GUÍA DEL USUARIO

USER’S GUIDE

EN/ES

Guarde toda la información para futuras consultas.

Please keep all information for future reference.

Precauciones de seguridad

Antes de intentar usar el piano digital, asegúrese de

leer las “Precauciones de seguridad” separadas.

Safety Precautions

Before trying to use the Digital Piano, be sure to read

the separate “Safety Precautions”.

CDP230-ES-1B

CDP-230R

EnglishEspañol

This recycle mark indicates that the packaging conforms to

the environmental protection legislation in Germany.

Esta marca de reciclaje indica que el empaquetado se

ajusta a la legislación de protección ambiental en Alemania.

MA1402-B Printed in China

CDP230R_es_Cover1-4.fm 1 ページ２０１４年２月１９日　水曜日　午後５時１３分

Function Transmitted Recognized Remarks

Basic

Channel

1 - 16

Default

Changed

Note

Number

0 - 127

0 - 127 *1

0 - 127

True voice

Program

Change

0 - 127

:True #

After

Touch

Control

Change

Pitch Bender

System Exclusive

Key’s

Ch’s

Velocity

9nH v = 1 - 127

9nH v = 0, 8nH v =**

9nH v = 1 - 127

9nH v = 0

Note ON

Note OFF

Mode

Mode 3

Default

Messages

Altered

System

Common

: Song Pos

: Song Sel

: Tune

Aux

Messages

Remarks

: All sound OFF

: Reset all controller

: Local ON/OFF

: All notes OFF

: Active Sense

: Reset

System

Real Time

: Clock

: Commands

0, 32

6, 38

100, 101

Bank select

Modulation

Data entry

Volume

Pan

Expression

Hold 1

Sostenuto

Soft pedal

Reverb send *4

Chorus send

RPN LSB, MSB

Model: CDP-230R Version : 1.0

Mode 1 : OMNI ON, POLY

Mode 3 : OMNI OFF, POLY

Mode 2 : OMNI ON, MONO

Mode 4 : OMNI OFF, MONO

O : Yes

X : No

(MSB only)

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider

than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are

provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where

they exit from the apparatus.

11.Only use attachments/accessories specified by the manufacturer.

12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13.Unplug this apparatus during lightning storms or when unused for long periods of time.

14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been

dropped.

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be

placed on the apparatus.

The power indicator being unlit does not mean the apparatus is completely disconnected from the MAINS.

When you need to have the apparatus completely disconnected from the MAINS, you must unplug the power cord. For that

purpose, locate the apparatus in a way that secures easy access to the power cord.

Declaration of Conformity

Model Number: CDP-230R

Trade Name: CASIO COMPUTER CO., LTD.

Responsible party: CASIO AMERICA, INC.

Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801

Telephone number: 973-361-5400

This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

*1: Depends on tone.

2: For details about NRPN, RPN, and system

exclusive messages, see MIDI Implementation at

http://world.casio.com/.

3: In accordance with pedal effect setting.

4: With this product, the Hall function is treated as one

type of reverb.

*1: Depende del tono.

2: Para obtener información acerca de NRPN, RPN y

los mensajes exclusivos del sistema, consulte

Implementación MIDI en http://world.casio.com/.

3: De acuerdo con el ajuste de efecto de pedal.

*4: En este producto, la función Hall se considera como

un tipo de reverberación.

CDP230R_es_Cover1-4.fm 2 ページ２０１４年２月１９日　水曜日　午後５時１３分

English

EN-1

Important!

Please note the following important information before using this product.

• Before using the AD-A12150LW Adaptor to power the product, be sure to check the AC Adaptor for any damage first. Carefully

check the power cord for breakage, cuts, exposed wire and other serious damage. Never let children use an AC adaptor that is

seriously damaged.

• The product is not intended for children under 3 years.

• Use only CASIO AD-A12150LW adaptor.

• The AC adaptor is not a toy.

• Be sure to disconnect the AC adaptor before cleaning the product.

Manufacturer:

CASIO COMPUTER CO., LTD.

6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan

Responsible within the European Union:

CASIO EUROPE GmbH

Casio-Platz 1, 22848 Norderstedt, Germany

This mark applies in EU countries only.

Declaration of Conformity According to EU Directive

●Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal

use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.

●IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION,

DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE

USE OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

●The contents of this manual are subject to change without notice.

●The actual appearance of the product may be different from that shown in the illustrations in this User’s Guide.

●Company and product names used in this manual may be registered trademarks of others.

CDP230R_e.book 1 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-2

Contents

General Guide ...........................EN-4

Using the 10-key Pad (br)..............................EN-7

FUNCTION Button (ck) Functions .................EN-7

Returning the Digital Piano to

Its Factory Default Settings .............................EN-8

Getting Ready to Play ..............EN-9

Preparing the Music Stand ..............................EN-9

Connecting a Pedal Unit..................................EN-9

Power Supply ..................................................EN-9

Playing the Digital Piano........EN-10

Turning on Power and Playing ......................EN-10

Using Headphones........................................EN-10

Changing Keyboard Response to

Touch Pressure (Touch Response)...............EN-11

Adjusting Display Contrast ............................EN-11

Using the Metronome ....................................EN-12

Controlling the Keyboard

Sounds ....................................EN-13

Select from a variety of

musical instrument sounds............................EN-13

Layering Two Tones......................................EN-14

Splitting the Keyboard between

Two Different Tones ......................................EN-14

Using Hall ......................................................EN-15

Using Reverb.................................................EN-15

Using Chorus.................................................EN-15

Using a Pedal ................................................EN-16

Changing the Pitch

(Transpose, Tuning, Octave Shift).................EN-16

Using the Pitch Bend Wheel to

Shift the Pitch of Notes..................................EN-17

Sampling Sounds and Playing

Them on the Digital Piano .....EN-18

Connection and Preparation..........................EN-18

Sampling and Playing a Melody Sound

(Melody Sampling) ........................................EN-19

Incorporating a Sampled Sound into

a Drum Set (Drum Sampling) ........................EN-21

Other Sampling Functions.............................EN-24

Playing Built-in Songs........... EN-26

Playing the Demo Songs .............................. EN-26

Playing Back a Particular Song..................... EN-26

Increasing the Selection of Songs ................ EN-29

Using Built-in Songs to

Master Keyboard Play ........... EN-30

Phrases......................................................... EN-30

Step Up Lesson Flow.................................... EN-30

Selecting the Song, Phrase,

and Part You Want to Practice...................... EN-31

Lessons 1, 2, and 3....................................... EN-32

Lesson Settings ............................................ EN-33

Using Auto Step Up Lesson.......................... EN-35

Music Challenge

Keyboard Game ..................... EN-36

Using Auto

Accompaniment..................... EN-37

Playing the Rhythm Part only........................ EN-37

Playing All Parts............................................ EN-38

Using Auto Accompaniment Effectively ........ EN-40

Using One-Touch Preset .............................. EN-41

Using Auto Harmonize.................................. EN-42

Looking Up the Notes of Chords

(Chord Book)................................................. EN-43

Editing Auto Accompaniment

Patterns................................... EN-44

Saving Keyboard Setups to

Registration Memory ............. EN-47

To save a setup to registration memory........ EN-48

To recall a setup from

registration memory ...................................... EN-48

CDP230R_e.book 2 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Contents

EN-3

Recording Your Keyboard

Play ..........................................EN-49

Recording and Playing Back

Keyboard Play ...............................................EN-49

Using Tracks to Record and Mix Parts..........EN-50

Recording Two or More Songs,

and Selecting One for Playback ....................EN-52

Recording while Playing Along with

a Built-in Song ...............................................EN-52

Saving Recorded Data on

an External Device ........................................EN-53

Other Useful Digital Piano

Functions ................................EN-54

Changing the Scale of the Keyboard.............EN-54

Using Music Preset .......................................EN-55

Using the Arpeggiator....................................EN-56

Deleting User Song Data...............................EN-57

Deleting All Data in Digital Piano Memory.....EN-57

Using a Memory Card.............EN-58

Memory Card and Card Slot Precautions......EN-58

Inserting and Removing a Memory Card.......EN-59

Formatting a Memory Card............................EN-59

Saving Digital Piano Data to

a Memory Card..............................................EN-60

Loading Data from a Memory Card into

Digital Piano Memory ....................................EN-61

Deleting Data from a Memory Card...............EN-62

Playing Back Data from a Memory Card ....... EN-63

Memory Card Error Messages ......................EN-63

Connecting External

Devices ................................... EN-64

Connecting to a Computer ............................ EN-64

MIDI Settings ................................................ EN-65

Storing and Loading Digital Piano

Memory Data ................................................ EN-67

Connecting to Audio Equipment ................... EN-68

Reference................................ EN-69

Troubleshooting ............................................ EN-69

Specifications................................................ EN-71

Operating Precautions .................................. EN-72

Error Messages............................................. EN-73

Song List ....................................................... EN-74

Fingering Guide ............................................ EN-75

MIDI Implementation Chart

Included Accessories

●Music Stand

●Pedal

●Song Book

●Leaflets

• Safety Precautions

• Appendix

• Other (Warranty, etc.)

Items included as accessories are subject to change without notice.

Separately Available Accessories

• You can get information about accessories that

are separately for this product from the CASIO

catalog available from your retailer, and from the

CASIO website at the following URL.

http://world.casio.com/

CDP230R_e.book 3 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-4

General Guide

• In this manual, the term “Digital Piano” refers to the CDP-230R.

• In this manual, buttons and other controllers are identified using the numbers shown below.

bobn bp bq bs bt ckbr

345678 bkblbm92

crcm

dk dl dk

dn dodm

cn cocl cp cs ctcq

CDP230R_e.book 4 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

General Guide

EN-5

• The following explains the meaning of the $ symbol that appears on the product console and with the key names below.

$: Indicates a function that is enabled by holding down the button for some time. For example, METRONOME, BEAT $ means that the BEAT

function is enabled by holding down the button for some time.

1VOLUME knob ☞EN-10

2P (POWER) button ☞EN-10

3INTRO, REPEAT button ☞EN-27, 40

4NORMAL/FILL-IN, REW button ☞EN-27, 40

5VARIATION/FILL-IN, FF button ☞EN-27, 40

6SYNCHRO/ENDING, PAUSE button ☞EN-27, 41

7START/STOP, PLAY/STOP button ☞EN-26, 37

8ACCOMP, CHORDS $, PART SELECT button

☞EN-29, 38

9TEMPO buttons ☞EN-12, 28, 41

bk RECORDER, SAMPLING $ button

☞EN-19, 49

bl RHYTHM EDITOR button ☞EN-44

bm METRONOME, BEAT $ button ☞EN-12

bn SONG BANK, $ button ☞EN-26

bo RHYTHM, ONE TOUCH PRESET $ button

☞EN-37, 41

bp TONE, MUSIC PRESET $ button ☞EN-13, 55

bq CARD, LOAD/SAVE $ button ☞EN-59

br Number buttons, [–]/[+] keys ☞EN-7

bs HALL button ☞EN-15

bt PIANO/ORGAN, CHORD BOOK $ button

☞EN-13, 43

ck FUNCTION button ☞EN-7

cl BANK, LISTEN button ☞EN-32, 47

cm Area1, WATCH button ☞EN-32, 47

cn Area2, REMEMBER button ☞EN-33, 47

co Area3, NEXT button ☞EN-31, 47

cp Area4, AUTO button ☞EN-35, 47

cq STORE, MUSIC CHALLENGE button ☞EN-36, 48

cr SPLIT button ☞EN-14

cs LAYER, $ button ☞EN-14

ct AUTO HARMONIZE/ARPEGGIATOR,

TYPE $ button ☞EN-42, 56

dk Speakers

dl Display

dm PITCH BEND wheel ☞EN-17

dn CHORD root names ☞EN-38

do Percussion instrument list ☞EN-13

CDP230R_e.book 5 ページ２０１４年２月１９日　水曜日　午後５時１１分

General Guide

EN-6

drdqdp ek el emdtds

dp SD CARD SLOT ☞EN-59

dq USB port ☞EN-64

dr SUSTAIN/ASSIGNABLE JACK ☞EN-9

ds AUDIO IN jack ☞EN-68

dt DC 12V terminal ☞EN-9

ek PHONES/OUTPUT jack ☞EN-10, 68

el MIC IN/SAMPLING jack ☞EN-18

em MIC VOLUME knob ☞EN-18

■Back

CDP230R_e.book 6 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

General Guide

EN-7

Use the number buttons and the [–] and [+] keys to change

the settings of the parameters that appear in the upper left

area of the display.

Use the number buttons to enter numbers and values.

• Enter the same number of digits as the currently displayed

value.

• Negative values cannot be input using the number buttons.

Use [–] (decrease) and [+] (increase) instead.

You can use the [–] (decrease) and [+] (increase) keys to

change the displayed number or value.

• Holding down either key scrolls the displayed setting.

• Pressing both keys at the same time will revert to the initial

default setting or the recommended setting.

You can use the FUNCTION button (ck) to adjust the reverb

effect, to delete data, and to perform a wide range of other

Digital Piano operations.

Press ck (FUNCTION) to display the function

menu.

Use the br (10-key) [4] (U) and [6] (I) keys to

display the function you want.

• You can exit the function menu by pressing ck

(FUNCTION).

• After selecting functions 8 through 13, press the br

(10-key) [9] (ENTER) key to display the menu item’s

submenu. Then use [4] (U) and [6] (I) to select an

item. You can exit a submenu by pressing the br

(10-key) [7] (EXIT) key.

Refer to the indicated pages for details about

each function.

• The tone and other parameters revert to their initial

defaults whenever you turn on power (page EN-10).

Using the 10-key Pad (br)

Number Buttons

Example: To enter tone number 001, input 0 3 0 3 1.

[–] and [+] Keys

FUNCTION Button (ck) Functions

To select a function

St .GrPno

Setting

Function Display See

Page

1 Transpose Trans. EN-16

2 Accompaniment Volume AcompVol EN-41

3 Song Volume Song Vol EN-28

4 Touch Response Touch EN-11

5 Tuning Tune EN-16

6 Reverb Reverb EN-15

7 Chorus Chorus EN-15

8 Sampling SAMPLING

Automatic Sampling Start AutoStrt EN-24

Automatic Sampling Stop AutoStop EN-24

Sampled Tone Protect (Protect) EN-25

9 Step Up Lesson LESSON

Voice Fingering Guide Speak EN-33

Note Guide NoteGuid EN-34

Performance Evaluation Scoring EN-34

Phrase Length PhraseLn EN-34

10 Preset Scales SCALE EN-54

11 Other Settings OTHER

Arpeggiator Hold ArpegHld EN-56

Pedal Effect Jack EN-16

Pitch Bend Range Bend Rng EN-17

Accompaniment Scale AcompScl EN-55

LCD Contrast Contrast EN-11

12 MIDI Settings MIDI

Keyboard Channel Keybd Ch EN-65

Navigate Channels Navi. Ch EN-65

Local Control Local EN-66

Accomp Out AcompOut EN-66

13 Delete DELETE

Sampled Sound Delete (tone name) EN-25

User Rhythm Delete (rhythm name) EN-46

User Song Delete (song name) EN-57

All Data Delete All Data EN-57

CDP230R_e.book 7 ページ２０１４年２月１９日　水曜日　午後５時１１分

General Guide

EN-8

Perform the following procedure when you want to return the

Digital Piano’s stored data and settings to their initial factory

defaults.

Turn off the Digital Piano.

While holding down bn (SONG BANK) and the

[1] 10-key (br) key at the same time, press 2.

• Keep bn (SONG BANK) and the [1] 10-key (br) key

depressed until the next step is complete.

When the message “Pls wait” appears on the

screen, release bn (SONG BANK) and the [1]

10-key (br) key.

• You will be able to use the Digital Piano in a short while

after its system is initialized.

• See “Turning on Power and Playing” (page EN-10) for

information about turning Digital Piano on and off.

Returning the Digital Piano to Its

Factory Default Settings

CDP230R_e.book 8 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

EN-9

Getting Ready to Play

Your Digital Piano runs on standard household power. Be

sure to turn off power whenever you are not using the Digital

Piano.

Use only the AC adaptor (JEITA Standard, with unified

polarity plug) that comes with this Digital Piano. Use of a

different type of AC adaptor can cause malfunction of the

Digital Piano.

Specified AC Adaptor: AD-A12150LW

• Use the supplied power cord to connect the AC adaptor as

shown in the illustration below.

Note the following important precautions to avoid

damage to the power cord.

During Use

• Never pull on the cord with excessive force.

• Never repeatedly pull on the cord.

• Never twist the cord at the base of the plug or connector.

During Movement

• Before moving the Digital Piano, be sure to unplug the AC

adaptor from the power outlet.

During Storage

• Loop and bundle the power cord, but never wind it around

the AC adaptor.

• Never connect the AC adaptor (JEITA Standard, with

unified polarity plug) that comes with this Digital Piano

to any other device besides this Digital Piano. Doing so

creates the risk of malfunction.

• Make sure the Digital Piano is turned off before

plugging in or unplugging the AC adaptor.

• The AC adaptor will become warm to the touch after

very long use. This is normal and does not indicate

malfunction.

Preparing the Music Stand

Connecting a Pedal Unit

Power Supply

Using the AC Adaptor

Music stand

SUSTAIN/ASSIGNABLE JACK

Household power outlet

AC Adaptor

• Configuration and type depends

on your geographic location.

DC 12V terminal Power cord

CDP230R_e.book 9 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-10

Playing the Digital Piano

Press 2 (P).

This turns on power.

• To turn off the Digital Piano, press 2 again.

Try playing something on the keyboard. Use 1

to adjust volume.

• If you press 2 only lightly, the display will light up

momentarily but power will not turn on. This does not

indicate malfunction. Press 2 firmly and completely

to turn on power.

• Turning off the Digital Piano causes most current

settings to be cleared. The Digital Piano will revert to

initial settings the next time you turn it on.

This is true for all settings except for sample sound

protection. Once you turn it on it remains on until you

turn it off again.

• The message “Pls wait” will remain on the display

while a data save operation is in progress. Do not

perform any other operation while it is displayed.

Turning off the Digital Piano or removing the memory

card can cause Digital Piano data to be deleted or

become corrupted.

• Pressing 2 to turn off power actually puts the Digital

Piano into a standby state. Minute amounts of current

continue to flow within the Digital Piano in the standby

state. If you do not plan to use the Digital Piano for a

long time or if there is a lightning storm in your area, be

sure to unplug the AC adaptor from the power outlet.

If you do not perform any operation for 30 minutes, the Digital

Piano will turn off automatically.

■Disabling Auto Power Off

You can disable Auto Power Off to ensure that power is not

turned off automatically during a concert, etc.

While holding down bp (TONE), turn on power.

Auto Power Off will be disabled.

Using headphones cuts off output from the built-in speakers,

which means you can practice playing even late at night

without disturbing others.

• Be sure to turn down the volume level before connecting

headphones.

• Headphones do not come with the Digital Piano.

• Use commercially available headphones. See page EN-3

for information about options.

• Do not listen to very high volume output over

headphones for long period. Doing so creates the risk

of hearing damage.

• If you are using headphones that require an adaptor

plug, make sure you do not leave the adaptor plugged

in when removing the headphones.

ckck

bmbm

brbrbpbp

Turning on Power and Playing Auto Power Off

Using Headphones

PHONES/OUTPUT jack

CDP230R_e.book 10 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Playing the Digital Piano

EN-11

Touch Response alters tone volume in accordance with

keyboard pressure (speed). This provides you some of the

same expressivity you get on an acoustic piano.

Use the procedure below to control how much the volume of

played notes change in accordance with playing speed.

Select the setting that best matches your playing style.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“Touch” (page EN-7).

Use br (10-key) [–] and [+] keys to select one of

the four Touch Response sensitivity settings.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“OTHER” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “Contrast”.

Use the br (10-key) [–] and [+] keys to adjust

the contrast.

• The contrast setting range is 01 to 17.

Changing Keyboard Response to

Touch Pressure

(Touch Response)

Pressing fast produces

louder notes.

Pressing slowly produces

softer notes.

Do not try to use too much

pressure.

Changing Touch Response Sensitivity

Off (oFF) Touch Response is turned off. Sound

volume is fixed, regardless of key press

speed.

Type 1 (1) Normal Touch Response

Type 2 (2) More sensitive Touch Response than Type 1

Type 3 (3) Less sensitive Touch Response than Type 1

Adjusting Display Contrast

Touch

OTHER

Flashes

Con t r as t

CDP230R_e.book 11 ページ２０１４年２月１９日　水曜日　午後５時１１分

Playing the Digital Piano

EN-12

The metronome lets you play and practice along with a steady

beat to help keep you on tempo.

Press bm.

This starts the metronome.

Press bm again to stop the metronome.

You can configure the metronome to use a bell sound for the

first beat of each measure of the song you are playing.

• You can specify 0, or a value from 1 to 9 as the number of

beat per measure.

• When playing a built-in song, the beats per measure setting

(which determines when the bell sounds) is configured

automatically for the currently selected song.

Hold down bm until the beats per measure

setting screen appears on the display.

• If you do not perform any operation for a few seconds

after the beats per measure setting screen appears, the

display will return to the screen displayed before you

pressed bm.

Use br (10-key) to enter the number of beats

per measure.

• The bell will not sound if you specify 0 for this setting. In

this case, all beats are indicated by a click sound. This

setting lets you practice with a steady beat, without

worrying how many beats there are in each measure.

Use the following procedure to change the tempo of the

metronome.

Press 9.

Use w (slower) and q (faster) to change the tempo

setting. Holding down either button changes the setting at

high speed.

• Pressing q and w at the same time will initialize the

tempo setting in accordance with the currently selected

song or rhythm.

• Pressing 9 causes the tempo value to flash on the

display. While the tempo value is flashing, you can use

br (10-key) to change it.

Note that you must input leading zeros, so 89 is input

as 089.

• The tempo value will stop flashing if you do not perform

any operation for a short while.

The metronome volume setting is changed automatically with

the volume level of the currently selected Auto

Accompaniment or song. The metronome volume cannot be

adjusted independently.

• For information about changing the Auto Accompaniment

volume, see page EN-41.

• For information about changing the song volume, see page

EN-28.

• You cannot adjust the balance between the metronome

and note volume during Auto Accompaniment and built-in

tune play.

Using the Metronome

Start/Stop

Changing the Beats per Measure

This pattern changes with each beat.

Bea t

Changing the Metronome Tempo

Changing the Metronome Sound Volume

Tempo value (flashes)

CDP230R_e.book 12 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

EN-13

Controlling the Keyboard Sounds

Your Digital Piano lets you select tones for a wide variety of

musical instrument sounds, including violin, flute, orchestra,

and more. Even the same song sound takes on a different feel

by changing the instrument type.

Press bp (TONE).

Use br (10-key) to select the tone number you

want.

The corresponding tone number and tone name will

appear on the screen.

• Use the number buttons to enter the tone number.

Specify three digits for the tone number.

• See the separate “Appendix” for a complete list of available

tones.

• When one of the drum sets is selected (tone numbers 684

through 700), each keyboard key is assigned a different

percussion sound.

Try playing something on the keyboard.

The tone of the instrument you selected will sound.

Pressing bt toggles between the piano and organ modes.

Each press of bt toggles the tone setting between a piano

tone (Tone Number 001) and an organ tone (Tone Number

089).

In addition to the tone number, you also can configure the

settings listed below.

ckckbrbr

crcr cscs

bsbsbpbp btbt

Select from a variety of musical

instrument sounds

To select an instrument for playing

Example: To select 001, enter 0 3 0 3 1.

St .GrPno

Tone nameTone number Playing with a Piano or Organ Tone

Hall : Off

Reverb : “06”

Transpose : “00”

Touch Response : Off:Returns to initial default

On: No change

Pedal Effect : SUS

Rhythm Number : “181” (When a piano tone is selected)

“108” (When an organ tone is selected)

Accompaniment : Rhythm part only

Local Control : On

Drum Assign : Off

Split : Off

Layer : Off

Chorus : Off

Octave Shift (Upper): “0”

Auto Harmonize : Off

Arppegiator : Off

Scale : Equal

CDP230R_e.book 13 ページ２０１４年２月１９日　水曜日　午後５時１１分

Controlling the Keyboard Sounds

EN-14

You can use the following procedure to layer two different

tones (such as piano and strings) so they sound

simultaneously when you press a keyboard key.

Select the first tone you want to use.

Press bp (TONE) and then use br (10-key) to select the

tone you want.

Press cs.

Use br (10-key) to select the second tone you

want.

Play something on the keyboard.

Both tones sound at the same time.

Pressing cs again to unlayer the keyboard (so

it plays only the tone you selected in step 1).

• Each press of cs toggles between layered (two tones)

and unlayered (one tone).

You can use the procedure below to assign different tones to

the right range and left range of the keyboard, so it sounds

like you are playing an ensemble between two instruments.

Select the tone for the right side range (page

EN-13).

Press bp (TONE) and then use br (10-key) to select the

tone you want.

Press cr.

Use br (10-key) to select the left side range

tone you want.

Play something on the keyboard.

This will sound the tones assigned to the left and right

side ranges of the keyboard.

Layering Two Tones

Example: 038 ELEC.PIANO 1

Example: 238 STRINGS 1

E.Pi ano1

Lights

St r in

s 1

Splitting the Keyboard between

Two Different Tones

To select the two tones for a split keyboard

Example: 365 FLUTE 1

Example: 074 VIBRAPHONE 1

Flute 1

Lights

Vibes 1

VIBRAPHONE 1 FLUTE 1

Split point

CDP230R_e.book 14 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Controlling the Keyboard Sounds

EN-15

Pressing cr again to unsplit the keyboard (so it

plays only the tone you selected in step 1).

• Each press of cr toggles between split (two tones) and

unsplit (one tone).

• If you turn on both layer and split, layering will be applied to

the right side range of the keyboard only.

While holding down cr, press the keyboard key

where you want the split point to be.

The key you press will become the lowest note of the right

side range of the split keyboard.

The Hall function lets you instantly configure the Digital Piano

to play with the acoustic effect of a classic concert hall.

Press bs (HALL) to turn on the Hall function.

To turn off the Hall function, press bs again.

• The reverb setting turns off automatically whenever the

Hall function is turned on. When you turn off the Hall

function, the reverb setting will return to whatever it was

before you turned on the Hall function.

Reverb adds reverberation to notes. You can change the

duration of the reverb.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“Reverb” (page EN-7).

Use the br (10-key) [–] and [+] keys to select

the reverb setting you want.

• Changing the reverb setting (including turning it off) while

the Hall function is turned on will turn off the Hall function.

Chorus is a function that adds depth and breadth to notes. It

makes you sound as if you are playing multiple instruments.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“Chorus” (page EN-7).

Use the br (10-key) [–] and [+] keys to select

the chorus type you want.

There are five chorus types, plus an off setting.

• The actual effect produced by chorus depends on the tone

you are using.

To change the split point

Example: Setting middle C (C4) as the split point.

Using Hall

Key name

Lights

The indicator will disappear when the Hall function is turned off.

Using Reverb

Off (oFF) Turns off reverb.

1 to 10 The larger the number selected, the longer

the reverb duration.

Using Chorus

Reve r b

Indicator disappears when reverb is turned off.

Cho r us

Indicator disappears when chorus is turned off.

CDP230R_e.book 15 ページ２０１４年２月１９日　水曜日　午後５時１１分

Controlling the Keyboard Sounds

EN-16

A pedal can be used to change notes in various ways while

playing.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“OTHER” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “Jack”.

Use the br (10-key) [–] and [+] keys to select

the pedal effect you want.

• The following shows the available pedal effects.

The transpose feature lets you change the pitch, in semitone

steps. A simple operation lets you instantly change the pitch

to match that of a singer.

• The transpose setting range is –12 to +12 semitones.

Press ck (FUNCTION).

Use the br (10-key) [–] and [+] keys to select

the transpose setting you want.

Use the tuning feature when you need to adjust the pitch

slightly to play along with another musical instrument. Also,

some artists perform their music with slightly altered tuning.

You can use the tuning feature to adjust tuning so it exactly

matches a performance on a CD.

• The tuning feature specifies the frequency of the A4 note.

You can set a frequency within the range of 415.5 to

465.9 Hz. The initial default setting is 440.0 Hz.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“Tune” (page EN-7).

Use the br (10-key) [–] and [+] keys to adjust

the tuning.

• Performing this step causes the display to change from

“Tune” to a value that indicates the current frequency

setting as shown below. You can change the frequency

in 0.1 Hz steps.

• Even if you do not perform a br (10-key) operation to

adjust the tuning, the current frequency setting will

appear automatically after a few seconds.

Using a Pedal

Selecting the Pedal Effect

Sustain

(SUS)

Sustains notes played while the pedal is

depressed. Organ and other similar tone

notes are sustained even if the pedal is not

pressed.

Sostenuto

(SoS)

Sustains notes that are playing when the

pedal is depressed before the keyboard

keys are released.

Soft

(SFt)

Slightly softens notes played while the pedal

is depressed.

Rhythm

(rHy)

Pressing the pedal starts and stops Auto

Accompaniment or song playback.

OTHER

Flashes

Jack

Changing the Pitch

(Transpose, Tuning, Octave Shift)

Changing the Pitch in Semitone Steps

(Transpose)

Fine Tuning (Tuning)

Trans.

Tune

440.0Hz

CDP230R_e.book 16 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Controlling the Keyboard Sounds

EN-17

Octave Shift lets you raise or lower the pitch of the keyboard

notes in octave units.

• The octave shift setting range is –2 to +2 octaves.

• When using Split (page EN-14), you can individually set the

left and right keyboard ranges to the pitches you want.

Keep pressing cs until the screen shown below

appears on the display.

If you want to use Split, turn on Split before pressing cs.

• If you do not perform any operation for a few seconds

after this screen appears, the display will return to the

previous screen automatically.

Use the br (10-key) [–] and [+] keys to shift the

octave.

Press cs.

Press cs again.

You can use the pitch bend wheel to slide the pitch of notes

smoothly upwards and downwards. This technique makes it

possible to produce effects that are similar to sounds

produced when bending notes on a saxophone or electric

guitar.

While playing a note on the

keyboard, rotate the pitch bend

wheel on the left of the keyboard

upwards or downwards.

The amount the note bends depends on how

much you rotate the pitch bend wheel.

• Do not have the pitch bend wheel rotated

as you turn on the Digital Piano.

Use the following procedure to specify how much the pitch of

the note changes whenever the pitch bend wheel is rotated

upwards or downwards. You can specify a range from 0 to 12

semitones (one octave).

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“OTHER” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “Bend Rng”.

Use the br (10-key) [–] and [+] keys to change

the range.

Octave Shift

• Split On : This step affects the right side keyboard

range only.

• Split Off : This step affects the entire keyboard range.

• Split On : The screen shown below will appear. Use the

br (10-key) [–] and [+] keys to shift the

octave for the left side keyboard range.

• Split Off : The screen shown below will appear.

Advance to step 4.

Oc tU

Oc t Lowe r

Using the Pitch Bend Wheel to

Shift the Pitch of Notes

To play with the pitch bend wheel

Specifying the Pitch Bend Range

OTHER

Flashes

Bend Rn

CDP230R_e.book 17 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-18

Sampling Sounds and Playing Them on the Digital

Piano

You can use the Digital Piano to sample a sound from a

microphone, and then play the sound with keyboard keys. For

example, you could sample the bark of your dog and then use

the sound in a melody. The sampling feature is a great way to

create new sounds that are highly creative.

• Turn off the microphone and the Digital Piano before

connecting them.

Connect a microphone.

• Use a commercially available dynamic microphone.

• You cannot sample sounds input from through the AUDIO

IN jack.

Turn the volume levels of the Digital Piano

down.

Turn on the microphone and then the Digital

Piano.

Use em (MIC VOLUME) to adjust the volume

level of microphone input.

• It will take a few seconds after you turn on the Digital Piano

before you will be able to use the microphone.

• Sampled sounds are recorded in monaural.

clcl cmcm cncn coco cpcp cqcq

brbrbobo bpbp btbt ckck

bkbk

Connection and Preparation

MIC IN/SAMPLING jack

CDP230R_e.book 18 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Sampling Sounds and Playing Them on the Digital Piano

EN-19

Use the procedures in this section to sample a sound and play

it as the melody part on the Digital Piano.

• Up to five sampled sounds can be stored in Digital Piano

memory as tone numbers 701 through 705. Simply select

the tone number where the sound you want is located to

assign the sound to the keyboard.

Press bp (TONE) and then use br (10-key) to

enter the tone number (701 to 705) where you

want to store the sampled sound.

Hold down bk until the display changes to the

screen shown below.

This enters sampling standby.

The allowable sampling time (in seconds) will appear on

the display momentarily and then the display will change

to the following.

Output the sound in the direction of the

microphone.

Sampling will start automatically.

• Sampling will not start if the volume of the sound picked

up by the microphone is too low.

After the sound you want to sample is finished,

press bk.

Sampling will stop.

• Even if you do not press bk, sampling will stop

automatically whenever there is no more sound being

input from the microphone. Sampling also will stop

automatically 10 seconds after it is started.

Play something on the Digital Piano.

• You may not be able to get 10 seconds of sampling if

Digital Piano memory is low due to storage of other data. If

this happens, deleting other memory data you no longer

need will free up memory space and you should be able to

sample for 10 seconds. See “Deleting a Sampled Sound”

on page EN-25 for more information.

• Sampling sound and storing it will delete any sound

data currently stored under the same tone number. To

help ensure that you do not accidentally delete

important data, be sure to read “Protecting Against

Accidental Deletion of Sampled Sounds” on page

EN-25.

Sampling and Playing a Melody

Sound (Melody Sampling)

To sample a sound

No Da t a

No sampled sound stored

Lights

ait in

Flashes

Sam

lin

S1 :Or

Sampled sound 1

Used memory

(Unit: Kbytes)

Remaining

memory capacity

CDP230R_e.book 19 ページ２０１４年２月１９日　水曜日　午後５時１１分

Sampling Sounds and Playing Them on the Digital Piano

EN-20

■How sampled sounds are played

Pressing Middle C (C4) will play back the original sound. The

keys to the left and right of C4 play the sound at different

pitches.

You can use the following procedure to loop a sampled sound

so it continues to repeat, as you play on the Digital Piano.

Press bo (RHYTHM).

Press bt and ck (FUNCTION) at the same time.

This enters repeat standby.

Press the button (cm to cq) that corresponds to

the melody sampling tone number you want to

select.

This will start looped playback of the selected sound.

Press the same button again to stop playback.

Press cl to return to the screen that was

displayed before step 2 of this procedure.

You can use the following procedure to change the volume

level of the looped playback of each sampled sound, if you

want.

Press the button of the sampled sound whose

volume you want to change (cm to cq).

• This will cause the sounds loop to sound.

While the loop is sounding hold down the same

sampled sound button (cm to cq) as you press

any keyboard key.

• Pressing the keyboard key quickly will increase sample

sound volume, while pressing slowly will decrease

volume.

After the sampled sound is at the volume level

you want, release its button (cm to cq).

Looping a Sampled Sound

To select this tone number: Press this button:

701 cm

702 cn

703 co

704 cp

705 cq

nthPo

Lights

Changing the Volume of Sampled Sound

Looped Playback

CDP230R_e.book 20 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Sampling Sounds and Playing Them on the Digital Piano

EN-21

You can apply various effects to sampled sounds.

Press bp (TONE) and then use br (10-key) to

enter the tone number (701 to 705) to which you

want to apply effects.

Press bp (TONE) to cycle through the available

effects, described below.

• Avoid assigning the same sampled sound (tone number

701 to 705) to the keyboard for play along and for looped

play. Doing so will cause, the Loop 1 effect to be applied to

the keyboard tone while looped play of the sampled sound

is being performed.

You can use the procedure to change the drum sounds that

are assigned to each keyboard key.

• You can store up to three drum sets and store them as tone

numbers 706, 707, and 708. Simply select the tone number

where the drum set you want is located to assign the drum

set sounds to the keyboard.

Press bo (RHYTHM).

Press bp (TONE) and then use br (10-key) to

enter the tone number (706, 707, or 708) for the

drum set whose sounds you want to change.

Hold down bk until the display changes to the

screen shown below.

Applying Effects to a Sampled Sound

Effect Type

(Display) Description

Original (Orgnl) Normal sampled tone (no looping, no

effect).

Loop 1 (Loop1) Loops the sampled sound.

Loop 2 (Loop2)

Loops the sample sound and raises the

pitch of the resonating sound when the

keyboard key is released.

Loop 3 (Loop3)

Loops the sample sound and lowers the

pitch of the resonating sound when the

keyboard key is released.

Pitch 1 (Ptch1) Changes the pitch from low to high, at an

increasing rate.

Pitch 2 (Ptch2) Changes the pitch from high to low, at a

decreasing rate.

Pitch 3 (Ptch3)

Changes the pitch from high to low, at a

decreasing rate, and then raises the pitch

when the key is released.

Tremolo (Treml) Alternates volume between high and low.

Funny 1 (Funy1) Adds vibrato and changes the pitch by a

gradually increasing amount.

Funny 2 (Funy2) Alternates between high pitch and low

pitch.

Funny 3 (Funy3) Adds vibrato and changes the pitch from

low to high.

Incorporating a Sampled Sound

into a Drum Set (Drum Sampling)

No Da t a

Lights

No Da t a

Flashes

CDP230R_e.book 21 ページ２０１４年２月１９日　水曜日　午後５時１１分

Sampling Sounds and Playing Them on the Digital Piano

EN-22

Press the keyboard key* to which you want to

assign the drum sound you are about to

sample.

This enters sampling standby.

The allowable sampling time (in seconds) will appear on

the display momentarily and then the display will change

to the following.

Output the sound in the direction of the

microphone.

Sampling will start automatically.

• Sampling will not start if the volume of the sound picked

up by the microphone is too low.

After the sound you want to sample is finished,

press bk.

Sampling will stop.

• Even if you do not press bk, sampling will stop

automatically whenever there is no more sound being

input from the microphone. Sampling also will stop

automatically 10 seconds after it is started.

Press the keyboard key.

• You can repeat steps 3 through 6 to change other sounds

that make up the currently selected drum set. There are

eight sounds per drum set.

• You may not be able to get 10 seconds of sampling if

Digital Piano memory is low due to storage of other data. If

this happens, deleting other memory data you no longer

need will free up memory space and you should be able to

sample for 10 seconds. See “Deleting a Sampled Sound”

on page EN-25 for more information.

• Sampling a sound will delete any sound data currently

assigned to the same keyboard key. To help ensure

that you do not accidentally delete important data, be

sure to read “Protecting Against Accidental Deletion of

Sampled Sounds” on page EN-25.

ait in

Flashes

C2 C7

*Drum sounds cannot be assigned to these keys.

Sam

lin

lDrm1

Used memory

(Unit: Kbytes)

Remaining memory

capacity

CDP230R_e.book 22 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Sampling Sounds and Playing Them on the Digital Piano

EN-23

You can use the procedures in this section to copy the drum

sound assigned to one keyboard key to another key, to

change the pitch of a sound, and to delete a sampled sound.

Press bp (TONE) and then use br (10-key) to

enter the tone number (706, 707, or 708) for the

drum set you want.

Hold down bk until the SAMPLING indicator

starts to flash.

Press ck (FUNCTION).

This is the editing mode.

• While in the editing mode, you can copy a sound,

change the pitch of a sound, or delete a sound (each of

which is described below). Pressing ck (FUNCTION)

again exits the editing mode and returns to step 2 of

this procedure.

■To copy a sampled sound from one key to

another

While holding down the keyboard key to which the sampled

sound you want to copy is assigned, press the keyboard key

to which you want to copy it.

• A keyboard key that already has a sampled sound assigned

cannot be selected as a copy destination.

■To change the pitch of a sampled sound

While holding down the keyboard key of the sampled sound

whose pitch you want to change, use the br (10-key) [–] and

[+] keys to change the pitch.

• You can change the pitch within a range of –64 to 63

semitones.

■To delete a keyboard key’s sampled sound

While holding down the keyboard key whose sound you want

to delete, press bo (RHYTHM). In response to the “DelSure?”

message that appears, press the br (10-key) [+] (YES) key to

delete, or [–] (NO) to cancel the delete operation.

• Deleting a sampled sound will return the key to its initial

default built-in sound.

Use the following procedure to change the rhythm part of an

Auto Accompaniment pattern to a drum set sound that you

sampled.

Press bo (RHYTHM) and then use br (10-key)

to enter the rhythm number of the Auto

Accompaniment pattern you want.

You cannot use a Drum Sampling Tone in a user rhythm,

so do not select a user rhythm in the above step.

Press bp (TONE) and then use br (10-key) to

enter the tone number of the sampling drum set

that contains the sound you want to use.

Press bp (TONE).

This changes the rhythm part of the Auto Accompaniment

pattern you selected in step 1 to the sampled sound you

selected in step 2.

• To change the Auto Accompaniment rhythm part back

to its original sound, press bp (TONE) again.

• Some rhythm part drum sounds cannot be replaced by

sampled sounds.

Editing Sampled Drum Set Sounds

Example: To copy sampled sound of key C3 to key D3

Flashes

lDrm1

Flashes at high

speed

Indicates keyboard keys that have sounds assigned.

Indicates the keyboard key whose sound was copied.

Example: To delete the sound assigned to key D3

Using a Drum Sampling Tone in Auto

Accompaniment (Drum Assign)

Disappears

CDP230R_e.book 23 ページ２０１４年２月１９日　水曜日　午後５時１１分

Sampling Sounds and Playing Them on the Digital Piano

EN-24

Normally when the Digital Piano is in sampling standby, it will

start sampling automatically whenever it detects sound input.

You can use the following procedure to enable manual

sampling start, which will cause sampling to wait until you

press a button to start it. You can use this to insert silence

before the sampled sound.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“SAMPLING” (page EN-7).

Press the br (10-key) [9] (ENTER) key.

Press the br (10-key) [–] key to turn off

automatic sampling start.

This enables manual sampling start, which operates as

described below.

• Melody sampling (page EN-19):

Sampling starts when you hold down bk in step 2 of

the sampling procedure to enter sampling standby, and

then press bk again.

• Drum sampling (page EN-21):

Sampling starts when you press a keyboard key in step

4 of the sampling procedure to enter sampling standby,

and then press bk.

Normally the Digital Piano will stop sampling automatically

whenever it detects there is no sound input. You can use the

following procedure to enable manual sampling stop, which

will cause sampling to continue until you press a button to

stop it. You can use this to insert silence after the sampled

sound.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“SAMPLING” (page EN-7).

Press the br (10-key) [9] (ENTER) key.

Press the br (10-key) [6] (I) key.

Press the br (10-key) [–] key to turn off

automatic sampling stop.

Sampling continues until you perform one of the

operations below, even if nothing is being input from the

microphone.

•Melody sampling (page EN-19)

Press bk.

•Drum sampling (page EN-21)

Press bk.

Other Sampling Functions

Changing to a Manual Sampling Start

SAMPL I NG

Flashes

Au t oSt r t

Changing to Manual Sampling Stop

Au t oSt o

CDP230R_e.book 24 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Sampling Sounds and Playing Them on the Digital Piano

EN-25

You can use the following procedure to specify a sampled

tone number and delete its data.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“DELETE” (page EN-7).

Press the br (10-key) [9] (ENTER) key.

Use the br (10-key) [–] and [+] keys to select

the tone number of the data you want to delete.

Press the br (10-key) [9] (ENTER) key.

This displays a delete confirmation message.

Press the br (10-key) [+] (YES) key to delete the

data, or [–] (NO) or [7] (EXIT) to cancel the

delete operation.

• After the delete procedure is complete, “Complete” will

appear on the display followed by the screen in step 1

of the above procedure.

• For information about deleting individual drum sounds

in a drum sampling set, see “Editing Sampled Drum Set

Sounds” on page EN-23.

You can use the following procedure to protect each sampled

sound against accidental deletion.

Press bp (TONE) and then use br (10-key) to

enter the tone number of the sampled tone you

want to protect.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“SAMPLING” (page EN-7).

Press the br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “Protect”.

Press the br (10-key) [+] key to turn on

protection.

Once protected a tone cannot be deleted.

A protected tone is indicated as shown below.

■Saving Sample Data on an External Device

• Memory card (page EN-60)

• Computer (page EN-67)

Deleting a Sampled Sound

DELETE

Flashes

S1 :Or

Used memory

(Unit: Kbytes)

Remaining

memory capacity

Sure?

Protecting Against Accidental Deletion of

Sampled Sounds

Protect

1:Or

Protected

CDP230R_e.book 25 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-26

Playing Built-in Songs

With this Digital Piano, built-in tune data is referred to as

“songs”. You can listen to the built-in songs for your own

enjoyment, or you can play along with them for practice.

• In addition to simple listening enjoyment, the built-in songs

can be used with the lesson system (page EN-30) for

practice.

• You can increase the number of tunes using your memory

cards (page EN-61) or computer (page EN-67).

Use the following procedure to play back built-in songs.

Press 7 and 8 at the same time.

This will start playback of the demo songs.

• See page EN-74 for information about song numbers

and the song sequence.

• Demo playback always starts from song number 151.

To change to another song while demo

playback is in progress, use br (10-key) [–] and

[+] keys to enter the song number you want

(page EN-7).

This will cause demo playback to jump to the song whose

number you entered.

• You cannot use br (10-key) number buttons to select a

song.

To stop demo playback, press 7.

Demo playback continues until you stop it by pressing 7.

• If Auto Power Off (page EN-10) is enabled, the Digital

Piano will turn off if 30 minutes (six minutes under battery

power) elapse without any keyboard operation being

performed. Use the procedure under “Disabling Auto Power

Off” (page EN-10) for information about how to disable Auto

Power Off.

Use the procedure below to play back one of the built-in

songs. You can play along on the keyboard with song

playback.

Press bn (SONG BANK).

Use br (10-key) to enter the number of the song

you want.

• See page EN-74 for a complete list of available songs.

• Use the number buttons to enter the song number.

Specify three digits for the song number.

33 44 55 66 77 88 99

ckckbnbn brbr

Playing the Demo Songs

DemoTun e

Tune nameSong numberFlashes

Playing Back a Particular Song

Start/Stop

Example: To select 001, enter 0 3 0 3 1.

Tw i nk l e

Tune nameSong numberLights

CDP230R_e.book 26 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Playing Built-in Songs

EN-27

Press 7.

This starts playback of the song.

Press 7 again to stop playback.

Song playback will continue (repeat) until you press 7 to

stop it. You can cancel song repeat by pressing 3.

Use the operations in this section to perform pause, skip

forward, and skip back operations.

■Pause

Press 6.

This pauses song playback.

Press 6 again to resume playback from the

point where you paused it.

■Skip Forward

Press 5.

This skips song playback forward to the next measure.

Each press of 5 skips ahead one measure. Holding

down 5 skips forward at high speed until you release it.

•Pressing

5 while song playback is stopped performs

lesson function phrase skip forward (page EN-31).

■Skip Back

Press 4.

This skips song playback back to the previous measure.

Each press of 4 skips back one measure. Holding down

4 skips back at high speed until you release it.

• Pressing 4 while song playback is stopped performs

lesson function phrase skip back (page EN-31).

You can use the procedure in this section to repeat particular

measures for practice playing along until you master it. You

can specify the start measure and the end measure of the

section you want to play and practice.

Press 3 to temporarily turn off song repeat.

When song playback reaches the measure you

want to specify as the start measure, press 3.

This specifies the measure as the start measure.

Pause, Skip Forward, Skip Back

Key

Tempo

Beat

Measure

Fingering

Sustain pedal

Note

Indicator disappears

when song repeat is

turned off.

Measure number

Repeating Playback of Specific Measures

Start End

These measures are repeated.

Disappears

Flashes

CDP230R_e.book 27 ページ２０１４年２月１９日　水曜日　午後５時１１分

Playing Built-in Songs

EN-28

When playback reaches the measure you want

to select as the end measure, press 3 again.

This specifies the measure as the end measure and starts

repeat playback of the measures in the specified range.

• During repeat play you can use 6 to pause playback,

5 to skip forward, or 4 to skip back.

Pressing 3 again returns to normal playback.

Changing the song number clears the start measure and

end measure of the repeat operation.

You can use the following procedure to change the speed

(tempo) in order to slow down playback to practice difficult

passages, etc.

Press 9.

Use w (slower) and q (faster) to change the tempo

setting. Holding down either button changes the setting at

high speed.

•Pressing w and q at the same time will return the

current song to its original default tempo.

•Pressing

9 causes the tempo value to flash on the

display. While the tempo value is flashing, you can use

br (10-key) to change it. The tempo value will stop

flashing if you do not perform any operation for a short

while.

• Changing the song number will return the song to its

original default tempo.

Use the following procedure to adjust the balance between

the volume of what you play on the keyboard and song

playback volume.

Press ck (FUNCTION) and then use the br (10-

key) [4] (U) and [6] (I) keys to display “Song

Vol” (page EN-7).

Use the br (10-key) [–] and [+] keys to adjust

the song volume.

The procedure below lets you select the same keyboard tone

as the one being used in the song and play along with your

favorite tunes.

After selecting a song, hold down bn (SONG

BANK) for about two seconds until the

displayed tone name changes to the tone name

of the song.

• If your currently selected tone is the same as the song

tone, the display contents will not change.

Play along with song playback.

• If you select a song that uses different tones for left and

right hand play, the right hand part tone is assigned to the

keyboard.

Changing Playback Speed (Tempo)

Lights

Disappears

Adjusting the Song Volume

Playing with the Tone as Song Playback

Son

Vo l

CDP230R_e.book 28 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Playing Built-in Songs

EN-29

You can turn off the right hand part or the left hand part of a

song during playback and practice playing along with the

remaining part.

Press 8 to select the part you want to turn off.

Each press of 8 cycles through the settings shown

below.

Press 7.

This starts playback in accordance with the setting you

selected in step 1.

• During playback with one part turned off, only the notes of

the part that is turned off are shown on the display.

You can load song data from an external device and increase

the selection of songs available on the keyboard. See the

following pages for more information.

• Memory card (page EN-61)

• Computer (page EN-67)

• For information about how to delete song data loaded from

an external device, see page EN-57.

Turning Off the Part of One Hand for Practice

(Part Select)

Right hand part off

Left hand part off

Both hand parts off

Both hand parts on

Increasing the Selection of Songs

CDP230R_e.book 29 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-30

Using Built-in Songs to Master Keyboard Play

To master a song, it is best to break it up into shorter parts

(phrases), master the phrases, and then put everything

together. Your Digital Piano comes with a Step Up Lesson

feature that helps you to do just that.

The built-in songs are pre-divided into phrases to help you

master keyboard play.

Step Up Lesson takes you through practice of the right hand

part, left hand part, and both hand parts for each phrase of a

song. Master all of the phrases and you master the song.

clcl cmcm cncn coco cpcp33 44 55 77 88

brbrbnbn ckck

Phrases

Song start Song end

Phrase 1 Phrase 2 Phrase 3 .... Final

Phrase

Step Up Lesson Flow

Phrase 1

• Right Hand Lesson 1, 2, 3

• Left Hand Lesson 1, 2, 3

• Both Hand Lesson 1, 2, 3

Repeat the above to practice phrase

2, 3, 4, and so on, until you reach the

final phrase of the song.

After mastering all of the phrases,

practice the entire song.

Now you have mastered the entire

song!

CDP230R_e.book 30 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using Built-in Songs to Master Keyboard Play

EN-31

The following are the messages that appear on the display

during Step Lessons.

First, select the song, phrase, and part you want to practice.

Select the song you want to practice (page

EN-26).

This will select the first phrase of the song.

Press co (or 5) to move forward one phrase,

or 4 to move back one phrase.

• Holding down 5 or 4 scrolls through phrases at high

speed.

• The Digital Piano remembers the last phrase you

practiced for up to 20 songs. To recall the last practice

phrase for the current song (if it is available), hold down

co.

Press 8 to select the part you want to practice.

Each press of 8 cycles through the settings

shown below.

Hold down bn (SONG BANK) for about two

seconds.

The same tone used for song playback will be assigned to

the keyboard (page EN-28).

Messages that Appear during Lessons

Message Description

<Phrase> Appears when you select a phrase, when a

lesson starts, etc.

• Note that certain phrases will cause

“<Wait>” to appear instead of “<Phrase>”.

<Wait> Appears when the lesson starts with an intro

or fill-in phrase that is not included in the

phrases to be practiced. Play toll advance

automatically to the next phrase after the un-

included phrase plays, so wait until then to

start playing on the keyboard.

NextPhrs Appears when advancing automatically to the

next phrase. This message appears following

a phrase for which “<Wait>” (see above) is

displayed, and during an Auto Step Up Lesson

(page EN-35).

Listen

Watch

Remember

Appears at the start of Auto Step Up lesson 1,

2, or 3 (page EN-35).

From top This message appears during Auto Step Up

Lesson (page EN-35) immediately before

practice from Phrase 1 up until the phrase

currently being practiced.

Complete Appears at the end of Auto Step Up Lesson

(page EN-35).

Selecting the Song, Phrase, and

Part You Want to Practice

Phrase number

First measure of the selected phrase

*This indicator (setting) is skipped if you press 8 while

a lesson is in progress.

Right hand practice

Left hand practice

Both hand practice

CDP230R_e.book 31 ページ２０１４年２月１９日　水曜日　午後５時１１分

Using Built-in Songs to Master Keyboard Play

EN-32

Now it is time to start the lessons. First, select the song and

part you want to practice.

First, listen to the example a few times to familiarize yourself

with what it sounds like.

Press cl.

This starts example play.

To stop Lesson 1, press cl or 7.

Play the song on the keyboard. During this lesson, the display

shows the key you need to press next. Voice fingering guide

also uses a simulate voice to announce which finger you

should use. Follow the instructions to press the correct

keyboard keys and play the notes. Don’t worry if you play the

wrong note. Song playback will wait until you play the correct

note. Take your time and play at your own pace.

Press cm.

This starts Lesson 2.

Play notes on the keyboard in accordance with

the instructions provided on the display and by

voice fingering guide.

During this lesson, the display shows the key you need to

press next. Voice fingering guide uses a simulate voice to

announce which finger you should use.

To stop Lesson 2, press cm or 7.

●If you complete Lesson 2 play to the end, a score that

rates your play appears on the screen.

Lessons 1, 2, and 3

Lesson 1: Listen to the song.

Lesson 2: Watch how the song is played.

Lights

Flashes

Master playing the correct note with the correct finger

as instructed by the guidance. Practice playing with the

correct timing.

Song playback will wait for you to play the correct note.

• Keyboard key goes from flashing to lit.

• Note guide sounds the correct note to be played.

• Voice Fingering Guide tells you what finger to use.

Pressing the correct keyboard key causes song

playback to resume and the key for the next note

flashes.

Bravo! You pass! Advance to the next lesson.

Again! Go back and try again.

CDP230R_e.book 32 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using Built-in Songs to Master Keyboard Play

EN-33

Though song playback stands by waiting for you to press the

correct keys as in Lesson 2, the Digital Piano does not

provide any guidance about what note you need to play next.

Remember everything you have learned up to Lesson 2 as

you play.

Press cn.

This starts Lesson 3.

Play the song along with the song playback.

To stop Lesson 3, press cn or 7.

• If you complete Lesson 3 play to the end, a score that

rates your play appears on the screen the same as with

Lesson 2.

After you successfully complete all of the phrases in Lessons

1, 2, and 3, it is time to try playing the entire song from

beginning to end.

Use 8 to turn off both hand parts and then

press 7.

Try playing with both hands and find out how the Digital

Piano evaluates your effort.

You can turn off phrase repeat for Lessons 1, 2, and 3.

Press 3.

This disables phrase repeat play.

Use the following procedure to turn off voice fingering guide,

which tells you which finger to use to play each note in

Lesson 2 and Lesson 3.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“LESSON” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Press the br (10-key) [–] key to select the OFF

setting.

Lesson 3: Remember what you learned as

you play.

Press the keyboard keys you learned in Lesson 2.

Song playback will wait for you to play the correct note.

• Note guide sounds the correct note to be played.

If you are still unable to press the correct keyboard

key, the Digital Piano will display keyboard guidance

and voice fingering guide will tell you what finger to

use, just as in Lesson 2.

Pressing the correct key will cause song playback to

resume.

Playing a Particular Song All the Way

Through

Lesson Settings

Playing without Phrase Repeat

Turning Off Voice Fingering Guide

Disappears

LESSON

Flashes

eak

CDP230R_e.book 33 ページ２０１４年２月１９日　水曜日　午後５時１１分

Using Built-in Songs to Master Keyboard Play

EN-34

Use the following procedure to turn off note guide, which

sounds the note to be played next in Lesson 2 and Lesson 3.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“LESSON” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “NoteGuid”.

Press the br (10-key) [–] key to select the OFF

setting.

Use the following procedure to turn off performance

evaluation, which evaluates your performance and displays a

score in Lesson 2 and Lesson 3.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“LESSON” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “Scoring”.

Press the br (10-key) [–] key to select the OFF

setting.

You can use the following procedure to change the length of

lesson phrases, or to configure the lesson feature so the song

is played all the way through, without being divided into

phrases.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“LESSON” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “PhraseLn”.

Use the br (10-key) [–] and [+] keys to select

the phrase length you want.

The following options are available for songs loaded from

external sources only.

Turning Off Note Guide

Turning Off Performance Evaluation

No t eGu i d

Scor i ng

Changing the Phrase Length

Off (oFF) The phrase length is from the beginning

to the end of the song.

Preset (PrE) Phrase lengths are as specified in the

song.

Short (Ln1) Length of one phrase is one measure.

Middle (Ln2) Length of one phrase is two measures.

Long (Ln3) Length of one phrase is four measures.

Ph r aseLn

CDP230R_e.book 34 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using Built-in Songs to Master Keyboard Play

EN-35

With Auto Step Up Lesson, the Digital Piano advances

through each lesson automatically.

Select the song and part you want to practice

(page EN-26).

Press cp.

Listen to the first phrase in Lesson 1.

• In Lesson 1, the sample phrase is played only once

before advancing to Lesson 2.

Auto Step Up Lesson stops automatically after

you are able to get through all of the lessons

successfully.

• In Lesson 2 and Lesson 3, the Digital Piano advances

to the next lesson if you are able to achieve the “Bravo!”

evaluation result.

• To cancel a lesson, press cp or 7.

• You can change the step and phrase during Auto Step Up

Lesson using 4, 5, and cl to co.

• Starting Auto Step Up Lesson automatically turns on

phrase repeat (page EN-33) and play evaluation (page

EN-34). These features cannot be turned off during

lessons.

■Auto Step Up Lesson Procedure

*Auto Step Up Lesson advances to the next phrase,

regardless of whether the “Bravo!” result is attained.

Using Auto Step Up Lesson Phrase 1

Lesson 1

Lesson 2

Lesson 3

Phrase 2

Lesson 1

Lesson 2

Lesson 3

Phrase 1, 2

• Lesson 3*

Phrase 3

Lesson 1

Lesson 2

Lesson 3

Phrase 1, 2, 3

• Lesson 3*

Next phrase practice using the same

procedure

Final phrase

Lesson 1

Lesson 2

Lesson 3

From Phrase 1 to the final phrase

• Lesson 3*

Lesson complete

CDP230R_e.book 35 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-36

Music Challenge Keyboard Game

Music Challenge is a game that measures your reaction

speed as you press keys in response to on-screen keyboard

indicators and fingering guide indications.

Press bn (SONG BANK).

Press cq.

This causes a key on the on-screen keyboard to start to

flash, and starts the Music Challenge song.

After the on-screen keyboard indicator changes

from flashing to lit, press the indicated key with

the indicated finger as quickly as possible.

This causes the on-screen keyboard key to go out to let

you know that you cleared the first note. The next on-

screen keyboard key starts to flash, so get ready to press

the next key.

• The time it takes you to press the keyboard key after

the on-screen key lights appears on the display (Unit:

0.1 sec). The shorter the time, the higher your score.

• Pressing a keyboard key before the on-screen key

goes from flashing to lit, will not advance to the next

note.

The game ends when you advance successfully

through 20 notes.

• Your playing time appears on the display. After a short

while, the playing time display changes to a score. To

clear the score from the display, press bn (SONG

BANK), bo (RHYTHM), or bp (TONE).

• You can cancel a game at any time by pressing cq or

• Notes and fingering guide fingers are indicated randomly.

• The tempo of the game songs cannot be changed.

• All buttons except 2, 7, and cq are disabled while a

game is in progress.

bobo bpbp

bnbn

cqcq22

M.CHAL . !

Fingering

Displayed during a game.

Number of remaining notes

M.CHAL. !

Time 0.3sec

Score 80

Time19.2

Playing time

Score

CDP230R_e.book 36 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

EN-37

Using Auto Accompaniment

With Auto Accompaniment, simply select an accompaniment

pattern. Each time you play a chord with your left hand the

appropriate accompaniment will play automatically. It’s like

having a personal backup group along with you wherever you

go.

• Auto Accompaniments are made up of the following three

parts.

(1) Rhythm

(2) Bass

(3) Harmony

You can have only the rhythm part play, or you can have all

three parts play at the same time.

The rhythm part is the foundation each Auto Accompaniment.

Your Digital Piano comes with a variety of built-in rhythms,

including 8-beat and waltz. Use the following procedure to

play the basic rhythm part.

Press bo (RHYTHM).

Use br (10-key) to select the rhythm number

you want.

• See the separate “Appendix” for information about

individual rhythms.

• Use the number buttons to enter the rhythm number.

Specify three digits for the rhythm number.

• With rhythms 191 to 200, nothing will sound until you play a

chord on the keyboard.

Press 7 or 4.

This starts the rhythm.

Play along with the rhythm.

To stop the rhythm, press 7 again.

66 9933 44 55 88

ckck

77 ctct

brbrbobo bqbq btbtbpbpbnbn

Playing the Rhythm Part only

Starting and Stopping the Rhythm Part only

Example: To select 001, enter 0 3 0 3 1.

nthPo

Rhythm number Rhythm pattern name

This pattern changes with each beat.

CDP230R_e.book 37 ページ２０１４年２月１９日　水曜日　午後５時１１分

Using Auto Accompaniment

EN-38

Playing a chord with your left hand automatically adds bass

and harmony accompaniment parts to the currently selected

rhythm. It is just like having your own personal back up group

on call.

Start play of the Auto Accompaniment rhythm

part.

Press 8.

This enables chord input on the accompaniment

keyboard.

Use the accompaniment keyboard to play

chords.

This will cause bass and harmony Auto Accompaniment

parts to be added to the rhythm part.

Play other chords with left hand as you play the

melody with your right hand.

Pressing 8 again returns to rhythm only

accompaniment.

• For information about starting Auto Accompaniment as

soon as a chord is played, see “Using Synchro Start” on

page EN-41.

• You can use the split point to change the size of the

accompaniment keyboard range (page EN-15).

You can select from among the following five chord input

modes.

• FINGERED 1

• FINGERED 2

• FINGERED 3

• CASIO CHORD

• FULL RANGE CHORD

Hold down 8 until the chord input mode

selection screen appears on the display.

Use the br (10-key) [–] and [+] keys to select

the chord input mode you want.

• If you do not perform any operation after the chord input

mode selection screen appears, the display will return

automatically to the screen that was displayed before

you held down 8.

Playing All Parts

Auto Accompaniment with Chords

Example: Pressing D-F#-A-C on the accompaniment keyboard

Accompaniment for the D-F#-A-C chord (D7) sounds.

Accompaniment keyboard

Lights

Chords

(no melody played) Melody

Selecting a Chord Input Mode

Cho r d

Chord input mode

CDP230R_e.book 38 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using Auto Accompaniment

EN-39

■FINGERED 1, 2, and 3

With these three input modes, you play chords on the

accompaniment keyboard using their normal chord fingerings.

Some chord forms are abbreviated, and can be fingered with

one or two keys.

See page EN-75 for information about chords that are

supported and how they are fingered on the keyboard.

●FINGERED 1

Play the component notes of the chord on

the keyboard.

●FINGERED 2

Unlike FINGERED 1, 6th input is not

possible. m7 or m7b5 is input.

●FINGERED 3

Unlike FINGERED 1, allows input of

fraction chords with the lowest keyboard

note as the bass note.

■CASIO CHORD

With CASIO CHORD, you can use

simplified fingerings to play the four types

of chords described below.

CASIO CHORD Fingering

• When playing a minor, seventh, or minor seventh chord, it

makes no different whether the additional keys you press

are black or white.

■FULL RANGE CHORD

With this mode, you can use the full range

of the keyboard to play chords and the

melody.

See page EN-75 for information about

chords that are supported.

Accompaniment keyboard

Chord Type Example

Major Chords

Letters above the accompaniment

keyboard indicate the chord

assigned to each key. Pressing a

single accompaniment area key in

the CASIO CHORD mode will play

the major chord whose name is

marked above the key. All of the

accompaniment area keys that are

marked with the same chord name

play exactly the same chord.

C (C Major)

Minor Chords

To play a minor chord, press the

accompaniment area key that

corresponds to the major chord,

while also pressing one other

accompaniment area key to the

right.

Cm (C Minor)

Seventh Chords

To play a seventh chord, press the

accompaniment area key that

corresponds to the major chord,

while also pressing two other

accompaniment area keys to the

right.

C7 (C Seventh)

Minor Seventh Chords

To play a minor seventh chord,

press the accompaniment area key

that corresponds to the major

chord, while also pressing three

other accompaniment area keys to

the right.

Cm7

(C Minor Seventh)

CCDE F F

CCDE F

CCDE F F

CCDE F

CCDE F F

CCDE F

CCDE F F

CCDE F

Accompaniment keyboard / Melody keyboard

CDP230R_e.book 39 ページ２０１４年２月１９日　水曜日　午後５時１１分

Using Auto Accompaniment

EN-40

Use the following procedures to play intro and ending

patterns, to play fill-in patterns, and to play variations of basic

Auto Accompaniment patterns.

■Auto Accompaniment Variation

Each Auto Accompaniment pattern has a basic “normal

pattern” as well as a “variation pattern”.

Press 5.

This starts the variation pattern.

Pressing 4 returns to normal pattern.

■Auto Accompaniment Intro

Use the following procedure to play an intro of a few

measures.

Press 3.

This starts the intro pattern. Normal pattern play will start

when the intro pattern is finished.

• If you press 5 while an intro pattern is being played,

the variation pattern will start when the intro pattern is

finished.

■Auto Accompaniment Fill-in

Use the procedure below to play a fill-in pattern during a

performance.

• A “fill-in” is a short phrase played where you want to change

the mood of a piece. A fill-in pattern can be used to create a

link between two melodies or an accent.

• Normal and variation patterns have their own unique fill-in

patterns.

●Normal Pattern Fill-in

While a normal pattern is playing, press 4.

This plays the fill-in for the normal pattern.

• Normal pattern play will resume after the fill in pattern is

complete.

●Variation Pattern Fill-in

While a variation pattern is playing, press 5.

This plays the fill-in for the variation pattern.

• Variation pattern play will resume after the fill in pattern

is complete.

■Auto Accompaniment Ending

Use the following procedure to play an ending of a few

measures.

While an Auto Accompaniment is playing, press

This will play the ending pattern and then stop Auto

Accompaniment play automatically.

Using Auto Accompaniment

Effectively

Auto Accompaniment Pattern Variations

Lights

CDP230R_e.book 40 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using Auto Accompaniment

EN-41

■Using Synchro Start

Use the following procedure to configure the Digital Piano to

start Auto Accompaniment play as soon as you press a

keyboard key.

Press 6.

This enters accompaniment start standby.

Play a chord on the keyboard.

This will start full part accompaniment (normal).

Any of the following operations can be performed while in

synchro standby to start a non-normal pattern.

• To start with intro pattern, press 3.

• To start with variation pattern play, press 5.

Use the following procedure to change Auto Accompaniment

speed to a level that suits you.

Press 9.

Use w (slower) and q (faster) to change the tempo

setting. Holding down either button changes the setting at

high speed.

•Pressing w and q at the same time will initialize the

tempo setting in accordance with the currently selected

rhythm.

• While the tempo value is flashing, you also can use br

(10-key) to change it.

• If you do not perform any operation for a few seconds

after the tempo setting screen appears, the display will

return to the screen displayed before you pressed 9.

Use the following procedure to adjust the balance between

what you are playing on the keyboard and the volume of the

Auto Accompaniment.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“AcompVol” (page EN-7).

Use the br (10-key) [–] and [+] keys to adjust

the accompaniment volume.

With One-Touch Preset, the Digital Piano automatically

configures optimal tone, tempo, and other settings in

accordance with the rhythm pattern you select.

Hold down bo (RHYTHM) until the current tone

screen appears on the display.

This will automatically apply the One-Touch Preset

settings in accordance with the rhythm pattern that is

currently selected.

Play a chord on the keyboard.

This will start accompaniment automatically.

Changing Auto Accompaniment Speed

(Tempo)

Flashes

Adjusting the Accompaniment Volume

Using One-Touch Preset

Acom

Vo l

CDP230R_e.book 41 ページ２０１４年２月１９日　水曜日　午後５時１１分

Using Auto Accompaniment

EN-42

Auto Harmonize automatically adds harmony to notes you

play with your right hand, which adds rich depth to the melody

of your performances. You can select from among 12 types of

Auto Harmonize to suit the type of music you are playing.

• Auto Harmonize is controlled using the same button ct as

the Arpeggiator (page EN-56). Because of this, these two

functions cannot be used at the same time.

Press 8 to enable Auto Accompaniment with

chords (ACCOMP indicator lit) (page EN-38).

• Auto Harmonize cannot be used while FULL RANGE

CHORD is selected as the chord input mode. Select

another mode if you want to use Auto Harmonize.

Hold down ct until the Auto Harmonize or

Arpeggiator type number and type name appear

on the display.

• If you do not perform any operation for a few seconds,

the display will return to previous screen automatically.

Use the br (10-key) [–] and [+] keys to select

the Auto Harmonize type you want.

• 013 through 102 are Arpeggiator types (page EN-56).

Do not select them when using the Auto Harmonize.

Press ct to turn on Auto Harmonize.

If you play chords with your left hand and the melody with

your right hand, harmony notes will be added to the

melody.

• Press ct again to turn off Auto Harmonize.

Using Auto Harmonize

Due t 1

Type number Type name

Due t 2

Type

number Type Name Description

001 Duet 1 Adds close (separated by 2 to 4

degrees) 1-note harmony below

the melody note.

002 Duet 2 Adds open (separated by more

than 4 to 6 degrees) 1-note

harmony below the melody note.

003 Country Adds country style harmony.

004 Octave Adds the note from the next lower

octave.

005 5th Adds the fifth degree note.

006 3-Way Open Adds 2-note open harmony, for a

total of three notes.

007 3-Way Close Adds 2-note close harmony, for a

total of three notes.

008 Strings Adds harmony that is optimal for

strings.

009 4-Way Open Adds 3-note open harmony, for a

total of four notes.

010 4-Way Close Adds 3-note close harmony, for a

total of four notes.

011 Block Adds block chord notes.

012 Big Band Adds big band style harmony.

St .GrPno

Lit when on

CDP230R_e.book 42 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using Auto Accompaniment

EN-43

You can use the Chord Book to look up chords that you do not

know how to play.

Hold down bt until the message “ChordBk”

appears on the display.

On the chord keyboard, press the keyboard key

that corresponds to the root note of the chord

you want to look up.

Use the br (10-key) [–] and [+] keys to select

the type of chord you want.

Selecting a chord type causes the chord to sound, and

shows the chord name and its notes on the display.

• You can select any one of the following chord types.

• To display inverted forms of the chord, use br (10-key)

keys [0] through [4] as shown below.

After you are finished looking up what you

want, press bt to exit the Chord Book.

• You can also exit the chord book by pressing bn

(SONG BANK), bo (RHYTHM), bp (TONE), or bq.

Looking Up the Notes of Chords

(Chord Book)

Example: To look up C

Cho r dBk

Chord keyboard

Cho r dBk

Root note

Example: Selecting M (Major)

M(Major), m(minor), dim, aug, sus4, sus2, 7th, m7,

M7, m7b5, 7b5, 7sus4, add9, madd9, mM7, dim7, 69,

6th, m6

To display this inverted form: Press this key:

Normal form 0

First inversion 1

Second inversion 2

Third inversion 3

Fourth inversion 4

(

)

Chord name Chord notes

Chord type

CDP230R_e.book 43 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-44

Editing Auto Accompaniment Patterns

You can use the procedure in this section to edit the Digital

Piano’s built-in Auto Accompaniment rhythm patterns and

create your own “user rhythms”.

• You can store up to 10 user rhythms in Digital Piano

memory, using rhythm numbers 201 through 210.

■Editable Accompaniment Patterns and

Instrument Parts

Any of the following parts that make up each rhythm that is

assigned a rhythm number can be edited.

Accompaniment patterns (intro, fill-in, etc.): 6 types

Instrument parts (drum, bass, etc.): 8 types

■Editable Contents

•Rhythm number

•Part on/off

• Tone number

•Volume level

• Left-right speaker balance (panning)

• Reverb depth (reverb send)

• Chorus depth (chorus send)

Select the number of the rhythm you want to

edit.

Press bl.

If the “Err Mem Full” message appears on the display, see

page EN-73 for information about what you should do.

6633 44 55 8877

brbrbobo

blbl

ckck

Accompaniment Pattern

Instrument

Parts

INNFVVFE

1Drum I-1 N-1 NF-1 V-1 VF-1 E-1

2Percussion I-2 N-2 NF-2 V-2 VF-2 E-2

3Bass I-3 N-3 NF-3 V-3 VF-3 E-3

4Chord 1 I-4 N-4 NF-4 V-4 VF-4 E-4

5Chord 2 I-5 N-5 NF-5 V-5 VF-5 E-5

6Chord 3 I-6 N-6 NF-6 V-6 VF-6 E-6

7Chord 4 I-7 N-7 NF-7 V-7 VF-7 E-7

8Chord 5 I-8 N-8 NF-8 V-8 VF-8 E-8

Button 344556

INTRO

NORMAL

FILL-IN

VARIATION

FILL-IN

ENDING

Button

To edit and save an Auto Accompaniment

Drm:Rh

Rhythm number

Editable content

Instrument part

Accompaniment Pattern (Flashes)

Lights

CDP230R_e.book 44 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Editing Auto Accompaniment Patterns

EN-45

Press a button from 3 to 6 to select the

Accompaniment Pattern you want to edit.

The name of the pattern will appear on the display.

Pattern selected by each button

Press 8 to select the instrument part you want

to edit.

The part number of the part you select will flash on the

display.

Press bo (RHYTHM).

This will display the rhythm name.

Use the br (10-key) [–] and [+] keys to select

the rhythm number you want to assign to the

instrument part you are editing.

A different rhythm number is assigned for each instrument

part.

• You can play the data of the currently selected rhythm

number by pressing 7.

• All of the eight instrument parts of an intro (I-1 to I-8)

must have the same rhythm number. If you assign

rhythm 003 to I-1, for example, 003 also will be

assigned automatically to parts I-2 through I-8. If you

then assign rhythm 004 to part I-2, for example, I-1 and

all of the other parts also will change to 004. All of the

eight parts of an ending (E-1 to E-8) also must have the

same rhythm number.

To edit the other contents, press ck

(FUNCTION) to display the screen for the

setting you want.

• Each press of ck (FUNCTION) will cycle through the

settings shown below, from 1 through 6.

• Use the br (10-key) [–] and [+] keys to change the

currently selected setting.

• You can play the current settings of the editable part by

pressing 7.

*Instrument parts 1 and 2 can be assigned drum set tones

(built-in tones 684 to 700) only.

Repeat steps 4 through 7 as many times as

necessary to edit the parts you want for the

pattern you selected in step 3.

• If you change the rhythm number in step 6, the editable

contents (1 through 6 in the above table) you last

configured in step 7 of this procedure will be overwritten

with the settings of the newly selected rhythm.

Repeat steps 3 through 8 as many times as

necessary to edit the accompaniment patterns

you want (intro through ending).

10.

Press bl.

This will display a message asking if you want to save the

user rhythm.

3:Intro

4: Normal, Normal Fill-in

(Each press toggles the selection.)

5: Variation, Variation Fill-in

(Each press toggles the selection.)

6: Ending

Drm:Rh

5 Variation selected

Part 6 (Chord 3)

Flashing: Part selected for editing.

Parts that contain data.

Setting Type Display Settings

1 Part on/off Part On/Off

2 Tone number*Tone 001 - 683

3 Volume level Vol. 000 - 127

4Left-right speaker balance

(panning) Pan –64 - 0 - +63

5 Reverb depth (reverb send) Rvb 000 - 127

6 Chorus depth (chorus send) Cho. 000 - 127

CDP230R_e.book 45 ページ２０１４年２月１９日　水曜日　午後５時１１分

Editing Auto Accompaniment Patterns

EN-46

11-1.

Press the br (10-key) [–] key to exit without

saving.

This displays the delete confirmation message.

Press the br (10-key) [+] key to exit the editing

procedure.

11-2.

Press the br (10-key) [+] key to save the data.

•Use

br (10-key) [–] and [+] keys to select the rhythm

number you want to save.

• You can edit the user rhythm name. Use the br

(10-key) [4] (U) and [6] (I) keys to move the cursor to

the character you want to change, and then use [+] and

[–] to change the character.

12.

Press br (10-key) [9] (ENTER) key.

This will display a message asking if you want to save the

user rhythm.

• Press the br (10-key) [+] key to save the data.

• Press the br (10-key) [–] key to return to the screen

that was displayed before you pressed [9] (ENTER)

key.

• If you select a user rhythm number that already

contains data, the existing data will be replaced by the

new data.

• You cannot change the tone assigned to the keyboard

while an Auto Accompaniment editing (rhythm edit)

operation is in progress.

■Saving User Rhythm Data on an External Device

• Memory card (page EN-60)

• Computer (page EN-67)

The following procedure cannot be performed while an Auto

Accompaniment editing (rhythm edit) operation is in progress.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“DELETE” (page EN-7).

Press the br (10-key) [9] (ENTER) key.

Press the br (10-key) [6] (I) key.

Use the br (10-key) [–] and [+] keys to select

the user rhythm you want to delete.

Press the br (10-key) [9] (ENTER) key.

This displays a delete confirmation message.

Press the br (10-key) [+] (YES) key.

After the delete procedure is complete, “Complete” will

appear followed by the screen in step 2 of the above

procedure.

• To cancel the delete operation, press [–] (NO) or [7]

(EXIT) in place of [+] (YES).

nthPo

To delete saved data

Used memory (Unit: Kbytes)

Remaining memory capacity

DELETE

Flashes

Use 1

User rhythm name

Su r e?

CDP230R_e.book 46 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

EN-47

Saving Keyboard Setups to Registration Memory

Registration memory lets you store Digital Piano setups (tone,

rhythm, etc.) for instant recall whenever you need them.

Registration memory simplifies performance of complex

pieces that require successive tone and rhythm changes.

You can have up to 32 setups in Registration memory at one

time. cl and cm to cp are used for recording.

• Each press of bank select button cl cycles through the

bank numbers, from 1 to 8.

• Pressing a button from cm to cp selects the corresponding

area in the currently selected bank.

■Registration Save Example

This example saves the data shown in the table below to the

following setups in Bank 1.

• Initial melody setup saved to Setup 1-1.

• Second melody setup saved to Setup 1-2.

• Third melody setup saved to Setup 1-3.

■Registration Memory Data

The following is the complete list of data that is saved to a

registration memory setup.

• Tone numbers (main, layer, split)

• Rhythm number

• Tempo

• Auto Harmonize

• Transpose

• Split point

• Touch Response

• Octave shift

• Chord fingerings

• Accompaniment volume

• Arpeggiator setting (on, off, type)

• Synchro start

• Hall (on, off)

• Reverb (on, off, type)

• Chorus (on, off, type)

• Bend Range

• Accomp (on, off)

• Arpeggiator hold (on, off)

• Layer (on, off)

• Split (on, off)

• Pedal effect

clcl cmcm cncn coco cpcp cqcq

brbrbobo

Area 1 Area 2 Area 3 Area 4

Bank 1 Setup 1-1 Setup 1-2 Setup 1-3 Setup 1-4

Bank 2 Setup 2-1 Setup 2-2 Setup 2-3 Setup 2-4

Bank 8 Setup 8-1 Setup 8-2 Setup 8-3 Setup 8-4

cl cm cn co cp

Setup 1–1 Setup 1–2 Setup 1–3

Tone Number 001 062 001

Rhythm Number 118 005 089

Tempo 080 140 089

CDP230R_e.book 47 ページ２０１４年２月１９日　水曜日　午後５時１１分

Saving Keyboard Setups to Registration Memory

EN-48

Press bo (RHYTHM).

Configure the tone, rhythm, and other settings

you can to include in the setup.

Press cl to select the bank you want.

Each press of cl cycles through the bank numbers.

• You also can select a bank by holding down cl as you

use the br (10-key) number buttons to enter a bank

number.

While holding down cq, press a button from cm

to cp to select an area.

This will save the settings you configured in step 2 into the

applicable setup.

• If there is anything already stored in the setup, it will be

replaced (deleted) by the new setup.

Press cl to select the bank that contains the

setup you want to recall.

Use buttons cm to cp to select the area whose

setup you want to recall.

This will recall the registration memory setup and

automatically configure the Digital Piano settings

accordingly.

• Notes currently being sounded by the keyboard may stop if

you recall a setup that causes a change in octave shift

(page EN-17). To keep this from happening, either select a

setup that does not cause a change in the octave shift

setting, or hold down the pedal (which will cause notes

currently being played to be sustained).

■Saving registration Data on an External Device

• Memory card (page EN-60)

• Computer (page EN-67)

To save a setup to registration

memory

Bank number

Bank 4

Store

Stored in Setup 4-1

To recall a setup from registration

memory

Bank 6

Reca l l

Setup 6-1 recalled

CDP230R_e.book 48 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

EN-49

Recording Your Keyboard Play

The recorder feature lets you record your keyboard play.

Use the following procedure to record everything you play on

the keyboard.

Press bo (RHYTHM).

Press bk.

Press bk again.

This will enter record standby.

Configure the tone, rhythm, and other settings

you want to use.

Start playing.

Recording starts as soon as you play something on the

keyboard.

• You can use Auto Accompaniment while playing. If you do,

Auto Accompaniment also will be recorded.

To stop recording, press 7.

To play back what you have recorded, press 7

again.

Each press of 7 starts and stops playback.

bpbpbnbn

8877 clcl cmcm cncn coco cpcp cqcq

bobo

bkbk

brbr

Recording and Playing Back

Keyboard Play

Lights

Flashes

Lights

CDP230R_e.book 49 ページ２０１４年２月１９日　水曜日　午後５時１１分

Recording Your Keyboard Play

EN-50

Press bk twice to exit the recorder mode.

• The flashing on the screen shown in step 3 becomes

faster when remaining recorder memory capacity

becomes less than 100 notes.

• Total recorder memory capacity is approximately

12,000 notes. Recording will stop automatically when

there is no more unused recorder memory remaining.

• Each press of bk cycles through the settings shown

below. You can listen to the recorded data as many

times as you like by pressing 7 while in playback

standby.

■To delete recorded data

After step 3 of the above procedure, do hold down bk

(without pressing any keyboard key) until the message

“Tr.Del?” appears on the display. Press [+] (YES) to delete the

data, or [–] (NO) to cancel the delete operation.

• Turning off the Digital Piano while recording is in

progress will cause any data in recorder memory to be

deleted.

• A new recording replaces (deletes) previously recorded

contents.

You can divide a song according to various types of parts

(instrument, left and right hand, etc.), and record each part to

a specific track. You can mix up to six tracks (the original track

plus five additional tracks) into a final song.

■About tracks

Tracks are numbered from 1 to 6.

• If you do not specify a track number when recording,

recording is performed to Track 1 automatically.

In addition to what you play on the keyboard, the following

information also is recorded.

• Track 1

Settings:

Tone number, rhythm number, tempo, hall, reverb, chorus,

chords, layer/split settings, Auto Harmonize/Arpeggiator

setting

Operations:

Pedal, pitch bend wheel, INTRO button, SYNCHRO/

ENDING button, NORMAL/FILL-IN button, VARIATION/

FILL-IN button

• Tracks 2 through 6

Tone number, pedal operation, pitch bend wheel operation

Record the first part to Track 1.

To record to Track 1, perform steps 1 through 4 under

“Recording and Playing Back Keyboard Play” (page

EN-49).

Press bk.

This will enter record standby.

Disappears

Recorder Off Playback

Standby Record Standby

Using Tracks to Record and Mix

Parts

To record to Tracks 1 through 6

Lights

Flashes

CDP230R_e.book 50 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Recording Your Keyboard Play

EN-51

Press a button from cm to cq to select the track

number of the next track to which you want to

record.

This will enter record standby for the track you selected.

• If you want to use a different tone than the one you

used in Track 1, press bp (TONE) and then use br

(10-key) to input the tone number.

Press 7.

This will start playback of what you recorded up to this

point in other tracks and record what you play on the

keyboard to the currently selected track. Play the notes

you want on the keyboard.

To stop recording, press 7.

• To play back what you have recorded, press 7 again.

Each press of 7 starts and stops playback.

Repeat steps 2 through 5 to record the other

tracks.

After you finish recording all of the tracks,

press 7.

• This will start playback of the recorded tracks. Press

7 to stop or restart playback.

• At this time you can turn off playback of specific tracks

using buttons cl to cq. Pressing a key toggles

playback of each track on (track number displayed) or

off (track number not displayed).

• If you want to re-record a track, press bk. This will

return to step 2 of the above procedure. Only the tracks

that are turned on (displayed) above will play as you

re-record.

Press bk twice to exit the recorder mode.

■To delete a recorded track

After step 3 of the above procedure, do hold down bk

(without pressing any keyboard key) until the message

“Tr.Del?” appears on the display. Press [+] (YES) to delete the

track, or [–] (NO) to cancel the delete operation.

Example: Track 2

Flashes

Example: Tracks 2 and 3 selected

Disappears

CDP230R_e.book 51 ページ２０１４年２月１９日　水曜日　午後５時１１分

Recording Your Keyboard Play

EN-52

You can record up to five songs (numbered 1 through 5) in

memory. After that, you can select a specific song for

playback.

Press bo (RHYTHM).

Press bk.

A song number will appear in the upper left corner of the

display for a few seconds. While it is, use br (10-key) to

specify the number of the song you want to record or play

back. The song number will disappear if you do not

perform any operation.

Press bk to record, or 7 to play back.

To stop recording or playback, press 7.

Press bk twice to exit the recorder mode.

■To delete recorded data

After step 2 of the above procedure, do hold down bk

(without pressing any keyboard key) until the message “Song

Del?” appears on the display. Press [+] (YES) to delete the

song, or [–] (NO) to cancel the delete operation.

This section explains how to play along and record along with

one of the Digital Piano’s built-in songs.

●The following operations and settings also are

recorded along with your keyboard play.

Tone number, song number, pedal operation, tempo, hall,

reverb, chorus, layer/split settings, pitch bend wheel operation

• There can be only one recording of keyboard play with a

built-in song in recorder memory. Making a new recording

replaces (deletes) previously recorded data.

Press bn (SONG BANK).

Press bk.

This will enter playback standby.

Press bk again.

This will enter record standby.

Use br (10-key) to enter the song number you

want to assign to the recording.

Recording Two or More Songs,

and Selecting One for Playback

Example: Song 2

Pla

No .

Recording while Playing Along

with a Built-in Song

Lights

Flashes

CDP230R_e.book 52 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Recording Your Keyboard Play

EN-53

Press 8 to cycle through the parts in the

sequence shown below.

• Configure tone and tempo settings at this time as well.

Press 7 to start built-in song playback and

recorder recording.

Play along with the playback.

• To stop recording part way through, press 7.

Recording will stop automatically when the end

of the built-in song is reached.

This will enter playback standby.

Press 7.

This will start playback of what you recorded.

• Each press of 7 starts and stops playback.

Press bk twice to exit the recorder mode.

■To delete recorded data

After step 2 of the above procedure, do hold down bk until

the message “Song Del?” appears on the display. Press [+]

(YES) to delete the song.

You can save data you record with the Digital Piano onto a

memory card or on your computer’s hard disk. In the case of a

memory card, you can save recorded song data as a standard

MIDI file (SMF 0 format).

■To save data to a memory card

See page EN-60.

■To save data on your computer’s hard disk

See page EN-67.

Example: Left-hand part recording

Right-hand Recording

Both-hand Recording

Left-hand Recording

Flashes

Lights

Saving Recorded Data on an

External Device

CDP230R_e.book 53 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-54

Other Useful Digital Piano Functions

You can use the following procedure to select from among 17

preset scales, including the standard Equal Temperament.

Press bo (RHYTHM).

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“SCALE” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [–] and [+] keys to select

the preset scale you want. After selecting a

scale, press the key on the keyboard that you

want to use as the root key (C to B).

After you are finished, press ck (FUNCTION) to

assign the scale to the keyboard.

ctct

bpbpbobo brbr ckckbnbn

Changing the Scale of the

Keyboard

No. Scale name Display

00 Equal Temperament Equal

01 Pure Major PureMajr

02 Pure Minor PureMinr

03 Pythagorean Pythagor

04 Kirnberger 3 Kirnbrg3

05 Werckmeister Wercmeis

06 Mean-Tone MeanTone

07 Rast Rast

08 Bayati Bayati

09 Hijaz Hijaz

10 Saba Saba

11 Dashti Dashti

12 Chahargah Chaharga

13 Segah Segah

14 Gurjari Todi GujrTodi

15 Chandrakauns Cndrkuns

16 Charukeshi Carukesi

Flashes

S C A L E

u a l

Scale Name

CDP230R_e.book 54 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Other Useful Digital Piano Functions

EN-55

You can use the following procedure to reflect the preset

scale you selected in Auto Accompaniments.

Press

(FUNCTION) and then use the

(10-key)

[4] (U

) and

[6] (I

) keys to display

“

OTHER

” (page

EN-7

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “AcompScl”.

Use the br (10-key) [+] key to select on.

Selecting a Music Preset instantly changes the Digital Piano

to a preset setup (tone, rhythm, tempo, etc.) for play of songs

of various genres/categories. The press of a button sets up

the Digital Piano so those songs sound exactly the way you

thought they should.

• See the separate “Appendix” for a complete list of the 305

Music Presets that are available.

Hold down bp (TONE) until the indicator shown

below appears on the display.

Use br (10-key) to select the preset number

you want.

This will change the setup (tone, rhythm, etc.) of the

Digital Piano.

• At this time the Digital Piano will go into Auto

Accompaniment synchro start standby (page EN-41).

• Pressing bn (SONG BANK), bo (RHYTHM), or bp

(TONE) will return to the screen that was displayed

before you held down in step 1, above.

Play along on the keyboard with the

accompaniment.

Using the Current Scale Notes for Auto

Accompaniments

Flashes

O T H E R

A c o m

S c l

Using Music Preset

I L o v e H e r

Preset number Preset name

Lights

CDP230R_e.book 55 ページ２０１４年２月１９日　水曜日　午後５時１１分

Other Useful Digital Piano Functions

EN-56

The Arpeggiator makes it possible to play an arpeggio pattern

automatically. There are 90 different arpeggio patterns from

which to choose in order to match the music you are playing.

• The Arpeggiator is controlled using the same button ct as

Auto Harmonize (page EN-42). Because of this, these two

functions cannot be used at the same time.

Hold down ct until the Auto Harmonize or

Arpeggiator type number and type name appear

on the display.

• If you do not perform any operation for a few seconds,

the display will return to the previous screen

automatically.

Use the br (10-key) [–] and [+] keys to select

the Arpeggiator type you want.

• 001 through 012 are Auto Harmonize types (page

EN-42). Do not select them when using the

Arpeggiator.

Press ct to turn on Arpeggiator.

Playing a chord on the keyboard will start arpeggio play.

• Press ct again to turn off Arpeggiator.

• The tempo setting of the Arpeggiator is the same as that set

for the metronome (page EN-12).

Use the following procedure when you want an arpeggio

pattern to keep playing after you release the keyboard keys.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“OTHER” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Press the br (10-key) [+] key to select the ON

setting.

Using the Arpeggiator

D u e t 1

Type number Type name

1 U

Speed (The number of arpeggio notes per beat)

Octave

1... Uses the actual notes played.

2... Uses the actual notes played plus the same notes one octave.

4... Uses the actual notes played plus the same notes three octaves.

Type

number Type Name Description

013-030 Up Rising

031-048 Down Falling

049-066 U/D A

Repeat pattern alternating

between rising and falling

(Type A)

067-084 U/D B

Repeat pattern alternating

between rising and falling

(Type B)

085-102 Random Random arrangement of

notes of the pressed keys

Sustaining an Arpeggio (Arpeggiator Hold)

St .GrPno

Lit when on

A r

H l d

CDP230R_e.book 56 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Other Useful Digital Piano Functions

EN-57

You can use the following procedure to delete user song data

stored as song numbers 153 through 162.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“DELETE” (page EN-7).

Press the br (10-key) [9] (ENTER) key.

Press the br (10-key) [6] (I) key twice.

Use the br (10-key) [–] and [+] keys to select

the user song you want to delete.

Press the br (10-key) [9] (ENTER) key.

This displays a delete confirmation message.

Press the br (10-key) [+] (YES) key.

After the delete procedure is complete, “Complete” will

appear followed by the screen in step 2 of the above

procedure.

• To cancel the delete operation, press [–] (NO) or [7]

(EXIT) in place of [+] (YES).

Use the following procedure when you want to delete sampled

sounds, user songs and all other data, except for recorded

songs, currently in Digital Piano memory.

• Performing this procedure also will delete protected

sampled sound data (page EN-25). It is recommended

that you save important data to a memory card (page

EN-58) or your computer’s hard disk (page EN-64).

• This operation does not delete recorded song data.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“DELETE” (page EN-7).

Press the br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “All Data”.

Press the br (10-key) [9] (ENTER) key.

This displays a delete confirmation message.

Press the br (10-key) [+] (YES) key.

After the delete procedure is complete, “Complete” will

appear followed by the screen in step 2 of the above

procedure.

• To cancel the delete operation, press [–] (NO) or [7]

(EXIT) in place of [+] (YES).

Deleting User Song Data

Used memory

(Unit: Kbytes) Remaining

memory capacity

D E L E T E

Flashes

U S E R S O N G

User song name

S u r e ?

Deleting All Data in Digital Piano

Memory

Used memory

(Unit: Kbytes)

Remaining

memory capacity

D E L E T E

Flashes

A l l D a t a

Flashes

S u r e ?

CDP230R_e.book 57 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-58

Using a Memory Card

You can save Digital Piano user area data to a memory card

and load data from a memory card to Digital Piano memory.

You also can play music files (MIDI files) stored on a memory

card on the Digital Piano.

• Use an SD memory card or an SDHC

memory card with a capacity of 32GB

or less. Use of a memory card with a

capacity that is greater than 32GB

and other types of memory cards is

not supported.

• SDHC Logo is a trademark of SD-3C, LLC.

User data that can be saved and loaded

• Use only memory cards. Operation is not guaranteed

when any other type of memory card is used.

• When using a memory card, make sure you observe all

of the precautions in the instructions that come with it.

• Memory cards have a write-protect switch that you can

use to protect against accidental deletion of data.

• Avoid using a memory card under the following

conditions. Such conditions can corrupt data stored on

the memory card.

– Areas subjected to high temperature, high humidity,

and corrosive gas

– Areas subjected to strong electrostatic charge and

digital noise

• Never touch the contacts of a memory card when

loading it or removing it from the Digital Piano.

• While data is being stored to or recalled from a memory

card, never perform any other Digital Piano operation

or remove the memory card. Doing so can corrupt the

data on the card and damage the card slot.

• Never insert anything besides a memory card into the

card slot. Doing so creates the risk of malfunction.

• Electrostatic charge discharging from your fingers or

the memory card to the card slot can cause

malfunction of the Digital Piano. If this happens, turn

the Digital Piano off and then back on again.

• A memory card can become quite warm after very long

use in the memory card slot. This is normal and does

not indicate malfunction.

bqbq brbr ckck

Data Type Description File Name

Extension

Sampled sound

(page EN-19) Sampled sound data TW7

DW7*1

User rhythms

(page EN-44)

Edited Auto

Accompaniment data AC7

User songs

(page EN-29)

Song data imported from

an external device (cannot

be saved to a memory

card).

CM2

MID*2

Recorded songs

(page EN-49) Recorded song data SP7

SL7*3

Registration

setups

(page EN-47)

Tone and rhythm setup

settings RM7

All data Above data AL7

*1: Sampled drum set sounds

*2: Standard MIDI file (format 0, 1)

*3: Data recorded playing along with built-in song

Memory Card and Card Slot

Precautions

CDP230R_e.book 58 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using a Memory Card

EN-59

• Note that the memory card must be oriented correctly

when you insert it into the memory card slot. Trying to

force the memory card into the slot can damage the

card and the slot.

With the top of the memory card facing

upwards (so you can see it), carefully insert the

card into the Digital Piano’s memory card slot

(dp) until stops with a click.

Press the memory card into the card slot and

then release it.

This will cause the card to disengage and eject partially.

Pull the card out of the slot.

• Before using a memory card, first be sure to format it

on the Digital Piano.

• Before performing the procedure below, check to make

sure that the memory card does not contain any data

you might need.

• The memory card format performed by the Digital

Piano is a “quick format”. If you want to completely

delete all of the data on the card, format it on your

computer or using some other device.

Insert the memory card you want to format into

the Digital Piano’s card slot.

• Make sure that the write-protect switch of the memory

card is not in the write-protect position.

Press bq and ck (FUNCTION) at the same time.

Press the br (10-key) [9] (ENTER) key.

This will display the format confirmation screen.

Press the br (10-key) [+] (YES) key.

The message “Pls wait” will appear on the display. Do not

perform any operation while this message is displayed.

“Complete” appears on the display after formatting is

complete.

• To cancel the format operation, press [–] (NO) or [7]

(EXIT) in place of [+] (YES).

Inserting and Removing a

Memory Card

Front

Formatting a Memory Card

F o r m a t

S u r e ?

P l s w a i t

C o m

l e t e

CDP230R_e.book 59 ページ２０１４年２月１９日　水曜日　午後５時１１分

Using a Memory Card

EN-60

Use the following procedure to save Digital Piano data to a

memory card.

On the Digital Piano, select the data you want to

save as described below.

• You cannot save a user song (song data loaded from

an external device) to a memory card.

• See page EN-58 for information about data types.

Insert a memory card into the Digital Piano’s

card slot.

Hold down bq until the screen shown below

appears on the display.

• To cancel data save, press bq again.

Use the br (10-key) [4] (U) and [6] (I) keys to

display one of the settings shown below.

• You also could use [–] and [+].

Saving a recording made while playing along with a built-in

song in SMF 0 format will save only what was played on the

keyboard.

Press the br (10-key) [9] (ENTER) key.

• Enter the file name of the data you are saving. Use the

br (10-key) [4] (U) and [6] (I) keys to move the cursor

to the character you want to change, and then use [+]

and [–] to change the character.

• Pressing [7] (EXIT) will return to the screen that was

displayed before you pressed [9] (ENTER).

Press the br (10-key) [9] (ENTER) key.

This will save the data to the memory card.

• If there is a file with the same name already on the

memory card, a message will appear asking if you want

to overwrite it. Press the br (10-key) [+] (YES) key to

overwrite, or [–] (NO) or [7] (EXIT) to cancel.

Saving Digital Piano Data to a

Memory Card

To save this type

of data Do this

Sampled sound Select the tone number of the sampled

sound you want to save.

User rhythm Select the rhythm number of the user

rhythm you want to save.

Recorded song Select the song you want to save and

put the Digital Piano in playback

standby.

Registration data Select one of the Digital Piano’s default

built in tones or rhythms.

All data

To save this data Display this screen

Sampled sound “SAv” “SmplTone”

User rhythm “SAv” “UserRhy.”

Recorded song “SAv” “Rec.Song”

Recorded song

(SMF 0 format) “SAv” “SMF 0”

Registration data “SAv” “Regist.”

All data “SAv” “All Data”

U S E R N A M E

Flashes

C o m

l e t e

R e

l a c e ?

CDP230R_e.book 60 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using a Memory Card

EN-61

• You can input the following characters in a file name.

• The Digital Piano displays the “~” character as “3”.

■Memory Card Data (File) Storage Locations

The above procedure stores Digital Piano data in a folder

named “MUSICDAT” on the memory card.

• The “MUSICDAT” folder is created automatically when you

format the memory card on the Digital Piano (page

EN-59).

• If you store a file in any location other than inside the

“MUSICDAT” folder, you will not be able to recall, delete, or

play the file on the Digital Piano. You also will not be able to

recall, delete, or play any file you store inside of a subfolder

you create inside the “MUSICDAT” folder.

• The message “No File” will appear on the display if you try

to perform a recall, delete, or play operation while there is

no file inside the “MUSICDAT” folder.

Use the following procedure to load data from a memory card

into Digital Piano memory.

• Whenever you copy a file to the memory card that you

plan to recall on the Digital Piano, be sure to store the

file in the memory card’s “MUSICDAT” folder.

On the Digital Piano, select the data you want to

load as described below.

Insert the memory card that contains the data

into the Digital Piano’s card slot.

Hold down bq until the screen shown below

appears on the display.

• To cancel data load, press bq again.

Use the br (10-key) [4] (U) and [6] (I) keys to

display one of the settings shown below.

• You also could use [–] and [+].

}

{

)

(

Loading Data from a Memory

Card into Digital Piano Memory

To load this type

of data Do this

Sampled sound Select the tone number of the sampled

sound you want to load.

User rhythm Select the rhythm number of the user

rhythm you want to load.

User song Select the song number of the song you

want to load.

Recorded song Select the song you want to load and

put the Digital Piano in playback

standby.

Registration data Select one of the Digital Piano’s default

built in tones, songs, rhythms, etc.

All data

To load this data Display this screen

Sampled sound “Lod” “SmplTone”

User rhythm “Lod” “UserRhy.”

User song “Lod” “UserSong”

Recorded song “Lod” “Rec.Song”

Registration data “Lod” “Regist.”

All data “Lod” “All Data”

CDP230R_e.book 61 ページ２０１４年２月１９日　水曜日　午後５時１１分

Using a Memory Card

EN-62

Press the br (10-key) [9] (ENTER) key.

• Pressing [7] (EXIT) will return to the screen that was

displayed before you pressed [9] (ENTER).

Use the br (10-key) [–] and [+] keys to select

the data (file) you want to load.

Press the br (10-key) [9] (ENTER) key.

This will load the data into Digital Piano memory.

• If there is already data stored in the user area where

you are trying to load data, an overwrite confirmation

message will appear. Press the br (10-key) [+] (YES)

key to overwrite, or [–] (NO) or [7] (EXIT) key to cancel.

Use the following procedure to delete data saved on a

memory card.

On the Digital Piano, select the data you want to

delete as described below.

Insert a memory card into the Digital Piano’s

card slot.

Hold down bq until the screen shown below

appears on the display.

• To cancel data delete, press bq again.

Use the br (10-key) [4] (U) and [6] (I) keys to

display one of the settings shown below.

• You also could use [–] and [+].

* * * * * * * *

Flashes

C o m

l e t e

R e

l a c e ?

Deleting Data from a Memory

Card

To delete this

type of data Do this

Sampled sound Select the tone number of the sampled

sound.

User rhythm Select the rhythm number of the user

rhythm.

User song Select the song number of the user

song.

Recorded song Select the song and put the Digital

Piano in playback standby.

Registration data Select one of the Digital Piano’s default

built in tones, songs.

All data

To delete this type

of data Display this screen

Sampled sound “dEL” “SmplTone”

User rhythm “dEL” “UserRhy.”

User song “dEL” “UserSong”

Recorded song “dEL” “Rec.Song”

Registration data “dEL” “Regist.”

All data “dEL” “All Data”

CDP230R_e.book 62 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Using a Memory Card

EN-63

Press the br (10-key) [9] (ENTER) key.

• Pressing [7] (EXIT) will return to the screen that was

displayed before you pressed [9] (ENTER).

Use the br (10-key) [–] and [+] keys to select

the number of the data (file) you want to delete.

Press the br (10-key) [9] (ENTER) key.

This will display the delete confirmation screen.

Press the br (10-key) [+] (YES) key.

• To cancel the delete operation, press [–] (NO) or [7]

(EXIT) in place of [+] (YES).

You can use the following procedure to play back user song

data (page EN-58) directly from a memory card.

• Whenever you copy a file to the memory card that you

plan to play on the Digital Piano, be sure to store the

file in the memory card’s “MUSICDAT” folder (page

EN-61).

Insert the memory card that contains the data

into the Digital Piano’s card slot.

Press bq.

This will display the file numbers and song names for the

data stored on the display.

Use br (10-key) to select the song you want to

play.

Press 7.

This will start playback.

• Each press of 7 starts and stops playback.

For information about memory card error messages, see page

EN-73.

* * * * * * * *

Flashes

S u r e ?

C o m

l e t e

Playing Back Data from a Memory

Card

Memory Card Error Messages

CDP230R_e.book 63 ページ２０１４年２月１９日　水曜日　午後５時１１分

EN-64

Connecting External Devices

You can connect the Digital Piano to a computer and

exchange MIDI data between them. You can send play data

from the Digital Piano to commercially available music

software running on your computer, or you can send MIDI

data from your computer to the Digital Piano for playback.

The following shows the minimum computer system

requirements for sending and receiving MIDI data. Check to

make sure that your computer complies with these

requirements before connecting the Digital Piano to it.

• Operating System

•USB port

• Never connect to a computer that does not conform to

the above requirements. Doing so can cause problems

with your computer.

• Make sure you follow the steps of the procedure below

exactly. Connecting incorrectly can make data send

and receive impossible.

Turn off the Digital Piano and then start up your

computer.

• Do not start up the music software on your computer

yet!

After starting up your computer, use a

commercially available USB cable to connect it

to the Digital Piano.

Turn on the Digital Piano.

• If this is the first time you are connecting the Digital

Piano to your computer, the driver software required to

send and receive data will be installed on your

computer automatically.

Start up commercially available music software

on your computer.

brbr ckck

Connecting to a Computer

Minimum Computer System Requirements

Windows® XP (SP2 or later) *1

Windows Vista® *2

Windows® 7 *3

Windows® 8 *4

Mac OS® X

(10.3.9, 10.4.11, 10.5.X, 10.6.X, 10.7.X, 10.8.X)

*1: Windows XP Home Edition

Windows XP Professional (32-bit)

*2: Windows Vista (32-bit)

*3: Windows 7 (32-bit, 64-bit)

*4: Windows 8 (32-bit, 64-bit)

Connecting the Digital Piano to Your

Computer

Computer USB port

A connector

B connector

Digital Piano USB port

USB cable

(A-B type)

CDP230R_e.book 64 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Connecting External Devices

EN-65

Configure the music software settings to select

one of the following as the MIDI device.

• For information about how to select the MIDI device,

see the user documentation that comes with the music

software you are using.

• Be sure to turn on the Digital Piano first before starting

up your computer’s music software.

• Once you are able to connect successfully, there is no

problem with leaving the USB cable connected when you

turn off your computer and/or Digital Piano.

• This Digital Piano conforms to General MIDI Level 1 (GM).

• For detailed specifications and connections that apply to

MIDI data send and receive by this Digital Piano, see the

latest support information provided by the website at the

following URL.

http://world.casio.com/

A keyboard channel is the channel used for sending Digital

Piano data to a computer. You can select the channel you

want for sending Digital Piano data to a computer.

• The keyboard channel setting range is 01 to 16.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“MIDI” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [–] and [+] keys to change

the keyboard channel.

The navigate channels can be used to display only the notes

of a particular channel (part) as on-screen guide information

from among the note information of a tune sent from the

computer.

■Specifying the Navigate Channels

From among the 16 available channels (numbered 1 to 16),

you can specify any two neighboring channels (such as 05

and 06) as navigate channels. The smaller numbered channel

is the navigate (L) channel, while the larger numbered

channel is the navigate (R) channel. Specifying the navigate

(R) channel will automatically configure the navigate (L)

channel as well.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“MIDI” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “Navi. Ch”.

CASIO USB-MIDI : For Windows Vista, Windows 7,

Windows 8, Mac OS X

USB Audio Device : For Windows XP

MIDI Settings

Keyboard Channel

Navigate Channels

M I D I

Flashes

K e

b d C h

N a v i . C h

CDP230R_e.book 65 ページ２０１４年２月１９日　水曜日　午後５時１１分

Connecting External Devices

EN-66

Use the br (10-key) to specify the navigate (R)

channel.

This also will automatically configure the next lower

channel number as the navigate (L) channel.

■Turning Off the Navigate Channel Sound and

Playing the Part on the Keyboard

You can turn off the sound on one or both of the navigate

channels and play the cancelled part on the keyboard

yourself.

Press 8 to select the channel setting you want

to turn off.

Each press of 8 cycles through settings (1) through (4)

described below.

• If you turn off one channel, you can play the cancelled

part on the keyboard using the same tone as the

channel you turned off. If you turn off both channels

(option (3)), what you play on the keyboard sounds

using the tone of the navigate (R) channel.

There are times when exchanging data with a computer when

you may not want the Digital Piano to sound notes you play on

its keyboard. The local control setting lets you do just that.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“MIDI” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “Local”.

Use the br (10-key) [–] and [+] keys to specify

the local control setting.

Enabling the Accomp Out setting causes Auto

Accompaniment data to be sent to the computer.

Press ck (FUNCTION) and then use the br

(10-key) [4] (U) and [6] (I) keys to display

“MIDI” (page EN-7).

Press br (10-key) [9] (ENTER) key.

Use the br (10-key) [4] (U) and [6] (I) keys to

display “AcompOut”.

Use the br (10-key) [–] and [+] keys to turn

Accomp Out on or off.

Navigate (L)

Channel

Navigate (R)

Channel

Sound

On-

screen

Guide

Sound

On-

screen

Guide

(1) R only displayed {××{

(2) L only displayed × {{ ×

(3) LR displayed × {×{

(4) LR nor displayed {{{{

Selected channel indicator appears.

Local Control

Accomp Out

L o c a l

A c o m

O u t

CDP230R_e.book 66 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Connecting External Devices

EN-67

You can transfer sampled sounds, recorded songs, and other

data in Digital Piano memory to a computer for storage. You

also can load standard MIDI file (SMF) data, and Auto

Accompaniment data you download from the CASIO website

to the Digital Piano, which greatly expands the Song Bank

songs and Auto Accompaniment patterns available to you.

A special Data Manager application is required in order to

transfer data to and from the Digital Piano.

The same types of data that you can store to or recall from a

memory card (page EN-58) can be transferred to and from the

Digital Piano. Note, that recorded song data can be

transferred to a computer in the Digital Piano’s native format

only. You cannot save recorded song data to a computer as a

standard MIDI file (SMF format).

Go to the CASIO WORLDWIDE site at the

following URL.

http://world.casio.com/

At the site, select a geographic area or country.

After accessing the area site, navigate to the

minimum computer system requirements for

Data Manager for this product.

• You should be able to find a link to Data Manager

information on the product introduction page of this

product. If you cannot find such a link, use the search

form of the area site where you are located to enter the

model name of this product and search for it.

• Note that site contents are subject to change without

notice.

Check if your computer system complies with

the minimum requirements for Data Manager.

Download Data Manager and its user’s guide to

your computer.

Follow the procedure in the user’s guide that

you downloaded in step 5 to install and use

Data Manager.

• You can download accompaniment data from the

Internet Data Expansion system of the CASIO MUSIC

SITE (http://music.casio.com/) and load it into the

memory of this Digital Piano. Note that there is not any

accompaniment data intended specifically for this

model, so you should use data for other models.

• Since the accompaniment data is for other models, you

may experience some abnormalities when playing it on this

model.

• For information about accompaniment data compatibility

between models, see the Data Manager user’s guide you

download in step 5 of the above procedure.

Storing and Loading Digital Piano

Memory Data

Data Types Supported for Data Transfer

Downloading Data Manager

CDP230R_e.book 67 ページ２０１４年２月１９日　水曜日　午後５時１１分

Connecting External Devices

EN-68

This Digital Piano can be connected to commercially available

stereo, amplifier, or recording equipment, to a portable audio

player or other equipment.

Connection requires commercially available connecting cords,

supplied by you. The connecting cords should have a stereo

standard plug on one end and a plug that matches the

configuration of the external device on the other end.

• Turn off the external device when making connections.

After connecting, turn down the Digital Piano and

external device volume levels whenever turning power

on or off.

• After connecting, turn on the Digital Piano and then the

external device.

• If Digital Piano notes sound distorted when they are

sounded from external audio equipment, lower the

Digital Piano’s volume setting.

Connection requires commercially available connecting cords,

supplied by you. The connecting cords should have a stereo

mini plug on one end and a plug that matches the

configuration of the external device on the other end.

• Turn off the Digital Piano when making connections.

After connecting, turn down the Digital Piano and

external device volume levels whenever turning power

on or off.

• After connecting, turn on the external device and then

the Digital Piano.

• If notes are distorted when they are sounded on the

external device, lower the volume setting of the

external device.

Connecting to Audio Equipment

Outputting Digital Piano Notes to Audio

Equipment

Playing an External Device from the Digital

Piano

PHONES/OUTPUT jack

Stereo standard plug

Audio equipment, amplifier,

etc.

Stereo mini plug

AUDIO IN jack

Portable audio player, etc.

CDP230R_e.book 68 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

EN-69

Reference

Troubleshooting

Symptom Action

Included Accessories

I can’t find something that should be here. Carefully check inside all of the packing materials.

Power Requirements

Power will not turned on. Correctly attach the AC adaptor (page EN-9).

The display lights up momentarily but power does

not turn on when I press the P (POWER) button

(2).

Press 2 firmly and completely to turn on power.

Display

On-screen keyboard keys or notes remain on the

display.

A Step Up Lesson is in progress and the Digital Piano is waiting for

you to play the next note in the song. To stop this from happening,

cancel the lesson (page EN-32).

Screen contents are visible only from straight ahead. This is dues to production limitations. It does not indicate malfunction.

Sound

Nothing happens when I press any keyboard key. • Adjust the volume setting (page EN-10).

• If there is no sampled sound in memory, nothing will play if you

press a keyboard key while a tone in the range of 701 to 705 is

selected (page EN-19).

Nothing happens or notes do not play normally when

I play notes on the left side of the keyboard.

Press 8 to disable chord input in the accompaniment keyboard area

(page EN-38).

Nothing happens when I start an Auto

Accompaniment.

• With rhythms 191 to 200, nothing will sound until you play a chord

on the keyboard. Try playing a chord (page EN-38).

• Check and adjust the accompaniment volume setting (page

EN-41).

• If there is no user rhythm stored in memory, Auto Accompaniment

will not start when you press 7 while a rhythm in the range of 201

to 210 is selected (page EN-44).

• Turn power off and then back on to initialize all Digital Piano

settings (page EN-10).

Nothing happens when I start playback of a built-in

song.

• It takes a little time after you press the button until the song starts to

play. Wait for a moment for the song to start.

• Check and adjust the song volume (page EN-28).

• If there is no user song stored in memory, song playback will not

start when you press 7 while a song in the range of 153 to 162 is

selected (page EN-29).

• Turn power off and then back on to initialize all Digital Piano

settings (page EN-10).

The metronome does not sound. • Check and adjust the accompaniment volume setting (page

EN-41).

• Check and adjust the song volume (page EN-28).

• Turn power off and then back on to initialize all Digital Piano

settings (page EN-10).

Notes keep sounding, without stopping. Turn power off and then back on to initialize all Digital Piano settings

(page EN-10).

Some notes are cut off while they are playing. Notes are cut off whenever the number of notes being sounded

exceeds the maximum polyphony value of 48 (24 for some tones).

This does not indicate malfunction.

The volume or tone setting I made has changed. • Adjust the volume setting (page EN-10).

• Turn power off and then back on to initialize all Digital Piano

settings (page EN-10).

CDP230R_e.book 69 ページ２０１４年２月１９日　水曜日　午後５時１１分

Reference

EN-70

Output volume does not change even though is

change my keyboard touch.

• Change the Touch Response setting (page EN-11).

• Turn power off and then back on to initialize all Digital Piano

settings (page EN-10).

In certain keyboard ranges, the volume and tone

quality sound are slightly different from those in other

keyboard ranges.

This is due to system limitations. It does not indicate malfunction.

With some tones, octaves do not change at the far

ends of the keyboard.

This is due to system limitations. It does not indicate malfunction.

The pitch of the notes does not match other

accompanying instruments or sounds strange when

played long with other instruments.

• Check and adjust the transpose (page EN-16) and tuning settings

(page EN-16).

• Turn power off and then back on to initialize all Digital Piano

settings (page EN-10).

The reverb of notes seems to change suddenly. • Check and adjust the reverb setting (page EN-15).

• Turn power off and then back on to initialize all Digital Piano

settings (page EN-10).

Operation

When I perform a skip forward or skip back

operation, the skip operation moves multiple song

measures instead of only a single measure.

While song playback is stopped or a Step Up Lesson is in progress,

skip forward and skip back operations are performed in phrase units

(page EN-27).

Tone, rhythm, and other settings revert to their initial

defaults whenever you turn on the Digital Piano.

Though Digital Piano settings reset when you turn off the Digital

Piano, you can save setups to registration memory for instant recall

whenever you need them (page EN-47).

Computer Connection

I can’t exchange data between the Digital Piano and

a computer.

• Check to make sure that the USB cable is connected to the Digital

Piano and computer, and that the device is selected correctly with

your computer’s music software settings (page EN-64).

• Turn off the Digital Piano and then exit the music software on your

computer. Next, turn the Digital Piano back on and then restart the

music software on your computer.

Symptom Action

CDP230R_e.book 70 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Reference

EN-71

Specifications

Model CDP-230RBK/CDP-230RSR

Keyboard 88-key piano keyboard

Touch Response 3 types, Off

Maximum Polyphony 48 notes (24 for certain tones)

Tones

Built-in Tones 700

Sampling Tones Up to 8 (Melody Sampling: 5, Drum Sampling: 3)*

Up to 10 seconds

Functions Layer, Split, Piano/Organ button

Hall On, Off

Reverb 1 to 10, Off

Chorus 1 to 5, Off

Metronome

Beats per Measure 0, 1 to 9

Tempo Range 30 to 255

Song Bank

Built-in Songs 152

User Songs Up to 10*

Step Up Lesson

Lessons 4 (Listen, Watch, Remember, Auto)

Lesson Part L, R, LR

Functions Repeat, Voice Fingering Guide, Note Guide, Performance Evaluation

Music Challenge 20 notes

Auto Accompaniment

Built-in Rhythms 200

User Rhythms Up to 10 (Accompaniment Edit)*

Chord Book Function Chord Guide

Registration 32 (4 setups × 8 banks)

Recorder Real-time recording, playback

Keyboard Play 5 songs, 6 tracks

Playing Along with a

Built-in Songs 1 song (L, R, LR)

Memory Capacity Approximately 12,000 notes (total for 6 songs)

Other Functions

Transpose ±1 octaves (–12 to +12 semitones)

Octave Shift Upper/Lower ±2 octaves

Tuning A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)

Preset Scales 17

Music Preset 305

One Touch Preset 200

Auto Harmonize 12 types

Arpeggiator 90 types

MIDI 16 multi-timbre received, GM Level 1 standard

Musical Information Function Tone, Rhythm, Song Bank numbers and names, staff notation, fingering, pedal operation,

tempo, measure and beat number, chord name, etc.

Pitch Bend Wheel

Pitch Bend Range 0 to 12 semitones

Memory Cards

Supported Memory Cards SD or SDHC memory cards, 32GB or less

Functions SMF playback, file storage, file recall, file delete, card format

CDP230R_e.book 71 ページ２０１４年２月１９日　水曜日　午後５時１１分

Reference

EN-72

• Design and specifications are subject to change without notice.

*This data is stored in a shared memory area with a total capacity of approximately 320Kbytes (1Kbyte = 1,024bytes).

Be sure to read and observe the following operating precautions.

■Location

Avoid the following locations for this product.

• Areas exposed to direct sunlight and high humidity

• Areas subjected to temperature extremes

• Near a radio, TV, video deck, or tuner

The above devices will not cause malfunction of the product, but interference from the product can cause audio or video

interference of a nearby device.

■User Maintenance

• Never use benzine, alcohol, thinner, or other chemical agents to clean the product.

• To clean the product or its keyboard, wipe with a soft cloth moistened in a weak solution of water and a mild neutral detergent.

Wring all excess moisture from the cloth before wiping.

■Included and Optional Accessories

Use only accessories that are specified for use with this product. Use of unauthorized accessories creates the risk of fire, electric

shock, and personal injury.

■Weld Lines

Lines may be visible on the exterior of the product. These are “weld lines” that result from the plastic molding process. They are not

cracks or scratches.

■Musical Instrument Etiquette

Always be aware of others around you whenever using this product. Be especially careful when playing late at night to keep the

volume at levels that do not disturb others. Other steps you can take when playing late at night are closing the window and using

headphones.

Inputs/Outputs

USB port TYPE B

Sustain/Assignable jack Standard jack (sustain, sostenuto, soft, rhythm)

Phones/Output jack Stereo standard jack

Output Impedance: 3Ω, Output Voltage: 1.5V (RMS) MAX

Audio In jack Stereo mini jack

Input Impedance: 40kΩ, Input Sensitivity: 200mV

Mic In/Sampling jack Standard jack

Input Impedance: 3kΩ, Input Sensitivity: 10mV

Power Jack 12V DC

Power Supply

AC Adaptor AD-A12150LW

• The AC adaptor can be used safely in areas up to 4,000 meters above sea level.

Auto Power Off 30 minutes after last key operation

Speakers (12cm × 6cm oval) × 2

Output 8W + 8W

Power Consumption 12V = 18W

Dimensions 132.2 × 28.6 × 12.9cm (52 1/16 × 11 1/4 × 5 1/16 inch)

Weight Approximately 11.3kg (24.9 lbs)

Operating Precautions

CDP230R_e.book 72 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Reference

EN-73

Error Messages

Display

Message Cause Action

Err CardFull There is not enough room available on the memory

card.

• Delete some of the files on the memory card to make

room for new data (page EN-62).

• Use a different memory card.

Err Card R/W The memory card is damaged. Use a different memory card.

Err Convert There is not enough unused memory available to save

recorded song data to a memory card as an SMF 0

format file.

Delete some or all of the following user data from memory

to make room for new data.

Sampled sounds (page EN-18), user rhythms (page

EN-44), user songs (page EN-29)

Err Exist A sampled drum set sound cannot be copied (page

EN-23) to a keyboard key because the key already has

a sampled sound assigned to it.

• Delete the sampled sound that is currently assigned to

the key you are copying to (page EN-23).

• Copy the sampled sound to another key that does not

yet have a sampled sound assigned to it.

Err Format 1. The format of the memory card is not compatible

with this Digital Piano.

1. Format the memory card (page EN-59).

2. The memory card is damaged. 2. Use a different memory card.

3. You are trying to use an SDXC card. 3. SDXC cards are not supported. Use an SD or SDHC

memory card.

Err Limit The tone number you selected before starting sampling

already has the allowable maximum of eight sampled

sounds assigned to it.

• Delete the one or more of the sampled sounds

currently assigned to the tone number (page EN-23).

• Select another tone number that has less than eight

sampled sounds currently assigned to it (page EN-21).

Err Mem Full 1. There is not enough memory available to play back

song data from a memory card.

Delete some or all of the following user data from memory

to make room for new data.

Sampled sounds (page EN-18), user rhythms (page

EN-44), user songs (page EN-29)

2. There is not enough memory available for sampling

or Auto Accompaniment editing.

Err No Card 1. The memory card is not set correctly in the card slot. 1. Remove the memory card and reinsert it correctly

(page EN-59).

2. The memory card was removed part way through a

card access operation.

2. Never remove a memory card from the card slot while

a card access operation is in progress.

Err No Data There is no data in the selected user area (tone,

rhythm, song number, etc.)

Select a Digital Piano user area that contains data.

Err No File There is no folder named “MUSICDAT” on the memory

card.

• Use a computer to create a folder named “MUSICDAT”

on the memory card (page EN-61).

• Format the memory card on the Digital Piano (page

EN-59).

Err NotSMF01 You are attempting to play back SMF Format 2 song

data.

Playback of SMF Format 0 or 1 only is supported.

Err Protect 1. The memory card is write protected. 1. Adjust the memory card’s write protect switch to

enable data storage.

2. Sampled sounds (Tone Numbers 701 to 708) are

protected.

2. Unprotect one or more of the sampled sounds, which

will allow it to be overwritten or deleted.

Err ReadOnly You are attempting to save a file using the same name

as an existing read-only file.

• Save the new file to a different card or use another

name.

• Remove the read-only attribute of the exiting file on the

memory card and try again.

• Use a different memory card.

Err SizeOver 1. The song data on the memory it too big to play back. 1. This Digital Piano can play back song data files with a

maximum size of about 320Kbytes.

2. Auto Accompaniment editing cannot be performed

because the accompaniment pattern or instrument

part data is too large.

2. Select a different accompaniment pattern or

instrument parts.

Err WrongDat 1. The data on the memory card is corrupted. —

2. The data on the memory card is a type that is not

supported by this Digital Piano.

CDP230R_e.book 73 ページ２０１４年２月１９日　水曜日　午後５時１１分

Reference

EN-74

WORLD

001 TWINKLE TWINKLE LITTLE STAR

002 LIGHTLY ROW

003 LONG LONG AGO

004 ON TOP OF OLD SMOKEY

005 SAKURA SAKURA

006 WHEN THE SAINTS GO MARCHING IN

007 AMAZING GRACE

008 AULD LANG SYNE

009 COME BIRDS

010 DID YOU EVER SEE A LASSIE?

011 MICHAEL ROW THE BOAT ASHORE

012 DANNY BOY

013 MY BONNIE

014 HOME SWEET HOME

015 AURA LEE

016 HOME ON THE RANGE

017 ALOHA OE

018 SANTA LUCIA

019 FURUSATO

020 GREENSLEEVES

021 JOSHUA FOUGHT THE BATTLE OF JERICHO

022 THE MUFFIN MAN

023 LONDON BRIDGE

024 UNDER THE SPREADING CHESTNUT TREE

025 SIPPIN’ CIDER THROUGH A STRAW

026 GRANDFATHER’S CLOCK

027 ANNIE LAURIE

028 BEAUTIFUL DREAMER

029 IF YOU’RE HAPPY AND YOU KNOW IT, CLAP YOUR

HANDS

030 MY DARLING CLEMENTINE

031 LITTLE BROWN JUG

032 HOUSE OF THE RISING SUN

033 SHE WORE A YELLOW RIBBON

034 YANKEE DOODLE

035 MY OLD KENTUCKY HOME

036 SZLA DZIEWECZKA

037 TROIKA

038 WALTZING MATILDA

039 ON THE BRIDGE OF AVIGNON

040 I’VE BEEN WORKING ON THE RAILROAD

041 OH! SUSANNA

042 CAMPTOWN RACES

043 JEANNIE WITH THE LIGHT BROWN HAIR

044 TURKEY IN THE STRAW

045 JAMAICA FAREWELL

EVENT

046 SILENT NIGHT

047 WE WISH YOU A MERRY CHRISTMAS

048 JINGLE BELLS

049 JOY TO THE WORLD

050 O CHRISTMAS TREE

PIANO/CLASSICS

051 MARY HAD A LITTLE LAMB

052 LE CYGNE FROM “LE CARNAVAL DES ANIMAUX”

053 JE TE VEUX

054 SONATA op.13 “PATHÉTIQUE” 2nd Mov.

055 HEIDENRÖSLEIN

Song List

SONG BANK

056 AIR FROM “SUITE no.3”

057 SPRING FROM “THE FOUR SEASONS”

058 HABANERA FROM “CARMEN”

059 BRINDISI FROM “LA TRAVIATA”

060 HUNGARIAN DANCES no.5

061 MINUET IN G MAJOR

062 MUSETTE IN D MAJOR

063 GAVOTTE (GOSSEC)

064 ARABESQUE (BURGMÜLLER)

065 CHOPSTICKS

066 DECK THE HALL

067 ODE TO JOY

068 AVE MARIA (GOUNOD)

069 SONATINA op.36 no.1 1st Mov.

070 PRELUDE op.28 no.7 (CHOPIN)

071 RÊVERIE

072 GYMNOPÉDIES no.1

073 GOING HOME FROM “FROM THE NEW WORLD”

074 FÜR ELISE

075 TURKISH MARCH (MOZART)

076 SONATA op.27 no.2 “MOONLIGHT” 1st Mov.

077 ETUDE op.10 no.3 “CHANSON DE L’ADIEU”

078 THE ENTERTAINER

079 WEDDING MARCH FROM “MIDSUMMER NIGHT’S

DREAM”

080 AMERICAN PATROL

081 FRÖHLICHER LANDMANN

082 LA CHEVALERESQUE

083 SONATA K.545 1st Mov.

084 LA PRIÈRE D’UNE VIERGE

085 VALSE op.64 no.1 “PETIT CHIEN”

086 LIEBESTRÄUME no.3

087 JESUS BLEIBET MEINE FREUDE

088 CANON (PACHELBEL)

089 SERENADE FROM “EINE KLEINE NACHTMUSIK”

090 MARCH FROM “THE NUTCRACKER”

091 INVENTIONEN no.1

092 PRAELUDIUM no.1 (J.S.BACH)

093 SONATINE op.20 no.1 1st Mov.

094 HUMORESKE (DVO ÁK)

095 DOLLY’S DREAMING AND AWAKENING

096 LA FILLE AUX CHEVEUX DE LIN

097 ARABESQUE no.1 (DEBUSSY)

098 TRÄUMEREI

099 MAPLE LEAF RAG

100 NOCTURNE op.9 no.2 (CHOPIN)

EXERCISE

101 - 150 EXERCISE I / II / III

DEMO TUNES

151 - 152 DEMO TUNES

USER SONGS

153 - 162 USER SONGS

CDP230R_e.book 74 ページ２０１４年２月１９日　水曜日　午後５時１１分

English

Reference

EN-75

In addition to the chords that can be fingered with Fingered 1

and Fingered 2, the following chords also are recognized.

• With Fingered 3, the lowest note fingered is interpreted as

the base note. Inverted forms are not supported.

• With Full Range Chord, when the lowest note fingered is a

certain distance from the neighboring note, the chord is

interpreted as a fraction chord.

• Unlike Fingered 1, 2, and 3, Full Range Chord requires

pressing of at least three keys to form a chord.

Fingering Guide

Fingered 1, Fingered 2 Chords

*1 With Fingered 2, interpreted as Am7.

*2 With Fingered 2, interpreted as Am7b5.

*3 Inverted form not supported in some cases.

Cdim

Caug *3

Csus4 *3

Csus2 *3

Cmadd9

CmM7

Cdim7 *3

C69 *3

C6 *1 *3

Cm6 *2 *3

Cm7 *3

CM7

Cm7b5 *3

C7sus4

Cadd9

C7b5 *3

Fingered 3, Full Range Chords

Ddim

Fm7

Gm7

add9

    

    

CDP230R_e.book 75 ページ２０１４年２月１９日　水曜日　午後５時１１分

Function Transmitted Recognized Remarks

Basic

Channel

1 - 16

Default

Changed

Note

Number

0 - 127

0 - 127 *1

0 - 127

True voice

After

Touch

Control

Change

Pitch Bender

Key’s

Ch’s

Velocity

9nH v = 1 - 127

9nH v = 0, 8nH v =**

9nH v = 1 - 127

9nH v = 0

Note ON

Note OFF

Mode

Mode 3

Default

Messages

Altered

0, 32

6, 38

Bank select

Modulation

Data entry

Volume

Pan

Expression

Hold 1

Sostenuto

Soft pedal

Rbd

Model: CDP-230R Version : 1.0

(MSB only)

**:no relation

**:sin relación

MIDI Implementation Chart

CDP230R_e.book 76 ページ２０１４年２月１９日　水曜日　午後５時１１分

Function Transmitted Recognized Remarks

Basic

Channel

1 - 16

Default

Changed

Note

Number

0 - 127

0 - 127 *1

0 - 127

True voice

Program

Change

0 - 127

:True #

After

Touch

Control

Change

Pitch Bender

System Exclusive

Key’s

Ch’s

Velocity

9nH v = 1 - 127

9nH v = 0, 8nH v =**

9nH v = 1 - 127

9nH v = 0

Note ON

Note OFF

Mode

Mode 3

Default

Messages

Altered

System

Common

: Song Pos

: Song Sel

: Tune

Aux

Messages

Remarks

: All sound OFF

: Reset all controller

: Local ON/OFF

: All notes OFF

: Active Sense

: Reset

System

Real Time

: Clock

: Commands

0, 32

6, 38

100, 101

Bank select

Modulation

Data entry

Volume

Pan

Expression

Hold 1

Sostenuto

Soft pedal

Reverb send *4

Chorus send

RPN LSB, MSB

Model: CDP-230R Version : 1.0

Mode 1 : OMNI ON, POLY

Mode 3 : OMNI OFF, POLY

Mode 2 : OMNI ON, MONO

Mode 4 : OMNI OFF, MONO

O : Yes

X : No

(MSB only)

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider

than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are

provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where

they exit from the apparatus.

11.Only use attachments/accessories specified by the manufacturer.

12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13.Unplug this apparatus during lightning storms or when unused for long periods of time.

14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been

dropped.

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be

placed on the apparatus.

The power indicator being unlit does not mean the apparatus is completely disconnected from the MAINS.

When you need to have the apparatus completely disconnected from the MAINS, you must unplug the power cord. For that

purpose, locate the apparatus in a way that secures easy access to the power cord.

Declaration of Conformity

Model Number: CDP-230R

Trade Name: CASIO COMPUTER CO., LTD.

Responsible party: CASIO AMERICA, INC.

Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801

Telephone number: 973-361-5400

This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

*1: Depends on tone.

2: For details about NRPN, RPN, and system

exclusive messages, see MIDI Implementation at

http://world.casio.com/.

3: In accordance with pedal effect setting.

4: With this product, the Hall function is treated as one

type of reverb.

*1: Depende del tono.

2: Para obtener información acerca de NRPN, RPN y

los mensajes exclusivos del sistema, consulte

Implementación MIDI en http://world.casio.com/.

3: De acuerdo con el ajuste de efecto de pedal.

*4: En este producto, la función Hall se considera como

un tipo de reverberación.

CDP230R_es_Cover1-4.fm 2 ページ２０１４年２月１９日　水曜日　午後５時１３分

GUÍA DEL USUARIO

USER’S GUIDE

EN/ES

Guarde toda la información para futuras consultas.

Please keep all information for future reference.

Precauciones de seguridad

Antes de intentar usar el piano digital, asegúrese de

leer las “Precauciones de seguridad” separadas.

Safety Precautions

Before trying to use the Digital Piano, be sure to read

the separate “Safety Precautions”.

CDP230-ES-1B

CDP-230R

EnglishEspañol

This recycle mark indicates that the packaging conforms to

the environmental protection legislation in Germany.

Esta marca de reciclaje indica que el empaquetado se

ajusta a la legislación de protección ambiental en Alemania.

MA1402-B Printed in China

CDP230R_es_Cover1-4.fm 1 ページ２０１４年２月１９日　水曜日　午後５時１３分

Casio Cdp 230R Owners Manual CDP230R_EN

Web_CDP230-ES-1B Web_CDP230-ES-1B_EN CDP-230R | Electronic Musical Instruments | Manuals | CASIO

Navigation menu

Versions of this User Manual:

Views

Navigation
