Bury and Co KG CCBTL Handsfree Car Kit User Manual
Bury GmbH & Co KG Handsfree Car Kit
user manual
Owner's Manual Part No: MZDA-A2DP-OM
®
Bluetooth Mobile Phone Kit
Owner's Manual
Issue X - XX/XX/14
02 Owner's Manual Part No: MZDA-A2DP-OM
Contents
Overview
Introduction
Bluetooth Wireless Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mobile Phone Functionality. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Further Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Audio System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Up Your Mobile Phone
Pairing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pairing Multiple Mobile Phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting Your Mobile Phone (After Initial Pairing) . . . . . . . . . . . . . . .
Phone Functions
Dialling Using Your Mobile Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voice Dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Answering/Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rejecting a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Redialling Last Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Private Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cancelling Bluetooth Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Streaming A2DP Audio
A2DP via Mobile Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting/Pairing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A2DP via Mazda Bluetooth Audio Transmitter . . . . . . . . . . . . . . . . . . . . .
Connecting/Pairing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thank you for purchasing a Mazda Bluetooth mobile phone kit. Before using the
Mazda Bluetooth mobile phone kit, thoroughly read this manual and follow the
instructions on how to operate this product.
04
05 - 06
05
05
05
06
06
06
06 - 07
06
07
07
08 -09
08
08
08
08
09
09
09
09
10-12
10
10
10
10
11
12
11
Bluetooth Mobile Phone Kit Owner's Manual
Contents - Continued
System Reset
Troubleshooting
Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A2DP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Specifications
FCC Notice
Further Information Contact
12
13 - 14
13
14
15
15
16
03
Owner's Manual Part No: MZDA-A2DP-OM
Bluetooth Mobile Phone Kit Owner's Manual
Overview
Initial Phone Pairing
1. Turn key to accessories.
2. Hold Bluetooth button pressed for 4 seconds.
3. Activate Bluetooth on phone and search for Bluetooth device.
4. Select device ‘MAZDA’
5. Key password: ‘0000’
Connecting Phone
Automatic - Activate Bluetooth on phone and turn car on.
Manual - Turn car on, then activate Bluetooth on phone and press
Bluetooth button once.
Incoming Call
Answer - Press Bluetooth button once.
Reject - Press and Hold Bluetooth button for 3 seconds.
Making a Call
Voice dial - Press Bluetooth button once.
Redial - Press Bluetooth button twice.
During a Call
Activate Private Mode - Press and hold Bluetooth button for 3 seconds.
Deactivate Private Mode - Press Bluetooth button once.
Activate Call Hold - Press Bluetooth button twice.
Deactivate Call Hold - Press Bluetooth button twice.
End Call - Press Bluetooth button once.
04 Owner's Manual Part No: MZDA-A2DP-OM
Bluetooth Mobile Phone Kit Owner's Manual
Bluetooth Mobile Phone Kit Owner's Manual
Introduction
Your Bluetooth mobile phone kit allows you to answer incoming calls on your
mobile phone without looking at or touching your mobile phone. Your Bluetooth
voice capable mobile phone needs to only be inside the vehicle for it to connect
to the Bluetoothmobile phone kit.
Bluetooth Wireless Technology
Bluetooth devices communicate using radio waves. The Bluetooth
mobile phone kit is specifically designed for mobile phones that support
Bluetooth wireless technology. The Bluetooth mobile phone kit can be
used with devices that support the hands-free profile. "Profile" in this
instance means a set of Bluetooth commands that your mobile phone
uses for controlling your Bluetoothmobile phone kit.
Your Bluetooth mobile phone and Bluetooth mobile phone kit do not
need to be in a line of sight. For example, your mobile may be in your bag
whilst connected to the Bluetooth mobile phone kit. The two devices
need to be within a maximum of 10 metres of each other.
Mobile Phone Functionality
Mobile phones differ in their method of menu navigation. Furthermore,
software releases of mobile phones with the same design can vary
significantly. Therefore, please carefully read the operating guidelines of
your mobile phone. Specifically take note of the functions relating to the
topics ’Bluetooth’, ‘Hands-Free’ and ‘Headset Mode’.
The capacity of your mobile phone's battery can quickly decrease when
the Bluetooth function is active. If you do not want to use the Bluetooth
function (i.e. when leaving your vehicle for an extended period) then
deactivate this function on your mobile phone.
Some functions described in this owners manual may not be available on
your mobile phone.
Further Information
Refer to your mobile phone's owners manual, mobile phone retailer or
mobile phone service provider for information that relates specifically to
your mobile phone. If you have any questions concerning the installation
or operation of your Bluetooth mobile phone kit, please contact your
Authorised Mazda Dealer.
05
Owner's Manual Part No: MZDA-A2DP-OM
Definitions
Paired: The mobile phone handset is set up to communicate with the
Bluetoothmobile phone kit.
Connected: The mobile phone handset is currently linked with the
Bluetooth mobile phone kit. The functions on the Bluetooth mobile phone
kit are active.
HF: Hands Free profile, used to transmit Bluetooth call data from a phone
to the Bluetooht kit.
AVRCP: Audio/Video Remote Control Profile, used to navigate through
music features such as Play/Pause/Next/previous.
A2DP: Advanced Audio Distribution Profile, used to transmit stereo music
data from a Bluetooth device to the Bluetooth kit.
Bluetooth Microphone
Vehicle Audio System
The vehicle’s audio system volume is automatically muted when you
make or receive a call. The voice of the caller is heard through the audio
system and the volume of the Bluetooth mobile phone kit can be
adjusted using the microphone during a phone call.
Setting Up Your Mobile Phone
Pairing
The connection between your Bluetooth capable mobile phone and the
Bluetoothmobile phone kit can be established as follows:
1. Switch on your mobile phone.
Note: If Mazda Bluetooth Audio Transmitter is connected to iPod,
disconnect Transmitter from iPod.
2. Switch on the ignition.
3. Press and Hold the Bluetooth button for 4 seconds.
Bluetooth Mobile Phone Kit Owner's Manual
• Increase Volume
• Play A2DP*
• Next Track*
• Decrease Volume
• Pause A2DP*
• Previous Track*
Bluetooth Button
* Function in A2DP mode
06 Owner's Manual Part No: MZDA-A2DP-OM
Bluetooth Mobile Phone Kit Owner's Manual
4. Perform the following steps on your mobile phone:
a. Enter the Bluetooth menu.
b. Activate the Bluetooth function.
c. Search for Bluetooth devices.
d. Select the device labelled ‘MAZDA’.
e. Enter the following PIN: 0000. This establishes the connection between
your mobile phone and the Bluetoothmobile phone kit.
f. Set the mobile phone to accept Bluetooth connection requests
automatically without your permission.
If it is not possible to establish a connection, refer to Troubleshooting.
Pairing Multiple Mobile Phones
The Bluetooth mobile phone kit can be paired with up to seven mobile
phones, but can only be connected to one mobile phone at a time.
When the ignition is turned on, the Bluetooth mobile phone kit searches
for the most recently paired mobile phone. If this phone is not found, the
Bluetooth mobile phone kit will continue searching for the next most
recently paired mobile phone until a connection is made.
Connecting Your Mobile Phone (After Initial Pairing)
To connect your mobile phone to the Bluetoothmobile phone kit:
1. Move your mobile phone to within 10 metres of the Bluetooth mobile
phone kit, preferably inside the vehicle.
2. Ensure that your mobile phone is switched on and the Bluetooth function
on your mobile phone is enabled.
Note: Ensure iPod dongle is not connected to iPod.
3. Switch on the ignition. Ensure the radio is switched ON.
4. The Bluetooth mobile phone kit will search for the last paired phone,
followed by the next recently paired phone, until a connection is made.
Note: If there are multiple phones in the vehicle which have been
previously paired to the system, you must disconnect the currently
paired phone before you can use the second phone in the vehicle.
Follow the standard pairing procedure to connect the second phone.
07
Owner's Manual Part No: MZDA-A2DP-OM
Phone Functions
Dialling Using Your Mobile Phone Handset
When the Bluetooth mobile phone kit is connected to your mobile phone,
you can make calls using your mobile phone handset.
Voice Dialling
If you wish to use the voice dial functions of your mobile phone (provided
that your mobile phone is capable), entries for dialling phone numbers
with voice dialling may have to be pre-recorded. These voice
commands can then be called via the Bluetooth mobile phone kit with
the active Bluetooth connection. To configure voice dialling on your
mobile phone, refer to your mobile phone's owner's manual.
To voice dial:
1. Ensure that there is no call in progress.
2. Press the Bluetooth button once. A tone will be heard indicating
readiness to accept voice input.
3. Speak into microphone.
4. The Bluetooth mobile phone kit plays back the voice tag and dials the
corresponding phone number.
Answering / Receiving a Call
To answer an incoming call:
1. Press the Bluetooth button once.
Rejecting a Call
If you do not wish to answer a call:
1. Press and hold the Bluetooth button until the ring tone stops.
Bluetooth Mobile Phone Kit Owner's Manual
08 Owner's Manual Part No: MZDA-A2DP-OM
It is dangerous and may be illegal to use a hand-held mobile phone
when you are driving. Always pull over to the side of the road (when
safe to do so) before answering or making a call with a hand-held
mobile phone.
Important
It is dangerous and may be illegal to use a hand-held mobile phone
when you are driving. Always pull over to the side of the road (when
safe to do so) before answering or making a call with a hand-held
mobile phone.
Important
Bluetooth Mobile Phone Kit Owner's Manual
Ending a Call
To end a call:
1. Press the Bluetooth button once.
Redialling Last Number
To redial the last number dialled:
1. Ensure that there is no call in progress.
2. Press the Bluetooth button twice.
Private Mode
Private Mode transfers the call from hands-free to the mobile phone
handset.
To activate Private Mode:
1. Press and hold the Bluetooth button for three seconds.
2. Continue the call on the mobile phone handset.
Cancelling Bluetooth Connection
The Bluetooth connection is automatically disconnected when:
1. You move your mobile phone outside of the reception range of the
Bluetooth mobile phone kit. (approximately 10 metres)
OR
2. The ignition switch is turned off and the system is not on a call.
OR
3. The mobile phone is switched off.
It is dangerous and may be illegal to use a hand-held mobile phone
when you are driving. Always pull over to the side of the road (when
safe to do so) before answering or making a call with a hand-held
mobile phone.
Important
09
Owner's Manual Part No: MZDA-A2DP-OM
Streaming A2DP Audio
The Bluetooth kit can stream audio music from an A2DP device via your stereo.
A2DP via Mobile Phone
Given that your mobile phone is enabled with A2DP Bluetooth Profile, you
will be able to stream the music via the Bluetooth kit to your stereo.
Note: The radio has to be set to AUX mode in order for the music to be
heard.
Connecting/Pairing
Given a mobile phone is enabled with A2DP it will pair and connect
automatically after the phone has previously been paired and
connected.
See ‘Setting up your mobile phone’ section.
Functions
Using your mobile phone, open the music player and select the desired
song you want to play. The music will be heard through the stereo.
All functionality can be done through the mobile phone. If AVRCP
Bluetooth Profile is available on the phone the following functions can be
done through the microphone:
Previous Track - Short Press ‘-’ button on Bluetooth microphone.
Next track - Short Press ‘+’ button on Bluetooth microphone.
Pause - Long Press ‘-’ button on Bluetooth microphone.
Play - Long Press ‘+’ button on Bluetooth microphone.
Note: Connecting any other media device to the vehicle AUX IN jack will
deactivate A2DP streaming.
A2DP via Mazda Bluetooth Audio Transmitter
Given you have a Mazda Bluetooth Audio Transmitter
you will be able to stream the music from your iPod via
the Bluetooth kit to your stereo.
Note: The radio has to be set to AUX mode in order for
the music to be heard.
Bluetooth Mobile Phone Kit Owner's Manual
10 Owner's Manual Part No: MZDA-A2DP-OM
It is dangerous and may be illegal to use a hand-held mobile phone
when you are driving. Always pull over to the side of the road (when
safe to do so) before answering or making a call with a hand-held
mobile phone.
Important
Connecting/Pairing
When the Mazda Bluetooth Audio Transmitter is not connected to the
iPod:
1. Switch on ignition.
2. Plug the Mazda Bluetooth Audio Transmitter into the iPod to begin the
pairing and connecting process.
3. While searching, the light on the adaptor will flash quickly. Once
connected the light will flash twice per second.
When Mazda Bluetooth Audio Transmitter is connected to iPod:
1. Switch ignition on.
2. Turn iPod on by pressing any button on the iPod.
3. Press the play button once to begin the pairing and connecting process.
4. While searching, the light on the adaptor will flash quickly. Once
connected the light will flash twice per second.
Bluetooth Mobile Phone Kit Owner's Manual
11
Owner's Manual Part No: MZDA-A2DP-OM
It is dangerous and may be illegal to use a hand-held mobile phone
when you are driving. Always pull over to the side of the road (when
safe to do so) before answering or making a call with a hand-held
mobile phone.
Important
Note: If connecting both a mobile phone and the Mazda Bluetooth Audio Transmitter to
the Bluetooth kit, it is recommended that the phone is connected first.
When using a phone which can enable/disable Bluetooth profiles (such as
Blackberry) manually disable Audio Source (A2DP) and AV Remote Control
target (AVRCP) profiles when using the iPod Adaptor.
Functions
All functionality can be done through the iPod itself however the
following functions can also be done through the microphone:
Previous Track - Short Press ‘-’ button on Bluetooth microphone.
Next track - Short Press ‘+’ button on Bluetooth microphone.
Pause - Long Press ‘-’ button on Bluetooth microphone.
Play - Long Press ‘+’ button on Bluetooth microphone.
The radio has to be set to AUX mode in order for the music to be heard.
Note: Connecting any other media device to the vehicle AUX IN jack will
deactivate A2DP streaming.
System Reset
If the Bluetooth Mobile Phone Kit is experiencing issues with operation or
connection, you can perform a System Reset to restore it to the factory
settings.
1. Switch on the ignition. Ensure the radio is switched ON.
2. Hold the Bluetooth button for 12 seconds.
3. At 10 seconds, the radio will ‘mute’. At 12 seconds, the radio will ‘mute’
again confirming the reset is complete.
Note: It is also recommended to delete any Bluetooth connections from your
mobile phone and connect to the device again. Refer to ‘Setting Up Your
Mobile Phone (Pairing)’ on page 6 of this manual and your mobile
phone’s owner’s manual.
Bluetooth Mobile Phone Kit Owner's Manual
12 Owner's Manual Part No: MZDA-A2DP-OM
When using Partially Compatible Nokia phones together with the Mazda
Bluetooth Audio Transmitter, the phone’s Bluetooth connection may be lost
when keypad tones or error tones are sounded. It is recommended to disable
any tones and limit the phone usage while connected to the Bluetooth kit. To
reconnect manually, enable the connection via the handset.
Problem Cause and Solution
1. Ignition is turned off. Turn on the ignition.
2. Already connected to another paired mobile
phone. Switch off other paired mobile phone(s) in the
vehicle.
3. The mobile phone is not supported. Refer to your
Authorised Mazda Dealer for phone compatibility list.
1. Ignition is turned off. Turn on the ignition.
2. Mobile phone is not paired to the Bluetooth mobile
phone kit. Follow the instructions to pair the mobile
phone to the Bluetoothmobile phone kit.
3. Automatic connection not set on the mobile phone.
Follow your mobile phone owners handbook to
ensure that authorised connection is enabled for the
Bluetooth car kit.
4. Bluetooth kit may have frozen up. Kit needs to be
reset, follow instructions to perform a System Reset
1. Mobile phone voice dialling is not available on your
mobile phone. Check your mobile phone owners
handbook.
2. No voice tags saved to your mobile phone. Refer to
your mobile phone owners handbook.
3. Mobile phone is not fully compatible with the
Bluetooth car kit. Refer to your Authorised Mazda
Dealer for phone Compatibility list.
1. Check the incoming call alert is not deactivated in
the mobile phone settings.
2. Check the mobile phone is not set to ‘silent’ mode.
1. Your mobile phone has no last redialled numbers.
Make the initial call from the mobile phone handset.
2. This feature is not enabled on your mobile phone.
3. Mobile phone is not fully compatible with the
Bluetooth car kit. Refer to your Authorised Mazda
Dealer for phone compatibility list.
1. Bluetooth system volume is too loud. Turn down the
volume on the Bluetooth system during the call.
Refer to your Authorised Mazda Dealer, or call Lumen
Australia on (03) 87871000 for further information.
Mobile phone will not pair
up with the Bluetooth mobile
phone kit.
Mobile phone will not
connect to the Bluetooth
mobile phone kit.
Voice dialling does not
work.
Incoming call does not
initiate an audible alert.
Redial does not work.
An echo is present.
Troubleshooting - Phone
Problem is still Present.
Bluetooth Mobile Phone Kit Owner's Manual
13
Owner's Manual Part No: MZDA-A2DP-OM
Problem Cause and Solution
1. Ignition is turned off. Turn on the ignition.
2. Mazda Bluetooth Audio Transmitter pairing time
expired. Reset Mazda Bluetooth Audio Transmitter by
disconnecting it from the iPod and repeat pairing
procedure.
3. Another A2DP device is already connected to the
Bluetooth kit. Hold down the ‘-’ button on the
microphone until a tone is heard. Redo pairing
procedure.
4. iPod battery low. Connect the charging cable. Redo
pairing procedure.
1. Ignition is turned off. Turn on the ignition.
2. Volume is on mute or set to low. Adjust volume on
vehicle’s audio system.
3. iPod battery low. Connect the charging cable. Redo
pairing procedure.
4. Mazda Bluetooth Audio Transmitter is not connected
to Bluetooth kit, re-connect Transmitter.
5. Radio is not set to Auxiliary input. Set radio to Auxiliary
input.
6. iPod is paused. Press play button.
7. Another media device is connected to the vehicle
AUX IN jack. Remove any plug from vehicle AUX IN
jack.
1. Bluetooth phone is connected and active/in call.
iPod functionality is not present when phone is
active/in call.
2. Bluetooth remote control profile is connected to
phone instead of dongle. Hold the ‘-’ button down
on the microphone until a tone is heard. Redo pairing
procedure.
1. Volume from Mazda Bluetooth Audio Transmitter is
fixed. Adjust volume from vehicle’s audio system.
Refer to your Authorised Mazda Dealer, or call Lumen
Australia on (03) 87871000 for further information.
Cannot pair or connect
Mazda Bluetooth Audio
Transmitter to Bluetooth Kit.
No iPod/Mobile A2DP audio
can be heard.
No iPod functionality
through Bluetooth Kit.
Cannot adjust volume from
iPod
Troubleshooting - A2DP
Problem is still present.
Bluetooth Mobile Phone Kit Owner's Manual
14 Owner's Manual Part No: MZDA-A2DP-OM
Technical Specifications
•Bluetooth 1.2 wireless technology, hands free system.
• Wireless radio connection with the mobile phone.
• Full duplex hands-free conversation with echo cancellation.
• Background noise reduction.
• Voice recognition dialling (if supported by the mobile phone).
• Automatic muting of the car radio system when a call is active.
• Operating button integrated with the vehicle styling.
• Manual number dial.
• Last number redial (if supported by the mobile phone).
• Private mode.
• Pairing of multiple phones (connection of one mobile phone at a time).
• Profiles enabled HF, A2DP, AVRCP.
Bluetooth Mobile Phone Kit Owner's Manual
15
Owner's Manual Part No: MZDA-A2DP-OM
FCC Notice
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
To comply with FCC RF exposure compliance requirements, a separation
distance of at least 20 cm must be maintained between the antenna of this
device and all persons.
Refer to your Mazda Dealer for further information.
Please note that all information, illustrations and specifications in this Handbook are based on the latest
product information available at the time of printing. Mazda reserves the right to make any changes at
any time without notice and without incurring any obligation.
®
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by
Mazda is under licence. Other trademarks and trade names are those of their respective owners.
COPYRIGHT Mazda 2009
Bluetooth Mobile Phone Kit Owner's Manual
Owner's Manual Part No: MZDA-A2DP-OM
Reproduction in whole or part prohibited without
written approval of Mazda Australia.Pty.Ltd.
iPod is a trademark of Apple Inc., registered in the US and other countries.
