CDVI WIRELESS S P A S3RT Part 15 Security / Remote Control Transmitter User Manual PWJS3RT UserMan
CDVI WIRELESS S.P.A. Part 15 Security / Remote Control Transmitter PWJS3RT UserMan
PWJS3RT_UserMan
The Installer’s Choice
www.cdvi.ca
www.cdvi.ca
1 - INTRODUCTION
The remote control RADIUM R1 - R2 - R4 is a 1-2-4 buons key chain style transmier, operang at 433,92
MHz. It has been designed for the control of automac closing systems and an-burglar systems, thanks to
its very high security coding system (KeeLoq® Hopping code). The code sent by the transmier changes at
each acvaon, avoiding any scanning and copying risk. A special algorithm allows to keep synchronized
transmier and receiver. The transmier can be equipped with passive tag ( see table for the reference ) The
CR 2016 lithium baeries of the transmier have a shelf life of about 6 months. The product fully complies
with Part 15 of FCC Regulaons and the European Direcves 2006/95/CE, 2004/108/CE, 99/05/CE.
2 - TECHNICAL SPECIFICATIONS
Operang frequency: 433,92 MHz
Number of buons: 1-2-4
Baery: 2 x 3V lithium CR2016
Baery life: 18 to 24 months
Security code: Keeloq® Hopping code
Number combinaons: 2exp64
Operang temperature: -20°F to +131°F
Overall dimensions: 2.83”x 1.4”x 0.47”
Weight: 0.49 oz. (14 gr.)
Radium
Remote control
R1 R2 R4
P/N Descripon Tag ( 125 KHz )
R1 1 Buon Remote -
R1H 1 Buon Remote HID
R1P 1 Buon Remote Paradox
R1C 1 Buon Remote CDVI
R2 2 Buons Remote -
R2H 2 Buons Remote HID
R2P 2 Buons Remote Paradox
R2C 2 Buons Remote CDVI
R4 4 Buons Remote -
R4H 4 Buons Remote HID
R4P 4 Buons Remote Paradox
R4C 4 Buons Remote CDVI
3 - PRODUCT RANGE
WIRELESS TECHNOLOGY
The Installer’s Choice
8 - BATTERY ACCESS
To access the baery slide out the baery door as shown
in gure. Slide out the 2 old baeries and replace them
with the new ones [CR2016] respecng the polarity, with
the posive (+) side upward.
NOTE: Please dispose of the baeries properly according
to local laws and regulaons. Test proper baery instal-
laon by verifying that the LED illuminates when the
buon is pushed.
4 - NUMBERING
Each transmier is manufactured and sold with a die-
rent factory-set serial number.
6 - PROGRAMMING
The transmier must be programmed into your system
memory.
7 - OPERATION
A - Firmly depress the buon unl the small red BLUE
illuminates.
B - Aer the LED has illuminated, release the buon.
If the device you are aempng to acvate does not re-
spond, repeat steps A and B or consult secon 9
( Troubleshoong ) of this manual.
9 - TROUBLESHOOTING
PROBLEM SOLUTION
The system does not receive the
transmier signal.
The transmier LED is ON
Check to verify if the remote
is programmed into your system
The operang range is reduced
The transmier LED is blinking
Low baery : replace baeries
The system does responds.
The transmier LED is OFF
Baery empty : replace baeries
5 - MAIN COMPONENTS
This device complies with Part. 15 of the FCC Rules
Operaon is subject to the following two condions:
(1) This device may not cause harmful interference, and
(2) this device must accept interference received, including inter-
ference that may cause undesired operaon.
FCC ID : PWJS3RT
Noce
Any changes or modicaon to CDVI equipment not expressly
approved by CDVI could void the manufacturer’s warranty.
Buon A
Buon B
Buon C Buon D
Baery door
2 x CR2016
Blue LED
Key ring
Slide to
open
CDVI 1637 Highway 440 West, Laval, Québec, Canada, H7L3W3
Tel: (450) 682-7945, Toll Free Tel: 1-866-610-0102,
Fax: (450) 682-9590, Toll Free Fax: 1-866-682-9590
Manufactured by:
CDVI Wireless
Made in ITALY
WARRANTY
The warranty period for this product is 60 months, beginning from
the manufacturer date. During this period, if the product does not
work correctly, due to a defecve component, the product will be
repaired or substuted at our discreon. The guarantee does not
cover the plasc container integrity. Aer-sale service is supplied
at the factory.
IS-T15CDUK Rev. 0 15/1/2014
This EUT is in compliance with MPE for general populaon
/ uncontrolled exposure limits and it had been tested in
accordance with the measurement methods and procedures
specied in FCC 47 CFR § 1.1310 and 2.1091 .
To sasfy FCC RF exposure requirements for mobile transming devices,
a separaon distance of 20 cm or more should be maintained between
the antenna of this device and persons during device operaon. To ensure
compliance, operaons at closer than this distance are not recommended.
The antenna used for this transmier must not be co-located in conjuncon
with any other antenna or transmier.
