CenTrak StaffBadgeIT‐744&IT‐744E*

CenTrak StaffBadgeIT‐744

•CenTrak Gen2IR™Technologyforroomandbed‐levelaccuracy

•Threecustomizablebuttons

•SystemcontrolledLED

•Ultrathin(only3.8mm)andlightweight

•Audiblealertfunctionality

•Shapeandsizeofastandardhospitalissuedbadge

•Holemountsforportraitorlandscapetowearbehinda

standardbadge

•Waterresistantandeasytoclean

•Longbatterylife

CenTrak StaffBadgeIT‐744E

•AllthefeaturesandbenefitsofIT‐744,plusitalsoincludesa

LowFrequency(LF)sensor.

•DesignedtobeusedwithCenTrak’s LowFrequencyMonitors

tocreatechokepointsandwithCenTrak’s HandWashing

Monitors.

Today’shospitalshaveacriticalneedtolocatepersonnelthroughouttheir

facilities.TheyrequireareliableRTLStooptimizepatientcareandensurethe

safetyofitspersonnel.TheCenTrak staffbadgewasdevelopedtomeetthis

needandincludesseveraluniquefeaturesthatimproveuponlegacystaff

locatingtechnology.

TheCenTrak StaffBadgecanbemountedontotheloopusedtoholdastandard

hospital‐issuedemployeebadge.TheStaffBadgeisdesignedtostaywiththe

caregiver,thuseliminatingtheneedforseparateprocessesthatrequiredaily

taggingofpersonnel.Itiswaterresistantandcanbeeasilycleaned.EachStaff

BadgehasthreecustomizablebuttonsthatcanbeassignedbasedupontheRTLS

usecase.

AboutCenTrak Gen2IR™Technology

TheCenTrak coreRTLSdiffersfromlegacysystemswithitscombineduseofa

patentedsecond‐generationinfrared(Gen2IR™)andactive‐RFIDtechnology.

Battery‐poweredMonitorstransmitauniqueroomnumberusingGen2IRwhich

isreceivedbyanytaginthatroom.Thetagcommunicatestheroomnumber

anditsownuniqueIDviaRFtotheCenTrak LocationServerusingahospital’s

existingwiredorWi‐Finetwork,whereitcanbeaccessedinreal‐timeby

hospitalpersonnelandintegratedwiththirdpartysolutionproviders.

Similartolight,Gen2IRwillnotpassthroughwallsanddoesnotsufferfrom

traditionalinfraredline‐of‐sightlimitations.Therefore,whenatagreadsaroom

number,therearenoerrors.Thisiscertainty‐basedRTLS.Unlikeestimation‐

basedinformation,certaintybasedlocationdatacanbeusedbyhospitalsto

makeimportantimprovementstoprocessflowandautomatedecisionmaking.

Mosthealthcareworkflowimprovementscanonlyberealizedwhenthelocation

dataiscertainty‐based.

*IT‐744andIT‐744EareforusewiththeCenTrak 2.0system.OrderIT‐741

forusewith1.0system.

©CenTrak 2012.AllRightsReserved.ProprietaryandConfidential.8/12

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

CenTrak StaffBadgeIT‐744&IT‐744E*

TechnicalSpecifications

Operation

FCCOperatingFrequencyRange 902‐928MHz

CEOperatingFrequencyRange 868‐870MHz

LowFrequency Sensor(125KHz) Optional (IT‐744E only)

Groupcode&tagIDcodes 8Mcodes

Outdoortransmissionrange >300feet

Averagetransmissionpower 2uW (average)

Smarttagfeatures 3 buttons,LED,lowbattery,audiblealarms

MotionSensor YES

Mounting/AttachmentOptions

Loop(portrait orlandscape) Fitsstandardemployeebadgemounting

Lanyard (optional)

TagDimensions

Caselength 3.40in(86mm)

Caseheight 2.125in(55mm)

Casewidth 0.15in(3.8mm)

Caseweight (withbattery).90 oz (25.5g)

Construction ABS&PolyCarbonatemixture

Environmental

OperatingTemperature 0Cto+70C

Storagetemperature ‐25Cto+80C

Sealing Splashresistant

Power

Batterytype LithiumCR@325x2replaceablepack

Smarttagfeature Lowbatteryindication

Cleaning

Tagcleaningmethod WipeCleaningMethodOnly.SeeCenTrak

TagDisinfectionGuide forInstructions

Note:MustuseCenTrak Disinfectionprocedure.Othermethodsmayvoidproductwarranty.

*IT‐744andIT‐744EareforusewiththeCenTrak 2.0system.OrderIT‐741forusewith1.0system.

Thiscomponentcomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:1)Thedevicemaynotcauseharmful

interference,and2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycasesundesiredoperation.Modifyingor

tamperingwiththetransceiver’sorreceiver’sinternalcomponentscancauseamalfunction,invalidatethewarranty,andwill voidFCCauthorizationto

usetheseproducts.ThisproductoritssystemsarecoveredbyoneormoreofthefollowingU.S.patents:5,917,425,7,061,428,7,378,964,7,619,532.

L‘utilisationdecedispositifestautoriséeseulementauxconditionssuivantes:(1)ilnedoitpasproduiredebrouillage et (2)l’utilisateurdudispositif

doitétre prêtàacceptertoutbrouillageradioélectriquereçu,mêmesicebrouillageestsusceptibledecompromettrelefonctionnement dudispositif.

Attachmentclipsareavailable

ITA‐763 (topimageshownwithbadge)

ITA‐766 (bottomimageabove)
