Cellon Communications Technology C3537 GSM/WCDMA MOBILE PHONE User Manual
Cellon Communications Technology (Shenzhen) Co.,Ltd. GSM/WCDMA MOBILE PHONE
User Manual
1 Introduction
1.1 Phone Display
1.2 Key
Key Function
Left/Right
Soft Key
Press to perform the function currently
displayed in the bottom left/right corner of
the screen.
In idle mode, press Left Soft Key to access
Main Menu.
Navigation
Key
In idle mode, Navigation Key UP to access
Write message.
Press the Navigation Key Down to access
STK.
Press the Navigation Key Left to access
phonebook.
Press the Navigation Key Right to access
Fun&Games.
OK Key In idle mode, press to access WAP.
Press to confirm a selection.
Dial/Answer
Key
Press to make/answer a call.
In idle mode, press to display call list.
End/Power
Key
Presstoendacall.
Press and hold to power on/off the phone.
Facebook
Key
Press to access the Facebook.
FN Key Activate FN mode to enter digits or
characters printed on the top part of the
keys. Press the FN Key once to activate it
once. Press the FN Key twice to activate the
FN mode all of the time. To deactivate the
FN mode, press the FN key.
1.3 Icons and symbols
Vertical bars indicate the signal strength of the
GSM、WCDMA network signal.
Indicates the battery charge level.
Indicates your phone is locked.
Indicates your phone uses the alert type of “Ring”.
Indicates your phone uses the alert type of “Vibrate”.
Alert type is “Vibrate and Ring”.
Alert type is “Vibrate then Ring”.
Indicates your phone uses the headsets profile
Indicates the alarm clock is set.
Indicates a missed call.
Indicates new text message(s).
Indicates new multimedia message(s).
Indicates new voice mail message(s).
Indicates WAP push messages.
Indicates sto
p
watch is enabled.
Indicates your phone has logged onto GPRS.
Indicates your phone has logged onto EDGE.
2 Getting Started
2.1 Inserting the SIM Card
2.1.1 Remove the back cover(1), remove the battery (2),
and insert the SIM card (3)
(1) (2)
(3)
2.1.2 Install the battery (4) and back cover (5)
(4) (5)
2.1.3 Inserting a T-Flash Card
3 Text Entry
3.1 Input Method
Your cellular phone supports several input methods, which
include:
ABC/Abc/abc/ES/Es/es
Numeric (123)
3.1.1 Changing the input modes
During text editing, you can press the Shift Key to switch input
modes.
Or press the Left Soft Key [Options] and choose Input
Method to select different input modes.
3.1.2 Entering Symbols
In any input mode, press the Symbol Key to open the
symbols input screen. Use the Navigation key to choose the
desired symbol and press the Ok key to select it.
3.2 Key Input
Letters and symbols represented by each key are as follows:
Key Function
All related keys Press to input letters
FN Key Activate FN mode to enter digits or
characters printed on the top part of the
keys, Press the FN Key once to activate
it once, press the FN Key twice can
activate FN mode all the time, in this
case, to deactivate the FN mode, press
the FN key.
Space Key Press to input space
Shift Key Press to switch input methods when
entering text.
Symbol Key Press to enter symbol screen
Example: How to enter the word "Happy2013!"
Press the Shift Key to activate the “ABC” mode, press the H
Key to enter “H”.
Press the Shift Key to activate the “abc” mode, press the a, p,
p, y key to enter “appy”.
Press the FN Key twice to activate FN mode, press the 2, 0, 1,
3, ! Key to enter “2013!”.
4 Call functions
4.1 Making a Call
1. In idle mode, enter the phone number.
2. Press the Dial / Answer Key to dial the number.
3. Press the End / Power Key to end the call.
4.2 Making an International Call
1. Press the + Key and "+" appears on the screen.
2. Enter the country code.
3. Enter the area code (normally without the 0 before it)
followed by the phone number.
4. Press the Dial / Answer Key to call directly.
4.3 Answering or Rejecting an incoming Call
1. Press the Dial / Answer Key to answer a call.
2. Press the End / Power key to reject a call.
5 Using the Menus
The phone offers a range of functions that allows you to tailor
it to your needs. These functions are arranged in menus and
submenus. You can scroll and access these menus by
pressing Navigation Keys.
5.1 STK
Note: The submenus of this feature depend on the operator
and different operators may provide different services
(some SIM cards do not support STK), which cannot be
modified.
5.2 Messaging
5.2.1 Creating a text message
1. Select Menu > Messaging > Write message >Text
message.
2. Write a message, please refer to the Text entry
section of this manual for detailed information.
3. After entering text, you can access the send options
by pressing the Left Soft Key [Options] and then select
Send to.
4. Enter the recipient number, or choose a contact from
phonebook.
5. press the the Left Soft Key [Options] and select send
to send the message.
5.2.2 Creating a multimedia message
1. Select Menu >Messaging > Write message >
Multimedia message.
2. Edit the content of the message; press the Left Soft Key
[Options] can add the picture, sound and other object
into the message.
3. After entering text, you should press the Left Soft Key
[Options] and then select Send to.
4. Enter the recipient and press the OK Key to complete
enter , then press the the Left Soft Key [Options] and
select send to send the message.
5.2.3 Broadcast Message
1. Select Menu > Messaging > Broadcast message.
2. Press the Left Soft Key [On] to activate this function.
3. Press the Navigation Key Down to select Channel
settings to enter the channel number.
5.3 Ideas
Ideas lets you enjoy your mobile lifestyle to the fullest, anytime.
With Ideas, you can be updated with news alerts, get access
to sports or finance information, be entertained with music or
games contents and much more, while you are on the go.
Before you use any Ideas applications, you need to activate
GPRS on your SIM card. For the activation, please contact
your service provider.
5.4 Call center
5.4.1
V
iew Call History
1. Select Menu > Call center > Call history.
2. Press the Navigation Key to view different call logs.
3. Choose a particular number and press the Dial Key to call
the number directly.
4. Select Delete call logs if you want.
5.5 WAP
Your phones support Web Browser. You can obtain various
services such as up-to date news, weather, sport, and other
information as well as other Internet services. These services
are designed and maintained by WAP service providers.
Note: To activate WAP service, you may need to contact
your service provider.
5.6 Facebook
Facebook is a social utility that connects people with friends
and others who work, study and live around.
This feature supports quick and easy access to Facebook on
your phone. You can use Facebook to keep up with friends.
You can also send messages, photos and notes from your
phone straight to Facebook.
To access Facebook, you need to get internet service first.
Please contact your network operator for more details.
5.7 Multimedia
5.7.1 iTonos
This menu allows you to access
http://z.clarodo.mobi/clarodocw.qpass.com/ndmns/index?m=iv
u;iv6
5.7.2 ilmagenes
This menu allows you to access
http://z.clarodo.mobi/clarodo-cw.qpass.com/ndmns/index?
5.7.3 Camera
How to ...
Launch Camera Select Menu > Multimedia > Camera.
Adjust settings Press the Left Soft Key
Take a picture Press the OK Key.
Exit Press the End Key or the Right Soft Key
5.7.4 Image Viewer
This menu lists the picture from File Manager >
Phone/Memory card >Photos according to its storage
setting.
5.7.5
V
ideo playe
r
It can play videos saved in your phone and SD card .
To play the video
1. In Multimedia menu, choose Video Player, and select the
file you wish to play.
2. After a certain video clip is selected, select Options >
Play.
5.7.6 Audio Player
Keys Operation
The keypad operations during music playback are as follows:
Key Description
Navigation
Key Down ▼
Presstostopthemusic.
Navigation
Key ◀or ▶
Short press to select the previous song/next
song. Press and hold to rewind/fast forward
the track during playback.
+, - Adjust volume.
Left Soft Key
[List]
List the audio file from the storage you set.
Right Soft
Key [Back]
Return to previous menu.
Navigation
Key Up ▲
Press to Start/Pause/resume the current
music.
5.7.7 Sound Recorder
1. Select Menu > Multimedia > Sound Recorder.
2. Press the Left Soft Key [Options] and select Settings
to set your preferred storage, file format and audio
quality.
3. Back to the previous menu, select New Record.
4. In the recording screen, you can press the Left Soft
Key to pause or continue.
5. If you have finished, press the Right Soft Key [Stop] to
stop recording.
6. Press the Left Soft Key [Yes] to Save.
5.7.8 FM Radio
Note: The radio will not work unless the headset is attached.
Attach the headset to the headset port located at the bottom of
the phone.
To operate the radio:
1. Press the Navigation Key Down to activate or
deactivate the FM radio.
2. Press the + / - Key to adjust the volume.
3. Press the Navigation Key Up to activate or deactivate
Auto search.
4. Press the Navigation Key Right/Left to switch the
channels. If auto search is activated, pressing the
Navigation Key Right/Left will switch the available
searched channels; if auto search is deactivated,
pressing the Navigation Key Right/Left will switch to
varying channels by 0.1 intervals.
5. Press the Left Soft Key [Options] to access FM
settings.
5.8 Phonebook
5.8.1 Search contact
1. Press Menu > Phonebook.
2. Enter the first few letters of the contact name to search.
Note: You can also press the Navigation key Down to
access the contact list.
5.8.2 Add New Contact
To create a new SIM/phone contact:
1. Select Menu > Phonebook > Add new contact.
2. Enter all related information about the contact.
3. Press the OK Key to save the contact details.
5.8.3 Phonebook settings
1. Select Menu > Phonebook.
2. If you select a contact, press the Left Soft Key
[Options] can send message, call, edit, copy, move,
and so on.
3. Select one item, press the Left Soft Key [Options] and
select Phonebook settings.
4. Now you can set the speed dial, view the memory
status, copy or move contacts, and so on.
5.9 Email
Select Main Menu > Email.
Select Email accounts to add an email account.
Touch Options and select New account to create an email
address. Now you can enter the email address, protocol, data
account, incoming server, outgoing server, user name,
password, and account name.
When you finish, the account will be saved automatically. You
can now select Options and choose Activate to activate this
account.
Go back to the previous menu and select Send and receive to
refresh your mailbox.
5.10 Fun & Games
Your cellular phone provides you with several games.
You can also adjust the game settings when you enter the
game menu.
5.11 Settings
You can configure your cellular phone to best suit your usage
preferences.
5.11.1 user profiles
Activate user profiles
1. Select Menu > User profiles.
2. Select one of the profile.
3. Select Customize to adjust the settings.
4. Back to previous menu, select Activate.
5.11.2 Phone Settings
This menu option allows you to set phone parameters such as
time and date, schedule power on/off, language, Pref. input
methods,Encoding, Display,Themes,Greeting text,Shortcuts,
Dedicated key,Auto update time,Flight mode and Misc.settings.
5.11.3 Network settings
Network Selection
New Search: Touch to search for a new network.
Select Network: Touch to select a network from the network
list.
Selection Mode: Touch to choose your network manually or
automatically.
Preferences
The phone will try to register on the network, according to your
preferences.
Service selection
Touch it to modify your Service selection: GSM, WCDMA,
Automatic.
Network information
This feature allow you to view the detail of the network
information which you are using.
GPRS Connection
Touch it to modify your GPRS connection: When needed, or
always.
GPRS transfer pref.
Touch to set the GPRS transfer preference. You can choose
Data prefer or Call prefer.
HSPA preference
Touch to turn off the HSPA.
5.11.4 Security Settings
SIM security
To prevent your SIM card from illegal use, your SIM card is
protected by a PIN code. If you set the SIM lock to On, you
can only use your mobile phone by entering the correct PIN
code every time you turn it on. If you enter the wrong PIN code
three times, your SIM card will be locked and a PUK code will
be required. Contact your service provider for more
information.
Phone security
To prevent your cellular phone from illegal use, you can
activate the Phone Lock option. If activated, you will need to
enter the correct Phone lock password before you can use the
phone.
When you set it to on or off, the phone lock password is also
required.
If you forget the password, contact your service provider for
assistance in unlocking the phone.
Note: The initial password is 1234. If you want to change your
password, go to Settings > Security Settings>Phone
security > Change Password.
Auto keypad lock
Select to set the time for auto keypad lock. If the time expires,
the keypad will be locked automatically.
Certificate manager
Select to view, delete, or set the key usage.
5.11.5 Connectivity
Here you can configure the data account, and use the
Bluetooth.
Bluetooth
Your phone is designed to be compliant with Bluetooth
technology. Bluetooth technology enables wireless
connections between electronic devices. The Bluetooth
connection can be used to listen to stereo music, send images,
video, texts and vCards.
Connection management
This function supports to manage the connections.
Data Account
You can access WAP via GPRS. To get the analogue number
or ISDN number information, you may need to contact your
operator for the service. To get the access point of GPRS, you
may need to contact your operator for the service.
Internet Services
This feature supports you to Access various internet options.
Homepage
Once connected, the homepage is displayed. The content
depends on the service provider. To exit the browser, press
the End Key.
Bookmarks
You can use this menu to save URL addresses to quick
access a website.
Input address
You can key in the URL address. When you are done, select
Options > Go to. Your phone will connect the URL you just
keyed in. After the address is entered, you may select the URL
and select Options > Go to to connect next time.
Last web address
Press to access the last web address you visited.
Recent pages
You can view the recent pages you have visited.
Stored pages
Touch to view the pages you have stored
Settings
GPRS (General Packet Radio Service) is a technology that
use for sending and receiving data over the mobile network.
If the settings have made by the service provider, you may
begin immediately. Otherwise, you may key in settings
manually.
You can also restore browser settings here.
5.11.6 Restore Factory Settings
You will be required to enter the phone lock password to
restore the phone to its original factory settings. After entering
and confirming the correct phone lock password, most of the
settings in your cellular phone will be restored to factory
settings.
5.11.7 Sound effects
This function allows you to set Audio effect and turn on or off
Bass enhancement.
5.11.8 Call settings
1. Select Menu > Settin
g
s>Callsettin
g
s.
2. Now you can set the call waiting, call divert, call barring
and so on.
5.12 Organizer
This menu contains features and options designed to keep
you organized and informed while on the go.
5.12.1 Calendar
This feature allows you to keep track of your schedule and
tasks saved in the calendar. You can also switch on the alarm
with the task for reminding.
To make a note and reminder in Calendar for the first time:
3. In Organizer menu, choose Calenda
r
.
4. Select a day in the calendar
5. Select Options >
V
iew to view the event. You can also
select Options > Add event to add a new event.
6. Choose a type of the event and then Input other details.
After you finish editing the event, select OK to save.
5.12.2 Tasks
You can also view, edit or delete the tasks from the options
under this feature. For the first-time user, you will need to
follow the steps below:
1. Select Add in the Task List. Then choose the task type.
2. Edit your Task by entering date, time, Subject, Alarm,
Repeat and other information.
3. You can choose to turn the alarm on as the reminder.
4. Select OK and Yes to save your task.
5.12.3 Alarm
1. Select Menu > Organizer > Alarm.
2. Select an alarm and then press the Left soft Key [Edit]
to create.
3. Use the Navigation Key to turn it on or off.
4. Enter other information, such as time, repeat, and so
on.
5.12.4 World clock
You can view the local date and time via selecting the city.
When the cross points out a certain city, it will show the local
date and time.
5.12.5 Notes
1. From the main menu, select Organizer > Notes.
2. Press Left Soft Key [Add] to add notes, edit the notes, then
select Options > Done to save.
5.13 Herramientas
5.13.1 Java
In this menu ,you can access the Java application here.
5.13.2 Java settings
This feature allows you to chang the Java settings.
5.13.3 Java default settings
In this menu,you can configure the third party and Untrusted
domain settings , you can also reset to default settings.
5.13.4 Calculator
Calculator applies simple calculator function such as addition,
subtraction, multiplications and division.
5.13.5 Unit converter
This feature helps you to convert either the weight or length to
a different unit.
5.13.6 Stopwatch
This function is designed to store the timepiece, which is to
start or stop for exact timing.
To use stopwatch
1. From the main menu select Herramientas >
Stopwatch.
2. Select Typical stopwatch. You can choose different
record methods and view records.
Split Timing: When you select this, the
timepiece will be saved and continue to count
when you press Split. The 2nd timepiece is
recorded based on the continuous timing. You can
stop and resume anytime.
Lap Timing: When you select this, the
timepiece will be saved and start the new timing
when you press Lap. The 2nd timepiece is
recorded in new timing. You can stop and resume
anytime.
View records: You can view those
timepieces you have recorded or delete the
records.
3. Select nWa
y
stopwatch. You can make four records.
5.14 File Manager
1. Select Menu > File manager.
2. When you highlight one of them, the related memory
information is displayed at the top of the screen,
including total volume and free volume.
Note: If you want to view the files in T-Flash card, please
insert the T-Flash card first.
6 Safety Information and Notices
Using the Cellular Phone and Charger
Danger:
Only use the battery and charger approved by the
manufacturer. Using other brands may cause battery leakage,
overheating, explosion or even fire.
Caution:
Keep the phone away from dust, water and damp areas. Dust,
water or other liquids may cause overheating, electrical
leakage, and/or phone failure.
The phone, battery, charger and AC adapter are not
waterproof. Keep them away from rain and liquid.
When charging, please place the phone in an environment
that has a normal room temperature and good ventilation. It is
recommended to charge the phone in an environment with a
temperature that ranges from 0ºC ~40ºC.
The maximum operating ambient temperature of the
equipment declared by the manufacturer is 55 ºC.
Warning:
Do not bump, shake or tamper with the phone or charger. This
may cause battery leakage, overheating, explosion or even
fire.
Do not place the battery, phone or charger near a microwave
or high-voltage device. This may cause battery leakage,
overheating, explosion or even fire. Also prevent the phone
and AC adapter from overheating, smoking or short circuiting.
Do not use the phone around volatile oil. This may cause fire,
breakdown or damage.
To avoid any damage or breakdown, do not disassemble the
phone, battery, charger or internal components by yourself.
Using the Cellular Phone
Warning:
Do not use the phone while you are driving. Pull over and stop
your automobile to dial or listen to a phone call.
Usage of cellular phones in aircrafts or hospitals is prohibited.
Switch the phone off to prevent interference with electronic
medical devices. Follow any rules or regulations in such
places.
Do not use the phone at a gas station, near fuel or near
chemicals.
Do not use the phone near electronic medical devices such as
hearing aids, pacemakers and auto-control devices such as
fire detectors and automatic doors.
If you have to use your cellular phone near an electronic
medical device such as a pacemaker, please contact your
manufacturer or dealer for information about preventing
interference.
Use the phone in a temperature range between 0~40℃and
humidity of 35%~85%.
Excessive sound pressure may harm your hearing.
Caution:
Electronic systems in automobiles such as anti-lock brakes,
speed control, or fuel spraying systems, are usually not
influenced by wireless devices. Manufacturers of these
systems will tell you whether they encompass good screening
mechanisms. If you suspect that an automobile failure is
caused by a wireless wave, please contact your automobile
dealer.
Avoid using your phone in crowded places.
Do not store your cellular phone near or with a credit card,
disk or other magnetic materials. This may affect information
stored on your phone.
Using the Battery
Danger:
Do not dispose of the battery into a fire. Doing so may cause
battery explosion or even fire.
If you have difficulties installing the battery, do not force the
installation. This may cause battery leakage, overheating,
explosion or even fire.
Keep metal objects away so they do not come in contact with
the battery or its connectors as it may cause the battery to
short circuit, overheat or explode.
Do not weld the polarities of the battery directly together. This
may cause battery leakage, overheating, explosion or even
fire.
Battery liquid is severely harmful for your eyes. If battery liquid
gets in your eyes, do not rub them. Instead, wash your eyes
with water first and then go directly to a doctor for help.
Do not use or store your phone in high temperature areas.
This may cause battery leakage, overheating, explosion or
even fire.
Warning:
Replace the battery when the normal usage time begins to
decrease or if you notice the battery is overheated or has
changed shape or color.
If battery liquid leaks onto your skin or clothes, immediately
wash the affected parts with water.
If the battery begins to leak or emits a strange odor, properly
dispose of the battery according to local regulations. Do not
throw it into a fire.
Caution:
Do not leave the product or its battery inside a vehicle or in
places where the temperature may exceed 60°C (140°F), such
as on a car dashboard, window sill, or behind a glass that is
exposed to direct sunlight or strong ultraviolet light for
extended periods of time. This may damage the product,
overheat the battery, or pose a risk to the vehicle.
Specific Absorption Rate (SAR) information
This mobile phone meets the government’s requirements for
exposure to radio waves.
This phone is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy
set by the Federal Communications Commission of the U.S.
Government.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit set is 1.6W/kg. *Tests for SAR are
conducted using standard operating positions with the phone
transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the
highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power
levels so as to use only the poser required to reach the
network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The highest SAR value for the model phone when tested for
use at the ear is 1.16 W/kg and when worn on the body, as
described in this user guide, is 0.495 W/kg (Body-worn
measurements differ among phone models, depending upon
available accessories .)
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirement.
12 MONTH LIMITED WARRANTY
Gong Qing Cheng Cellon Communications Technology Co.,
Ltd (the Company) warrants to the original retail purchaser of
this handheld portable cellular telephone, that should this
product or any part there of during normal consumer usage
and conditions, be proven defective in material or
workmanship that results in product failure within the first
twelve (12) month period from the date of purchase, such
defect(s) will be repaired or replaced (with new or rebuilt parts)
at the Company’s option, without charge for parts or labor
directly related to the defect(s).
The antenna, keypad, display, rechargeable battery and
battery charger, if included, are similarly warranted for twelve
(12) months from date of purchase.
This Warranty does not apply to:
Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse,
improper installation or repair or improper storage; Product
whose mechanical serial number or electronic serial number
has been removed, altered or defaced.
Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
Damage resulting from connection to, or use of any accessory
or other product not approved or authorized by the Company;
Defects in appearance, cosmetic, decorative or structural
items such as framing and non-operative parts;
Product damaged from external causes such as fire, flooding,
dirt, sand, weather conditions, battery leakage, blown fuse,
theft or improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of
the product, for geographic coverage, for inadequate signal
reception by the antenna or for communications range or
operation of the cellular system as a whole.
When sending your wireless device to Gong Qing Cheng
Cellon Communications Technology Co., Ltd for repair or
service, please note that any personal data or software stored
on the device may be inadvertently erased or altered.
Therefore, we strongly recommend you make a back up copy
of all data and software contained on your device before
submitting it for repair or service. This includes all contact lists,
downloads (i.e. third-party software applications, ringtones,
games and graphics) and any other data added to your device.
In addition, if your wireless device utilizes a SIM or Multimedia
card, please remove the card before submitting the device and
store for later use when your device is returned, Gong Qing
Cheng Cellon Communications Technology Co., Ltd is not
responsible for and does not guarantee restoration of any
third-party software, personal information or memory data
contained in, stored on, or integrated with any wireless device,
whether under warranty or not, returned to Gong Qing Cheng
Cellon Communications Technology Co., Ltd for repair or
service.
To obtain repairs or replacement within the terms of this
Warranty, the product should be delivered with proof of
Warranty coverage (e.g. dated bill of sale), the consumer’s
return address, daytime phone number and/or fax number and
complete description of the problem, transportation prepaid, to
the Company at the address shown below or to the place of
purchase for repair or replacement processing.
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR
REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT,
SHALL THE
COMPANY’S LAIBILITY EXCEED THE PURCHASE PRICE
PAID BY PURCHASER FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE
DURATION OF THIS WRITTEN WARRANTY. ANY ACTION
FOR BREACH OF ANY WARRANTY MUST BE BROUGHT
WITHIN A PERIOD OF 18 MONTHS FROM DATE OF
ORIGINAL PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR AN SPECIAL CONSEQUENTIAL
OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE
FOR THE DELAY IN RENDERING SERVICE UNDER THIS
WARRANTY OR LOSS OF USE DURING THE TIME THE
PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the
Company any liability other than expressed herein in
connection with the sale of this product.
Gong Qing Cheng Cellon Communications Technology
Co.,LTD
New Industrial Park, Gong Qing Cheng City
Jiang xi Province 332020 PRC.
(86)0792-7720000
FCC Regulations:
This mobile phone complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This mobile phone has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiated radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
4RF Exposure Information (SAR)
This model phone meets the government’s requirements for
exposure to radio waves.
This phone is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy
set by the Federal Communications Commission of the U.S.
Government.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for
SAR are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only
the poser required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the
power output.
The highest SAR value for the model phone as reported to the
FCC when tested for use at the ear is 1.080 (Head SAR)W/kg
and when worn on the body, as described in this user guide, is
1.436 (Body SAR)W/kg (Body-worn measurements differ
among phone models, depending upon available
enhancements and FCC requirements.)
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirement.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and
can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID:
T38C3537.
For body worn operation, this phone has been tested and
meets the FCC RF exposure guidelines for use with an
accessory that contains no metal and the positions the
handset a minimum of 1.5 cm from the body. Use of other
enhancements may not ensure compliance with FCC RF
exposure guidelines. If you do no t use a body-worn
accessory and are not holding the phone at the ear, position
the handset a minimum of 1.5 cm from your body when the
phone is switched on.
