Cannice Technology M14 Bluetooth Earphone User Manual
Shenzhen Cannice Technology Co., Ltd. Bluetooth Earphone Users Manual
Users Manual
Pair headset to first phone per usual pairing procedure, then switch
off headset. Then switch on headset again and enter pairing mode,
enable Bluetooth function in second phone, find headset’s Pairing
Name ",M14" and pair to second phone per usual procedure. Switch
off headset one more time. Then simply switch on headset, without
entering pairing mode (a short press until blue light comes on). The
headset should automatically re-connect to the last connected
phone (which is the second phone). Then find headset "M14" in first
phone’s Bluetooth setting, select this to pair to first phone. Both
phones should now be paired to the headset.
Multipoint technology enables you to pair headset to two phones
at the same time and take calls from either:
Do not use earphone in thunderstorm weather, the earphone may
not work properly in the condition, and increase the risk of being hit
by lightning .
Following items are included
Start here
Pair one phone
1.Make sure the earphone is turned off and within 1 meter of your
phone, press and hold the Multifunction button until the LED
indicator flashes red and blue alternately (About 5 seconds), then
release Multifunction button.
2.Activate on your phone (See below for more details).Bluetooth
Basic operation
Pairing
3. Select "M14". If your phone asks, enter 0000 (four zeros) for the
Passcode or accept the connection. The LED indicator stops flashing
red and blue once successfully paired, you hear "Connection successful".
Some phone list an option to "Play through earphone", select to use the
earphones.
Pair another phone
Status indicator
Instruction
Power on
Power off
Standby
Pairing
LED status
Stay blue about two second
Stay red about two second
Blink blue twice every 5 seconds
Flashes red and blue alternately
Voice prompts
Power on
Power off
Pairing
/
Battery low
Bluetooth
ON
Search
M14
Call
Answer a call
Redial the last call
Mute on/off
Press the Multifunction button once.
Double-press the Multifunction button in standby mode.
The mobile phone will redial the last call number.
Press the Volume "-" for about 2 seconds to mute on/off.
Reject a call
Press and hold the Multifunction button for about 2 seconds.
Press the Multifunction button once.
End a call
Hard reset
forcallsandmusic
If the earphone cannot be turned on even when fully charged or does
not respond during use, follow the instructions below to reset it.
1.While pressing and holding the multifunction button, connect the
earphoneto your PC’s USB port or a USB power adapter with the
charging cable.
2.Keep pressing and holding the Multifunction button until the
earphone turns on. The earphone is now reset.
M14 INSTRUCTION
Music
Music play / pause
Press Multifunction button once to play / pause music. (Some
phones may require you to start a media player first) .
Track back/forward
Press the Volume "-" for 2 seconds once to skip track backward,
press Volume "+" for 2 seconds once to skip track forward.
(Need media player support).
Battery low Flashes red twice every 8 seconds
Charging Stays on red while charging
Stays on blue after fully charged
Clear paired list
Press and hold the volume"+ " button ,the multifunction button and
press volume"-" button for about 5 seconds in standby mode.
(Note :The earphone will enter pairing mode after power on next time.)
Product overview
1. Volume + / Track forward
2. Charge jack
3. LED indicator
4.Talking mic
5. Multifunction button
6. Volume - / Track back
USB cable
Ear cushions
/
Voice dial (Need phone support)
Press the Volume button "+" and "-" in standby mode , wait
for phone prompt and then tell the phone to dial the name
of a stored contact.
Bluetooth
ON
Se arch
M14
Switch between the earphone and phone
Press the Volume "+" for about 2 seconds during a call,
the call will be switched to the mobile phone, redo this
operation again, the call will be switched to the earphone.
Charging
Your new earphone has enough power to pair and make a few
calls. It takes 2 hours to fully charge the earphone; while charging,
the battery indicator light is red, the indicator light flashes blue
once charging is complete.
Note: The lifetime of the battery will be significantly reduced if
your earphone is left uncharged for a long period. We recommend
that you recharge your earphone at least once a month.
Volume up/down Press the volume"+" to turn volume up
Press the volume"-" to turn volume down
iPhone
a. On your phone, open the menu.Settings
b. Select . If Bluetooth is off, turn it on. Bluetooth
The iPhone will search for new devices automatically.
Android phone
a. On your phone, open the menu.Settings
b. Select (For old Android phone, is found in the Bluetooth Bluetooth
). If Bluetooth is off, turn it on. Select Wireless & Networks Search for
Devices if your phone does not automatically search for new devices.
Windows Phone 8
a. On your phone, open the menu.Settings
b. Select . If Bluetooth is off, turn it on.Bluetooth
The Phone will search for new devices automatically.
Safety and care
Using earphone at high to moderate volumes for extended periods
of time will result in permanent hearing damage .It is advised you
keep volume levels moderate to low at all times for your safety.
Do not use any corrosive cleaner/oil to clean the earphone.
If the earphone comes in contact with liquids, quickly wipe away .If
submersed in water, do not turn the earphone on until completely dried.
Tips:liquid submersion voids the warranty.
Keep the earphone and packaging out of reach of children .
Turn on voice prompts: enter pairing mode: Press the volume "+"
button for 3 seconds, the blue LED lights flash 3 times;
Turn off voice prompts: enter pairing mode: Press the volume"-"
button for 3 seconds, the red LED lights flash 3 times.
Power on
Power off
Press and hold Multifunction button for about 2 seconds,
the LED flashes blue twice.
Press and hold Multifunction button for about 5 seconds,
the LED flashes red twice.
Tips: When the distance between the earphone and phone is beyond
effective range, earphone disconnects with phone. Earphone will
power off automatically once no active for 20 minutes.
Do not use while driving a car, cycling, operating machinery, or
performing other activities that require hearing surrounding sounds.
Earphone may not work properly under high temperature or high
humidity conditions.
504.00 mm
Note: When the earphone and phone have been paired once,
they will automatically connect when the earphone is on and
Bluetooth is activated on the phone.
1
4
3
5
6
2
Bluetooth
ON
Connect
M14
ON
Connect
M14
Blu et oo th
Bluetooth Earphone
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference,
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment .
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
