Carematix MOD6 RF Transceiver Module User Manual Carematix
Carematix Inc RF Transceiver Module Carematix
Users Manual
Carematix ####
Adapter
Connecting to a Device
1. Please ensure that the batteries are
installed in the adapter. See below for
instructions on how to install batteries.
2. Connect the device to the adapter using
the adapter’s cable. Make sure that the
connection is secure.
Transmitting a Measurement
1. Take a measurement as you normally do
using the device.
2. If your adapter does not have a Send button, then
the measurement will be automatically
transmitted from the device to the adapter.
3. If your adapter does have a Send button,
please press it once after the device has
taken the measurement. Your
measurement will now be send to the
adapter and then on to the receiver hub.
4. Do not yank at the cable as its connection
to the peak flow meter may become
unsecured.
Helpful Hints
1. Please insure that the device and the
adapter fit together securely.
2. The connector will fit properly only one
way. If resistance is encountered while
connecting, please check and reorient
connector if necessary.
3. Please check batteries after approximately
6 months of regular use and replace if
necessary.
Power Supply
Battery Installation
1. Open the battery compartment cover on the
underside of the adapter.
2. When the compartment is opened, insert 2 AA
batteries, making sure they are oriented correctly.
3. Replace the battery compartment cover.
Notes:
1. Since the batteries installed from the factory at the
time of shipment are monitor batteries, their life
may be shorter than regular, new batteries.
Care and Maintenance
1. Because this unit uses precision parts, care
should be taken to avoid extremes in temperature
variations, humidity, shock, dust and direct
sunlight.
2. Do not open or take apart the adapter or its
components. There are no user
serviceable parts.
3. Do not drop or strike this unit.
5. If the unit is to be stored for a long period, please
disconnect it from the peak flow meter and be
sure to remove batteries before storage.
Specifications
Operating Principle Serial interface
Power Supply 2 AA batteries
Operating Temperature +50°F to +104°F
Relative humidity 15 to 90%
Storage Temperature -4°F to +122°F
Specifications are subject to change without
prior notice due to improvements in
performance and quality.
Warranty
This equipment is guaranteed for the period of 1 year
after the date of purchase against manufacturing
defects when returned along with the proof of date of
purchase. During this period, the unit will be repaired
or replaced free of charge if the failure is attributable to
faulty design or manufacture. This warranty does not
cover damage or malfunctions caused by improper
handling or use contrary to the instructions in this
manual. Opening or taking apart the unit or its
components will void the warranty. Should your
unit require service, please e-mail to us at
service@carematix.com
SAFETY PRECAUTION
Regarding Use of Information
From the Carematix ####
The Carematix #### Adapter is designed to
provide supplemental information only.
Changes in treatment or therapy should not
be based on information provided by the
Adapter. The clinician is expected to
exercise clinical judgment and
independently corroborate the information
provided by the Carematix #### Adapter
prior to making any treatment or therapy
decisions
Therapy or intervention decisions should
not be based on information provided by the
Carematix #### Adapter. Any changes in
therapy should be based on an actual
examination by the clinician.
SAFETY PRECAUTIONS
Batteries should not be left in the Carematix
7100 Adapter for an extended period of time
that the Adapter is not is use.
Batteries should be disposed of properly
according to the manufacturer’s
recommendations.
If the monitor is accompanied by a base
station (hub) requiring plugging into a phone
line, the line should NEVER be plugged in
during a thunderstorm.
CAUTION
Changes or modifications to this equipmen
t
not expressly approved by Carematix, Inc.
could void the user’s authority to operate
the equipment.
NOTICE
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause undesired
operation.
Carematix, Inc.
2 NORTH LASALLE STREET, SUITE 1805
CHICAGO, IL 60602
WEB SITE: HTTP//WWW.CAREMATIX.COM
