PX-330, AP-620/6 MIDI Implementation

CASIO COMPUTER CO., LTD.

Contents

2

9.16 Portamento Control (54H) ................................................................................................................. 15

9.17 Reverb Send (5BH) ........................................................................................................................... 16

9.18 Chorus Send (5DH) ........................................................................................................................... 16

9.19 NRPN (62H, 63H).............................................................................................................................. 16

9.19.1 Assignable Functions to NRPN............................................................................................................16

9.20 RPN (64H, 65H) ................................................................................................................................ 17

9.20.1 Pitch Bend Sensitivity .......................................................................................................................... 17

9.20.2 Fine Tune..............................................................................................................................................17

9.20.3 Coarse Tune..........................................................................................................................................17

9.20.4 Modulation Depth ................................................................................................................................ 18

9.20.5 Null.......................................................................................................................................................18

9.21 All Sound Off (78H) ........................................................................................................................... 18

9.22 Reset All Controllers (79H)................................................................................................................ 18

10 Mode Messages ............................................................................................................................ 19

10.1 All Notes Off (7BH) ............................................................................................................................ 19

10.2 Omni Off (7CH).................................................................................................................................. 19

10.3 Omni On (7DH).................................................................................................................................. 19

10.4 Mono (7EH) ....................................................................................................................................... 20

10.5 Poly (7FH) ......................................................................................................................................... 20

11 Program Change ........................................................................................................................... 20

11.1 About Timbre Type............................................................................................................................ 21

11.2 DSP Assignments during Tone Selection.......................................................................................... 21

11.2.1 DSP Line Structure............................................................................................................................... 21

11.2.2 DSP Line Assignment .......................................................................................................................... 21

11.2.3 Use of the Same DSP Line by Multiple Parts ......................................................................................21

12 Channel Aftertouch ........................................................................................................................ 22

13 Pitch Bend Change ........................................................................................................................ 22

Part III System Messages

14 Active Sensing ............................................................................................................................... 23

15 System Exclusive Message ........................................................................................................... 23

15.1 Universal Realtime System Exclusive Message................................................................................ 23

15.1.1 Master Volume .....................................................................................................................................23

15.1.2 Master Balance.....................................................................................................................................24

15.1.3 Master Fine Tuning ..............................................................................................................................24

15.1.4 Master Coarse Tuning ..........................................................................................................................24

15.1.5 Reverb Parameter .................................................................................................................................25

15.1.6 Chorus Parameter .................................................................................................................................25

15.1.7 GM System Message............................................................................................................................27

15.1.8 GS Message.......................................................................................................................................... 27

15.2 Instrument-Specific System Exclusive Messages ............................................................................. 27

3

Part IV Instrument-Specific System Exclusive Messages

16 Format ........................................................................................................................................... 28

16.1 Message Classifications.................................................................................................................... 28

16.2 Basic Message Structure................................................................................................................... 28

16.3 Field Formats..................................................................................................................................... 29

16.3.1 SX : System Exclusive Message Status ............................................................................................... 29

16.3.2 MAN : Manufacturer’s ID.................................................................................................................... 29

16.3.3 MOD : Model ID.................................................................................................................................. 29

16.3.4 dev : MIDI DeviceID 00H - 7FH .........................................................................................................29

16.3.5 act : Action ........................................................................................................................................... 29

16.3.6 cat : Category ....................................................................................................................................... 30

16.3.7 mem : Memory Area ID ....................................................................................................................... 30

16.3.8 pset : Parameter Set Number ................................................................................................................30

16.3.9 blk : Block Number ..............................................................................................................................30

16.3.10 prm : Parameter ID............................................................................................................................... 31

16.3.11 idx : Data Index Number ......................................................................................................................31

16.3.12 len : Data Length ..................................................................................................................................31

16.3.13 data : Parameter Data ...........................................................................................................................32

16.3.14 EOX : End of System Exclusive Message ........................................................................................... 32

17 Parameter Transfer........................................................................................................................ 33

17.1 Two-way Communication .................................................................................................................. 33

17.1.1 Example : Data send in response to send request to the Instrument ....................................................33

17.2 One-way Communication .................................................................................................................. 33

17.2.1 Example : Data send to Instrument from external source ....................................................................33

17.2.2 Example : Data send resulting from Instrument operation .................................................................. 33

Part V Parameter List

18 System Parameters ....................................................................................................................... 34

18.1 System Information Parameter.......................................................................................................... 34

19 Setup Parameter............................................................................................................................ 34

19.1 MIDI Parameter ................................................................................................................................. 34

20 Patch Parameters .......................................................................................................................... 35

20.1 Master Tune Parameters................................................................................................................... 35

20.2 Master Mixer Parameters .................................................................................................................. 35

20.3 System Chorus Parameter ................................................................................................................ 35

20.4 System Reverb Parameters .............................................................................................................. 36

20.5 System Acoustic Resonance Parameters ......................................................................................... 36

20.6 Brilliance Parameters ........................................................................................................................ 36

20.7 Part Parameters ................................................................................................................................ 37

21 Tone Parameters ........................................................................................................................... 37

21.1 Basic Parameters .............................................................................................................................. 37

21.2 LFO Parameters ................................................................................................................................ 38

21.3 DSP Parameters................................................................................................................................ 39

21.4 Scale Tune ........................................................................................................................................ 39

4

22 Music Library Parameters .............................................................................................................. 39

Part VI DSP Parameter List

23 Tone with DSP List ........................................................................................................................ 40

24 DSP Algorithm ID Tables............................................................................................................... 41

24.1 Monaural Tone DSP.......................................................................................................................... 41

24.2 Stereo Tone DSP .............................................................................................................................. 41

25 DSP Parameter Set Types ............................................................................................................ 41

25.1 Tremolo/Auto Pan.............................................................................................................................. 41

25.2 3Band EQ .......................................................................................................................................... 41

25.3 Wide 3Band EQ................................................................................................................................. 42

25.4 Enhancer ........................................................................................................................................... 42

25.5 Distortion ........................................................................................................................................... 42

25.6 Early Reflection ................................................................................................................................. 42

25.7 Rotary ................................................................................................................................................ 43

25.8 Drive Rotary....................................................................................................................................... 43

Part VII Setting Values and Send/Receive Values

26 Setting Value Tables...................................................................................................................... 44

26.1 Off/On Setting Value Table................................................................................................................ 44

26.2 Slow/Fast Setting Value Table .......................................................................................................... 44

26.3 Rotate/Brake Setting Value Table ..................................................................................................... 44

26.4 –64 - 0 - +63 Setting Value Table...................................................................................................... 44

26.5 Pan Setting Value Table.................................................................................................................... 44

26.6 –100 - 0 - +99 Setting Value Table.................................................................................................... 44

26.7 Reverb Type Setting Value Table...................................................................................................... 44

26.8 Chorus Type Setting Value Table...................................................................................................... 45

26.9 Equalizer Mid Frequency Setting Value Table .................................................................................. 45

26.10 Wide Band Equalizer Mid Frequency Setting Value Table................................................................ 45

26.11 Brilliance Gain Setting Value Table ................................................................................................... 46

26.12 DSP Equalizer Gain Setting Value Table .......................................................................................... 46

Part VIII MIDI Implementation Notation

27 Value Notation ............................................................................................................................... 47

27.1 Hexadecimal Notation ....................................................................................................................... 47

27.2 Binary Notation .................................................................................................................................. 47

5

Part I

MIDI Message Overview

1 Product Configuration as a MIDI Device

As a MIDI device, the instrument consists of the System Section, Sound Generator Section, and Performance Controller

Section described below.

Each of these sections sends and receives specific MIDI Messages in accordance with its function.

•System Section

–Device settings

–Function status

•Sound Generator Section

–Common

Sound generator common section

System effects

Brilliance adjustment function

Mixer master

–Parts

Sound generator instrument parts

DSP (insertion effects)

Mixer channel

•Performance Controller Section

–Keyboard

–Pedal and other real-time controllers

–Auto play function

–Auto Accompaniment

1.1 System Section

The System Section consists of a sound generator (sound source), a performance controller part (performance), and functions

that are not directly related to Instrument play. In addition to manipulating Instrument setting parameters, this section is

also used to exchange information.

1.2 Sound Generator Section

The Sound Generator Section consists of a common part that does not depend on the channel and a part that is specific

to each channel. Mainly it receives performance information and performs operations.

1.2.1 Sound generator common section

The common section consists of sound generator setting blocks that do not depend on the sound generator part, such as

system effects, mixer master control, etc.

These can be controlled by system exclusive messages that are basically exclusive to this particular Instrument, but several

parameters also can be controlled by general universal system exclusive messages.

6

1.2.2 Parts

The settings of the sound generator parts can be changed using Instrument-specific system exclusive messages.

This Instrument consists of 48 parts. Of these, channel messages can be used to perform note on operations and to change

settings of only the C Group (C01 through C16).

The relationships between the channel message receive channel and part number are fixed, as shown in “1.2.3 Part

Assignments”.

1.2.3 Part Assignments

Part Number Part Name MIDI Receive Ch MIDI Send Ch Assigned Function Description

00 A01 - 01(Note1) Keyboard Upper1 (main)

(Right-side keyboard in the Duet Mode)

01 A02 - 02 Keyboard Upper2 (Layer)

02 A03 - 03 Keyboard Lower1 (Split)

(Left-side keyboard in the Duet Mode)

03 A04 - 08 Keyboard Harmonize (DSP not supported.)

04 A05 - 05 Recorder Play System track main

05 A06 - 06 Recorder Play System track layer

06 A07 - 07 Recorder Play System track split

07 A08 - - Metronome/Count

08 A09 - 09 Accompaniment Percussion (DSP not supported.)

09 A10 - 10 Accompaniment Drum (DSP not supported.)

10 A11 - 11 Accompaniment Bass (DSP not supported.)

11 A12 - 12 Accompaniment Chord 1 (DSP not supported.)

12 A13 - 13 Accompaniment Chord 2 (DSP not supported.)

13 A14 - 14 Accompaniment Chord 3 (DSP not supported.)

14 A15 - 15 Accompaniment Chord 4 (DSP not supported.)

15 A16 - 16 Accompaniment Chord 5 (DSP not supported.)

16 B01 - 01 (Note2) Recorder/Song Play Ch.01

17 B02 - 02 (Note2) Recorder/Song Play Ch.02

18 B03 - 03 (Note2) Recorder/Song Play Ch. 03 (Left hand track)

19 B04 - 04 (Note2) Recorder/Song Play Ch. 04 (Right hand track)

20 B05 - 05 (Note2) Recorder/Song Play Ch.05

21 B06 - 06 (Note2) Recorder/Song Play Ch.06

22 B07 - 07 (Note2) Recorder/Song Play Ch.07

23 B08 - 08 (Note2) Recorder/Song Play Ch.08

24 B09 - 09 (Note2) Recorder/Song Play Ch.09

25 B10 - 10 (Note2) Recorder/Song Play Ch.10

26 B11 - 11 (Note2) Recorder/Song Play Ch.11

27 B12 - 12 (Note2) Recorder/Song Play Ch.12

28 B13 - 13 (Note2) Recorder/Song Play Ch.13

29 B14 - 14

(Note2) Recorder/Song Play Ch.14

30 B15 - 15

(Note2) Recorder/Song Play Ch.15

31 B16 - 16 (Note2) Recorder/Song Play Ch.16

32 C01 01 - MIDI Ch.01

33 C02 02 - MIDI Ch.02

34 C03 03 - MIDI Ch.03

35 C04 04 - MIDI Ch.04

36 C05 05 - MIDI Ch.05

37 C06 06 - MIDI Ch.06

38 C07 07 - MIDI Ch.07

39 C08 08 - MIDI Ch.08

40 C09 09 - MIDI Ch.09

41 C10 10 - MIDI Ch.10

42 C11 11 - MIDI Ch.11

43 C12 12 - MIDI Ch.12

44 C13 13 - MIDI Ch.13

45 C14 14 - MIDI Ch.14

46 C15 15 - MIDI Ch.15

47 C16 16 - MIDI Ch.16

7

Note 1:

Can be changed by the Keyboard Channel setting.

Note 2:

Sent during recorder play only.

When there is no data recorded in the applicable recorder track, the MIDI information of the functions of parts with the

same send channel (A01 through A16) is sent.

1.3 Performance Controller Section

The Performance Controller Section consists of keyboard, pedal and other real-time controllers, as well as blocks that generate

auto accompaniment, auto performance, and other performance information.

These messages are transmitted to the sound generator in accordance with operations, while they are also being sent out

as MIDI messages.

The channel number of the sent message is in accordance with Instrument’s part number.

1.3.1 Auto Accompaniment and Auto Performance MIDI Send

This document what operation is sent by a message in the case of each message type. However, since there are so many

messages sent by an auto accompaniment operation when auto performance and Accomp MIDI Out is turned on, those

messages are not covered here.

2 Conditions that Disable Message Send and Receive

All MIDI message send and receive is temporarily disabled in all of the following cases.

•During instrument startup

•During SD card formatting

•During user data initialization

•Immediately after the recorder is exited

•During storage of registration data

•While storage is selected as the USB device mode

3 Timbre Type Specific Operation

The operation that is performed for a received message depends on the current Timbre Type setting (see “11.1 About Timbre

Type”), which is the operation mode of each sound generator part. Applicable information is provided in the explanations

for each message.

8

Part II

Channel Message

4 Send Channel

For information about the MIDI channels of the channel messages that are sent when this Instrument is played, see

“1.2.3 Part Assignments”.

Note, however, that the MIDI channel of the performance information that corresponds to the keyboard main part can be

changed by the Keyboard Channel setting value.

5 Receive Channel

For information about the MIDI channel numbers of channel messages received by each part, see “1.2.3 Part Assignments”.

The MIDI channel number of a channel message that changes DSP settings also coincides with the MIDI channel of the

part using the DSP. A channel message is not received by a part that is turned off by the Part Enable Parameter value

explained under “20.7 Part Parameters”.

6 Note Off

Format

Send

Sent when a key is released.

Receive

Recognized as key release information. The velocity value is ignored.

Message Format:

Send Receive

8nH kkH vvH 8nH kkH vvH

9nH kkH 00H

n: MIDI Channel Number

kk: Key Number

vv: 40H Ignored

9

7Note On

Format

Send

Sent when a key is pressed.

Receive

Recognized as key press information.

8 Polyphonic Key Pressure

Format

Send

This message is not sent by this Instrument.

Receive

This message is not received by this Instrument.

9 Control Change

Format

Send

Sent when a pedal or another controller operation is performed, when settings are changed, when the tone is changed, or

when an auto performance, Auto Accompaniment, or other operation is performed.

Receive

Receipt changes the controller and settings that correspond to the control number.

Message Format: 9nH kkH vvH

n: MIDI Channel Number

kk: Key Number

vv: Velocity

Message Format: AnH kkH vvH

n: MIDI Channel Number

kk: Key Number

vv: Pressure Value

Message Format: BnH ccH vvH

n: MIDI Channel Number

cc: Control Number

vv: Value

10

9.1 Bank Select (00H)

Format

Send

Sent when a tone is selected.

For information about numbers, see the Tone List in the User’s Guide.

Receive

Receipt switches the tone bank number stored in Instrument memory. Note, however, that the tone is not changed until a

Program Change message is received.

For details, see “11 Program Change”.

For information about numbers, see the Tone List in the User’s Guide.

9.2 Modulation (01H)

Format

Send

This message is not sent by this Instrument.

Receive

Receipt adds, to the voice being sounded, modulation of a depth specified by the value. In the case of a tone that already

has modulation applied, receipt of this message increases the modulation depth. The modulation effect differs according

to the tone being used.

9.3 Portamento Time (05H)

Format

Send

This message is not sent by this Instrument.

Receive

Receipt changes the time it takes until pitch reaches the target portamento effect pitch.

Message Format: BnH 00H mmH (MSB)

BnH 20H llH (LSB)

n: MIDI Channel Number

mm: Value

ll: Send: 00H, Receive: Ignored

Message Format: BnH 01H vvH

n: MIDI Channel Number

vv: Value

Message Format: BnH 05H vvH

n: MIDI Channel Number

vv: Value

11

9.4 Data Entry (06H, 26H)

Format

Send

Sent when there is a change in the parameters assigned to NRPN and RPN.

For details about information assigned to parameters that correspond to NRPN and RPN, see “9.19 NRPN” and “9.20 RPN”.

Receive

Receipt changes the parameter assigned to RPN. This Instrument does not have a parameter that corresponds to NRPN.

9.5 Volume (07H)

Format

Send

Sent when layer balance is adjusted.

Receive

Receipt changes the volume of the corresponding part.

9.6 Pan (0AH)

Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.5 Pan Setting Value Table”

in “Part VII Setting Values and Send/Receive Values”.

Send

Sent in the following cases.

•When Accomp MIDI Out is on

•When Music Library play is stopped

Receive

Receipt changes the pan setting of the corresponding part.

Message Format: BnH 06H vvH (MSB)

BnH 26H vvH (LSB)

n: MIDI Channel Number

vv: Value

Message Format: BnH 07H vvH

n: MIDI Channel Number

vv: Value

Message Format: BnH 0AH vvH

n: MIDI Channel Number

vv: Value (Note1)

12

9.7 Expression (0BH)

Format

Send

Sent in the following cases.

•When Accomp MIDI Out is on

Receive

Receipt changes the Expression value.

9.8 General Use Controllers 1 through 8 (10H through 13H, 50H through 53H)

These messages are used to control DSP operation.

Format

Send

This message is not sent by this Instrument.

Receive

Receipt change the value of Parameter7 [0-7] (7-Bit Parameter) explained under “21.3 DSP Parameters”. Any message

received that corresponds to the parameter of a number not being used by the currently selected DSP is ignored.

Note 1:

Received values and parameter setting values

The range of the value of each DSP Parameter 7 array element depends on the selected DSP or array number.

Unlike manipulation of a DSP parameter using a System Exclusive Message, a value received by this control change message

is always in the range of 0 to 127, but the range is changed in accordance with the setting range of the applicable parameter

setting. Because of this, it is impossible for a value to be outside of the range.

Conversion to the parameter setting value from the value received with the message can be represented in general terms

by the expression shown below.

For details about Parameter 7 of each DSP, see the explanations under “VI DSP Parameter List”.

Message Format: BnH 0BH vvH

n: MIDI Channel Number

vv: Value

Message Format: BnH 10H vvH

BnH 11H vvH

BnH 12H vvH

BnH 13H vvH

BnH 50H vvH

BnH 51H vvH

BnH 52H vvH

BnH 53H vvH

DSP Parameter7[0]

DSP Parameter7[1]

DSP Parameter7[2]

DSP Parameter7[3]

DSP Parameter7[4]

DSP Parameter7[5]

DSP Parameter7[6]

DSP Parameter7[7]

n: MIDI Channel Number (Note1)

vv: Value

Parameter

Setting Value

=

Parameter

Minimum Value

+

(

Parameter

Maximum Value

-

Parameter

Minimum Value)

X

Received Value

127

13

9.9 Hold1 (40H)

Format

Send

Sent in the following cases.

•When a pedal that has a sustain (damper) function is operated

•When Accomp MIDI Out is on

Receive

Receipt performs an operation equivalent to a sustain (damper) pedal operation.

Timbre Type Specific Operation

This operation differs in accordance with the Timbre Type (see “11.1 About Timber Type”) setting.

•Timbre Type: Melody

Sustain off/on control is performed in accordance with the value of the received message. For information about

the relationship between setting values and send/receive values, see the “26.1 Off/On Setting Value Table” in

“Part VII Setting Values and Send/Receive Values”.

•Timbre Type: Piano or LM Piano

Continuous control of the following is performed in accordance with the value of the received message.

–Piano note decay rate

–Resonance characteristics and decay rate of Acoustic Resonance effect resonance note

•Timbre Type: Drum

The received message does not affect sound source operation.

9.10 Portamento Switch (41H)

Format

Note 1:

For information about the relationship between setting values and send/receive values, see the “26.1 Off/On Setting Value

Table” in “Part VII Setting Values and Send/Receive Values”.

Send

This message is not sent by this Instrument.

Receive

Receipt can be use to switch portamento between enabled (On) and disabled (Off).

Message Format: BnH 40H vvH

n: MIDI Channel Number

vv: Value

Message Format: BnH 41H vvH

n: MIDI Channel Number

vv: Value (Note1)

14

9.11 Sostenuto (42H)

Format

Note 1:

For information about the relationship between setting values and send/receive values, see the “26.1 Off/On Setting Value

Table” in “Part VII Setting Values and Send/Receive Values”.

Send

Sent when a pedal that has a sostenuto function is operated.

Receive

Receipt performs an operation equivalent to a sostenuto pedal operation.

9.12 Soft (43H)

Format

Note 1:

For information about the relationship between setting values and send/receive values, see the “26.1 Off/On Setting Value

Table” in “Part VII Setting Values and Send/Receive Values”.

Send

Sent when a pedal that has a soft function is operated.

Receive

Receipt performs an operation equivalent to a soft pedal operation.

9.13 Vibrato Rate (4CH)

Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.4 –64 - 0 - +63 Setting

Value Table” in “Part VII Setting Values and Send/Receive Values” of this document.

Send

This message is not sent by this Instrument.

Receive

Receipt changes the vibrato rate of the tone that is currently selected by the applicable part.

Message Format: BnH 42H vvH

n: MIDI Channel Number

vv: Value (Note1)

Message Format: BnH 43H vvH

n: MIDI Channel Number

vv: Value (Note1)

Message Format: BnH 4CH vvH

n: MIDI Channel Number

vv: Value (Note1)

15

9.14 Vibrato Depth (4DH)

Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.4 –64 - 0 - +63 Setting

Value Table” in “Part VII Setting Values and Send/Receive Values” of this document.

Send

This message is not sent by this Instrument.

Receive

Receipt changes the vibrato auto depth of the tone that is currently selected by the applicable part.

9.15 Vibrato Delay (4EH)

Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.4 –64 - 0 - +63 Setting

Value Table” in “Part VII Setting Values and Send/Receive Values” of this document.

Send

This message is not sent by this Instrument.

Receive

Receipt changes the vibrato auto delay of the tone that is currently selected by the applicable part.

9.16 Portamento Control (54H)

Format

Send

This message is not sent by this Instrument.

Receive

Receipt of this message first stores the Source Note Number for the next note. When the next Note On is received, the

portamento effect is applied to the note using this Source Note Number as the pitch start point and the Note On event key

number as the end point. If there already is a note being sounded by Source Note Number at this time, the new note on

is not performed and the portamento effect is applied to the pitch of the note being sounded. That is to say that legato

play is performed.

Message Format: BnH 4DH vvH

n: MIDI Channel Number

vv: Value (Note1)

Message Format: BnH 4EH vvH

n: MIDI Channel Number

vv: Value (Note1)

Message Format: BnH 54H vvH

n: MIDI Channel Number

kk: Source Note Number

16

9.17 Reverb Send (5BH)

Format

Send

Sent when a GM tone is selected.

Receive

Receipt changes Reverb Send.

9.18 Chorus Send (5DH)

Format

Send

This message is sent at initialization, when the panel tone selection is changed, and when a chorus on/off operation is

performed.

Receive

Receipt changes Chorus Send.

9.19 NRPN (62H, 63H)

Format

Send

This message is not sent by this Instrument.

Receive

This message is not received by this Instrument.

9.19.1 Assignable Functions to NRPN

This Instrument does not assign any parameters to NRPN.

Message Format: BnH 5BH vvH

n: MIDI Channel Number

vv: Value

Message Format: BnH 5DH vvH

n: MIDI Channel Number

vv: Value

Message Format: BnH 62H vvH (LSB)

BnH 63H vvH (MSB)

n: MIDI Channel Number

vv: Value

17

9.20 RPN (64H, 65H)

Format

The following are the parameters assigned to RPN by this Instrument.

9.20.1 Pitch Bend Sensitivity

Format

Send

Sent when the pitch bend range is changed. (PX-330)

Receive

Receipt changes Pitch Bend Sensitivity.

9.20.2 Fine Tune

Format

Send

This message is not sent by this Instrument.

Receive

Receipt changes Channel Fine Tune.

9.20.3 Coarse Tune

Format

Send

This message is not sent by this Instrument.

Receive

Receipt changes Channel Coarse Tune.

Message Format: BnH 64H vvH (LSB)

BnH 65H vvH (MSB)

n: MIDI Channel Number

vv: Value

Message Format: BnH 64H 00H 65H 00H 06H mmH 26H llH

n: MIDI Channel Number

mm:

ll:

Value 0 - 24

Send: 00H, Receive: Ignored

Message Format: BnH 64H 01H 65H 00H 06H mmH 26H llH

n: MIDI Channel Number

mm: Value MSB

ll: Value LSB

Message Format: BnH 64H 02H 65H 00H 06H mmH 26H 00H

n: MIDI Channel Number

mm: Value

18

9.20.4 Modulation Depth

Format

Send

This message is never sent.

Receive

Receipt changes the Vibrato Modulation Depth for the tone that is currently selected by the applicable part.

9.20.5 Null

Format

Send

This message is never sent.

Receive

Receipt deselects RPN.

9.21 All Sound Off (78H)

Format

Send

Sent when an SD card is inserted or removed, and when an SD card operation is performed.

Receive

Receipt stops all voices that are sounding.

9.22 Reset All Controllers (79H)

Format

Send

Sent in the following cases.

•When the keyboard channel is changed

•When a recorder function is used

•When another mode is entered from the rhythm mode

Receive

Receipt initializes each performance controller.

Message Format: BnH 64H 05H 65H 00H 06H mmH 26H 00H

n: MIDI Channel Number

mm: Value

Message Format: BnH 64H 7FH 65H 7F

n: MIDI Channel Number

Message Format: BnH 78H 00H

n: MIDI Channel Number

Message Format: BnH 79H 00H

n: MIDI Channel Number

19

10 Mode Messages

10.1 All Notes Off (7BH)

Format

Send

Sent in the following cases.

•When the keyboard channel is changed

•When a recorder function is used

•When another mode is entered from the rhythm mode

Receive

Receipt of this message releases the currently sounding voice (same as releasing the keyboard key).

10.2 Omni Off (7CH)

Format

Send

This message is never sent.

Receive

Receipt of this message releases the currently sounding voice (same as releasing the keyboard key).

10.3 Omni On (7DH)

Format

Send

This message is never sent.

Receive

Receipt of this message releases the currently sounding voice (same as releasing the keyboard key).

Message Format: BnH 7BH 00H

n: MIDI Channel Number

Message Format: BnH 7CH 00H

n: MIDI Channel Number

Message Format: BnH 7DH 00H

n: MIDI Channel Number

20

10.4 Mono (7EH)

Format

Send

This message is never sent.

Receive

Receipt of this message stops the currently sounding voice.

10.5 Poly (7FH)

Format

Send

This message is never sent.

Receive

Receipt of this message stops the currently sounding voice.

11 Program Change

Format

Send

Sent when a tone is selected.

For information about numbers, see the Tone List in the User’s Guide.

Receive

Receipt changes the tone.

The selected tone is determined by the program value of this message and the Bank Select message value received prior

to this message.

For information about the program number of the actually selected tone, see the Tone List in the User’s Guide.

Also note that receipt of this message may also change the Timbre Type parameter at the same time. For more information,

see “11.1 About Timbre Type” below.

Message Format: BnH 7EH 00H

n: MIDI Channel Number

Message Format: BnH 7FH 00H

n: MIDI Channel Number

Message Format: CnH ppH

n: MIDI Channel Number

pp: Program Number

21

11.1 About Timbre Type

The tone selected by each part of this Instrument has a “Timbre Type” parameter that specifies the type of sound source

for the tone. As explained under “21.1 Basic Parameters”, there are four Timbre Types settings: Melody, LM Piano, Piano,

and Drum. The operation for a received channel message differs according to the Timbre Type.

•Timbre Type: Melody

This Timbre Type is for normal melody tones. The damper pedal performs on/off operations.

•Timbre Type: Piano or LM (Linear Morphing) Piano

This Timbre Type is for piano tones.

The decay rate of the voice being sounded and Acoustic Resonance effect characteristics are continually altered in

accordance with the damper pedal position. The method for producing sound in response to the note messages also

is different from that of the melody Timbre Type, and operation is optimized for piano.

•Timbre Type: Drum

This Timbre Type is for drum sounds. The method for producing sound is optimized for drums. The damper pedal

and sostenuto pedal do not work for sounds that do not recognize Note Off. The tuning setting also does not affect

this Timbre Type.

11.2 DSP Assignments during Tone Selection

11.2.1 DSP Line Structure

Though the Instrument has four DSP lines that can be used simultaneously, selecting a tone that uses DSP causes the

required number of DSP lines to become reserved so the tone is configured with the requisite DSP.

Tones listed under “24.1 Monaural Tone DSP” use only one DSP line, while the tones under “24.2 Stereo Tone DSP” use

two DSP lines.

For information about tones that use DSP, see “23 Tone with DSP List”.

11.2.2 DSP Line Assignment

Selecting multiple tones with DSP at the same time creates the possibility that there will not be enough DSP lines. In this

case, the last selected tone with DSP is given priority. Some DSP line(s) already being used will be released so they can

be assigned to the newly selected tone.

11.2.3 Use of the Same DSP Line by Multiple Parts

When all of the settings below are the same for multiple parts that select tones that use DSP, the same DSP line is assigned

to all of the parts in order to maximize DSP line availability. Note, however, that a DSP cannot be shared simultaneously

between parts A01 through B16, and parts C01 through C16.

•Tone Number

•Part Volume

•Part Pan

•All DSP parameters

After the same DSP line is assigned to different parts as described here, Part Volume, Pan, Reverb Send, Chorus Send,

Acoustic Resonance Send, and all DSP parameter settings are common to all parts. Note that changing the settings on any

part will also affect all of the other parts that are sharing the DSP line.

To assign the parts to a different DSP line, you need to change one of the parameters listed above before selecting the tone.

22

12 Channel Aftertouch

Format

Send

This message is not sent by this Instrument.

Receive

Receipt of this message adds modulation to the voice that is sounding.

The modulation effect differs according to the tone being used.

13 Pitch Bend Change

Format

Send

Sent when the bend wheel is operated. (PX-330)

Receive

Receipt of this message changes the pitch of the currently sounding voice. Pitch bend change sensitivity depends on the

pitch bend sensitivity configured with RPN.

Message Format: DnH vvH

n: MIDI Channel Number

vv: Value

Message Format: EnH llH mmH

n: MIDI Channel Number

ll: Value LSB

mm: Value MSB

23

Part III

System Messages

14 Active Sensing

Format

Send

This message is never sent.

Receive

Once this message is received, the Active Sensing mode is entered. If no MIDI message is received for a specified amount

of time, voices being sounded by the Instrument’s sound source are released, the controller is reset, and the Active Sensing

mode is exited.

15 System Exclusive Message

Format

The Instrument sends and receives standard universal system exclusive messages, and system exclusive messages that have

Instrument-specific formats.

15.1 Universal Realtime System Exclusive Message

Format

15.1.1 Master Volume

Format

Send

This message is never sent.

Receive

Receipt changes the Master Volume parameter. Note that the Master Volume parameter cannot be changed with an Instrument

operation.

Message Format: FEH

Message Format: F0H....F7H

Message Format: F0H 7FH....F7H

Message Format: F0H 7FH 7FH 04H 01H llH mmH F7H

ll: Value LSB

mm: Value MSB

24

15.1.2 Master Balance

Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.5 Pan Setting Value Table”

in “Part VII Setting Values and Send/Receive Values”.

Send

This message is never sent.

Receive

Receipt changes the Master Pan parameter. Note that the Master Pan parameter cannot be changed with an Instrument

operation.

15.1.3 Master Fine Tuning

Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.6 –100 - 0 - +99 Setting

Value Table” in “Part VII Setting Values and Send/Receive Values” of this document.

Send

This message is sent when the tuning setting is changed.

Receive

Receipt changes the Master Fine Tune8 parameter of Patch.

Acoustic Resonance Actions

Acoustic Resonance acoustic characteristics also alter Fine Tune of the strings that simulate resonance in accordance with

the Master Fine Tune8 value. Because of this, receipt of this message may cause the resonance interval to change temporarily.

15.1.4 Master Coarse Tuning

Format

Send

This message is never sent.

Receive

Receipt changes the Patch Master Coarse Tune parameter.

Message Format: F0H 7FH 7FH 04H 02H llH mmH F7H

ll: Value LSB (Note1)

mm: Value MSB (Note1)

Message Format: F0H 7FH 7FH 04H 03H llH mmH F7H

ll: Value LSB (Note1)

mm: Value MSB (Note1)

Message Format: F0H 7FH 7FH 04H 04H llH mmH F7H

ll: Send: 00H, Receive: Ignored

mm: Value MSB

25

15.1.5 Reverb Parameter

Format

Type Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.7 Reverb Type Setting Value

Table” in “Part VII Setting Values and Send/Receive Values”.

Send

This message is sent when the System Reverb Type setting is changed.

Receive

Receipt changes the Reverb Type parameter.

Time Format

Send

This message is never sent.

Receive

Receipt changes the Reverb Time parameter.

15.1.6 Chorus Parameter

Format

Type Format

Note 1:

For information about the relationship between setting values and send/receive values, see “26.8 Chorus Type Setting Value

Table” in “Part VII Setting Values and Send/Receive Values”.

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 01H ppH vvH F7H

pp: Parameter

vv: Value

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 01H 00H vvH F7H

vv: Value (Note1)

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 01H 01H vvH F7H

vv: Value

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 02H ppH vvH F7H

pp: Parameter

vv: Value

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 02H 00H vvH F7H

vv: Value (Note1)

26

Send

This message is sent when the System Chorus Type setting is changed.

Receive

Receipt changes the System Chorus Type parameter.

Rate Format

Send

This message is never sent.

Receive

Receipt changes the System Chorus Rate parameter.

Depth Format

Send

This message is never sent.

Receive

Receipt changes the System Chorus Depth parameter.

Feedback Format

Send

This message is never sent.

Receive

Receipt changes the System Chorus Feedback parameter.

Send To Reverb Format

Send

This message is never sent.

Receive

Receipt changes the Chorus Send To Reverb parameter.

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 02H 01H vvH F7H

vv: Value

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 02H 02H vvH F7H

vv: Value

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 02H 03H vvH F7H

vv: Value

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H

01H 02H 04H vvH F7H

vv: Value

27

15.1.7 GM System Message

GM System On Format

Send

This message is never sent.

Receive

Receipt puts the sound source into a GM sound source mode. Also, the Scale Tune Enable setting shown under “20.7 Part

Parameters” for parts C01 through C16 become zero, which disables the temperament (scale) function.

GM System Off Format

Send

This message is never sent.

Receive

Receipt returns the sound source to its power on default settings.

GM2 System On Format

Send

This message is never sent.

Receive

Though the Instrument does not support GM2, receipt of the GM2 System On message has the same result as receipt of

the GM System On message.

15.1.8 GS Message

Send

This message is never sent.

Receive

Receipt performs the same operation as when the GM System On message is received.

15.2 Instrument-Specific System Exclusive Messages

Format

Most Instrument parameters and user data, and some operation commands can be controlled using this message.

For more information, see “Part IV Instrument-Specific System Exclusive Messages”.

1 Message Format: F0H 7EH 7FH 09H 01H F7H

Message Format: F0H 7EH 7FH 09H 02H F7H

Message Format: F0H 7EH 7FH 09H 03H F7H

Message Format: F0H 41H ddH 42H 12H 40H 00H 7FH 00H 41H F7H

Note: dd (Device ID) is ignored.

Message Format: F0H 44H 15H 01H....F7H

28

Part IV

Instrument-Specific System Exclusive Messages

16 Format

This section explains the format of the Instrument-specific System Exclusive Messages. See “Part V Parameter List” for

information about what type of data can actually be sent.

16.1 Message Classifications

Basically, the operation that corresponds to Instrument-specific system exclusive messages is parameter data transfer. The

following operations can be performed from an external device using this parameter transfer message.

•Modification of an individual Instrument parameter

•Import of an individual Instrument parameter value

In addition to parameters being used as device setting values, some parameters act as commands when received by the

Instrument and as device status information when sent from the Instrument.

The following table shows the parameter category for each type of transfer.

16.2 Basic Message Structure

Since Instrument-specific System Exclusive messages are sent and received on an individual parameter basis, the Individual

Parameter Transfer method is used, and a number of message types are provided to suit specific operations. The field in

the SysEx message that specifies the message type is the action (act) field. The format of the “body” part of the message

depends on the “act” value.

The table below shows the body format for each action of Instrument-specific system exclusive messages. An actual message

consists of the items indicated by “Y”, from left to right.

Function Section Parameter Category Description

System System Commands, Instrument status

Setup Instrument basic settings

Sound Generator Patch Sound source common settings (system effects, master

settings, etc.)

Sound source part settings (tone selection, mixing,

tuning, etc.)

Tone Tone parameter, DSP settings

Scale Tune Scale Tune Table

Music Player Music Library User song data

act SX MAN MOD dev act body (Depends on act.) EOX

cat mem pset blk pkt prm idx len data

IPRYYYYYYYYYYYYY-Y

IPSYYYYYYYYYYYYYYY

29

16.3 Field Formats

16.3.1 SX : System Exclusive Message Status

This is the System Exclusive Message status byte established by the MIDI standard.

16.3.2 MAN : Manufacturer’s ID

Indicates this Instrument’s manufacturer ID.

16.3.3 MOD : Model ID

These two successive bytes (MSB, LSB) indicate the PX-130, 330, 3, 730, 7, 830, and AP-220, 420, 620, 6 model ID.

16.3.4 dev : MIDI DeviceID 00H - 7FH

The contents of this field in a received message are compared with the Model’s MIDI Device ID, and receipt of the incoming

message is allowed only when the two IDs match. The default value for this field is 10H. When a message containing

7FH is received, receipt of the message is always allowed, regardless of the Instrument’s ID setting.

MIDI Device ID is a Patch Parameter, and it can be changed with a System Exclusive Message. In this case, the Device

ID of the MIDI System Exclusive Message must be set to 7FH before it is sent.

16.3.5 act : Action

This field indicates the operation of the Instrument-specific System Exclusive Message.

IPR : Individual Parameter Request

Indicates an individual parameter value send request message. When the Instrument receives this action, it uses an IPS

message to return the specified parameter value.

IPS : Individual Parameter Send

Indicates an individual parameter value send message. When the Instrument receives this action, it rewrites the value specified

by the data field with the specified parameter value.

Format: 11110000B (F0H)

Format: 01000100B (CASIO = 44H)

Format: MSB 00010101B (15H)

LSB 00000010B (02H)

Format: 0dddddddB

Format: 0aaaaaaaB

aaaaaaaB Action Function

00H IPR Individual Parameter Request

01H IPS Individual Parameter Send

30

16.3.6 cat : Category

0cccccccB = Category (7bit)

The category indicates the categories of data handled by the System Exclusive Message. The ID number (ID) of the category

is indicated on the left, while the communication operation (Action) is indicated on the right.

A .. Available (Also including when only some parameters are available.)

F... File Information (Not the data itself. Name, size, and other file information only.)

16.3.7 mem : Memory Area ID

Specifies the memory area that is the object of the parameter transfer. The following are defined for this Instrument. Basically,

Instrument-specific System Exclusive messages are valid for user area data only.

16.3.8 pset : Parameter Set Number

This field is a 2-byte (LSB, MSB) value indicating the number of the parameter set (mmmmmmmnnnnnnnB, binary) being

transferred.

16.3.9 blk : Block Number

This supplementary number specifies which block is the object when there are multiple blocks within the same parameter set.

When there are multiple parameters with the same ID inside the same category, as with the mixer channel volume setting

for example, the block number required to specify to which block data belongs is specified as: kkkkkkkjjjjjjjiiiiiiiB (Binary).

When the parameter block has a multi-dimensional array structure, bit 21 of the block number is divided into prescribed

bit fields based on the rules explained below.

Format: 0cccccccB

Category Transfer

ID (c) Parameter Set Individual Parameter

00H System A

01H Setup A

02H Patch A

03H Tone A

21H Music Library F

Format: 0mmmmmmmB

mem Data Type Meaning

0 User area Read/write enabled

1 Preset area Read/write disabled

Format: LSB 0nnnnnnnB

MSB 0mmmmmmmB

Format: 0iiiiiiiB (LSB) 0jjjjjjjB 0kkkkkkkB (MSB)

31

Block Bit Field Division

•Case 1

When an array has three or fewer nesting levels and the number of arrays in each dimension is 128 or less, they

are assigned below the three 7-bit fields. Unused regions are filled with zeros.

Example:

parameter [A][B][C]

With a 3-dimensional array parameter that consists of A=8 (3 bits), B=5 (3 bits) and C=10 (4 bits), the block bit

fields are allocated as: Block = 0000aaa 000bbb ccccccc (Binary).

•Case 2

When Case 1 conditions are not satisfied, the minimal number of fields required for each number of arrays is reserved

from the lower bit of the block. Unused regions are filled will zeros.

Example 1:

parameter [A][B][C][D]

With a 4-dimensional array parameter that consists of A=3 (2 bits), B=4 (2 bits), C=3 (2 bits) and D=4 (2 bits)

like the one shown above, the block bit fields are allocated as: Block = 0000000 00000a abbccdd (Binary).

Example 2:

parameter [A][B]

With an A=3 (2bit), B=200 (8bit) 2-dimensional array parameter, the block bit fields are allocated as:

Block = 0000000 000aab bbbbbbb (Binary).

16.3.10 prm : Parameter ID

The Parameter ID indicates the parameter type. (See “Part V Parameter List”.)

When transferring individual parameters individually (as opposed to bulk transfer), this field is used to identify the parameter

by its parameter ID.

16.3.11 idx : Data Index Number

The data index number indicates the first array number of the array where transfer starts.

16.3.12 len : Data Length

The value of this field specifies the size of the parameter value stored in the data field. Data length indicates the length

of the array being transferred minus 1 when the parameter contains a character string or other similar array structure.

Format: LSB 0pppppppB

MSB 0qqqqqqqB

Format: 0iiiiiiiB

Format: 0lllllllB

32

16.3.13 data : Parameter Data

Parameter data indicates the parameter value.

The data array size is len + 1. For a one data item structure, the length depends on the data bit width, as shown below.

Each block of data is packed from the lowest order byte first. In the case of multiple-byte data, the lowest weighted bit

is the LSB of the first “data” block, and the highest weighted bit is the MSB of the final “data” block.

The following shows an example of how data would be divided for transfer in the case of 32-bit data.

Single Message Size Limit

With the Instrument’s system exclusive message format, the size of a single message cannot exceed 48 bytes.

The data size and the array size, however, can cause a packet to exceed 48 bytes when transferring a single parameter array.

In this case, the IPS and IPR message data length and data index number values can be modified to enable division of a

single parameter value into multiple messages so it can be sent that way.

16.3.14 EOX : End of System Exclusive Message

This is the End of System Exclusive Message status byte established by the MIDI standard.

Format: index0 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

index1 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

index2 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

::

indexN 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

dddddB + 1 Number of data

1 - 71

8 - 14 2

15 - 21 3

22 - 28 4

29 - 32 5

76543210

data0: 0 [bit06] [bit05] [bit04] [bit03] [bit02] [bit01] [bit00]

data1: 0 [bit13] [bit12] [bit11] [bit10] [bit09] [bit08] [bit07]

data2: 0 [bit20] [bit19] [bit18] [bit17] [bit16] [bit15] [bit14]

data3: 0 [bit27] [bit26] [bit25] [bit24] [bit23] [bit22] [bit21]

data4: 0 0 0 0 [bit31] [bit30] [bit29] [bit28]

Format: 11110111B

33

17 Parameter Transfer

There are two parameter operations: Individual Parameter Transfer and Individual Parameter Request.

A single session is concluded only when this Instrument returns an IPS (Individual Parameter Send) in response to an

IPR (Individual Parameter Request) from an external device, or when an external device or this Instrument spontaneously

sends an IPS. If this Instrument received an IPS, the value of the applicable parameter is changed.

Depending on the function of a parameter, Individual Parameter Send may be used to issue a command to the Instrument

or Individual Parameter Request may be used to check Instrument status information.

17.1 Two-way Communication

17.1.1 Example : Data send in response to send request to the Instrument

17.2 One-way Communication

17.2.1 Example : Data send to Instrument from external source

17.2.2 Example : Data send resulting from Instrument operation

Data Receiver Data Sender Operation

IPR Send Request

IPS Data Transfer

Data Sender Data Receiver Operation

IPS Data Transfer

Data Receiver Data Sender Operation

IPS Data Transfer

34

Part V

Parameter List

How to Read the Tables

Number Base Notation

“Size” indicates the parameter value bit width as a decimal value.

The bit field position of “Block” as a decimal value.

Values used in the explanations under “Description” are all decimal values, unless specified otherwise.

Values other than those described above are all hexadecimal.

R/W field

The R/W field indicates whether an IPR (Individual Parameter Request) read operation or IPS (Individual Parameter Send)

write operation is enabled.

18 System Parameters

These parameters make it possible for an external device to check the status of the Instrument and for an external device

to command some operation of the Instrument.

18.1 System Information Parameter

This parameter is a container for system information.

19 Setup Parameter

Setup Parameters put a device into the setup mode.

19.1 MIDI Parameter

Parameter ID R/W Block Size Array Min-Def-Max Description

Model 0000 R 000000 7 01 00-00-7F 0...PX-130

1...PX-330

2...PX-730/PX-7

3...PX-830

4...reserved

5...AP-220

6...AP-420

7...AP-620/AP-6

8...PX-3

Parameter ID R/W Block Size Array Min-Def-Max Description

Midi Device Id 006D R/W 000000 7 01 00-7F-7F 0-127

35

20 Patch Parameters

The main function of patch parameters is to configure the settings of the sound source of a device.

20.1 Master Tune Parameters

These parameters configure the Master Tuning Settings.

20.2 Master Mixer Parameters

These parameters configure the Master settings of the mixer.

20.3 System Chorus Parameter

Note 1:

Selects the System Chorus preset type. Receipt of GM/GS Reset selects Chorus3. The value of this type is also linked to

System Chorus parameters, and to the Chorus Send to Reverb and System Chorus Return Level parameters, and its setting

causes these parameters to change to prescribed values. For details about the preset type list, see “26.8 Chorus Type Setting

Value Table”.

Parameter ID R/W Block Size Array Min-Def-Max Description

Master Fine Tune8

Master Coarse Tune

Stretch Tune Enable

0001

0002

0003

R/W

R/W

R/W

000000





8

7

1

01

01

01

00-80-FF

00-40-7F

00-01-01

–100 - 0 - +99(cent)

–24 - 0 - +24(semitone)

0...Disable

1...Enable

Parameter ID R/W Block Size Array Min-Def-Max Description

Master Volume

Master Pan

Acou Reso To Chorus

Acou Reso To Reverb

Acou Reso Return

Chorus To Reverb

Chorus Return

Reverb Return

Dsp Cancel

0012

0013

0016

0018

0019

001D

001E

0025

0028

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

000000

















7

7

7

7

7

7

7

7

1

01

01

01

01

01

01

01

01

01

00-7F-7F

00-40-7F

00-00-7F

00-00-7F

00-40-7F

00-00-7F

00-40-7F

00-40-7F

00-00-01

0-127

–64 - 0 - +63

0-127

0-127

0-127

0-127

0-127

0-127

0...Normal

1...Cancel

Parameter ID R/W Block Size Array Min-Def-Max Description

Cancel

Type

Rate

Depth

Feedback

Tone

0050

0051

0052

0053

0054

0055

R/W

R/W

R/W

R/W

R/W

R/W

000000











1

7

7

7

7

7

01

01

01

01

01

01

00-00-01

00-02-0F

00-0B-7F

00-21-7F

00-00-7F

00-4B-7F

0...Normal

1...Cancel

1-16 (Note1)

0-127

0-127

0-127

0-127

36

20.4 System Reverb Parameters

Note 1:

Selects the System Reverb preset type. Receipt of GM/GS Reset selects Hall2. This is the value of this Type is also linked

to each of the System Reverb parameters and to the System Reverb Return Level parameter, and changes them to prescribed

values. For details about the preset type list, see “26.7 Reverb Type Setting Value Table”.

20.5 System Acoustic Resonance Parameters

Note 1:

Changing this parameter configures the Tuning setting of System Acoustic Resonance. When the Instrument’s Master Fine

Tune8 setting is changed, this parameter is reset to the Master Fine Tune8 value.

Note 2:

Changing this parameter performs a Damper Pedal operation on System Acoustic Resonance. When the damper pedal of

the part being used by System Acoustic Resonance is operated, this parameter is reset to the depth of the damper pedal

operation.

Note 3:

The value is set when the damper pedal is completely depressed.

20.6 Brilliance Parameters

Note 1:

Selects Master EQ mid 6 (Brilliance) gain. See “26.11 Brilliance Gain Setting Value Table”.

Parameter ID R/W Block Size Array Min-Def-Max Description

Cancel

Type

Feedback

Er Level

Damp

Tone

0080

0081

0082

0083

0084

0085

R/W

R/W

R/W

R/W

R/W

R/W

000000











1

7

7

7

7

7

01

01

01

01

01

01

00-00-01

00-04-0F

00-40-7F

00-40-7F

00-67-7F

00-65-7F

0...Normal

1...Cancel

1-16 (Note1)

0-127

0-127

0-127

0-127

Parameter ID R/W Block Size Array Min-Def-Max Description

Cancel

Tuning

Damper Pedal

Wet Level Max

Low Boost Freq

Low Boost Level

High Cut Freq

0030

0031

0032

003B

003C

003D

003E

R/W

R/W

R/W

R/W

R/W

R/W

R/W

000000













1

7

7

16

16

16

16

01

01

01

01

01

01

01

00-00-01

00-40-7F

00-00-7F

0000-0800-7FFF

0000-0A00-4000

0000-7FFF-7FFF

0000-2F00-7FFF

0...Normal

1...Cancel

–100 - 0 - +99(cent) (Note1)

0-127 (Note2)

0x0000-0x7FFF (Note3)

0x0000-0x4000

0x0000-0x7FFF

0x0000-0x7FFF

Parameter ID R/W Block Size Array Min-Def-Max Description

Type

Mid6 Gain

00A0

00AE

R/W

R/W

000000



7

7

01

01

00-00-01

00-0C-18

0...For Speaker

1...For Phones

–12 - 0 - +12 (Brilliance) (Note1)

37

20.7 Part Parameters

21 Tone Parameters

21.1 Basic Parameters

Note 1:

When a tone is selected whose Sys Fx Send Override parameter setting is “Yes”, the send level setting value to the

System Chorus, System Reverb, and System Acoustic Resonance of the part assigned to this tone is rewritten to the value

that is stored by this tone.

Parameter ID R/W Block Size Array Min-Def-Max Description

Part Enable

Tone Num

Fine Tune

Coarse Tune

Scale Tune Enable

Volume

Acmp Volume

Pan

Cho Send

Rev Send

Acou Reso Send

Bend Range

00E0

00E1

00E2

00E3

00E4

00E5

00E6

00E7

00E8

00E9

00EA

00EC

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

20-6: 0

5-0: Part #























1

14

7

7

1

7

7

7

7

7

7

7

01

01

01

01

01

01

01

01

01

01

01

01

00-01-01

0000-0000-3FFF

00-40-7F

28-40-58

00-00-01

00-64-7F

00-7F-7F

00-40-7F

00-00-7F

00-28-7F

00-00-7F

00-02-18

0...Off

1...On

0-16383

–100 - 0 - +99(cent)

–24 - 0 - +24(semitone)

0...Disable

1...Enable

0-127

0-127

–64 - 0 - +63

0-127

0-127

0-127

0-24

Parameter ID R/W Block Size Array Min-Def-Max Description

Name

Timbre Type

Timbre Num

Oct Shift

Line Select

Level

Touch Sens

Sys Fx Send Override

Cho Normal Send

Cho Deep Send

Rev Send

Acou Reso Send

0000

0001

0002

0003

0004

0005

0006

0007

0008

0009

000A

000B

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

000000























7

4

14

3

1

7

7

1

7

7

7

7

10

01

01

01

01

01

01

01

01

01

01

01

00-20-7F

00-00-0F

0000-0000-3FFF

02-04-06

00-00-01

00-7F-7F

00-7F-7F

00-00-01

00-00-7F

00-00-7F

00-28-7F

00-00-7F

Ascii Character

0...Melody

1...Piano

2...Drum

3...reserved

4...LM Piano

0-16383

–2 - 0 - +2

0...Direct

1...DSP

0-127

–64 - 0 - +63

0...No (Note1)

1...Yes

0-127

0-127

0-127

0-127

38

21.2 LFO Parameters

Note 1:

The function of this parameter is to relatively change the original setting value of the tone. The parameter is set to the

maximum value when the maximum is exceeded, and to the minimum when the minimum is exceeded.

Parameter ID R/W Block Size Array Min-Def-Max Description

Vib Wave

Vib Rate

Vib Auto Delay

Vib Auto Rise

Vib Auto Depth

Vib Mod Depth

Vib After Depth

Lfo Wave

Lfo Rate

Lfo Fil Auto Delay

Lfo Fil Auto Rise

Lfo Fil Auto Depth

Lfo Fil Mod Depth

Lfo Fil After Depth

Lfo Amp Auto Delay

Lfo Amp Auto Rise

Lfo Amp Auto Depth

Lfo Amp Mod Depth

Lfo Amp After Depth

000D

000E

000F

0010

0011

0012

0013

0014

0015

0016

0017

0018

0019

001A

001B

001C

001D

001E

001F

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

000000





































4

7

7

7

7

7

7

4

7

7

7

7

7

7

7

7

7

7

7

01

01

01

01

01

01

01

01

01

01

01

01

01

01

01

01

01

01

01

00-00-0F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-00-0F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

00-40-7F

0...Sin

1...Tri

2...Saw Up

3...Saw Down

4...Pulse 1:3

5...Pulse 2:2

6...Pulse 3:1

15...Depends on original

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63

(Note1)

–64 - 0 - +63 (Note1)

0...Sin

1...Tri

2...Saw Up

3...Saw Down

4...Pulse 1:3

5...Pulse 2:2

6...Pulse 3:1

15...Depends on original

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

–64 - 0 - +63 (Note1)

39

21.3 DSP Parameters

Note 1:

This value is the DSP algorithm ID, which cannot be changed directly at the user level. Changing the DSP Type or Tone

Number causes the algorithm ID of the original DSP to be copied automatically to this area. See “24 DSP Algorithm ID

Tables”.

21.4 Scale Tune

22 Music Library Parameters

This parameter is a container for Music Library related information.

Parameter ID R/W Block Size Array Min-Def-Max Description

Name

Algorithm

Cho Normal Send

Cho Deep Send

Rev Send

Acou Reso Send

Parameter7

Parameter16

002D

002E

002F

0030

0031

0032

0034

0035

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

000000















7

14

7

7

7

7

7

16

10

01

01

01

01

01

20

10

00-20-7F

0000-0000-3FFF

00-00-7F

00-00-7F

00-28-7F

00-00-7F

00-40-7F

0000-8000-FFFF

Ascii Character

Serial Number

(Note1)

0-127

0-127

0-127

0-127

0-127

0x0000-0xFFFF

Parameter ID R/W Block Size Array Min-Def-Max Description

Note

A Key Mode

0000

0001

R/W

R/W

000000



8

1

0C

01

00-80-FF

00-00-01

–128 - 0 - 127

Array : Note

0....C

1....C#

2....D

3....D#

4....E

5....F

6....F#

7....G

8....G#

9....A

10...A#

11...B

0...Relative

1...Absolute

Parameter ID R/W Block Size Array Min-Def-Max Description

Name

Address

Size

0000

0001

0002

R

R

R

000000





7

32

32

0C

01

01

20-20-7F

00000000-00000000-00FFFFFF

00000000-00000000-00FFFFFF

Ascii Character

0-0xFFFFFFFF

0-0xFFFFFFFF

40

Part VI

DSP Parameter List

23 Tone with DSP List

This is a list of tones that use DSP.

Tone Name Display Mono/Stereo DSP Algorithm

GRAND PIANO MODERN GrPianoModrn Stereo-Stereo Wide-3Band EQ

LA PIANO LA Piano Stereo-Stereo Wide-3Band EQ

MODERN PIANO Modern Piano Stereo-Stereo Wide-3Band EQ

DANCE PIANO Dance Piano Stereo-Stereo Wide-3Band EQ

GRAND PIANO CLASSIC GrPianoClasc Stereo-Stereo Wide-3Band EQ

STRINGS PIANO StringsPiano Stereo-Stereo Enhancer

PIANO PAD Piano Pad Mix-Stereo Enhancer

60’S E.PIANO 60’s E.Piano Mono-Mono Tremolo

DYNO ELEC.PIANO Dyno E.Piano Mono-Stereo Auto Pan

POP ELEC.PIANO Pop E.Piano Mono-Mono Enhancer

VIBRAPHONE Vibraphone Mono-Mono Tremolo

CLAVI Clavi Mono-Mono Enhancer

ROCK ORGAN Rock Organ 1 Mix-Stereo Drive Rotary

JAZZ ORGAN Jazz Organ Mix-Stereo Rotary

DRAWBAR ORGAN DrawbarOrgan Mix-Stereo Rotary

ROTARY DRAWBAR RotaryDrwbar Mix-Stereo Rotary

ROTARY ORGAN Rotary Organ Mix-Stereo Rotary

PERC.ORGAN Perc.Organ Mix-Stereo Rotary

70’S ORGAN 70’s Organ Mix-Stereo Rotary

OVERDRIVE ORGAN OverdriveOrg Mono-Mono Distortion

TREMOLO ORGAN Tremolo Org Mono-Mono Tremolo

SYNTH-STRINGS SynthStrings Mono-Mono 3Band EQ

NEW AGE New Age Mono-Mono 3Band EQ

CHORUS CLEAN GUITAR Cho.CleanGt Mono-Mono Enhancer

OVERDRIVE GUITAR Overdrive Gt Mono-Mono Distortion

TRUMPET Trumpet Mono-Mono Enhancer

TROMBONE Trombone Mono-Mono Enhancer

STEREO BRASS Stereo Brass Mix-Stereo Early Reflection

41

24 DSP Algorithm ID Tables

The lists in this section show the DSP algorithms that are built into the Instrument.

24.1 Monaural Tone DSP

24.2 Stereo Tone DSP

25 DSP Parameter Set Types

This section describes the DSP parameter combination patterns of each algorithm specified in the “Parameter Set Type”

column of “24 DSP Algorithm ID Tables”.

Note:

The characteristics of a DSP are different depending on the tone, even if the same algorithm is used. Because of this, the

same algorithm may not produce the same effect for different tones.

25.1 Tremolo/Auto Pan

25.2 3Band EQ

ID Algorithm Input Output Parameter Set Type

0001 Tremolo Mono Mono Tremolo/Auto Pan

0002 3Band EQ Mono Mono 3Band EQ

000B Auto Pan Mono Stereo Tremolo/Auto Pan

0011 Wide 3Band EQ Mono Mono 3Band EQ

0013 Distortion Mono Mono Distortion

ID Algorithm Input Output Parameter Set Type

2001 3Band EQ Stereo Stereo 3Band EQ

200B Early Reflection Mix Stereo Early Reflection

200C Rotary Mix Stereo Rotary

200D Drive Rotary Mix Stereo Drive Rotary

2017 Wide 3Band EQ Stereo Stereo Wide 3Band EQ

Parameter Number Parameter Name Value Notes

Parameter7[00] Rate 00 - 7F

Parameter7[01] Depth 00 - 7F

Parameter Number Parameter Name Value Notes

Parameter7[00] Low Freq 00 - 07 Note1

Parameter7[01] Low Gain 34 - 4C Note2

Parameter7[02] Mid Freq 00 - 07 Note1

Parameter7[03] Mid Gain 34 - 4C Note2

Parameter7[04] High Freq 00 - 07 Note1

Parameter7[05] High Gain 34 - 4C Note2

42

Note 1: See “26.9 Equalizer Mid Frequency Setting Value Table”.

Note 2: See “26.12 DSP Equalizer Gain Setting Value Table”.

25.3 Wide 3Band EQ

Note 1: See “26.10 Wide Band Equalizer Mid Frequency Setting Value Table”.

Note 2: See “26.12 DSP Equalizer Gain Setting Value Table”.

25.4 Enhancer

25.5 Distortion

25.6 Early Reflection

Parameter Number Parameter Name Value Notes

Parameter7[00] Low Freq 00 - 07 Note1

Parameter7[01] Low Gain 34 - 4C Note2

Parameter7[02] Mid Freq 00 - 07 Note1

Parameter7[03] Mid Gain 34 - 4C Note2

Parameter7[04] High Freq 00 - 07 Note1

Parameter7[05] High Gain 34 - 4C Note2

Parameter Number Parameter Name Value Notes

Parameter7[00] Low Freq 00 - 7F

Parameter7[01] Low Gain 00 - 7F

Parameter7[02] Hi Freq 00 - 7F

Parameter7[03] Hi Gain 00 - 7F

Parameter Number Parameter Name Value Notes

Parameter7[00] Gain 00 - 7F

Parameter7[01] Low 00 - 7F

Parameter7[02] High 00 - 7F

Parameter7[03] Level 00 - 7F

Parameter Number Parameter Name Value Notes

Parameter7[00] Wet Level 00 - 7F

Parameter7[01] Feedback 00 - 7F

Parameter7[02] Tone 00 - 7F

43

25.7 Rotary

Note 1: See “26.2 Slow/Fast Setting Value Table”.

Note 2: See “26.3 Rotate/Brake Setting Value Table”.

25.8 Drive Rotary

Note 1: See “26.2 Slow/Fast Setting Value Table”.

Note 2: See “26.3 Rotate/Brake Setting Value Table”.

Parameter Number Parameter Name Value Notes

Parameter7[00] Speed 0 - 1 Note1

Parameter7[01] Brake 0 - 1 Note2

Parameter7[02] Fall Accel 00 - 7F

Parameter7[03] Rise Accel 00 - 7F

Parameter7[04] Slow Rate 00 - 7F

Parameter7[05] Fast Rate 00 - 7F

Parameter Number Parameter Name Value Notes

Parameter7[00] Overdrive Gain 00 - 7F

Parameter7[01] Overdrive Level 00 - 7F

Parameter7[02] Speed 0 - 1 Note1

Parameter7[03] Brake 0 - 1 Note2

Parameter7[04] Fall Accel 00 - 7F

Parameter7[05] Rise Accel 00 - 7F

Parameter7[06] Slow Rate 00 - 7F

Parameter7[07] Fast Rate 00 - 7F

44

Part VII

Setting Values and Send/

Receive Values

26 Setting Value Tables

26.1 Off/On Setting Value Table

26.2 Slow/Fast Setting Value Table

26.3 Rotate/Brake Setting Value Table

26.4 –64 - 0 - +63 Setting Value Table

26.5 Pan Setting Value Table

26.6 –100 - 0 - +99 Setting Value Table

26.7 Reverb Type Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH Off

7FH 40H - 7FH On

Transmit Value Receive Value Parameter

00H 00H - 3FH Slow

7FH 40H - 7FH Fast

Transmit Value Receive Value Parameter

00H 00H - 3FH Rotate

7FH 40H - 7FH Brake

Transmit/Receive Value Parameter

00H –64

01H –63

::

40H 0

::

7EH +62

7FH +63

Transmit/Receive Value Parameter

00H Left

::

40H Center

::

7FH Righet

Transmit/Receive Value Parameter

(MSB-LSB)

00H - 00H –100

::

40H - 00H 0

::

7FH - 7FH +99

Transmit /

Receive Value

Parameter Display

00H Room1 -

01H Room2 Room

02H Room3 -

03H Hall1 Large Hall

04H Hall2 Hall

05H Plate1 -

06H Delay -

07H Panning Delay -

08H Plate2 -

09H Plate3 -

0AH Large Room1 -

0BH Large Room2 -

0CH Stadium1 Stadium

0DH Stadium2 -

0EH Long Delay -

0FH Long Panning Delay -

45

26.8 Chorus Type Setting Value Table

26.9 Equalizer Mid Frequency Setting

Value Table

26.10 Wide Band Equalizer Mid

Frequency Setting Value Table

Transmit /

Receive Value

Parameter Display

00H Chorus1

LightChorus

01H Chorus2 -

02H Chorus3 Chorus

03H Chorus4 -

04H Feedback Chorus -

05H Flanger1 -

06H Short Delay -

07H Short Delay FB -

08H Soft Chorus -

09H Bright Chorus -

0AH Deep Chorus Deep Chorus

0BH Flanger2 Flanger

0CH Flanger3 -

0DH Flanger4 -

0EH Short Delay

Modulation -

0FH Short Delay

Modulation FB -

Parameter Value Frequency

00H 1.0KHz

01H 1.3KHz

02H 1.6KHz

03H 2.0KHz

04H 3.0KHz

05H 4.0KHz

06H 6.0KHz

07H 8.0KHz

Parameter Value Frequency

00H 100Hz

01H 130Hz

02H 160Hz

03H 200Hz

04H 300Hz

05H 400Hz

06H 600Hz

07H 800Hz

08H 1.0KHz

09H 1.3KHz

0AH 1.6KHz

0BH 2.0KHz

0CH 3.0KHz

0DH 4.0KHz

0EH 6.0KHz

0FH 8.0KHz

46

26.11 Brilliance Gain Setting Value

Table

Note:

The gain value does not exactly correspond to decibels (dB).

26.12 DSP Equalizer Gain Setting Value

Table

Note:

The gain value does not exactly correspond to decibels (dB).

Parameter Value Gain

00H –12

01H –11

02H –10

03H –9

04H –8

05H –7

06H –6

07H –5

08H –4

09H –3

0AH –2

0BH –1

0CH 0

0DH +1

0EH +2

0FH +3

10H +4

11H +5

12H +6

13H +7

14H +8

15H +9

16H +10

17H +11

18H +12

Parameter Value Gain

34H –12

35H –11

36H –10

37H –9

38H –8

39H –7

3AH –6

3BH –5

3CH –4

3DH –3

3EH –2

3FH –1

40H 0

41H +1

42H +2

43H +3

44H +4

45H +5

46H +6

47H +7

48H +8

49H +9

4AH +10

4BH +11

4CH +12

47

Part VIII

MIDI Implementation

Notation

27 Value Notation

27.1 Hexadecimal Notation

MIDI implementation sometimes requires that data be

expressed in hexadecimal format. Hexadecimal values are

indicated by the letter “H” after the value. The hexadecimal

equivalents of decimal values 10 through 15 are expressed

as the letters A through F. The table below shows the

hexadecimal equivalents for decimal values 0 through 127,

which are often used in MIDI messages.

27.2 Binary Notation

When a MIDI implementation data value is expressed in

binary, the letter “B” (for “binary”) is affixed at the end of

the value. The table below shows the binary equivalents for

the decimal values 0 through 127, which are often used for

settings.

Decimal

Hexadecimal

Decimal

Hexadecimal

Decimal

Hexadecimal

Decimal

Hexadecimal

0 00H 32 20H 64 40H 96 60H

1 01H 33 21H 65 41H 97 61H

2 02H 34 22H 66 42H 98 62H

3 03H 35 23H 67 43H 99 63H

4 04H 36 24H 68 44H 100 64H

5 05H 37 25H 69 45H 101 65H

6 06H 38 26H 70 46H 102 66H

7 07H 39 27H 71 47H 103 67H

8 08H 40 28H 72 48H 104 68H

9 09H 41 29H 73 49H 105 69H

10 0AH 42 2AH 74 4AH 106 6AH

11 0BH 43 2BH 75 4BH 107 6BH

12 0CH 44 2CH 76 4CH 108 6CH

13 0DH 45 2DH 77 4DH 109 6DH

14 0EH 46 2EH 78 4EH 110 6EH

15 0FH 47 2FH 79 4FH 111 6FH

16 10H 48 30H 80 50H 112 70H

17 11H 49 31H 81 51H 113 71H

18 12H 50 32H 82 52H 114 72H

19 13H 51 33H 83 53H 115 73H

20 14H 52 34H 84 54H 116 74H

21 15H 53 35H 85 55H 117 75H

22 16H 54 36H 86 56H 118 76H

23 17H 55 37H 87 57H 119 77H

24 18H 56 38H 88 58H 120 78H

25 19H 57 39H 89 59H 121 79H

26 1AH 58 3AH 90 5AH 122 7AH

27 1BH 59 3BH 91 5BH 123 7BH

28 1CH 60 3CH 92 5CH 124 7CH

29 1DH 61 3DH 93 5DH 125 7DH

30 1EH 62 3EH 94 5EH 126 7EH

31 1FH 63 3FH 95 5FH 127 7FH

Decimal

Hexadecimal

Binary

0 00H 00000000B

1 01H 00000001B

2 02H 00000010B

3 03H 00000011B

4 04H 00000100B

5 05H 00000101B

6 06H 00000110B

7 07H 00000111B

8 08H 00001000B

9 09H 00001001B

10 0AH 00001010B

11 0BH 00001011B

12 0CH 00001100B

13 0DH 00001101B

14 0EH 00001110B

15 0FH 00001111B

16 10H 00010000B

::

125 7DH 01111101B

126 7EH 01111110B

127 7FH 01111111B

CASIO COMPUTER CO.,LTD.

6-2, Hon-machi 1-chome

Shibuya-ku, Tokyo 151-8543, Japan

MA1004-B
