Cannice Technology 0W2 Bluetooth headset User Manual 15 W2 UserMan
Shenzhen Cannice Technology Co., Ltd. Bluetooth headset 15 W2 UserMan
15_W2 UserMan.pdf
1
2
3
4
5
6
10min
? ?
7
Following items are included
Start here
Basic operation
Volume control
Press the Volume "+" or "-" to turn volume up or down, you hear
beep once reach the maximum or minimum volume.
3. Select "W2". If your phone asks, enter 0000 (four zeros) for the
passcode or accept the connection. The LED indicator stops
flashing red and blue once successfully paired, you hear
"Connection successful". Some phone list an option to "Play
through earphone", select to use the earphones.
Pair another phone
USB cable
Ear cushions
Multipoint technology enables you to pair another phone and take a
call from either.
To pair with another mobile phone, follow the steps for "Pair one
phone". After pairing successfully, restart the earphone to connect to
2 paired mobile phone automatically.
Status indicator
Instruction
Power on
Power off
Standby
Incoming call
Pairing
LED status
Stays blue 1.5 seconds
Stays red 1.5 seconds
Blink blue twice every 5 seconds
Blink blue once every 3 seconds
Flashes Red and Blue alternately
Voice prompts
Power on
Power off
Pairing
/
/
Battery low Flashes red twice every 8 seconds Battery low
Product overview
Bluetooth
ON
Se arc h
W2
Call
Answer a call
Redial the last call
Mute on/off
Press any button (Multifunction/Vol+/Vol-) once.
Double-press the Multifunction button in standby mode. The
mobile phone will redial the last call number.
Press the Volume "+" for about 2 seconds to mute on/off.
Reject a call
Press and hold the Multifunction button for about 2 seconds.
Press the Multifunction button once.
End a call
Charging Stays on red while charging,
Stays on blue after fully charged /
1. Volume + / Track forward 5. Status indicator
2. Multifunction button 6. Talking mic
3. Volume - / Track back 7. Turn on / off
4. Charge port
Pair one phone
1. Press and hold the Power button for about 3 seconds until LED
flashes blue and red alternately, you hear "Power on" and
"Pairing", now earphone is in pairing mode.
2. Activate Bluetooth on your phone and set it to search for new
devices.
Pairing
Bluetooth
ON
Se arc h
W2
Bluetooth
ON
Se arch
W2
ON
连 接
W2
Bluetooth
Auto power-off
More features
Battery Indicator
Hard reset
When the distance between the earphone and the mobile phone
is beyond effective range, a voice prompt "Connection lost" and
earphone disconnects with the mobile phone, the earphone will
power off automatically once no active for 10 minutes.
Charging
Connection standby
Automatic connection after powering on
RINGCOLLAR
MUSICWIRELESSHEADSET
Your earphone has enough power to complete the pairing and a
few calls. When battery is low, you will hear the voice prompt
"Battery low". It takes 1.5 hours to fully charge the earphone. The
red LED turns on during charging. The red LED will turn off and
the blue LED will turn on after being fully charged.
When the earphone is connected to a device with iOS system, a
battery indicator will appear at the upper right of the system,
indicating battery status of the earphone.
After successful pairing and connection, you will hear the voice
prompt "Connection successful". the earphone will be in turning
on mode or standby mode automatically and the blue LED will
flash twice every 5 seconds, when the earphone disconnect the
phone, you will hear the voice prompt "Connection lost".
When the earphone and phone have been paired once, they will
automatically connect when the earphone is on and Bluetooth is
activated on the phone.
In turning on mode, press and hold the Multifunction button with
the charger plugged to reset the earphone and power off(you can
release the Multifunction button 2 seconds after mounting the
charger).
W2 INSTRUCTION
Note: The lifetime of the battery will be significantly reduced if
your earphone is left uncharged for a long period. We recommend
that you recharge your earphone at least once a month.
Switch between the earphone and phone
Press the Volume "-" for about 2 seconds during a call, the call
will be switched to the mobile phone, redo this operation again,
the call will be switched to the earphone.
End current call and answer new call
When a new call rings during a call, press the Multifunction
button once to answer new call and end current call
simultaneously.
On hold current call and answer new call
When a new call rings during a call, hold the Multifunction
button for 2 seconds to hold current call and answer new call.
To switch between held call and active call, Hold the
multifunction button for 2 seconds.
Music
Music play / pause
Press Multifunction button once to play / pause music. (Some
phones may require you to start a media player first)
Track back/forward
Press the Volume "+" for 2 seconds once to skip track forward,
press Volume "-" for 2 seconds once to skip track backward.
Switch Music and Call
When a call rings during a music playing, the music
automatically pauses to allow you to answer or ignore the call.
Once the call is ignored or ends, the music is resumed.
(Need media player support)
Effective
range
Clear paired list
In standy mode, press Vol+,Vol- and Multifunction buttons
simultaneously for about 5 seconds, LED indicator flashes blue&red 5
times quickly, then clear all paired list, the earphone will enter pairing
mode automatically after power on next time.
Voice dial (Need phone support.)
Press Vol+ and Vol- simultaneously, you will hear beep, and wait
for phone prompt and then tell the phone to dial the name of a
stored contact.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
