©CenTrak2011.AllRightsReserved.ProprietaryandConfidential.10/24/11

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

CenTrak AlertTagIT‐753*

•AudibleSoundAlertCapability

•LEDFlashAlertCapability

•StaffDuressCall

•DesignedforusewiththeCenTrak HandHygiene

ComplianceSystem

•AttachestoastandardhospitalissuedIDBadge

•CenTrak HybridRTLSTechnologyforroomandbed‐level

accuracy

TheAlertTag(IT‐753)hasthecapabilityofalertingwithaudiblesound.The

AlertTagisavailablewithastaffbadgeholderandcomesstandardwith1

programmablebutton.

ThistagwasdevelopedtoworkalongwiththeHygieneMonitoraspartofthe

CenTrak HandHygieneComplianceSystem,butcanalsobeusedforsolutions

suchasstafflocating,staffduresscallandworkflowoptimization.Whenused

forhandhygienecompliance,itworksasaproactiveremindertocaregiversof

non‐complianceevents;thesystemautomaticallycapturesaspecific

caregiver’sbadgeIDandentrytoandexitfrompatientcareareasalongwith

handhygieneevents.TheHygieneMonitorcommunicateseacheventtothe

networkandrecordseachcaregiver’scomplianceperformance.Allofthe

recordeddataisstoredonCenTrak’s localorhostedserverandcanbe

accessedbycompliancemanagementandreportingsolutions.Thebattery

poweredHygieneMonitorscanbemountedtoanydispenser,canister,pump,

orsinktotracktheirusage.

AboutCenTrak HybridRTLSTechnology™

TheCenTrak coreRTLSdiffersfromlegacyinitscombineduseofapatented

second‐generationinfrared(Gen2IR™)andactiveRFIDtechnology.Battery‐

poweredMonitorstransmitauniqueroomnumberusingGen2IRwhichis

receivedbyanytaginthatroom.Thetagcommunicatestheroomnumberand

itsownuniqueIDviaRFtotheCenTrak LocationServerusingahospital’s

existingwiredorWiFi network,whereitcanbeaccessedinreal‐timeby

hospitalpersonnelandintegratedwiththirdpartysolutionproviders.

Similartolight,Gen2IRwillnotpassthroughwallsanddoesnotsufferfrom

traditionalinfraredlin‐of‐sightlimitations.Therefore,whenatagreadsaroom

number,therearenoerrors.Thisiscertainty‐basedRTLS.Unlikeestimation‐

basedinformation,certaintybasedlocationdatacanbeusedbyhospitalsto

makeimportantimprovementstoprocessflowandautomatedecisionmaking.

Mosthealthcareworkflowimprovementscanonlyberealizedwhenthe

locationdataiscertainty‐based.

*IT‐753isforusewiththeCenTrak 2.0system.OrderIT‐751forusewiththe1.0

system.

IT‐753CenTrak AlertTag

IT‐753CenTrak AlertTagshown

withattachmentaccessories

©CenTrak2011.AllRightsReserved.ProprietaryandConfidential.10/24/11

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

CenTrak StaffBadgeIT‐743*

TechnicalSpecifications

Operation

FCCOperatingFrequencyRange 902‐928MHz (Model#IT‐753)*

CEOperatingFrequencyRange 868‐870MHz(Model#ITEU‐753)*

Groupcode&tagIDcodes 2Mcodes

Outdoortransmissionrange >300feet

Averagetransmissionpower 2uW (average)

Smarttagfeatures 1button,LED,lowbattery

MotionSensor YES

AttachmentOptions

Clip‐onbackattachment Clip attachestolanyardorclothing(pocket,

shirt,jacket)

TagDimensions

Case width 1.5in(38.48 mm)

Caseheight 1.98in(50.36mm)

Casewidth 0.6in(15 mm)

Caseweight (withbattery)1.1 oz (34.02 g)

Construction Heatreflectivepolycarbonate

Environmental

OperatingTemperature 0Cto+70C

Storagetemperature ‐25Cto+80C

Sealing Splashresistant

Power

Batterytype LithiumCR2340

Smarttagfeature Lowbatteryindication

Note:MustuseCenTrak Disinfectionprocedure.Othermethodsmayvoidproductwarranty.

*IT‐753isforusewiththeCenTrak 2.0system.OrderIT‐751forusewiththe1.0system.

Thiscomponentcomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:1)The

devicemaynotcauseharmfulinterference,and2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycasesundesiredoperation.Modifyingortamperingwiththetranceiver’s orreceiver’sinternal

componentscancauseamalfunction,invalidatethewarranty,andwillvoide FCCauthorizationto usetheseproducts.

ThisproductoritssystemsarecoveredbyoneormoreofthefollowingU.S.patents:5,917,425,7,061,428,7,378,964.

L‘utilisationdecedispositifestautoriséeseulementauxconditionssuivantes:(1)ilnedoitpasproduirede

brouillageet(2)l’utilisateurdudispositifdoitétre prêtàacceptertoutbrouillageradioélectriquereçu,mêmesice

brouillageestsusceptibledecompromettrelefonctionnementdudispositif.

IT‐753CenTrak AlertTag
