User Manual 2
27
➍Plug the phone cord into the phone jack on the wall.
➎Hang the bracket on the phone wall plate.
Getting Started
MA300welcome.book Page 27 Friday, April 12, 2002 9:30 AM
28
➏Plug the other end of the phone cord into the jack on
the back of the base.
➐Plug the power cord into a power outlet if it is not
already plugged in.
Getting Started
MA300welcome.book Page 28 Friday, April 12, 2002 9:30 AM
29
➑Insert the four tabs on the wall mount into the four slots
on the back of the base then push down.
mem
mute
flash
redial
chan
1
2
3
4
56
7
8
0
*
#
9
Getting Started
MA300welcome.book Page 29 Friday, April 12, 2002 9:30 AM
30
Setting Tone or Pulse
➊Press flash.
➋Press: * for tone operation or
# for pulse operation
➌Press flash.
Tip: If you select pulse, you can still use touch tone menu
systems. To activate tone temporarily for one call, press
the * key.
Setting the Ringer Tone
➊Press flash.
➋Press: \Ring tone 1
]Ring tone 2
➌Press flash.
Getting Started
MA300welcome.book Page 30 Friday, April 12, 2002 9:30 AM
31
Now that you have set up your phone, read the next section
of this guide for information on how to make calls and store
phone numbers in memory.
CAUTION
The long-term characteristics or the possible physiological
effects of Radio Frequency (RF) electromagnetic fields have
not been evaluated by UL.
If you are concerned with the risk of RF exposure, you may
want to limit the duration of calls and position the antenna
as far away from your body as is practical.
Getting Started
MA300welcome.book Page 31 Friday, April 12, 2002 9:30 AM
32
How to Use
6
lmn
020109-O
Talk: Make or
answer a call,
hang up
Flash: Use for call
waiting and 3-way
calling
Turn ringer on (up)
and off (down)
Adjust handset
volume
Chan: Use if you
hear interference or
static
Mute: Press to mute
microphone (caller will
not hear you). Press
again to unmute.
Redial last called
number (up to 32 digits)
How to Use
MA300welcome.book Page 32 Friday, April 12, 2002 9:30 AM
33
How to Locate a Lost Handset
➊Press page to find a lost handset.
➋Follow the sound to locate the lost handset.
Tip: No need to hurry. The handset will not stop beeping
until you press page again.
➌Press page again to stop the beeping.
Press to page the
person carrying the
handset or to locate
a lost handset.
Press again to
cancel the page (or
press Talk on the
handset).
How to Use
MA300welcome.book Page 33 Friday, April 12, 2002 9:30 AM
34
Storing a Number into Memory
You can store 10 phone numbers into memory with up to
20 digits each.
➊Turn the phone off.
➋Press mem.
➌Press any number key (Ñ through É) to select the
memory location.
➍Press mem.
➎Enter the phone number you want to store, or press
redial to store the last number you dialed.
➏ Press mem.
Tip: To insert a pause in the dial sequence (for example, if
you have to dial “9” then wait for a dial tone), press
the # key twice.
How to Use
MA300welcome.book Page 34 Friday, April 12, 2002 9:30 AM
35
Dialing a Number from Memory
➊Press â.
➋Press mem.
➌Press the number key (Ñ through É) to select the
memory location of the phone number you want to call.
Tip: You can use your memory numbers to simplify calling
card calls and other calls that require multiple strings
of numbers.
For example, if you stored your calling card number
in memory location 1, your calling card password in
location 2, and the phone number you want to call in
location 3, you would press the following keys to call
the number in location 3:
â mem \ mem ] mem ^
How to Use
MA300welcome.book Page 35 Friday, April 12, 2002 9:30 AM
36
Storing and Calling Emergency Numbers
When storing an emergency number (such as 911) into
memory or making a test call to an emergency number
stored in memory, remain on the line and briefly explain to
the dispatcher the reason for the call. This should be
performed in off-peak hours, such as early morning or late
evening.
How to Use
MA300welcome.book Page 36 Friday, April 12, 2002 9:30 AM
37
Troubleshooting
What to do if...
The phone
doesn’t work at
all (no lights,
no dial tone)
• Check the power and phone
connections. Is the power cable
plugged in at both ends? Phone cable?
• Check the battery. Is it charged? Does
it fit properly?
No dial tone • Check the items listed above.
• Move closer to the base.
• Verify dial tone using another phone. If
you have no dial tone on that phone, call
your phone company.
• Disconnect the phone and reconnect it
at a different phone and power outlet.
Troubleshooting
MA300welcome.book Page 37 Friday, April 12, 2002 9:30 AM
38
You can’t
receive calls
• Check the battery. Is it charged? Does
it fit properly?
• Make sure the handset ringer is turned
on.
• Move closer to the base.
• Unplug other phones. You may have too
many phones on your telephone line to
allow all of them to ring.
Troubleshooting
MA300welcome.book Page 38 Friday, April 12, 2002 9:30 AM
39
The signal is
weak or has
noise or static
• Press chan to select a different
channel.
• Check the battery and power.
• Move closer to the base.
• Move the base to a different power
outlet (especially if the phone is sharing
an outlet with an appliance).
You hear other
calls on your
line
• Press chan to select a different
channel.
• Hang up. Place the handset into the
base. Wait 30 seconds then try again.
• Disconnect the base from power and
phone.
Troubleshooting
MA300welcome.book Page 39 Friday, April 12, 2002 9:30 AM
40
The battery
won’t charge
• Check the base. Is it properly
connected? Are its contacts clean and
dry?
• Check the battery contacts. Make sure
the battery is connected properly.
• Is it an old battery? Replace the battery.
The battery
loses charge
faster than
normal
• Is it a new battery? A new battery needs
to be charged at least 12 hours before
use to maintain normal talk time.
• Is it an old battery? Replace the battery.
TroubleshootingTroubleshooting
MA300welcome.book Page 40 Friday, April 12, 2002 9:30 AM
41
Warranty
Motorola Limited Warranty
for Consumer Products, Accessories, and Software
Purchased in the United States or Canada
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones and consumer two-way radios that operate via Family
Radio Service or General Mobile Radio Service (“Products”),
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on CD-
Roms or other tangible media and sold for use with these Products
(“Software”) to be free from defects in materials and workmanship
under normal consumer usage for the period(s) outlined below. This
limited warranty is a consumer’s exclusive remedy, and applies as
follows to new Motorola Products, Accessories and Software
purchased by consumers in the United States or Canada, which are
accompanied by this written warranty:
Warranty
MA300welcome.book Page 41 Friday, April 12, 2002 9:30 AM
42
Products and Accessories
as defined above, unless otherwise pro-
vided for below. Length of coverage: one (1) year
from the date of pur-
chase by the first consumer purchaser of the product unless otherwise
provided for below.
•
Decorative Accessories and Cases.
Decorative covers, bezels,
PhoneWrap™ covers and cases. Length of coverage: limited lifetime
warranty for the lifetime of ownership by the first consumer purchaser
of the product.
•
Monaural Headsets.
Ear buds and boom headsets that transmit
mono sound through a wired connection. Length of coverage: limited
lifetime warranty for the lifetime of ownership by the first consumer
purchaser of the product.
•
Consumer Two-Way Radio Accessories.
Length of coverage:
Ninety (90) days from the date of purchase by the first consumer
purchaser of the product.
Warranty
MA300welcome.book Page 42 Friday, April 12, 2002 9:30 AM
43
Warranty
• Products and Accessories that are Repaired or Replaced.
Length of coverage: The balance of the original warranty or for ninety
(90) days from the date returned to the consumer, whichever is
longer.
Software.
Applies only to physical defects in the media that embodies
the copy of the software (e.g. CD-ROM, or floppy disk). Length of
coverage: ninety (90) days
from the date of purchase.
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and
replacement of parts due to normal wear and tear are excluded from
coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80%
of their rated capacity and batteries that leak are covered by this
limited warranty.
Warranty
MA300welcome.book Page 43 Friday, April 12, 2002 9:30 AM
44
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or
food; (c) use of the Products or Accessories for commercial purposes
or subjecting the Product or Accessory to abnormal usage or
conditions; or (d) other acts which are not the fault of Motorola, are
excluded from coverage.
Use of Non-Motorola Products and Accessories.
Defects or
damage that result from the use of Non-Motorola branded or certified
Products, Accessories, Software or other peripheral equipment are
excluded from coverage.
Unauthorized Service or Modification.
Defects or damages
resulting from service, testing, adjustment, installation, maintenance,
Warranty
MA300welcome.book Page 44 Friday, April 12, 2002 9:30 AM
45
Warranty
alteration, or modification in any way by someone other than Motorola,
or its authorized service centers, are excluded from coverage.
Altered Products.
Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken
seals or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola housings, or parts,
are excluded from coverage.
Communication Services.
Defects, damages, or the failure of
Products, Accessories or Software due to any communication service
or signal you may subscribe to or use with the Products, Accessories
or Software is excluded from coverage.
Software Embodied in Physical Media.
No warranty is made that the
software will meet your requirements or will work in combination with
any hardware or software applications provided by third parties, that
the operation of the software products will be uninterrupted or error
free, or that all defects in the software products will be corrected.
Warranty
MA300welcome.book Page 45 Friday, April 12, 2002 9:30 AM
46
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided
“as is” and without warranty.
Who is Covered?
This warranty extends to the first end-user purchaser, only.
What will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product,
Accessory or Software, including but not limited to personal contacts,
games and ringer tones, will be reinstalled. To avoid losing such data,
software and applications please create a back up prior to requesting
service.
Warranty
MA300welcome.book Page 46 Friday, April 12, 2002 9:30 AM
47
Warranty
How to Get Warranty Service or Other Information
For accessories and software, please call the telephone number
designated above for the product with which they are used. You will
receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center.
To obtain service, you must include: (a) a copy of your receipt, bill of
sale or other comparable proof of purchase; (b) a written description of
the problem; (c) the name of your service provider, if applicable; (d) the
name and location of the installation facility (if applicable) and, most
importantly; (e) your address and telephone number.
In the USA, call: In Canada, call:
1-800-353-2729 1-800-461-4575
TTY 1-888-390-6456 TTY 1-888-390-6456
Warranty
MA300welcome.book Page 47 Friday, April 12, 2002 9:30 AM
48
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR
REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT
SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE,
OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF
BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR
APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE
PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT
THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Warranty
MA300welcome.book Page 48 Friday, April 12, 2002 9:30 AM
49
Warranty
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation
on the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from
state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as the
exclusive rights to reproduce and distribute copies of the Motorola
software. Motorola software may only be copied into, used in, and
redistributed with, the Products associated with such Motorola
software. No other use, including without limitation disassembly of
such Motorola software or exercise of the exclusive rights reserved for
Motorola, is permitted.
Warranty
MA300welcome.book Page 49 Friday, April 12, 2002 9:30 AM
Notes
MA300welcome.book Page 50 Friday, April 12, 2002 9:30 AM
Notes
MA300welcome.book Page 51 Friday, April 12, 2002 9:30 AM
Notes
MA300welcome.book Page 52 Friday, April 12, 2002 9:30 AM
MA300welcome.book Page 53 Friday, April 12, 2002 9:30 AM
6881040B30-A
@6881040B30@
motorola.com
MA300welcome.book Page 54 Friday, April 12, 2002 9:30 AM
