Mini DW Ext Term - Tilt—Installaon Instrucons
Mini DW Ext Term - Tilt Sensor
1 - Tilt Sensor 1- Mounng Tape 2 - Baeries ( 2- 3VDC CR 2032) Instrucons
Tamper
switch
Doc # I-RF-MDWSX Rev. A Jan 2015
Installaon
1. Remove the transmier’s cover by pressing in on
the small rectangular latch on the end of the cover
and li up
2. Mount the sensor base directly to the surface us-
ing the mounng tape provided.
3. Remove the baery isolator tabs from both baer-
ies on the sensor
4. Replace the cover on the transmier
5. Enroll the senor into the control panel according
the instrucons
Note: Mounng the transmier onto metal surfaces
may impact the eecve range of the transmier
Cover
Latch
Cover
Latch
Tamper
Base
Note: Baery Safety
Observe polarity when inserng
replacement baeries to avoid dam-
aging the sensor.
Risk of re, burns and explosion. Do
not recharge, disassemble, burn or
expose baeries to temperatures
above 100C (212F)
Dispose of used baeries properly
and in accordance with all local laws
Keep baeries away from children
Baeries
Tilt Sensor
The Tilt sensor is designed to mount on an overhead
garage door, and provide and open/close indicaon.
Mini DW Ext Term - Tilt—Installaon Instrucons
Mini DW Ext Term - Tilt Sensor
1 - Tilt Sensor 1- Mounng Tape 2 - Baeries ( 2- 3VDC CR 2032) Instrucons
Tamper
switch
Doc # I-RF-MDWSX Rev. A Jan 2015
Installaon
1. Remove the transmier’s cover by pressing in on
the small rectangular latch on the end of the cover
and li up
2. Mount the sensor base directly to the surface us-
ing the mounng tape provided.
3. Remove the baery isolator tabs from both baer-
ies on the sensor
4. Replace the cover on the transmier
5. Enroll the senor into the control panel according
the instrucons
Note: Mounng the transmier onto metal surfaces
may impact the eecve range of the transmier
Cover
Latch
Cover
Latch
Tamper
Base
Note: Baery Safety
Observe polarity when inserng
replacement baeries to avoid dam-
aging the sensor.
Risk of re, burns and explosion. Do
not recharge, disassemble, burn or
expose baeries to temperatures
above 100C (212F)
Dispose of used baeries properly
and in accordance with all local laws
Keep baeries away from children
Baeries
Tilt Sensor
The Tilt sensor is designed to mount on an overhead
garage door, and provide and open/close indicaon.
Mounng
Doc # I-RF-MDWSX Rev. A Jan 2015
Specicaons:
Dimensions: 2.5 X 1 X .5
Baeries:
(2) - Panasonic CR2032
Energizer CR2032
Duracell DL2032
2.5”
.5”
1”
Tilt sensor orientaon:
The Tilt sensor must be orientated properly
in order to recognize an opening or closing
Aer installing press the
lt sensor down in the
housing as shown
For overhead garage door mounng, mount the
sensor near the top of the door with the lt
sensor facing down as shown
