Canpow Technology CP622 Wireless charger User Manual CP622 01
Shenzhen Canpow Technology Co., Ltd Wireless charger CP622 01
User manual
Furniture
Wireless Charger
CP622 USER GUIDE
In Box Items
Wireless Charger*1
USB cable*1
User guide*1
Product Specification
Input：5V/2A, 9V/1.67A
Output: 5V/1A, 9V/1.1A
Charging distance：≤8mm
Charging efficiency：≥76%
Dimensions：φ89mmx14.6mm
Notes
1.Keep the charging pad and receiver away from water or
any liquid.
2.Cut off input power source during cleaning pad.
3.Working temperature 0-45℃.
Warranty
1.Two years warranty service from the date you buy it. We
provide the free service or product exchange within the
warranty period with any quality problem of product itself.
2.When the product cannot be repaired during the warranty
period, you can get a new one replaced the same type of
product you purchased from us.
3.If other reasons such as strong impact, fire, water, and so on,
lead the product failing to use, or aer warranty period, we will
charge the repair fee when the product might be repaired and
used again.
Product Introduction
Product Outline
This Charging Pad is one intelligent wireless power charging
product, supporng 10W quick charging(requiring adapter &
receiving device to support QC2.0 9V/1.67A charging), and
compable for 5W standard power charging. It’s designed for
furniture and perfectly compable with any Qi standard
devices. Without cable, it brings you free and safe charging
experiences.
Applicable Device
Instructions
1.Devices with built-in wireless charging receiver module
(Samsung S8, Iphone 8/8 Plus, Iphone X etc).
2.Devices with reserved wireless charging input port (Galaxy
S5, Galaxy Note4 etc).
3.Wireless charging mod or case with receiver module
(iPhone5, iPhone 6/6 Plus etc).
(Note: Receivers must meet WPC standard)
1.Insert the device
into the hole, fix the 3
screws from boom
with a screwdriver.
Silicone pad
Power input
Bayonet
Screw
2.Connect the adapter and
the wireless charger with
USB cable.
3.Place device with
wireless power receiver
on charger, then start
charging immediately.
FCC Statement
The device complies with part 15 and 18 of the FCC Rules.
FCC StatementFCC Statement
Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not explicitly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Note: this equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--- Reorient or relocate the receiving antenna.
--- Increase the separation between the equipment and receiver.
--- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--- Consult the dealer or an experienced radio/TV technician for help.
The equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This device has been tested for human exposure limits
and found compliant at a minimum distance of 10cm during operation.
Thus during the operation of device a distance of 10cm must be respected in every
direction.
Radiation Exposure StatementRadiation Exposure StatementRadiation Exposure Statement
