User Manual
Introduction
It happens to all of us. You jump in your car, hurry off, and miles later, “Oh
No! I forgot my cell phone!” Now you’ve lost your lifeline. You can’t make
a call, get text messages, or even hear your voicemails - never mind using
GPS, contact lists, or special apps. It can be an embarrassing, expensive,
or even dangerous mistake.
Bringrr lives in your car’s cigarette lighter. When you start your car, Bringrr
senses that your car has started and immediately employs Bluetooth to
look for the signal from your phone. If your phone isn’t in the car, it sounds
an alert and the Bringrr light goes from blue to red.
It’s that simple. Set it up once by pairing it with your phone and it’s good
to go. Now you can relax and forget about forgetting your cell phone.
Setup & Pairing
To get started, plug Bringrr into your car’s power port (cigarette
lighter) and start your car.
Note: Some cars are equipped with power ports that are always
on, while others turn on and off with the car’s engine. If your car’s
power port is always on, the Bringrr light will flash when plugged
in. If your car’s power port is not an always-on, Bringrr will not light
up until the car is started. In general, the operation of Bringrr will
be the same regardless of which type of power port you have.
Press and hold the button on the side of your Bringrr until you hear
a beep.
Bringrr will now go into “pairing mode” and the light will flash red
and blue.
Make sure your phone’s Bluetooth is turned on. Put your phone
into Bluetooth discovery mode and select the option to search for
new devices. Bringrr will appear in the list of available Bluetooth
devices. Select Bringrr and the option to pair with it. If your phone
asks for a passkey, enter 0000.
Once your phone is paired, Bringrr will beep. A few seconds later
it will produce it’s “positive” beep and the light will turn solid blue
indicating that it still “sees” the phone with which it paired. As
long as your phone is in your car, the light will remain blue.
Your phone is now successfully paired to Bringrr.
Note: If, for some reason Bringrr is not able to pair with your phone,
you can restart the pairing process by pulling Bringrr out of the socket
and re-inserting. Be sure the car is still running, then simply press
and hold the Bringrr button again until you hear the beep and see
the flashing of the red and blue light - this means you are back in
pairing mode.
Once you have paired, your phone may prompt you to “connect” with
Bringrr. If this occurs, select “no”. (Unlike a hands-free unit, Bringrr
does not need to be connected to work.) Some phones will say
Bringrr is “not connected” or “disconnected”. You don’t need to do
anything in these cases as it is okay for Bringrr to be unconnected.
Bluetooth On Off
Discoverable
Bringrr
Bringrr Systems, LLC
33 South Commercial St.tManchester, NH 03101
603.413.6195t888.944.8222twww.bringrr.com
Bringrr Beta Setup Guidet1SFMJNJOBSZ
Using Bringrr Day to Day
You should leave Bringrr in your power port all the time, meaning
it will be at your service at the beginning of each trip. There is no
need to ever turn it on - it will be always be ready to do its job. Just
start your car and Bringrr will go to work, looking for your phone.
After you start your car, Bringrr’s blue light will begin ashing.
This means Bringrr is doing its “start-up” search, looking for your
phone.
If Bringrr nds your phone: It will sound its positive beep and
the blue light will stop ashing and remain solid blue for the rest of
your trip. If you wish to turn o the solid blue light for the remainder
of your trip, simply press the Bringrr button once.
If Bringrr cannot nd your phone: It will sound an alert “bring”
.der gnihsa ot egnahc lliw thgil eulb eht dna semit eerht
After the alert, the red light will stop ashing and remain on solid
red for the rest of your trip. If you wish to turn o the solid red
light for the remainder of your trip, simply press the Bringrr button
once.
Note: If your car engine has been o for less than 5 minutes when
you restart it, and you have an always-on power port, Bringrr will
not perform its “start-up” search when you restart the engine. This
scenario might occur, for example, if you stopped for coee. Once
your trip starts (see below) Bringrr will perform a continuing series
of “in-transit” searches and will quickly tell you if you don’t have
your phone. You just won’t hear the positive tone if you do have
your phone. It’s a minor issue for sure, but we thought you might
want to know, particularly if you missed the friendly positive beep
after a quick stop.
During Your Trip
Bringrr will continue to monitor your phone during your entire
trip using its in-transit search algorithm. This will be particularly
valuable if your phone runs down its battery during the trip.
If your phone was found at the start of your trip,
and Bringrr
stops detecting your phone, the Bringrr alert will sound only once,
and the Bringrr light will ash red.
Bringrr could lose your phone signal if:
If your phone was not found at the start of your trip
and Bringrr subsequently detects it, Bringrr
will sound the positive beep and the light will change from r
blue.
Bringrr could detect your phone during a trip if:
Bringrr Beta Setup Guide
Bringrr Systems, LLC
33 South Commercial St. Manchester, NH 03101
603.413.6195 888.944.8222 www.bringrr.com
CE NOTICE:
The device has been evaluated to meet general RF exposure requirement. The device can be used inportable exposure condition without restriction.CE in which
countries where the product may be used freely:Germany, UK, Italy, Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembourg,Austria, Finland,
Sweden, Norway and Iceland.France: except the channel 10 through 13, law prohibits the use of other channels.
FCC NOTICE:
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
IC NOTICE
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
y
red to
You have now arrived at your destination. Your phone should be
at your side. And you should be relaxed and ready for action not
having worried about your phone along the way.
Note: If your car has an always-on power port, the Bringrr
light will remain on for approximately ve minutes before
it shuts o. This will NOT drain your car’s battery.
