IT-104
Clear Router
•Central component of the CenTrak Wireless Mesh Network
•Manages and Secures Mesh Network
•Designed to be PoE-connected and centrally located
•Easy installation
•Can be placed in waterproof container for outdoor use
Senior Living Communities have a critical need for the wireless
monitoring of residents to ensure safety and improve
workflow. The IT-104 Clear Router creates, secures, and
manages the Clear Network. With easy installation and
automatic management, the IT-104 takes full simple control of
the total campus network.
The Clear Network is a Long Range Network to support True
Locator and CenTrak Geo, IT-726E. This enables senior care
communities to make decisions based on facts about where
and when residents and staff are located.
The IT-104 is externally powered by a power outlet or PoE
(Power over Ethernet) and connects to the CenTrak Social
Platform. The 900MHz system provides long-range network
coverage across an entire senior care community campus.
CenTrak, Inc.
826 Newtown-Yardley Road
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
© CenTrak 2018. All Rights Reserved. Proprietary and Confidential. Draft version subject to review
IT-104 Clear Router
© CenTrak 2015. All Rights Reserved. Proprietary and Confidential. Draft version subject to revision.
Technical Specifications
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cases undesired operation. Modifying or
tampering with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to
use these products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif
doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
CenTrak, Inc.
826 Newtown-Yardley Road
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-104
Clear Router
© CenTrak 2018. All Rights Reserved. Proprietary and Confidential. Draft version subject to review
IT-104 Clear Router
Operation
FCC Operating Range (Americas) 902-928 MHz
CE Operating Range (Europe, Middle
East)
868-870 MHz
FCC Operating Range (Australia/NZ) 920-926 MHz
Read Range –to repeaters up to 2000’
Tag Density
Dimensions
Case Length 5.35 in (136 mm)
Case Height (thickness) 1.4 in (36mm)
Case Width 5.5 in (139 mm)
Case Weight (with battery) 10.82 oz (306.7 g)
Construction ABS Plastic
Environmental
Operating Temperature -10 °C to 50 °C
Storage Temperature -40 °C to 80 °C
Operating Humidity 10% to 90% non-condensing
Plenum Rating
Power
External Power Supply 100 –240VAC
Power Consumption 5VDC 500mA
