Brookstone Purchasing EXTSPK Wireless Executive Speaker User Manual 989236 INS Wireless Executive Speaker
Brookstone Purchasing, Inc. Wireless Executive Speaker 989236 INS Wireless Executive Speaker
User manual
989236_INS_Wireless Executive Speaker
Instructions Doc. Size: 270mm W x 115mm H Folded Size: 50mmW x 115mmH
Output at 100% Prints 1/1 Black Finishing: Trim to Crops; Accordion Fold: 5 folds
Fold
Fold
Fold
Fold
LITHIUM-ION BATTERY
WARNINGS
This device contains a non-removable
lithium-ionbattery. The battery must be
recycled or disposed of properly .
Contact your local waste management
oce for informationon battery
recycling or disposal.
FCC INFORMATION
This equipmenthas been tested
and found to comply with the
limits for a Class B Digital Device,
pursuant to Part 15 of the FC C
Rules. These limits are designed to
providereasonable protectionagainst
harmful interference in a residential
installation.This equipmentgenerates,
uses, and can radiate radio frequency
energy and, if not installed and used
in accordance with the instructions,
may cause harmful interference to
radio communications.However, there
is no guarantee that interference will
not occur in a particular installation.
If this equipmentdoes cause harmful
interference to radio or television
reception,which can be determined
by turningthe equipmento and
on, the user is encouraged to try to
correct the interference by one or
more of the followingmeasures:
tReorient or relocate the
receiving antenna.
tIncrease the distance between
the equipmentand receiver.
tConnect the equipmentto an outlet
on a circuit different from that to
which the receiver is concted.
tConsult the dealer or an
experienced radio/TV technician
for help.
This equipmentcomplies with
Part 15 of the FC C Rules.
Operation is subject to the
followingtwo conditions:
1. This equipmentmay not cause
harmful interference.
2. This equipmentmust accept any
interference received, including
interf erence that may cause
undesired operation.
Modications not authorizedby the
manufacturer may void the user’s
authorityto operate this device.
This equipmentcomplies with FC C
R F radiationexposure limits set forth
for an uncontrolledenvironment.This
transmittermust not be co-located or
operating in conjunctionwith any other
antenna or transmitter.
Wireless Executive Speaker
FOR TABLETS AND SMARTPHONES
Fold
989236
Merrimack, New Hampshire, USA 03054
800-8 46 -3000 tBrookstone.com
CARE AND STORAGE
1. To clean speaker, wipe with a soft,
dry cloth.
2. Store speaker in a cool, dry location.
SPECIFICATIONS
Power Supply: 5V, 500mA
Total Output: 5W
Range: Class 2, up to 33 ft (10 m)
Li-ion Re chargeable Battery: 700mAh
Speaker: 1.57 in . , 4 Ohm
Charging Time: Approx. 2.5 hours
Battery Li fe: Approx. 5 hours
Compatibility: Bluetooth
® 3.0 or a bove
device with A2DP/ AVR C P
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of
such marks by Brookstone is under
license.
Total Audio Output: 5W
989236_INS_Wireless Executive Speaker
ONE (1) YEAR LIMITED WARRANTY
Brookstone®warrants this product against
defects in materials and/or workmanship under
normal use for a period of ONE (1) YEAR from
the date of purchase by the original purchaser
(“Warranty Period”). If a defect arises and a
valid claim is received within the Warranty
Period, at its option, Brookstone will either
1) repair the defect at no charge, using
new or refurbished replacement parts, or
2) replace the product with a new product that
is at least functionally equivalent to the original
product, or 3) provide a store credit in the
amount of the purchase price of the original
product. A replacement product or part, including
a user-installable part installed in accordance with
instructions provided by Brookstone, assumes
the remaining warranty of the original product.
When a product or part is exchanged, any
replacement item becomes your property and the
replaced item becomes Brookstone’s property.
When a store credit is given, the original product
must be returned to Brookstone and becomes
Brookstone’s property.
Obtaining Service: To obtain warranty service,
call Brookstone Limited Warranty Service at
1-800-292-9819 . Please be prepared to
describe the product that needs service and
the nature of the problem. A purchase receipt
is required. All repairs and replacements must
be authorized in advance. Service options, parts
availability and response times will vary. You are
responsible for delivery and the cost of delivery of
the product or any parts to the authorized service
center for replacement, per our instructions.
Limits and Exclusions: Coverage under this
Limited Warranty is limited to the United States of
America, including the District of Columbia and the
U.S. Territories of Guam, Puerto Rico, and the U.S.
Virgin Islands. This Limited Warranty applies only
to products manufactured for Brookstone that can
be identied by the “Brookstone” trademark, trade
name, or logo axed to them or their packaging.
The Limited Warranty does not apply to any non-
Brookstone products. Manufacturers or suppliers
other than Brookstone may provide their own
warranties to the purchaser, but Brookstone,
in so far as permitted by law, provides these
products “as is.” This warranty does not apply to:
a) damage caused by failure to follow instructions
relating to product’s use or the installation of
components; b) damage caused by accident,
abuse, misuse, re, oods, earthquake or other
external causes; c) damage caused by service
performed by anyone who is not a representative
of Brookstone; d) accessories used in conjunction
with a covered product; e) a product or part
that has been modied to alter functionality or
capability; f) items intended to be periodically
replaced by the purchaser during the normal
life of the product including, without limitation,
batteries or light bulbs; g) any product sold
“as is” including, without limitation, oor
demonstration models and refurbished items;
or h) a product that is used commercially or for a
commercial purpose.
BROOKSTONE SHALL NOT BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE
OF THIS PRODUCT, OR ARISING OUT OF
ANY BREACH OF THIS WARRANTY. TO THE
EXTENT PERMITTED BY APPLICABLE LAW,
BROOKSTONE DISCLAIMS ANY AND ALL
STATUTORY OR IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN
OR LATENT DEFECTS. IF BROOKSTONE
CANNOT LAWFULLY DISCLAIM STATUTORY
OR IMPLIED WARRANTIES, THEN TO THE
EXTENT PERMITTED BY LAW, ALL SUCH
WARRANTIES SHALL BE LIMITED IN
DURATION TO THE DURATION OF THIS
EXPRESS WARRANTY.
Some states disallow the exclusion or limitation of
incidental or consequential damages or how long
an implied warranty lasts, so the above exclusions
or limitations may not apply to you. This warranty
gives you specic legal rights and you may also
have other rights, which vary from state to state.
Instructions Doc. Size: 270mm W x 115mm H Folded Size: 50mmW x 115mmH
Output at 100% Prints 1/1 Black Finishing: Trim to Crops; Accordion Fold: 5 folds
Fold
Fold
Fold
Fold
Fold
CHARGING THE SPEAKER USING THE SPEAKERPHONE
LOCATION OF PARTS
AND CONTROLS
1.
1
2
3
2.
Power Switch
3.
LED Indicator
Micro USB Port
1. Connect the USB Cable
(included) to the Micro USB
Port on the speaker.
2. With the speakers Power Switch o,
plug the other end of the USB Cable
into a USB port on a computer or USB
wall adapter (not included)
3. The LED Indicator will illuminate
red while charging, and the light
will go out when the speaker
is fully charged. Charges in
approximately 2 hours for up to
5 hours of listening enjoyment.
PAIRING YOUR DEVICE
1. Pairing for the rst time
Searching starts automatically
after power up. Simultaneously,
a tone will sound (the red and
blue lights will ash alternately).
In your device’s Bluetooth menu,
search for and select Executive
Speaker for pairing.
2. Automatic Pairing
After restarting the unit, it will pair
to the last connected device
automatically. When pairing is
complete, a tone will sound.
Re-pairing
To change the connected device,
hold down the power button for 1
second to enter pairing mode.
3.
Hands-free function when in
connection with the phone,
short press the power button
to pick-up the phone call, short
press the power button one
more time to hang on the call.
1.
1.
2.
If no devices are found after
6 minutes in searching mode,
the speaker will turn o
automatically.
The speakers battery level will
display on your device if it is an
iPhone. Alerting you to the
remaining charge on the speaker.
OTHER FUNCTIONS
