Brightstar GP855 GSM Fixed Wireless Phone User Manual
Brightstar Corporation GSM Fixed Wireless Phone
User Manual
Congratulations on the purchase of your GP855 product!
Please retain your original dated sales receipt for your records.
For warranty service of your GP855 product, you will need to provide a
copy
of your dated sales receipt to confirm warranty status.
Thank you for choosing a Avvio product.
Please read important safety instructions before using.
Read and understand all instructions before using.
Please retain this guide for future reference.
The information contained in the GP855 user guide is believed to be
correct
at the time of printing. We reserve the right to change or modify any
information,
product specifications, features or functionality without notice. The
contents of
the GP855 user guide are provided “as is.” Certain features may not be
activated by your service provider, and/or their network settings may
limit the
feature’s functionality. Additionally, certain features may require a
subscription.
Contact your service provider for details.
PREFACE CONTENTS
WELCOME
27CLEAR ALL RECORDS
20USING PHONE MENUS
17BASIC OPERATION
17
BASIC FUNCTION
15DISPLAY INDICATORS AND ICONS
13KEY FUNCTION
27COPY
26SPEED DIAL
26SERVICE DIAL
26MEMORY STATUS
26ADD
25READ
25THE CONTACTS
23OVERVIEW OF MENU TREE
23
MAIN MENU
21ENTER LETTERS AND NUMBERS
11INSTALLATION
10PHONE OVERVIEW
10
ABOUT YOUR PHONES
9PACKAGE CONTENTS
9
PACKAGE CONTENTS
6SAFETY INFORMATION
5PRECAUTIONS
5
SAFETY PRECAUTIONS
1 2
CONTENTS CONTENTS
CALENDAR
ALARM
REFERENCE INFORMATION
CALCULATOR
TECHNICAL INFORMATION
TROUBEL SHOOTING 46
45
45
43
42
42
42APPLICATIONS
CALL DURATION
FACTORY DEFAULT
GROUP
NETWORK SETUP
OUTGOING CALL
MESSAGE SETTINGS
33DIAL DECORDS
32MEMORY STATUS
31
31BROADCAST MESSAGE
31VOICEMAIL
41
40SECURITY SETUP
39
37CALL SETUP
37DISPLAY
36MELODY
35PHONE SETTINGS
35SETTINGS
34
34MISSED CALL
33
33INCOMING CALL
31DRAFTS
30OUTBOX
30INBOX
29WRITE NEW
29MESSAGE
28MY NUMBER
27
3 4
1. Please do not try to take out the SIM card of this phone.
This SIM card is a special encrypt card, it cannot be used in other mobile
phones. It’s the warranty of the product, if you try to rip or remove the SIM
Card, the warrant will be not valid and your product will not be warranty in
any case.
2. Please do not turn around the antenna at will, in order to avoid create
the damage of antenna.
3. Keep the phone away from water and damp areas.
Water or other liquids may cause overheating, electrical leakage, and failure
of the phone.
4. Do not try to disassemble the phone.
This can cause electric shock and failure of the phone. Tampering will also
void the phone’s warranty.
5. Put the phone in a safe and stable place.
6. Keep away from dust and heat radiation (i.e. microwaves, stoves, etc.)
7. Try to use the phone away from ordinary telephones, television sets, radios,
and automated office equipment to avoid interference between the devices.
8. Use clean soft dry cloth to wipe the phone. Do not use any chemical agents.
9. Do not put the phone near explosive or inflammable materials.
10. Use the phone only within the temperature range of -20°C~60°C and
humidity range of 0%~90%.
11. Keep all accessories or batteries out of the reach of small Children or babies.
Please instruct children the proper ways of handling phone during usage.
Shock circuit or breakdown may occur and may cause severe danger to
usersdue to improper usage.
SAFETY PRECAUTIONS SAFETY PRECAUTIONS
PRECAUTIONS
1. EXPOSURE TO RADIO FREQUENCY (RF) ENERGY
Your phone contains a transmitter and a receiver. When it is ON, it receives and
also sends out radio frequency (RF) signals. When you communicate with your
phone, the system handling your call controls the power level at which your
phone transmits.
Your phone is designed to comply with local regulatory requirements in your
country concerning exposure of human beings to RF energy.
2. OPERATIONAL PRECAUTIONS
To assure optimal phone performance and make sure human exposure to RF
energy is within the guidelines set forth in the relevant standards; always adhere
to the following procedures.
3. EXTERNAL ANTENNA CARE
Use only the supplied Avvio approved antenna. Unauthorized antennas,
modifications, or attachments could damage the phone.
Do NOT hold the antenna when the phone is IN USE. Holding the antenna
affects call quality and may cause the phone to operate at a higher power level
than needed. In addition, use of unauthorized antennas may result in non-
compliance with the local regulatory requirements in your country.
4. PHONE OPERATION
When placing or receiving a phone call, hold your phone as you would use a
wireless telephone.
To maintain compliance with RF energy exposure guidelines, ensure the phone
antenna is at least 10 inches (25 centimeters) from your body when transmitting.
5. APPROVED ACCESSORIES
Use of accessories not approved by Avvio, including but not limited to
batteries and antennas, may cause your phone to exceed RF energy exposure
guidelines.
SAFETY INFORMATION
5 6
Your battery or phone may containssymbols, defined as follows.
Please don’t use any damaged battery or charger and use the battery only for
its intended purpose.
Don’t apply extreme shock to the battery. It’s dangerous to disassemble a
battery or to apply extreme shock to the battery via nail or heavy metal objects.
Keep the charger or batteries out of reach of small children or babies.
Always try to keep the battery between -10 ~ 55 Celsius.
Use only manufacturer approved rechargeable batteries and charger designated
for this devise
9. Seizures / Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when watching television or playing video
games. These seizures or blackouts may occur even if a person never had a
previous seizure or blackout.
If you experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult with your doctor.
6. RF ENERGY INTERFERENCE / COMPATIBILITIES
Nearly every electronic device is susceptible to RF energy interference from
external sources if inadequately shielded, designed, or otherwise configured for
RF energy compatibility. In some circumstances your phone may cause
interference.
7. MEDICAL DEVICES
1) Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 10 inches
(25 centimeters) be maintained between the fixed wireless phone and a
pacemaker.
Persons with pacemakers should:
Always keep the phone more than 8 inches (20 centimeters) from your
pacemaker when the phone is turned ON.
Turn OFF the phone immediately if you have any reason to suspect that
interference is taking place.
2) Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event
of such interference, you may want to consult your hearing aid manufacturer to
discuss alternatives.
3) Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your
device to determine if it is adequately shielded from RF energy. Your physician
may be able to assist you in obtaining this information.
8. BATTERIES
Batteries can cause property damage and / or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touches exposed
terminals. The conductive material may complete an electrical circuit (short
circuit) and become quite hot. Exercise care in handling any charged battery,
particularly when placing it inside a pocket, purse or other container with metal
objects. Use only original batteries and chargers.
SAFETY AND GENERAL INFORMATION SAFETY AND GENERAL INFORMATION
Your battery or phone should not be thrown in the trash
Your battery or phone may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information
Your battery or phone should not be disposed of in a
fire
Important safety information will follow
7 8
Transceiver / Phone Handset Handset Cord
Adapter / Charger Antenna Backup Battery
The appearance of the parts in your package may be different from those in this
manual
Package contents may vary by market. Please check with your service provider.
PACKAGE CONTENTS ABOUT YOUR PHONES
PACKAGE CONTENTS PHONE OVERVIEW
Send / Answer / Call Key6Dual Band Antenna5
Microphone14Coil Cord13
Dial / Numeric Key12Receiver of Handset11
Speaker10Speaker Phone Key9
SMS Key8End / Power on off Key7
Scroll / Navigation Key
( Up, Down, Right, Left )
4Contacts / Back / Cancel /
Right soft Key
3
Menu / OK / Option / Left
soft Key
2LCD Display1
DescriptionNoDescriptionNo
910
[ 1 ] installing Coil Cord
Connect the coil cord to both the handset and the transceiver ( phone ).
[ 2 ] Installing Antenna
Install the antenna to the antenna connector. Hold the plastic portion of the
antenna and turn the metal screw clock-wise.
[ 3 ] Plugging AC/DC Adapter
Connect the adaptor to the AC Wall outlet.
[ 4 ] SIM Card and battery
1) Remove the battery door.
2) Insert SIM card into the SIM slot in the right direction
3) Connect the rechargeable battery pack into the battery plug
4) Replace the battery door.
[5 ] Turning Phone’s Power On/Off
After installing the handset correctly, press the power key which is on the right
of the front panel for about 3 seconds, the phone will then automatically test
whether the SIM Card is inserted and valid. Wait for the antenna icon to display
indicator bars before you make a call.
1) When the battery icon is empty, connect the external power adapter’s barrel
connector to the external power input on back panel of unit.
2) Plug the external power adapter into the power socket. The unit will power
up automatically.
3) Check the cellular signal strength and move the unit until the best signal
possible is achieved.
4) In state of power-on, press and hold power key button, LCD screen closes.
ABOUT YOUR PHONES ABOUT YOUR PHONES
INSTALLATION
Note :
The battery pack is a backup for emergencies in case of a power failure.
Do not operate the phone without having the AC/DC adaptor connected.
Be sure to carefully match the positive and negative terminals as shown
on the battery. When using the phone for the first time, charge it for over
6 hours to ensure optimum battery charge.
Caution :
It is prohibited to use the SIM card for this Fixed Wireless Phone in other
GSM phone. Once the SIM pin number has entered, the SIM pin maybe
automatically changed so the initial PIN is no longer valid. Therefore, it is
highly recommended
NOT to take out the SIM card once it has installed in this product.
DO NOT bend or scratch your SIM card, and avoid exposing it to static
electricity, water, or dirt.
12
11 12
4
3
[ 1 ] Left / Right Soft Key ( Menu / Contacts key )
Press the left soft key ( Menu ) to perform the function indicated by the
text on the screen above the key.
Press the right key ( Contacts ) to directly access the Contacts list.
[ 2 ] Send key
Press to make a call to a name / number shown on the screen.
Press to answer a call.
Press and hold for 1 second to access the list of recently dialed
numbers.
[ 3 ] End key
Press to end a call.
Press once to exit a function and return to the idle screen.
[ 4 ] Numeric Keys / ‘*’ keys/ ‘#’ Keys
Used for entering numbers and letters.
Press and hold to call the voice mailbox.
Press to toggle between upper case, lower case and numeric modes.
Press to toggle between letters and symbols.
[ 5 ] Navigation / Scroll keys
Press left / right navigation key to increase or decrease ring volume.
Press up navigation key to select dial records.
Press down navigation key to Calculator function.
Press this key to press up / down the phone’s menu.
Press to move the cursor when entering letters.
[ 6 ] SMS Key
Press to enter ‘write new message’ function in idle mode
[ 7 ] Speaker key
If you are using the handset to call and you want to transfer the call to the
speakerphone mode, press the Speaker key button and hang up the
receiver to transfer the call to the speakerphone.
ABOUT YOUR PHONES ABOUT YOUR PHONES
KEY FUNCTION
Note :
The functions of the soft keys depend on the guiding text shown
above the keys. For example, when the text Menu is above the left soft
key, press , and the left key enters the menu functions. Similarly, press the
right soft key under the text Contacts accesses the Contact list functions.
13 14
The display indicators and icons provide informationsabout the operation of the
phone.
The start screen is displayed when the phone is turned ON. Several features
can be used only when the phone is at the start screen.
ABOUT YOUR PHONES ABOUT YOUR PHONES
DISPLAY INDICATORS AND ICONS
Contacts / Messages stored in Phone
Contacts / Messages stored in SIM card
Unread SMS
Sent SMS
SMS read already
Received New message
Voice message
Call Divert
Alarm Indicator : shows when the alarm is activated
Battery Level indicator
Volume tone Indicator
Indicate the tones of the Volume
Signal Strength Indicator
Indicate the strength of the network signal
15 16
[ 1 ] Switching the phone ON and OFF
1) To turn on your phone, press and hold “End key” for a few
seconds or until the display turns on.
2) To turn off your phone, press and hold “End key” for a few seconds
[ 2 ] Making a call
1) Dial a Call
Raise your receiver and enter phone number which you want to call
After entering phone number and press “Call key” to make a call.
2) Dial the Fixed Phone Extension Number
Some fixed phone extension can’t be called directly, it need a phone
exchange. If you input the pause character ‘P’ between the exchange phone
number and extension number, the phone will finish the dial procedure,
connect to the extension. To get the “P”, press the “＊” key for a while till the
“P” displayed on the phone screen.
3) Dial a International Call
Press the “＊”key till the char “+” displayed on the phone screen.
Input the country code and the phone number after the prefix.
4) Dial From Contacts
Press the right soft key to get into the phone book. Press Up / Dow
navigation key to scroll the list to search the caller’s name. Then press call
key to make a call.
5) Speed Dial
Press 2-9 keys for a while, the phone number stored in speed dial list will be
sent out. Make sure the speed dial key has been set up.
[ 3 ] Answering a call
When your phone rings, just raise your receiver to answer, or press “Call key”
or “Speaker key” to answer in speaker phone mode.
[ 4 ] Speaker mode.
You can make or answer a phone call by pressing Speaker key when the
handset is on the base.
To make a call:
1) Press Speaker key to turn ON the speaker phone mode.
2) If you hear the dial tone, press the number you want to connect to.
3) Press Send key
To answer a call
When the phone rings, press Speaker key to turn ON the speaker phone
mode.
[ 5 ] Adjusting the Ring Volume
You can adjust the ring tone volume by pressing the scroll keys on the phone.
1) Press left / right navigation key up to enter the ring volume
control screen.
2) Press right navigation key to increase the volume.
3) Press left navigation key to decrease the volume.
[ 6 ] Redialing the last-dialed number
The phone stores up to 10 last dialed numbers.
1) Press Send key for a second to find the most recently dialed numbers.
2) Press navigation key to scroll to the number you wish to dial.
3) Press Send key once.
BASIC FUNCTION BASIC FUNCTION
BASIC OPERATION
Tip: In some menus like Contacts, Dial Records, etc. which have
individual phone number, Press “Call key” directly to make a
call.
Note: The call is automatically made without pressing, approximately
3 seconds after you dial the number.
Note : If no recently dialed numbers are stored, you will not be able
to use this function.
17 18
[ 7 ] Caller ID
Requires a subscription to a calling plan that supports this feature. Not available
in all areas. Contact you telephone service provider for availability and details.
When Caller ID is active, your phone shows the caller’s phone number during
an incoming call, as long as this number is a part of your service provider’s
wireless network.
The wireless network lets you know if it does not recognize the caller’s phone
number.
The wireless network will also let you know if the calling party has blocked the
Caller ID feature.
If you have stored the name and number of the calling party in your Contacts
and that number is supported by the wireless network, the caller’s name will
also appear.
[ 8 ] SMS and Voice Mail
Requires a subscription to a calling plan that supports this feature. Not available
in all areas. Contact you telephone service provider for availability and details.
A new SMS arrives:
The back light of the LCD is ON and the display shows “New Message, Read
Now ?” text message with SMS icon . And if you want to read received new
Message, press the left soft key ( Yes ). If you want to check message later,
press the right soft key ( No ).
Voice mail arrives :
The back light of the LCD is ON and the display shows “New Voice Message,
Listen Now ?” text message with Voicemail icon . And if you want to check
new voice message, press the left soft key ( Yes ). If you want to check
message later, press the right soft key ( No ).
[ 1 ] Menus
A menu is a list of choices you can make. Your phone has 5 menus. ( And your
service provider may add STK menu extra depending on network service )
Each menu contains options that allow you to use the message, change the
ring tone, etc.
You can use menus and sub-menus in two ways: by scrolling or by using
shortcuts.
[ 2 ] Scrolling through menus
1) From the Start screen, press Menu, and then scroll through the menus using
up / down navigation key.
2) Use the scroll and OK key to select the submenus and back key to return to
the Start screen.
[ 3 ] Exiting menu levels
1) To return to the previous menu level, press Back key or Cancel key.
2) To return to the Start screen, press End key. No menu setting changes
will be saved.
[ 4 ] Menu Tree
You can refer to 23 pages about Menu tree for more details.
[ 5 ] Using shortcuts through menus
1) Contacts : press the right soft key directly
2) Dial Records : press up navigation key directly.
3) Calculator : press down navigation key directly.
4) Write New ( Message ) : press SMS key directly.
5) Outgoing call : press Call key one time for a second.
BASIC FUNCTION BASIC FUNCTION
USING PHONE MENUS
19 20
You can enter letters, as well as numbers, when storing information in your
phone by using your phone’s keypad. To enter letters, press the key associated
with the letter you wish to enter until it appears on the screen (numbers will also
appear).
[ 1 ] Entering Letters
When you want to add new names or when you view names in the Contacts,
your phone automatically switches to the abc ( ABC ) mode and displays the
abc icon on the right upper side in Display .
Key Characters Key Characters
* : abc ÎAbc ÎABC Î123 rotated
[ 2 ] Editing name or phone number
To edit a name already stored in the Contacts:
1) From the main screen, use the right soft key.
2) From the Contacts list ( Read ), select the name you want to edit by scrolling
up / down navigation key and press OK key.
3) To edit, press the left soft key and scroll down to the edit option and press
OK key .
4) Edit the name you want to change and / or press again OK key to change
the phone number .
5) Press up or left navigation key to scroll the cursor to the left.
6) Press down or right navigation key to scroll the cursor to the right.
7) Press Clear to correct any mistakes.
8) Press the left soft key OK to save changes or the right soft key to cancel.
[ 3 ] Changing the case of letters and numbers
You can switch the mode among uppercase and lowercase letters and numbers
by pressing # key.
BASIC FUNCTION BASIC FUNCTION
ENTER LETTERS AND NUMBERS
Change letter case( * )#, . ‘ ? ! “ @ ￥$ _ ‘ ˆ { }
[ ∼] | # ¤ % & ( ) * + - / : ;
< = > ¡ §¿
*
(Space) 00w x y z 99
t u v 8 ù ü8p q r s 7 β$7
m n o 6 ö ø ò ñ6j k l 5 £5
g h i 4 ì4d e f 3 è é3
a b c 2 å æ ä à ç2, . ? ! 11
CharactersKeyCharactersKey
21 22
Your phone’s menu may differ from the following list, depending on the
Network services to which you have subscribed and the accessories you
are using. If you have any questions, please call your service provider.
1. Contacts 2. Message
1. Read 1. Write New
2. Add 2. Inbox
1) Save to SIM 3. Outbox
2) Save to Phone 4. Drafts
3. Memory Status 5. Voice mail
4. Service dial 1) Number
5. Speed dial 2) Clear
6. Copy 3) Call Voice mail
1) SIM to Phone 6. Broadcast Message
2) Phone to SIM 1) Receive Mode
7. Clear all records 2) Languages
1) Phone Records 7. Message Settings
2) SIM Records 1) Service center number
8. Group 2) Expire Period
1) Family 3) Message Type
2) Friends 4) Status Report
3) Office 5) Alert Period
4) Others 8. Memory Status
9. My Number
3. Dial Records
1. Incoming Call
2. Outgoing Call
3. Missed Call
4. Call Duration
4. Settings 5. Applications
1. Phone Setting 1. Alarm
1) Clock Settings 1) Alarm 1
2) Language 2) Alarm 2
3) Answer Mode 3) Alarm 3
2. Melody 2. Calculator
1) Melody Setup 3. Calendar
2) Volume
3. Display
1) Idle Display
2) Contrast
3) Backlight
4. Call Setup
1) Call Divert
2) Call Barring
3) Call Waiting
4) Auto Redial
5) Caller ID
5. Network Setup
1) Network select mode
6. Security Setup
1) SIM PIN
2) Phone Lock
3) Change Password
7. Factory Default
MAIN MENU MAIN MENU
OVERVIEW OF MENU TREE
23 24
New entries can be stored in the SIM card or in your Phone.
You can store up to 100 entries in the phone and an additional 250 in the SIM
depending on the SIM limitations. Entries stored in the phone allow numbers of
up to 30 digits, and names of up to 16 characters.
In standby mode, you can press Right Soft key to immediately access
the Contacts list. When the name is found by pressing Contacts, press
OK and option key to select option sub menu ( you can choose to send
Message to, edit, clear, add to group, copy )
The Contacts has several menus to select from. These menus appear when you
press Menu ( Left Soft key ) and select Contacts menu by pressing OK
key. Press right soft key ( back ) to move back to the main menu.
Read : Show the names stored in phone and / or SIM card.
Add: Add new entry (s)
Memory Status: Memory status of phone and SIM
Service dial : Show the phone numbers provided by Service networks
Speed Dial: One button dialing
Copy: Copy from SIM (Phone) to Phone (SIM)
Clear All Records : Clear all Phone or SIM entries
Group: Organizing group of Contacts
My number: Inputting your own number
[ 1 ] Read (by name)
From the Contacts menu, select Read and press left OK key or just press 1.
Enter the first letters of the name you need and then the cursor goes to the
name you wanted directly after one second or select name using to scroll and
press left OK key
After choosing one of the name, you can select left option and you can choose
five sub menus.
Send Message To: You can send SMS to this entry
Edit : You can edit the name and number of this entry
Clear : You can delete this entry only ( You need to re-confirm )
Add to group: You can put this entry to group, but you cannot use SIM
entry to a group.
Copy: If you select a SIM card’s entry and select Copy, you can copy it
to phone memory. If your selection is Phone memory’s entry, Copy
means copy chosen entry to SIM card
[ 2 ] Adding a new Contacts Entry
To create a Contacts entry:
1) Press Menu > Contacts > Scroll to Add and press OK
2) Press Save To SIM or Save To Phone depending on where you want to
store the phone entry.
3) Add Name and press OK key
4) Add Number and press OK key
[ 3 ] Memory Status
To press ‘Memory Status’ and you can see the capacity of SIM card used / SIM
card total and Phone used / Phone total.
[ 4 ] Service dial
You can check or / and call service number provided by your network
Service. This menu may differ depending on the Network services to which you
have subscribed. Not available in all areas. Contact you telephone service
provider for availability and details.
[ 5 ] Speed Dial
1) Press Menu > Contacts
2) Scroll to Speed Dial and press OK
3) Select one entry. If the numbers are Empty, Press OK > Select Set/Change
and press OK, you can assign one phone number. After choosing one, press
OK
4) If you assigned one phone number already, you can see four sub categories
MAIN MENU MAIN MENU
THE CONTACTS
Using Contact Menus
25 26
Set / Changes : You can change the assigned number
Detail : You can see the number of this entry
Clear : You can delete this entry
Dial to : You can dial to this entry
[ 5 ] Copy
You can use this function to copy all numbers from the SIM card to your fixed
phone, or vice versa:
1) Press Menu > Contacts
2) Scroll to Copy and press OK
3) Press SIM to phone or Phone to SIM depending on where you want to copy
all Contacts entries.
4) Press YES, then the copy process is done promptly
[ 6 ] Clear All Records
You can delete all Contacts entries:
1) Press Menu > Contacts
2) Scroll to Clear all Records and press OK
3) Press Phone Records or SIM Records, depending on where you want to
delete all Contacts entries.
4) Press OK to confirm the deletion of all Contacts entries.
5) Select Yes if you want to delete. Otherwise, select No to go back to the
previous menu.
[ 7 ] Group
Contacts entries can be grouped to some units :
1) Press Menu > Contacts
2) Scroll to Group and press OK
3) And you can see four groups 1) Family 2) Friends 3) Office 4) Others
4) Select one and press left OK and you can see the sub menus
In one group, you can select three sub menus
Group Member: You can see entry (s) belongs to the group
Rename : You can edit the name of this group itself (Ex> Family Î
Home)
Alert Tone: You can change the tone when the member of this group
called you.
[ 8 ] My Number
You can check, edit, erase and save your owner number
1) Press Menu > Contacts
2) Scroll to My number and select Line 1 Number or Line 2 Number
3) Save, edit, clear your own number and press OK
MAIN MENU MAIN MENU
Caution : When complete all information stored in your Contacts
will be deleted and can no longer be restored.
27 28
You can use only phone entries (No SIM entries) and appoint 8 entries.
On the idle display, press one assigned button and press Call button
or press one assigned number for about 3 seconds till make a call.
Ex> If the number assigned in 2 is 01-34-567, just press 2 and Call
button
Requires a subscription to a calling plan that supports this feature. Not available
in all areas. Contact you telephone service provider for availability and details.
You can send or receive text messages with your phone. Text messages that
you receive may contain ring tones that you can store in your phone. It supports
160 characters.
You can also send maximum about 600 characters. If your message is about
600 characters, the phone divides your message into four parts and send these
in each time. This function is called SMS concatenation.
After completing the message content, you can choose to send it out right away,
or save it as a draft.
Write New
Inbox
Outbox
Drafts
Voice Mail
Broadcast Message
Message Settings
Memory Status
[ 1 ] Write New
You can send a text message to one recipient. You can manually enter each
recipient’s phone number, or you can select the numbers from the Contacts.
1) Press Menu > Message> OK.
2) Scroll to Write New and press OK
3) You can create the message.
4) When you press OK, you can see three submenus;
Only Send : After sending, the message is deleted
Only save : No sending. The message is saved into Drafts.
Send and Save : After sending the message is saved into Outbox
[ 2 ] Inbox
When a message arrives, a pop-up message is displayed and a new message
icon appears. You can read it immediately, or read it later in your Inbox. You
can see the icon
1) Press Menu > Message.
2) Scroll to the Inbox and press OK.
3) From the list, highlight the one you need and press OK.
4) You can choose six options
Reply : You can reply your messages.
Forward : You can forward the chosen message
Edit: You can edit the chosen message.
Clear : You can delete the chosen one.
Clear All: You can empty the Inbox
Cut Number : You can cut and save the phone number from Inbox
message
[ 3 ] Outbox
The Outbox stores messages sent and saved.
1) Press Menu > Message.
2) Scroll to the Outbox and press OK.
3) From the list, highlight the one you need and press OK.
4) You can choose six options
Send: You can send the chosen message.
Forward : You can forward the chosen message to others
Edit: You can edit the chosen message.
Clear : You can delete the chosen one.
Clear All: You can empty the Out box
MAIN MENU MAIN MENU
MESSAGE
Note: The maximum length of a text message differs, depending on
the capabilities of the network from which it originated.
Also, text messages may appear different at different times
because messages can originate in networks other than your
own. Contact your service provider for more information about
this feature.
29 30
Cut Number : You can cut and save the phone number from outbox
message.
[ 4 ] Drafts
You can see draft messages which you already saved. After choosing one of
them, you can have four choices
Forward: You can send the chosen message.
Edit: You can edit and save the chosen message.
Clear : You can delete the chosen one.
Clear All: You can empty the draft box.
[ 5 ] Voicemail (Network Service)
You can listen to your voicemail messages by calling your network voicemail
phone number. Voicemail messages are stored in the network voicemail box,
not in your phone. Also refer to [ 8 ] section in 19page.
1) Press MENU > Message.
2) Scroll to Voice Mail and press OK.
3) There are three submenus. Select one and press OK
Number: Enter or modify the network service number.
Clear: Delete Pre-saved service number
Call Voice Mail: Dial the network service number and connect to the
Voicemail Server.
[ 6 ] Broadcast Message
There are 2 submenus you can choose
Receive Mode
Languages
[ 7 ] Message Settings
There are 5 submenus you can choose.
Service Center Number: The SMS Center Number is required in order
to send messages. Ask your service provider for this number.
Expire Period: Set the period of time the message is stored in the
service center. You can set the period for 1 hour, 12 hours, 1 day, 1
week, maximum. When the set period expires, the service center will
delete all messages, even if the user has not received the message.
Message Type: When you set the message type, the network will
convert the message to the type you have set. (Text//Fax//E-mail)
Status Report: If you turn On this option, you can be notified if the
recipient read your message.
Alert Period: you can choose message alert time with one time // Every
2 min // Off when we receive new message.
[ 8 ] Memory Status
Check memory status in the SIM and in the Phone. The total capacity of
SIM is 50, total capacity of phone is 100. Also you can see used area of
SIM and phone.
MAIN MENU MAIN MENU
Note : After the SMS memory in the Phone is full, the phone starts
using the memory in the SIM card.
31 32
The Call History function keeps track of:
Incoming Calls
Outgoing Calls
Missed Calls
Call Duration
When you miss a call (s), the Missed Calls message appears on your phone’s
screen. You can press Yes to view the Missed Calls list or press No to
ignore the message and go back to Standby. The records will be stored in Call
History. You are notified of missed calls only when your phone is turned ON in
the service area from which the missed call originated.
[ 1 ] Checking Incoming/Outgoing/Missed Call
1) Press Menu > Dial Records
2) Select Incoming // Outgoing // Missed Call and press OK
3) From the list of records, scroll the one you need
4) The screen shows Call Information including Number, Date and Time of
receiving.
[ 2 ] Call options
You can choose some options in related with Missed Calls, Dialed Calls or
Received Calls when you have any call log.
1) Press Menu > Dial Records
2) Choose one of them;
Incoming call / Outgoing call / Missed call and press OK
3) You can press left Option
4) You can see six different menus
Dial To: When you choose one entry and select OK, directly calls to.
Send Message To: You can send this entry the SMS message without
selecting recipient.
Clear : You can delete chosen entry
Save Number: You can save chosen number to SIM or Phone.
Clear all: You can delete all entries in the category (If you select
Outgoing call all the Outgoing call entries are deleted)
Show Number: You can see the number of chosen entry
[ 3 ] Call Duration
You can check the total duration of incoming call and last call duration
You can see Outgoing Duration, Incoming Duration and Last Call Duration
in one display.
The type of checking time is hh : mm : ss ( h: Hours, m: Minute, s: Second )
You can press left Reset to erase all call duration time.
MAIN MENU MAIN MENU
DIAL RECORDS
Note : Your phone can store up to 30 call numbers including missed,
received and dialed calls.
33 34
Setting menu includes:
Phone Settings
Melody
Display
Call Setup
Network Setup
Security Setup
Factory Default
[ 1 ] Phone Settings
[ 1.1 ] Clock settings
This menu guides you to set Time/Date.
Date & Time Setting : Set the correct time and date to ensure the Alarm is
working correctly.
Date & Time Setting
1) Press Menu > Settings > OK
2) Scroll Phone Settings and press OK.
3) Select Clock Settings then press OK.
4) Select Date & Time Setting and press OK.
5) Input month / day / year and hour/minute/am or pm by using numeric keys
and left and right navigation key
6) Press Save
Date Format : There are four types of expressions of dates
DD / MM / YY (day / month / last two digits of this year)
MM / DD / YY
DD / MM / YYYY (day / month / full digits of this year)
MM / DD / YYYY
Date Separator : There are four types of separators of date digits
OO-OO-OO (Hyphen)
OO/OO/OO (Slash)
OO.OO.OO (Dot)
OO OO OO (Blank)
Time Format:
You can choose 12h or 24 hours. For example, if the time is 1:22 pm ( 12h
expression) , it can be shown as 13:22 (24h expression)
[ 1.2 ] Language
Three languages options can be selected: English / Spanish ( Español ). Also
you may choose automatic option ; Your native language can be chosen without
manual selection.
1) Press Menu > Settings and press OK
2) Scroll Phone Settings and press OK
3) Select Language and then press OK
4) Select the language you need and press OK
[ 1.3 ] Answer Mode
Normal answer : You can press only answer key to receive the incoming call.
You can also can receive the incoming call by pick the handset up without press
any other key.
Any key answer : To answer your receiving call, you can press any key
except End key.
[ 2 ] Melody
[ 2.1 ] Melody setup
Set Melody for Incoming Call and Message Tone
[ 2.2 ] Volume
Eight volume levels are available for Call, ring tone and keypad tone. Adjust the
volume to your preference using left / right navigation key.
MAIN MENU MAIN MENU
SETTINGS
Note : For each tone setup, you can choose one of 10 ring tones for
Incoming call and 4 ring tones for Message Tone.
35 36
[ 3 ] Display
[ 3.1 ] Idle Display
Clock and Date
When you choose Enable, you can see the date and clock on your idle display
[ 3.2 ] Contrast
There are 20 levels for LCD contrast. Press right navigation key then the
contrast goes up. Press left navigation key then the contrast is down
[ 3.3 ] Backlight
Set Specific LCD and Keypad Backlight time.
1) Select Backlight and press OK
2) Toggle Always off, 5 sec, 15 sec, 30 sec or 45 sec and press OK
[ 4 ] Call Setup
The following features may require a subscription to a calling plan that supports
them.
Not available in all areas. Contact you telephone service provider for availability
and details
[ 4.1 ] Call Divert
Call Divert is a network or subscription dependent service. It allows you to
forward a call to another number, based on various conditions.
1) Press Menu >Settings and press OK
2) Scroll Call Setup and press OK
3) Press Call Divert and press OK
4) Select one of the options below, and then press OK
All Voice Calls : All incoming calls to a designated number.
On Busy : Divert all incoming calls when there is at least one call in
progress.
No Answer : Divert the incoming call if it is not answered
Unreachable : Divert all incoming calls when the phone is not reachable
due to a network error or some other reason.
5) Select Check Status, Activate, or Deactivate and press OK
Check Status: Check current Call Divert setting status.
Activate: Activate the chosen Call Divert option. Type the number you
want a call to be forwarded to.
Deactivate: Deactivate the chosen Call Divert option.
[ 4.2 ] Call Barring (Network Service)
Call Barring is a network or subscription dependent service.
This feature allows you to restrict or bar certain or all types of calls to and from
your phone.
1) Press Menu >Settings and press OK
2) Scroll Call Setup and press OK
3) Press Call Barring and press OK
4) Select one of the options below, and then press OK
All Outgoing Calls : Bar all outgoing calls.
All Calls abroad : Bar all outgoing international calls.
Abroad but Home: Prevent users from making any international calls
other than to home
All Incoming Calls: All Calls Bar all incoming calls.
Incoming While Roam: Bar all incoming calls when the phone is
roaming.
5) Select Check Status, Activate, Deactivate and press OK
Check Status: Check current Call Barring setting status.
Activate: the chosen Call Barring option.
Deactivate: Deactivate the chosen Call Barring option.
[ 4.3 ] Call waiting (Network service)
Call Waiting is a network or subscription dependent service.
If set to Activate, the Call Waiting feature enables the network to remind you of
other incoming calls during a call in progress.
MAIN MENU MAIN MENU
Note : To activate and deactivate Outgoing, Incoming, and Cancel
Calls, the SIM password may be required. Contact your service
provider.
37 38
1) Press Menu > Settings and press OK
2) Scroll Call Setup and press OK
3) Select Call Waiting and press OK
4) Select Check Status, Activate, Deactivate and then press OK
Check Status: Check current Call Waiting setting status.
Active: Activate Call Waiting function
Deactivate: Deactivate Call Waiting function.
[ 4.4 ] Auto Redial
Setting the Auto Redial to toggle enable, the phone to keep dialing if the called
party is not available.
1) Press Menu > Settings and press OK
2) Scroll Call Setup and press OK
3) Select Auto Redial and press OK
4) Toggle Enable or Disable, and then press OK
[ 4.5 ] Caller ID
Caller ID is a network or subscription dependent service.
You can choose to send/hide your phone number to/from the calling party.
1) Press Menu > Settings and press OK
2) Scroll Call Setup and press OK
3) Select Caller ID and press OK
4) Toggle Set by Network, Hide Number or Show Number and then press OK
Set By Network: Accepts the default value set by Network.
Show ID: Shows your phone number to the calling party.
Hide ID: Does not show your phone number to the calling party.
[ 5 ] Network Setup
Network Select mode
You can set the phone to automatically search the most suitable network to
camp on or to manually select the network you need.
1) Press Menu >Settings and press OK .
2) Scroll Network Setup and press OK
3) Select Network Select mode and press OK
4) Select Automatic selection or Manual selection and then press OK
[ 6 ] Security Setup
There are three options available:
SIM PIN : Prevent unauthorized use of the SIM card and or the some
features of services of telephone service provider
Phone Lock : Prevent unauthorized use of the phone.
Change Password : Change by inputting the password two times
[ 6.1 ] SIM PIN
SIM PIN ( SIM Personal Identification number ) is a four-to-eight digit numeric or
password. It is related with the service of your service provider. For more detail,
contact your service provider.
1) Press Menu > Settings and press OK
2) Scroll Security Set Up and press OK
3) Select SIM PIN and press OK
4) Select PIN Check, Change PIN1, Change PIN2 and then press OK.
PIN Check : Allow or disallow the use of SIM PIN by entering old SIM
PIN code
Change PIN 1 : This is a pin code that locks the SIM card until you enter
the correct code. The default code is set by the Service Provider. You
can change it if you like by entering defaulted PIN code by Service
provider, but make sure you don't forget the new code
Change PIN 2 : This SIM card code controls access to some of the
more advanced features of the phone. The default code is set by the
Service Provider. You can change it if you like by entering defaulted PIN
code by Service provider, but make sure you don't forget the new code.
Not all networks support pin 2.
MAIN MENU MAIN MENU
Manual mode : The phone starts searching available networks. Use
the up and down key to browse the network list, and press OK to set
the highlighted networks
Caution: If you unsuccessfully enter the SIM PIN code three times,
the SIM card will be Locked. And then contact your telephone
service provider to get PUK code to unlock SIM card.
39 40
[ 6.2 ] Phone Lock
The default password is “0000”.
1) Press Menu > Settings and press OK
2) Scroll Security Set Up and press OK
3) Select Phone Lock and press OK
4) When ‘On’ is chosen, there are two options.
Verify when Power-on: Every time you must enter password when
power on
Verify with new SIM: When you change SIM card, you enter the
password
Change Password
This feature allows you to change the password.
1) Press Menu > Settings and press OK
2) Scroll Security Setup and press OK
3) Select Change Password and press OK
[ 7 ] Factory Default
This feature resets the current settings to the factory default values.
The default phone code is “0000”.
1) Press Menu > Settings and press OK
2) Select Factory Default and press OK
3) Enter the 4-digit password and press OK
MAIN MENU MAIN MENU
Note : You need to input three times. Old password, the new
password and confirmation. Every time you enter the input
press OK
Applications includes:
Alarm
Calculator
Calendar
[ 1 ] Alarm
When alarm is set, the icon appears on the standby screen.
1) Press Menu > Applications and press OK
2) Select Alarm and press OK
3) Select Alarm 1and or 2 and or 3 for setting alarm and Press OK
4) You can select four cases. Off//One time // Mon~Fri // Everyday. Select your
favorite by scrolling left and right navigation keys
5) After selecting one type, you can go down using up down navigation key and
set the alarm time by pressing numeric key ( time ) and left right navigation
key ( am / pm ).
6) After setting the time, you can go down using up down navigation key and
choose alarm ring tone by pressing left and right key. There are 3 options of
ring tone.
7) Press Save
[ 2 ] Calculator
You can calculate 9 digits.
Key description:
+, -, /, x : Use up / down navigation keys or “*” keys to select.
Clear : Press once to clear one digit.
APPLICATIONS
41 42
1) Press Menu > Applications and press OK
2) Select Calculator and press OK.
3) Enter the first value by number keys
4) Select the calculating mark by the up and down navigation keys or ‘ * ‘ button
5) The calculating mark will toggle among , , , by turns
6) Enter the second value by number keys
7) Press left OK to display the result of calculation. And you can use calculated
results using up / down navigation keys in the next calculation.
[ 3 ] Calendar
You can examine the month and date by Navigation keys .
1) Press Menu > Applications and press OK
2) Select Calendar and press OK
MAIN MENU MAIN MENU
43 44
Technical Specification Before contacting the after-sales service, perform the following simple checks.
They may save you the time and expense of an unnecessary service call.
When you power your phone on, the following messages appear
Insert SIM Card
• Check that the SIM card is correctly installed. (Try opposite direction)
Phone Locked
• The automatic locking function has been enabled. You must enter the phone’s
password before you can use the phone.
Enter PIN
• You are using your phone for the first time. You must enter the Personal
Identification Number supplied with the SIM card.
• The option requiring that the PIN be entered each time when the phone has
powered on has been enabled. You must enter your PIN and then disable this
option if so required.
Enter PUK
• The PIN code was entered wrongly three times in succession and the phone is
now blocked. Enter the PUK supplied by your network operator.
“No service” is displayed
• The network connection is lost. You may be in a weak reception area (in a
tunnel or surrounded by buildings). Move and try again.
• You are trying to access an option for which you have not taken out a
subscription with your service provider. Contact the service provider for further
details.
You have entered a number but it was not dialed
• Have you pressed ?
• Are you accessing the right cellular network?
• You may have set an outgoing call barring option.
REFERENCE INFORMATION REFERENCE INFORMATION
TROUBLE SHOOTINGTECHNICAL INFORMATION
ExternalAntenna
150 HoursStandby time
4 HoursTalk time
Output Voltage
Input Voltage
Type
Resolution
Type
Antenna
Transceiver
Handset
Transceiver
Handset
850 / 1900 MHzWireless Network
210mm(L)
199.4mm(W)*200mm(L)*53.6mm(H)
48mm(W)*190.2mm(L)*44.7mm(H)
Size
Rechargeable / Ni-MH
Battery
824~960MHz, 1710~1990MHzFrequency range
575 gram
5 V
100 V ~ 240 V
AC
Adapter
128*64 ( pixel * pixel )LCD
155 gram
Weight
45 46
* Above technical specification maybe changed without any notice.
Your correspondent cannot reach you
• Is your phone switched on ( pressed for more than one second)?
• Are you accessing the right cellular network?
• You may have set an incoming call barring option.
Your correspondent cannot hear you speaking
• Have you switched off the microphone (appears)?
• Are you holding the phone close enough to your mouth? The microphone is
located in the right side of front cover of the phone.
The audio quality of the call is poor
• Check the signal strength indicator in the display. The number of bars after it
indicates the Signal strength from strong to weak.
• Try moving the phone slightly or moving closer to a window if you are in a
building.
No number is dialed when you recall a phonebook entry
• Check that the numbers have been stored correctly, by using the Contacts
Read feature.
• Re-store them, if necessary.
Access Codes
There are several access codes that are used by your phone and its SIM card.
These codes help you protect the phone against unauthorized use.
The access codes (except for the PUK codes) can be changed using the
Security Settings menu options.
Phone Password
The phone password can be set to avoid unauthorized use of the phone. The
password generally supplied with the phone is 0000. You are advised to change
it before you start using your phone.
Keep the new password secret and in a safe place, separate from the phone.
PIN
The PIN (Personal Identification Number) protects your SIM card against
unauthorized use. The PIN is usually supplied with the SIM card. When the PIN
Check feature is enabled, the PIN is needed each time the phone is powered on.
If you key in an incorrect PIN three times in succession, key in the PUK and
press the OK soft key.
Key in a new PIN and press the OK soft key. Key in the new PIN again and
press the OK soft key.
PUK
The PUK (Personal Unblocking Key) is required to change a blocked PIN. The
PUK may be supplied with the SIM card. If not, contact your local service
provider.
If you key in an incorrect PUK ten times in succession, the SIM card cannot be
used anymore.
Contact your service provider for a new card.
You cannot change the PUK.
REFERENCE INFORMATION REFERENCE INFORMATION
47 48
