Building Robotics FS-D2 Intelligent Light Sensor for Smart Networked Energy Saving Lighting Systems User Manual PhysicalInstall
Enlighted, Inc. Intelligent Light Sensor for Smart Networked Energy Saving Lighting Systems PhysicalInstall
Users Manual
Page 1
Cautionary Suggestions
•Disconnect all power before installation or service.
•Installation and maintenance must be performed by qualified
personnel.
•Installations and maintenance must be performed in accordance
with state, local, and national electrical codes and requirements.
Installation Steps
Page 2 Page 3
Fixture Mount
DALI Sensor (D2)
Installation
Instructions
Figure 1: Fixture Mount DALI Sensor
Shipped Components
•DALI Sensor (D2)
Tools You May Need
•Wire cutter and stripper
Supplies You May Need
•18 AWG Solid Copper Wire, rated >=300V
Step Description
1 Turn off all power to the light fixture by switching off the circuit
breaker.
2 The face of the sensor is only 1.08 inches (27mm) in diameter and is
designed to mount in a ½ inch trade size (0.875 inch) hole.. (All parts
of the sensor are inside the lighting fixture except for a ring and
spring.)
3 Determine the location for the sensor in fixture, and either remove
an existing ½ inch knockout or cut a hole in the fixture.
4 Orient the sensor and measure the length between it and the LED
driver “DALI connections”, and cut two lengths of 18 AWG wire
that are at least this length plus 1 inch.
5 Strip each end of the 2 wires leaving 3/8inch of exposed wire.
6Insert one end of the wires in the sensor’s wire holes and the other in
the DALI LED driver “DALI connections” wire holes
7 Remove (by unscrewing) the outer ring from the sensor (saving the
ring and pressure spring). On the inside of the fixture, insert the
sensor in the hole in the fixture and on the outside of the fixture,
replace the spring and screw back on the outer ring. Tighten firmly,
but do no over tighten.
8 Ready the fixture for use, and when done, restore power to the
fixture.
<documentID>
Figure 2: Mechanical dimensions of the DALI Sensor
Figure 3: Wiring Diagram
This installation assumes that you have already installed the DALI
LED driver.
FCC and Industry Canada Compliance Information
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
USA
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
•this devicemay not cause harmful interference, AND
•this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by Enlighted Inc. could void the
user's authority to operate the equipment.
Canada
This device complies with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions:
•this devicemay not cause harmful interference, AND
•this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by Enlighted Inc. could void the
user's authority to operate the equipment.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes:
•l'appareil ne doit pas produire de brouillage, ET
•l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Copyright © 2014 Enlighted Inc. All rights reserved.
All other brand or product names are trademarks of
their respective companies or organizations.
TechnicalSupport
For questions regardingthe installation or operation of this product,
contact Enlighted
Technical Support: support@enlightedinc.com
Company Contact Information
Location: 930 Benecia avenue, Sunnyvale, CA 94085
Phone: +1.650.964.1094
Web: enlightedinc.com
CA Contractor’s License: CCL# 980903
Page 4 Page 5 Page 6
Model: FS-D2
FCC ID: AQQ-FS-D2
Industry Canada: 10138A-FSD2
