Broadcom BRCM1063 802.11bgn WLAN+Bluetooth PCI-E Mini Card User Manual part1

Broadcom Corporation 802.11bgn WLAN+Bluetooth PCI-E Mini Card part1

User Manual_part1

Lenovo regulatory notice for wireless adapters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

This manual contains regulatory information for the following Lenovo products.

• Lenovo Yoga 2 11

The following wireless modules are supported on Lenovo Yoga 2 11:

• BCM943142HM

•QCWB335

Read first — regulatory information

Please read this document before you use the Lenovo computer. Lenovo computer complies

with the radio frequency and safety standards of any country or region in which it has been

approved for wireless use. You must install and use your computer in strict accordance with

the instructions as described hereafter.

Veuillez lire ce document avant d’utiliser l’ordinateur Lenovo. L’ordinateur Lenovo est

conforme aux normes de sécurité et de radiofréquence du pays ou de la région où son

utilisation sans fil est agréée. Vous devez installer et utiliser votre ordinateur en respectant

scrupuleusement les instructions décrites ci-après.

USA — Federal Communications Commission (FCC)

I. Factory preinstalled Wireless LAN module

• FCC ID: QDS-BRCM1063 (Model: BCM943142HM)

• FCC ID: PPD-QCWB335 (Model: QCWB335)

Wireless LAN Mini PCI Express Cards marketed in the USA and Canada do not support nor

function in the extended channels (12ch, 13ch).

i) The FCC RF Exposure compliance:

The radiated output power of the Wireless LAN Mini PCI Express Card authorized to use for

the your Lenovo computer is far below the FCC radio frequency exposure limits.

Nevertheless, it shall be used in such a manner that the potential for human contact during

normal operation is minimized as follows:

ii) FCC ID of wireless module:

On the bottom side of your Lenovo computer, you will find an indicator label of the format

“Contains Transmitter Module: FCC ID XXXX”, where XXXX represents the FCC ID that

corresponds to your preinstalled Wireless LAN module.

Note: The transmission diversity function is implemented for this product. For WLAN cards (Model:

BCM943142HM, QCWB335) using Main and Auxiliary antennas for transmission in the IEEE

802.11 b/g/n transmission mode, radio frequency energy is not emitted simultaneously from

both Main and Auxiliary antennas. One of the antennas is selected automatically or manually

(by users) to have good quality of radiocommunication (transmission diversity function). For

WLAN cards BCM943142HM, QCWB335 in the IEEE 802.11 b/g/n, or MIMO (Multiple In

Multiple Out ) transmission mode, the radio frequency energy is emitted from Main antenna.

Rev. AA00

iii) Radio Frequency interference requirement:

Each device has been tested and found to comply with the limits for a Class B digital device

pursuant to FCC Part 15 Subpart B. Refer to “Electronic emission notices” on page 5.

The models BCM94330UARTSDB underwent the certification process with each respective

FCC ID number listed in “1. Factory preinstalled Wireless LAN module” on page 1.

II. Simultaneous use of RF transmitters

Please make sure of the following conditions on use of wireless features:

1. When you use any other RF option device, all wireless features in your Lenovo computer

are required to be turned off.

2. Users must follow the RF Safety instructions on wireless option devices that are included

in the RF option device's user's manual.

Canada — Industry Canada (IC)

IC Certification number

I) Factory preinstalled Wireless LAN modules:

• IC: 4324A-BRCM1063 (Model: BCM943142HM)

• IC: 4104A-QCWB335 (Model: QCWB335)

Wireless LAN Mini PCI Express Cards marketed in the USA and Canada do not support nor

function in the extended channels (12ch, 13ch).

There is no certification number of Industry Canada for Mini PCI Express Card shown on the

enclosure of your Lenovo computer. Instead you will find an indicator label pointing to the

location of the IC Certification number on the bottom side of your Lenovo computer. This label

will be of the format “Contains Transmitter Module: Canada IC: XXXX”, where XXXX

represents the IC ID that corresponds to your preinstalled WLAN module.

II) Low power license-exempt radiocommunication devices (RSS-210):

Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. this device must accept any interference, including interference that may cause undesired

operation of the device.

The transmitter devices have been designed to operate with the antennas integrated in

Lenovo computer, and having a maximum gain of within 3 dBi.

III) Exposure of humans to RF fields (RSS-102):

Lenovo computers employ low gain integral antennas that do not emit RF field in excess of

Health Canada limits for the general population; consult Safety Code 6, obtainable from

Health Canada’s Web site at www.hc-sc.gc.ca/rpb

The radiated energy from the antennas connected to the wireless adapters conforms to the

IC limit of the RF exposure requirement regarding IC RSS-102, Issue 2 clause 4.2.

Numéro d’homologation IC

I) Modules de réseaux local sans fil pré-installé à l’usine:

• IC: 4324A-BRCM1063 (Model: BCM943142HM)

• IC: 4104A-QCWB335 (Model: QCWB335)

Les cartes de réseau local sans fil Express mini-PCI commercialisées aux Etats-Unis et au

Canada ne prennent pas en charge les canaux étendus (12ch, 13ch) et ne fonctionnent donc

pas sur de tels canaux.

Le boîtier de votre ordinateur Lenovo ne comporte pas de numéro d’homologation IC (Industry

Canada) pour la carte mini-PCI Express ; mais sous votre Lenovo, vous trouverez une étiquette

indicatrice pointant vers l’emplacement du numéro d’homologation IC. L’étiquette se présente

sous la forme “Contains Transmitter Module: Canada IC: XXXX” où XXXX représente l’ID IC qui

correspond au module WLAN préinstallé.

II) Remarque relative aux appareils de communication radio de faible puissance sans

licence (CNR-210):

Le fonctionnement de ce type d’appareil est soumis aux deux conditions suivantes:

1. Cet appareil ne doit pas perturber les communications radio, et

2. cet appareil doit supporter toute perturbation, y compris les perturbations qui pourraient

provoquer son dysfonctionnement.

Les périphériques d’émission sont conçus pour fonctionner avec des antennes intégrées aux

Lenovo et ayant un gain maximal de moins de 3 dBi.

III) Exposition des êtres humains aux champs radioélectriques (RF) (CNR-102):

L’ordinateur Lenovo utilise des antennes intégrales à faible gain qui n’émettent pas un

champ électromagnétique supérieur aux normes imposées par le Ministére de la santé

canadien pour la population. Consultez le Safety Code 6 sur le site Web du Ministére de la

santé canadien à l’adresse “www.hc-sc.gc.ca/rpb”.

L’énergie émise par les antennes reliées aux adaptateurs sans fil respecte la limite d’exposition

aux radiofréquences telle que définie par Industrie Canada dans la clause 4.2 du document

CNR-102.

Le gain d'antenne maximal autorisépour les appareils dans les bandes de fréquence 5250-5350

MHz, 5470-5725 MHz et 5725-5825 MHz est conforme àla limite p.i.r.e (puissance isotrope

rayonnée équivalente) définie dans la section A9.2 du CNR-210.

Lorsque vous utilisez une carte de réseau local sans fil dans le mode de transmission 802.11

a/n:

• Les appareils destinés àla bande 5150-5250 MHz devront être exclusivement utillsés en

intérieur afin de réduire les risques de perturbations électromagnétiques gênantes sur les

systèmes de satellite mobile dans un même canal.

• Les radars àforte puissance sont désignés comme les utilisateurs principaux (c'est-à-dire

qu'ils sont prioritaires) des bandes 5250-5350 MHz et.

5650-5850 MHz. lls peuvent provoquer des perturbations électromagnétiques sur les appareils

de type LELAN (réseau de communication local sans licence) ou les endommager.

Electronic emission notices

Federal Communications Commission (FCC) Statement

• BCM943142HM

•QCWB335

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult an authorized dealer or service representative for help.

Lenovo is not responsible for any radio or television interference caused by unauthorized

changes or modifications to this equipment. Unauthorized changes or modifications could

void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

Responsible Party:

Lenovo (United States) Incorporated

1009 Think Place - Building One

Morrisville, NC 27560

Telephone: 1-919-294-5900

Industry Canada Class B Emission Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003.

Avis de conformité à la réglementation d’Industrie Canada

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

This device has been tested and meets the FCC RF exposure guidelines.

The maximum SAR value reported is 1.15w/kg.

Lenovo limited warranty

L505-0010-02 08/2011

This Lenovo Limited Warranty consists of the following parts:

Part 1 - General Terms

Part 2 - Country-specific Terms

Part 3 - Warranty Service Information

The terms of Part 2 replace or modify terms of Part 1 as specified for a particular country.

Part 1 - General Terms - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

This Lenovo Limited Warranty applies only to Lenovo hardware products you purchased for

your own use and not for resale.

This Lenovo Limited Warranty is available in other languages at www.lenovo.com/warranty.

What this Warranty Covers

Lenovo warrants that each Lenovo hardware product that you purchase is free from defects in

materials and workmanship under normal use during the warranty period. The warranty period

for the product starts on the original date of purchase as shown on your sales receipt or invoice or

as may be otherwise specified by Lenovo. The warranty period and type of warranty service that

apply to your product are as specified in "

Part 3 - Warranty Service Information

" below. This

warranty only applies to products in the country or region of purchase.

THIS WARRANTY IS YOUR EXCLUSIVE WARRANTY AND REPLACES ALL OTHER

WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED

TO, ANY IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE. AS SOME STATES OR JURISDICTIONS DO NOT ALLOW THE

EXCLUSION OF EXPRESS OR IMPLIED WARRANTIES, THE ABOVE EXCLUSION MAY NOT

APPLY TO YOU. IN THAT EVENT, SUCH WARRANTIES APPLY ONLY TO THE EXTENT AND

FOR SUCH DURATION AS REQUIRED BY LAW AND ARE LIMITED IN DURATION TO THE

WARRANTY PERIOD. AS SOME STATES OR JURISDICTIONS DO NOT ALLOW

LIMITATIONS ON THE DURATION OF AN IMPLIED WARRANTY, THE ABOVE LIMITATION

ON DURATION MAY NOT APPLY TO YOU.

How to Obtain Warranty Service

If the product does not function as warranted during the warranty period, you may obtain

warranty service by contacting Lenovo or a Lenovo approved Service Provider. A list of approved

Service Providers and their telephone numbers is available at:

www.lenovo.com/support/phone.

Warranty service may not be available in all locations and may differ from location to location.

Charges may apply outside a Service Provider's normal service area. Contact a local Service

Provider for information specific to your location.

Customer Responsibilities for Warranty Service

Before warranty service is provided, you must take the following steps:

• follow the service request procedures specified by the Service Provider

P/N: XXXXXXXXX

Rev. AA00

Yoga 2 11 SPEC&LLW EN.book Page 1 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

• backup or secure all programs and data contained in the product

• provide the Service Provider with all system keys or passwords

• provide the Service Provider with sufficient, free, and safe access to your facilities to perform

service

• remove all data, including confidential information, proprietary information and personal

information, from the product or, if you are unable to remove any such information, modify

the information to prevent its access by another party or so that it is not personal data under

applicable law. The Service Provider shall not be responsible for the loss or disclosure of any

data, including confidential information, proprietary information, or personal information, on

a product returned or accessed for warranty service

• remove all features, parts, options, alterations, and attachments not covered by the warranty

• ensure that the product or part is free of any legal restrictions that prevent its replacement

• if you are not the owner of a product or part, obtain authorization from the owner for the

Service Provider to provide warranty service

What Your Service Provider Will Do to Correct Problems

When you contact a Service Provider, you must follow the specified problem determination and

resolution procedures.

The Service Provider will attempt to diagnose and resolve your problem by telephone, e-mail or

remote assistance. The Service Provider may direct you to download and install designated

software updates.

Some problems may be resolved with a replacement part that you install yourself called a

"Customer Replaceable Unit" or "CRU." If so, the Service Provider will ship the CRU to you for you

to install.

If your problem cannot be resolved over the telephone; through the application of software updates

or the installation of a CRU, the Service Provider will arrange for service under the type of

warranty service designated for the product under "

Part 3 - Warranty Service Information

" below.

If the Service Provider determines that it is unable to repair your product, the Service Provider will

replace it with one that is at least functionally equivalent.

If the Service Provider determines that it is unable to either repair or replace your product, your

sole remedy under this Limited Warranty is to return the product to your place of purchase or to

Lenovo for a refund of your purchase price.

Replacement Products and Parts

When warranty service involves the replacement of a product or part, the replaced product or part

becomes Lenovo's property and the replacement product or part becomes your property. Only

unaltered Lenovo products and parts are eligible for replacement. The replacement product or part

provided by Lenovo may not be new, but it will be in good working order and at least functionally

equivalent to the original product or part. The replacement product or part shall be warranted for

the balance of the period remaining on the original product.

Yoga 2 11 SPEC&LLW EN.book Page 2 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

Use of Personal Contact Information

If you obtain service under this warranty, you authorize Lenovo to store, use and process

information about your warranty service and your contact information, including name, phone

numbers, address, and e-mail address. Lenovo may use this information to perform service under

this warranty. We may contact you to inquire about your satisfaction with our warranty service or

to notify you about any product recalls or safety issues. In accomplishing these purposes, you

authorize Lenovo to transfer your information to any country where we do business and to provide

it to entities acting on our behalf. We may also disclose it where required by law. Lenovo's privacy

policy is available at www.lenovo.com/.

What this Warranty Does not Cover

This warranty does not cover the following:

• uninterrupted or error-free operation of a product

• loss of, or damage to, your data by a product

• any software programs, whether provided with the product or installed subsequently

• failure or damage resulting from misuse, abuse, accident, modification, unsuitable physical or

operating environment, natural disasters, power surges, improper maintenance, or use not in

accordance with product information materials

• damage caused by a non-authorized service provider

• failure of, or damage caused by, any third party products, including those that Lenovo may

provide or integrate into the Lenovo product at your request

• any technical or other support, such as assistance with “how-to” questions and those

regarding product set-up and installation

• products or parts with an altered identification label or from which the identification label has

been removed

Limitation of Liability

Lenovo is responsible for loss or damage to your product only while it is in the Service Provider's

possession or in transit, if the Service Provider is responsible for the transportation.

Neither Lenovo nor the Service Provider is responsible for loss or disclosure of any data, including

confidential information, proprietary information, or personal information, contained in a product.

UNDER NO CIRCUMSTANCES, AND NOTWITHSTANDING THE FAILURE OF ESSENTIAL

PURPOSE OF ANY REMEDY SET FORTH HEREIN, SHALL LENOVO, ITS AFFILIATES,

SUPPLIERS, RESELLERS, OR SERVICE PROVIDERS BE LIABLE FOR ANY OF THE

FOLLOWING EVEN IF INFORMED OF THEIR POSSIBILITY AND REGARDLESS OF

WHETHER THE CLAIM IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE, STRICT

LIABILITY OR OTHER THEORY OF LIABILITY: 1) THIRD PARTY CLAIMS AGAINST YOU

FOR DAMAGES; 2) LOSS, DAMAGE OR DISCLOSURE OF YOUR DATA; 3) SPECIAL,

INCIDENTAL, PUNITIVE, INDIRECT OR CONSEQUENTIAL DAMAGES, INCLUDING BUT

NOT LIMITED TO LOST PROFITS, BUSINESS REVENUE, GOODWILL OR ANTICIPATED

SAVINGS. IN NO CASE SHALL THE TOTAL LIABILITY OF LENOVO, ITS AFFILIATESS,

SUPPLIERS, RESELLERS OR SERVICE PROVIDERS FOR DAMAGES FROM ANY CAUSE

EXCEED THE AMOUNT OF ACTUAL DIRECT DAMAGES, NOT TO EXCEED THE

AMOUNT PAID FOR THE PRODUCT.

Yoga 2 11 SPEC&LLW EN.book Page 3 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

THE FOREGOING LIMITATIONS DO NOT APPLY TO DAMAGES FOR BODILY INJURY

(INCLUDING DEATH), DAMAGE TO REAL PROPERTY OR DAMAGE TO TANGIBLE

PERSONAL PROPERTY FOR WHICH LENOVO IS LIABLE UNDER LAW.

AS SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR

LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE ABOVE

LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

Your Other Rights

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER

RIGHTS ACCORDING TO THE APPLICABLE LAWS OF YOUR STATE OR JURISDICTION.

YOU MAY ALSO HAVE OTHER RIGHTS UNDER A WRITTEN AGREEMENT WITH

LENOVO. NOTHING IN THIS WARRANTY AFFECTS STATUTORY RIGHTS, INCLUDING

RIGHTS OF CONSUMERS UNDER LAWS OR REGULATIONS GOVERNING THE SALE OF

CONSUMER GOODS THAT CANNOT BE WAIVED OR LIMITED BY CONTRACT.

Part 2 - Country-specific Terms - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Australia

"Lenovo" means Lenovo (Australia & New Zealand) Pty Limited ABN 70 112 394 411. Address:

Level 10, North Tower, 1-5 Railway Street, Chatswood, NSW, 2067. Telephone: +61 2 8003 8200.

Email: lensyd_au@lenovo.com

The following replaces the same section in Part 1:

What this Warranty Covers:

Lenovo warrants that each hardware product that you purchase is free from defects in materials and

workmanship under normal use and conditions during the warranty period. If the product fails due to a

covered defect during the warranty period, Lenovo will provide you a remedy under this Limited

Warranty. The warranty period for the product starts on the original date of purchase specified on your

sales receipt or invoice unless Lenovo informs you otherwise in writing. The warranty period and type of

warranty service that apply to your product are set forth below in

Part 3 - Warranty Service Information

THE BENEFITS GIVEN BY THIS WARRANTY ARE IN ADDITION TO YOUR RIGHTS AND

REMEDIES AT LAW, INCLUDING THOSE UNDER THE AUSTRALIAN CONSUMER LAW.

The following replaces the same section in Part 1:

Replacement Products and Parts:

When warranty service involves the replacement of a product or part, the replaced product or part

becomes Lenovo's property and the replacement product or part becomes your property. Only

unaltered Lenovo products and parts are eligible for replacement. The replacement product or part

provided by Lenovo may not be new, but it will be in good working order and at least functionally

equivalent to the original product or part. The replacement product or part shall be warranted for

Yoga 2 11 SPEC&LLW EN.book Page 4 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

the balance of the period remaining on the original product. Products and parts presented for

repair may be replaced by refurbished products or parts of the same type rather than being

repaired. Refurbished parts may be used to repair the product; and repair of the product may result

in loss of data, if the product is capable of retaining user-generated data.

The following is added to the same section in Part 1:

Use of Personal Contact Information:

Lenovo will not be able to perform our service under this warranty if you refuse to provide your

information or do not wish us to transfer your information to our agent or contractor. You have the

right to access your personal contact information and request correction of any errors in it pursuant

to the Privacy Act 1988 by contacting Lenovo.

The following replaces the same section in Part 1:

Limitation of Liability:

Lenovo is responsible for loss or damage to your product only while it is in the Service Provider's

possession or in transit, if the Service Provider is responsible for the transportation.

Neither Lenovo nor the Service Provider is responsible for loss or disclosure of any data, including

confidential information, proprietary information, or personal information, contained in a product.

TO THE EXTENT PERMITTED BY LAW, UNDER NO CIRCUMSTANCES AND

NOTWITHSTANDING THE FAILURE OF ESSENTIAL PURPOSE OF ANY REMEDY SET

FORTH HEREIN, SHALL LENOVO, ITS AFFILIATES, SUPPLIERS, RESELLERS, OR SERVICE

PROVIDERS BE LIABLE FOR ANY OF THE FOLLOWING EVEN IF INFORMED OF THEIR

POSSIBILITY AND REGARDLESS OF WHETHER THE CLAIM IS BASED IN CONTRACT,

WARRANTY, NEGLIGENCE, STRICT LIABILITY OR OTHER THEORY OF LIABILITY: 1)

THIRD PARTY CLAIMS AGAINST YOU FOR DAMAGES; 2) LOSS, DAMAGE OR

DISCLOSURE OF YOUR DATA; 3) SPECIAL, INCIDENTAL, PUNITIVE, INDIRECT OR

CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOST PROFITS,

BUSINESS REVENUE, GOODWILL OR ANTICIPATED SAVINGS. IN NO CASE SHALL THE

TOTAL LIABILITY OF LENOVO, ITS AFFILIATESS, SUPPLIERS, RESELLERS OR SERVICE

PROVIDERS FOR DAMAGES FROM ANY CAUSE EXCEED THE AMOUNT OF ACTUAL

DIRECT DAMAGES, NOT TO EXCEED THE AMOUNT PAID FOR THE PRODUCT.

THE FOREGOING LIMITATIONS DO NOT APPLY TO DAMAGES FOR BODILY INJURY

(INCLUDING DEATH), DAMAGE TO REAL PROPERTY OR DAMAGE TO TANGIBLE

PERSONAL PROPERTY FOR WHICH LENOVO IS LIABLE UNDER LAW.

The following replaces the same section in Part 1:

Your Other Rights:

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU ALSO HAVE OTHER

RIGHTS AT LAW, INCLUDING UNDER THE AUSTRALIAN CONSUMER LAW. NOTHING

IN THIS WARRANTY AFFECTS STATUTORY RIGHTS OR RIGHTS AT LAW, INCLUDING

RIGHTS THAT CANNOT BE WAIVED OR LIMITED BY CONTRACT.

Yoga 2 11 SPEC&LLW EN.book Page 5 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

For example, our products come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for any other

reasonably foreseeable loss or damage. You are also entitled to have the products repaired or replaced if the

products fail to be of acceptable quality and the failure does not amount to a major failure.

New Zealand

The following is added to the same section in Part 1:

Use of Personal Information:

Lenovo will not be able to perform our service under this warranty if you refuse to provide your

information or do not wish us to transfer your information to our agent or contractor. You have the

right to access your personal information and request correction of any errors in it pursuant to the

Privacy Act 1993 by contacting Lenovo (Australia & New Zealand) Pty Limited ABN 70 112 394

411. Address: Level 10, North Tower, 1-5 Railway Street, Chatswood, NSW, 2067. Telephone: 61 2

8003 8200. Email: lensyd_au@lenovo.com

Bangladesh, Cambodia, India, Indonesia, Nepal, Philippines, Vietnam and Sri Lanka

The following is added to Part 1:

Dispute Resolution

Disputes arising out of or in connection with this warranty shall be finally settled by arbitration

held in Singapore. This warranty shall be governed, construed and enforced in accordance with the

laws of Singapore, without regard to conflict of laws. If you acquired the product in India, disputes

arising out of or in connection with this warranty shall be finally settled by arbitration held in

Bangalore, India. Arbitration in Singapore shall be held in accordance with the Arbitration Rules of

Singapore International Arbitration Center ("SIAC Rules") then in effect. Arbitration in India shall

be held in accordance with the laws of India then in effect. The arbitration award shall be final and

binding on the parties without appeal. Any award shall be in writing and set forth the findings of

fact and the conclusions of law. All arbitration proceedings, including all documents presented in

such proceedings shall be conducted in the English language. The English language version of this

warranty prevails over any other language version in such proceedings.

European Economic Area (EEA)

The following is added to Part 1:

Customers in the EEA may contact Lenovo at the following address: EMEA Service Organisation,

Lenovo (International) B.V., Floor 2, Einsteinova 21, 851 01, Bratislava, Slovakia. Service under this

warranty for Lenovo hardware products purchased in EEA countries may be obtained in any EEA

country in which the product has been announced and made available by Lenovo.

Russia

The following is added to Part 1:

Product Service Life

The product service life is four (4) years from the original date of purchase.

Yoga 2 11 SPEC&LLW EN.book Page 6 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

Part 3 - Warranty Service Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

If required, the Service Provider will provide repair or exchange service depending on the type

of warranty service specified for your product and the available service. Scheduling of service

will depend upon the time of your call, parts availability, and other factors.

Product or

machine type Country or region of purchase Warranty period

Types of

warranty

service

notebook:

20332, 80CX

Taiwan, Korea

parts and labor -

1 year

battery pack - 1 year

3, 4

Singapore 1, 3, 4

China (Hong Kong S.A.R.), China

(Macau S.A.R.), India, Indonesia,

Malaysia, Thailand, Philippines,

Vietnam, Bahrain, Kuwait,

Oman, Qatar, Egypt, South

Africa, Saudi Arabia, UAE,

Algeria, Nigeria, Kenya, Sri

Lanka 1, 4

Bosnia-Herzegovina, Croatia,

Cyprus, Greece, Macedonia,

Romania, Slovenia, Serbia,

Poland, Hungary, Slovakia,

Bulgaria

Argentina, Colombia, Peru,

Venezuela, Bolivia, Uruguay,

Chile, Paraguay, Ecuador

Austria, France, Germany, Iceland,

Israel, Ireland, Italy, Latvia,

Lithuania, Switzerland, the United

Kingdom 1, 3

Japan, Australia, New Zealand

United States of America, Canada

Russia, Ukraine, the Republic of

Kazakhstan, Belarus,

Turkmenistan, Azerbaijan,

Georgia 4

Brazil

Mexico 1, 5

Belgium, Denmark, Estonia,

Finland, Luxembourg,

Netherlands, Norway, Spain,

Sweden, Portugal

parts and labor -

2 years

battery pack - 1 year

1, 3

Turkey, Czech Republic 1, 4

Yoga 2 11 SPEC&LLW EN.book Page 7 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

Types of Warranty Service

Customer Replaceable Unit (“CRU”) Service

Under CRU Service, the Service Provider will ship CRUs to you at its cost for installation by you.

CRU information and replacement instructions are shipped with your product and are available

from Lenovo at any time upon request. CRUs that are easily installed by you are called "Self-

service CRUs". "Optional-service CRUs "are CRUs that may require some technical skill and

tools. Installation of Self-service CRUs is your responsibility. You may request that a Service

Provider install Optional-service CRUs under one of the other types of warranty service

designated for your product. An optional service offering may be available for purchase from a

Service Provider or Lenovo under which Self-service CRUs would be installed for you. You may

find a list of CRUs and their designation in the publication that was shipped with your product

or at www.lenovo.com/CRUs. The requirement to return a defective CRU, if any, will be

specified in the instructions shipped with a replacement CRU. When return is required: 1) return

instructions, a prepaid return shipping label, and a container will be included with the

replacement CRU; and 2) you may be charged for the replacement CRU if the Service Provider

does not receive the defective CRU from you within thirty (30) days of your receipt of the

replacement CRU.

On-site Service

Under On-Site Service, a Service Provider will either repair or exchange the product at your

location. You must provide a suitable working area to allow disassembly and reassembly of the

product. Some repairs may need to be completed at a service center. If so, the Service Provider

will send the product to the service center at its expense.

Courier or Depot Service

Under Courier or Depot Service, your product will be repaired or exchanged at a designated

service center, with shipping at the expense of the Service Provider. You are responsible for

disconnecting the product and packing it in a shipping container provided to you to return your

product to a designated service center. A courier will pick up your product and deliver it to the

designated service center. The service center will return the product to you at its expense.

Customer Carry-In Service

Under Customer Carry-In Service, your product will be repaired or exchanged after you deliver

it to a designated service center at your risk and expense. After the product has been repaired or

exchanged, it will be made available to you for collection. If you fail to collect the product, the

Service Provider may dispose of the product as it sees fit, with no liability to you.

Mail-In Service

Under Mail-In Service, your product will be repaired or exchanged at a designated service

center after you deliver it at your risk and expense. After the product has been repaired or

exchanged, it will be returned to you at Lenovo's risk and expense, unless the Service Provider

specifies otherwise.

Yoga 2 11 SPEC&LLW EN.book Page 8 Monday, August 5, 2013 2:45 PM

Lenovo limited warranty

Customer Two-Way Mail-In Service

Under Customer Two-Way Mail-In Service, your product will be repaired or exchanged after

you deliver it to a designated service center at your risk and expense. After the product has been

repaired or exchanged, it will be made available to you for return shipping at your risk and

expense. If you fail to arrange return shipment, the Service Provider may dispose of the product

as it sees fit, with no liability to you.

Product Exchange Service

Under Product Exchange Service, Lenovo will ship a replacement product to your location. You

are responsible for its installation and verification of its operation. The replacement product

becomes your property in exchange for the failed product, which becomes the property of

Lenovo. You must pack the failed product in the shipping carton in which you received the

replacement product and return it to Lenovo. Transportation charges, both ways, shall be at

Lenovo’s expense. If you fail to use the carton in which the replacement product was received,

you may be responsible for any damage to the failed product occurring during shipment. You

may be charged for the replacement product if Lenovo does not receive the failed product

within thirty (30) days of your receipt of the replacement product.

Yoga 2 11 SPEC&LLW EN.book Page 9 Monday, August 5, 2013 2:45 PM

Product specific Notices

The notices in this appendix are specific to the product with the given MT number. Notices that are

common for most Lenovo products are included in “Appendix A. Notices” of the

Lenovo Safety and

General Information Guide

Energy star information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

ENERGY STAR

is a joint program of the U.S. Environmental Protection Agency and the U.S.

Department of Energy aimed at saving money and protecting the environment through energy

efficient products and practices.

Lenovo

is proud to offer our customers products with an ENERGY STAR compliant designation.

Lenovo computers of the following machine types, if the ENERGY STAR mark is affixed, have

been designed and tested to conform to the ENERGY STAR program requirements for computers.

• 20332, 80CX

By using ENERGY STAR compliant products and taking advantage of the power-management

features of your computer, you reduce the consumption of electricity. Reduced electrical

consumption contributes to potential financial savings, a cleaner environment, and the reduction

of greenhouse gas emissions.

For more information about ENERGY STAR, visit http://www.energystar.gov.

Lenovo encourages you to make efficient use of energy an integral part of your day-to-day

operations. To help in this endeavor, Lenovo has preset the following power-management features

to take effect when your computer has been inactive for a specified duration:

To awaken your computer from a Sleep mode, press any key on your keyboard. For more

information about these settings, refer to your Windows Help and Support information system.

Table 1. ENERGY STAR power-management features

Windows® 8

Power plan: balanced (plugged in)

• Turn off the display:

After 5 minutes

• Put the computer to sleep:

After 30 minutes

• Advanced power settings:

- Turn off hard disks:

After 20 minutes

Yoga 2 11 SPEC&LLW EN.book Page 10 Monday, August 5, 2013 2:45 PM

Product specific Notices

Electronic emissions notices - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

The following information refers to Lenovo Yoga 2 11, machine type 20332, 80CX.

Federal Communications Commission (FCC) Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee the

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult an authorized dealer or service representative for help.

Properly shielded and grounded cables and connectors must be used in order to meet FCC

emission limits. Proper cables and connectors are available from Lenovo authorized dealers.

Lenovo is not responsible for any radio or television interference caused by using other than

recommended cables or connectors or by unauthorized changes or modifications to this

equipment. Unauthorized changes or modifications could void the user’s authority to operate the

equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Responsible party:

Lenovo (United States) Incorporated

1009 Think Place - Building One

Morrisville, NC 27560

U.S.A.

Telephone: (919) 294-5900

Yoga 2 11 SPEC&LLW EN.book Page 11 Monday, August 5, 2013 2:45 PM

Product specific Notices

Industry Canada Class B Emission Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003.

Avis de conformité à la réglementation d’Industrie Canada

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

German Class B Compliance Statement

Deutschsprachiger EU Hinweis:

Hinweis für Geräte der Klasse B EU-Richtlinie zur Elektromagnetischen Verträglichkeit

Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG (früher 89/

336/EWG) zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in

den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse B ein.

Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren

und zu betreiben. Des Weiteren dürfen auch nur von der Lenovo empfohlene Kabel angeschlossen

werden. Lenovo übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen,

wenn das Produkt ohne Zustimmung der Lenovo verändert bzw. wenn

Erweiterungskomponenten von Fremdherstellern ohne Empfehlung der Lenovo gesteckt/

eingebaut werden.

Deutschland:

Einhaltung des Gesetzes über die elektromagnetische Verträglichkeit von Betriebsmittein

Dieses Produkt entspricht dem “Gesetz über die elektromagnetische Verträglichkeit von

Betriebsmitteln” EMVG (früher “Gesetz über die elektromagnetische Verträglichkeit von

Geräten”). Dies ist die Umsetzung der EU-Richtlinie 2004/108/EG (früher 89/336/EWG) in der

Bundesrepublik Deutschland.

Zulassungsbescheinigung laut dem Deutschen Gesetz über die elektromagnetische

Verträglichkeit von Betriebsmitteln, EMVG vom 20. Juli 2007 (früher Gesetz über die

elektromagnetische Verträglichkeit von Geräten), bzw. der EMV EG Richtlinie 2004/108/EC

(früher 89/336/EWG), für Geräte der Klasse B.

Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG das EG-

Konformitätszeichen - CE - zu führen. Verantwortlich für die Konformitätserklärung nach

Paragraf 5 des EMVG ist die Lenovo (Deutschland) GmbH, Gropiusplatz 10, D-70563 Stuttgart.

Informationen in Hinsicht EMVG Paragraf 4 Abs. (1) 4:

Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse B.

Yoga 2 11 SPEC&LLW EN.book Page 12 Monday, August 5, 2013 2:45 PM

Product specific Notices

European Union Compliance Statement Class B Compliance

European Union - Compliance to the Electromagnetic Compatibility Directive

This product is in conformity with the protection requirements of EU Council Directive 2004/108/

EC on the approximation of the laws of the Member States relating to electromagnetic

compatibility. Lenovo cannot accept responsibility for any failure to satisfy the protection

requirements resulting from a non-recommended modification of the product, including the

installation of option cards from other manufacturers.

This product has been tested and found to comply with the limits for Class B Information

Technology Equipment according to European Standard EN 55022. The limits for Class B

equipment were derived for typical residential environments to provide reasonable protection

against interference with licensed communication devices.

EU Contact Address: Lenovo, Einsteinova 21, 851 01 Bratislava, Slovakia

Yoga 2 11 SPEC&LLW EN.book Page 13 Monday, August 5, 2013 2:45 PM

Specifications

Model Name: Lenovo Yoga 2 11

Machine Type: 20332, 80CX

Note:

The following specifications may contain technical inaccuracies or typographical errors. Lenovo reserves the

right to improve and/or change specifications at any time without notice.

Form Factor

Dimensions Appr. 298 mm × 206 mm × 17.2 mm

Weight Appr. 1.45 kg

LCD size 11.6-inch

Processor

View the system properties of your computer.

You can do this as follows: Open the Control Panel,

and then select System and Security → System.

Memory

Type and speed DDR3L

Maximum

supported

capacity

4 GB

SSD

Capacity 320G+16G/500G+16G

Interface SATA

Display

Touch Screen Multi-touch screen

I/O Ports

USB USB 2.0 × 1, USB 3.0 × 1

Audio Combo audio jack × 1

Video/Audio Micro HDMI × 1

Card reader 2 in 1 card reader (SD/MMC)

Battery pack

Type Li-Polymer

Cells/Capacity 4 cell, 34 Wh

AC power adapter

Input 100 - 240 V, 50 - 60 Hz AC

Output voltage 20 V DC

Power 45 W

Miscellaneous

Camera 1.0 Mega, 720P HD

Yoga 2 11 SPEC&LLW EN.book Page 14 Monday, August 5, 2013 2:45 PM

Trademarks

The following terms are trademarks or registered trademarks of Lenovo in the United States, other

countries, or both.

Lenovo

Onekey

Microsoft and Windows are trademarks of Microsoft Corporation in the United States, other

countries, or both.

Yoga 2 11 SPEC&LLW EN.book Page 15 Monday, August 5, 2013 2:45 PM

Yoga 2 11 SPEC&LLW EN.book Page 16 Monday, August 5, 2013 2:45 PM

Lenovo Yoga 2 11

Read the safety notic es and important tips in the

included manuals before using your computer.

User Guide

First Edition (August 2013)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General

Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set

forth in Contract No. GS-35F-05925.

The Regulatory Notice provides information about the radio frequency and safety

standards. Be sure to read it before using wireless devices on your computer.

To refer to it, go to http://www.lenovo.com, click Support, and then click User’s guides

and manuals.

Regulatory Notice

Before using the product, be sure to read Lenovo Safety and General Information Guide first.

The features described in this guide are common to most models. Some features may not

be available on your computer or your computer may include features that are not

described in this user guide.

Some instructions in this guide may assume that you are using Windows® 8. If you are

using another Windows operating system, some operations may be slightly different. If

you are using other operating systems, some operations may not apply to you.

Notes

•

The illustrations in this manual may differ from the actual product. Please refer to the

actual product.

•

Chapter 1. Getting to know your computer ..................................................................................... 1

Top view ......................................................................................................................................................... 1

Left-side view ................................................................................................................................................ 8

Right-side view............................................................................................................................................ 11

Chapter 2. Starting to use Windows 8............................................................................................12

Configuring the operating system for the first time .............................................................................. 12

Operating system interfaces ...................................................................................................................... 12

The charms ................................................................................................................................................... 13

Putting the computer to sleep or shutting it down................................................................................ 15

Touch screen operation.............................................................................................................................. 17

Connecting to wireless LAN ..................................................................................................................... 21

Help and support........................................................................................................................................ 22

Chapter 3........................................................................................................................................... 23

Lenovo OneKey Recovery System................................................................................................. 23

Chapter 4. Troubleshooting ............................................................................................................ 24

Frequently asked questions ....................................................................................................................... 24

Troubleshooting .......................................................................................................................................... 26

Trademarks....................................................................................................................................... 29

Contents

Chapter 1. Getting to know your computer

Top view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Note: The dashed areas indicate parts that are not visible externally.

Attention:

•When closing the display panel, be careful not to leave pens or any other objects in between the display

panel and the keyboard. Otherwise, the display panel may be damaged.



Chapter 1. Getting to know your computer

Integrated camera (on

select models)

Use the camera for the video communication.

Wireless LAN

antennas

Connect to the wireless LAN adapter to send and receive wireless radio

signals.

Multi-touch screen Functions as the visual display as well as one of the two primary input

methods.

Note: For details, see “Touch screen operation” on page 17.

Windows button Press this button to:

Toggle between the current view and the Start screen.

-or-

Wak e up the computer from sleep mode.

Built-in microphones Capture sound which can be used for video conferencing, voice narration,

or audio recording.

Touch pad The touch pad functions as a conventional mouse.

Touch pad: To mo ve the pointer on the screen, slide your fingertip over the

pad in the direction in which you want the pointer to move.

Touch pad buttons: The functions of the left/right side correspond to

those of the left/right mouse button on a conventional mouse.

Note: You can enable/disable the touch pad by pressing F6 ().

Chapter 1. Getting to know your computer

Keyboard function keys

You can access certain system settings quickly by pressing the appropriate function keys.

:Mutes/unmutes the sound. :Enables/disables Airplane

mode.

:Decreases the volume level. :Displays all currently active

apps.

:Increases the volume level. :Turns on/off the backlight of

the LCD screen.

:Closes the currently active

window. :

Toggles the display between the

computer and an external

device.

:Refreshes the desktop or the

currently active window. :Decreases the display

brightness.

Enables/disables the touch pad

. :Increases the display

brightness.

Note: By default, the screen brightness is set automatically (based on the ambient light level). If you want to

adjust the brightness of the screen manually, open the charms bar and select Settings → Change PC

settings → General → Screen (Adjust my screen brightness automatically) and toggle the switch to

Off.

Chapter 1. Getting to know your computer

Screen orientation

You can rotate the display panel to your preferred orientation.

•The orientation of the display automatically changes (alternating between portrait and

landscape modes) depending upon how you hold the computer.

•To prevent automatic orientation, press the rotation lock button. It is located on the right edge

of the computer. (See below illustration).

Chapter 1. Getting to know your computer

Positioning the display panel

The display panel can be opened to any angle up to 360 degrees.

Notebook Mode

Suitable for tasks that require a keyboard and mouse (such as creating documents, writing e-

mails, and so on).

Chapter 1. Getting to know your computer

Stand Mode (Theater Mode)

Suitable for tasks that require little or no touch (such as viewing photos or playing videos).

Tablet Mode

Suitable for tasks that require touching the screen often (such as surfing the Web, playing games,

and so on).

Chapter 1. Getting to know your computer

Tent Mode (Presentation Mode)

Suitable for tasks that require limited interaction with the touch screen (such as displaying

graphs or a PowerPoint presentations).

Attention:

•Do not open the display with too much force, otherwise the panel or hinges may be damaged.

Note: The keyboard and touch pad are automatically locked when the screen is opened beyond 190

degrees (approximately).



Chapter 1. Getting to know your computer

Left-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

AC power adapter

jack

Connect the AC power adapter here.

USB port Connects to USB devices.

Note: For details, see “Connecting USB devices” on page 9.

Memory card slot Insert memory cards (not supplied) here.

Note: For details, see “Using memory cards (not supplied)” on page 10.

HDMI port Connects to devices with HDMI input such as a TV or an external display.

a b c d

Chapter 1. Getting to know your computer

Connecting USB devices

Your computer comes with two USB ports compatible with USB devices.

The first time you plug a USB device into a particular USB port on your computer, Windows

automatically installs a driver for that device. After the driver has been installed, you can

disconnect and reconnect the device without performing any additional steps.

Before disconnecting a USB storage device, make sure your computer has finished transferring

data to that device. Click the Safely Remove Hardware and Eject Media icon in the Windows

notification area to remove the device before disconnecting.

Note: Typically, Windows detects a new device after it has been connected, and then installs the driver

automatically. However, some devices may require you to install the driver before connecting.

Check the documentation provided by the device’s manufacturer before connecting the device.

Note: If your USB device uses a power cord, connect the device to a power source before connecting it.

Otherwise, the device may not be recognized.

Chapter 1. Getting to know your computer

Using memory cards (not supplied)

Your computer supports the following types of memory cards:

•Secure Digital (SD) card

•MultiMediaCard (MMC)

Inserting a memory card

Push the dummy card in until you hear a click.

Gently pull the dummy card out of the memory card slot.

Slide the memory card in until it clicks into place.

Removing a memory card

Push the memory card in until you hear a click.

Gently pull the memory card out of the memory card slot.

Notes:

•Insert only one card in the slot at a time.

•This card reader does not support SDIO devices (e.g., SDIO Bluetooth, etc.).

Note: The dummy card is used for preventing dust and small particles from entering the inside of your

computer when the memory card slot is not in use. Retain the dummy card for future use.

Note: Before removing the memory card, disable it by using the Windows safely remove hardware and

eject media utility to avoid data corruption.

Chapter 1. Getting to know your computer

Right-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Power and battery

status indicator

Power button Press this button to turn on the computer.

Novo button When the computer is off, press this button to start the Lenovo OneKey

Recovery System or the BIOS setup utility, o r to enter the boot menu.

Rotation lock button Keeps the screen locked in portrait or landscape orientation. Locking

the screen rotation will disable the gravity sensing function, thereby

preventing the screen from changing its orientation automatically

depending upon the angle at which it is held.

Volume down button Decreases the volume level.

Volume up button Increases the volume level.

Combo audio jack Connects to headsets.

Notes:

•The combo audio jack does not support conventional microphones.

•The recording function may not be supported if third-party headphones or headsets are connected,

due to different industry standards.

USB port Connects to USB 2.0 devices.

Note: For details, see “Connecting USB devices” on page 9.

bac defgh

Chapter 2. Starting to use Windows 8

Configuring the operating system for the first time - - - - - - - - - - - - - - - -

You may need to configure the operating system when it is first used. The configuration process

may include the procedures below:

•Accepting the end user license agreement

•Configuring the internet connection

•Registering the operating system

•Creating a user account

Operating system interfaces - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Windows 8 comes with two main User Interface: the Start screen and the desktop.

To switch from the Start screen to the desktop, do one of the following:

•Select the desktop tile on the Start screen.

•Press the Windows button.

•Press Windows key + D.

To switch from the desktop to the Start screen, do one of the following:

•Select Start from the charms.

•Move the pointer to the lower-left corner and then select the Start screen thumbnail when it is

displayed.

Start screen Desktop

Chapter 2. Starting to use Windows 8

The charms - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

The five charms provide new and faster ways to perform many basic tasks, and are always

available regardless of which app you are currently in.

To display the charms, do one of the following:

•Move the pointer to the upper-right or lower-right corner until the charms bar is displayed.

•Use one finger to swipe in from the right edge of the screen until the charms bar is displayed.

•Press Windows key + C.

Search charm

The Search charm is a powerful new way to find whatever you are looking for, including apps,

settings and files.

Chapter 2. Starting to use Windows 8

Share charm

The Share charm lets you send links, photos, and more to your friends and social networks

without leaving the app you are in.

Start charm

The Start charm is a fast way to go to the Start screen.

Devices charm

The Devices charm allows you to connect or send files to any external devices, such as digital

cameras, TVs, or printers.

Settings charm

The Settings charm lets you perform basic tasks, such as setting the volume or shutting down

the computer. Also, you can get to the Control Panel through the Settings charm when using the

desktop screen.

Chapter 2. Starting to use Windows 8

Putting the computer to sleep or shutting it down - - - - - - - - - - - - - - - - - - -

When you have finished working with your computer, you can put it to sleep or shut it down.

Putting your computer to sleep

If you will be away from your computer for a short time, put the computer to sleep.

When the computer is in sleep mode, you can quickly wake it to resume use, bypassing the

startup process.

To put the computer to sleep, do one of the following:

•Close the display panel.

•Press the Power button.

•Open the charms and then select Settings → Power → Sleep.

To wake the computer, do one of the following:

•Press any key on the keyboard. (Notebook mode only)

•Press the Power button.

•Press the Windows button.

Note: Put your computer to sleep before you move it. Moving your computer while the hard disk is

spinning can damage the hard disk, causing loss of data.

Broadcom BRCM1063 802.11bgn WLAN+Bluetooth PCI-E Mini Card User Manual part1

Broadcom Corporation 802.11bgn WLAN+Bluetooth PCI-E Mini Card part1

Contents

User Manual_part1

Navigation menu

Namespaces

Views

Navigation
