Centrak IT373LTX Hand Sanitizer i-DIM-GO LTX IT-373LTX User Manual
Centrak, Inc. Hand Sanitizer i-DIM-GO LTX IT-373LTX Users Manual
Centrak >
Users Manual
© CenTrak 2014. All Rights Reserved. Proprietary and Confidential.
IT-373LTX i-DIM-GO LTX
•Automatically tracks hand hygiene compliance at the
caregiver level
•Collects data on all events at hand washing stations
•Designed to integrate with GOJO hand hygiene dispensers
•Multiple mechanisms to activate the dispenser including
proximity and motion sensor
•Works in conjunction with CenTrak’s full RTLS and with
CenTrak’s Clinical-Grade Locating Staff Badge.
The Integrated Dispenser Interface Module for GOJO (i-DIM-GO) is a
component of CenTrak’s Clinical-Grade Hand Hygiene Compliance Solution –
the healthcare industry’s only solution designed to automatically monitor
hygiene dispenser usage by caregivers as well as their entry and exit to patient
care areas. It eliminates costly manual monitoring, and proactively alerts
caregivers who enter patient care environments without proper hand hygiene,
to assist in compliance and behavior modification.
IT-373LTX units integrate with GOJO dispensers, and automatically
communicate a specific caregiver’s badge ID from patient care areas along
with hand hygiene events, based upon hospital determined compliance
business rules. The i-DIM-GO communicates each event to the network which
records each caregiver’s compliance performance. All of the recorded data is
stored on CenTrak’s local or hosted server and can be accessed by third party
compliance management and reporting solutions.
The LED indicator on the Dispenser flashes a blue confirmation light when the
dispenser is activated and detects a care giver with a CenTrak badge is within
range (approximately 4 feet).
The i-DIM-GO captures all hand hygiene events whether or not a caregiver is in
direct line of sight of the module using a combination of technologies. Unlike
other hand hygiene compliance solutions, CenTrak is able to capture 100% of
clinical hand washing events without errors.
IT-373GJ i-DIM-GO
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-373GJ shown integrated
with a GOJO dispenser
© CenTrak 2014. All Rights Reserved. Proprietary and Confidential.
IT-373LTX i-DIM-GO LTX
Technical Specifications
Operation
FCC Operating Frequency Range 902-928 MHz
CE Operating Frequency Range 868-870 MHz
Maximum transmission power 1 mW peak
Low Frequency 125 KHz
Indicators
LED Indicators Not on unit; Enables integrated blue
confirmation LED light on GOJO Dispenser
Enclosure
Case width 1.5 in (38.1 mm)
Case height 2.75 in (70 mm)
Case depth 0.6 in (15 mm)
Construction ABS Plastic
Environmental
Operating Temperature 0 C to +50 C
Storage temperature -30 C to +70 C
Operating Humidity 10% to 90% non-condensing
Power
Battery type N/A, GOJO Dispenser powered
Note: Must use CenTrak disinfection procedure. Other methods may void product warranty.
Activation Sensors
Proximity and/or Motion Optional configurations
Low Frequency Range Up to 4 feet
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Modifying or
tampering with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to
use these products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif
doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-373GJ shown integrated
with a GOJO dispenser
IT-373GJ i-DIM-GO
IC Statement:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
