Corporate Solutions

MAIN UNIT

Type: Color Digital Multifunction

Imaging System

Copying Method: Laser Dry Electrostatic Transfer

Developing System: Dry Dual Component Developing

System

Memory: Standard 1GB RAM

Maximum 1.5GB RAM

Hard Disk Drive: 80GB

Network Interface

Connections: 10/100Base-TX (RJ-45)

Other Interface: USB 2.0 (Device), USB 2.0 (Host)

First-Copy Time: 8.0 Seconds (Color)

6.2 Seconds (B/W)

Warm-Up Time: 4 Minutes After Powering On

Copy/Print Speed

(B/W, Color): Up to 51/51 ppm (Letter)

Scan Resolution: 600 dpi x 600 dpi

Copy Resolution: 600 dpi x 600 dpi

Engine Resolution: 1200 dpi x 1200 dpi

Halftone: 256 Gradations (Continuous-Tone)

Paper Sources

Standard: Dual 550-Sheet Paper Cassettes

100-Sheet Stack Bypass

Optional: Dual 550-Sheet Paper Cassettes

2,700-Sheet Paper Deck

Paper Sizes

Drawers: 12" x 18", 11" x 17", Legal, Letter,

Letter-R, Statement-R, Executive

Bypass: 12" x 18", 11" x 17", Legal, Letter,

Letter-R, Statement-R, Executive,

12-5/8" x 17-11/16", Irregular

size (3-15/16" x 5-7/8" to

12-7/8" x 18") and Envelopes

Acceptable Paper Weight

Drawers: 17 lb. Bond to 110 lb. Index

Bypass: 17 lb. Bond to 140 lb. Index

Duplexing: Standard Automatic Trayless

Duplexing (Executive to

12" x 18")

Image Reader: Color Image Reader-G1 (Standard)

Acceptable Originals: Sheet, Book, 3-Dimensional

Objects (up to 4.4 lb.)

Max. OriginalSize:11" x 17"

Document Feeding Method: Single Pass Duplexing Automatic

Document Feeder (Standard)

Acceptable Originals: Statement to 11"x 17"

Paper Capacity: 100 Sheets

Acceptable Paper

Weight of Originals: Simplex 11 to 32 lb. Bond

(42 to 128 g/m2)

Duplex 13 to 32 lb. Bond

(50 to 128 g/m2)

Scan Speed (Letter)

Simplex: 70 ipm (300 dpi)/51 ipm (600 dpi)

Duplex: 100 ipm (300 dpi)/51 ipm (600 dpi)

Dimensions (H x W x D): 35-5/8" x 24-3/8" x 33-1/2"

Installation Space (W x D): 35-1/2" x 33-1/2" (When Stack

Bypass is Extended)

Weight: Approximately 309 lb. (140.2kg)

Power Requirements: 120V AC, 60Hz, 20A

Power Consumption: 2,100W

Plug: NEMA 5-20P

Toner (Estimated Yield): Black: 27,000 Images @

5% Coverage

Color: 36,000 Images @

5% Coverage

Copy Features

Multiple Copies: 1 to 999

Max. Copy Reservation: 10 Jobs

Color Mode: Auto Color, Full Color, Black,

Single Color, Two Colors

Copy Exposure: Automatic or Manual (9 Levels)

Magnification

Preset Reduction: 25%, 50%, 64%, 73%, 78%

Preset Enlargement: 121%, 129%, 200%, 400%

Zoom Mode: 25% - 400% (1% Increments)

Mail Box Features

Max. Mail Boxes Supported: 100 User Inboxes, 1 Memory

RX Inbox, 50 Confidential Fax

Inboxes

Scan Feature

Network TWAIN Scan: Standard

Network Scan Utility: Color Network ScanGear

Color Universal Send Feature (Standard)

Color Mode: Auto Color Select

(Full Color/Gray Scale)

Auto Color Select (Full Color, B/W)

Full Color, Grayscale, B/W

Address Book Capacity: Max. 1,800 Destinations (Includes

200 One-Touch Buttons)

Max. 5 LDAP Servers

Sending Methods: E-mail, I-fax, SMB, File Server (FTP,

IPX, WebDAV), User Inbox,

Super G3 Fax (Optional)

Communication Protocol

File: FTP (TCP/IP), SMB (TCP/IP),

NCP (IPX), WebDAV

E-mail/I-fax: SMTP, POP3, I-fax (Simple, Full)

DataFormat

File, E-mail: TIFF, JPEG, PDF, PDF (Compact),*

PDF (Trace & Smooth),* PDF (OCR),*

Encrypted PDF,** Digital Signature

PDF (Device,** User***)

I-fax: B/W: TIFF (MH, MR, MMR)

Color: TIFF (Profile-C)

OPTIONAL ACCESSORIES

Super G3 Fax Board-V3/Super G3 Multi-Line Fax Board-H2

Applicable Line: Public Switched Telephone

Network (PSTN)

Connection Lines: One-Line (Super G3 Fax Board-V3),

Two-Lines (Super G3 Multi-Line

Fax Board-H2)

Sending/Original Size: Statement to 11" x 17"

Recording/Printing Size: Statement to 11" x 17"

Color UFR II/PCL Printer Kit-N2 (Standard for C5185i)

CPU: Canon Dual Custom Processor

(Shared)

Memory: 1GB RAM (Std.), 1.5GB RAM (Max.)

(Shared)

Hard Disk Drive 80GB (Shared)

Productivity far beyond the norm

The Canon Color imageRUNNER C5185 Series is a full-color digital multifunctional solution that provides exceptional

productivity to all office environments. Color and black-and-white documents are output at high print speeds of up to

51 ppm (letter). And each model delivers advanced imageCHIP system architecture and advanced document handling,

including the standard Single Pass Duplex Document Feeder that scans up to 100 ipm (letter, two-sided).

Offering digital copying and Mail Box features, standard Color Universal Send, robust finishing options, a choice of print

controllers, and much more, the Color imageRUNNER C5185 Series has the ability to serve corporate offices as well as

professional color environments. And, as always, you can trust Canon to deliver performance, quality, and reliability.

Supported PDL: UFR II/PCL 5c/PCL 6

Optional PDL Support: PostScript®3™Emulation

(PS Printer Kit-N2s)

Print Resolution:

UFR II/PS3: 1200 dpi x 1200 dpi, 2400 dpi

Equivalent x 600 dpi

PCL 5c: 2400 Equivalent dpi x 600 dpi

PCL 6: 1200 dpi x 1200 dpi, 2400 dpi

Equivalent x 600 dpi

Printer Drivers

UFR II: Windows®(Windows 2000/XP/

Server 2003/Windows Vista®)

Citrix MetaFrame

Macintosh®(OS 10.2.8 or Later)

PCL 5c: Windows (Windows 98/Me/2000/

XP/Server 2003/Windows Vista)

Citrix MetaFrame

PCL 6: Windows (Windows 98/Me/2000/

XP/Server 2003/Windows Vista)

Citrix MetaFrame

XPS:ss Windows Vista

PS3 (Optional): Windows (Windows 98/Me/2000/

XP/Server 2003/Windows Vista)

Citrix MetaFrame

Macintosh (OS 10.2.8 or Later)

imagePASS-H1 v2.0

ConnectableDevice: Color imageRUNNER C5185

CPU: Celeron®M1.5GHz

System: System 8e Release 2

Memory: 256MB (Std.), 512MB (Max.)

HardDisk Drive: 80GB

Interfaces (to LAN): 10/100/1000Base-T (RJ-45)

Supported PDL: Adobe®PostScript 3, PCL 5c/6

Print Resolution: 1200 dpi x 1200 dpi

2400 dpi Equivalent x 600 dpi

Utility Software: Command WorkStation®for

Windows

Command WorkStation for Mac

Options: 256MB RAM, Secure Erase v1.0,

Hot Folders v2.0, Impose v2.7

ColorPASS-GX200

Connectable Device: Color imageRUNNER C5185

CPU: Intel®Core 2 Duo E6400, 2.13GHz

System: System 8 Release 2

Memory: 1GB (Std.)

Hard Disk Drive: 160GB

DVD-ROM: Standard

Interfaces (to LAN): 10/100/1000Base-T (RJ-45)

Supported PDL: Adobe PostScript 3

Print Resolution: 1200 dpi x 1200 dpi

2400 dpi Equivalent x 600 dpi

Options: GA Package, GA Premium,

Compose v2.0, Impose v2.7,

ACI Kit, Removable HDD

Cassette Feeding Unit-Z2

sss

Paper Sizes: 12" x 18", 11" x 17", Legal, Letter,

Letter-R, Statement-R, Executive

Paper Drawers Capacity: 550 Sheets x 2 Cassettes

[20 lb. Bond (80g/m2)]

Dimensions (H x W x D): 12-1/4" x 24-3/8" x 27-3/4"

Weight: Approximately 66.1 lb. (30kg)

Paper Deck-Y1

Paper Size: Letter

Paper Deck Capacity: 2,700 Sheets (20 lb. Bond

80g/m2)

Dimensions (H xWx D): 17" x 12-3/4" x 23-1/4"

Installation Space (W x D): 37-1/8" x 33-1/2"

Weight: Approximately 66.1 lb. (30kg)

Finisher-X1

Number of Trays: One Tray

Paper Size

Standard: 12" x 18", 11" x 17", Legal, Letter,

Letter-R, Statement-R, Executive

Non-Standard Size: (3-15/16" x 5-7/8" to

12-7/8" x 18")

Weight: 17 lb. Bond to 140 lb. Index

Paper Capacity Per Tray: 1,000 Sheets (Letter, Statement-R,

Executive)

500 Sheets (12" x 18", 11" x 17",

Legal, Letter-R)

Paper Capacity of

Staple Mode: 1,000 Sheets/30 Sets (Letter,

Executive) 500 Sheets/30 Sets

(11" x 17", Legal, Letter-R)

Max. Stapling Capacity

Letter, Executive: 50 Sheets (17 lb. to 20 lb. Bond)

30 Sheets (20 lb. to 28 lb. Bond)

2Sheets (28 lb.Bond to 140 lb.

Index)

11" x 17", Legal,

Letter-R: 30 Sheets (17 lb. to 20 lb. Bond)

20 Sheets (20 lb. to 28 lb. Bond)

2Sheets (28 lb. Bond to 140 lb.

Index)

Staple Mode: Corner (11" x 17", Legal, Letter,

Letter-R, Executive)

Dimensions (H x W x D): 28-5/8" x 16-1/4" x 24"

Installation Space (W x D): 46-1/2" x 33-1/2" (when auxiliary

tray is extended)

Weight: Approximately 35.3 lb. (16kg)

Finisher-W1/Saddle Finisher-W2

Number of Trays: Three Trays

Paper Size

Standard: 12" x 18", 11" x 17", Legal,

Letter, Letter-R, Statement-R,

Executive

Non-Standard Size: (3-15/16" x 5-7/8" to

12-7/8" x 18")

Paper Weight: 17 lb. Bond to 140 lb. Index

Paper Capacity Per Tray

Non-Collating Tray: 250 Sheets (Letter, Statement-R,

Executive)

125 Sheets (12" x 18", 11" x 17",

Legal, Letter-R)

Upper Tray: 1,300 Sheets (Letter, Statement-R,

Executive)

650 Sheets (12" x18", 11" x17",

Legal, Letter-R)

Lower Tray: 2,450 Sheets (Letter)

1,700 Sheets (Statement-R,

Executive)

650 Sheets (12" x 18", 11" x 17",

Legal, Letter-R)

Finisher-X1 Finisher-W1 Saddle

Finisher-W2

Puncher

Unit-AH1

Cassette

Feeding Unit-Z2

Paper Deck-Y1

Copy Tray-M1

Copy Tray-N1

Plain

Pedestal-E2

Document Tray-J1

Stack Bypass

Alignment Tray-B1

1-800-OK-CANON

www.usa.canon.com

Canon U.S.A., Inc.

One Canon Plaza

Lake Success, NY 11042

0408R-C5185-PDF-MC

Paper Capacity of Staple Mode

Upper/Lower Tray: 1,300 Sheets/100 Sets (Letter,

Executive)

650 Sheets/50 Sets (11" x 17",

Legal, Letter-R, Staple with

Different Paper Sizes)

Max. Stapling Capacity

Letter, Executive: 50 Sheets (17 lb. to 20 lb. Bond)

30Sheets (20 lb. to 28 lb. Bond)

2Sheets (28 lb. Bond to 140 lb.

Index)

11" x 17", Legal,

Letter-R: 30 Sheets (17 lb. to 20 lb. Bond)

20 Sheets (20 lb. to 28 lb. Bond)

2Sheets (28 lb. Bond to 140 lb.

Index)

Staple Mode: Corner (11" x 17", Legal, Letter,

Letter-R, Executive)

Double (11" x 17", Legal, Letter,

Letter-R, Executive)

Saddle-Stitching†

Acceptable Paper Sizes: 12" x 18", 11" x 17", Legal,

Letter-R

Saddle Stitch Capacity: 15 Sheets (17 lb. to 20 lb. Bond)

10Sheets (20 lb. to 28 lb.Bond)

Tray Capacity: 25 Sets (1 t o 5 Sheets)

15 Sets (6 to 10 Sheets)

10 Sets (11 to 15 Sheets)

Folding: V-Fold

Dimensions (H x W x D): 46-1/4" x 26-3/4" x 25-7/8"

Installation Space (W x D): 55-1/2" x 33-1/2" (when auxiliary

tray is extended)

59-5/8" x 33-1/2" (when optional

Puncher Unit-AH1 is attached and

auxiliary tray is extended)

Weight: Approximately 101 lb. (50kg)

Puncher Unit-AH1

††

Paper Size: 11" x 17", Legal, Letter, Letter-R

Max. Paper Weight: 17 lb. Bond to 140 lb. Index

Punch Type: 3 Holes (Letter, 11" x 17")

2Holes (Legal, Letter-R)

Punch Waste Tray Capacity: When approximately 3,000 Sheets

of paper have been punched

Dimensions (H x W x D): 32-3/4" x 4-1/4" x 24-1/2"

Weight: Approximately 15.9 lb. (7.2kg)

OTHER OPTIONAL ACCESSORIES

Footnotes:

*When configured on C5185, requires Universal Send PDF

Advanced Feature Set-A1.

** When configured on the C5185, requires Universal Send

PDF Security Feature Set-A1.

*** Requires Digital User Signature Kit-A1.

sRequires iR 512MB Expansion RAM-C1.

ss Check with your Authorized Canon Dealer for availability.

sss C5185/C5185i requires Cassette Feeding Unit-Z2 or

Plain Pedestal-E2.

†Available with Saddle Finisher-W2 only.

†† Puncher Unit-AH1 can only be installed with either the

Finisher-W1 or Saddle Finisher-W2.

††† Requires UFR II/PCL Printer Kit-N2.

sWhen configured on the C5185, requires UFR II/PCL

Printer Kit-N2 if printing Web pages; requires PS Printer

Kit-N2 on C5185/C5185i if printing PDF files.

ss Standard on C5185i.

nVoiceGuidanceKit and Voice Operation Kit cannot be

installed together.

£Not supported with imagePASS-H1 V2.0 or

ColorPASS-GX200.

•Encrypted Secured Print

Software-C1†††

•Barcode Printing Kit-A1†††

•Web Access Software-E1s

•Universal Send PDF

Advanced Feature Set-A1ss

•Universal Send PDF Security

Feature Set-A1ss

•Digital User Signature PDF

Kit-A1

•Secure Watermark-A1s

•Super G3 Fax Board-V3

•Super G3 Multi-Line

Fax Board-H2

•imageRUNNER 512MB

Expansion RAM-C1

•HDD Encryption Kit-B1

•HDD Erase Kit-A1

•Voice Guidance Kit-A2n

As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that these products meet

the ENERGY STAR guidelines for energy efficiency. ENERGY STAR and the ENERGY STAR mark

are registered U.S. marks. Microsoft, Windows, and Windows Vista are registered trade-

marksof Microsoft Corporation in the United States and/or other countries. Macintosh is

atrademark of Apple Computer, Inc. Command WorkStation is a registered trademark of

Electronics for Imaging, Inc. in the U.S. Patent and Trademark Office and/or certain other

foreign jurisdictions. Adobe, Acrobat, and PostScript are registered trademarks of Adobe

Systems Incorporated in the United States and/or other countries. Intel, Celeron, and

Pentium are registered trademarks of Intel Corporation. CANON, IMAGERUNNER, MEAP,

and the GENUINE logo are registered trademarks of Canon Inc. in the United States and

may also be registered trademarks or trademarks in other countries. IMAGEWARE is a regis-

tered trademark of Canon U.S.A., Inc. in the United States and is a trademark of Canon

Inc. in certain countries. IMAGEANYWARE is a trademark of Canon. All referenced product

names and other marks are trademarks of their respective owners.

Specifications and availability subject to change without notice.

©2008 Canon U.S.A., Inc. All rights reserved.

Federal Law prohibits copying of certain documents. Violators may be

subject to penalties. We suggest that you check with your own legal counsel.

Canon U.S.A., Inc. and Canon Canada, Inc. intend to cooperate with Law

Enforcement Agencies in connection with claims of unauthorized copying.

•Voice Operation Kit-A1n

•Remote Operator’s Software

Kit-A2

•Plain Pedestal-E2sss

•Document Tray-J1

•Copy Tray-M1

•Copy Tray-N1

•Stack Bypass Alignment

Tray-B1

•Card Reader-D1

•Key Switch Unit-A2

•Braille Label Kit-A1

•ADF Access Handle-A1

•Stamp Unit-A1

•eCopy Suite

•imageWARE™ Suite

•Access Management

System Kit-A1

•Workflow Composer-B3

•Wireless Network Interface

Adapter NB-W1£
