:23:43 PM19/9/07 2:23:43 PM

7
Programmable Function
This espresso machine offers a convenient
choice between the Manual Operation or the
intelligent Programmable Function that can be
personalised with the user’s favourite espresso
setting.
Espresso Pressure Gauge
The espresso pressure gauge assists in
obtaining the most favourable extraction
pressure, guiding the user to create their ideal
espresso. This is achieved by measuring the
pressure at which the water is being forced
through the ground coffee in the fi lter holder.
White Zone - Ideal Espresso
The gauge needle when positioned within the
recommended White Zone during pouring
indicates that the espresso will be produced at
the ideal pressure. The brewed espresso should
have a generous layer of fi ne textured and
evenly coloured golden crèma.
Green Zone - Under Extracted
The gauge needle when positioned within the
Green Zone during pouring indicates that the
espresso will be produced with insuffi cient
pressure resulting in an ‘under extracted’
espresso. This occurs when the water fl ow
through the ground coffee in the fi lter is too
fast. As a result the optimal fl avour will not be
extracted and the coffee will be watery and lack
thick créma on the top. Possible other causes
for under extraction are: coffee grind is too
coarse and/or insuffi cient coffee in fi lter and/or
under tamping.
Red Zone - Over Extracted
The gauge needle when positioned within
the Red Zone during pouring will indicate
that the espresso will be produced with too
much pressure resulting in an ‘over extracted’
espresso. This occurs when the water fl ow
through the ground coffee in the fi lter is too
slow. As a result the coffee will be very dark
and bitter, with a mottled and uneven créma on
top. Possible other causes for over extraction
are: ground coffee is too fi ne and/or too much
ground coffee in fi lter and/or over tamping.
Hot Water Wand
The dedicated hot water wand is ideal for
making your favourite hot drinks. For convenient
use the wand has a commercial style 360° ball
joint.
FEATURES OF YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ PROGRAMMABLE ESPRESSO MACHINE
BES820 IB V6.indd 7BES820 IB V6.indd 7 19/9/07 2:23:43 PM19/9/07 2:23:43 PM

8
FEATURES OF YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ PROGRAMMABLE ESPRESSO MACHINE (continued)
Commercial Style Steam Wand
The swivel-action steam wand, with
stainless steel frothing attachment, easily
adjusts to the perfect position for texturing
milk. The wand has a commercial style
360° ball joint.
Advanced Dual Wall Créma System
Filters
Advanced Dual Wall Créma System Filters
(one and two cup) are supplied with the
Breville Professional 800 Collection™
Programmable Espresso Machine.
The Advanced Dual Wall Créma System
Filters are designed to intentionally
slow the water fl ow rate during brewing,
allowing you to easily pour your espresso
at the ideal pressure, for the perfect
créma.
The fi lters are suited to both pre-ground
vacuum packed coffee and freshly ground
coffee.
Electronic Temperature Control
The electronic temperature control system
accurately maintains the optimal brewing
temperature of the water. This helps
ensure the user gets the best possible
extraction each time an espresso is made.
Energy Saving Features
The Breville Professional 800 Collection™
Programmable Espresso Machine will
enter the ‘Power Save Mode’ if not used
for one hour, and will automatically switch
off if not used for a further three hours.
The ‘Power Save Mode’ uses 45% less
power than when the machine is in
‘Stand by’ Mode.
During ‘Power Save Mode’ only the
POWER button surround will be
illuminated. All other button and light
surrounds will not be illuminated.
To re-activate the machine during ‘Power
Save Mode’, simply press the program or
one-cup or two-cup buttons. The POWER
button surround will then illuminate and
fl ash while the machine quickly reheats to
operational temperature. When the correct
temperature has been reached, all the
button surrounds on the control panel
will illuminate.
To switch off the espresso machine whilst
it is in ‘Power Save Mode’, simply press
the POWER button once.
BES820 IB V6.indd 8BES820 IB V6.indd 8 19/9/07 2:23:45 PM19/9/07 2:23:45 PM

9
KNOW YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ PROGRAMMABLE ESPRESSO MACHINE
Extra-large cup warming plate
Power button
surround illuminates when the
button is pressed to ‘On’
Steam light
illuminates to indicate that the steam
function is selected
Extra-large cup height for coffee
mugs
Removable 1 litre drip tray
and stainless steel grid
NOT SHOWN
Custom designed accessories:
Stainless steel frothing jug
Measuring/tamping spoon
Cleaning Tool
Quick Guide
1 & 2 cup dual wall stainless steel fi lters
15 bar pump
Italian-designed and made
Hot water wand
provides instant hot water
‘Power Save Mode’
Hot water light
illuminates to indicate hot water function
is selected
Pre-brew function
for optimal coffee extraction pressure
Auto purge function
for optimal coffee extraction temperature
Electronic temperature control
Drip tray full indicator
BES820 IB V6.indd 9BES820 IB V6.indd 9 19/9/07 2:23:45 PM19/9/07 2:23:45 PM

10
KNOW YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ PROGRAMMABLE ESPRESSO MACHINE (continued)
External viewing back-lit
water window Swivel steam wand and stainless
steel frothing attachment
easily adjusts to perfect positioning for
frothing milk
Espresso pressure gauge
assists in obtaining the most favourable
extraction pressure
Group head
for easy fi tment of the fi lter holder
Advanced dual wall créma system
for the ideal créma
Programmable features:
1 cup button and 2 cup button
Solid chrome brass fi lter holder
Thermoblock heating system
ensures coffee is extracted at the
correct temperature
NOT SHOWN
Cord storage
Storage tray
located behind the drip tray for storage
of accessories
Selector control for steam or hot water
Removable 2.2 litre water tank
fi lled from the front of the machine
Program button
Intelligent programmable function
that can be personalised with your
favourite espresso setting
BES820 IB V6.indd 10BES820 IB V6.indd 10 19/9/07 2:23:45 PM19/9/07 2:23:45 PM

11
BEFORE FIRST USE
Your Breville Professional 800 Collection™
Programmable Espresso Machine will have
the drip tray, water tank and storage tray in
place when you unpack it from the box.
The drip tray is located in the base of the
machine towards the front of the machine.
The water tank is located in the centre of
the machine towards the back wall.
The storage tray is located at the base
of the machine behind the drip tray and
under the water tank. The drip tray, water
tank and storage tray slide in and out for
easy access.
Ensure you have removed all parts
and accessories before discarding the
packaging.
Remove the drip tray, water tank and
storage tray. Disassemble the drip tray
by removing the stainless steel grid and
‘Empty Me!’ full indicator. Wash all parts
and accessories in warm, soapy water
using a non-abrasive washing liquid. Rinse
and dry thoroughly.
Wipe the outer housing with a soft damp
cloth and dry thoroughly. Do not immerse
the outer housing, power cord or plug in
water or any other liquid.
NOTE: Do not clean any of the parts or
accessories in the dishwasher.
BES820 IB V6.indd 11BES820 IB V6.indd 11 19/9/07 2:23:46 PM19/9/07 2:23:46 PM

12
New photo of machine showing
water tank being removed
ASSEMBLING YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ ESPRESSO MACHINE
STEP 1
Insert the storage tray into the base of
the machine and slide towards the back
wall. The storage tray conveniently stores
the cleaning tool, stainless steel fi lters,
measuring/tamping spoon and Quick
Guide when not in use, so they are not
misplaced.
STEP 2
Insert the ‘Empty Me!’ full indicator into
position in the drip tray and place the
stainless steel grid on top. Slide the
drip tray into position in the base of the
machine in front of the storage tray.
STEP 3
Slide the water tank over the drip tray
and into the front opening of the machine
and into position above the storage tray.
Ensure the water tank aligns fl ush with the
sides of the machine.
NOTE: Before each use it is
recommended to complete a water
fl ushing operation, without ground
coffee, to ensure that all internal
piping has been preheated. Refer
to Steps 1 and 4 in ‘Operating your
Espresso Machine’, page 14
BES820 IB V6.indd 12BES820 IB V6.indd 12 19/9/07 2:23:46 PM19/9/07 2:23:46 PM

13
Operating
BES820 IB V6.indd 13BES820 IB V6.indd 13 19/9/07 2:23:47 PM19/9/07 2:23:47 PM

14
• As the water tank is removed, a black
tube slides and extends out from the
water tank storage area. Do not touch or
try to remove this tube, it will
automatically slide back into position
when the water tank is re inserted.
• Fill the water tank with cold, tap water to
the maximum mark on the water window
and slide the water tank carefully back
into position in the machine.
• Ensure the Selector Control is in the
‘Standby’ position and plug the power
cord into a 230/240V power outlet and
switch on.
• Press the POWER button to ‘On’, the
POWER button surround will fl ash while
the machine is heating. When the
correct temperature has been reached,
all the button surrounds on the control
panel will illuminate.
New close up photo of 1 cup
button on control panel
STEP 1 - FILLING THE WATER TANK
• Ensure the Power button is in the ‘Off’
position and the Selector Control, on the
side of the machine, is set to the
Standby position.
• Switch the machine off at the power
outlet and unplug the power cord.
• Remove the fi lter holder if locked into the
brew head and move the steam wand to
the side of the machine.
• Remove the water tank by sliding out
using the handle insert in the front of the
water tank.
STEP 2 - PRE-WARMING THE CUPS
• The Cup Warming Plate will start to
warm as the machine heats.
• Pre-warm the espresso cups by placing
on the Cup Warming Plate. This will help
maintain the coffee’s optimal
temperature when brewed into the cups.
OPERATING YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ ESPRESSO MACHINE
NOTE: Check the water level before use
and replace the water daily. The
water tank should be refi lled
with fresh, cold tap water before
each use. Do not use mineral or
distilled water or any other liquid.
BES820 IB V6.indd 14BES820 IB V6.indd 14 19/9/07 2:23:47 PM19/9/07 2:23:47 PM

15
OPERATING YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ ESPRESSO MACHINE (continued)
STEP 3 - PREPARING THE COFFEE
• Place the 1 or 2 cup fi lter into the fi lter
holder (use the smaller fi lter for 1 cup
and the larger fi lter for 2 cups). When
brewing for a mug of coffee always use
the 2 cup fi lter and only extract 60ml.
If you require a larger coffee, add the hot
water fi rst and then brew the coffee.
• Preheat the fi lter holder by placing
underneath the group head. Rinse with
hot water from the wand using the hot
water function or from the group
head and rinse with hot water using the
manual pour function. Dry the fi lter and
fi lter holder thoroughly before use.
• Use 1 level measure of ground espresso
coffee for the 1 cup fi lter and 2 level
measures for the 2 cup fi lter. It is
important to use the correct amount
of coffee for each fi lter as the fi lter
perforations have been constructed
to utilise the pressure in the machine to
extract optimal fl avour with each
brewing.
Refer to ‘The Coffee Making Tip’,
page 22.
NOTE: When using a 1 cup fi lter holder,
for optimal fl avour, you should
only extract approximately 30ml.
When using a 2 cup fi lter holder,
for optimal fl avour, you should
only extract approximately 60ml.
STEP 4 - TAMPING THE GROUND COFFEE
• Distribute the ground coffee evenly in
the fi lter and press down lightly with the
tamping end of the measuring spoon.
Refer to ‘Coffee Making Tips’, page 22
• Clean any excess ground coffee from
the rim of the fi lter holder to ensure a
proper fi t into the group head.
BES820 IB V6.indd 15BES820 IB V6.indd 15 19/9/07 2:23:48 PM19/9/07 2:23:48 PM

16
STEP 5 - PRIMING THE GROUP HEAD
• Before placing the fi lter holder into
position, it is recommended to run a
short fl ow of water through the group
head.
• Place a container or empty cup under
the group head.
• With the fi lter holder removed, prime
the group head by pressing and holding
down the single or double cup button
for approximately 5 seconds. Refer to
‘Manual Espresso’, page 17.
A pumping noise will be heard during
this operation, and water will run through
the group head. STEP 6 - INSERTING THE FILTER HOLDER
Place the fi lter holder underneath the
group head so that the handle is aligned
with the insert graphic. Insert the fi lter
holder up into the group head and rotate
the handle to the right until resistance is
felt, this will be at an approximate 90°
angle to the machine.
STEP 7 – BREWING THE COFFEE
• Ensure all the button surrounds on the
control panel are illuminated, indicating
the machine has reached the correct
temperature for brewing, and is ready for
use.
• Ensure the drip tray and fi lter holder are
in place.
• Place one or two pre-warmed cups
beneath the fi lter holder outlet.
PROGRAMMED ESPRESSO – ONE CUP
Press the one cup button once. After a
few seconds, aromatic coffee will begin to
pour into the cup. A pumping noise will be
heard in this operation. The machine will
automatically stop once the preset pour
has been delivered.
OPERATING YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ ESPRESSO MACHINE (continued)
BES820 IB V6.indd 16BES820 IB V6.indd 16 19/9/07 2:23:49 PM19/9/07 2:23:49 PM

17
PROGRAMMED ESPRESSO – DOUBLE CUP
Press the two cup button once.
After a few seconds, aromatic coffee will
begin to brew into the cup. A pumping
noise will be heard in this operation. The
machine will automatically stop once the
preset pour has been delivered.
NOTE: The minimum pour for
one cup and two cups
is set at 15ml.
NOTE: Pressing the one cup or
two cup buttons during
a programmed espresso will
immediately stop the pour.
PROGRAMMING SINGLE ESPRESSO
1. Prepare to make a single cup of
espresso by following steps 2 to 6 in
‘Operating your Espresso Machine’,
pages 14-16.
2. Place your cup underneath the group
head.
3. To begin programming, press the
‘PROGRAM’ button once. The machine
will beep once and the program button
will begin to fl ash. This indicates the
machine is in programming mode.
4. Press the one cup button once.
The machine will commence normal
pour function, and the one cup button
surround will begin to fl ash.
5. When the desired amount of espresso
has poured into the cup, press the
one cup button to stop the pour.
The machine will beep twice,
indicating it has saved your measured
pour quantity and exited programming
mode.
PROGRAMMING DOUBLE ESPRESSO
1. Prepare to make a two cup of espresso
by following steps 2 to 6 in ‘Operating
your Espresso Machine’, pages 14-16.
2. Place your cup underneath the group
head.
3. To begin programming, press the
‘PROGRAM’ button once. The machine
will beep once and the program button
will begin to fl ash. This indicates the
machine is in programming mode.
4. Press the two cup button
once. The machine will commence
normal pour function, and the two cup
button surround will begin to fl ash.
5. When the desired amount of espresso
has poured into the cup, press the
two cup button to stop the pour.
The machine will beep twice, indicating it
has saved and exited programming
mode.
RESETTING DEFAULT VOLUMES
To reset the machine to the default one
and two cup pour quantities, press and
hold the program button, until the machine
beeps three times. Release button. This
indicates the machine has returned to its
original default settings.
NOTE: Default settings: one cup pour is
approximately 30ml. Two cups
is approximately 60ml.
OPERATING YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ ESPRESSO MACHINE (continued)
BES820 IB V6.indd 17BES820 IB V6.indd 17 19/9/07 2:23:51 PM19/9/07 2:23:51 PM

18
PROGRAMMING YOUR BREVILLE PROFESSIONAL 800 COLLECTION™ PROGRAMMABLE ESPRESSO MACHINE
MANUAL ESPRESSO
Press and hold the single or two cup
button. Release the button once
suffi cient coffee has fl owed into the cup.
NOTE: PRE-BREW FUNCTION
When a single or double coffee is
selected, the machine will pump
water momentarily, followed by
a pause then continues to pump
the water through to the ground
coffee in the fi lter holder. The
ground coffee is moistened by
a small amount of water before
full extraction then expands
resulting in greater pressure
build-up to extract all the oils
and full fl avour from the ground
coffee.
STEP 8 – EMPTYING THE FILTER HOLDER
Remove the fi lter holder from the group
head by rotating the fi lter holder to the
left until it releases. To empty the used
coffee grounds, turn the fi lter holder
upside down in a bin and gently tap out
the coffee (used coffee grounds should
be thrown away with domestic waste
and not down the sink which may block
drains). Remove the fi lter by using the
indents on the side of the fi lter holder.
Rinse the fi lter and fi lter holder with water
and allow to dry.
WARNING: THE METAL PARTS OF THE
FILTER HOLDER MAY STILL BE
VERY HOT. COOL THESE PARTS IN
COLD WATER.
BES820 IB V6.indd 18BES820 IB V6.indd 18 19/9/07 2:23:53 PM19/9/07 2:23:53 PM

19
HOW TO TEXTURE MILK FOR A CAPPUCCINO OR LATTÉ
The Breville Professional 800 Collection™
Programmable Espresso Machine comes
complete with a Commercial Style Swivel
Steam Wand and Stainless Steel Frothing
Attachment. When using the frothing
attachment on the steam wand a large
amount of froth is easily created.
If less texture is required, remove the
frothing attachment from the steam wand
and steam the milk using the steam
wand. To remove the frothing attachment,
ensure it is cool then simply pull down
and remove. The frothing attachment can
be stored in the storage tray inside the
machine if not used regularly.
To refi t the frothing attachment ensure it is
securely attached to the steam wand by
inserting it, from either opening, onto the
steam wand and pushing fi rmly upwards
onto the rubber surround. Ensure the fi ne
steam holes on either end of the frothing
attachment are clean to achieve optimal
texturing.
• Press the POWER button to ‘On’.
• The fi rst step in making a cappuccino
or latté is to make a short espresso.
Refer to ‘Operating your Espresso
Machine’, pages 14-16.
• Then fi ll the stainless steel frothing jug
1⁄3 full with cold, fresh milk.
• Turn the Selector Control to the ‘Steam’
position. The white steam light will start
to fl ash indicating that the Thermoblock
Heating System is heating and preparing
to create steam.
• For improved results, purge the steam
wand of water before placing into the
milk.
NOTE: When the espresso machine
creates steam, a pumping noise
can be heard. This is the normal
operation of the 15 Bar pump.
• When the steam light stops fl ashing,
quickly insert the steam wand into the
jug of milk so that the froth attachment is
just immersed into the milk.
NOTE: If steam starts coming from the
steam wand before it is immersed
in the milk, pause the steam by
turning the Selector Control back
to the ‘Standby’ position. This will
avoid the steam pressure blowing
milk out of the jug.
BES820 IB V6.indd 19BES820 IB V6.indd 19 19/9/07 2:23:53 PM19/9/07 2:23:53 PM

20
• Hold the frothing jug at an angle so
that steam wand and/or the frothing
attachment sits just below the surface of
the heating milk and the steam will move
the milk around the inside of the jug in a
circular motion.
NOTE: The espresso machine features
a swivel steam wand assembly so
the position of the steam wand can
be changed to a comfortable angle.
HOW TO TEXTURE MILK FOR A CAPPUCCINO OR LATTÉ
• When the milk starts to increase in
volume, immerse the steam wand and/
or frothing attachment deeper into the
jug to heat the milk.
• Hold the jug at an angle with one hand
and place your other hand on the outer
base of the stainless frothing jug.
• When the base of the jug becomes too
hot to touch, set the Selector Control
to the ‘Standby’ position, stopping
the steaming function before
removing the jug. A pumping noise will
sound for a short time, do not be
alarmed as there will be a fi ve second
delay prior to the machine carrying out
the Auto-purge function.
• Pour the steamed milk into each cup of
freshly brewed espresso coffee and
spoon in the frothing milk, in the
following ratios:
Cappuccino - 1⁄3 espresso, 1⁄3 steamed milk,
1⁄3 frothed milk
Latté -
1⁄3 espresso topped with steamed milk
and approximately 1cm frothed milk, traditionally
served in a glass.
NOTE: After 5 minutes of continuous
steaming, the machine will
automatically disable the steam
function. The steam and hot water
lights will fl ash. When this occurs
return the selector control to the
‘Standby’ position.
NOTE: Always ensure that the frothing
attachment has been fi rmly pushed
onto the steam wand and connects
with the rubber surround. For best
results use cold fresh milk (low
fat milk will froth easier). Always
clean the steam wand and frothing
attachment after every use. Refer
to ‘Care and Cleaning’, page 24.
NOTE: For brewing more coffee
immediately after using the steam
function, this machine features an
auto-purge function. This ensures
that ground coffee will not be burnt
by the initial water fl ow from the
thermoblock being too hot. Instead
this water is automatically released
internally into the drip tray ensuring
that the internal thermostat is at
optimal temperature for extracting
coffee. Your coffee will always
be extracted at this optimal
temperature ensuring only the best
fl avoured coffee is achieved.
WARNING: MILK SHOULD NOT BE ALLOWED TO RUN OVER THE TOP OF THE FROTHING
ATTACHMENT, OTHERWISE IT WILL NOT FUNCTION PROPERLY. TO AVOID
SPLATTERING OF HOT MILK, DO NOT LIFT THE END OF THE FROTHING ATTACHMENT
ABOVE THE SURFACE OF THE MILK WHILE FROTHING. ENSURE THE SELECTOR
CONTROL IS IN THE ‘STANDBY’ POSITION BEFORE REMOVING THE FROTHING JUG.
BES820 IB V6.indd 20BES820 IB V6.indd 20 19/9/07 2:23:54 PM19/9/07 2:23:54 PM

21
The espresso machine features a separate
hot water function that can be used for
making tea, hot chocolate and other warm
drinks. The hot water is dispensed from
the dedicated Hot Water Wand.
Place a jug or cup underneath the Hot
Water Wand to collect the hot water.
To use the hot water function, turn the
Selector Control to HOT WATER. The hot
water light will illuminate when selected.
To turn the hot water off, turn the Selector
Control to the ‘Standby’ position.
Limit the extraction of hot water to 2 litres
each use.
The machine is not designed to make
large pots of coffee and tea. The more hot
water used at the one time, the cooler it
becomes.
USING THE HOT WATER FUNCTION
NOTE: After 2 minutes of continued hot
water use, the machine will
automatically disable the hot water
function. The steam and hot water
lights will fl ash. When this occurs
return the selector to the ‘Standby’
position.
BES820 IB V6.indd 21BES820 IB V6.indd 21 19/9/07 2:23:55 PM19/9/07 2:23:55 PM

22
WARMING YOUR CUP OR GLASS
A warm cup will help maintain the coffee’s
optimal temperature. Preheat your cup by
storing on the cup warming tray or rinsing
with hot water from the hot water wand.
WARMING THE FILTER HOLDER
A cold fi lter holder can drop the extraction
temperature enough to signifi cantly affect
the quality of your coffee. Always ensure
the fi lter holder is preheated by running
hot water through it before tamping it with
coffee.
NOTE: Always wipe the fi lter and fi lter
holder dry before tamping with
ground coffee as moisture can
encourage ‘drilling’ - this is when
water bypasses the ground coffee
during extraction.
THE GRIND
If using a pre-ground coffee, ensure an
espresso grind suitable for espresso/
cappuccino machines is purchased.
If grinding coffee beans, the grind should
be fi ne but not too fi ne or powdery. The
grind will effect the rate at which the water
fl ows through the coffee in the fi lter and
therefore the taste of the coffee.
If the grind is too fi ne (looks like powder
COFFEE MAKING TIPS
and feels like fl our when rubbed between
fi ngers), the water will not fl ow through the
coffee even when under pressure. The
resulting coffee will be over extracted, too
dark and bitter, with a mottled and uneven
créma on top.
If the grind is too coarse the water will fl ow
through the coffee too quickly. This will
result in an under-extracted coffee lacking
in fl avour and without the thick créma on
the top layer of coffee.
THE RIGHT MEASUREMENT
A single espresso is made with ¼ ounce or
7g of coffee. A level measure of the tamp/
spoon is the correct amount of coffee for a
single espresso and 2 level measures for a
double espresso. It is important to use the
correct fi lter for the amount of coffee.
TAMPING CORRECTLY
Level the desired amount of coffee by
gently tapping the side of the fi lter holder
before pressing down fi rmly with the
tamping end of the measuring spoon.
When packing for a double espresso it is
important only to tamp after the second
measure. Tamping between measures
will create a layer in the coffee that can
impede full extraction.
PURGE THE GROUP HEAD
Before inserting the fi lter holder, run
some water through the group head. It
will ensure that your machine has a last
minute ‘clean through’ and stabilises the
temperature prior to extracting.
NOTE: Make sure to wipe off any excess
coffee from the rim of the fi lter to
ensure a proper seal is achieved
under the group head.
BREWING YOUR ESPRESSO
The most common mistake in brewing is
to over extract from your ground coffee.
This results in a bitter beverage with visibly
bleached crèma. Crèma is the caramel
coloured layer that fl oats on top of the
coffee following extraction.
NOTE: The taste of your coffee will, of
course, depend on personal
preference and on many other
factors such as the type of coffee
bean used, the coarseness or
fi neness of the grind and the
tamping pressure (pressed down).
We recommend experimenting by
varying these factors to achieve the
coffee taste of your preference.
BES820 IB V6.indd 22BES820 IB V6.indd 22 19/9/07 2:23:55 PM19/9/07 2:23:55 PM

23
Cleaning
BES820 IB V6.indd 23BES820 IB V6.indd 23 19/9/07 2:23:56 PM19/9/07 2:23:56 PM

24
CLEANING THE STEAM WAND AND
FROTHING ATTACHMENT
• The steam wand and frothing
attachment should always be cleaned
after frothing milk
• Remove the frothing attachment and
rinse in warm tap water. Ensure the
two fi ne steam holes on either end of
the frothing attachment are clear. Use
the pin on the cleaning tool to unblock
these holes.
• Wipe the steam wand with a damp
cloth, and then with the steam wand
directed back into the drip tray, briefl y
set the Selector Control to the ‘Steam’
position. This will clear any remaining
milk from inside the steam wand.
CARE AND CLEANING
• Ensure the Selector Control is in the
‘Standby’ position. Press the POWER
button to off, switch off at the power
outlet, unplug the power cord and allow
the machine to cool.
• If the Steam Wand remains blocked, use
the pin on the cleaning tool to clear the
opening.
• If the steam wand continues to be
blocked, the tip of the steam wand can
be removed by using the spanner in the
middle of the cleaning tool.
• Soak the tip in hot water before using
the pin on the cleaning tool to unblock.
Replace the tip back onto the steam
wand and secure with the cleaning tool.
CLEANING THE FILTERS, FILTER HOLDER
AND GROUP HEAD
• The stainless steel fi lters and fi lter holder
should be rinsed under water directly
after use to remove all coffee particles.
Should the fi ne holes in the fi lters
become blocked, the fi ne pin on the
cleaning tool can be used to clear the
holes.
• The group head interior should be wiped
with a damp cloth to remove any ground
coffee particles.
• Periodically run water through the
machine with the fi lter holder in place,
but without any ground coffee, to rinse
out any residual coffee particles.
BES820 IB V6.indd 24BES820 IB V6.indd 24 19/9/07 2:23:56 PM19/9/07 2:23:56 PM

25
CARE AND CLEANING (continued)
CLEANING THE OUTER HOUSING / CUP
WARMING PLATE
• The outer housing and cup warming
plate can be cleaned with a soft, damp
cloth. Then polish with a soft, dry cloth.
Do not use abrasive cleansers, pads or
cloths which can scratch the surface.
CLEANING THE DRIP TRAY
• The drip tray should be removed,
emptied and cleaned at regular intervals,
particularly when the drip tray full
indicator is showing ‘Empty Me!’.
• Remove the stainless steel grid and
‘Empty Me!’ indicator from the drip tray,
wash with warm soapy water, using a
non-abrasive washing liquid, rinse and
dry thoroughly. The ‘Empty Me!’
indicator can be removed from the drip
tray by inserting fi ngers into two holes in
the corners and pulling upwards to
release the side latches.
CLEANING THE STORAGE TRAY
• The storage tray can be removed after
the drip tray is removed then cleaned
with a soft, damp cloth (do not use
abrasive cleansers, pads or cloths which
can scratch the surface).
NOTE: Do not clean any of the parts or
accessories in the dishwasher.
BES820 IB V6.indd 25BES820 IB V6.indd 25 19/9/07 2:23:57 PM19/9/07 2:23:57 PM

26
DECALCIFYING
• After regular use, hard water can cause
mineral build up in and on many of the
inner functioning components, reducing
the brewing fl ow, power of the machine,
and affecting the quality of coffee.
• We advise decalcifying the machine on
a regular basis (every 2-3 months) using
a mixture of white vinegar and water.
Follow the instructions provided, or use
the following as a guide:
Diluted solution (for softer water)
• 1 part white vinegar
• 2 parts cold tap water
Concentrated solution (for harder water)
• 1 part white vinegar
• 1 part cold tap water
DECALCIFYING THE MACHINE
• Ensure the Selector Control is in the
‘Standby’ position, the POWER button
is in the ‘Off’ position and the machine
is switched off at the power outlet and
unplugged.
• Remove the fi lter holder and frothing
attachment. Pour the mixture of white
vinegar and water into the water tank.
• Plug the machine into the power outlet
and switch on.
• Press the POWER button to the ‘On’
position and turn the Selector Control to
the ‘Standby’ position.
• Place a large container under the group
head, steam wand and hot water wand.
• When the brewing temperature has
been reached all the button surrounds
on the Control Panel will illuminate.
Press and hold the single or double
WARNING: DO NOT IMMERSE CORD, PLUG OR APPLIANCE IN WATER OR ANY OTHER LIQUID.
THE WATER TANK SHOULD NEVER BE REMOVED OR COMPLETELY EMPTIED DURING
DECALCIFYING.
cup button to commence manual pour.
Release the button once half the mixture
of white vinegar and water has run
through the group head.
• Set the Selector Control to the ‘STEAM’
position and allow steam to run through
the Steam Wand for approximately 2
minutes. Return the Selector Control
back to the ‘Standby’ position.
• Set the Selector Control to the ‘HOT
WATER’ position and allow the
remaining liquid to run through the hot
water wand. When the liquid stops
fl owing, set the Selector Control back to
‘Standby’ position.
• After decalcifying, remove the water tank
and rinse thoroughly then re-fi ll with
fresh cold water. To rinse the machine,
repeat previous steps.
CARE AND CLEANING (continued)
BES820 IB V6.indd 26BES820 IB V6.indd 26 19/9/07 2:23:58 PM19/9/07 2:23:58 PM

27
TROUBLE SHOOTING GUIDE
PROBLEM POSSIBLE CAUSES WHAT TO DO
When the machine is switched
on, the steam and hot water lights
are fl ashing.
Selector Control is not in ‘Standby’
position
Turn the Selector Control to ‘Standby’ position.
Machine will commence normal heat up
procedure.
Coffee does not run through Machine is not turned on or plugged in Ensure the machine is plugged in, switched on
at the power outlet and the POWER button is
pressed to ‘on’.
Water tank is empty Refer to ‘Filling The Water Tank’, page 14.
Coffee grind is too fi ne Ensure you use a suitable espresso grind. Refer to
‘The Grind’ on page 22.
Too much coffee in the fi lter Refer to ‘Preparing The Coffee’, page 15.
Coffee tamped too fi rmly Refer to ‘Tamping The Coffee’, page 15.
The fi lter is blocked Use the fi ne pin on the cleaning tool to clear the
holes. Refer to ‘Cleaning The Filters’, page 24.
Coffee runs out too quickly The coffee grind is too coarse Ensure you use a suitable espresso grind. Refer to
‘The Grind’ on page 22.
Not enough ground coffee in the fi lter Refer to ‘Preparing The Coffee’, page 15.
Ground coffee not tamped fi rmly enough Refer to ‘Preparing The Coffee’, page 15.
Coffee is too cold Cups not preheated The cup warming plate starts to warm up as the
machine warms up. Refer to ‘Pre-Warming The Cups’,
page 14.
Milk not heated enough (if making a
cappuccino or latté)
When the base of the jug becomes too hot to
touch this is when the milk is heated at the correct
temperature. Refer to ‘How To Texture Milk For A
Cappuccino Or Latté’ page 19.
BES820 IB V6.indd 27BES820 IB V6.indd 27 19/9/07 2:23:58 PM19/9/07 2:23:58 PM

28
PROBLEM POSSIBLE CAUSES WHAT TO DO
No créma Coffee is not tamped fi rmly enough Refer to ‘Tamping The Coffee’, page 15.
Coffee grind is too coarse Ensure you use a suitable espresso grind. Refer to
‘The Grind’ on page 22.
Ground coffee is not fresh Pre-ground coffee should not be kept for longer
than a week. Refer to ‘The Grind’ on page 15.
Filter holes are blocked Use the fi ne pin on the cleaning tool to clear the
holes. Refer to ‘Cleaning The Filters’, page 24.
Machine is making pulsing/
pumping sound while extracting
coffee or steaming milk
The machine is carrying out the normal
operation of the 15 bar pump
No action require as this is the normal operation of
the machine.
Coffee runs out around the edge
of the fi lter holder
Filter holder is not inserted in the brew
head properly
Refer to ‘Inserting The Filter Holder’, page 16.
There are coffee grounds around the
fi lter rim
Clean any excess ground coffee from the rim of
the fi lter holder to ensure a proper fi t into the brew
head.
Too much ground coffee in the fi lter Refer to ‘Preparing The Coffee’, page 15.
Ground coffee has been tamped too fi rmly Refer to ‘Tamping The Coffee’, page 15.
Incorrect fi lter for amount of ground
coffee used
Ensure you use the small fi lter for 1 cup of coffee
and the larger fi lter for 2 cups of coffee.
Coffee fi lters out in drops from
the fi lter holder
The water tank is empty or low Refer to step 1 – ‘Filling The Water Tank’, page 14.
Coffee grind is too fi ne Ensure you use a suitable espresso grind. Refer to
‘The Grind’ on page 22.
Machine is blocked by mineral deposits Decalcify the machine. Refer to ‘Decalcifying’, page
26.
BES820 IB V6.indd 28BES820 IB V6.indd 28 19/9/07 2:23:58 PM19/9/07 2:23:58 PM

29
PROBLEM POSSIBLE CAUSES WHAT TO DO
Machine is making a loud and
continuous pumping noise
Water tank is empty Refer to step 1 – ‘Filling The Water Tank’, page 14 .
Water tank is not securely in place Refer to step 1 – ‘Filling The Water Tank’, page 14 .
Coffee is too weak or watery Coffee grind is not fi ne enough Ensure you use a suitable espresso grind. Use
a dark roast coffee generally labelled ‘Espresso
Blend’. Refer to ‘The Grind’ on page 22.
No steam/hot water is generated Machine is not turned on Ensure the machine is plugged in, switched on
at the power outlet and the POWER button is
pressed to ‘on’.
Water tank is empty Refer to step 1 – ‘Filling The Water Tank’, page 14.
Selector Control is not in ‘Steam’ or ‘Hot
Water’ position
Turn the selector control to the ‘Steam’ or ‘Hot
Water’ position.
Steam Wand is blocked Use the pin on the cleaning tool to clear the
opening. If the steam wand continues to be
blocked remove the tip of the steam wand using
the spanner in the middle of the cleaning tool. Refer
to ‘Care and Cleaning’, page 24.
Milk is not foamy after texturing Not enough steam Steam wand may be blocked. Refer to “Care and
Cleaning’, page 24.
Milk is not fresh and cold Milk must be cold and fresh. Refer to ‘How To
Texture Milk For A Cappuccino Or Latté’, page 19.
Machine is not working The unit appears to be ‘on’ but the
machine ceases to operate
The safety thermal-cut may have activated due to
the pump overheating. Turn the machine off and
allow it to cool for about 30-60 minutes.
BES820 IB V6.indd 29BES820 IB V6.indd 29 19/9/07 2:23:59 PM19/9/07 2:23:59 PM

30
COFFEES TO TRY
ESPRESSO
Intense and aromatic, an espresso or short
black as it’s also known uses about 7g of
ground coffee. It is served in a small cup or
glass to a level of approximately 30ml.
LONG BLACK
A long black is generally served as a
standard espresso with hot water added
to taste.
FLAT WHITE
A single dose of espresso in a cup topped
with steamed milk, 1⁄3 coffee and 1⁄3 milk.
BES820 IB V6.indd 30BES820 IB V6.indd 30 19/9/07 2:23:59 PM19/9/07 2:23:59 PM

31
COFFEES TO TRY (continued)
CLASSIC CAFE LATTÉ
Traditionally the morning coffee of Italy and
France, taken with pain au chocolate or
sweet biscotti. This blend of 1⁄3 espresso
to 2⁄3 milk is made with a single shot of
espresso. Top with steamed milk, poured
down the inside rim of the glass to give a
creamy consistency and perfect layer of
froth.
CAPPUCCINO
The real thing is served very light and luke
warm with 1⁄3 espresso to 1⁄3 steamed milk
and a generous fi nal third of creamy froth.
For added fi nesse, hold a piece of card
over one half of the cappuccino before
dusting with chocolate.
MACCHIATO
A shot of espresso served short in a 70ml
demitasse and stained with a dash of fi nely
frothed milk.
BES820 IB V6.indd 31BES820 IB V6.indd 31 19/9/07 2:23:59 PM19/9/07 2:23:59 PM

32
COFFEES TO TRY (continued)
MOCHA FRAPPE (SERVES TWO)
Ready in minutes this impressive refresher
will delight chocolate and coffee drinkers
alike. Melt two heaped teaspoons of
quality chocolate bits into a double shot
of espresso. Add ½ cup cold milk and 9
ice cubes and process in blender on a low
speed to a smooth, velvety consistency.
Pour evenly into two glasses and serve
immediately.
ESPRESSO AFFOGATO
Totally irresistible, this sweet temptation is
simply a single scoop of premium vanilla
bean ice cream, drenched in espresso and
if desired, your favourite liqueur. To create
a sense of occasion, serve ice cream in a
martini glass with shots on the side.
CON PANNA
Meaning ‘with cream’ this heart warmer is
a chic variation on old-fashioned Vienna
Coffee. In a 90-120ml cup, dress a double
shot of espresso with a dollop of fresh
cream, whipped until glossy. Dust with
cinnamon and serve immediately.
BES820 IB V6.indd 32BES820 IB V6.indd 32 19/9/07 2:24:01 PM19/9/07 2:24:01 PM

33
Recipes
BES820 IB V6.indd 33BES820 IB V6.indd 33 19/9/07 2:24:03 PM19/9/07 2:24:03 PM

34
DESSERTS
BAKED CUSTARDS WITH FRESH RASPBERRY AND COFFEE
FLOAT
Serves 6
750ml cream
3⁄4 cup caster sugar
2 vanilla beans, cut lengthways
1 tablespoon gelatine
1 punnet fresh raspberries
1 tablespoon caster sugar, extra
3⁄4 cup strong espresso coffee, cooled
1. Combine the cream, caster sugar and vanilla beans in a saucepan. Stir
over medium heat until just boiling. Remove the vanilla beans.
2. Add the gelatine and stir constantly with a wooden spoon until
dissolved. Remove from heat. Allow the custard to cool.
3. Pour custard evenly into 6x150ml glasses. Refrigerate for minimum 3
hours or until set.
4. Place the raspberries into a medium sized bowl, sprinkle with sugar and
crush lightly with a fork.
5. Fold the cooled coffee through the crushed raspberries. Cover and chill
in the refrigerator.
6. To serve, top the custards, when set, with the raspberries and coffee
mixture.
7. Serve immediately with freshly brewed coffee.
TIRAMISU
Makes 4
11⁄2 cups mascarpone
11⁄4 cups cream
21⁄2 tablespoons icing sugar
1⁄2 cup strong espresso coffee, cooled
1⁄2 cup Tia Maria or coffee liqueur
16 sponge fi ngers
Cocoa powder, for dusting
1. Combine mascarpone, cream and icing sugar in a large bowl. Whisk
lightly until soft peaks form. Set aside.
2. Combine coffee and liqueur in bowl. Dip the sponge fi ngers into the
coffee mixture a few at a time. Ensure all the coffee mixture is absorbed
evenly by the sponge fi ngers.
3. Layer half the sponge fi ngers evenly into the base of 4 dessert bowls or
glasses. Spread the layered sponge fi ngers with half of the cream
mixture. Repeat the layers with remaining sponge fi ngers and cream
mixture.
4. Dust evenly with cocoa powder and refrigerate until required.
5. Serve with fresh fruits and freshly brewed espresso coffee.
BES820 IB V6.indd 34BES820 IB V6.indd 34 19/9/07 2:24:04 PM19/9/07 2:24:04 PM

35
COFFEE, CINNAMON AND WALNUT MUFFINS
Makes 12
21⁄2 cups/375g plain fl our
2 teaspoons baking powder
1 teaspoon ground cinnamon
3⁄4 cup caster sugar
1 cup sour cream
2x60g eggs
1 teaspoon fi nely grated lemon rind
1⁄3 cup olive oil
3⁄4 cup strong espresso coffee, cooled
1 cup roughly chopped walnuts
1. Sift fl our, baking powder and cinnamon into a large bowl and stir in
sugar.
2. Place sour cream, eggs, lemon rind, oil and espresso coffee into a
medium bowl, stir until well combined.
3. Fold creamed mixture and walnuts into the sifted ingredients, do not
over mix.
4. Spoon the mixture evenly into 12 lightly greased and base lined muffi n
pans until two-thirds full.
5. Place into a preheated oven 180°C for 12-15 minutes or until cooked
when tested.
8. Serve warm, or cooled and spread with Rich Coffee Icing. Delicious with
a Cappuccino or Café Latté.
RICH COFFEE ICING
2 cups icing sugar, sifted
1 tablespoon butter, softened
1⁄4 cup strong espresso coffee, warm
1. Combine icing sugar, butter and half the coffee in a bowl, stir well and
gradually add remaining coffee until a spreadable consistency is
achieved.
DESSERTS (continued)
BES820 IB V6.indd 35BES820 IB V6.indd 35 19/9/07 2:24:04 PM19/9/07 2:24:04 PM

36
BES820
Issue 1/07
Australian Customers
Mail: Breville Customer
Service Centre
PO Box 22
Botany
NSW 2019
AUSTRALIA
Phone: Customer Service:
1300 139 798
Fax: (02) 9384 9601
Email: Customer Service
askus@breville.com.au
New Zealand Customers
Mail: Breville Customer
Service Centre
Private Bag 94411
Greenmount
Auckland
New Zealand
Phone: Customer Service:
09 271 3980
Fax: 0800 288 513
Email: Customer Service
askus@breville.com.au
Breville Customer Service Centre
www.breville.com.au
Breville is a registered trademark of Breville Pty Ltd. A.B.N. 98 000 092 928
Professional Collection is a trademark of Breville Pty Ltd
Head Offi ce Building 2, Port Air Industrial Estate,
1A Hale Street, Botany, NSW, 2019 Australia Tel 1300 139 798
20 Mono Place, Ellerslie, Auckland, New Zealand
Private Bag 94411, Greenmount, Auckland Tel 09 271 3980
Due to continued product improvement, the products illustrated/photographed in this brochure may vary
slightly from the actual product.
BES820 IB V6.indd 36BES820 IB V6.indd 36 19/9/07 2:24:04 PM19/9/07 2:24:04 PM
