Centrak IT725 Single-Use Patient Tag IT-725/IT-725P/IT-725S User Manual
Centrak, Inc. Single-Use Patient Tag IT-725/IT-725P/IT-725S Users Manual
Centrak >
Users Manual
© CenTrak 2014. All Rights Reserved. Proprietary and Confidential.
IT-725 Single-Use Patient Tag
•Practical patient tracking solution with low cost, fully
waterproof tags which may either be discarded or recycled
•Gen2IR™ Technology for Clinical-Grade Locating™ applications
•Thin, small size, lightweight
•Designed to integrate with existing hospital ID bracelets
•Operates for 30 days – perfect more most patient flow
applications
Healthcare facilities have a critical need for the wireless monitoring of
patients to ensure safety and improve workflow. CenTrak’s Clinical-Grade
Locating™ technology was developed to meet these needs when used with
automated workflow and bed management applications. The CenTrak Tag is
securely associated with a patient wearing the tag to help with identification
before medication is administered or a medical procedure is performed, to
confirm identity and reduce errors. The tags enable patients to have
increased mobility while improving their safety by quickly alerting staff if
patients enter or leave restricted areas. Patients enjoy having the freedom
and flexibility to move as supported by their care plan.
The IT-725 tag utilizes CenTrak’s Gen2IR™ to support Clinical-Grade
Locating™ applications. Gen2IR™ enables certainty-based accuracy at the
bed-, bay- and chair-level. This empowers hospitals and healthcare
administrators to make decisions based on facts about where and when
their people and resources are located. The IT-725 tag provides the ability to
monitor patients at any time anywhere in a facility. This single tag can be
used to track, locate, protect and identify a patient in seconds.
Tags may be worn on standard issued medical ID bracelets. With a modular
design and low price, tags provide an economical solution to a wide variety
of patient management challenges.
IT-725 Single-Use Patient Tag
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-725 in use
© CenTrak 2014. All Rights Reserved. Proprietary and Confidential.
IT-725, IT-725P,IT725S Single-Use Patient Tag
Technical Specifications
Operation
FCC Operating Frequency Range 902-928 MHz (Model #IT-725)
CE Operating Frequency Range 868-870 MHz (Model #ITEU-725)
Group code & tag ID codes 8M code5
Outdoor transmission range > 300 feet
Average transmission power 2 uW (average)
Gen2IR sensor YES
Motion Sensor YES
Tag Dimensions
Case width 1.5 in (38.1 mm)
Case height 1.98 in (50.3 mm)
Case width 0.6 in (15 mm)
Case weight (with battery) 0.77 oz (21.8 g)
Construction Soft PVC
Environmental/Cleaning
Operating Temperature 0 C to +70 C
Storage temperature -25 C to +80 C
Sealing Splash & Water resistant
Power
Battery type Lithium CR2032
Smart tag feature Low battery indication
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Modifying or tampering
with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to use these
products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit
étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-725 Single-Use Patient Tag
IT-725 in use
IC Statement:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
