ITDK‐318Multi‐ModeMonitor

•CCXonWi‐FinetworksandGen2IR™

•BatteryOperated

•Canbeconfiguredandmonitoredbycentralserverfor

superiorcontrol

•Simpletoinstallceilingtilemountingbracket,noin‐room

wiringrequired

TheMonitorisanIR(infrared)signalingunitusedwithIR‐enabledtags

orMulti‐Modetagstoprovideamethodoflocatingtaggedassetsor

people.EachMonitortransmitsaninfraredpulsepatterncontaininga

uniquelocationcode.TheMulti‐ModeMonitorisdifferentfrom

CenTrak’sstandardGen2IRMonitorbecauseitfunctionsinbotha900

MHzand/orWi‐Fienvironmentwithoutanywiring.

AboutCenTrakGen2IR™Technology™

TheCenTrakproprietaryIRprotocolachievesamarkedimprovement

overconventionalIRprotocolsthatweredesignedforremotecontrol

applications.Itprovidessuperiorresiliencetofluorescentandother

commonindoorinterferencesources.Coveragezonesarelimitedby

solidphysicalstructuressuchaswalls;however,contrarytopopular

belief,IRdoesnotneedlineofsightforeffectivecommunication.IR

signalsbounceeffectivelyfromstructuresandwallsfloodtheentire

roomincludinglocationsthatarenotindirectlineofsighttothe

monitor.Thebatteryoperationandtheextremelysimplemounting

mechanismallowsforthequickandlowcostinstallation.

ITDK‐318MountedtoCeiling

ITDK‐318Multi‐ModeMonitor

©CenTrak2013.AllRightsReserved.ProprietaryandConfidential.

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

ITDK‐318Multi‐ModeMonitor

TechnicalSpecifications

Reach

MaximumRoomSize 20’squarerooms(400square feet)

Maximum Range Upto60’

Enclosure

Diameter 6.5in(165.1mm)

Height 2.25in(57.15mm)

Weight 18oz (.51kg)withoutbatteries

Mounting Ceilingtileclip,wall‐mount,desktop

operation

Monitor MountingPlate ITA‐352

Mounting Accessories Variousitemsdetailedonpage3

Power

ExternalPower Externalpoweradaptercapability– (optional)

see page3

Batterytype Pre‐installed Lithium

Environmental

OperatingTemperature ‐20Cto+70 C

Storagetemperature ‐25Cto+80C

OperatingHumidity Splashresistantoroptionalweatherproof

case

THISDEVICECOMPLIESWITHPART15OFTHEFCCRULESANDINDUSTRYCANADALICENSE‐EXEMPTRSSSTANDARD(S).OPERATIONISSUBJECTTOTHE

FOLLOWINGTWOCONDITIONS:(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFERENCE,AND(2)THISDEVICEMUSTACCEPTANYINTERFERENCE

RECEIVED,INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIREDOPERATION.Modifyingortamperingwiththetransceiver’sorreceiver’sinternal

componentscancauseamalfunction,invalidatethewarranty,andwillvoidFCCauthorizationtousetheseproducts.Thisproductoritssystemsare

coveredbyoneormoreofthefollowingU.S.patents:5,917,425,7,061,428,7,378,964,7,619,532

L‘utilisationdecedispositifestautoriséeseulementauxconditionssuivantes:(1)ilnedoitpasproduiredebrouillageet(2)l’utilisateurdudispositif

doitétre prêtàacceptertoutbrouillageradioélectriquereçu,mêmesicebrouillageestsusceptibledecompromettrelefonctionnement dudispositif.

Operation

FCCOperatingFrequencyRange 2.4GHz(CCXonWi‐Finetworks,802.11b/g)

902‐928MHz

ITDK‐318MountedtoCeiling

ITDK‐318Multi‐ModeMonitor

©CenTrak2013.AllRightsReserved.ProprietaryandConfidential.

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

ITDK‐318Multi‐ModeMonitor

Accessories

ITA‐361MonitorMetal

CeilingAttachment

(9/16inch)

ITA‐362MonitorMetal

CeilingAttachment

(15/16inch)

ITA‐356

DCellLithium

Battery(2)

(forillustration

purposesonly)

CeilingAttachments

Power

ITA‐374‐MMonitor

Weather‐Proof

ProtectiveDome

(Monitornotincluded)

ITA‐351

Monitor

Power

Adapter

ITA‐353

CeilingTile

Attachment

(standard)

ITA‐363MonitorMetal

CeilingAttachment

(5/16inch)

ITA‐352

Monitor

MountingPlate

(standard)

Enclosure

ITDK‐318MountedtoCeiling

ITDK‐318Multi‐ModeMonitor

ITA‐377MonitorFlush

MountingPlate

(Monitornotincluded)
