CETIS DCT1905 DECT Phone User Manual DCT1900 User Guide

CETIS,INC. DECT Phone DCT1900 User Guide

Contents

Users manual

INCLUDED IN YOUR PACKAGE
Cordless Handset AC Adapter
Base Unit User Guide
Battery Pack RJ-11 Line Cord
Rubber Battery Screw Cover RJ-45 Cable
Phillips Screw Clear Plastic Overlay
PREPARING TO USE THE DCT1900 SERIES
1. Prepare to install the battery into the cordless handset by
firmly pressing down on the top of the battery cover and
sliding it off. If cover is secured with a screw, remove the
screw first.
2. Locate the lightly embossed numbers “1” and “2” on the
battery’s plastic connector.
3. Insert the battery connector into the handset’s connector
with the embossed numbers facing up.
Note: The handset may “beep” when the battery is connected.This is not
an indication that the telephone is ready to use. To obtain optimal perform-
ance of the telephone, be sure to charge the battery for 15 to 20 hours.
4. Replace the battery compartment cover and retaining screw.
5. Insert the provided rubber screw cover.
6. Turn the telephone base so the back panel is facing you.
Insert either end of the RJ-45 cable into the jack on the back
of the telephone labeled LINE.
7. Insert the other end of the cable into the jack on the AC
adapter labeled PHONE.
8. Insert one end of the RJ-11 line cord into the jack on the AC
adapter labeled LINE.
9. Insert the other end of this line cord into a telephone jack.
10. Plug the AC adapter into an unswitched electrical outlet.
11.Once your telephone is connected, remove the plastic
overlay and place the paper faceplate over the keys. Replace
the plastic overlay by hooking the tabs on the overlay into
the recessed slots located on both sides. The overlay is
easiest to insert when the left or right side tabs are inserted
first, and the middle of the overlay is slightly bowed to allow
for insertion of the other tabs.
12.Place the cordless handset on the base unit.
CHARGING THE BATTERY
The rechargeable battery must be fully charged before using the
phone for the first time. It is recommended that that battery pack
be charged for approximately 15 to 20 hours, without interruption,
before use.To charge the battery, place the handset, keypad down,
in the base unit. Make sure the CHARGE LED on the base lights.
If the LED does not light:
1. Ensure that the AC adapter is plugged in.
2. Ensure that the AC adapter is not plugged into a switched
electrical outlet.
3. Ensure that the handset charging contacts at the bottom of
the handset are making good contact with the base unit’s
charging contacts.
CLEANING THE BATTERY CONTACTS
To maintain a good charge, it is important to clean all charging
contacts on the handset and base unit. Use a pencil eraser or
other contact cleaner. Do not use any liquids or solvents.
BATTERY SAFETY INSTRUCTIONS
1. Use only Teledex-approved battery replacements.
2. Dispose of used batteries according to local codes pertaining
to rechargeable batteries.
3. Do not dispose of batteries in fire, as they may explode
4. Charge the telephone's batteries only while in the telephone
handset, and only by using the telephone base unit to charge.
Do not attempt to remove the batteries and charge them in
a separate charging unit.
5. Do not short-circuit the battery pack, as this may cause it to
explode or catch fire.
HANDSET/BASE REGISTRATION PROCEDURE
This procedure establishes an exclusive link between a specific
handset and base, thereby allowing no other access to this
specific base. To accomplish this procedure, place the handset
on the base in the charging position. The LINE indicator will
blink while the process is occuring. This process occurs each
time the handset is placed on the base in the charging cradle.
ADJUSTING THE RING VOLUME
The up and down volume keys will adjust the ringer volume of
the telephone. Additionally, the DCT1900 series telephone has
an optional “courtesy” ring mode, wherein the ring volume
begins at the lowest setting, then automatically rings louder
with each successive ring during an incoming call. To select the
courtesy ring mode, follow these steps:
Press the FLASH key; then the 4key; then the STORE key; then
the 1key.
To return to regular ring mode: Press the FLASH key; then the 1
key; then the STORE key; then the 1key.
ADJUSTING SPEAKERPHONE VOLUME
The speakerphone has eight (8) levels. To adjust speakerphone
volume, locate the volume up/down keys, located on the front
surface of the phone below the keypad. With the speaker active,
press the “down” arrow key to decrease the volume level, and
press the “up” arrow key to increase it.
- IF THE PRODUCT HAS BEEN DROPPED OR THE CABINET HAS BEEN DAM-
AGED.
- IF THE PRODUCT EXHIBIT A DISTINCT CHANGE IN PERFORMANCE.
10. AVOID USING A TELEPHONE (OTHER THAN A CORDLESS TYPE)
DURING AN ELECTRICAL STORM. THERE MAY BE A REMOTE RISK OF ELECTRIC
SHOCK FROM LIGHTNING.
11. DO NOT USE THE TELEPHONE TO REPORT A GAS LEAK IN THE
VICINITY OF THE LEAK.
PLEASE SAVE THESE INSTRUCTIONS
DCT1900 SERIES DIAGRAM
DCT1900 SERIES USERS GUIDE
1.9 GHz DECT Single-Line Digital Cordless Telephone
Part Number 600-0480-77 Copyright © 2006 Teledex LLC. ALL RIGHTS RESERVED.
Telephone
(408) 363-3100
(800) 794-8353
Internet
www.teledex.com
store.teledex.com
Email
sales@teledex.com
Mailing Address
6311 San Ignacio Avenue
San Jose, CA 95119 USA
CONTACTING TELEDEX
8. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT DISASSEMBLE THIS
PRODUCT. BUT TAKE IT TO A QUALIFIED SERVICE FACILITY IF
SERVICE OR REPAIR WORK IS REQUIRED. OPENING OR REMOVING COVERS
MAY EXPOSE YOU TO DANGEROUS VOLTAGES OR OTHER RISKS. INCORRECT
REASSEMBLY CAN CAUSE ELECTRIC SHOCK WHEN THE APPLIANCE IS SUBSE-
QUENTLY USED.
9. UNPLUG THIS PRODUCT FROM THE WALL OUTLET AND REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL UNDER THE FOLLOWING CON-
DITIONS:
- WHEN THE POWER SUPPLY CORD OR PLUG IS DAMAGED OR FRAYED.
- IF LIQUID HAS BEEN SPILLED INTO THE PRODUCT.
- IF THE PRODUCT HAS BEEN EXPOSED TO RAIN OR WATER.
- IF THE PRODUCT DOES NOT OPERATE NORMALLY BY FOLLOWING THE
OPERATING INSTRUCTIONS. ADJUST ONLY THOSE CONTROLS THAT ARE COV-
ERED BY THE OPERATING INSTRUCTIONS, AS IMPROPER ADJUSTMENT OF
OTHER CONTROLS MAY RESULT IN DAMAGE, AND MAY REQUIRE EXTENSIVE
WORK BY A QUALIFIED TECHNICIAN TO
RESTORE THE PRODUCT TO NORMAL OPERATION.
ADJUSTING HANDSET RECEIVE VOLUME
The handset has eight (8) volume levels. To adjust the handset
volume, locate the volume up/down keys, located on the
handset, below the “#” key. Pressing the “minus” (-) key will
decrease the volume level, while pressing the “plus” (+) key
will increase it.
AUTO DIAL KEYS
The DCT1900 series has either five (5) or ten (10) programmable
guest service (auto dial) keys, depending on the model you own.
These keys can be programmed to automatically dial telephone
numbers, or to activate telephone system features.To program the
auto dial keys (programming can only be done from base unit):
1. With the phone “on hook” (inactive) and the faceplate
removed, press the recessed STORE key (see diagram).
2. Enter the desired telephone number (up to 15 digits in
length) to be stored. To enter a “pause” in the number
string, press the REDIAL key as necessary.
3. Press the STORE key again.
4. Press the auto dial key where the number is to be stored.
Programming is now completed for that auto dial key.
To program additional keys, repeat this process.
RECEIVING A CALL
An audible ring and flickering red LED indicate an incoming call.
To answer the call using the handset while it is not on the base:
1. Pick up the handset and press the ON key.
2. The handset will go “off-hook” answering the call.
3. To end the call, place the handset in the base unit cradle, or
press the OFF key on the handset.
To answer the call using the handset while it is resting on the base:
1. Pick up the handset from the base. The phone will
automatically connect to the line.
2. To end the call, replace the handset in the base unit cradle,
or press the OFF key on the handset.
To answer the call using the speakerphone:
1. Press either the LINE key or the SPKR key. The speakerphone
will go “off-hook” answering the call.
2. To end the call, press the SPKR key to hang up.
PLACING A CALL
Using the handset:
1. Pick up the handset and press the ON key. Listen for dial
tone and dial the desired number.
2. After the call is complete, press the OFF key to hang up.
Using the speakerphone:
1. Press either the LINE key or the SPKR key.
2. Listen for dial tone, and dial the desired number, or press an
auto dial key to dial a preprogrammed number.
3. After the call is complete, press the SPKR key to hang up.
REDIAL
The DCT1900 series can automatically redial the last number
dialed. On the handset, press the REDIAL key to redial the last
number.
USING THE HOLD KEY
The HOLD key places the call on hold locally at the cordless
telephone.
To place a call on hold:
1. With a call active, press the red HOLD key on either the
handset or base unit.
2. The red line LED will flash, indicating the call is on hold.
To remove a call from hold:
1. Press the line key of the call on hold. This will remove the
call from hold, making the call active again.
2. The red line LED will return to steady illumination, indicating
the line is active.
To change phones after placing a call on hold:
1. Place the call on hold as above.
2. Pick up the call at another telephone that is on the same
line. The telephone will activate the line and remove the hold
at the original telephone.
TO MUTE THE SPEAKERPHONE
1. Press the MUTE key on the base unit. The red LED above
the MUTE key will illuminate. The party on the other end
will not be able to hear you when the MUTE LED is lit.
2. Press the MUTE key again to turn off the mute feature.
The MUTE LED will go out.
CONVERTING FROM DESK TO WALL MOUNT
The DCT1900 series can be adapted for wall mounting applica-
tions. The conversion is easiest to make when the handset and
cords are not connected.
1. Located on the handset cradle, above the speaker grill, is the
wall/desk mount clip. Remove this clip by firmly pushing it
upward towards the top of the phone.
2. Flip the clip over (top to bottom) so that the protruding edge is
towards the top of the phone and replace it in its slot.This edge
will hold the handset when the phone is mounted on the wall.
3. Turn the telephone over so the bottom is up, facing you.
Place it on a non-abrasive surface to prevent scratching.
4. Locate and remove the mounting bracket. Firmly push back
and pull up to remove two of the four retaining tabs.
5. Rotate the mounting bracket 180º degrees clockwise, so that
the mounting eyelet on the bracket is facing in the same
direction as the other mounting eyelet located on the
bottom of the telephone.
6. Insert the top two retaining tabs of the mounting brackets
into the mounting bracket slots (located near the middle of
the telephone). Then firmly push down to insert the retaining
tabs on the opposite side of the mounting bracket.
7. Connect a 15-foot RJ-45 cord into the LINE jack on the back
of the phone.
8. Turn the telephone over, and slide the telephone down onto
the mounting posts of the wall bracket. Ensure that both
eyelets line up with the mounting posts.
REQUIREMENTS OF PART 68 - FCC RULES
This device has been granted a registration number by the Federal
Communications Commission, under Part 68 rules and regulations for direct con-
nection to the telephone lines. In order to comply with these FCC rules, the fol-
lowing instructions must be carefully read and applicable portions followed com-
pletely:
1. Direct connection to the telephone lines may be made only through the stan-
dard modular cord furnished, to the utility installed jack. No connection may be
made to party or coin phone lines. On the bottom of the phone is a label that
contains among other information, the FCC Registration Number and the Ringer
Equivalence number (REN) for this equipment. If requested this information must
be provided to the telephone company. The USOC Jack for this equipment is
RJ11C.
2. The telephone company, under certain circumstances, may temporarily discon-
tinue and make changes in facilities and services which may affect the operation
of the users' equipment: however, the user shall be given adequate notice in writ-
ing to allow the user to maintain uninterrupted service.
3. In certain circumstances, it may be necessary for the telephone company to
request information from you concerning the equipment which you have connect-
ed to your telephone line. Upon request of the telephone
company, provide the FCC registration number and the ringer equivalence num-
ber of the equipment which is connected to your line; this information will be
found on the device.
4. If any of your telephone equipment is not operating properly, you should imme-
diately remove it from the telephone line. It may cause harm to the telephone
network.
5. If the telephone company notes a problem, they may temporarily
discontinue service. When practical, they will notify you in advance
disconnection. If advance notice is not feasible, the telephone company must;
promptly notify you of such temporary discontinuance; afford the opportunity to
correct the condition; inform you of your rights to bring a complaint to the FCC
under their rules.
6. Repairs to the device may be made only by the manufacturer or an authorized
service agency. This applies at any time during and after
warranty. If unauthorized repair is performed, registration, connection to the tele-
phone lines and remainder of warranty period all become null and void.
7. This equipment is hearing aid compatible.
8. This telephone must be connected behind a PBX.
REQUIREMENTS OF PART 15 - FCC RULES
Statement according to FCC part 15.105: NOTE:This equipment has been tested
and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures: Reorient
or relocate the receiving antenna; Increase the separation between the
equipment and receiver; Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected. Consult the dealer or
an experienced radio/TV technician for help.
Statement according to FCC part 15.21: Modifications not expressly approved
by this company could void the user’s authority to operate the equipment.
RF Exposure (Handset) (DECT): This device and its antenna must not be
co-located or operating in conjunction with any other antenna or transmitter.
RF Exposure mobile (Base) (DECT): The internal/external antennas used for this
mobile transmitter must provide a separation distance of at least 20 cm from
all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.
INDUSTRY OF CANADA REQUIREMENTS
NOTICE: The Industry Canada label identifies certified equipment. This certifica-
tion means that the equipment meets certain telecommunications network pro-
tective operational and safety requirements as prescribed in the appropriate
Terminal Equipment Technical Requirements documents. The department does
not guarantee the equipment will operate to the users satisfaction. Before
installing this equipment, users should ensure that it is permissible to be con-
nected to the facilities of the local telecommunications company. The equip-
ment must also be installed using an acceptable method of connection. The
customer should be aware that compliance with the above conditions may not
prevent degradation of service in some situations. Repairs to certified equip-
ment should be coordinated by a representative designated by the supplier. Any
repairs or alterations made by the user to this equipment, or equipment mal-
functions, may give the telecommunications company cause to request the user
to disconnect the equipment. Users should ensure for their own protection that
the electrical ground connections of the power utility, telephone lines, and
internal metallic water pipe systems, if present, are connected together. This
precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should
contact the appropriate electric inspection authority or electrician, as appropriate.
The Ringer Equivalence Number (REN) of this device is 0.6A.
Notice: The Ringer Equivalence Number (REN) assigned to each terminal device
provides an indication of the maximum number of terminals allowed to be con-
nected to a telephone interface. The termination on an interface may consist of
any combination of devices subject only to the requirement that the sum of the
Ringer Equivalence Numbers of all the devices does not exceed 5.This tele-
phone connects to the telephone network under the connecting arrangement
code CA11A.
Statement according to fcc part 15.214:Privacy of
communications may not be ensured when using this telephone!
1.ˇThis equipment complies with Part 68 of the FCC rules and the requirements
adopted by the ACTA. On the bottom of this equipment is a label that contains,
among other information, a product identifier in the format US:AAAEQ# # TXXXX.
If requested, this number must be provided to the telephone company.
2.ˇA plug and jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements adopted
by the ACTA. A compliant telephone cord and modular plug is provided with this product.
It is designed to be connected to a compatible modular jack that is also compliant.
See installation instructions for details.
3. If this equipment [US:2N3W410BDCT1905] causes harm to
the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be
required. But if advance notice isn't practical, the telephone
company will notify the customer as soon as possible. Also, you
will be advised of your right to file a complaint with the FCC
if you believe it is necessary.
4. The telephone company may make changes in its
facilities, equipment, operations or procedures that could
affect the operation of the equipment. If this happens the
telephone company will provide advance notice in order for you
to make necessary modifications to maintain uninterrupted
service.
5.If trouble is experienced with this equipment [US: 2N3W410BDCT1905],
for repair or warranty information, Service can be facilitated through our office at:
U.S. Agent Company name: Cetis, Inc.
Address: 5025 Galley Road, Colorado Springs CO, 80915
Tel: 719-638-8821
6.Please follow instructions for repairing if any (e.g. battery replacement section);
otherwise do not alternate or repair any parts of device except specified.
7.Connection to party line service is subject to state
tariffs. Contact the state public utility commission, public
service commission or corporation commission for information.
8.If your home has specially wired alarm equipment connected to the telephone line,
ensure the installation of this [US: 2N3W410BDCT1905] does not disable your alarm
equipment.If you have questions about what will disable alarm equipment,
consult your telephone company or a qualified installer.
9.If the telephone company requests information on what equipment is
connected to their lines, inform them of:
a) The ringer equivalence number [ 0.6A]
b) The USOC jack required [ RJ11C]
c) Facility Interface Codes (ìFICî) [ 02LS2]
d) Service Order Codes (ì SOCî) [ 9.0y]
e) The FCC Registration Number [ US: 2N3W410BDCT1905]
10.The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not ringing
in response to an incoming call. In most but not all areas, the sum of RENs should not
exceed five (5.0). To be certain of the number of devices that may be connected to a line,
as determined by the total RENs, contact the local telephone company. The REN for
this product is part of the product identifier that has the format US:AAAEQ# # TXXXX.
The digits represented by # # are the REN without a decimal point. For this product
the FCC Registration number is [ US: 2N3W410BDCT1905] indicates the REN would
be 0.6.
11.If this product is equipped with a corded or cordless handset,
it is hearing aid compatible.
Customer Information
IMPORTANT SAFETY INSTRUCTIONS
WHEN USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK
AND INJURY TO PERSONS, INCLUDING THE FOLLOWING:
1. READ AND UNDERSTAND ALL INSTRUCTIONS.
2. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE PRODUCT.
3. UNPLUG THE PRODUCT FROM THE WALL OUTLET BEFORE CLEANING. DO
NOT USE LIQUID CLEANER OR AEROSOL CLEANERS. USE A DAMP CLOTH FOR
CLEANING.
4. DO NOT USE THIS PRODUCT NEAR WATER, FOR EXAMPLE, NEAR A BATH-
TUB, WASH BOWL, KITCHEN SINK OR LAUNDRY TUB, IN A WET BASEMENT, OR
NEAR A SWIMMING POOL.
5. DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND OR TABLE.
THE PRODUCT MAY FALL, CAUSING SERIOUS DAMAGE TO THE PRODUCT.
6. SLOTS AND OPENINGS IN THE CABINET AND THE BACK OF BOTTOM ARE
PROVIDED FOR VENTILATION, TO PROTECT IT FROM OVERHEATING.THESE
OPENINGS MUST NOT BE BLOCKED OR COVERED. THE OPENINGS SHOULD
NEVER BE BLOCKED BY PLACING THE PRODUCT ON THE BED, SOFA, RUG OR
ANY OTHER SIMILAR SURFACE. THIS PRODUCT SHOULD NEVER BE PLACED
NEAR OR OVER A RADIATOR OR HEAT REGISTER.THIS PRODUCT SHOULD NOT
BE PLACED IN A BUILT-IN INSTALLATION UNLESS PROPER VENTILATION IS
PROVIDED.
7. NEVER PUSH OBJECTS OF ANY KIND INTO THIS PRODUCT THROUGH CABI-
NET SLOTS AS THEY MAY TOUCH DANGEROUS VOLTAGE POINTS OR SHORT
OUT PARTS THAT COULD RESULT IN A RISK OF FIRE OR ELECTRIC SHOCK.
NEVER SPILL LIQUID OF ANY KIND ON THE PRODUCT.

Navigation menu
