3838TPMSToolQuickStartGuide

©BoschAutomotiveSolutions3838575254REV‐BEN1/4

3838TPMSToolQuickStartGuide



1. BatterychargeindicatorandSDcardinslotindicator.

2. Display.

3. Charginglight(red=charging;green=charged).

4. Keyboard.

5. Powerbutton,PresstopowertoolONorOFF.

6. OBDIImodule(Bluetooth).

7. IRprinterWindow.

8. Antenna.

9. SDcardslot

10. USBport

11. RS232port

12. Powerport.

Productcontent:

 3838TPMSScanToolx1

 USBcablex1

 OBDIIModulex1

 RJ45cablex1

 24vadapter

 Magnet

 QuickStartGuide

 CD–UserManualandUSBDrivers

 Carryingcase

Note

The3838batterymaybepartiallydischarged.Connectthe3838totheACPowerAdapterandfullychargethe

batterybeforeuse.

1

4

3

7

8

91011

2

1

4

3

7

8

9

10 1112

2

5

6

3838TPMSToolQuickStartGuide

©BoschAutomotiveSolutions3838575254REV‐BEN2/4

3838TPMSToolQuickStartGuide

Charge

ConnectthetooltoACpowerandfullychargethebattery.

Whencharging,thebatterylightisredandbecomesgreenwhenthebatteryisfully

charged.



Tochargethetool,connect

theACPowerAdapterintothe

providedjackonthetooland

110Vendintoanappropriate

walloutlet.TheLED"CHARGE"

lightwillilluminate.



FunctionKeys



PowerON/OFFswitchToTest/Activatesensor.



Next,continueorconfirm.



Back,previousstep.

Navigatetoselect"up".

Navigatetoselect"down".



Navigatetoselect"left".



Navigatetoselect"right".



Poweronandstart

Tostart:Press toturnonthetool.

Usetoselecttask.

3838TPMSToolQuickStartGuide

©BoschAutomotiveSolutions3838575254REV‐BEN3/4

3838TPMSToolQuickStartGuide

Iconsmenu

Refertotheuserguideformoredetailinformation.

Diagnostics:Accesstoregistrationprocedures

andTPMScodes.

RecentVehicles:QuickaccesstorecentTPM

sensortestresults.

SensorActivation:Usedtoactivate/testTire

PressureMonitoring(TPM)Sensors.Followthe

on‐screeninstructionstocompletethetask.

KeyfobTest:Testsignalstrengthofvehicle

remotekey.

UniversalSensorProgramming:Usedfor

programmingNon‐OEMprogrammable

sensors.

Settings:Changetoolsettings:language,units,

buzzerandtoolinfo.

Changelanguagesettings

LANGUAGE:selectdisplayedlanguageamongEnglish,Español.



EnterSettingsMenu



=Continue



=Previous



EnterLanguageMenu



=Continue



=Previous



Scrollupanddownto

selectlanguage.



=Continue



=Previous

3838TPMSToolQuickStartGuide

Updates&software

InserttheCDsuppliedwithyourtoolintoaPCdriveandclickonthe3838TPMicontostarttheprogram.The

softwarewillpreparethesetup.Followtheonscreeninstructionstoupdateyourtoolorprintreports.



Warning

Thisproductemitselectromagneticandelectronicallygeneratedwavesthatmayinterferewith

thesafeoperationofpacemakers.

Individualsthathavepacemakersshouldneverusethisproduct.



Triggering

Warning!Forbestsensortriggering,holdthetoolagainstthetiresidewallright

abovethesensor.



Recycling



DonotdisposeoftherechargeableLithium‐Ionbatteryorthetooland/oritaccessoriestothe

dustbin.

Thesecomponentsmustbecollectedandrecycled.



Forfurtherinformation,pleaserefertothecompleteuserguide.



OTCTechnicalSupport:(800)533‐6127

Pleaserecordandretainthisimportantinformation:

PartNo:________________________________________

SerialNo:_______________________________________

PurchaseDate:___________________________________


